Condition: used, Year of construction: 2006, BAZ Matsuura MAM 72-25V, year 2006 The machine is still powered and fully operational. The spindle and spindle motor were last replaced in 2018. The machine is available immediately. Scope of delivery: Knsdpfxjxqd Has Afksc - Machine - 2x additional pallets - Knoll high-pressure unit - Machine operating hours: 19,911 (see photo)

Condition: used, Year of construction: 2003, A one owner and well maintained 2003 built Fanuc RoboDrill T21iD with Fanuc 16iMB control, BT30 10,000RPM Spindle, 21 Tool ATC, Nikken 4th Axis Head, Zero Point sub plate, machine vice & coolant equipment. Very clean machine! Specification: X Axis Travel 500 mm Y Axis Travel 400mm Z Axis Travel 350mm Table Size 650 x 400mm Table Load 250 Kgs Spindle Taper BT-30 Max. Speed 10,000RPM Motor Power 7.5 KW ATC Tool Capacity 21 stations CNC Control Fanuc 16i-MB Ksdjxqdvuepfx Afkenc Rapid Traverse 54 m/min Machine Weight Approximately 2,000 kg Control: Fanuc 16i MB Spec: Travels 500mm x 400mm x 330mm 10,000 RPM Accessories: Nikken 4th Axis Head, Zero Point sub plate, machine vice

Condition: used, Year of construction: 2004, Immediately available from site: CNC Vertical Machining Center HAAS Type: Super Mini Mill Year of manufacture: 2004 Haas control Table: 914 x 305 mm Table load: 227 kg Travels X/Y/Z: 406/356/381 mm Rapid traverse X/Y/Z: 15 m/min Knedjxqbm Dopfx Afkec Spindle speeds up to 8000 rpm 10-position tool changer Weight: 2 tons Accessories Offered at a price of EUR 7,750.— plus VAT, ex location

Condition: excellent (used), Year of construction: 2006, Haas Minimill Ksdpfx Afoxp U T Uokonc Year of manufacture: 2006 Very good running condition Incl. toolholders

Condition: excellent (used), Year of construction: 1999, travel distance X-axis: 500 mm, travel distance Y-axis: 350 mm, travel distance Z-axis: 610 mm, controller manufacturer: HEIDENHAIN, controller model: TNC 426, table width: 380 mm, table length: 920 mm, spindle speed (max.): 18,000 rpm, CONTROLS .. CNC controls HEIDENHAIN TNC 426 WORKING RANGE -CUBIC- .. number of processing axes (excl parallel axes): 3 .. X-axis travel: 500 mm .. Y-axis travel: 350 mm .. Z-axis travel: 610 mm TABLE .. table surface (left-right): 920 mm .. table surface (front-back): 380 mm SPINDLE / HEAD .. spindle revolutions (min): 50 /min .. spindle revolutions (max): 18000 /min .. tool fixture: ISO SK 30 TOOL MAGAZINE .. number of positions: 24 ELECTRICAL SPECIFICATIONS .. mains voltage: 400 V .. mains frequency: 50 Hz DIMENSIONS / WEIGHTS .. space requirements -left/right-: 2000 mm .. space requirements -front/back-: 1700 mm .. total height: 3000 mm .. total weight approx.: 3200 kg ATTACHMENTS .. chip conveyor: no .. coolant unit: yes .. through spindle coolant attachment: no .. closed cabin: yes .. European CE standards: yes Knsdoxp Uvcepfx Afkoc Machine in TOP condition - Power ON : about 37000 h - Spindle hours: about 3640 h Equipment: - various tool holders - 1 x Mecatool clamping system - machine on power to inspection

Condition: ready for operation (used), Year of construction: 2003, General Data Measurements width 1520 Measurements depth 2000 Measurements height 2140 Machine weight 2800 Control Unit Brand HEIDENHAIN Model TNC 310 Main Drive Spindle speed range 4500 Number of axis 3 Movement X-Axis Movement 500 mm X-Axis Rapid Traverse 5 m/min Y-Axis Movement 400 mm Y-Axis Rapid Traverse 5 m/min Z-Axis Movement 400 mm Z-Axis Rapid Traverse 5 m/min Table Kjdpfxsxp Sr Ue Afksnc Outer length 700 mm Outer width 500 mm Tslots size 63 mm Distance between 14 H7 Table load 200 kg This 3-axis DECKEL DMU 50 vertical machining center was manufactured in 2003. It features a Heidenhain TNC 310 control, electronic handwheel HR 150, and a main drive speed of 4,500 min-1. The machine offers a rapid traverse of 5 m/min and a maximum load capacity of 200 kg. If you are looking to get high-quality milling capabilities, consider the DECKEL DMU 50 machine we have for sale. Contact us for further details regarding this machine. Application Types Milling

Condition: used, Year of construction: 2011, x-travel 635 mm y-travel 510 mm z-travel 460 mm Control Heidenhain TNC 620 turning speed range 20 - 8.000 U/min number of tool places 20 Pos. tool taper SK 40 Knjdpfx Aexp R Egjfkoc table surface area 790 x 560 mm spindle drive 13 kW Number of working hours ca. 3.870 h In our opinion, the machine is in good used condition and can be inspected under power by appointment. Technical Features & Accessories: - Chip conveyor Accessories, tools, and clamping devices shown are only included in the scope of delivery if noted in the additional information. Subject to changes and errors in the technical data and information, as well as subject to prior sale!

Condition: used, Year of construction: 2011, x-travel 500 mm y-travel 450 mm z-travel 400 mm Control Siemens SlimLine Shopmill C-Axis 360 ° b-axis -5/+110 ° spindle tunring speed 8.000 U/min number of tool places 16 Pos. table surface area 630 x 500 mm spindle drive 13 kW Number of working hours ca. 30.900 h spindle hours ca. 300 h In our opinion, the machine is in good used condition and can be inspected under power by appointment. The spindle has been overhauled - approximately 300 spindle hours Knsdpfx Afjxp R D Ajkec Accessories, tools, and clamping devices shown are only included in the scope of delivery if noted in the additional information. Subject to changes and errors in the technical data and information, as well as subject to prior sale!

Condition: ready for operation (used), Year of construction: 2014, Main Drive Spindle speed range 21000 Number of axis 4 Movement X-Axis Movement 500 mm Y-Axis Movement 400 mm Kedjxpyymopfx Afksnc Z-Axis Movement 330 mm This Fanuc Robodrill D21MiA5 Vertical Machining center was manufactured in the year 2014. It has 4 axis. The machine has a spindle speed of 21000 rpm. Open the attached PDF document to see all additional options of machine configuration (scroll down to access the document). Application Types Milling

Condition: ready for operation (used), Year of construction: 2006, operating hours: 19,604 h, General Data Measurements width 1600 mm Measurements depth 2000 mm Measurements height 2500 mm Control Unit Brand HAAS Kjdpfxexpym Ts Afkjnc Model N/A Main Drive Number of axis 3 Movement X-Axis Movement 400 mm Y-Axis Movement 300 mm Z-Axis Movement 250 mm This 3-axis HAAS Mini-Mill HE was manufactured in 2006. It features a spindle SK 40 with 6000rpm, 400 x 300 x 250mm travel, and a 10-fold tool changer. New ball screws for all axes are included. If you are looking to get high-quality milling capabilities consider the HAAS Mini-Mill HE machine we have for sale. Contact us for more information. Application Types Milling

Condition: like new (used), Year of construction: 2019, functionality: fully functional, machine/vehicle number: MV0098-000226, travel distance X-axis: 520 mm, travel distance Y-axis: 360 mm, travel distance Z-axis: 350 mm, rapid traverse X-axis: 48 m/min, rapid traverse Y-axis: 48 m/min, rapid traverse Z-axis: 56 m/min, nominal power (apparent): 16 kVA, controller manufacturer: FANUC, workpiece weight (max.): 200 kg, spindle speed (max.): 12,000 rpm, operating hours of spindle: 200 h, number of slots in tool magazine: 21, tool diameter: 200 mm, input voltage: 380 V, Equipment: chip conveyor, documentation/manual, rotational speed infinitely variable, The machine is in perfect condition, with only 200 spindle hours since new. It never had a collision. It is possible to inspect the machine under power and verify its geometry. Included in the package: 3D probing system Tool measurement probe (the stylus is damaged — we can replace it) Through-spindle coolant (TSC) Chip conveyor Kedpfsxpuwmox Afkenc 21-tool magazine

Condition: excellent (used), Dugard Mini Mill CNC Vertical Machining Centre Fanuc Oi, 4th Axis, 2011 Year: 2011 Model: MN965005 Control System: Fanuc Oi-MB X-Axis Travel: 450 mm Y-Axis Travel: 350 mm Z-Axis Travel: 380 mm Kedpfxsxpnlqe Afkenc Table Size: 700 × 320 mm Max Table Load: 150 kg Spindle Speed: 80–8,000 RPM Spindle Taper: BT‑40 Spindle Motor: Fanuc Version: 5.5 kW Siemens Version: 8.5 kW (specify if applicable) Toolchanger: 12-position Automatic Tool Changer 4th Axis: Included Rapid Feed Rate: 36 m/min Working Feedrate: Up to 10,000 mm/min

Condition: ready for operation (used), Year of construction: 2008, Main Drive Knedjxn Uz Aepfx Afkec Spindle speed range 20000 Tool taper HSK A-40 Number of axis 4 Movement X-Axis Movement 550 mm X-Axis Rapid Traverse 70 m/min Y-Axis Movement 400 mm Y-Axis Rapid Traverse 70 m/min Z-Axis Movement 415 mm Z-Axis Rapid Traverse 70 m/min This 4-axis Brother TC-32BN QT was manufactured in 2008, featuring a Brother B00 control system, X-axis travel of 550 mm, Y-axis travel of 400 mm, and Z-axis travel of 415 mm. It boasts rapid traverse rates of 70 m/min, a spindle speed up to 20,000 rpm, and a tool magazine with 40 positions. Consider the opportunity to buy this Brother TC-32BN QT vertical machining centre. Contact us for more information about this machine. Application Types Milling

Condition: ready for operation (used), Year of construction: 2022, operating hours: 1,316 h, General Data Measurements width 2665 mm Measurements depth 3065 mm Measurements height 2840 mm Machine weight 5600 kg Control Unit Brand SIEMENS Model Sinumerik 828D Main Drive Spindle speed range 20 – 12000 Number of axis 3 Movement X-Axis Movement 550 mm Y-Axis Movement 550 mm Z-Axis Movement 510 mm Table Table load 600 kg Tools Max weight 8 kg Max tool diameter 80 mm Max tool length 300 mm Kodpfx Asxn Uz Nsfkjnc Type of tool holder SK40 Media Power consumption 20 kVA Additional Equipment Job Shop package Renishaw PP40 wireless workpiece probe TS27R tool measurement probe Scraper-type chip conveyor Coolant tank capacity: 200 L (left side) Coolant pump: 20 bar internal through-spindle coolant Machine enclosure roof LED work area lighting This 3-axis DMG MORI M1 PRO was manufactured in 2022. It features a robust inline spindle with a speed range of 20-12000 rpm and a 24-position automatic tool changer. The worktable supports up to 600 kg with dimensions of 850 × 650 mm. Additional highlights include a Renishaw PP40 probe, 20 bar coolant system, and LED lighting. Ideal for precision machining tasks. Contact us for more information about this machine. Application Types Milling

Condition: ready for operation (used), Year of construction: 2008, General Data Measurements width 2930 mm Measurements depth 3210 mm Measurements height 2900 mm Machine weight 9200 kg Control Unit Brand HEIDENHAIN Model iTNC 530 Main Drive Spindle speed range 28000 rpm Spindle motor power 38/28 kW Tool taper HSK-A63 Number of axis 5 Kjdpfexn U A Hsx Afkonc Movement X-Axis Movement 450 Y-Axis Movement 600 Z-Axis Movement 400 Table Outer length 400 mm Outer width 400 mm Number of tslots 5 Distance between 63 mm Media Chip conveyor Yes Internal cooling Yes Additional Equipment Tool Storage Capacity: 30 tools /Max Tool Weight: 6 kg / Max Tool Diameter: 80 mm / Max Tool Length: 250 mm Graphite Dust Collector Heidenhain Touch Probe TS 649 3D Quick Set for 5-Axis Calibration This 5-axis DMG DECKEL MAHO HSC 55 linear vertical machining centre was manufactured in 2008. Consider the opportunity to buy this DMG DECKEL MAHO HSC 55 linear vertical machining centre if you are looking to get high quality milling capabilities. Contact us for more information about this machine. Application Types Milling

Condition: ready for operation (used), Year of construction: 2006, operating hours: 2,988 h, functionality: fully functional, machine/vehicle number: 14106232, travel distance X-axis: 500 mm, travel distance Y-axis: 255 mm, travel distance Z-axis: 160 mm, table load: 250 kg, spindle speed (max.): 9,000 rpm, Machining center with extensive accessories and only 2,988 spindle hours! TECHNICAL DETAILS Travel X-axis: 500 mm Travel Y-axis: 255 mm Travel Z-axis (manual): 160 mm Travel Z-axis (controlled): 147 mm Travel W-axis: 500 mm Table width: 320 mm Table length: 885 mm Table load capacity: 250 kg Spindle speed (min.): 50 rpm Spindle speed (max.): 9,000 rpm MACHINE DETAILS Control system: HEIDENHAIN iTNC 530 Spindle motor power: 9,900 W Spindle power (S6, 40%): 9.9 kW Dimensions & Weight Dimensions (L x W x H): 1,900 x 1,900 x 2,300 mm Machine weight: 2,450 kg Spindle hours: 2,988 h EQUIPMENT Documentation/manual Infinitely variable spindle speed Knsdpoxnz Tfofx Afkoc Nameplate available 60 pcs. SF-32 tools 97 pcs. collets Renishaw probe: MP15 Handwheel (manual control unit) Complete machine documentation including EC Declaration of Conformity

Condition: ready for operation (used), Year of construction: 2007, functionality: fully functional, machine/vehicle number: 121162, travel distance X-axis: 550 mm, travel distance Y-axis: 400 mm, travel distance Z-axis: 415 mm, table load: 200 kg, spindle speed (max.): 12,000 rpm, TECHNICAL DETAILS Travel paths X-axis: 550 mm Y-axis: 400 mm Z-axis: 415 mm Work table Work table size: 550 x 400 mm Table load capacity: 200 kg Spindle Max. spindle speed: 12,000 rpm MACHINE DETAILS Kedpfexnwvpjx Afkjnc Number of axes: 5 Weight: 4,600 kg Electrical data Power supply: 220 V, 3 phase Frequency: 50/60 Hz Rated power: 16.0 kVA Max. power: 32.0 kVA EQUIPMENT 2 pallets

Condition: new, functionality: fully functional, travel distance X-axis: 510 mm, travel distance Y-axis: 400 mm, travel distance Z-axis: 300 mm, 📝 Description & Additional Technical Parameters Product Description: The VTX-5 is part of the Tongtai VTX Series of compact CNC vertical tapping / milling centers. It is designed to combine high speed, rigidity, and precision in a relatively small footprint. It uses a direct-drive spindle to improve tapping accuracy and reduce maintenance compared to belt-driven designs. Roller guideways (linear rails) are used to ensure smooth, rigid motion. Tool changing is relatively fast, and the structure is optimized for stability and precision under moderate loads. Technical Parameters: Table size: 600x400mm Strokes on X/Y/Z: 510/400/300mm Maxim loading capacity on the table: 250kgs Rapid traverse on X/Y/Z: 60/60/60 m/min Machine size (Width x Depth x Height): 1.700x2.600x2.700mm Machine weight: 2.850kgs Kodoxni Iqepfx Afkonc Siemens controller model 828D with Shopmill and 10,4inch LCD Spindle speed 12.000 rpm direct driven Spindle motor 5,8kW Tool shank BBT-30 4th axis rotary table diameter 170mm and tailstock CTS ( coolant through spindle) 20bar Chip Conveyor chain type

Condition: excellent (used), Year of construction: 2023, travel distance X-axis: 210 mm, travel distance Y-axis: 270 mm, travel distance Z-axis: 360 mm, controller manufacturer: SIEMENS, controller model: 840D SL 4.8, overall weight: 6,000 kg, spindle speed (max.): 40,000 rpm, space requirement length: 8,500 mm, space requirement width: 2,500 mm, CONTROLS .. CNC controls SIEMENS 840D SL 4.8 WORKING RANGE -CUBIC- .. number of processing axes (excl parallel axes): 4 .. X-axis travel: 210 mm Knjdpoxm Rv Hsfx Afkec .. Y-axis travel: 270 mm .. Z-axis travel: 360 mm SPINDLE / HEAD .. spindle revolutions (max): 40000 /min .. tool fixture: HSK A40 TOOL MAGAZINE .. number of positions: 72 AUTOMATIC WORKLOAD EQUIPMENT .. workpiece manipulator: articulated robot .. number of store positions: 36 ELECTRICAL SPECIFICATIONS .. mains voltage: 400 V .. mains frequency: 50 Hz DIMENSIONS / WEIGHTS .. space requirements -left/right-: 8500 mm .. space requirements -front/back-: 2500 mm .. total weight approx.: 6000 kg ATTACHMENTS .. central lubrication system: yes .. chip conveyor: yes .. coolant unit: yes .. through spindle coolant attachment: yes .. European CE standards: yes -Siemens tool management with retooling -Fanuc Automation Robot M-10IA -Operating hours: 7,200 h - of which spindle 1 original, spindle 2: 3896 h

Condition: good (used), Year of construction: 2008, Röders RXP 500 DS with RC 2 / 5 axes, year of manufacture 2008, Knedpfx Afoxmhmpekec Röders control, travel X/Y/Z 500/400/240 mm, 2-axis NC swivel/rotary table 550 x 450 mm, max. workpiece weight 400 kg, spindle speed up to 42,000 rpm, linear drive X/Y/Z, 42-position tool changer, HSK E 40, 96-position electrode changer, all axes completely overhauled in 2021, used exclusively for electrode milling.

Condition: excellent (used), Year of construction: 2018, operating hours: 25,320 h, travel distance X-axis: 700 mm, travel distance Y-axis: 400 mm, travel distance Z-axis: 330 mm, spindle speed (max.): 24,000 rpm, operating hours of spindle: 8,221 h, Accessories: - Coolant tank MCO incl. belt filter system and scraper belt conveyor - M&H 3D probe - Fanuc zero-point option - Spare spindle - 2GB data server (program storage) Travel X/Y/Z: mm: 700 x 400 x 330 Table size: mm: 850 x 410 Max. table load: kg: 300 Machine weight/with DDR-TiB: t: 2.1 / 2.3 Max. tool length: mm: 250 Max. tool diameter: mm: 80 Max. tool weight: kg: 3 Total weight: kg: 33 Number of tools: 21 Spindle taper 7/24 taper No. 30/SK30 DIN 69871A Spindle interface BBT30 Distance spindle nose to table (with HC100): mm: 250-580 Control: 31i-B5 Plus Spindle speed: rpm: 24,000 Spindle torque at 24,000 rpm (1 min): Nm | kW: 35 | 26 Spindle torque at 24,000 rpm (continuous): Nm | kW: 7.5 | 5.5 Rapid traverse in all axes: m/min: 54 Max. programmable feedrate: mm/min: 30,000 Tool change time (2 kg tool, chip-to-chip): S: 1.6 Bidirectional positional accuracy per axis (ISO230-2:1988): Knsdpjxmhmvsfx Afkjc mm: < 0.006 Bidirectional positional repeatability per axis (ISO230-2:1997, 2006): mm: < 0.004 Air consumption: L/min | MPa: 160 | 0.35-0.55

Condition: ready for operation (used), Year of construction: 2022, operating hours: 123 h, Control Unit Brand SIEMENS Model SINUMERIK One 828D Main Drive Spindle speed range 12000 Kodpfxoxl H Hxs Afkonc Movement X-Axis Movement 550 Y-Axis Movement 550 Z-Axis Movement 510 Table Outer length 850 mm Outer width 650 mm Table load 600 kg Tools Slots in storage 24 Additional Equipment Automation interface with 6-axis robot, high dynamics Siemens PLC and HMI with safety module IDS industrial camera with Halcon Vision integration This 3-axis DMG M1 vertical machining center was manufactured in 2022. It features a Siemens SINUMERIK One 828D control, a spindle speed of 12,000 rpm, and a table size of 850 x 650 mm supporting up to 600 kg. Equipped with a 24-place tool changer and both internal and external cooling systems, it ensures precise milling operations. If you are looking to get high-quality milling capabilities consider the DMG M1 machine we have for sale. Contact us for more information. Application Types Milling

Condition: excellent (used), Year of construction: 2021, functionality: fully functional, travel distance X-axis: 540 mm, travel distance Y-axis: 635 mm, travel distance Z-axis: 400 mm, controller manufacturer: Röders, rotational speed (max.): 80,000 rpm, spindle speed (max.): 80,000 rpm, operating hours of spindle: 300 h, spindle nose: HSK-A25, number of slots in tool magazine: 60, tool length: 80 mm, tool diameter: 2 mm, Equipment: chip conveyor, documentation/manual, rotational speed infinitely variable, Fully equipped HSC milling machine with 80,000 rpm, pallet changer RCE1 with Erowa UPC 320×320 system size GRINDING OPTION AND FIRE EXTINGUISHING SYSTEM Features: (see attachment PDF for detailed information) Last control update: 11/2025 Spindle replacement: 06/2025 (current runtime approx. 300 hours) Tool diameter: max. 2.0 mm and total length including holder max. 80 mm 3D probe OMP400 Tool measurement with laser Thermal package Work area temperature control Cooling water temperature control Surface optimizer Collision protection Minimum quantity lubrication Ksdpfx Ajxl E Rcsfkjnc Workpiece cleaning Prepared for operation with oil 8 Erowa UPC carrier pallets included (no clamping devices) 50 Regofix and shrink-fit tool holders included (no tools)

Condition: ready for operation (used), Year of construction: 1995, Control Unit Brand SIEMENS Model Sinumerik 810D Main Drive Spindle speed range 10000 rpm Spindle motor power 95 kW Number of axis 2 Movement X-Axis Movement 550 mm Y-Axis Movement 300 mm This CHIRON FZ 12 W was manufactured in 1995. A vertical machining center featuring a SK30 spindle mount, maximum spindle speed of 10,000 rpm, and a tool magazine with 12 positions. It includes a Sinumerik 810D control system and rapid traverse rates up to 40 m/min. Table size measures 660 x 350 mm. Consider the opportunity to buy this CHIRON FZ 12 W vertical machining center. Contact us for more information. Knjdpoxlvccefx Afkoc Application Types Milling

Condition: good (used), Year of construction: 2015, functionality: fully functional, travel distance X-axis: 450 mm, travel distance Y-axis: 400 mm, travel distance Z-axis: 400 mm, controller manufacturer: FANUC, controller model: FANUC 0i-MD, spindle speed (max.): 15,000 rpm, Equipment: chip conveyor, rotational speed infinitely variable, Milling spindle up to 15,000 rpm "in-line" direct drive Power 7.5 kW (S6/40%) Travel X=450mm Y=400mm Z=400mm; 36m/min Kjdpfx Afjxlq Itjksnc Tool taper size 40 according to DIN 69871-A, tightening bolt according to DIN 69872-A Blow-out device for spindle taper High-speed automatic tool changer as double-arm changer for 24 tools Linear guide in all three axes Spindle with "in-line" direct drive without belt for speeds up to 15,000 rpm with Fanuc 0iMD-Alpha-Drive-HV-Technology controller and 10.4" color screen With graphical user interface for workshop programming Fanuc "Manual-Guide i" Chip conveyor mounted on coolant tank instead of chip container. Discharging to the right. Scraper belt conveyor suitable for short milling chips.
