Condition: good (used), Year of construction: 1998, functionality: fully functional, CNC turning machine EMCOTURN 365 MC with counter spindle Year of manufacture: 1998 Ijdpfx Aez Tc Utop Doih Control system: Sinumerik 840D Accessories: - Parts collector - Chip conveyor Further details to follow Includes a wide range of accessories.

Condition: good (used), Year of construction: 2011, operating hours: 18,000 h, functionality: fully functional, turning length: 740 mm, turning diameter: 430 mm, spindle bore: 65 mm, travel distance X-axis: 280 mm, travel distance Y-axis: 100 mm, travel distance Z-axis: 750 mm, rotational speed (max.): 5,000 rpm, rotational speed (min.): 10 rpm, bar passage: 65 mm, overall weight: 8,000 kg, Equipment: documentation/manual, rotational speed infinitely variable, Turn-milling center EMCO HYPERTURN 665 MC Plus Year of manufacture: 2011 Control system: Sinumerik 840D Operating hours: 18,300h (according to hour meter) Technical data: Main spindle speed: 0 - 5,000 rpm Drive power: 21/29 kW (100/40%) Torque: 250 Nm Spindle mounting: KK6 Bar diameter: 65 mm Counter spindle speed: 0 - 7,000 rpm Drive power: 17/21 kW (40/100%) Torque: 130 Nm Spindle mounting: KK6 Milling spindle speed: Mounting: Capto C4 Number of magazine positions: 23 Travel ranges: X1/Z1: 280/750 mm X”/Z2: 205/750 mm Y-axis: +/- 50 mm Lower turret: Mounting: VDI 30 Number of positions: 12 Number of powered tools: 12 Accessories: - Emco short magazine LM 1200 - Chip conveyor Iodoz Tc Umopfx Ap Djih - High-pressure coolant system - Parts catcher - Extensive equipment with tool holders

Condition: used, Year of construction: 2013, operating hours: 51,438 h, functionality: fully functional, turning length: 2,000 mm, turning diameter: 630 mm, spindle motor power: 34 W, spindle speed (max.): 4,000 rpm, spindle bore: 102 mm, travel distance X-axis: 650 mm, travel distance Y-axis: 400 mm, travel distance Z-axis: 2,050 mm, rapid traverse X-axis: 40 m/min, rapid traverse Y-axis: 30 m/min, rapid traverse Z-axis: 40 m/min, type of input current: AC, feed rate X-axis: 40 m/min, feed rate Y-axis: 40 m/min, feed rate Z-axis: 30 m/min, total height: 2,670 mm, total length: 7,601 mm, total width: 4,215 mm, spindle nose: 220h5, overall weight: 24,000 kg, Equipment: documentation/manual, Control system: Siemens 840D sl with ShopTurn Year of manufacture: 2013 Isdpfx Apjz Tc Tpe Dsih Spindle hours: 16,310 Location: Germany Equipment: -Main spindle ISM 102 -Counter spindle ISM 102 -Milling spindle HSK63A 12,000 rpm -Eccentric turning and milling -Milling of gears using the involute method -Easy Tool Monitor for Siemens control system -Chuck flushing system, external -Chuck flushing system, counter spindle -Differential pressure monitoring for H-spindle -Differential pressure monitoring for C-spindle -Coolant supply through the counter spindle -Partially hollow chuck, Ø 104 mm -Tailstock function for the counter spindle -Rest support for rest 30-245 mm -Rest slide, NC-controlled -BFA 8/20/80 bar, 980 l, cooler -Hinged belt chip conveyor -Automatic sliding hood, electric -Tool measuring device -Chain magazine for 120 tools HSK63A -Signal light, 4-way -Cleaning of the safety glass -Coolant spray gun -Control cabinet lighting -Oil mist separator Including the following overhaul/repair measures: -General overhaul of main spindle S1 HSK 63 12,000 rpm -Replacement of safety glass -Replacement of hoses (pneumatics, cooling system, CNC)

Condition: excellent (used), Year of construction: 2012, Machine data Year of manufacture: 2012 Control system: Mitsubishi Spindles: Main and counter spindle Y-axis: Available Tool turret: 8 stations Bar feeder: LNS Sprint 542 Full load current: 84 A Connection, weight and dimensions Machine weight: 3,000 kg Voltage / phases / frequency: 200 V / 3~ / 50–60 Hz Connection power: 29 kVA Equipment and scope of supply Iiodpfx Aoz Tc S Ejp Djh Main and counter spindle Y-axis Tool turret with 8 stations LNS Sprint 542 bar feeder Basic set of tool holders; the exact scope of holders will be listed in the quotation. Further accessories belonging to the machine, as shown in the offer photos. LNS Sprint 542, basic set of tool holders and further accessories belonging to the machine, as shown in the offer photos. Exact scope of holders as per quotation. Technical specifications are subject to change without notice. Errors and prior sale excepted. The properties and scope of supply agreed upon in the purchase contract shall be binding.

Condition: excellent (used), Year of construction: 2006, functionality: fully functional, table length: 1,120 mm, table width: 600 mm, Cincinnati Arrow 2-1000 machining center, with Siemens Acramatic 2100 CNC, automatic tool changer, 1120mm x 600mm table, maximum table load of 1000kg, travels X 1016mm, Y 510mm, Z 560mm, with electronic handwheel, BT40 taper, 11/15 hp, maximum spindle speed of 12500 rpm, oil-lubricated spindle, Heidenhain measuring scales on all three axes, automatic tool changer with 21 positions, year 2006, serial number 7049-AQA-KE1134, part number 91204519A, machine in very good condition, machine has never been used for metalworking. Isdpjz Tc Igofx Ap Doih

Condition: ready for operation (used), Moriseiki SL-250B Iisdpoz Tc Exofx Ap Dsh

Condition: excellent (used), Year of construction: 2008, operating hours: 22,090 h, Machine type: CNC turning and milling center Manufacturer: MORI SEIKI Type: NL 2500 Y / 1250 Year of manufacture: 2008 Control system: MSX 850 III Technical data: Turning diameter: 275 mm Turning length: 1,298 mm Control system: MSX 850 III Swinging diameter over bed: 923.8 mm Swinging diameter over cross slide: 755 mm Max. turning diameter: 356 mm Max. bar diameter: 80 mm Main spindle: Speed range - main spindle: 4,000 rpm Drive power - main spindle: 18.5 / 15 kW Spindle nose: JIS A2-8 Spindle bore: 91 mm Spindle bearing diameter: 140 mm C-axis: 0.001° Ijdpfoz S Rk Hjx Ap Doih Travel: X-axis: 260 mm Z-axis: 1,345 mm Y-axis: +/- 50 mm Turret: Tool positions: 12 Shank height for square tools: 25 mm Shank diameter for boring bars: max. 50 mm Turret indexing time: 0.25 sec. Speed range of driven tools: 6,000 rpm Drive power - driven tools: 5.5 / 3.7 kW Feed rate: Rapid traverse X-axis: 30 m/min Rapid traverse Z-axis: 30 m/min Rapid traverse Y-axis: 10 m/min Tailstock: Tailstock travel: 1,284 mm Quill diameter: 110 mm Taper: MT 5 Rapid traverse: 7 m/min Total power requirement: 38 kVA Machine weight approx.: 7.5 t Space requirement approx.: 5.5 x 3.4 x 2.3 m

Condition: used, Year of construction: 2015, turning diameter max. 500 mm turning length 800 mm control sl Operate 3G ShopTurn Siemens swing diameter 500 mm distance between spindles 1.020 mm turning speed range - main spindle max. 5.000 min/-1 power capacity - main spindel 25 / 34 kW max. Torque 280 / 380 Nm spindle head 170h5 spindle diameter in front bearing 130 mm spindle bore 87 mm C-Axis 0,001 ° tool taper HSK 63 A number of toolpositions 80 pos. max. tool diameter 80 mm max. tool-dia with free toolbox 120 mm max. tool weight 12 kg max. tool length 300 mm Speed Milling Spindle max. 12.000 min/-1 power capacity - milling spindle 19 / 22 kW Torque 85 / 100 Nm tool taper HSK 63 A B-Axis +/- 110 ° x-axis -10 ... +490 mm y-axis +/- 100 mm z-axis 1: 845 mm z-axis 2: 600 mm z-axis 3: 800 mm Spindle speed range subspindle max. 6.000 min/-1 power capacity - Sub spindle 20 / 27 kW bar material dia. 51 mm spindle bore diameter 73 mm spindle diameter in front bearing 100 mm C-Axis 0,001 ° total power requirement 85 kVA weight of the machine ca. 10,0 t dimensions of the machine ca. 7,0 x 2,9 x 2,6 m CNC - Turning- and Millingcenter DMG MORI - CTX beta 800 TC V6 - 5-axis simultaneous machining Ijdpfez S Nygjx Ap Doih - Main and counter-spindle - Swivel-type milling spindle - ShopTurn - Off-center turning and milling - Multi-thread cycle - Program state control - Tool sorting cycle - Easy Tool Monitor for Siemens control system - Chuck flushing system for main spindle - Chuck flushing system for counter-spindle - Differential pressure clamping - Coolant supply through the counter-spindle - Bar machining package for CTX beta (77 mm capacity) Workpiece the-take-off device (left side) Hydraulic hollow clamping system 4-color signal tower Interface for bar feeder or bar magazine - In-process workpiece measuring system (Renishaw) - Safety window cleaning system - Coolant spray gun

Condition: used, Year of construction: 2015, turning diameter max. 240 mm turning length 470 mm control 840 D sl Operate 4.8 Celos greates pass round over bed 500 mm swing diameter over slide rest 290 mm centre distance 780 mm turning speed range - main spindle max. 6.000 min/-1 power capacity - main spindel 13 / 14 kW max. Torque 171,5 / 192 Nm inner draw tube diameter 52 mm C-Axis 0,001 ° spindle diameter in front bearing 100 mm spindle nose FL 140H5 Spindle speed range subspindle max. 6.000 min/-1 power capacity - Sub spindle 12,6 / 16,2 kW max. Torque 48 / 62 Nm inner draw tube diameter 37 mm C-Axis 0,001 ° spindle diameter in front bearing 90 mm spindle nose FL 140H5 number of toolpositions 12 pos. Number of driven toolspositions 12 pos. tool taper VDI 30 Spindle speed - driven tool stations max. 5.000 min -1 power capacity - driven tool-stations 4,18 kW max. Torque 16 / 20 Nm y-axis 80 (+/- 40) mm x-axis 145 mm y-axis 80 (+/- 40) mm z-axis 520 mm z2-Axis 550 mm rapid traverse ( X / Y / Z ) 30 / 22,5 / 30 m/min Feed force ( X / Y / Z ) 4,5 / 4,5 / 7,5 kN total power requirement 30 kVA Iisdpfjz S Nyaox Ap Doh weight of the machine ca. 4,3 t dimensions of the machine ca. 7,0 x 3,0 x 2,2 m CNC - Turning- and MillingCenter DMG GILDEMEISTER - CTX alpha 500 V6 - Only approx. 11,139 spindle hours - External chuck flushing system for the main spindle - External chuck flushing system for the counter-spindle Coolant supply through the counter-spindle - Coolant spray gun - Bar machining package Workpiece unloading device with conveyor belt (left-hand side) for parts up to 51 mm in diameter and 185 mm in length, max. 3 kg Hydraulic hollow clamping system Draw tube inner diameter: max. 52 mm 4-color signal light Connection for bar feeder or bar loading magazine - Preparation for external handling Electrical robot interface (Profibus) Automatic work area door Chuck flushing system with coolant (main spindle)

Condition: used, Year of construction: 2004, turning diameter 820 mm Isdoz S Nx Aspfx Ap Doih turning length 3000 mm control Siemens 840 D workpiece weight 2,5 t drive of main spindle 77 kW spindle nose A15 spindle bore 160 mm Workpiece head (C-axis) 0,005 grad max. torque on the working spindle 2500 Nm main spindle speeds: 0-2.430 U/min feeds z-axis 0,1-18.000 mm/min rapid traverse Z-axis 18 m/min feeds x-axis 0,1-30.000 mm/min rapid traverse X-axis 30 m/min steady 50-350 Spannbereich tailstock - quill dia 180 mm tailstock - travel of quill 170 mm y-axis -100/+150 mm rapid traverse y-axis 12.000 mm/min b-axis -105/+95 Grad milling spindle - taper HSK100 milling spindle motor 43 kW milling head speed 1-5.500 U/min max. torque on the milling spindle 336 Nm tool changer 96 Plätze weight of tools max. 15 kg total power requirement 166 KVA weight of the machine ca. 40 t dimensions of the machine ca. 112x4,4x3,85 m

Condition: ready for operation (used), Year of construction: 2012, operating hours: 13,550 h, functionality: fully functional, turning length: 3,000 mm, turning diameter: 920 mm, spindle speed (max.): 10,000 rpm, spindle bore: 230 mm, type of input current: three-phase, total height: 3,937 mm, total length: 8,931 mm, total width: 3,277 mm, overall weight: 31,700 kg, Model: Integrex e-670H II Control: Mazatrol Matrix 2 Year: 2012 Cutting Dia: 920mm Distance Between Centre: 3000mm Spindle Speeds: 1600 RPM Spindle Bore: 230mm Ijdpfez S Ndxox Ap Doih Milling Speed: 10,000 RPM Milling Power: 37KW Tool Change Capacity: 80 Total Cutting Time:13550 RPM NOTE: Machine Has No Tailstock Dimensions: 8931 x 3277 x 3937 (approx.) Machine Weight: 31,700 KGS (approx.)

Condition: good (used), Year of construction: 2014, Description: The machine is in good technical condition, and a test run is possible upon prior arrangement. It is more suitable for serial production; it also includes a feeder and an output belt for finished parts. It comes with accessories – 2 universal chucks, clamps, and holders. Parameter PUMA MX 1600 ST Max. machining / turning diameter: 330 mm Recommended turning diameter: 170 mm Max. machining length: 900 mm Diameter over bed: 680 mm Diameter over carriage: 630 mm Bar diameter: approx. 51 mm Standard chuck: 6" Main spindle – speed: 6,000 rpm Main spindle – power: 15 / 11 kW Max. torque of main spindle: approx. 208 Nm Iiodsz S Hnhspfx Ap Doh Spindle nose: A2-5 Tailstock – speed: 6,000 rpm Tailstock – power: 15 / 11 kW Tailstock – nose: A2-5 Milling spindle: 12,000 rpm Power of milling spindle: 9 kW Torque of milling spindle: approx. 49 Nm Y-axis: 170 mm (??85 mm) B-axis: ??120?? / range 240?? X1: 450 mm Z1: 935 mm X2: 165 mm Z2: 925 mm Tool magazine: 40 positions Max. tool Ø: 70 / 95 mm Max. tool length: 200 mm Tool change time: approx. 2.1 s Lower turret: 16 positions, BMT45 Driven tools of lower turret: 6,000 rpm Power of driven tools: 5.5 kW Control system: Fanuc 31i-A Weight: approx. 11,600 kg Dimensions: approx. 3,800 × 2,530 × 2,760 mm

Condition: excellent (used), Year of construction: 2018, operating hours: 7,200 h, Technical Data Main spindle, counter spindle Turning length: mm 660 Spindle bore: mm 65 Chuck diameter: mm 165 Speed max.: min-1 6,000 Power (100% / 40% duty cycle): kW 20 / 24 Torque (100% / 40% duty cycle): Nm 125 / 170 C-axis resolution: degrees 0.001 Slide travel X: mm 710 Rapid traverse: m/min 60 Feed force: N 6000 Turret, lower / upper Speed max.: min-1 7,200 Power max.: kW 9 Torque max.: Nm 16 Milling spindle Tool system: HSK-A40 Speed max.: min-1 7,200 Torque (25% duty cycle): Nm 52 Power (25% duty cycle): kW 22 Tool holder 1 Slide travel X: mm 230 Rapid traverse: m/min 30 Feed force: N 6000 Slide travel Y: mm +/-65 Rapid traverse: m/min 15 Feed force: N 10,000 Slide travel Z: mm 845 Rapid traverse: m/min 50 Feed force: N 6000 3 Turrets Turret 1 YB - 6-position tool changer HSK Turret 2 Y Turret 3 y Year of manufacture 2018 Control system Siemens SINUMERIK 840D sl Turning length up to 660 mm Spindle bore 65 mm Milling spindle with 360-degree B-axis Production hours approx. 7,200 h Turret, lower and upper Feature Specification Stations and tool positions 14 stations per turret (VDI 25), a total of 42 tool positions Maximum speed 7,200 min⁻¹ Ijdpfx Apjz Sywce Dsih Maximum power 9 kW Maximum torque 16 Nm Milling spindle Feature Specification Tool system HSK-A40 Tool magazine 6 tool positions B-axis 360 degrees Maximum speed 7,200 min⁻¹ Torque at 25 percent duty cycle 52 Nm Power at 25 percent duty cycle 22 kW Tool holder 1 Feature Specification X-axis 230 mm, rapid traverse 30 m/min, feed force 6,000 N Y-axis ±65 mm, rapid traverse 15 m/min, feed force 10,000 N Z-axis 845 mm, rapid traverse 50 m/min, feed force 6,000 N Tool holder 2 Feature Specification X-axis 140 mm, rapid traverse 30 m/min, feed force 6,000 N Y-axis ±45 mm, rapid traverse 15 m/min, feed force 10,000 N Z-axis 810 mm, rapid traverse 50 m/min, feed force 6,000 N Workpiece removal Feature Specification Design Gantry part removal system with conveyor belt Maximum workpiece length 200 mm Maximum workpiece weight 5 kg Dimensions and connection values Feature Specification Length × Width × Height 5,355 × 2,235 × 2,400 mm Weight approx. 8,500 kg Connected power 42 kW Bar feeder magazine and accessories Feature Specification Bar feeder magazine INDEX MBL 65 Coolant system KNOLL system with band filter and high-pressure pump 80 bar Automation Automatic door Accessories Tool holder

Condition: excellent (used), Year of construction: 2009, functionality: fully functional, * Mori Seiki NL 2500 SY. * Year 2009. * 5-axis machine. * Sub-spindle. * Y-axis. * C-axis. * 1.5-meter LNS bar loader. * 12-station turret, all stations motorized. Ijdpfx Apjz Sx N Rs Deih * Y-axis travel: ±60 mm. * C-axis on both spindles. * Integrated main spindle motor: 18 kW. * Integrated sub-spindle motor: 15 kW. * Direct-drive motor for powered tools: 5.5 kW. * Motor starting torque: 640 N·m. * Motors without belts or gearboxes. * Main spindle size: A2-8. * Sub-spindle size: A2-6. * Bar capacity: 80 mm. * 250 mm Kitagawa B-210 main spindle chuck with metric system. * 210 mm Kitagawa B-208 sub-spindle chuck with metric system. * Prismatic guides on all axes. * Main spindle speed: 4,000 rpm. * Motorized tool speed: 6,000 rpm. * Daikin oil cooler for both spindles. * Mapps 4 conversational automatic programming system. * Automatic force control and tool wear monitoring. * Rapid traverse speed: 30 m/min on the X and Z axes. * Turret indexing time: 0.2 seconds. * Two Renishaw arms for automatic tool measurement. * Communication ports via USB, PCMCIA card, and RS-232. * Installation interface for bar feeder. * Automatic workpiece collector. * Dual foot pedal for independent opening and closing of the main spindle and sub-spindle. * Side-mounted hinged chip extractor with integrated particle filters. * Extensive selection of static and motorized tool holders. * Electrical transformer. * Documentation, parts list, electrical schematics, programming guide, and operating manual. * Weight: 6,200 kg. * Machine currently in operation. * Immediate delivery, unless sold immediately.

Condition: excellent (used), Year of construction: 2006, functionality: fully functional, * Mori Seiki ZT 1500 YB. * Opposed-spindle machine. * Spindle size A2-6, twin spindles. * 2 stacked turrets. * 9-axis controlled turning and milling center. * 2 turrets. * Y-axis upper turret. * 2 C-axes. * Bar capacity: 65 mm. * Two integrated 15 kW motors. * Tool life management and tool wear monitoring. * Two Renishaw automatic tool measurement arms. * Mapps 4 conversational automatic programming system. * Automatic force control and tool wear monitoring. * Oil cooler for both spindles. * 340 Nm cutting torque. * 15-position turret, all positions motorized. * Automatic workpiece collector. * 1.5-meter bar loader. * Interface for bar loader installation. * Rear automatic part pick-up with special gripper for long parts. * Max. turning diameter: 320 mm. * Turning length: 810 mm. * Mori Seiki MSX-701 III control. * Max. distance between main spindle and counter spindle: 920 mm. * Main spindle speed: 5000 rpm. * Counter spindle speed: 5000 rpm. * X1 travel: 210 mm. * Y1 travel: +50 / -50 mm. * X2 travel: 210 mm. * Counter-spindle travel: 920 mm. * Number of powered tool stations: 2 x 15. * Capable of holding 30 tools per turret. * Large selection of external and internal tool holders. * Large selection of axial and radial motorized blocks. * Approximate value of equipment: 18,000 euros. * Speed range of powered tools: 5,000 rpm. * Drive motor for powered tools: 5.5 kW. * Rapid traverse X1, X2: 25,000 mm/min. * Rapid traverse Y1: 20,000 mm/min. * Rapid traverse Z1, Z2: 30,000 mm/min. * C-axis resolution: 0.001°. Iedpfx Apoz Sx Nqe Deih * High-precision Hainbuch collet chucks on both spindles. * External and internal tool holders. * Motorized axial and radial blocks. * Communication ports via USB, PCMCIA card, and RS-232. * Rear chip conveyor. * Power transformer, documentation, parts list, electrical schematics, programming, and operating manual. * Machine in very good condition. * Machine weight 6.5 tons. * Machine available for inspection while in operation.

Condition: excellent (used), Year of construction: 2023, 400mm swing, 220mm max diameter, Iijdpfoz Srv Dex Ap Dsh 490mm between Centres, Siemens 828 Control, 65mm bar capacity, 12 station VDI30 turret, 17kW Spindle Motor, Spindle Speed 4000rpm, 0.001 degree C axis, +/- 35mm Y axis, low volt light, coolant, Tool setter, Tailstock, swarf conveyor

Condition: excellent (used), Year of construction: 2010, MaXXturn 65 SMY (Siemens) CNC TURNING CENTER FOR COMPLETE MACHINING WITH POWERED TOOLS, C-AXIS, AND Y-AXIS Linear guide system, digital drive system. Spindle motor (ISM) on the main and counter spindle with thermal compensation system (liquid-cooled). State-of-the-art control technology SINUMERIK 840D with ShopTurn dialog programming. Main spindle: A2-6" connection (DIN 55026) * Drive power: 29 kW * Speed range: 0-5000 rpm Counter spindle: A2-6" connection (DIN 55026) * Drive power: 22 kW * Speed range: 0-7000 rpm Tool system: * 12-position tool turret VDI 30 radial, with direction logic for up to 12 powered tools * Power: max. 6.7 kW * Torque: max. 25 Nm * Speed range: 0-5000 rpm * C-axis on the main and counter spindle Y-axis: * Travel range: +/- 40 mm * Rapid traverse speed: 12 m/min Includes: * Coolant unit for spindle head * Hollow chuck incl. draw rod * Sinumerika 840D/PCU20 control * SHOPTURN dialog programming * RS 232 interface * Machine light * Coolant system incl. coolant pump 3.5 bar * Chuck flushing (additional pump (3.5 bar)) * Part ejector and flushing through the Iijdpfx Ajz Sq Sdop Doh counter spindle * Control cabinet air conditioning * Hydraulic unit * Interface for chip conveyor * Documentation * CE certificate Machine no. S6AY1202 Year of manufacture: 2010

Condition: good (used), Year of construction: 2013, 230mm Swing, 230mm Max Turned Diameter, 230mm maximum turning length, 12 + 12 Station Turrets, 65mm Bar Capacity, 5000rpm Iodpfx Apsz Sqcvo Doih 15KW Main Spindle, Fanuc 31i Control, C Axis to both Spindles, 5000rpm Sub Spindle, +/-50mm Y axis, coolant, swarf conveyor, tool setter, parts catcher, Magazine Bar-feed.

Condition: ready for operation (used), Year of construction: 1989, operating hours: 39,768 h, travel distance X-axis: 235 mm, travel distance Z-axis: 520 mm, number of axes: 3, This 3-axis MORI SEIKI SL-250ASMC was manufactured in 1989. It features a Z-axis travel of 520 mm and a B-axis travel of 515 mm, providing versatile turning and milling capabilities. The machine is equipped with a chip conveyor and a bar feeder for enhanced productivity. If you are looking to get high-quality turning and milling capabilities, consider the MORI SEIKI SL-250ASMC turn-mill centre we have for sale. Contact us for further details. - Control Unit: Mori Seiki MSD-501II- Phase: 3- Frequency: 50 Hz- Voltage: AC 200 V- Full Load Current: 142 A- Current Rating of the Spindle Motor: 78 A- Interrupting Capacity: 5 kA- Electrical Diagram No.: AEF0253- Rated Power: 49 kVA- Operating Hours: 39,768 h- Number of Axes: 3 Main Axes (X, Z, C) + Sub-spindle/Tailstock (B)- X-Axis Travel: 235 mm- Z-Axis Travel: 520 mm- C-Axis Indexing: 360° (0.001° positioning)- B-Axis Travel: 515 mm- Additional Equipment: Chip conveyor, Bar feeder (Kurt Breuning IRCO Maschinenbau GmbH PROFIMAT Type 52.8 196, 2 kW, 200 V, 50 Hz, YOM 1998, Machine No. Technical Specification Ijdpfx Ajz Sp Nzop Deih Counter Spindle No Driven Tools Yes

Condition: good (used), Year of construction: 2008, functionality: fully functional, Weiler DZ 40, Year of manufacture: 2008, Siemens 840 D control, Travel X/Z: 200/350 mm, Turning diameter: 180 mm, Max. swing diameter: 560 mm, Y-axis: +/-25 mm, Q-axis / programmable tailstock, Q-axis travel: 360 mm, Q-axis measuring system: rotary, Tailstock: MK 4, Main spindle max. bar capacity: 42 mm, Iedpfx Ajz Sml Isp Deih Spindle bore: 52 mm, Rapid traverse X/Z/Q: 30/30/20 m/min, Turret: 16 stations – all driven, VDI 25, Shank diameter: 25 mm, Driven tools up to 4,500 rpm, Parts catcher, Accessories, Driven tool holders, Fixed holders,

Condition: good (used), Year of construction: 1998, functionality: fully functional, machine/vehicle number: TLUY7024, turning length: 600 mm, turning diameter: 250 mm, spindle speed (min.): 4,000 rpm, spindle speed (max.): 4,000 rpm, spindle bore: 86 mm, rotational speed (min.): 4,000 rpm, bar passage: 76 mm, total height: 1,900 mm, total length: 4,500 mm, total width: 2,200 mm, overall weight: 6,500 kg, Equipment: documentation/manual, Takisawa TA25 CBT turning center Main spindle: collet chuck for SK65BZI collets Tailstock with jaw chuck, alternatively collet chuck for 173E collets 12-station turret, incl. 25 tool holders (6 powered) Fanuc 18-T control + Manual Guide control Operating hours in automatic mode: 16,800 hours The drive for the powered tools in the turret has been removed. Complete manuals and documentation incl. FMB 10-65 loading magazine with traversing unit Iedoz Smhpjpfx Ap Djih Optically and technically in very good condition, hardly used. Year of manufacture: 2018 D60 conversion kit installed Ex works

Condition: used, Year of construction: 2018, functionality: fully functional, turning length: 530 mm, turning diameter: 255 mm, spindle motor power: 22 W, spindle speed (max.): 4,000 rpm, spindle bore: 65 mm, rotational speed (max.): 4,000 rpm, type of input current: three-phase, bar passage: 65 mm, chuck outer diameter: 210 mm, Equipment: documentation/manual, For sale is our well-maintained CNC turning center, a Hyundai WIA L210 LMA, manufactured in 2018, from our production facility. Technical data: Spindle bore: 65 mm Max. turning diameter: 255 mm Max. turning length: 530 mm Turning chuck: Samchully, 210 mm Main spindle speed: 4,000 rpm, 22/18.5 kW Control system: Siemens 828D C-axis Tool turret VDI 40, 12 stations, driven tools (5,000 rpm) Coolant pressure: 4.5 bar Tool presetter: Q-Setter Part catcher Preparation for bar feeder magazine Chip conveyor Tailstock MK4 Ijdpoz Smd Rjfx Ap Doih The price includes an extensive tool package: 6 driven tools with internal cooling (3 of which are angled at 90°) 7 holders for turning tools and drill bars 2 sets of soft jaws for the above-mentioned chuck Condition: well-maintained, from ongoing production, technically flawless. Dismantling and loading can be arranged.

Year of construction: 1989, condition: excellent (used), For sale: CNC lathe Mazak QuickTurn 20N. The lathe is in very good condition. Equipment includes: MAZATROL T-2, MAZATROL CAM-T-2 control system. Iisdpoz Scfkofx Ap Dsh

Condition: used, Year of construction: 1999, functionality: fully functional, turning length: 200 mm, turning diameter: 150 mm, spindle motor power: 7,500 W, spindle speed (max.): 5,000 rpm, spindle bore: 48 mm, rotational speed (max.): 5,000 rpm, bar passage: 45 mm, spindle nose: ASA 5, Equipment: documentation/manual, CNC MSC 501 Iijdpfx Ajz R Ug Dop Deh Turning diameter: 150 mm Maximum turning diameter: 420 mm Maximum turning length: 200 mm Spindle/tailstock bore diameter: 48 mm Spindle/tailstock bar passage: 45 mm Spindle/tailstock nose mounting: ASA 5 Spindle/tailstock speed: 5000 rpm Spindle motor power: 7.5 kW Tailstock motor power: 7.5 kW Machine complete with: -Presetting on spindle and tailstock -No. 2 motorized turrets, 12 positions -Operating manuals and CE declaration Year of manufacture: 1999

Condition: good (used), Year of construction: 2007, Machine is fully functional. Iiodpfsz R T E Sox Ap Dsh
