Condition: used, Year of construction: 2001, Brand and Model: CORREA EURO 2.000 Type: CNC Year: 2001 Cnc: HEIDENHAIN TNC- 426 Table dimensions: 2000x1000 mm T- slots: 8 x 22 mm Distance between slots: 125 mm Maximum table load: 5000 kgs X – axis travel : 2000 mm Y- axis travel : 1250 mm Z – axis travel: 650 mm Spindle head Direct exit Taper: ISO 40 Speed range : 20-10000 rpm Spindle power : 25 kw Working feed rates: 2-20000 mm/min Rapid traverse rates(X,Y,Z) : 20000 mm/min Approx. Machine weight: 14000kgs Machine dimensiones: 6500x3728x4000 mm Machine equipped with: Fgsde Aivm Ispfx Abaei Electronic handwheel : HR-410 Chip conveyor 2 Longitudinal , 1 transverse Toolt changer : ATC 24 Through-spindle cooling

Condition: good (used), Year of construction: 1999, travel distance X-axis: 3,000 mm, travel distance Y-axis: 2,500 mm, travel distance Z-axis: 1,150 mm, Control: Siemens 840 D Powerline Tool holder: HSK-A63 Max. rpm: 16,000 X-travel: 3,000 mm Y-travel: 2,500 mm Z-travel: 1,150 mm A-axis: +/- 100 mm C-axis: +/- 181.5 mm Fodpfe Ait Ndex Abajgi Table size: 3,000 mm x 2,500 mm Option: External blowing air Kinematics: Fork head

Condition: new, functionality: fully functional, travel distance X-axis: 900 mm, travel distance Y-axis: 1,200 mm, travel distance Z-axis: 150 mm, total length: 1,720 mm, total width: 1,200 mm, spindle speed (max.): 24,000 rpm, total height: 1,700 mm, type of input current: AC, overall weight: 340 kg, spindle motor power: 2,200 W, High-performance CNC milling machine Professional 1200×600 – extensively equipped Precision, stability, and versatile applications: The Professional 1200×600 is a CNC milling machine for processing wood, plastics, composite panels, and aluminum. It is suitable for milling, cutting, and engraving – ideal for prototypes, individual pieces, and small series. Extensive equipment * Work area: 1200 × 600 × 150 mm * Water-cooled 2.2 kW high-frequency spindle with ER20 collet system * 2.2 kW vacuum pump and zone-controlled vacuum table * Three powerful 9.0 Nm stepper motors * Dust extraction hood and chip extraction hose * Minimum quantity lubrication * Tool length sensor * Heat exchanger with a closed 9-liter tank * Mach3 CNC control program Stable machine construction The table made of ferritic cast iron forms a massive, vibration-damping base. Hiwin profile rail guides with 20 mm and TBI ball screw spindles ensure precise axis guidance. The rigid portal cheeks made of aluminum die casting support dynamic movements. The T-slot/vacuum table combination offers flexible options for workpiece clamping. Several vacuum zones can be switched on individually – practical for workpieces of different sizes and shapes. Control and technical data * ProControl control with Mach3 Motion Controller Version 5 * USB interface, 230 VAC power supply * Spindle speed: 0–24,000 rpm Fodj Aig Izspfx Abaegi * Positioning accuracy: ±0.02 mm/300 mm * Repeatability: ±0.03 mm * Resolution X/Y: < 0.01 mm * Machine dimensions: approx. 1720 × 1200 × 1700 mm * Net weight: approx. 340 kg A versatile CNC milling machine for everyday workshop use – from the first prototype to small series production, with a stable design, flexible workpiece clamping, and extensive equipment. Available for immediate delivery – demonstrations possible in our showroom.

Condition: good (used), Machine parameters: Travel in X, Y, and Z axes: 1200, 800, 500 mm Description: The machine is in good technical condition; testing is possible upon prior arrangement. CONTROL SYSTEM: HEIDENHAIN iTNC 530. Fjdpfxo Aibuzs Abaegi

Condition: good (used), Year of construction: 2003, FOOKE ENDURA 83.1 Portal Milling Machine The FOOKE ENDURA 83.1 is a 5-axis CNC portal milling machine with three linear axes (X, Y, Z) and two rotary axes (A, C). The clamping surface consists of two machine tables, each measuring 3,200 mm x 1,000 mm. An additional, brand-new spindle unit from the manufacturer SPL is included in the scope of supply. Year of manufacture: 2003 Control system: SIEMENS SINUMERIK 840D Travel distances: X - 3,500 mm / Y - 2,500 mm / Z - 1,200 mm A - ± 120° / C - 365° Rapid traverse rate of X/Y/Z axes up to 20 m/min Rotational speed of A/C axes up to 15 rpm Equipment: Spindle HSK 63A, manufacturer SPL, type/DRF-FO-180M-W-16-34 with 34 kW up to 16,000 rpm. Tool changer for 20 tools / diameter up to 100 mm Internal coolant supply (IKZ) up to 30 bar Spindle cooling Paper band filter system KNOLL Articulated band chip conveyor KNOLL Automatic doors Full enclosure Electronic handwheel Machine table elements Machine parameters on USB stick Operating manual/documentation Additionally included in the scope of supply: a brand-new spindle unit from the manufacturer SPL. Technical data and equipment – see PDF. All technical specifications, images, and content are non-binding and without guarantee. Subject to change and errors. All other accessories visible in the photos and video are not included in the scope of supply and are therefore not part of this sale. The scope of supply only includes the accessories that are explicitly listed here, in the order confirmation, and in the invoice. EXW D-46446 Emmerich, Germany (Incoterms® 2020) Fedpfxs Ahm N Ds Abajgi excluding dismantling, removal, and loading Delivery time: immediately, subject to prior sale Payment: 100% advance payment upon order placement

Condition: good (used), Year of construction: 2004, Ref. -No.: 10634 Manufacturer: ANAYAK Type: P 3200 Year of construction: 2004 Type of control: CNC-Steuerung Control: Heidenhain Storage location: Halberstadt Country of origin: Germany Fgodpfx As Ahmvqebaji X-Travel: 3200 mm Y-Travel: 1400 mm Z-Travel: 750 mm Table-Size (Lxw): 3200 x 1400 mm spindle running time: 23.291 H Control: 83.301 H machine: 73.907 H Program run: 27.807 H

Condition: good (used), Year of construction: 2004, functionality: fully functional, travel distance X-axis: 3,750 mm, travel distance Y-axis: 1,870 mm, travel distance Z-axis: 700 mm, spindle speed (max.): 6,000 rpm, overall weight: 30,000 kg, Equipment: rotational speed infinitely variable, X-axis: 3.750 mm Fgjdpfxo Ahfn Ro Abaji Y-axis: 1.870 mm Z-axis: 700 mm CNC Controller: Heidenhain iTNC 530 Spindle nose: ISO 50 Spindle speed: 6.000 Rpm Toolchanger: 30 pockets Table size: 4.000 x 1.650 mm Distance between columns: 2.100 mm Featured with: - Vertical milling head attachement - Touch probe - Cooling throught spindle - Double chip conveyor - Cooling unit - Machine manuals Country of origin: Taiwan Machine LxWxH: 9000 x 3500 x 4000 mm +/- Machine weight: 30.000 kg

Condition: used, Year of construction: 1994, travel distance X-axis: 2,500 mm, travel distance Y-axis: 2,000 mm, travel distance Z-axis: 800 mm, total length: 7,435 mm, table length: 3,000 mm, table width: 1,250 mm, total width: 3,587 mm, spindle speed (max.): 3,000 rpm, total height: 4,845 mm, rapid traverse X-axis: 12 m/min, rapid traverse Y-axis: 12 m/min, rapid traverse Z-axis: 15 m/min, distance between stands: 1,740 mm, type of input current: three-phase, table load: 10,000 kg, position of the milling head: Acodado a 90°, indexable cada 2,5°, workpiece weight (max.): 10,000 kg, torque: 725 Nm, overall weight: 25,500 kg, spindle nose: ISO 50 / BT 50, spindle motor power: 30,000 W, Equipment: rotational speed infinitely variable, Nicolás Correa FP 30/30 portal milling machine with a moving table, manufactured in 1994. Heidenhain TNC 426 numerical control with a mobile console and portable handwheel HR. Work table of 3,000 × 1,250 mm with 7 T-slots of 22 mm and a maximum allowable load of 10,000 kg. Travels of 2,500 mm on the X-axis, 2,000 mm on the Y-axis, and 800 mm on the Z-axis. Column spacing of 1,740 mm. Fsdpfxs Agm Idj Abaegi 90° swiveling head with automatic indexing every 2.5° and hydraulic tool clamping, ISO 50 / BT 50 taper. Power of 30 kW, maximum torque of 725 Nm, and spindle speed of 3,000 rpm. Automatic tool changer system. ATC tool magazine with 60 positions. Rapid traverse rates of 15 m/min on the X-axis and 12 m/min on the Y and Z axes. Weight of 25,500 kg. Dimensions of 7,435 × 3,587 × 4,845 mm.

Condition: used, travel distance X-axis: 9,000 mm, table length: 2,800 mm, table width: 8,000 mm, table load: 64,000 kg, TECHNICAL DETAILS Longitudinal travel: 9,000 mm Transverse travel: 2,950 mm Vertical travel: 1,250 + 2,200 mm Fgsdpe Agftiofx Abaei Rapid traverse rates for longitudinal/transverse/vertical axes: 3 / 3 / 2 m/min Table size: 2,800 × 8,000 mm Table division: 5,000 + 3,000 mm Permissible table load: max. 64,000 kg Spindle speed: 20–600 rpm Spindle motor power: 100 kW Spindle torque: 13,000 Nm Spindle mounting: ISO 60 Distance between columns: 3,200 mm Distance from spindle nose to table: 2,806 mm MACHINE DETAILS Overall dimensions: 21,000 × 7,800 × 6,650 mm EQUIPMENT 90° head Compact 90° head Vertical extension Swiveling head 3-stage gearbox Note: The machine is in good condition. However, an overhaul may be necessary.

Condition: used, Year of construction: 2001, machine/vehicle number: .01720, with CNC control, manufactured by FIDIA, type: C20, travel ranges: X-axis: 2400 mm, Y-axis: 2850 mm, Z-axis: 1000 mm, with automatic tool changer with 20 tool stations, with T-slot clamping plate, size: approx. 2000 x 1800 mm, coolant system. Fgjdo Af Nlmspfx Abasi

Condition: used, functionality: unexamined, travel distance X-axis: 2,400 mm, travel distance Y-axis: 1,200 mm, travel distance Z-axis: 130 mm, total length: 3,070 mm, table length: 2,800 mm, table width: 1,340 mm, total width: 1,800 mm, spindle speed (max.): 30,000 rpm, total height: 1,420 mm, overall weight: 500 kg, spindle motor power: 2,200 W, controller manufacturer: CNC-STEP (KinetiC-NC), number of axes: 3, Equipment: documentation/manual, We are selling our CNC portal milling machine, CNC-STEP High-Z T-Rex S-1224, with extensive equipment. The machine was purchased new in 2019 (total investment approximately €39,900 net) and is suitable for milling and engraving aluminum, plastic, and wood. Condition: The machine is generally functional. However, after being transported to its current location, it has not been fully reassembled and connected, so its functionality cannot currently be tested. An inspection is possible, but a test run under power is not. Technical data: - Travel distances: X 2,400 mm / Y 1,200 mm / Z 130 mm - Clamping area: 2,800 x 1,340 mm Fgedpj Af Ifzefx Abaei - Drive: 3 brushless stepper motors, ball screw spindles on all axes - Linear guides HIWIN/THK on all axes - Rapid traverse max. approx. 12,000 mm/min, working speed max. approx. 8,000 mm/min - Repeatability approx. 0.01 mm - Overall dimensions approx. 3,070 x 1,800 x 1,420 mm, weight approx. 500 kg Equipment: - High-frequency spindle Mechatron ATC-8022-30: 2.2 kW, 30,000 rpm, HSK25/ER16, pneumatic, with control cabinet and frequency inverter - 5 tool holders HSK-E-25-ER16, collet set ER16 - Tool length sensor - Vacuum table covering the entire area (MDF), 2 side channel blowers each 4 kW (high voltage) - Minimum quantity lubrication - T-slot table - KinetiC-NC control system with wireless remote control, emergency stop - Control laptop (ASUS) included - CAM software VCarve Pro - Operating manuals and wiring diagrams Without automatic tool changer. Notes: - Inspection possible by arrangement (not under power) - Disassembly and transport by the buyer, we will assist with the forklift during loading - Sale excludes any warranty - Invoice with VAT shown

Condition: excellent (used), Year of construction: 2015, First commissioning: 2015 Control system: Heidenhain iTNC 530 HSCI incl. handwheel HR 520 Machine hours Machine operating hours: approx. 78,000 h Spindle hours: approx. 22,000 h Spindle hours of current milling spindle: approx. 250 h X-axis: approx. 2,500 mm Fgsdpfx Abo Adtq Soasi Y-axis: approx. 3,000 mm Z-axis: approx. 1,250 mm A-axis: ± 110° C-axis: ± 300° Clamping table Clamping area: approx. 2,500 x 3,250 x 600 mm 2-axis milling head VH30 Spindle power: 60 kW Spindle speed: max. 22,000 min-1 Torque: 95 Nm Tool holder: HSK 63A Tool clamping: hydraulic Coolant supply: external and internal Drives for linear axes Feed rate X/Y/Z-axis: up to 60 m/min Axis acceleration X/Y/Z-axis: up to 5 m/s² Connection data Connected power: 190 kVa Fuse rating: approx. 315 A Dimensions, weights Space requirement machine with peripherals: approx. 10,000 x 7,000 x 5,700 mm Total weight: approx. 63,000 kg Color Enclosure, portal, control cabinet: RAL 7035 light gray Milling head and applications: RAL 6038 bright green Additional equipment - Coolant supply with belt filter system - 50-position chain-type tool changer - Work area cover - Chip conveyor - Keller oil mist extraction system Optional, at extra cost: - Renishaw RMP60 wireless measuring probe - BLUM Control NT Condition of the machine Fully functional, very good condition, and can still be inspected while running! More pictures available upon request!

Condition: good (used), Year of construction: 2006, functionality: fully functional, Overhauled: 2014 Control system: Heidenhain iTNC 530 Table: 10,000 x 3,000 mm X-axis travel: 10,000 mm Y-axis travel: 4,200 mm Z-axis travel: 1,100 mm Distance between columns: 3,500 mm Distance between table and spindle (without head): 2,000 mm Distance between table and 45° head: 1,298 mm Table load capacity: max. 30,000 kg Rapid traverse rate: 10 m/min Feed rates: 6 m/min Spindle speed: 3,000 RPM Spindle power: 40 kW Fodpfxo Adn Rgj Abasgi 3 heads: 1. Vertical, integrated, 2. Universal orthogonal head 1°, 3. Universal twist head

Condition: ready for operation (used), Year of construction: 2001, travel distance X-axis: 3,000 mm, travel distance Y-axis: 1,970 mm, travel distance Z-axis: 920 mm, controller manufacturer: FANUC, table load: 6,500 kg, overall weight: 37,000 kg, spindle speed (max.): 6,000 rpm, spindle motor power: 22,000 W, number of axes: 3, This 3-axis HARTFORD HB-3190 was manufactured in 2001. It features an impressive X-axis travel of 3,000 mm, Y-axis travel of 1,970 mm, and Z-axis travel of 920 mm. The machine includes a robust table size of 3,100 × 1,800 mm and a maximum table load of approximately 6,500 kg. If you are looking to get high-quality machining capabilities, consider the HARTFORD HB-3190 horizontal machining centre we have for sale. Contact us for further details. • Table size: 3,100 × 1,800 mm Fgedj Abbdhepfx Abaji • CNC control: FANUC 18i or FANUC 21i (depending on configuration) • Spindle type: Gear-driven • Tool magazine capacity: 32–42 tools • Distance between columns: approx. 2,200 mm • Rapid traverse rate: approx. 10,000 mm/min Technical Specification Taper Size BT 50

Condition: ready for operation (used), Year of construction: 2003, travel distance X-axis: 4,000 mm, travel distance Y-axis: 2,500 mm, travel distance Z-axis: 760 mm, spindle speed (max.): 8,000 rpm, table load: 15,000 kg, overall weight: 40,000 kg, spindle motor power: 26,000 W, controller manufacturer: FANUC, number of slots in tool magazine: 32, number of axes: 3, This 3-axis AWEA LP4025 gantry milling machine was manufactured in 2003. It features an impressive X-axis travel of 4,000 mm, Y-axis travel of 2,500 mm, and Z-axis travel of 760 mm. The machine includes a robust table size of 4,020 × 2,400 mm and a maximum table load of 15,000 kg. If you are looking to get high-quality milling capabilities, consider the AWEA LP4025 gantry milling machine we have for sale. Contact us for further details. • Table size: 4,020 × 2,400 mm • Distance between columns: 2,700 mm • CNC control: FANUC (depending on configuration) • Spindle speed: 6,000 rpm (8,000 / 10,000 rpm optional) • Spindle motor power: 22 / 26 kW • Tool magazine capacity: 32 tools (60 / 90 / 120 optional) • Maximum tool diameter: 127 mm • Maximum tool length: 350 mm • X-axis rapid traverse rate: 15,000 mm/min • Y-axis rapid traverse rate: 15,000 mm/min • Z-axis rapid traverse rate: 15,000 mm/min Fedpfxe Aba S Rj Abajgi Technical Specification Taper Size BT 50

Condition: used, Year of construction: 2002, functionality: fully functional, travel distance X-axis: 2,000 mm, travel distance Y-axis: 1,250 mm, travel distance Z-axis: 650 mm, total length: 6,500 mm, table length: 2,000 mm, table width: 1,000 mm, total width: 3,600 mm, spindle speed (max.): 12,000 rpm, total height: 4,000 mm, distance between stands: 1,250 mm, type of input current: three-phase, position of the milling head: Vertical, overall weight: 14,000 kg, spindle motor power: 25,000 W, Equipment: rotational speed infinitely variable, TECHNICAL DETAILS General Information Machine type: Portal milling machine Manufacturer: Nicolás Correa Model: EURO 2000 Year of manufacture: 2002 Retrofit: 2024 Fgodpfx Ao Aaytfebaoi Machine weight: 14,000 kg CE marking: present Control System Control system: Heidenhain TNC 530 Handwheel: Heidenhain HR-410 Work Table and Working Area Work table: 2,000 × 1,000 mm Travel in X-axis: 2,000 mm Travel in Y-axis: 1,250 mm Travel in Z-axis: 650 mm Column spacing: 1,250 mm Spindle Spindle design: direct-drive motor spindle head Spindle power: 25 kW Spindle speed: max. 12,000 min⁻¹ Tool interface: HSK 63 Tool Changer Tool changer: 24 positions Coolant System and Chip Disposal Coolant system: external Internal cooling: through the spindle head Chip conveyor: present Axes and Rotary Table Rotary table/indexing table: stepless Additional axes: 4th and 5th axis Machine Dimensions Length: 6,500 mm Width: 3,600 mm Height: 4,000 mm EQUIPMENT Heidenhain TNC 530 control system Portable handwheel Heidenhain HR-410 Automatic tool changer with 24 positions External coolant system Internal coolant supply through the spindle head Chip conveyor Stepless rotary table or indexing table for the 4th and 5th axis Fully enclosed working area enclosure

Condition: as good as new (ex-display), functionality: fully functional, travel distance X-axis: 2,050 mm, travel distance Y-axis: 3,010 mm, travel distance Z-axis: 290 mm, warranty duration: 24 months, Top-of-the-line CNC portal milling machine as a demonstration system. Particularly suitable for processing non-ferrous metals, plastics, wood, and composite materials. vhf machines have been manufactured in Germany for over 35 years and are characterized by their ease of operation and high reliability. A professional service team ensures prompt support. Features: - Large vacuum table with a clamping area of 2,000 x 2,500 mm - T-slot clamping area at the front of 2,000 mm x 500 mm - Water-cooled spindle (40,000 rpm, S1 = 2.3 kW) - Automatic tool changer for 4 tools Fgsdpfxjz Sy A Se Abaei - Dust and chip extraction system including vacuum cleaner - Electrically controlled minimum quantity lubrication system - System cabinet for manufacturing computer and control components Price approximately 30% below the new price of the machine plus delivery, installation, and software Complete equipment and options available upon request.

Condition: ready for operation (used), Year of construction: 2008, travel distance X-axis: 2,230 mm, travel distance Y-axis: 1,700 mm, travel distance Z-axis: 850 mm, table length: 2,000 mm, table width: 1,650 mm, spindle speed (max.): 5,000 rpm, table load: 6,000 kg, overall weight: 19,500 kg, controller manufacturer: HEIDENHAIN, controller model: iTNC 530, number of axes: 3, This 3-axis KAOMING KMC-2000 SV gantry milling machine was manufactured in 2008. It features a generous X-axis travel of 2,230 mm, Y-axis travel of 1,700 mm, and Z-axis travel of 850 mm. The machine includes a substantial table size of 2,000 x 1,650 mm and a maximum table load of 6,000 kg. If you are looking to get high-quality milling capabilities, consider the KAOMING KMC-2000 SV machine we have for sale. Contact us for further details. - Tool Taper: SK50 - Tool Changer Positions: 30 slots - Control On Hours: 30,233 h (as of end of 2025) - Program Run Hours: 17,814 h (as of end of 2025) - Optional Equipment: Integrated magnetic/clamping plates on table, chip conveyor, internal/external coolant nozzles, remote handwheel control unit, electrical cabinet with cooling/air conditioning unit. Fgedjz Sp I Dspfx Abaoi

Condition: used, Year of construction: 1998, Portal Milling Machine JOBS JOMACH 241 Year of construction: 1998 Travel X: 3400 mm Travel Y: 2700 mm Travel Z: 1250 mm Numerical Command: CNC Siemens SINUMERIC 840 D Table size: 3000 x 1500 mm Fgsdpfx Abez Nxx Hjasi Distance between uprights: 1700 mm 1 Tool Changer 32 Tools ISO 50 + 1 Tool Changer 32 Tools HSK-63 3 Milling heads - Axe C: 2 heads TWIST - ISO 50 + HSK 63 A + 1 head 3 axes ISO 50 Weight: 44 T

Condition: like new (used), Year of construction: 2021, travel distance X-axis: 4,000 mm, travel distance Y-axis: 3,000 mm, travel distance Z-axis: 1,500 mm, Year of manufacture: 2020 Fgsdsz Nihfopfx Abaei Table: 4,500 * 2,000 mm X: 4,000 mm Y: 3,000 mm Z: 1,500 mm Additional information: Heidenhain TNC 640 HSCI Main spindle ISO 50 Spindle speeds: max. 6,000 rpm Tool changer: 60 tools Coolant through the spindle UAD/universal head 0.002/0.002 degrees Many additional options!

Condition: like new (used), Year of construction: 2018, travel distance X-axis: 4,000 mm, travel distance Y-axis: 3,000 mm, travel distance Z-axis: 1,500 mm, Year of manufacture: 2018 Table: 4,500 * 2,000 mm X: 4,000 mm Y: 3,000 mm Fgjdpfxjz Nifds Abaji Z: 1,500 mm Additional information: Heidenhain TNC 640 HSCI Main spindle ISO 50 Spindle speeds: max 6,000 rpm Tool changer: 60 tools Coolant through the spindle UAD/universal head 0.002/0.002 degrees Many additional options!

Condition: new, Year of construction: 2026, functionality: fully functional, machine/vehicle number: 50977, travel distance X-axis: 5,500 mm, travel distance Y-axis: 3,500 mm, travel distance Z-axis: 1,500 mm, feed rate X-axis: 90,000 m/min, feed rate Y-axis: 90,000 m/min, total length: 9,600 mm, total width: 6,500 mm, spindle speed (max.): 16,000 rpm, total height: 5,600 mm, table load: 20,000 kg, torque: 160 Nm, rotational speed (max.): 16,000 rpm, overall weight: 63,000 kg, warranty duration: 18 months, State-of-the-art linear motor milling machine in a compact GANTRY design with 5 CNC-controlled simultaneous axes, particularly suitable for efficient 5-sided machining of workpieces made of synthetic and composite materials, model-building block material, and aluminum, as well as for HSC machining of cast and steel materials. Travel ranges: X = 5,500 mm x Y = 3,500 mm x Z = 1,500 mm Swivel milling head 15 with CNC-controlled A and C axes High-frequency milling spindle, HSK100A, 60 kW, 16,000 rpm, 160 Nm CNC control HEIDENHAIN TNC 7 80-position tool changer, chain magazine KSS and MMS Laser tool measuring system Wireless measuring probe RMP60 Bellows cover Equipment and further options available upon request. Available from August 2027! Fodpfxsz I Rlzj Abasgi

Condition: new, Year of construction: 2026, functionality: fully functional, machine/vehicle number: 50940, travel distance X-axis: 2,200 mm, travel distance Y-axis: 3,500 mm, travel distance Z-axis: 1,500 mm, feed rate X-axis: 90,000 m/min, feed rate Y-axis: 90,000 m/min, total length: 4,500 mm, table length: 3,500 mm, total width: 6,500 mm, spindle speed (max.): 24,000 rpm, total height: 5,600 mm, table height: 300 mm, rotational speed (max.): 24,000 rpm, overall weight: 34,000 kg, warranty duration: 18 months, State-of-the-art linear motor milling machine in a compact GANTRY design with 5 CNC-controlled simultaneous axes, particularly suitable for the efficient 5-sided machining of workpieces made of plastics and composite materials, model-making block materials and aluminum, as well as for HSC machining of cast and steel materials. Travel ranges: X = 2,200 mm x Y = 3,500 mm x Z = 1,500 mm Swivel milling head 15 with CNC-controlled A and C axes High-frequency milling spindle, HSK63A, 60 kW, 24,000 rpm, 60 Nm CNC control HEIDENHAIN TNC 7 Fgodpfx Abez I Rfbsaoi 68-position tool changer, chain magazine Coolant system and mist extraction system Laser tool measurement system Wireless measuring probe RMP60 Bellows cover Equipment and additional options available upon request. Available from August 2027!

Condition: ready for operation (used), Year of construction: 2013, operating hours: 12,486 h, functionality: fully functional, travel distance X-axis: 3,400 mm, travel distance Y-axis: 2,300 mm, travel distance Z-axis: 1,000 mm, spindle speed (max.): 18,000 rpm, controller model: Siemens 840D sl, TECHNICAL DETAILS Travel range X-axis: 3,400 mm Travel range Y-axis: 2,300 mm Travel range Z-axis: 1,000 mm Rapid traverse X-axis: 60 m/min Rapid traverse Y-axis: 60 m/min Rapid traverse Z-axis: 40 m/min Design: C3 swivel head Swivel range C-axis: 200° Swivel range A-axis: 120° Spindle motor power: 24 kW Spindle mounting: HSK 63 A Spindle speed: 18,000 rpm Spindle cooling: Water cooling Fsdjz Izduepfx Abasgi Design: Disc tool changer Tool magazine positions: 20 Pick-up positions: 1 Tool diameter: up to Ø 500 mm Table length: 2,000 mm Table width: 1,500 mm Table thickness: 30 mm Grid spacing: 100 x 100 mm Maximum load capacity: 2,000 kg Repeatability: approx. 0.012 mm MACHINE DETAILS CNC control: Siemens 840D sl Spindle operating time: approx. 12,486 hours Power-on hours: approx. 37,297 hours EQUIPMENT 5-axis package: included Advanced Surface: included TCP: included Control panel size: 15 inches Remote maintenance: prepared Workpiece measuring probe: m&h wireless measuring probe Tool measurement: BLUM laser Minimum quantity lubrication: internal and external lubrication Central lubrication: automatic Spray mist extraction: with electrostatic separation Full protective cabin: included Tool changing chamber: separate Technical documentation Operating manual Omlat spare spindle included

Condition: like new (used), Year of construction: 1996, Retrofitted: 2023 Fgedpfez Iuk Uox Abasi Numerical control: HEIDENHAIN TNC-426 Technical features Dimensions Table dimensions: 3000 x 1250 mmNumber of T slots: 8T slots dimensions: 22 mm Traverses of axis X axis traverse: 2500 mmY axis traverse: 1800 mmDistance between columns: 1680 mmZ axis traverse: 800 mm Milling head Head type: Standard vertical spindleTool clamping system: HydraulicTaper nose: ISO 50Speed range: 20 - 2000 r.p.m.Spindle power: 22 kW Feedrates Feedrate: 2 - 5000 mm/minRapid feedrate (X / Y,Z): 15000 / 12000 mm/min Weight and dimensions Max Weight on table: 10000 kgMachine weight: 21500 kgMachine dimensions: 7300 x 2690 x 3400 mm Accessories Guarding: YesCoolant: ExternalElectronic handwheel: HR-330 Sale conditions Warranty: 6 months mechanical partsPrice and sale conditions: On request View all technical features
