Condition: used, Kitchen & Walker E50-1400 Radial Arm Drill Nwodpoymg Ruefx Ag Iec Serial number 3865. Tee slotted box table to two faces, Brake, Light, coolant, 5 MT, 25-1560 RPM.

Condition: used, Year of construction: 1978, machine/vehicle number: 78004, type of input current: three-phase, We are offering this used Csepel 12UH/1600 radial drilling machine, year of manufacture 1978. Model: 12UH/1600 Serial number: 78004 Power type: 3~ Wiring diagram no.: 358000 Nwedpfx Ageyh Uaqj Ioc If you have any questions or require further information, please feel free to send us a message or give us a call.

Condition: excellent (used), Year of construction: 2018, bore capacity in steel (diameter) 75 mm spindle taper: MT 5 spindle stroke - max. 380 mm transmission ratio 2 11,2 - 2.000 quill stroke 16 mm feed for quill 1: 16 Njdpfoyh Rqfsx Ag Ijwc spindle throat 2000/ 38 mm spindle drive 15 kW weight 7,1 t Thread in steel, strength 600 N/mm² max. M75x4 Vertical swivel arm adjustment max. 950 mm Drill slide adjustment on the swivel arm 1614 mm Distance between spindle nose and clamping surface max. / min. 2000/670 Accessories: Heidenhain Radial digital display, clamping cube 1000 x 750 x 500 mm Coolant system, work light

Condition: excellent (used), Year of construction: 2003, column diameter: 400 mm, drill diameter: 65 mm, Drilling ; Tapping in all directions Can be moved in 7 axes Fast preparation, accuracy and performence on heavy and bulky parts. Field using Turbines, Generators, Compressors, Steel Construction, Boilers Nwedpfx Ageyh Dr Ns Iec Containers, Chemoical equipment, furnces of cement work and shipbuilding Arm Length: 2070mm Max. drill Ø cast: 65mm Max. tap Ø: 48M Stroke pinole: 350mm Max. distance spindle - table:1550mm Min. distance spindle - table:305mm Speeds / ranges: 900Rpm Spindle Taper: 5ISO/Bt/Mk Column sleeve: 400mm Power: 4kW Max. drill Ø steel: 50mm Length: 3500mm Width: 1325mm Height: 3400mm Weight: 6570kg Please Note: The information on this page has been obtained to the best of our ability and belief, and from the manufacturers where possible. It is given in good faith, but its accuracy can not be guaranteed. Accordingly, it will not form a representation or constitute contractual terms. We advise you to check any vital details!

Condition: excellent (used), Year of construction: 2012, bore capacity in steel (diameter) 62 mm Nwedpfx Aeyhq T Nsg Ijc arm length 350-1600 mm workpiece height max. 1250 mm distance spindle nose and table 350-1250 mm Boring depth max. 315 mm machine table 2400 x 1000 x 200 mm Turning speeds of the bor. spindle 38 - 2000 U / min spindle taper MT5 feed 0,06 - 1,00 mm/U engine output 4 kW stroke drive 1,5 kW oil pump 0,75 kW total power requirement 6 kW weight of the machine ca. 3,8 t dimensions of the machine ca. 2490 x 1050 x 2780 mm Steps of spindle speed: step-less Steps of spindle feed: 8 Speed of the arm up and down: 1.2 m/min Arm moving angle: ±180 degree Spindle moving distance of each dial revolution: 122 mm Max. spindle torque: 400 Nm Max. spindle feed resistance: 16000 N

Condition: repair required (used), functionality: limited functionality, type of input current: AC, total width: 905 mm, total length: 2,160 mm, total height: 2,500 mm, throat depth: 1,200 mm, For sale: Caser pillar drilling machine including extensive accessories: Scope of delivery: - Clamping block - Cross table - Vice Condition / Function: - The machine is basically functional - Defect: The arm clamping no longer works - Likely cause is an issue with the hydraulic valve - All other functions work as intended Notes: Nodpfx Ageyhmkke Ijwc - Sold as seen - Ideal for hobbyists, repair or for spare parts No warranty or returns Price: negotiable Collection preferred, shipping by arrangement

Condition: ready for operation (used), Year of construction: 1977, Asquith ODI Mk2 14/54 5MT Radial Arm Drilling Machine Spindle centre to column centre max. 54" Spindle travel 14″ Spindle taper 5 MT Spindle speeds (16) 40-2040rpm, Spindle motor 5.5 HP Spindle emergency brake Power elevation of arm Power locking to arm and head Box Table Coolant 415V Electrics 1977 Nedpfx Agsyg Skas Ijwc For sale with Jet Machinery Ltd Jet Machinery Stock No: #79026 Machine Serial Number: P.33677 Cost: £6,950.00 + VAT Whilst every effort has been made to ensure that the above information is accurate it is not guaranteed. We advise prospective purchasers to check any vital details. Health and Safety At Work Act 1974: It is not reasonably practical for ourselves as suppliers to ensure that for your application the goods comply with requirements of the Act with respect to guarding etc. Prospective purchasers should ensure that a guarding specialist inspect the goods prior to use.

Condition: good (used), Year of construction: 2018, machine/vehicle number: ZA-12080, Offer 25498 Technical Specifications: Nedpfx Aeyf A A Reg Iowc - Drilling capacity: 50 mm - Tapping unit up to: M 40 mm - Tool holder: MT 5 - Spindle stroke: 280 mm - Spindle speeds: 38 – 2,000 rpm - 6 feed rates: 0.08 – 0.83 mm/rev - Drive: 400 V / 5.5 kW - Throat depth min. / max.: 350 / 1,400 mm - Distance spindle to machined base plates min. / max.: 350 / 1,250 mm - Machined base plate with T-slots: W 1,650 x D 930 mm - Electric central clamping - Coolant system + lighting - Cube table - Required space approx.: W 2,300 x H 2,400 x D 1,050 mm - Weight approx.: 3,500 kg

Condition: ready for operation (used), Year of construction: 1984, total length: 1,600 mm, overall weight: 4,500 kg, drilling capacity: 55 mm, arm 1600 mm Nwodpfx Agoycdbie Iec hydraulic locking drilling capacity 55 mm cube weight 4500 kg

Condition: used, Drilling machine Brand: GSP Model: 407C27 Reach: 2250 mm Drilling capacity (steel): - normal feed: diameter 70 mm - slow feed: diameter 90 mm Carriage travel on arm: 1900 mm Drilling radius (min. - max.): 630 - 2500 mm Height (min. - max.): 500 - 1750 mm Vertical arm travel: 850 mm Nwedpfeyanmwox Ag Ijc Spindle stroke: 400 mm Spindle speeds: 25 to 1400 rpm Motor power: 6 kW Spindle taper: MT 5

Condition: excellent (used), Year of construction: 1994, Arm Length: 1600mm Max. drill Ø cast: 60mm Nsdpsx Sx D Ssfx Ag Ijwc Max. tap Ø: 42M Stroke pinole: 310mm Max. distance spindle - table:1505mm Min. distance spindle - table:320mm Floor / table area: 1470x986mm Speeds / ranges: 2500Rpm Spindle Taper: 6ISO/Bt/Mk Quill Ø: 55mm Power: 4kW Length: 2900mm Width: 1200mm Height: 3200mm Weight: 4700kg Please Note: The information on this page has been obtained to the best of our ability and belief, and from the manufacturers where possible. It is given in good faith, but its accuracy can not be guaranteed. Accordingly, it will not form a representation or constitute contractual terms. We advise you to check any vital details!

Condition: used, Year of construction: 1960, arm length 1600 mm tool adaptor ja fabric-no. 9787 Nodpfx Asx Ik Unsg Iewc weight 4,6 t with drill cube

Condition: used, Year of construction: 1973, total width: 720 mm, total length: 2,300 mm, total height: 2,700 mm, Empty weight: 3.000 kg - Year: 1973 - Documentation available: Yes - CE certificate present: No - Serial number: 95361 - Control: Conventional - Motor power: 3.0kW - Drilling depth: 330mm - Spindle speed max.: 1120rpm - Model: iaalboormachine - Tool holder: MK4 - Table width: 600mm - Table length: 750mm - Drilling capacity: 40mm - Travel X: 1000mm - Spindle diameter: 5mm - Travel Z: 900mm - Max. reach: 1300mm - Spindle speed min.: 28rpm - Transport dimensions: 2300mm x 720mm x 2700mm (l x w x h) - Transport weight [kg]: 3000kg - Transport packages [pcs.]: 1 Financial information VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Delivery and trade-in always possible for everything in the industrial sectors Lukas van Rossum Nwodpex Igczsfx Ag Ijc

Condition: good (used), Year of construction: 2017, machine/vehicle number: N 16601, Offer 25387 Technical Data: - Drilling capacity in steel: 60 mm - Drill spindle taper: MT 5 - Drill spindle stroke: 300 mm - Digital positioning display for stroke and position - Radius (throat): 1600 mm - Column diameter: 350 mm - Max. distance spindle – base plate: 350 – 1650 mm - Vertical travel of the arm: 1250 mm - Spindle speeds, stepless: 30 – 1500 rpm - Feeds, stepless: 1 – 600 mm/rev - Drive: 400 V / 8.9 kVA - 2 x cube tables - Coolant system Nedpox Ei D Aofx Ag Ijwc - Required floor space approx.: W 2490 x H 2980 x D 1060 mm - Weight approx.: 3800 kg

Condition: ready for operation (used), Year of construction: 2014, functionality: fully functional, drilling depth: 315 mm, rotational speed (max.): 2,000 rpm, throat depth: 1,600 mm, drilling capacity: 62 mm, column diameter: 350 mm, TECHNICAL DETAILS Drilling capacity in steel (diameter): 62 mm Thread cutting in steel (St 60): M46 Nsdpfxoxxrcxs Ag Ijwc Thread cutting in grey cast iron (GG 20): M52 Maximum drilling depth: 315 mm Machine table dimensions: 2,400 x 1,000 x 200 mm Throat: 1,600 mm Drill head travel (horizontal): 1,250 mm Arm stroke (vertical): 585 mm Column diameter: 350 mm Speed range: 38 – 2,000 rpm Spindle taper: MK 5 Feeds: 0.06 – 1 mm/rev MACHINE DETAILS Total power requirement: 5.5 kW Dimensions & Weight Space requirement: approx. 2,490 x 1,050 x 2,780 mm Machine weight: approx. 3,800 kg

Condition: ready for operation (used), Year of construction: 1996, functionality: fully functional, throat depth: 1,600 mm, drilling capacity: 60 mm, workpiece height (max.): 1,300 mm, spindle speed (max.): 1,450 rpm, spindle stroke: 350 mm, TECHNICAL DETAILS Drilling capacity in steel (diameter): 60 mm Arm reach: 1,600 mm Workpiece height – max. approx.: 1,300 mm Reaming diameter in steel: 80 mm Reaming diameter in cast iron: 100 mm Thread cutting in ST 60: M55 mm Spindle speed: 29–1,450 rpm Drill spindle: 100 mm Morse taper: MK5 Spindle stroke: 350 mm MACHINE DETAILS Nodpfx Aoxxrbnog Iswc Total power requirement: 7.5 kW Dimensions & Weight Space requirements (L x W x H): approx. 2,600 x 1,100 x 3,200 mm Machine weight approx.: 4,600 kg

Condition: used, Year of construction: 1990, Radial Drilling Machine Z3050 x 16 I Spindle: Ø 80 mm Spindle exit: 300 mm Spindle speed: from 25 to 2000 RPM Arm travel: 1600 mm Year of construction: 1990 Column diameter: Ø 320 mm Maxi distance spindle nose/table: 1800 mm Mini distance spindle nose/table: 1200 mm Table useful dimensions: 1700 x 1000 mm Tailstock CM5 Hydraulic clamping trolley + arm + column Auto advance non-functional Lubricant pump Nwodpfx Ajxxax Uog Isc Voltage: 380 V Dimensions (L x W x H): 2400 x 1200 x 3200 mm Weight: approx 4 T

Condition: used, Radial Drilling Machine GSP type 49S22 Spindle: Ø 125 mm Cone: CM6 Nodexu H Uujpfx Ag Iewc Spindle exit: 600 mm Spindle speed: from 17 to 1050 RPM Arm travel: 1800 mm Maxi height column travel: 1800 mm Column diameter: Ø 600 mm Total column height: 3000 mm Spindle speed: 11 kW Drilling/tapping function Mechanical locking of the column Hydraulic locking of the trolley Auto descent Delivered with one cube Cube dimensions: L 800 x W 560 x H 600 mm Table size: L 3300 x W 1400 x H 320 mm Voltage: 380 V Weight: 12 T

Condition: used, Year of construction: 1984, bore capacity in steel (diameter) 80 mm arm length 2000 mm workpiece height max. ca. 1300 mm borehole diameter in Stahl 80 mm borehole diameter in Guss 100 mm threading in St 60 M 68 mm spindle turning speed range 16 - 1250 U/min Njdpfjxqrc Nex Ag Iewc Spindle Speed 32 Stück spindle bore diameter / taper 110 mm / MK 5 spindle stroke 550 mm number of feeds 18 feed 0,06 - 3,0 mm/U distance spindle/base plate 480 bis 1800 mm column diameter 500 mm spindle drive 11 kW stroke drive 4 kW total power requirement 15 kW weight of the machine ca. 8500 kg base area 3190 x 1250 x 3600 mm with work table 1200 x 1200 x 720 mm, weight approx. 800 kg

Condition: excellent (used), Year of construction: 1987, functionality: fully functional, Drilling capacity in steel: 50 mm Throat depth: 30 - 1650 mm Max. workpiece height: 940 mm Horizontal travel of drill head: 1300 mm Spindle taper: MT 5 Drill spindle stroke: 360 mm Nwjdpfx Aoxl Tqqjg Ijc Spindle speeds: 31.5 - 1400 rpm in 12 steps Weight: 3.8 t

Condition: excellent (used), functionality: fully functional, RADIAL DRILL Nwodpsxf Hucefx Ag Iec BREDA 1250 x 55 MODEL R55 USED MACHINE INTERNAL CODE: SVR 319

Condition: excellent (used), Year of construction: 2018, Radial Drilling Machine KNUTH R 40 V Year of manufacture: 2018 Nedpsxdw Uksfx Ag Iswc Very little used Clamping cube Digital depth display Technical Data: WORKING AREA Drilling capacity: 40 mm Tapping capacity, cast iron: M 40 Tapping capacity, steel: M 32 Max. drilling depth: 260 mm Machine table dimensions: 2050 mm x 920 mm x 180 mm Cube table dimensions: 620 mm x 450 mm x 450 mm Arm reach: 300 mm - 1300 mm Distance spindle nose to table surface: 300 mm - 1200 mm Vertical arm travel: 640 mm Column diameter: 280 mm TRAVEL Horizontal travel of drilling head: 1000 mm MAIN SPINDLE Speed range: 54 rpm - 2150 rpm Spindle taper: 4 MT FEED Feeds: 0.1 mm/rev - 0.63 mm/rev DRIVE POWER Main drive motor power: 2.2 kW Lifting motor: 1.1 kW DIMENSIONS AND WEIGHT Dimensions (L x W x H): 2.07 m x 0.85 m x 2.43 m Weight: 2300 kg

Condition: new, bore capacity in steel (diameter) 32,0 mm arm length 310 - 820 mm workpiece height max. 370 - 870 mm turning speeds 75 - 1220 U/min spindle taper MT 4 MK base plate 825 x 690 mm threading 24 M quill stroke 250 mm quill feed 0,1/0,16/0,25 mm/U travel x / y 500 / 510 mm total power requirement 2,25 kW weight of the machine ca. 1200 kg. range L-W-H 1470 x 750 x 2100 mm Description : - Large-sized base plate - ideal for processing large workpieces - Thick-walled, polished column for increased sliding properties of the boom Nedpfxjxabrle Ag Iowc - Extension arm and drill head with independent hydraulic clamping - Simple height adjustment of the extension arm using a lifting motor - Ideal for drilling, countersinking, reaming and thread cutting - Hardened and ground gears, running in an oil bath - Good sliding of the drill head on the boom thanks to the ground surface scope of delivery : - Cube table - Reducing sleeves MK 5/4, MK 4/3, MK3 / 2 - LED machine light - First filling with Shell Tellus 46 - coolant device - lifting motor - hydraulic motor - operating tool - Height-adjustable protective cover

Condition: new, bore capacity in steel (diameter) 60,0 mm arm length 350 - 1.600 mm workpiece height max. 665 x 1.250 mm turning speeds 38 - 2.000 U/min spindle taper MT 5 MK base plate 960 x 1.760 mm threading 42 M quill stroke 325 mm total power requirement 4,0 kW weight of the machine ca. 3.800 kg. range L-W-H 2.600 x 1.100 x 2.770 mm scope of delivery : - Cube table - Drill chuck arbor MK 5 / B 16 - Reducing sleeves MK 5/4, MK 4/3, MK3 / 2 - LED machine light - First filling with Shell Tellus 46 - coolant device - Frequency converter - Digital speed display - lift motor - hydraulic motor Nwedpfxjxaa H Us Ag Iec - Height-adjustable protective cover - operating tool

Condition: new, bore capacity in steel (diameter) 50,0 mm arm length 350 - 1.590 mm workpiece height max. 645 - 1.240 mm turning speeds 25 - 2000 U/min spindle taper MT 5 MK base plate 980 x 1.600 mm Njdpsxaad Tjfx Ag Iswc threading 42 M quill stroke 320 mm total power requirement 4,0 kW weight of the machine ca. 3.500 kg. range L-W-H 2450 x 980 x 2840 mm Description : - Large-sized base plate - ideal for processing large workpieces - Thick-walled, polished column for increased sliding properties of the boom - Extension arm and drill head with independent hydraulic clamping - Simple height adjustment of the extension arm using a lifting motor - Ideal for drilling, countersinking, reaming and thread cutting - Hardened and ground gears, running in an oil bath - Good sliding of the drill head on the boom thanks to the ground surface scope of delivery : - Cube table - Reducing sleeves MK 5/4, MK 4/3, MK3 / 2 - LED machine light - First filling with Shell Tellus 46 - coolant device - lifting motor - hydraulic motor - operating tool - Height-adjustable protective cover
