Schimpf GmbH

Condition: new, Year of construction: 2025, Vacuum lifter for glass GLASS SYSTEM DS600C Device dedicated for window production and narrow glazing Lifter features • Equipped with suction pad covers. • Individual adjustment of each suction pad on the Y-axis • Manual control – vacuum suction/release • Smooth manual rotation around its own axis by 45 degrees • Smooth adjustment from vertical to horizontal position • Easy suction pad configuration without tools • Power supply: 230V Cedpoxqfwyefx Ah Ujri • Own weight: approx. 80 kg • Lifting capacity: 200 kg • 3 suction pads Ø 250 • CE certified

Condition: new, Year of construction: 2025, functionality: fully functional, total height: 4,000 mm, overall weight: 820 kg, load capacity: 500 kg, The offer includes the following set: (it is possible to customize device parameters or purchase the vacuum lifter or crane separately) - Vacuum lifter for boards, designed among others for MDF, laminated, raw and chipboard panels, etc. (model WOOD SYSTEM DS 250) - Stationary jib crane - Electric chain hoist - Manual trolley Features of the WOOD SYSTEM DS 250 vacuum lifter: - Designed for panel handling - Actuator for vertical-horizontal rotation - Six suction pads, Ø 200 mm - Adjustable suction pad positioning to adapt to varying panel dimensions - Traverse length: 2500 mm - Each suction pad equipped with a ball valve – allowing individual suction pad control - Compressed air pulse function to prevent material stickiness effect - Individual adjustment of each suction pad in X and Y axes - Gripper control via console (control panel): - Aggregator on/off - Vacuum suction/release - Electric hoist thumb control – raising/lowering the lifter - Manometer - Powered by compressed air – fitted with vacuum generators - Lifting capacity: 400 kg - Device weight: 100 kg - CE certificate Stationary jib crane – technical data: • Column height: 4 m Crodpfxsxln Drj Ah Uji • Height under jib: 4 m • Jib length: 4 m • Lifting capacity: 400 kg • Slew range: 270 degrees • Lifting speed: approx. 3 m/min • Any RAL color available • Manual rotation • Manual trolley • Quadruple / double needle bearing for easy swing • Chain hoist: electric • CE certificate INCLUDED IN PRICE: • Column-mounted jib crane • 1-phase electric hoist • Manual trolley • CE certificate • Complete documentation Standard warranty: 12 months

Condition: excellent (used), Year of construction: 2018, functionality: fully functional, We are offering a column manipulator from Zeilhofer here. This is the 'Mirus 80' model, year of manufacture 2018. The manipulator has a dead weight of 280 kg and a load capacity of 13 kg. Rotation of the main axis is 360º. Documentation is available. The manipulator functioned flawlessly until it was dismantled. It was only in use for a short period during trials. We consider its condition to be like new. Cedpoxgd Uvefx Ah Usri

Condition: good (used), Year of construction: 2020, operating hours: 200 h, functionality: fully functional, total height: 4,820 mm, total width: 15,000 mm, total length: 20,000 mm, type of input current: AC, input voltage: 400 V, SOCO SYSTEM End-of-Line Packaging Line with Robotic Palletizer, Carton Erectors & Sealers (Year of manufacture: 2020) This offer includes our complete SOCO SYSTEM shipping and end-of-line packaging line, exactly as installed in our facility. The system is fully operational, well-maintained, and was used until recently for pallet dispatch. This line is ideal for companies with high shipping or packaging volumes that value automated, efficient, and modular packaging processes. The system can be taken over in full or in part – we are happy to advise you on the optimal configuration. Technical Equipment / Components - 2 x Carton Erectors BE-2300 ATS and BE-2200 ATS Automatic carton erectors for folding and sealing bottom flaps (self-adhesive tape, width = 50 mm). - Long Flap Spreader For precise feeding and alignment of cartons onto the main conveyor line. - Powered Conveyors & Labelling Sections Roller conveyors, curves, and distribution lines with integrated label transport. - Carton Sealer T-4000 with Tape Alarm Automated top carton sealing with self-adhesive tape. - Labeller LOGOPAK Logomatik 415-T (integration ready) Transfers cartons for automatic labelling and verification via scanner. - Palletizing Robot SOCO PRS-LRS-1218-H3 Industrial robot for fully automated palletizing according to customer-specific patterns. - Pallet magazine for 14 pallets Automatic provision of empty pallets. - Safety Features: Swing doors / light curtains, emergency stop interlinking, Type 2 control, controller, CE certification. - Additional Modules: T-55 with conveyor system and ball table, F-100 + T-2000 conveyor system, RAL 9006 special colour. Complete assembly, factory testing, installation, and commissioning included (original system price according to SOCO SYSTEM offer: €243,700). Csdpfjxdb Saex Ah Ujri Function Description The line automatically erects cartons, seals the bottoms, conveys them on the main packaging conveyor, closes and seals the tops, labels and inspects them. Error-free cartons are then picked up by the robotic palletizer and stacked according to defined pallet layouts. The entire system is modular and can be integrated into existing production or shipping operations. General Information Year of manufacture: 2020 Manufacturer: SOCO SYSTEM A/S Condition: used / very good / immediately operational Location: Norderstedt (near Hamburg) Scope of delivery: complete shipping line including robot, sealer, and conveyor technology.

Condition: like new (used), Smart robot operation in harsh industrial environments Our teach pendants set your robot in motion and open up almost unlimited application options. With their intuitive operator control, they allow even complex tasks to be solved quickly and precisely – without programming knowledge. They also guarantee safe control in demanding environments. The application options are clearly displayed on the display of the KUKA teach pendant as well as on your own device, so that you can get started directly as an operator. Used for KRC4 controller. Credpow Rl Tvofx Ah Uoi

Condition: new, Year of construction: 2025, This handling device is suitable for safely and stably handling large-area materials with just one operator. The device can be provided as an independent unit to any machine. The price-performance ratio is impressive, as the payback period is less than one year. Comprises the following main components (also available individually): • Column stand • Pivot arm • Lifting traverse with controls Technical data VT 1000: Lifting capacity: 1000 kg Max. lifting height: 1295 mm Lifting speed: 4 and 8 m/min Max. rotation radius: 3900 mm Crodsw Nh Dzopfx Ah Uei Power supply: 400 V / 50 Hz Max. product dimensions: 4000 x 2000 mm² (weight dependent) Overall height: 2990 mm Total weight: 1350 kg Alternatively, we also offer this handling device with a lifting capacity of 500 kg.

Condition: excellent (used), Year of construction: 2022, operating hours: 1,619 h, functionality: fully functional, machine/vehicle number: PEC 50 2158273, total height: 3,000 mm, total width: 1,000 mm, total length: 1,000 mm, type of input current: three-phase, input voltage: 400 V, Arm-mounted manipulator with a gripper for cylindrical parts. Cjdpfxow Hwq To Ah Ujri

Condition: new, Year of construction: 2025, operating hours: 1 h, functionality: fully functional, overall weight: 110 kg, Vacuum Lifter GLASS SYSTEM DS600 L Vacuum lifter for installation of large glass panes, shopfronts, and for glass transport. Thanks to its design, it allows for the installation of long, narrow panes as well as standard sizes. Specification: LIFTING CAPACITY – 450 kg CONTROL – radio remote control POWER SUPPLY – battery powered (up to 12 hours operation) BATTERY CHARGE INDICATOR – yes VERTICAL-HORIZONTAL ROTATION – yes AXIAL ROTATION – yes NUMBER OF SUCTION PADS – 4 NUMBER OF ARMS — HST GLASS LIFTING CAPABILITY – no GLASS SIZE – min. 0.3 x 1.5 m, max. 3 x 4.5 m NUMBER OF CIRCUITS – 2 ACTUATOR FOR ROTATION OPTION – yes MACHINE WEIGHT – 110 kg Lifting capacity can be increased to 650 kg and additional suction pads can be supplied at extra cost. Machine customization to individual requirements and purchase with a crane are available. Check our offer or contact us – we will surely find a solution tailored to your company’s needs! Crjdpfx Ahsw Hq I Ej Uji

Condition: new, Year of construction: 2025, operating hours: 1 h, functionality: fully functional, overall weight: 62 kg, Vacuum lifter designed for handling black steel, stainless steel, and other sheet metal. The device can be optionally equipped with a compressed air impulse system for easy sheet release. It is compatible with all types of cranes and overhead hoists. Sample specification: Lifting capacity – 600 kg Power supply – Permanent 230V Working position – Horizontal Number of suction cups – DS.250-8 Minimum working area dimensions – 0.6m x 0.4m Maximum working area dimensions – 1.5m x 3.0m Compressed air impulse – Optional upgrade Device weight – 62 kg Credpfxow Eltto Ah Uji The listed price applies to the machine with the above parameters. Custom configuration – available upon request.

Condition: ready for operation (used), Year of construction: 2000, A total of three conveyor belts (transport modules) are available for the PCB industry. 1) Three-segment conveyor belt with buffer module Asys FPS 30, year of manufacture: 1996. 2) Transport module Rommel SM 600 T. 3) Transport module Rommel BM 500 S, year of manufacture: 2000. Documentation available. On-site inspection is possible. Credpfxswzlfuj Ah Uoi

Condition: good (used), overall weight: 280 kg, FANUC positioner. manufactured in 2012. tested and serviced. Credpfxjwzk Sye Ah Uji collection only

Condition: new, Year of construction: 2025, operating hours: 1 h, functionality: fully functional, machine/vehicle number: 600, overall weight: 60 kg, warranty duration: 12 months, GLASS SYSTEM DS600 MINI VACUUM LIFTER For facade installation, glass window assembly, and glass transportation. Device size optimized for operation between façades and scaffolding. Technical specifications Lifting capacity: Maximum lifting capacity: 350 kg Control system: Radio remote control (remote range up to 200 m) Battery charge indicator: Yes Power supply: Battery-powered, up to 12 hours of operation Construction: Number of suction cups: 4 Number of circuits: 1 Number of arms: — Credpswzafpjfx Ah Usi Device weight: 60 kg Movement capabilities: Vertical/horizontal rotation: No Rotation around own axis: No Option to use rotation actuator: No Supported material dimensions: Minimum: 0.8 x 0.8 m Maximum: 2.5 x 2.5 m Ability to lift HST glazing: No Compatibility: For use with cranes and HDS (truck-mounted cranes) Flexible device configuration – can be tailored to individual customer needs

Condition: ready for operation (used), Year of construction: 2019, A conveyor belt is available for buffering and transferring PCBs between processing systems. Transport height: 870mm-970mm, max. transport width: 460mm, min. PCB dimensions X/Y: 70mm/50mm, max. PCB dimensions X/Y: 460mm/460mm, PCB thickness: 0.5mm-4.5mm, max. PCB weight: 3kg. Machine dimensions X/Y/Z: approx. 1590mm/800mm/925mm, weight: approx. 170kg. Documentation available. On-site inspection is possible. Crodpfx Ahowwvvvs Uji

Condition: excellent (used), Year of construction: 2005, Industrial manipulators (2 units) Mounting: ceiling-mounted Ceiling guide length: approx. 15 meters Number of axes: 4 Load capacity: Manipulator 1: 30 kg Manipulator 2: 35 kg Gripper: pneumatic part gripper (for each manipulator) Codpfx Aswvi Upeh Uori Year of manufacture: 2005

Condition: new, Year of construction: 2025, functionality: fully functional, machine/vehicle number: DS550 CA, overall weight: 50 kg, load capacity: 400 kg, VACUUM LIFTER PANEL SYSTEM DS550 CA Compact vacuum device for sandwich panels, ideal for wall installation. Its construction allows it to fit even in the trunk of a passenger car. The lifter is additionally equipped with a rotator, enabling 360° rotation of the panel. Available with radio control, manual operation, and a single-circuit version. Weight of the device: 50 kg Lifting capacity: 400 kg Control - radio/manual Power supply - external battery (DeWalt - one included, with charger) Battery charge indicator: Yes Cedjwutibspfx Ah Uori Mounting position: vertical/horizontal Vertical wall mounting: Yes Number of suction pads: 1 Material length: 1-8 m

Condition: ready for operation (used), A vacuum lifting beam including a small sanding unit and a motor is available. Year of construction: 1994, load capacity: 10000kg, dead weight: 3000kg. Engine: Hatz 3L40C and sanding station: Hommel. On-site inspection is possible. Credswt Tkpopfx Ah Usi

Condition: ready for operation (used), A DMG Automation robot automation cell is available. Interior dimensions X/Y: approx. 700mm/1050mm, max. workpiece weight: 10kg, max. workpiece dimensions X/Y: 150mm/120mm, positioning accuracy: +/-0.1mm, robot axes: 6, robot controller: Kuka KR C 2. Documentation available. On-site inspection is possible. Codpfowixzxjx Ah Ujri

Condition: ready for operation (used), Year of construction: 2018, A Nutek PCB turning station with pneumatic lifting and turning mechanism for the semiconductor industry is available. Transfer height: 950mm, transfer height adjustment: +/-25mm, belt speed range: 2m-14m/min, PCB edge support: 3mm, component clearance (bypass mode) top/bottom: 30mm/30mm, PCB length range: 80mm-460mm, PCB width range: 75mm-460mm, machine dimensions X/Y/Z: approx. 1000mm/900mm/1100mm, weight: approx. 150kg. Documentation available. On-site inspection is possible. Codpfx Aswhfnpeh Uori

Condition: ready for operation (used), Year of construction: 2007, A PCB destacker (PCB feeder) for the semiconductor industry is available. Transfer height: 950mm, transfer height adjustment: +/-25mm, belt speed: 12m/min, PCB edge support: 3mm, component clearance (bypass mode) top/bottom: 30mm/30mm, PCB thickness range: 0.6mm-4mm, PCB length range: 80mm-460mm, PCB width range: 75mm-460mm, max. PCB stacking height: 220mm, machine dimensions X/Y/Z: approx. 700mm/1000mm/1300mm, weight: approx. 200kg. Documentation available. On-site inspection is possible. Crjdowhfniopfx Ah Uei

Condition: like new (used), Year of construction: 2022, operating hours: 5 h, functionality: fully functional, machine/vehicle number: 2260081, load capacity: 400 kg, Hello, I have this fully pneumatic DELMEC remote arm, which can lift and move up to 400 kg with one hand. Csdewcpl Uepfx Ah Ujri The machine has been used very little; it's a showroom model. The machine is complete and in perfect working order. It can be sold as is, delivered, and even installed (to be determined together).

Condition: new, Year of construction: 2025, functionality: fully functional, machine/vehicle number: KAP1, air demand: 16,000 m³/h, power: 36 kW (48.95 HP), suction capacity: 16,000 m³/h, Equipment: cabin, Dielectric automatic powder booth KAP1 Price: PLN 492,693.30 + VAT Electrical and energy data • Voltage: 400 V (3P + N + PE) • Power connection: 36.34 kW • Pneumatic connection: 1" • Air pressure: min. 6 bar • Air quality: oil < 0.1 mg/m³, water vapor < 1.3 g/m³ • Air consumption: 1710 Nl/min (operation) • Compressor: SC-30 • Air tank: 1800 L Painting parameters • Painting speed: 1933 mm/min • Part dimensions: 800 x 1800 mm • Hanger height: 500 mm • Coating thickness: 100 µM • Gun array: vertical Technical data and configuration • Design: dielectric plastic • Passage dimensions: 1000 x 2400 mm • Air flow: 12348–16000 m³/h • Powder center: ProfiCenter CP02 • Manipulators: 2 pcs. • Guns: 8 automatic, 2 manual (ProfiSpray) • Part detection: yes (height, width) • Systems: cyclone separator, ProfiControl, beam pulling • ATEX: zone 22, II 3D Cjdpfjv Rpx Ssx Ah Ueri Platforms and cabin body • Platforms: entry, exit, stainless steel floor, anti-slip stairs • Housing: dielectric plastic, LED lighting, slots for manipulators Air knives and suction channel • Automatic floor cleaning • Suction channel with pneumatic flap Gun blow-off and control • Automatic blow-off guns • 10" touch panel, 50 programs, manipulator control, dust extractor, drive speed X-axis and part pulling system • Automatic gun setting • Part pulling: speed 570–2830 mm/min, 2 pullers The machine also includes: • ProfiSpray A applicator • PSS-1 controller • PM-1 guns • ProfiCenter CP-02 powder center • CK-D1400L cyclone dust extractor • MA1-180 manipulator and MX1-10 X-axis • OZ-12H dust extractor • ProfiControl 10" control • BP-H2000 W900 part measuring system

Condition: good (used), Year of construction: 2009, Stäubli t TX90 L with Controller CS8C. (2009) Number of axis: 6 Cedpfsv Hdk Isx Ah Ueri Payload: 5 kg

Condition: ready for operation (used), Year of construction: 2008, A stacker and destacker cutter for the PCB industry is available. 1) Stacker for slotted cassettes Kuttler SUE 50, year of construction: 2008, running direction: right-left, operating hours (plate counter): 2.8 million, weight: approx. 800 kg. 2) Single stacker for slotted cassettes Kuttler RLE 160, year of manufacture: 2004, with conveyor belt CO 800, year of manufacture: 2008, running direction: right-left, operating hours (plate counter): 5.4 million. The system is missing cylinders and brackets for automatic format adjustment. Documentation available. On-site inspection is possible. Crsdpfx Ahsv Daggs Uji

Condition: excellent (used), Year of construction: 2014, Vacuum unit for e.g. manipulator, Dalmec - used - : Price (net), ex location: only €995 Manufacturer: dalmec Type: vacuum lifter Year of manufacture: 2014 Code: 85.16.0991 Load capacity: 7kg. Operating pressure: 0.60Mpa With this unit, plastic stacking boxes with external dimensions (LxWxH): 1,190 x 610 x 420mm filled with cable harnesses were lifted (see photos below) Cedpfsvzli Ijx Ah Ujri Condition: very good Available: immediately Location: Emden, later warehouse Frankenberg / Saxony

Condition: used, Year of construction: 2014, Type: IRB 6640 M2004 Variant: IRB 6640-130/3,2 Year: 2014 The ABB IRB 6640-130/3.2 robot is a 6-axis robot arm, it has a payload of 130 kg and a reach of 3200 mm. Manufacturing applications include Finishing. Codpfxevwb Irs Ah Ujri Machine has Pendant + Elektrobox / however it was used in Line there the box is maybe needs some adjustment for working alone. Weight ca: 1340 kg
