Condition: used, Semi-automatic table punching machine Working width max. 340 mm Punching thickness up to 3.5 mm (recommended 2.0-2.5 mm) Mechanical cycle rate up to 1,200 per hour Tools: 2:1, 6.0 mm, Ø 2:1, 6 x 6 mm, Square Kdodpfx Aboy Tzdks Uol

Condition: used, TECHNICAL DETAILS TRAVELS - Travels on X/Y/Z axes : 600x400x310 [mm] - Travels on U/V axes : [mm] - Max. taper : [°/mm] PART - Max. part dimensions : 1050x820x300 [mm] - Max. part weight : 1000 [kg] WIRE GUIDE - Wire diameter : 0.1-0.3 [mm] - Coil weight : 16 [kg] POWER SUPPLY - Supply voltage : 380 [V] - Total installed power : 13 [kVA] WEIGHT & DIMENSIONS - Machine floor space : 2650x3050 [mm] - Machine height : 2070 [mm] - Machine weight : 3600 [kg] EQUIPMENT - CNC : Fanuc 31iw-model B Kjdpfx Absy Tzc Tj Uodl - Cooling unit - Filtration unit

Condition: used, TECHNICAL DETAILS - Number of axes : 5 MILLING SPINDLE - Tool holder type : BT40 - Spindle power : 36.5 [kW] - Spindle speeds : 12000 [rpm] - B Rotary Axis : 90 [°] (+/-) LINEAR AXES - Travels on X/Y/Z axes : 1525 / 660 / 610 [mm] - Rapid traverses rates (X/Y/Z) : 32 / 32 / 24 [mm/min] TOOL CHANGER - Auto. Tool Changer type : Bras chargeur - Tool magazine capacity : 40 TABLE - Table dimensions : 1680 x 660 [mm] - Distance table / spindle nose (min./max.) : 12.7 - 622.3 [mm] - Maximum weight upon table : 1360 [kg] - Diameter of the C-type rotary table : 600 [mm] - Travel : 360 [°] - Maximum load on the rotary table : 500 [kg] POWER SUPPLY - Supply voltage : 400 [V] - Total installed power : 69 [kVA] WEIGHT & DIMENSIONS - Machine weight : 9.800 [kg] EQUIPMENT - CNC : WinMax / MAX5 - Electronic handwheel Kdjdjy Tzc Hopfx Ab Uol - Coolant tank * with high-pressure pump - Coolant through spindle - Chips conveyor - Spindle cooling unit - Tool probe

Condition: used, TECHNICAL DETAILS - Number of axes : 3 MILLING SPINDLE - Tool holder type : BT40 - Spindle power : 15 [kW] - Spindle speeds : 10000 [rpm] LINEAR AXES - Travels on X/Y/Z axes : 762 x 516 x 570 [mm] - Rapid traverses rates (X/Y/Z) : 40 / 40 / 36 [m/min] Kdsdpfxoy Tzcye Ab Uel TOOL CHANGER - Auto. Tool Changer type : Bras chargeur - Tool magazine capacity : 30 - Tool exchange time : 1,3 [sec] PALLET CHANGER - Pallet size : 860 x 570 [mm] - Pallets number : 2 - Pallet exchange time : 5 [sec] POWER SUPPLY - Supply voltage : 200 [V] - Total installed power : 40,25 [kVA] WEIGHT & DIMENSIONS - Machine floor space : 3130x3260 [mm] - Machine height : 3130 [mm] - Machine weight : 9200 [kg] EQUIPMENT - CNC : Fanuc 0i-MD Interface : PCMCIA, RS232 / RJ45 - 3 colors status lamp - Coolant tank * with high-pressure pump : 20 [bars] - Coolant through spindle - Spindle cooling unit - Chips conveyor - Electric transformer

Condition: used, TECHNICAL DETAILS - Number of axes : 5 MILLING SPINDLE - Tool holder type : HSK63 - Spindle speeds : 18000 [rpm] - Spindle power : 25 [kW] LINEAR AXES - Travels on X/Y/Z axes : 760 / 510 / 520 [mm] - Rapid traverses rates (X/Y/Z) : 45 / 45 / 40 [mm/min] A ROTARY AXIS - Travel : -110 / +30 [°] - C ROTARY AXIS - Travel : 360 [°] - Rapid traverse rate : 25 [rpm] TOOL CHANGER - Auto. Tool Changer type : Bras chargeur - Tool magazine capacity : 40 TABLE - Table dimensions : Ø248 [mm] - Maximum weight upon table : 200 [kg] POWER SUPPLY - Supply voltage : 400 [V] Kdsdpfxsy Tzcte Ab Ujl - Total installed power : 48 [kVA] WEIGHT & DIMENSIONS - Machine floor space : 3.940 x 4.060 [mm] - Machine height : 2.865 [mm] - Machine weight : 6000 [kg] EQUIPMENT - CNC : Hurco WinMax / MAX5 - Interactive programming - Electronic handwheel - Coolant tank * with high-pressure pump - Coolant through spindle - Chips conveyor - Spindle cooling unit

Condition: used, Surface grinder MAEGERLE MFP-125-35 Kdedpoy Tzcmofx Ab Ujl

Condition: used, TECHNICAL DETAILS - Number of axes : 5 MILLING SPINDLE - Tool holder type : BT40 - Spindle speeds : 12000 [rpm] - Spindle power : 18 [kW] LINEAR AXES - Travels on X/Y/Z axes : 800 / 700 / 510 [mm] - Rapid traverses rates (X/Y/Z) : 35 / 35 / 35 [mm/min] A ROTARY AXIS - Travel : -110 / +30 [°] - C ROTARY AXIS - Travel : 360 [°] TOOL CHANGER - Auto. Tool Changer type : Bras chargeur - Tool magazine capacity : 32 TABLE Kdsdoy Tzcgspfx Ab Uol - Table dimensions : 610 x 530 [mm] - Maximum weight upon table : 350 [kg] POWER SUPPLY - Supply voltage : 400 [V] WEIGHT & DIMENSIONS - Machine floor space : 4.000 x 2.700 [mm] - Machine height : 2.600 [mm] EQUIPMENT - CNC : Hurco Ultimax - Interactive programming - Electronic handwheel - Coolant tank

Condition: used, TECHNICAL DETAILS - Number of axes : 4 MAIN SPINDLE - Spindle nose : A2-11" - Spindle power : 51 [kW] - Spindle speeds : 2200 [rpm] - Max. bar diameter : 127 [mm] - Max. turning diameter : 550 [mm] - Max. diameter on bench : 950 [mm] - C axis indexing precision : 0.001 [°] TURRET - Number of positions : 16 - Number of motorized positions : 16 - X/Z stroke : 380/2200 [mm] - Y stroke : +80/-60 [mm] - Live tools speed : 12000 [rpm] - Live tools power : 13.7 [kW] TAILSTOCK - Tailstock type : Automatique POWER SUPPLY - Supply voltage : 400 [V] - Total installed power : 65 [kW] WEIGHT & DIMENSIONS - Machine floor space : 5375 x 2361 [mm] - Machine height : 2236 [mm] Kedpfx Aboy Tzcaj Uedl - Machine weight : 12600 [kg] MACHINE HOURS - Number of working hours : 3012 [h] EQUIPMENT - CNC : Fanuc 32i-MODEL B - Coolant tank - Chips conveyor - Rest : SMW SLUX4

Condition: used, TECHNICAL DETAILS - Number of axes : 4 MAIN SPINDLE - Spindle nose : ASA 11'' A2 - Spindle power : 39 / 48 [kW] - Spindle speeds : 3000 [rpm] - Max. bar diameter : 95 [mm] - Max. turning diameter : 550 [mm] - Max. diameter on bench : 920 [mm] - Maximum rotation diameter on the carriage : 745 [mm] - C axis indexing precision : 0,001 [°] TURRET Kodpjy Tzb Aefx Ab Uedl - Number of positions : 12 - Number of motorized positions : 12 - Live tools speed : 4000 [rpm] - Live tools power : 16 [kW] - X/Z stroke : 315 / 1350 [mm] - Y stroke : [mm] - Rapid traverses rates (X/Y/Z) : 30 / 15 / 30 [m/min] TAILSTOCK - Tailstock stroke : 1350 [mm] POWER SUPPLY - Supply voltage : 400 [V] - Total installed power : 65 [kVA] WEIGHT & DIMENSIONS - Machine floor space : 4088 x 2020 [mm] - Machine height : 2240 [mm] - Machine weight : 9000 [kg] MACHINE HOURS - Number of hours under power : 35873 [h] EQUIPMENT - CNC : Fanuc 32i Model B - 3 colors status lamp - Coolant tank * with high-pressure pump - Chips conveyor - Spindle cooling unit - Tool probe : Renishaw

Condition: used, TECHNICAL DETAILS - Number of axes : 3 MAIN SPINDLE - Spindle power : 42 [kW] - Spindle speeds : 3500 [rpm] - Maximum diameter of rotation on the bench : 760 [mm] - Maximum rotation diameter on the carriage : 600 [mm] - Max. turning diameter : 460 [mm] - Max. chuck diameter : 250 / 315 [mm] - C axis indexing precision : 0.001 [°] TURRET - Number of positions : 12 - X/Z stroke : 310 / 640 [mm] TAILSTOCK - Distance between spindle and tailstock centre : 689 [mm] Ksdpfx Aboy Tzbve Ujdl WEIGHT & DIMENSIONS - Machine floor space : 2.540 x 1.760 [mm] - Machine height : 1.880 [mm] - Machine weight : 6600 [kg] EQUIPMENT - CNC : Fanuc Series 32i Model B - Coolant tank - Chips conveyor - Tool probe : Renishaw - Bar loader : LNS Quick Load Servo 80 S2

Condition: used, TECHNICAL DETAILS - Number of axes : 3 MAIN SPINDLE - Spindle nose : A2-8 - Spindle power : 27 [kW] - Spindle speeds : 3500 [rpm] - Maximum diameter of rotation on the bench : 920 [mm] - Maximum rotation diameter on the carriage : 745 [mm] - Max. turning diameter : 550 [mm] - C axis indexing precision : 0.001 [°] TURRET - Number of positions : 12 - Number of motorized positions : 12 - Live tools speed : 4000 [rpm] - Live tools power : 16 [kW] - X/Z stroke : 315 /1350 [mm] TAILSTOCK - Distance between spindle and tailstock centre : 1424 [mm] POWER SUPPLY - Supply voltage : 4000 [V] - Total installed power : 45 [kVA] WEIGHT & DIMENSIONS Kjdpsy Tzbpjfx Ab Uedl - Machine floor space : 4088 x 2020 [mm] - Machine height : 2236 [mm] - Machine weight : 8100 [kg] MACHINE HOURS - Number of hours under power : 34000 [h] EQUIPMENT - CNC : Fanuc Series 32i Model A - 3 colors status lamp - Coolant tank - Chips conveyor - Spindle cooling unit

Condition: used, mileage: 73,328 km, power: 184 kW (250.17 HP), first registration: 10/2009, fuel type: diesel, tire size: 385/55R22.5, axle configuration: 6x2, wheelbase: 5,100 mm, fuel: diesel, brakes: engine braking, color: green, gearing type: mechanical, number of gears: 8, emission class: euro5, suspension: steel-air, total length: 9,750 mm, total width: 2,550 mm, loading space length: 6,400 mm, loading space width: 2,460 mm, Year of construction: 2009, Equipment: ABS, AdBlue, central locking, crane, cruise control, differential lock, electric window regulation, traction control, trailer coupling, = Additional Options and Accessories = - Air suspension - Fifth wheel coupling - PTO (Power Take-Off) - Radio/CD player - Disc brakes - Sun visor - Toolbox = Notes = DAF CF 75.250 6x2 Liftable steering axle. 8-speed manual gearbox. Palfinger PK 23002 4 x outriggers 4 x hydraulic extension. 2 x manual extension. Toolbox. Hardwood floor. Stacking area. Trailer coupling. = Further Information = Technical Information Number of cylinders: 6 Axle Configuration Brakes: Disc brakes Front axle: Tire size: 385/55R22.5; Steerable; Tire tread depth left: 50%; Tire tread depth right: 50%; Suspension: Leaf spring suspension Rear axle 1: Tire size: 315/70R22.5; Dual tires; Tire tread depth left inner: 60%; Tire tread depth left outer: 60%; Tire tread depth right inner: 60%; Tire tread depth right outer: 60%; Suspension: Air suspension Rear axle 2: Tire size: 385/55R22.5; Steerable; Tire tread depth left: 50%; Tire tread depth right: 50%; Suspension: Air suspension Weights Unladen weight: 14,645 kg Payload: 13,355 kg GVW (Gross Vehicle Weight): 28,000 kg Functional Crane: Palfinger Ksdpfey Ty Smsx Ab Usdl Maintenance APK (Technical Inspection): Valid until 08.2026 Financial Information Price: Upon request Identification Model number: DAF CF 75 6X2 / PALFINGER 23 tm = Company Information = ALL PRICES ARE NET FOR EXPORT. (Joris Versteijnen NL-DE-GB, Wouter Greutink NL-DE-GB-ES-IT, Govorim po ryccki) We make every effort to provide accurate information; however, no rights can be derived from the information provided in these texts.

Condition: used, Oil-water separator KAESER BEKO, type Öwamat Tank diameter: 600 mm Overall height: 1200 mm With activated carbon filter Space requirement: Ø 700 x 1200 mm Weight: approx. 30 kg In good condition. Kdsdpfxjy Ty Sas Ab Ujl

Condition: used, Year of construction: 1999, x-travel 1250 mm y-travel 850 mm z-travel 800 mm Kodpfjy Ty R Asx Ab Uedl Control Heidenhain MillPlus

Condition: used, Year of construction: 1988, plate width 2500 mm plate depth 4000 mm plate height 345 mm no. of flutes 11 Kedpfoy Ty Rvjx Ab Usdl 2 weight of the machine ca. 7000 t

Condition: used, Year of construction: 1974, mechanical ja Kjdpfx Aey Ty Rpeb Ujdl centre distance 2000 mm weight of the machine ca. 7,9 t

Condition: used, Year of construction: 1974, mechanical ja centre distance 2000 mm weight of the machine ca. 7,9 t Kjdpfxey Ty Rij Ab Ujdl

Condition: used, Year of construction: 1999, centre distance 2200 mm Kodpfxey Ty Rcs Ab Ujdl digital ja

Condition: used, Year of construction: 1970, mechanical ja centre distance 2000 mm Kdedpfjy Ty N Sex Ab Uol weight of the machine ca. 7,9 t

Condition: used, x-travel 560 mm y-travel 500 mm z-travel 410 mm Control Heidenhain TNC 355 In our opinion, the machine is in good used condition and can be inspected under power by appointment. Accessories, tools and clamping devices shown are only included in the scope of delivery if this is noted in the additional information. Kdedpfsy Ty Nrsx Ab Ujl Subject to changes and errors in the technical data and information as well as prior sale!

Condition: used, mileage: 171,000 km, power: 309 kW (420.12 HP), first registration: 05/2019, fuel type: diesel, empty load weight: 13,275 kg, maximum load weight: 18,725 kg, overall weight: 32,000 kg, tire size: 315/80R22.5, axle configuration: 8x4, wheelbase: 4,300 mm, brakes: engine braking, color: red, driver cabin: day cab, gearing type: automatic, emission class: euro6, suspension: steel-air, number of seats: 2, Equipment: ABS, air conditioning, cabin, cruise control, differential lock, fog lights, seat heater, traction control, trailer coupling, Vehicle location: en route / in transit, body: flatbed, 1x comfort seat, seat heating, rear window, electric mirrors, heated mirrors, electric window left, electric window right, air conditioning, sun visor, cruise control, ABS (anti-lock braking system), traction control (ASR), constant throttle, auxiliary drive, automatic transmission, differential lock, fog lights, rotating beacon, leaf-air suspension, trailer hitch with air and electrical connections, aluminum tank, underrun protection, hydraulic cross-locking, sunroof, green environmental badge. Kdodpjy Ty Nljfx Ab Uel Wheelbase: 4300 mm, body capacity: 26 tons, Hiab Multilift XR26S53 roll-off system for containers up to 6.5 m (extendable underrun protection), transmission: 12TX-2820 OD! Matching roll-off containers available for an extra charge! All information is without guarantee as the vehicle is currently en route! ACCESSORY INFORMATION WITHOUT GUARANTEE, subject to changes, prior sale and errors!

Condition: used, x-travel 800 mm y-travel 600 mm z-travel 550 mm Control Deckel Dialog 11 In our opinion, the machine is in good used condition and can be inspected under power by appointment. Accessories, tools and clamping devices shown are only included in the scope of delivery if this is noted in the additional information. Ksdpfx Ajy Ty Nfeb Uodl Subject to changes and errors in the technical data and information as well as prior sale!

Condition: used, x-travel 300 mm y-travel 300 mm z-travel 400 mm Control Dialog 11 turning speed range - main spindle 40 - 4000 min/-1 tool taper SK 40 swivellable +/- 90 ° quill stroke 80 mm In our opinion, the machine is in very good used condition and can be inspected under power by appointment. Kdjdpfxsy Ty I Uo Ab Usl Accessories: - Cabin Accessories, tools and clamping devices shown are only included in the scope of delivery if this is noted in the additional information. Changes and errors in the technical data and information as well as prior sale reserved!

Condition: used, Year of construction: 2003, turning diameter over bed 330 mm centre distance 1.000 mm centre height 167 mm spindle bore 38 mm turning diameter over cross slideways 210 mm spindle tunring speed 40 - 2.500 U/min x-axis 190 mm z-axis 92 mm In our assessment, the machine is in good used condition and can be inspected under power by appointment. Accessories, as well as the tools and clamping devices shown in the images, are included in the scope of delivery only if explicitly noted in the additional information. Subject to changes, errors in technical data and specifications, and prior sale! Kdedpoy Ty I Isfx Ab Uol

Condition: used, Year of construction: 2008, x-travel 700 mm y-travel 420 mm z-travel 610 mm Control Heidenhain output 22 kVA weight ca. 5.200 kg In our assessment, the machine is in good used condition and can be inspected under power by appointment. Accessories, as well as the tools and clamping devices shown in the images, are included in the scope of delivery only if explicitly noted in the additional information. Kdjdpfoy Ty Izjx Ab Usl Subject to changes, errors in technical data and specifications, and prior sale!
