Condition: used, Year of construction: 2007, functionality: fully functional, type of input current: three-phase, Glass laminating oven with vacuum mat (bag oven), manufacturer SIMTECH (Belgium), Flexlam series – Glass Laminating Solutions. Manufacturer: SIMTECH (Belgium) Fsdozqmhaepfx Apwogf Model: Flexlam Laminating Oven Electrical panel: Alfametal / Dynamics, Project No. 0467 Year of manufacture: December 2007 Power supply: 3 x 400V AC + PE, 50Hz Network: TN-S, Icc < 10kA Control panel: Allen-Bradley PanelView 300 Micro Controls: Cycle Start/Stop, Vacuum Start, Reset, Emergency Stop Vacuum system: Dedicated vacuum pump, vacuum mat/bag Signaling: Signal tower (End of Cycle / Alarm-Fault / In Process)

Condition: used, Year of construction: 2009, 3520 kW Operating weight max. 120.000 ca. 55.000 kg Unladen weight of the kiln car ca. 40.000 Usable dimensions 4000x1500x10500 Clear dimensions 5.000 x 2.575 x 11.275 External dimensions 7.100 x 7.245 (mit Türpor 550 – 1.100 °C Max. permissible oven chamber temperature 1.150 Safety cut-off temperature 1.180 Complete System – Industrial Heat Treatment Line with 6 Identical Bogie Hearth Furnaces and Quenching System For sale is a complete industrial heat treatment system consisting of 6 identical bogie hearth furnaces type HW150-3520-1100, including an integrated quenching system and complete central plant equipment. Fodezpbmbspfx Apwjgf The offered system represents a fully coordinated industrial production solution for demanding thermal processing applications. All six bogie hearth furnaces are of identical design, ensuring consistent process conditions, high operational availability, and excellent interchangeability of components. The complete system includes not only the six high-performance bogie hearth furnaces but also the required central plant components and auxiliary systems, including burner systems, combustion air supply, exhaust gas extraction, temperature control and monitoring systems, as well as the complete furnace and bogie equipment. With a rated heating capacity of 3,520 kW per furnace, an operating temperature range of up to 1,100 °C, and a maximum load capacity of up to 120,000 kg per furnace, this system provides a powerful solution for large-scale industrial heat treatment processes. The combination of six identical furnace units together with the integrated quenching section offers: High production capacity through parallel operation of multiple furnace units Reliable and repeatable heat treatment processes Flexible handling of different charge sizes Centralized and coordinated plant utilities Robust industrial design for continuous production environments The system is offered as a complete turnkey heat treatment solution and provides an immediately deployable production platform for industrial applications requiring high capacity, process reliability, and consistent thermal treatment results. Technical Data 7.1 Furnace Housing Dimensions External dimensions1: 7,100 x 7,245 (incl. door portal) x 12,745 mm Clear dimensions: 5,000 x 2,575 x 11,275 mm Usable dimensions: 4,000 x 1,500 x 10,500 mm Workpiece supports: 6 units, height 475 x 340 mm 7.2 Weights Empty weight of housing: approx. 55,000 kg Empty weight of hearth car: approx. 40,000 kg Operating weight: max. 120,000 kg Weight of supports: 6 units at 5,083 kg each = 30,500 kg 7.3 Performance Data Nominal heating capacity: 3,520 kW Temperature control range: 550 – 1,100°C Max. permissible furnace chamber temperature: 1,150°C Safety cut-off temperature: 1,180°C Heating rate: max. 60 K/h at 120,000 kg operating weight Max. permissible heating rate: 60 K/h Number of temperature control zones: 6 All dimensions: width x height x depth or Ø x height. Utility Supply Parameters 7.4.1 Natural Gas Calorific value Hu(n): 10.6 kWh/m³(n) Gas inlet pressure: 2.0 bar Max. volume flow: 334 m³(n)/h / 118 m³(b)/h Temperature: +5 to +25°C. 7.4.2 Combustion air Composition: Ambient air Combustion air pressure: max. 100 mbar Max. volumetric flow rate: 11,500 m³(n)/h Temperature: +5 to +40°C 7.4.3 Power supply Voltage: 400 V Mains frequency: 50 Hz Connected loa...

Condition: used, Year of construction: 2011, Industrial furnace for tempering flat glass, used in construction, for door and window glass, furniture glass, decorative glass, and certain types of coated glass. Manufacturer: SHANGHAI REFINE MACHINERY Type: RGT A-1530 Maximum glass size: 1500 x 3000 mm Minimum glass size: approx. 200 x 300 mm Fgodpfxezh Uyre Apwjf Glass thickness: 5-19 mm Output for 5 mm glass: approx. 16-18 cycles/hour Installed power: 500 kVA Compressed air pressure: >0.8 MPa Year of manufacture: 2011 Technical condition: used machine, requires technical inspection, condition as shown in the photos.

Condition: excellent (used), Year of construction: 2017, functionality: fully functional, Glass tempering furnace - Maximum glass size: 2800 x 6000 mm - Glass thickness: 3 - 19 mm - Blower system for tempering down to 3.8 mm acc. to EN 12150 and ANSI Z97.1 - BOOST315 OPTIMIZED Boost unit for tempering down to 3.15 mm acc. to EN 12150 and ANSI Z97.1 with optimized capacity and loading area HS12 + INA 2860 Fjdpfx Apozgfzkswegf - Heat strengthening system up to 12 mm acc. to EN 1863 including Low-E glass and ASTM 1048 heat strengthening up to 12 mm. - Includes independent quench nozzle height adjustment (INA) - N85 2860 Noise reduction cabin around the chiller LpA = 85 dB(A) - iLooK integrated - 28xx Integrated Online Glass Quality Measuring System control - V for FC/RC Series Additional process screen to unloading table - Cullet conveyor - Cam option (cameras & screens) - Excellent condition, very little used, fully serviced! - Available immediately

Condition: excellent (used), Year of construction: 2014, functionality: fully functional, Horizontal glass convection tempering furnace . For max. glass sizes : 1500 x 3000 mm Glass thikness : 4 - 19 mm Voltage : 400 V 50 Hz Control voltage : 230 V V AC 24 Power : Heating : 296 Kw Motors : 262 Kw Total : 558 Kw Current : Heating : 470 A Motors : 450 A Fgedpfx Asyw Hgrepwef Total : 920 A

Condition: ready for operation (used), Year of construction: 1999, functionality: fully functional, total length: 23,000 mm, type of input current: AC, number of chambers: 1, Equipment: documentation/manual, Glass tempering furnace Fjdpfx Asylaqlepwegf TAMGLASS / GLASTON, HTF-2442-CTA-10-L 2400 x 4200 mm, Left – Right Year: 1999. With convection (Low-E glass) Noise reduction cabin included. 400 V, 50 Hz, total power: 1160 kW (heating 630 kW, motors 530 kW) In good technical condition. Inspection during production is possible by appointment. Available: SEPTEMBER 2026

Condition: ready for operation (used), Year of construction: 2021, functionality: fully functional, temperature: 250 °C, power: 30 kW (40.79 HP), Curing oven with two chambers (one programmable heat cycle per chamber)! Equipped with conveyor belt and cleanroom classification! TECHNICAL DETAILS Process area (minimum): 1,700 x 1,400 mm (2.40 m²) MACHINE DETAILS Electrical Data Main power supply: 3x400 V ±5%, 50 Hz ±5% Control voltage: 230 Vac 50 Hz and 24 Vdc Main fuse: 140 A Motor Output Fgsdjyk Sd Uepfx Apwef Circulating fan motor: 2.2 kW (2 units) Drive motor for vertical transport: 0.39 kW Drive motor for horizontal transport: 0.09 kW Heating Heating type: Electric with sealed tubular elements Output: 30 kW per chamber Temperature range: 50 °C to 250 °C EQUIPMENT Conveyor system Cleanroom classification

Condition: excellent (used), Year of construction: 2006, functionality: fully functional, Glass tempering machine for thicknesses from 3.8 to 19 mm. Maximum glass dimensions: 2440 x 4500 mm. Fgodex Trg Aopfx Apwef

Condition: ready for operation (used), Year of construction: 2001, total width: 1,500 mm, total length: 3,000 mm, Glass tempering furnace 4-19 mm, loading 1.5 x 3 m, without convection, furnace is connected, machine is operational but requires improvements, on-site testing possible. Fjdpox Dy Sfsfx Apwjgf

Condition: ready for operation (used), Year of construction: 2017, functionality: fully functional, total width: 2,350 mm, total length: 6,000 mm, inner dimension length: 3,000 mm, inner dimension width: 1,600 mm, TECHNICAL DETAILS Oven dimensions: 3,000 x 1,600 mm MACHINE DETAILS External dimensions (L x W): 6,000 x 2,350 mm Firing: Gas Orientation: Vertical, for use with vacuum bags; connection to vacuum port inside oven EQUIPMENT 2 x trolleys included The following data is from a general offer; the seller accepts no liability for its accuracy. This also applies to the data sheet in the appendix. Electrical Voltage: 400 V Current: 16 A Frequency: 50 Hz Gas Type: Natural gas / Propane / LPG Connection: 1"1/4 Gas pressure: 20–60 mbar Propane/LPG consumption (4 burners): 8 kg Propane/LPG consumption (8 burners): 16 kg Natural gas consumption (4 burners): 9.6 m³ Natural gas consumption (8 burners): 19.2 m³ Temperature range (4 burners): 40–150 °C Temperature range (8 burners): 40–320 °C Power output (4 burners): 96 kW Fgsdpfexur Ndox Apwsf Power output (8 burners): 192 kW

Condition: excellent (used), Year of construction: 2006, functionality: fully functional, type of input current: AC, Equipment: documentation/manual, TAMGLASS / GLASTON HTF ProE – 2448-ADS-R 2400 x 4800 mm, 3 – 19 mm, Right – Left Glass tempering furnace (for Low-E glass) Year: 2006 Noise reduction cabin included 160 kW compressor for 3 mm glass included Fedpsxtf Dfsfx Apwogf In good condition.

Condition: used, Year of construction: 1997, functionality: fully functional, type of input current: AC, Glass tempering furnace EFCO, 1500x3000 1500 x 3000 mm, Right – Left Year: 1997. Fjdpfx Apsxguqnswogf 415 V, 50 Hz, 3 Ph. In good technical condition. Disassembled and ready for loading.

Condition: excellent (used), Year of construction: 2021, temperature: 1,000 °C, energy consumption: 10 kWh, Laboratory furnace / Glass tempering furnace Fedpfxoxcb Hno Apwjgf Max temperature: 1000°C

Condition: excellent (used), max. temperature 1200 Grad size of opening 220 x 120 mm depth of chamber 400 mm Fgjdexcbldspfx Apwef dimensions of the machine ca. 1,4 x 1,2 x 1,6 m

Condition: used, • Front side: 2 boxes for the films • 2 flaps for vacuum • Dimensions: W 2,450 x L 3,000 x H 2,650 mm • For production of double mirrors or laminated glass Fgodpfx Apewc Abvewof • Price on request

Condition: good (used), Year of construction: 2001, functionality: fully functional, type of input current: three-phase, Glass tempering furnace TAMGLASS, HTF-2136-ABT-10-R 3,8 – 19 mm, 2100 x 3600 mm, Right-Left Year: 2001. Without convection Noise reduction cabin included 400 V, 50 Hz, total power: 800 kW (heating 470 kW, motors 330 kW) Fgodpfovkhl Dex Apwsf In good technical condition. Inspection is possible by appointment.

Condition: good (used), horizontal single-chamber glass tempering system suitable for coatet glass assignable area: max. 2400 x 4200 mm Fjdpsipx Dyjfx Apwogf KW: 814,5 Dimensions: length = 22 m, width = 7 m

Condition: good (used), Glasbeek Finish Gas Chamber Furnace Type 003.05 Glasbeek finish Gas chamber furnace Type 003.05 With loading trolley Maximum temperature 200 ° C Fjdpfx Aped Spx Dewogf Approximate inside dimensions (B1900mm x T2950mm x H1800mm) Financing through our bank is also possible. komplett-konzept.leasingo.de More articles - new and used - can be found in our shop! International shipping costs on request!

Condition: good (used), Glasbeek Finish Gas Chamber Furnace Type G.11.01 Glasbeek finish Gas chamber furnace Type G.11.01 With loading trolley Maximum temperature 200 ° C BJ. 1991 3 x 380V 54 kW Approximate inside dimensions (B1900mm x T2940mm x H1965mm) Financing through our bank is also possible. komplett-konzept.leasingo.de Fedpjd Spxvofx Apwsgf More articles - new and used - can be found in our shop! International shipping costs on request!
