Genta Srl

Condition: used, Year of construction: 1998, functionality: fully functional, Brand: TMP - TIAZHMEJPRESS - Model: KB 4043 Year: 1998 Mechanical press 2000 t. Movable table: 5000 x 2700 mm. Itjdpfx Ajyibu Rsb Tjc Distance between uprights: 5120 mm. Lower and upper pneumatic cushion. Slide stroke: 900 mm. Slide adjustment: 800 mm. Closed press height: 1800 mm. Microinch force: 400 t. Lower cushion adjustment: 350 mm. Lower cushion force: 400 t. Upper cushion force: 200 t. Upper cushion stroke: 200 mm.

Condition: used, Year of construction: 1963, Single-column hydraulic press MÜLLER ZE 250/300-12.5 1.3-U, No. 586, year of manufacture 1963, pressing force 250 t, working area 1,300 x 1,100 x 1,000 mm, retrofitted with ROMA safety roller door (year of manufacture 2012) Iedoyhqqnjpfx Ab Tstc

Condition: used, Year of construction: 1998, functionality: fully functional, Brand: TMP - TIAZHMEJPRESS - Model: KB 4043 Year: 1998 Mechanical press 2000 t. Movable table: 5000 x 2700 mm. Distance between uprights: 5120 mm. Lower and upper pneumatic cushion. Slide stroke: 900 mm. Slide adjustment: 800 mm. Itjdpfoyg E Dmox Ab Tsc Closed press height: 1800 mm. Microinch force: 400 t. Lower cushion adjustment: 350 mm. Lower cushion force: 400 t. Upper cushion force: 200 t. Upper cushion stroke: 200 mm.

Condition: good (used), Year of construction: 1995, table height: 950 mm, total height: 3,800 mm, table width: 1,250 mm, table length: 1,000 mm, installation height: 900 mm, pressing force: 120 t, total length: 2,100 mm, total width: 2,050 mm, control cabinet height: 1,900 mm, control cabinet length: 600 mm, control cabinet width: 500 mm, retraction force: 5 t, stroke length: 400 mm, Equipment: safety light barrier, Deep drawing press, press power 120 to, stroke 400 mm, distance between tabels 900 mm, with oil cooler, light security bareer, dimension 2100x2050x3800 mm, weight ca. 13400 kgs Itsdoycin Uspfx Ab Tec

Condition: used, Year of construction: 1986, Make: MÜLLER, Model: ZE400-20.24.1, Year of manufacture: 1986, Machine No.: 498601, Max. pressure: 400 t, Clamping area (table): 2,000 x 1,300 mm, Clamping area (ram): 2,000 x 1,300 mm, Installation height min./max.: 600-1,400 mm, Ram stroke: 800 mm, Ram adjustment: 200 mm, Table draw cushion pressure: 5-160 t, Table draw cushion stroke: 350 mm, Ram draw cushion pressure: 5-40 t, Ram cushion stroke: 125 mm, 2x two-hand operation, safety guard system, press control, 2 accessory cabinets with contents. +++ Attention: This machine is part of an online auction! +++ Itsdpfx Aox R D R Ueb Tjc

Condition: used, Year of construction: 1980, functionality: limited functionality, WAGNER MECHANICAL ECCENTRIC PRESS — 500 TON — DOUBLE COLUMN Brand: Wagner Model: 500-ton eccentric press Year: 1980 Mechanical overhaul: 2010 Electrical panel: overhauled 2011 Condition: partially functional Type: double column – eccentric system Strokes/min: 0–30 Ram stroke: 300 mm Ram adjustment: 140 mm Iedpfxsx A Akze Ab Tstc Clearance at TDC: 1100 mm Front opening between uprights: 1850 mm Side window: 800 mm Table: 1800 × 1000 mm Ram: 1800 × 1000 mm Number of pressure points: 2 Ram guides: 8 Guards: front and rear Machine dimensions: 3000 × 2000 × 6000 mm Weight: 55 tons Foundation required: 100 cm Accessories: ELMEA L500 POWER SUPPLY feeder Status: visible in operation

Condition: excellent (used), functionality: fully functional, die cushion stroke: 400 mm, table width: 1,900 mm, table length: 3,000 mm, installation height: 1,800 mm, distance between stands: 3,040 mm, pressing force: 1,000 t, die cushion force: 400 t, stroke length: 1,400 mm, ram plate width: 1,900 mm, ram plate length: 3,000 mm, Technical data: FORCES Ram force: 10,000 kN Ram return force: 1,000 kN Ram cushion force: 2,000 kN Drawing cushion force (blank holder): 4,000 kN STROKES Ram stroke: 1,400 mm Ram cushion stroke: 200 mm Drawing cushion stroke: 400 mm Itodpfsxpctcex Ab Tec Die height (table to ram) Stroke upper position: 1,800 mm Stroke lower position: 400 mm Table size: 3,000 x 1,900 mm Ram size: 3,000 x 1,900 mm Clear space between uprights (left/right): approx. 3,040 mm Table height above floor: 450 mm Table plate as sliding plate Sliding direction: front Sliding travel: 3,000 mm Sliding speed: 0.5 - 6 m/min Load capacity: 20 t Table and ram deflection at F=max. 2/3 surface load: 0.125 mm/m Drawing cushion size: 2,450 x 1,550 mm Drawing cushion hole pattern From left to right: 17 rows = 16 spaces at 150 mm each From front to back: 11 rows = 10 spaces at 150 mm each Ram cushion size: 2,450 x 1,550 mm Ram cushion hole pattern From left to right: 17 rows = 16 spaces at 150 mm each From front to back: 11 rows = 10 spaces at 150 mm each Height above floor: approx. 7,700 mm Weight, static: approx. 160,000 kg Installed power, total: approx. 265 kW Drive power (main drives, 2 x 110 kW): 220 kW SPEEDS Ram Rapid down speed: approx. 600 mm/s Working speed max. up to 2,500 kN: approx. 37 mm/s Working speed F max.: approx. 16 mm/s Return speed: approx. 430 mm/s Die spotting speed: approx. ≤ 10 mm/s The above information is taken from the machine documentation. The seller accepts no liability for completeness or accuracy. The actual technical data and functions of the machine are decisive.

Condition: excellent (used), functionality: fully functional, table height: 585 mm, die cushion stroke: 280 mm, table width: 2,900 mm, table length: 5,000 mm, installation height: 1,190 mm, pressing force: 2,000 t, die cushion force: 380 t, stroke length: 1,050 mm, The machine on offer is a hydraulic tryout press. This press underwent a comprehensive general overhaul in 2014 by a specialist company in Germany. During the overhaul, the mechanics, electrics, and hydraulics were completely renewed and modernized. Only components from renowned European manufacturers were used for the refurbishment. A particular highlight of this tryout press is that both the ram and the bolster are equipped with draw cushions. The bolster is designed as a movable table. The ram can be stopped and mechanically locked in any position as required. Technical specifications: Table size: 5000 mm x 2900 mm Draw cushion size: 4200 mm x 1800 mm Itsdpfx Abjxgz Rns Tsc Draw cushion stroke: 280 mm Draw cushion force: 380 t Draw cushion operation: 4-way controlled draw cushion, compensation not required Table height above floor: 585 mm Ram size: 5000 mm x 2900 mm Ram force: 2000 t Ram cushion size: 2400 mm x 1200 mm Ram cushion stroke: 150 mm Ram cushion force: 200 t Ram return force: approx. 120 t Ram up position: 2350 mm Ram stroke: 1050 mm Air pins retracted by 185 mm Max. die installation height: 1190 mm Lower clamping: manual Upper clamping: manual Centering: via air pin pattern Sliding bolster: 3000 mm travel distance Ram locking: stepless Cut stroke damping: not available The above information is based on the machine documentation. The seller does not assume any liability for the completeness or accuracy of these details. The actual technical specifications and functions of the machine are decisive.

Condition: used, Year of construction: 1989, Pressure total: 800 ton Ram stroke: 700 mm Slide adjustment: 600 mm Shut height (stroke down, adjustment up): 1475 mm Ijdpexbpb Rjfx Ab Tetc Free frontal opening L-R: 3700 mm Free lateral opening F-B: 2300 mm Table surface area : 3600 x 2200 mm Slide area: 3500 x 2070 mm Die cushion capacity in table: 150 ton Die cushion stroke: 250 mm Die cushion pad area: 2780 x 1570 mm Ejector in ram: 60 ton Ejector stroke in ram: 150 mm Number of strokes: 7 - 21 s.p.m. Required power: kW Height over floor approx.: 9510 mm Weight of machine approx.: 260 ton

Condition: ready for operation (used), Year of construction: 1992, functionality: fully functional, machine/vehicle number: H92-2348, table width: 1,150 mm, table length: 1,250 mm, pressing force: 250 t, stroke length: 400 mm, Control system retrofit to SIEMENS (2005) TECHNICAL DETAILS Press force at 260 bar: 250 t Table clamping area: 1,150 x 1,250 mm Ram clamping area: 1,150 x 1,250 mm Draw cushion area: 800 x 1,000 mm Draw cushion force at 200 bar: 100 t Draw cushion stroke: 150 mm Installation height: 700 mm Ram stroke: 400 mm Oil quantity: 2,300 l Return speed: 330 mm/s Rapid approach speed: 365 mm/s Working speed (partial load): 36 mm/s Working speed (full load): 15 mm/s MACHINE DETAILS Power requirement: 45 kW Weight without oil: 28 t Iedpfx Aowur R Rjb Tetc Machine height: 5,400 mm EQUIPMENT - Programming language: Polish

Condition: used, Year of construction: 2005, Pressure total: 400 ton Ram stroke: 500 mm Slide adjustment: 350 mm Daylight: 1250 mm Table surface area : 2500 x 1500 mm Slide area: 2500 x 1500 mm Number of strokes: 15 - 30 s.p.m. Die weight at the ram max.: 4000 kg Required power: 70 kW Height over floor approx.: 8000 mm Weight of machine approx.: 150 ton Standard configuration without cushion Iedjwnpavepfx Ab Totc

Condition: used, Year of construction: 2005, Pressure total: 400 ton Ram stroke: 500 mm Slide adjustment: 350 mm Daylight: 1250 mm Table surface area : 2500 x 1500 mm Slide area: 2500 x 1500 mm Iodpfxewnn Rts Ab Tetc Die cushion capacity in table: 80 ton Die cushion stroke: 250 mm Number of strokes: 15 - 30 s.p.m. Die weight at the ram max.: 4000 kg Required power: 70 kW Height over floor approx.: 8000 mm Weight of machine approx.: 150 ton Standard configuration 2 cushion cylinder 2 pads

Condition: used, Pressure total: 500 ton Ram stroke: 500 mm Slide adjustment: 400 mm Daylight: 1350 mm Table surface area : 3000 x 1700 mm Slide area: 3000 x 1700 mm Die cushion capacity in table: 80 ton Isdpfxjwnnanj Ab Tetc Die cushion stroke: 250 mm Number of strokes: 20 s.p.m. Required power: 75 kW Height over floor approx.: 8000 mm Weight of machine approx.: 160 ton Standard configuration 2 cushion cylinder 1 pad

Condition: used, Year of construction: 1972, pressure 800 t distance between columns 3160 mm stroke 1100 mm control Siemens S5 distance table/blankh.,max. stroke up,adjustm. up 1900 mm table surface area 3100 x 1900 mm die-cushion pressure inside the table 300 t stroke of drawing cushion in table 400 mm die-cushion pressure in pusher 80 t stroke of drawing cushion in table 150 mm ram surface 3100 x 1900 mm die-cushion in pusher hydraulic, controlled die-cushion inside the table hydraulic, controlled total power requirement 200 kW weight of the machine ca. 150 t dimensions of the machine ca. 4,95 x 3,3 x 10,2 m Itodpfx Abevxwm Tj Tec

Condition: used, Year of construction: 1972, pressure 800 t distance between columns 3160 mm stroke 1100 mm control Siemens S5 distance table/blankh.,max. stroke up,adjustm. up 1900 mm Itodjvxwmmjpfx Ab Tec table surface area 3100 x 1900 mm die-cushion pressure inside the table 300 t stroke of drawing cushion in table 400 mm die-cushion pressure in pusher 80 t stroke of drawing cushion in table 150 mm ram surface 3100 x 1900 mm die-cushion in pusher hydraulic, controlled die-cushion inside the table hydraulic, controlled total power requirement 200 kW weight of the machine ca. 150 t dimensions of the machine ca. 4,95 x 3,3 x 10,2 m

Condition: used, Year of construction: 1972, pressure 800 t distance between columns 3160 mm stroke 1100 mm control Siemens S5 distance table/blankh.,max. stroke up,adjustm. up 1900 mm table surface area 3100 x 1900 mm Isdovxwmgspfx Ab Tetc die-cushion pressure inside the table 300 t stroke of drawing cushion in table 400 mm die-cushion pressure in pusher 80 t stroke of drawing cushion in table 150 mm ram surface 3100 x 1900 mm die-cushion in pusher hydraulic, controlled die-cushion inside the table hydraulic, controlled total power requirement 200 kW weight of the machine ca. 150 t dimensions of the machine ca. 4,95 x 3,3 x 10,2 m

Condition: used, Year of construction: 1972, pressure 800 t Iedpfxjvxwh Dj Ab Tetc distance between columns 3160 mm stroke 1100 mm distance table/blankh.,max. stroke up,adjustm. up 1900 mm table surface area 3100 x 1900 mm die-cushion pressure inside the table 300 t stroke of drawing cushion in table 400 mm die-cushion pressure in pusher 80 t stroke of drawing cushion in table 150 mm ram surface 3100 x 1900 mm die-cushion in pusher hydraulic, controlled die-cushion inside the table hydraulic, controlled

Condition: used, Year of construction: 1973, pressure 1600 t distance between columns 3160 mm ram stroke 1450 mm distance table/blankh.,max. stroke up,adjustm. up 2250 mm table surface area 4000 x 2200 mm ram pressure 1000 t pressure of blank holder 600 t stroke of blankholder at the bottom 1000 mm stroke of blankholder with adjustment 0-100 mm 1450 mm blank holder size 4000 x 2200 mm die-cushion pressure inside the table 360 t stroke of drawing cushion in table 275 / 400 mm ram surface 4000 x 2200 mm column travel -side 1100 mm die-cushion inside the table hydraulic, controlled die-cushion in pusher hydraulic, controlled oil volume 9000 l total power requirement 390 kW weight of the machine ca. 250 t dimensions of the machine ca. 6,0 x 4,3 x 10,5 m Head press (1600 tons) of a press line with five subsequent presses (800 tons) Ijdpfx Ajvxwhweb Tstc

Condition: used, Year of construction: 1973, pressure 1000 t distance between columns 4150 mm stroke 1200 mm distance table/blankh.,max. stroke up,adjustm. up 2100 mm table surface area 4000 x 2200 mm die-cushion pressure inside the table 360 t stroke of drawing cushion in table 300 mm die-cushion pressure in pusher 100 t Itedpfx Abevxwhqo Tec stroke of drawing cushion in pusher 150 mm ram surface 4000 x 2200 mm column travel -side 1300 mm die-cushion inside the table hydraulic, controlled die-cushion in pusher hydraulic, controlled Cut Shock absorption hydraulic weight of the machine ca. 280 t The machine was overtaken 1999.

Condition: used, Year of construction: 1973, pressure 1000 t distance between columns 4150 mm stroke 1200 mm distance table/blankh.,max. stroke up,adjustm. up 2100 mm table surface area 4000 x 2200 mm die-cushion pressure inside the table 360 t Iodpfx Asvxwhkjb Totc stroke of drawing cushion in table 300 mm die-cushion pressure in pusher 100 t stroke of drawing cushion in pusher 150 mm ram surface 4000 x 2200 mm column travel -side 1300 mm die-cushion inside the table hydraulic, controlled die-cushion in pusher hydraulic, controlled Cut Shock absorption hydraulic weight of the machine ca. 280 t The machine was overtaken 1999.

Condition: used, Year of construction: 1974, pressure 600 t Itsdpjvxwg Tefx Ab Tjc distance between columns 2600 mm stroke 900 mm distance table/blankh.,max. stroke up,adjustm. up 1600 mm table surface area 2500 x 1730 mm die-cushion pressure inside the table 250 t stroke of drawing cushion in table 400 mm die-cushion pressure in pusher 63 t stroke of drawing cushion in pusher 150 mm ram surface 2500 x 1730 mm column travel -side 1100 mm die-cushion inside the table hydraulic, controlled die-cushion in pusher hydraulic, controlled overhauled in 2005

Condition: used, Year of construction: 1974, pressure 600 t distance between columns 2600 mm stroke 900 mm distance table/blankh.,max. stroke up,adjustm. up 1600 mm table surface area 2500 x 1730 mm Itedpfx Aovxwg Hsb Tjc die-cushion pressure inside the table 250 t stroke of drawing cushion in table 400 mm die-cushion pressure in pusher 63 t stroke of drawing cushion in pusher 150 mm ram surface 2500 x 1730 mm column travel -side 1100 mm die-cushion inside the table hydraulic, controlled die-cushion in pusher hydraulic, controlled overhauled in 2005

Condition: used, Year of construction: 1974, pressure 600 t distance between columns 2600 mm stroke 900 mm distance table/blankh.,max. stroke up,adjustm. up 1600 mm table surface area 2500 x 1730 mm die-cushion pressure inside the table 250 t stroke of drawing cushion in table 400 mm die-cushion pressure in pusher 63 t stroke of drawing cushion in pusher 150 mm ram surface 2500 x 1730 mm column travel -side 1100 mm Itodpfx Abevxwgyj Tec die-cushion inside the table hydraulic, controlled die-cushion in pusher hydraulic, controlled overhauled in 2005

Condition: used, Year of construction: 1972, pressure 800 t distance between columns 3160 mm stroke 1100 mm control Siemens S5 Itodpfsvxwgtjx Ab Tsc distance table/blankh.,max. stroke up,adjustm. up 1900 mm table surface area 3100 x 1900 mm die-cushion pressure inside the table 300 t stroke of drawing cushion in table 400 mm die-cushion pressure in pusher 80 t stroke of drawing cushion in table 150 mm ram surface 3100 x 1900 mm die-cushion in pusher hydraulic, controlled die-cushion inside the table hydraulic, controlled total power requirement 200 kW weight of the machine ca. 150 t dimensions of the machine ca. 4,95 x 3,3 x 10,2 m

Condition: used, Year of construction: 1973, pressure 1000 t distance between columns 4150 mm stroke 1200 mm distance table/blankh.,max. stroke up,adjustm. up 2100 mm table surface area 4000 x 2200 mm die-cushion pressure inside the table 360 t stroke of drawing cushion in table 300 mm die-cushion pressure in pusher 100 t stroke of drawing cushion in pusher 150 mm ram surface 4000 x 2200 mm column travel -side 1300 mm die-cushion inside the table hydraulic, controlled die-cushion in pusher hydraulic, controlled Cut Shock absorption hydraulic Control Siemens S7 height over floor 7,7 m total power requirement 300 kW weight of the machine ca. 280 t Itjdpsvxwggofx Ab Tsc dimensions of the machine ca. 5,75 x 4,3 x 9,55 m Year of construction 1973 Modernization 2005 with oil-hydraulic drive, hydraulically controlled drawing cushion in the table and Ram, hydraulic cutting impact damping stored dismantled - short video available from the seller before dismantling
