Tischlerei Höhler

Condition: used, Year of construction: 2001, Storage location: Supplier Ledpeym D Eiefx Ab Tsrh

Condition: like new (used), Year of construction: 2024, operating hours: 120 h, functionality: fully functional, planing height: 200 mm, spindle diameter: 50 mm, planing width: 260 mm, jointer table length: 2,500 mm, number of spindles: 5, Profile milling machine Superset NT V5 carpenter's version with 2 axes Equipment as per attachment Machine connected and ready for demonstration Lsdpfoym A A Hjx Ab Tjrh Availability: 1 to 2 weeks

Condition: excellent (used), Year of construction: 2006, functionality: fully functional, machine/vehicle number: 108146, WEINIG U500 Industrial Wood Planer / Moulder – Year 2006 For sale: WEINIG U500 high-quality industrial woodworking machine, manufactured in 2006, suitable for professional wood processing operations. The machine is renowned for its precision, durability, and reliable performance in continuous production. Specifications: • Model: WEINIG U500 Lrsdpfxeymzdpe Ab Toh • Year: 2006 • Serial number: 108146 • Total installed power: 50 kW • Operating voltage: 3 × 400 V / 50 Hz • Control voltage: 230 V / 50 Hz • Nominal current: 111 A • Main fuse: 125 A • Max motor current: 20.5 A Condition: • Industrial used condition • Robust German construction • Suitable for immediate operation (subject to installation and inspection) Ideal for: • Joinery workshops • Wood processing factories • Industrial moulding and planing applications

Condition: excellent (used), Year of construction: 2022, WADKIN M623S (6 SPINDLE) YEAR 2022 WIDTH 230MM HEIGHT 160MM ALL SPINDLES 6000 RPM ALL SPINDLES 40MM SHORT INFEED TABLE Lodpfsymyk Uox Ab Tjrh 1: BOTTOM 11 KW 2: RIGHT 11 KW 3: LEFT 11 KW 4: TOP 15 KW 5: TOP 15 KW 6: BOTTOM 11 KW 50 M/MIN+ ELECTRIC. FEED 7 x DRIVEN TOP FEED ROLLERS 3 x DRIVEN BED FEED ROLLERS ANTI-KICKBACK DEVICE AUTOM. BED LUBRICATION DIMENSION: APPR 3500 X 2000 X 1800 MM WEIGHT: APPR. 5500 KGS DUSTHOODS: 6 x 140 MM DIAMETER DUST MANIFOLD INCLUDED POSSIBLE TO SUPPLY WITH MOULDER INFEED AND DROP LEAF OUTFEED POSSIBLE TO SUPPLY TOOLING IF NEEDED

Condition: excellent (used), functionality: fully functional, Min./max. workpiece height: 15-100 mm Min./max. workpiece length: 500-2000 mm Min./max. workpiece width: 25-230 mm Lrodpfxoymn Rce Ab Toh Feed speed: 5-36 m/min

Condition: excellent (used), Catalogue number 6393 TECHNICAL DATA - Maximum workpiece width: 200 mm - Maximum workpiece height: 150 mm - Number of spindles: 4: 1) Bottom horizontal, 200 mm, 5.5 kW 2) Right vertical, 150 mm, 4 kW 3) Left vertical, 150 mm, 4 kW 4) Top horizontal, 200 mm, 5.5 kW - All cutterheads adjustable vertically and horizontally - Spindle diameter: 40 mm - Spindle speed: 6,000 rpm From above: - 6 feed-in traction rollers, toothed (including 2 double) - 1 feed-out traction roller, rubber-coated From below: - Feed-in drive roller, toothed, steering, integrated in lower table - 3 side pressure rollers - Feed-out traction roller, metal, smooth - All rollers pneumatically loaded - Infeed table length: 2,130 mm - Height-adjustable table - Centralized lubrication system - Electric adjustment of planing thickness - Lift motor: 1.1 kW - Stepless feed speed control via inverter - Feed drive motor: 3 kW - Feed via Cardan shafts - Fully enclosed in cabin - Extraction port diameters: 4 x 130 mm - Dimensions (LxWxH): 3,550 x 1,750 x 1,800 mm - Approx. weight: 3,000 kg ADVANTAGES – Equipped with 4 cutterheads – Ideal for wet and dry timber – DTR operation and maintenance manual included – Used machine, very good condition Net price: 65,900 PLN Lrodpfxoymnqcj Ab Teh Net price: 15,690 EUR Net price calculated at an exchange rate of 4.2 PLN/EUR (In case of significant exchange rate fluctuations, the price may change)

Condition: used, functionality: fully functional, SCM Sintex NTE Four-Sided Planer – only 200 operating hours Specification: • Condition: pre-owned, after professional inspection • Manufacturer: SCM • Model: Sintex NTE • Year of manufacture: 2011 • Operating hours: 200 mth • Working width: 180 mm Ledpoymlx Refx Ab Torh • Working height: 120 mm • Vertical spindle motor: 5.5 kW (one motor for 2 heads) • Horizontal spindle motor: 9.0 kW (one motor for 2 heads) • Total power: 16 kW • Programmer for setting planing dimensions, with memory for 300 settings • Automatic head positioning based on entered dimensions • 4 spindles equipped with Tersa system knives • Feed rack before the first head • Infeed table: 230 cm length, 19.5 cm width • Manual lubrication pump for the table • Two working speeds (6 and 12 m/min) • Sound-insulated cabin • Original paintwork • Weight: 996 kg • CE compliant • Documentation in Italian • Overall dimensions: 330 x 110 x 161 cm (L x W x H) Additional Information: • Machine is in very good technical condition, ready for immediate use • Actual machine condition shown in the attached photos • Possibility to power up and inspect the machine on site • Price listed does not include VAT or transport costs Financing and Transport: • We arrange transport with MDD fleet, courier companies, or third-party carriers • Financing support available in the form of leasing or lease loan

Condition: good (used), Weinig Hydromat H23 8 spindle Lredpjyl Rm Dsfx Ab Tsh 50mm spindles 6,000 RPM Bottom 7.5kW jointer ready Right 7.5kW straight jointer ready Left 15kW straight and profile jointer ready Right 11kW profile jointer ready Top 15kW jointer ready Bottom 18.5kw jointer ready Top 11kw straight and profile jointer ready + outboard bearing Bottom 7.5 kw straight and profile jointer ready + outboard bearing 7.5kW feed motor. Automatic lubrication system. Full heavy duty sound enclosure Possible to supply with moulder infeed and outfeed as needed. Possible to offer tooling if needed.

Condition: excellent (used), Year of construction: 2003, Weinig Hydromat 23C with 6 Spindles. Separate electrical panel. Automatic lubrication system for bedplates Maximum dimensions 140mm x 230mm No 1.  11kw - Bottom 6000rpm + Outboard bearing - straight jointer prepared No 2. 11kw - Right 6000rpm - straight and profile jointer prepared No 3. 11kw - Left 6000rpm - straight and profile jointer prepared No 4 . 15kw - Top 6000rpm + Outboard bearing - jointer prepared No 5 . 11kw - Top 6000rpm + Outboard bearing - straight jointer No 6 . 18.5kw - Bottom 6000rpm + Outboard bearing - straight jointer 7.5 kw feed. 6-60m/min (Possible to increase speed as needed). Ledpsyl Rmwjfx Ab Tjrh 50mm spindles Beam 0.55kW Full documentation included. Possible to supply with hydro tooling if needed. Possible to supply with infeed and outfeed if needed.

Condition: excellent (used), Weinig Hydromat 23C with 6 Spindles. Max width 245mm Max Thickness 160mm Separate electrical panel. Separate remote control panel Automatic lubrication system for bedplates Full heavy duty sound enclosure. 15kW feed motor 100m/min No 1.  7.5kw - Bottom 6000rpm straight jointer prepared No 2. 11kw - Right 6000rpm straight and profile jointer prepared Lrjdpoyl Rmqefx Ab Tjh No 3. 15kw - Left 6000rpm straight and profile jointer prepared No 4 . 15kw - Top 6000rpm + Outboard bearing + straight and profile jointer prepared No 5 . 30kw - Top 6000rpm + Outboard bearing + straight and profile jointer prepared No 6 . 15kw - Bottom 6000rpm + Outboard bearing + straight and profile jointer prepared 50mm spindles Beam 0.55kW Full documentation included. Heavy duty sound enclosure. Possible to supply with hydro tooling if needed. Possible to supply with full mechanisation if needed.

Condition: excellent (used), Year of construction: 2015, Weinig Powermat 2400 moulder with 7 Spindles. (Year 2015) Ledpfx Absyl Rmks Torh 50mm spindles 6,000 RPM (Not Powerlock) Bottom 15 kW + outboard bearing Right 11 kW + Straight jointer Left 11 kW + Straight jointer Top 15 kW + Straight jointer + outboard bearing Bottom 18.5 kW + Profile jointer Top 18.5 kW + Straight + Profile jointer Bottom 18.5 kW Straight jointer + outboard bearing 11kW feed motor Automatic lubrication system. Electric digital display memory system. Possible to supply with Weinig moulder infeed and outfeed

Condition: reconditioned (used), Leadermac Thundermac 923T Lredpfeyl Rmdjx Ab Tsh Spindles: 9 x 50mm x 6000 rpm Bottom (22 kW) - Right (15 kW) - Left (15 kW) - Right (15 kW) - Left (15 kW) - Top (22 kW) - Bottom (22 kW), Top (22 kW) - Bottom (22 kW). Working width: 250 mm, height: 160 mm. Max feed speed 100m/min (Possible to increase to 150m/min) Straight jointers. Profile jointers. Connection: 380 V / / 50 Hz 400 amps. Full Documentation included.

Condition: reconditioned (used), Year of construction: 2013, Leadermac Speedmac 631 Working width: 310 mm, height: 150 mm. Spindles: 6 x 50mm (4x spindles with inverter speed control Lodpfx Aeyl Rl Tob Torh Bottom (22 kW) - 6000 rpm outboard bearing Right (15 kW) - (4000 to 9000 rpm) straight jointer Left (15 kW) - (4000 to 9000 rpm) straight jointer Top (22 kW) - 6000 rpm, outboard bearing, Top (22 kW) - (4000 to 9000 rpm), outboard bearing, straight jointer Bottom (22 kW)- (4000 to 9000 rpm), outboard bearing, straight jointer Electronic spindle position adjustment as follows 1. 3rd spindle width adjustment. 2. 4th spindle thickness adjustment. 3. 5th spindle thickness adjustment. Feed speed 60m/min (Possible to increase). Top feed rollers 200mm (first 2) and 140mm others Connection: 380 V / / 50 Hz Full Documentation included.

Condition: excellent (used), Year of construction: 2015, WEINIG POWERMAT 1200 (6 SPINDLE) YEAR 2015 WIDTH 230MM HEIGHT 160MM ALL SPINDLES 8000 RPM ALL SPINDLES 50MM SHORT INFEED TABLE 1: BOTTOM 11 KW 2: RIGHT 11 KW Lrjdpeyl Rl Hofx Ab Teh 3: LEFT 11 KW 4: TOP 15 KW 5: TOP 15 KW 6: BOTTOM 11 KW CNC AXIAL CONTROL ON SPINDLES 3, 4 AND 5 40 M/MIN+ ELECTRIC. FEED 7 x DRIVEN TOP FEED ROLLERS 3 x DRIVEN BED FEED ROLLERS ANTI-KICKBACK DEVICE AUTOM. BED LUBRICATION PNEUM. POWERED SIDE PRESSURE ROLLERS DIMENSION: APPR 3000 X 2000 X 1800 MM WEIGHT: APPR. 4500 KGS DUSTHOODS: 6 x 140 MM DIAMETER DUST MANIFOLD INCLUDED POSSIBLE TO SUPPLY WITH MOULDER INFEED AND DROP LEAF OUTFEED POSSIBLE TO SUPPLY TOOLING IF NEEDED

Condition: excellent (used), Year of construction: 2012, Weinig H1000 moulder Weinig Hydromat 1000 with 5 Spindles. (Year 2012) Separate electrical panel Separate remote control panel Automatic lubrication system for bedplates Memory system Full sound enclosure No 1. 7.5kw - Bottom 6000rpm + Outboard bearing + Straight jointer No 2. 7.5kw - Right 6000rpm + profile jointer Lrjdpfx Ajyl Rlyeb Toh No 3. 7.5kw - Left 6000rpm + profile jointer No 4 . 7.5kw - Top 6000rpm + Outboard bearing + Straight jointer No 5 . 7.5kw - Bottom 6000rpm + Outboard bearing + Straight jointer 50mm spindles Beam 0.55kW Full documentation included. Extraction manifold included. Possible to supply with Weinig mechanisation if needed (Year 2012)

Condition: used, Used Weinig A510 surface planer Year of manufacture: ~1970 Manufacturer: Weinig Model: A 510 Working width: 510 mm Table length: 2500 mm 2-knife cutterblock Star-delta starter Extraction connection: Ø 120 mm Weight: approx. 800 kg Lredpfsylwdijx Ab Toh Dimensions (LxWxH): approx. 250 x 95 x 110 cm

Condition: excellent (used), SCM Compact 23 Four-Sided Planer Working width: 230 mm Working height: 120 mm Number of spindles: 4 Spindle arrangement: Bottom 5.5 kW Ljdpeylnr Rsfx Ab Tjrh Right Left 7.5 kW Top 5.5 kW Spindle speed: 6000 rpm Feed speed adjustable via variator up to 22 m/min Spindles with adjustment

Condition: used, Year of construction: 2004, Speed 60 m/min 8 workstations Lrjdpfx Ajyll D Rsb Tjh Digital positioning Chrome table Thrust bearings Lubrication 400V

Condition: ready for operation (used), Year of construction: 2020, operating hours: 80 h, overall weight: 1,000 kg, Wood Planer manufactured in 2020. This FORMAT4 EXACT 63 features a planing width of 630 mm and a table length of 1050 mm. It offers a thickness range of 3 – 300 mm with a maximum chip removal of 10 mm. If you are looking to get high-quality planing capabilities, consider the FORMAT4 EXACT 63 machine we have for sale. Contact us for further details. • Planing width: 630 mm • Table length: 1050 mm • Thickness range: 3–300 mm • Maximum chip removal: 10 mm • Cutterblock: 4-knife system, diameter 120 mm, speed 4600 rpm, self-setting planer knives • Feed speed: stepless 5–20 m/min; feed unit with variable speed • Main motor: 10.0 kW • Electrical: 3 x 400 V, 50 Hz, duty type S6, star-delta start • Thickness height adjustment: electric with digital display • Position control: Digi Drive D1 with LED display for set/actual value; programmable positioning functions Lsdpfsylkhzex Ab Terh • Infeed roller: steel, spiral toothed, 630 mm • Outfeed roller: steel, 630 mm • Pressure bars: segmented at infeed; spring-loaded at outfeed • Side guiding strips on thickness table • Swiveling extraction hood • Machine weight: approx. 1000 kg • Control: conventional (non-CNC) Additional equipment • Table extension with workpiece roller, 630 x 570 mm

Condition: excellent (used), CATALOG NO. 7133 TECHNICAL SPECIFICATIONS - Max. working width: 220 mm - Max. working height: 120 mm – 5 spindles: 1) Bottom horizontal, 220 mm, 5.5 kW 2) Right vertical, 120 mm 3) Left vertical, 120 mm; spindles 2 & 3: 11 kW 4) Top horizontal, 220 mm, 11 kW 5) Bottom horizontal, 220 mm, 5.5 kW - All spindles adjustable up/down, right/left - Spindle diameter: 40 mm - Pneumatic pressure hold-downs - Top: 4 powered, gear-driven feed rollers (including 2 double rollers) - Top: 1 double outfeed roller, smooth, rubber-coated - Bottom: powered outfeed roller, rubber-coated - Feed on Cardan shafts - Variable feed speed adjustment - Feed motor: 2.2 kW - Lifting motor: 0.25 kW - Electric planing thickness adjustment - Infeed table length: 1970 mm - Central lubrication system - Extraction nozzle diameter: 4 x 120 mm, 1 x 140 mm - Dimensions (L/W/H): 3500 x 1550 x 1400 mm - Weight: 1750 kg ADVANTAGES – Equipped with 5 heads – German-manufactured – Not repainted – Used planer, in very good condition Net price: 43,900 PLN Net price: 10,450 EUR (according to exchange rate of 4.2 EUR) Lrjdpfoyla Taox Ab Tsh (Prices may vary with significant exchange fluctuations)

Condition: used, Year of construction: 1993, Catalogue number 7705 Ljdpfx Abeyla Rxj Tsrh TECHNICAL DATA - Max. width of workpiece: 220mm - Max. height of workpiece: 160mm – 4 spindles: 1) Lower horizontal: 220mm, 5.5kW 2) Right vertical: 160mm 3) Left vertical: 160mm; (spindles 2 and 3) 11kW 4) Upper horizontal: 220mm with electric height adjustment, 7.5kW - All spindles adjustable vertically and horizontally - Spindle diameter: 40mm - Top: 4 toothed, steel infeed rollers - Top: 1 double rubber outfeed roller - Bottom: rubber outfeed roller - Feed on Cardan shafts - Infinitely variable feed speed adjustment - Feed motor: 2.2kW - Lift motor: 0.55kW - Electrically adjustable planing thickness - Infeed table length: 1970mm - Central lubrication - Extraction port diameter: 3x120mm, 140mm - Enclosed in soundproof cabin - Dimensions (L/W/H): 3500x1600x1500mm - Weight: 1620kg Net price: 28,900 PLN Net price: 6,880 EUR, depending on rate 4.2 EUR (Prices subject to change with exchange rate fluctuations.)

Condition: excellent (used), Catalogue number 7706 Ljdpfjylazdjx Ab Tsrh TECHNICAL DATA - Maximum workpiece width: 220 mm - Maximum workpiece height: 120 mm – 5 spindles: 1) Bottom horizontal: 220 mm, 4 kW 2) Right vertical: 120 mm 3) Left vertical: 120 mm (spindles 2 and 3: 7.5 kW) 4) Top horizontal: 220 mm, 5.5 kW 5) Bottom horizontal: 220 mm, 4 kW - All spindles are adjustable up/down, right/left - Spindle diameter: 40 mm - Pneumatic pressure rollers - 4 top infeed geared rollers, including 1 twin - 1 top outfeed smooth rubber roller - 1 bottom outfeed rubber roller - Feed driven by Cardan shafts - Stepless feed speed adjustment: 6–36 m/min - Feed motor: 2.2 kW - Lifting motor: 0.25 kW - Equipped with brake - Electric planing thickness adjustment - Central table lubrication - Infeed table length: 1970 mm - Extraction port diameter: 4 x 120 mm, 140 mm - Dimensions (L x W x H): 3450 x 1600 x 1450 mm - Weight: 1112 kg Net price: 39,900 PLN Net price: 9,500 EUR (based on exchange rate of 4.2 EUR) (Prices may change subject to significant fluctuations)

Condition: excellent (used), Year of construction: 2005, We offer a Weinig Super 4 planer in very good condition with EM 15 feed unit, year of manufacture 2005. Ljdpfjylagmsx Ab Torh Manufacturer: Weinig Model: Super 4 Year of manufacture: 2005 Condition: very good Type: planer If you have any questions or need further information, please send us a message or contact us by phone.

Condition: excellent (used), Catalogue number 6765 TECHNICAL DATA - max. working width of element: 230 mm - max. working height of element: 160 mm Number of spindles: 4: 1) lower horizontal, 230 mm, 5.5 kW 2) right vertical, 160 mm, 5.5 kW 3) left vertical, 160 mm – electrically adjustable left/right from the control panel, 5.5 kW 4) upper horizontal, 230 mm – electrically adjustable up/down from the control panel, 7.5 kW - all spindles adjustable up/down, left/right - spindle diameter: 40 mm from the top: - driven infeed rollers, geared, 6 pcs (incl. 2 double rollers) - driven outfeed rollers, rubber-coated, 2 pcs from below: - infeed roller, driven, geared, metallic, swiveling in the lower table Lrjdpfxoyk Hk Ao Ab Tsh - outfeed roller, driven, metallic, smooth - pneumatically adjustable rollers - length of infeed table (with pneumatic feeder): 3390 mm - possible operation without activating the pneumatic feeder; the table is height-adjustable - central lubrication - electric thickness adjustment - variable feed speed adjustment - feed via cardan shafts - feed motor: 4 kW - enclosed in cabin - extraction port diameter: 4 x 120 mm - dimensions (L x W x H): 7000 x 1950 x 1700 mm - weight: approx. 3000 kg - suitable for wet and dry wood - pneumatic feeder on the infeed table - second-hand planer, in very good condition Net price: 89,900 PLN Net price: 21,400 EUR Net price calculated at exchange rate 4.2 PLN/EUR (price may change in case of significant exchange rate fluctuations)

Condition: used, Year of construction: 1998, operating hours: 6,720 h, functionality: fully functional, machine/vehicle number: 22.303, planing height: 300 mm, planing width: 400 mm, rotational speed (max.): 5,800 rpm, height adjustment type: electric, compressed air connection: 7 bar, input voltage: 400 V, number of spindles: 12, power: 111.2 kW (151.19 HP), chip removal: 20 mm, input frequency: 50 Hz, input current: 327 A, For sale is a heavy-duty, industrial-grade four-sided planer Rex 410 complete with extensive HIT mechanization, designed for the efficient processing of structural timber, KVH/BSH products, and profile boards. The system is suitable for: • Pre-planing • Lamella planing • Final planing of KVH/BSH • Profile production • Continuous beam processing including turning and patching The machine features 12 spindle units including chamfering devices and is engineered for high material removal rates as well as large cross-sections. Ljdoyk E R Iepfx Ab Tsrh Sold ex-location (machine is not dismantled). If you have any questions or require further information, please feel free to send us a message or give us a call.
