Gamba Machine Tools

Condition: used, Year of construction: 2021, turning diameter 42/200 mm turning length 430 mm control Fanuc 3li-B clamping chuck diameter 165 mm turret (x-stations) 2x12 travel -y axis 70 mm Chedpfe Ah T Uljx Aqved range L-W-H 2645 x 1645 x 1900 mm total power requirement 11/7,5 kW turning speeds 6000 U/min gripping station 42/200 mm load magazine Breuning IRCO SIMag chip conveyor Knoll kW coolant filtering unit Knoll kW total power requirement 11/7,5 kW weight of the machine ca. 6250 kg CNC Turning & Milling machine Miyano ANX 42 SYY

Condition: ready for operation (used), Year of construction: 2019, operating hours: 7,150 h, travel distance X-axis: 180 mm, travel distance Z-axis: 620 mm, controller manufacturer: FANUC, controller model: i-HMI, number of axes: 5, This 5-axis Biglia B 620 YS was manufactured in 2019. It features a maximum turning diameter of 360 mm and a turning length of 620 mm. The machine is equipped with a powerful main spindle speed of 4,500 rpm and a sub-spindle speed of 5,000 rpm. If you are looking to get high-quality turning and milling capabilities, consider the Biglia B 620 YS turn-mill centre we have for sale. Contact us for further details. Cjdpfx Ao Ah Tn Hoqvehd Working Hours (Power-On): 25,900 hFeed Working Hours: 7,150 hCNC Control: Fanuc i-HMI (Touchscreen interface, DIN ISO programming, Manual Guide)Max. Swing Diameter: 700 mmMax. Turning Diameter: 360 mm (over 280 mm length)Max. Turning Length: 620 mmMax. Bar Capacity: 50 / 70 mm (Main spindle 72 mm clearance; D60 mm reduction tube included)Main Spindle Nose: ASA 6" (liquid-cooled motor spindle, C-axis, hydraulic disc brake)Main Spindle Speed: 4,500 rpmMain Spindle Power (S1/S3): 30 / 40 kWMain Spindle Torque (S1/S3): 286 / 382 NmSub-Spindle (Counter-Spindle): ASA 5" (liquid-cooled motor spindle, C-axis, hydraulic disc brake, pneumatic ejector)Sub-Spindle Speed: 5,000 rpmSub-Spindle Power (S1/S3): 17 / 25 kWSub-Spindle Torque (S1/S3): 108 / 159 NmSub-Spindle Bar Clearance: 50 mm (52 mm draw tube)Tool Turret: 15 stations, all live / driven stationsLive Tooling Speed: 6,000 rpmLive Tooling Power (S1/S3): 11 / 13 kWLive Tooling Torque (S1/S3): 27 / 38 NmX-Axis Travel: 180 mm (Rapid traverse: 18 m/min)Z-Axis Travel: 620 mm (Rapid traverse: 30 m/min)Y-Axis Travel: mm (Rapid traverse: 18 m/min)B-Axis Travel: 620 mmBed Construction: 30° cast iron slant bed (weight: 2,800 kg), 45° linear roller guideways on Z-axisOperating Voltage: 3 x 400 V AC ±10%, 50 HzPower Consumption / Absorbed Power: 56 kVA (for 71-spindle / ASA 6")Current Rating / Fuse: 82 A (absorbed current ~75 A)Machine Weight: 6,200 kg (Nameplate) / Approx. 6,500 kg (with chip conveyor 500 kg: up to 7,000 kg)Overall Machine Dimensions (Layout): 4,340 mm x 1,979 mm x 2,037 mm (Width with chip conveyor discharge: 4,475 mm; Depth clearance: up to 2,890 mm)Operating Temperature: 0 - 45 °CRelative Humidity: 75%Optional Equipment : Chip conveyor, finished parts catcher / unloader with parallel discharge conveyor belt, pneumatic parts ejector, D60 mm spindle reduction tube Technical Specification Counter Spindle Yes Driven Tools Yes

Condition: ready for operation (used), Year of construction: 2021, operating hours: 30 h, spindle speed (max.): 4,500 rpm, travel distance X-axis: 175 mm, travel distance Z-axis: 350 mm, overall weight: 2,940 kg, controller manufacturer: FANUC, number of axes: 2, Turn-mill centre manufactured in 2021. This SMEC PL 2000 features a maximum permissible spindle speed of 4500 rpm and includes additional equipment such as a measuring arm (tool setter) and an automatic lubrication unit. If you are looking to get high-quality turning capabilities, consider the SMEC PL 2000 machine we have for sale. Contact us for further details. - Control: Fanuc CNC control- Machine Weight: 2940 kg- Max. Permissible Spindle / Chuck Speed: 4500 rpm- Electrical Connection: 3PH, PE- Frequency: 50/60 Hz- Voltage: AC 200/220 V- Rated Power: 25 kVA- Optional Equipment: Tool presetter / measuring arm, 3-jaw hydraulic chuck, tailstock, HALS Lube automatic lubrication system, pneumatic service unit with twin regulators Technical Specification Chode Ah Suxopfx Aqved Counter Spindle No Driven Tools No

Condition: used, Year of construction: 2014, functionality: fully functional, 4-AXIS CNC TURNING CENTER • Color: Light gray/anthracite RAL7035, 7016 • Main spindle 26 kW • Counter spindle AS 11 kW • Bar diameter 65 mm • Control system Fanuc 31i B-5 • Counter spindle can be lowered • 2 Y-axes *50/-40 mm, 4-way guided • X-axes with flat guide • 2 turrets with 12 tool stations each • 24 powered tool stations. Torque 47 Nm. • 2 C-axes • Bar loader interface • Controlled parts catcher, can be used for main and counter spindles • Finished parts conveyor belt, installed lengthwise, 500 mm long • Hinged belt chip conveyor with discharge height of 820 mm • 2 coolant pumps at 7 bar including filter • Foot switch for chuck operation on the main spindle • Internal flushing system with 4-bar pump • Flushing gun, 4 bar, for cleaning the work area • Intelligent handwheel Program execution with simultaneous movement of all axes MACHINE EQUIPMENT Chsdpfx Aqe Ah Scneved - Conveyor belt for machined parts Belt width/length 300x800 mm, Discharge on the operator side - Measuring probe, swiveling, with 2 heads for tool measurement Turret, top and bottom - High-pressure coolant pump, 18 bar for 2 turrets incl. coolant filter Pump capacity 20 l/min - MANUAL GUIDE i, dialog programming Turning/milling cycle, 3D simulation Manual (on CD) - SBS tool breakage and wear monitoring - Programmable axis mirroring Bar loader magazine Bar loader magazine FMB turbo 5-55 Bar length max. 3200 mm Oil lubrication for the bar Bars 5-55 / turned down to 50 mm Loading level 250 mm Guided by roller guide, can be changed to guide chuck (polygonal) Precise positioning during insertion Interval mode for polygonal material Residual piece ejection to the rear (max. 530 mm)

Condition: good (used), Year of construction: 2008, functionality: fully functional, Technical Data Machine Type: CNC Multi-Spindle Turning and Milling Center OKUMA MULTUS B400-W Control System: OSP-P200L Year of Manufacture: 2007 Machine Capacity Codpfx Ae Ah Rr Toqvohd - Max. Turning Diameter over Bed: Ø 710 mm - Distance between Centers: 1,500 mm - Max. Turning Diameter: Ø 710 mm Main Spindle - Spindle Taper: JIS A2-8 (optional JIS A2-11) - Speed Range: 38–3,800 rpm (optional 38–2,800 rpm) - Spindle Diameter: Ø 120 mm (optional Ø 150 mm) - Drive Power: 22 / 15 kW (30 / 20 hp) Counter Spindle - Spindle Taper: JIS A2-8 - Speed Range: 38–3,800 rpm - Spindle Diameter: Ø 120 mm - Drive Power: 22 / 15 kW (30 / 20 hp) Milling Spindle / Driven Tools - Max. Speed: 6,000 rpm - Optional: 10,000 rpm - Max. Torque: 85 / 58 Nm (5 min / Continuous Duty) - Drive Power: 14 / 10 kW (19 / 13 hp) Axes and Travels - X-Axis: 690 mm - Y-Axis: 230 mm (± 115 mm) - Z-Axis: 1,545 mm - W-Axis: 1,550 mm - C-Axis: 360° - B-Axis: Swivel Axis - Smallest Programmable Angular Increment C-Axis: 0.001° - Smallest Programmable Angular Increment B-Axis: 0.001° Rapid Traverse Rates - X-Axis: 4,000 mm/min - Y-Axis: 26,000 mm/min - Z-Axis: 40,000 mm/min - W-Axis: 20,000 mm/min - C-Axis: 200 rpm Tool Magazine / Automatic Tool Changer (ATC) - Tool Holders: HSK-A63 / CAPTO-C6 - Max. Tool Weight: 10 kg - Max. Tool Length: 400 mm (without tool holder) - Max. Tool Diameter: 20 mm - Optional Tool Diameter: 40 mm Turret - Type: H1 - Tool Holder: 1 tool L or M - Tool Dimensions for External Machining: 25 × 25 mm - Tool Diameter for Internal Machining: Ø 40 mm Drive Powers - Main Spindle Drive: 22 / 15 kW - Counter Spindle Drive: 22 / 15 kW - Axis Drive ZB, XB, and W: 3.3 kW - Axis Drive X: 5.5 kW - Axis Drive Z: 4.4 kW - Axis Drive YS: 3.3 kW - B-Axis Drive: 2.5 kW - Hydraulic Pump: 2.2 kW - Lubricant Pump: 0.017 kW - Coolant Pump: 0.8 kW - Tool Spindle Drive: 14 / 10 kW - Tool Magazine Drive: 1.0 kW - Automatic Tool Changer (ATC): 1.0 kW Dimensions and Weight - Machine Height: 3,000 mm - Footprint (L × W): 4,925 × 2,585 mm - Machine Weight: approx. 15,500 kg

Condition: used, Year of construction: 2017, A rare machine just arrived in our Bristol showroom! - 2017 Miyano BNJ 51 SY6 in what can only be described as being in super condition, superbly specified and well tooled too! - This 1 owner machine has only clocked up 6,600 hours, hence its condition! The machine is Fanuc controlled, has Twin Spindles with motorised direct drive motors, Twin Turrets, with driven stations on each turret, 2 x C-Axis and Y-Axis too! Supplied with a full turret of driven and static tool holders, collet chucks on both spindles, an Iemca servo barfeed, part catcher and conveyer. Specification from Miyano's website: - Maximum Bar Capacity: 51 mm (2.0 in) - Maximum Turning Diameter: 165 mm (6.5 in) - Maximum Turning Length: 246 mm (9.68 in) - Distance Between Spindle Faces: 555 mm Dual Spindle Specifications Both spindles provide high rigidity and precision, utilising integrated motors with dedicated C-axis functionality for seamless part handoffs. Features: Main Spindle, Second Spindle Maximum Speed 5,000 RPM on both Motor Power 15kW & 11 kW Max Torque112.8 Nm & 66.8 Nm Asymmetric Turret Configurations. The SY6 configuration relies on an unbalanced twin-turret concept to maximize tool access for both main and back-side machining cycles simultaneously. - Turret 1 (Main / HD1):Tooling Stations: 12 stations (all can accept live tooling) - Axes: Z1, X1, and Y1 - Y-Axis Stroke: 80 mm (±40 mm) - Rotary Tool Specs: 2.2 kW power / 6,000 RPM max speed / 25 Nm torque - Turret 2 (Sub / HD2):Tooling Stations: 8 stations (provides 4 revolving tool layout positions) - Rotary Tool Specs: 10 Nm torque capacity - Physical Metrics & Controls CNC Control Unit: Fanuc 0i-TF - Machine Floor Space: 2,840 mm × 1,560 mm (excluding chip conveyor) - Machine Weight: ~5,300 kg (11,685 lbs) Chodpfo Ah Immjx Aqvjd - Power Requirement: 33 kVA - servo barfeed

Condition: used, Year of construction: 2008, Due in at the end of November, so photo'd on site...more pictures will be available on arrival in our showrooms. 2008 MAZAK Nexus 200-II M with driven tools, C-Axis, barfeed, swarf conveyor, parts catcher and tool setter. Cjdpfxe Ah Ik Sj Aqvohd - Maximum Swing: 675 mm (26.57 in) - Maximum Machining Diameter: 380 mm (14.96 in) - Maximum Bar Material Capacity: 74 mm to 76 mm (2.91 in to 3.0 in) - Maximum Turning Length: Available in two distinct bed lengths:500U Specification: ~538 mm max turning length - 1000U Specification: Up to 1,000 mm max turning length Spindle & Turret Specifications The machine pairs a high-torque main turning spindle with an integrated milling drive inside the tool turret. Features Main Spindle, Rotary / Milling Turret Spindle Speed Range 35 – 5,000 RPM, Motor Power 26 kW (35 HP), Driven tool Motor 5.5 kW (7.5 HP), Spindle Nose / Bore A2-6 / 76 mm Turret Capacity 12 Tools (all can be live) Spindle Indexing (C-Axis)0.001° Increments - Physical Machine Metrics Rapid Traverse Rates: 30 m/min (X-axis) / 33 m/min (Z-axis) - Machine Approximate Footprint (500U): ~2,430 mm (L) x 1,800 mm (W) x 1,780 mm (H) - Machine Net Weight: Approximately 4,900 kg (10,800 lbs)

Condition: used, Year of construction: 2016, Due in at the end of November and there photos are taken on site... more photo available on arrival in our showrooms Chsdpfx Aj Ah Iimeqvsd Superb 2016 MAZAK Quick Turn Nexus-2 250-II MS with driven tools, 2 x C Axis, Sub Spindle, tool setter, parts catcher, servo barfeed and suite of tooling. - Maximum Swing: 695 mm (27.36 in) - Maximum Machining Diameter: 380 mm (14.96 in) - Maximum Bar Work Capacity: 80 mm (3.15 in) – Note: standard setup typically supports up to 3.0 in bars - Maximum Machining Length: ~540 mm Supplied with Main Spindle, Second (Sub) Spindle, Rotary/Milling Turret, 10" Chuck on main, 6" chuck on sub, Main spindle Maximum Speed 4,000 RPM, 6,000 RPM on Sub Motor Power Mian, 35 HP (26 kW) Sub 10 HP (7.5 kW) & Driven tool motor 7.5 HP (5.5 kW) - Turret Stations: 12-position drum turret where rotary tools can be mounted at any station. - Axis Travel: X-Axis: 234 mm (9.21 in) - Z-Axis: 625 mm (24.61 in) - W-Axis (Sub-Spindle Travel): 585 mm (23.03 in)

Condition: ready for operation (used), Year of construction: 2014, functionality: fully functional, A used CNC turning machine with driven tools and a C-axis. Cjdpfe Ah H Tbjx Aqvohd

Condition: used, Year of construction: 1996, functionality: fully functional, Equipment: documentation/manual, EQUIPPED WITH C-AXIS – POWER TOOLS SELF-CENTERING HYDRAULIC CHUCK: 1600 MM MAXIMUM TURNING DIAMETER: 2000 MM MAXIMUM TURNING HEIGHT: 2000 MM CNC: FANUC 0T MACHINE STILL UNDER POWER Chodj Ah Hytepfx Aqvsd

Condition: good (used), Year of construction: 2017, functionality: fully functional, Okuma Multus U 3000, Year of manufacture 2017, OSP P 300 SA control system, Main spindle, Counter spindle, Y-axis +/- 125 mm, B-axis as milling spindle, Chedpfx As Ah Huyoqved B-axis indexing 0.001°, Turning length 1,500 mm, Max. turning diameter 650 mm, Main spindle chuck Ø 400 mm, Counter spindle chuck Ø 400 mm, 2 x C-axis 0.001, 80-position tool changer, High-pressure cooling system, chip conveyor.

Condition: used, Year of construction: 1996, functionality: fully functional, Equipment: documentation/manual, CNC lathe, of Japanese manufacture, complete with C-axis and powered tool turret; FANUC 18T CNC control. Equipped with: chip conveyor tailstock hydraulic chuck with various sets of jaws tool presetter parts collection arm for bar machining 4 powered tool turrets included set of fixed tool holders machine manuals Chedpfx Aqs Ah Hfvsvod

Condition: used, Year of construction: 2012, Doosan Puma TT1800SY Twin Turret Multi Axis CNC Lathe (2012), 230mm Swing, 230mm Max Turned Diameter, 230mm Maximum Turning Length, 12 + 12 Station Turrets, 65mm Bar Capacity, 5000rpm 15KW Main Spindle, Fanuc 31i Control, C Axis to both Spindles, 5000rpm Sub Spindle, +/-50mm Y Axis, Coolant, Swarf Conveyor, Tool Setter, Parts Catcher, Hydrafeed Multifeed Magazine Bar-feed. S/No. ML0177-000555, Machine Weight: 9000kg. Country of Origin: Korea Location: This lot is located in Leicester, UK. A charge of £350 for dismantling and loading onto suitable transport will be automatically added to your invoice should you be successful in purchasing this item. Blocking and securing will be at the cost of the purchaser. Chodpfx Ao Ah E Nnjqvsd

Condition: ready for operation (used), Year of construction: 2011, operating hours: 22,008 h, spindle motor power: 52,000 W, spindle speed (max.): 2,500 rpm, travel distance X-axis: 650 mm, travel distance Y-axis: 400 mm, travel distance Z-axis: 2,050 mm, total height: 2,670 mm, total width: 4,215 mm, overall weight: 24,000 kg, controller manufacturer: SIEMENS, controller model: Sinumerik 840D sl, product length (max.): 7,601 mm, number of slots in tool magazine: 12, swivel angle B-axis (min.): -119 °, swivel angle B-axis (max.): 120 °, number of axes: 7, This 7-axis DMG CTX gamma 2000 TS was manufactured in 2011. It features a maximum turning diameter of 700 mm and a turning length of 2,000 mm. The machine includes impressive X1-axis travel of 650 mm and Z1-axis travel of 2,050 mm. If you are looking to get high-quality turning and milling capabilities, consider the DMG CTX gamma 2000 TS turn-mill centre we have for sale. Contact us for further details. • Working area + axes travels: • Swing diameter: 700 mm • Maximum turning diameter: 700 mm • Maximum turning diameter opposite spindle/tool holder: 400 mm • Spindle distance: 2,260 mm • Turning length: 2,000 mm • X1-axis travel: 650 mm • Y1-axis travel: +/- 200 mm • Z1-axis travel: 2,050 mm • B1-axis travel: +/- 120 degrees • X2-axis travel: 210 mm • Z2-axis travel: 1,910 mm • Z3-axis travel: 1,910 mm • Main Spindle: Integrated motor spindle ISM 102 Plus: • Clamping cylinder diameter: 630 mm • Inner draw tube 104 mmDraw tube diameter: 104 mm • Spindle bore diameter: 118 mm • Front bearing diameter: 180 mm • Maximum spindle power (100% / 40% ED): 40 / 52 kW (53.6 / 69.7 hp) • Maximum spindle speed: 2,500 rpm • Maximum torque (100% / 40% ED): 1,700 / 2,200 Nm • C-axis angular resolution: 0.001 degrees • Sub-Spindle: Integrated motor spindle ISM 102 Plus: power 40/52 kW, torque 1700/2200 Nm, max speed 2500 min-1, inner draw tube 104 mm, C-axis and hydraulic brake, lower support (Z3) • Tool Magazine: Disc magazine with 36 stations (max tool diameter 80 mm, max length 400 mm, max weight 10 kg) • Milling Spindle: Power 13.2/22 kW (100/40% ED), HSK-63A clamping, Speed Max 12000 min-1, Torque 60/100 Nm (100/40% ED) • Tool turret: 12-position star turret with driven tools, VDI 40 mm, lower cross slides (X2, Z2) with AC servo drives • Power Consumption / Supply: 100 kVA, 400V (±10%, N, PE), 50 Hz, 160 A fuse • Machine Dimensions (LxWxH): 7601 x 4215 x 2530 mm (without external cooling unit) • ADDED OPTIONS: • Automation: Automatic sliding door for workspace (Landert) • Workpiece measuring system Renishaw • Cooling and Chip Removal: Coolant system 8/20 bar (980 l tank, 40 µm band filter, 4.5 kW heat exchanger), outer chuck flushing for main and sub-spindles, chip flushing pistol, mechanical oil mist extractor (1100 m³/h, H13 filter) • Shaft Machining Equipment: Tailstock function for sub-spindle (250-1200 daN), steady rest on turret head (SR-3.1-ZSW, clamping Ø25-165 mm) Codpfj Ah E Ecex Aqvjhd • Spindle Clamping: Power-operated shaft chuck (SMW W 260-3-A08), dual clamping cylinder SMW, face driver with fixed center point, torque support for milling spindle, angular drilling head 90° (Benz), 4-color signal light, unstable grid package, higher ambient temperature package • Sub-Spindle Clamping: Power-operated chuck for shaft machining with retractable jaw holder (type W 260-3-A08, manufacturer SMW, including A8/Z220 reduction flange), dual clamping cylinder for shaft machining chuck (SMW, surcharge to standard cylinder), face driver in workpiece-dependent design with fixed centering point and power-operated driving pins for shaft machining chuck • Software & Powertools: DMG Messenger, DMG Netservice (VPN), 3D data model of workspace (Step/IGES), DMG programming software for PC with Windows XP Pro, Shopturn 840D with CAD-Reader Technical Specification Counter Spindle Yes Driven Tools Yes Taper Size HSK 63 Through-spindle Coolant Yes

Condition: used, Year of construction: 2007, Mazak Integrex E500H-II Multi-tasking CNC Lathe (2007), Maximum Cutting Diameter 820mm, Maximum Cutting Length 1500mm, C axis 0.0001 degrees, B Axis -30/+210 degrees, 40 ATC, Spindle Speed 1,600rpm, Milling Speed 10,000rpm, Main Spindle 37Kw, Spindle Taper din50, Y axis -/+ 250mm, Mazatrol Matrix Control, Swarf Conveyor. S/No. 186364. Country of Origin: Japan Location: This lot is located in Leicester, UK. A charge of £375 for dismantling and loading onto suitable transport will be automatically added to your invoice should you be successful in purchasing this item. Blocking and securing will be at the cost of the purchaser. Csdpfx Aqe Ah E Dbovehd

Condition: used, Year of construction: 2013, Mori Seiki NLX2500-700SY CNC Lathe with C&Y Axis, Barfeed Unit. (2013), Swing Over Cross-slide 360mm, Maximum Cutting Diameter 366mm, Maximum Cutting Length 705mm, Bar Capacity 80mm, Spindle Speed 4,000rpm, Milling Speed 10,000rpm, Main Spindle Power 18.5Kw, C Axis 0.001 degrees, Y axis -/+ 50mm, 12 Station Turret, Mori Control M730BM, equipped with Toolsetter, Swarf Conveyor, 3 Jaw Chuck, Parts Catcher. S/No. NL254130462. Country of Origin: Japan Cjdpfs Ah E Aajx Aqvohd Location: This lot is located in Leicester, UK. A charge of £250 for dismantling and loading onto suitable transport will be automatically added to your invoice should you be successful in purchasing this item. Blocking and securing will be at the cost of the purchaser.

Condition: used, Year of construction: 2013, Mori Seiki NLX2500-700SY CNC Lathe with C&Y Axis, Barfeed Unit. (2013), Swing Over Cross-slide 360mm, Maximum Cutting Diameter 366mm, Maximum Cutting Length 705mm, Bar Capacity 80mm, Spindle Speed 4,000rpm, Milling Speed 10,000rpm, Main Spindle Power 18.5Kw, C Axis 0.001 degrees, Y axis -/+ 50mm, 12 Station Turret, Mori Control M730BM, equipped with Toolsetter, Swarf Conveyor, 3 Jaw Chuck, Parts Catcher. S/No. NL254130462. Country of Origin: Japan Chedj Ah Ex Ejpfx Aqvjd Location: This lot is located in Leicester, UK. A charge of £250 for dismantling and loading onto suitable transport will be automatically added to your invoice should you be successful in purchasing this item. Blocking and securing will be at the cost of the purchaser. Lot 1 of Auction 3519

Condition: good (used), Year of construction: 2003, EMCO HYPERTURN 665MCPLUS Turning center with C/Y-axis Portal loading system and bar loader magazine Turning and milling operations performed in a single setup Year of manufacture 2003 Control system: SIEMENS SINUMERIK 840D Equipment: Portal loading system with 20 base pallets Automatic bar loader magazine, manufacturer IEMCA, type MASTER 880 MP 2 tool turrets, each with approx. 12 stations Main spindle with C-axis Counter spindle with C-axis Chip conveyor, manufacturer KNOLL Cooling unit, manufacturer KELVIO Included in the scope of delivery: VDI tool holders Powered tools Tool cabinet Drawer cabinet Operating manual/documentation Machine parameters on storage medium Technical data and equipment – see PDF. All technical information, illustrations, and content are non-binding and without warranty. Subject to change and errors. All other accessories visible in the photos and video are not included in the scope of delivery and are therefore not part of this sale. The scope of delivery includes only the accessories that are explicitly listed here, in the order confirmation, and on the invoice. EXW D-40721 Hilden, Germany (Incoterms® 2020) Codpfs Ah Evmex Aqvjhd excluding disassembly, removal, and loading Delivery time: immediately, subject to prior sale Payment: 100% prepayment upon order placement

Condition: like new (used), Year of construction: 2025, functionality: fully functional, MAZAK INTEGREX i-250H S U1000 Max. machining diameter: 670 mm Max. machining length: 1,011 mm Max. milling speed: 12,000 RPM Max. spindle speed: 5,000 RPM Max. bar diameter: 65 mm!!! Machine is equipped with: - CNC control: Mazatrol SmoothAi - Tool magazine for 74 tools (CAPTO) - KITAGAWA three-jaw chuck for main spindle, diameter 210 mm - KITAGAWA three-jaw chuck for 2nd spindle, diameter 210 mm - Tool Eye - Y-axis - B-axis 0.0001° (swiveling head) - C-axis (main spindle) input accuracy 0.0001° - Counter spindle with full C-axis Csdpfx Aqj Ah Dx Ajvshd - Main spindle with spindle bore 65 mm - Interface for bar loader magazine - 5-axis machining package for SmoothAi - Tailstock function, counter spindle!!! - Preparation for MAZAK Monitoring System B - Chip conveyor - KNOLL KSS compact filter system - Approx. 80-85 pieces of CAPTO tool holders!!! * Like new, with only approx. 350 machining hours!!! * IMMEDIATELY AVAILABLE

Condition: like new (used), Year of construction: 2022, operating hours: 2,085 h, functionality: fully functional, turning diameter: 240 mm, spindle speed (min.): 3,200 rpm, travel distance X-axis: 142 mm, travel distance Z-axis: 165 mm, rapid traverse X-axis: 24 m/min, rapid traverse Z-axis: 24 m/min, rotational speed (max.): 2,500 rpm, Only approximately 2,000 operating hours! TECHNICAL DETAILS Travel range X-axis: 142 mm Travel range Z-axis: 165 mm Swinging diameter: 240 mm Spindle speed: max. 2,500 rpm Number of spindles: 2 Number of tool turrets: 2 Number of linear robots: 2 Spindle motor power: 11 kW Spindle bore: 90 mm Spindle speed: min. 3,200 rpm Cede Ah Dv Ispfx Aqvehd MACHINE DETAILS CNC control: FANUC 0i-TD Dimensions & Weight Dimensions (L x W x H): 3,590 x 2,610 x 2,700 mm Total weight: 5,200 kg Operating hours: approx. 2,000 h EQUIPMENT Powered tools C-axis 2 linear robots 2 side feed systems Collet chuck 3-jaw chuck Chain conveyor RAKU-RAKU monitor Extensive full equipment package Continuously adjustable speed Documentation/Manual

Condition: used, Year of construction: 2009, controller manufacturer: Siemens, controller model: 840 Dsl, _____ Description: Year of manuf. : 2009 - RETROFIT 2019 Control : Siemens 840 Dsl Turning diam. : 200 mm Turning length : 550 mm In General: Year of manufacture:2009 - RETROFIT 2019 Control system:Siemens 840 Dsl Bar capacity:65 mm Main spindle Technology:Direct drive spindle Speed:5,000 rpm Max. power:33 kW Max. torque:150 Nm C-axis:0.00014° Bar capacity:65 mm Clamping cylinder:Hollow clamping cylinder Chuck:Hainbuch Spanntop Sub spindle: Technology:Direct drive spindle Speed:5,000 rpm Max. power:22 kW Max. torque:100 Nm C-axis:0.00014° Z-axis:700 mm Bar capacity:65 mm Clamping cylinder:Hollow clamping cylinder Chuck:Hainbuch Spanntop Tool carrier I (X/Y/Z): Technology:Tool turret on cross slide Number of stations:14 Tool holder:VDI 25 Tool drive:8,000 rpm, 16 Nm X-axis:110 mm Y-axis:100 mm Z-axis:320 mm Tool carrier II (X/Y/Z): Technology:Tool turret on cross slide Number of stations:14 Tool holder:VDI 25 Tool drive:8,000 rpm, 16 Nm X-axis:110 mm Y-axis:100 mm Z-axis:550 mm Tool carrier III (X/Y/Z): Technology:Tool turret on cross slide Number of stations:14 Tool holder:VDI 25 Tool drive:8,000 rpm, 16 Nm X-axis:180 mm Equipment: Chip removal:Chip conveyor Cedpfx Aqs Ah Adfovjhd Coolant supply:Pump station Bar feeder:Irco Profimat Part removal:Part gripper + indexing belt Chucks:2x Hainbuch chucks Tool holders:Various static and driven holders : Note:The machine was overhauled (retrofitted) by Index in 2019

Condition: used, Year of construction: 2014, controller manufacturer: Siemens, controller model: 840 Dsl - Operate, _____ Description: Year of manuf. : 2014 Control : Siemens 840 Dsl - Operate Turning diam. : 340 mm Turning length : 1185 mm In General: Year of manufacture:2014 Control system:Siemens 840 Dsl - Operate Swivel diameter:540 mm Turning length:1,185 mm Bar capacity:102 mm Main spindle: Technology:Direct drive spindle Speed:4,000 rpm Power:48 kW Torque:680 Nm Bar capacity:102 mm C-axis:0.001° Chuck:Hainbuch Spanntop 100 Hydraulic clamping:Differential pressure clamping Clamping cylinder:Hollow Clamping Cylinder Coolant supply:External (chuck flushing) Sub spindde: Technology:Direct drive spindle Speed:4.000 rpm Power:48 kW Torque:680 Nm C-axis:0.001° Chuck:Hainbuch Spanntop 65 Hydraulic clamping:Differential pressure clamping Clamping cylinder:Partially Hollow Clamping Cylinder 848 mm Coolant supply:External and internal Tailstock function:Mechatronic control of the sub spindle Cede Ah Adbepfx Aqvshd Tool carrier I (X/Y/Z/B): Technology:Milling spindle on a travelling column Milling spindle speed:12,000 rpm Max. power:22 kW Tool holder:HSK 63 X-axis:450 mm Y-axis:200 mm (+/- 100) Z-axis:1,200 mm B-axis:+/- 110° Position measurement systems:Direct (glass scales) Tool carrier II (X/Y/Z): Technology:Tool turret on cross slide Tool drive:Direct drive Speed:10,000 rpm Power:14 kW Torque:34 Nm X-axis:195 mm Y-axis:80 mm (+/- 40) Z-axis:1,200 mm Tool holder:VDI 40 Number of tool stations:12 Steady rest:SLU2X turret steady rest, 8–101 mm Tool magazin: Technology:Chain magazine Number of stations:120 Tool changer:Double gripper Equipment: Position sensors:Direct in X1/Y1/Z1/X2/Z2/Z3 Chip removal:Chip conveyor Coolant supply:CTS system, 20 barCoolant Coolant Temperature Control Tool monitoring:Easy Tool Monitor Tool Breakage Monitoring:Swivel Wire Touch Probe:Renishaw Part removal:Part gripper, conveyor belt Bar feeder:Interface Software option I:5-axis simultaneous milling Software option II:Off-centre turning and milling Software Option IV:Gear Cutting and Gear Shaping Software option III:Alternating spindle speed Chucks:2x Hainbuch Spanntop :

Condition: ready for operation (used), Year of construction: 1990, functionality: limited functionality, turning length: 600 mm, spindle speed (min.): 4,000 rpm, spindle bore: 65 mm, type of input current: three-phase, total height: 270 mm, total length: 5,000 mm, total width: 220 mm, overall weight: 4,000 kg, There are 2 MONFORTS CNC lathes for sale. * Machine 1, MONFORTS RNC4, serves as a source of spare parts. The main circuit board has been removed and used elsewhere. (Chuck cylinder; hydraulic unit, spindle, tailstock; turret; chip conveyor; various control parts are still usable.) You are welcome to submit an offer for this machine. Control: GE Fanuc Tool turret: SAUTER turret ø40 • Type 0.5.801.020; • ID No. 070615; • Com. No. 14-89.44436/7 Without chuck Without tools Accessories: Articulated band chip conveyor Discharge height 1100 mm KS cable carrier Year of manufacture: 1990 Serial No. 3046 ----- * Machine 2 MONFORTS RNC 4 without tailstock Machine No. 137xx Series No. 119xx Control: GE Fanuc Monforts Control System F SAUTER turret ø 40mm • Type 0.5.801.020; • ID No. 070615; • Com. No. 14-89.44436/7 Without chuck, without tools Control powers up without problems. Maintenance, regular replacement of buffer batteries. Condition: The machine can be moved in the X & Z axes. The hydraulic system does not power up, probably because the solenoid valves are stuck due to prolonged downtime. Can be repaired. Accessories: Chip conveyor, KS cable carrier Year of manufacture: 1990; Serial No. 3254 ----- Technical data: RNC 4, RNC series Control: Fanuc 10 T Monforts Control F Max. turning length 600 mm / 1000mm Machine Ø over bed 420 mm Max. turning Ø over cross slide 280 mm Tool turret stations 12 VDI Spindle flange according to DIN 55026 A 6/A 8 Spindle Ø in the front bearing 130 mm Material passage through the spindle 65 mm Speed range, basic version 5-4000 rpm Tool turret, 12 tool positions Total power consumption: 22 kW Machine weight approx.: 4 t Cjdpfs Ahzfwjx Aqvohd Space requirement approx.: m The machines are no longer used in production. Both machines can be sold as a package. The machines are still connected to the power supply. The control of machine 2 powers up without any problems.

Condition: ready for operation (used), Year of construction: 2018, operating hours: 25,500 h, travel distance X-axis: 160 mm, travel distance Z-axis: 510 mm, controller manufacturer: SIEMENS, controller model: Sinumerik 840D-sl, number of slots in tool magazine: 24, number of axes: 8, This 8-axis EMCO Hyperturn 45 was manufactured in 2018. It features dual water-cooled integrated motor spindles with a maximum bar capacity of 45 mm and a powerful drive power of 15 kW for each spindle. The machine includes two 12-station radial tool turrets and a high-pressure coolant system. If you are looking to get high-quality turning and milling capabilities, consider the EMCO Hyperturn 45 turn-mill centre we have for sale. Contact us for further details. - CNC Control: Siemens Sinumerik 840D-sl / OPERATE with 22" Multi-Touch Display, emcONNECT, IPC with 240 GB, and ShopTurn dialog programming- Operating Hours (Machine on): 25,304 h 09 min 43 sec- Operating Hours (Ready for operation / automatic mode): 22,788 h 54 min 36 sec- Operating Hours (Production mode): 21,003 h 11 min 32 sec- Total Alarm Time: 2,625 h 48 min 54 sec- Number of Spindles: 2 (Water-cooled integrated motor spindles for main and counter spindle)- Drive Power (Main Spindle): 15 kW- Drive Power (Counter Spindle): 15 kW- Speed Range (Main Spindle): 0 - 7,000 rpm- Speed Range (Counter Spindle): 0 - 7,000 rpm- Spindle Nose (Main Spindle): DIN 55026 KK 5- Maximum Bar Capacity: 45 mm- Spindle Nose (Counter Spindle): DIN 55026 KK 5- Axes: 6 linear axes, 2 rotary axes (C-axis on main and counter spindle, TRANSMIT software included)- Y-Axis Travel: mm- Y-Axis Rapid Traverse Rate: 15 m/min- Tool Carriers: 2x 12-station radial tool turrets VDI 25 with directional logic (for up to 2x 12 driven tool stations)- Driven Tools Power: max. 4 kW at 2,080 rpm- Driven Tools Torque: 16 Nm constant- Driven Tools Speed Range: 0 - 6,000 rpm- Linear Scales: Absolute direct linear encoders (HEIDENHAIN) with sealing air on X1, Y1, and X2 axes- Workpiece Handling: Pneumatic finished-part catcher HT45 (max. part length 120/180 mm, max. part diameter 45 mm, max. weight 2 kg) with indexed conveyor belt (storage area 340 x 750 mm)- Spindle Extension: For DM45, including 3 reduction tubes (allows short bars up to 1,200 mm through the spindle)- Mist Collector: Mechanical oil mist separator REVEN (RECOJET-2), air throughput 1,000 m³/h, 250 W, connection diameter Ø160 mm- Electrical Connection: 3x 400V / PE, 50/60 Hz, Imax = 60 A, Supply line fuse 80 A gG/gL, Icw Chedpfx Ae Ahzcieqvsd

Condition: good (used), Year of construction: 2004, CNC turning/milling center Manufacturer: MAZAK Machine model: Integrex 200 2S Control: Mazatrol 640 MT pro Year of manufacture: 2004 TECHNICAL DATA Swing diameter, max. (mm) 660 Turning diameter, max. (mm) 660 Max. turning diameter over slide (mm) 500 - 660 Bar machining up to Ø (mm) 64 Workpiece weight - Chuck workpiece (kg) 100 - Shaft workpiece (kg) 150 Travel distances - X-axis (mm) 580 - Z-axis (mm) 1,045 - Y-axis (mm) ± 80 - W-axis (mm) 1,050 - B-axis (degrees) -30 to +195 Rapid traverse rate (m/min) - X-axis (m/min) 38 - Y-axis (m/min) 26 - Z-axis (m/min) 38 - W-axis (m/min) 30 - C-axis (rpm) 400 Feed rate range - X / Z / Y-axis (mm/min) 0 – 8,000 Main spindle integrated spindle motor - Speed range (stepless) (rpm) 35 – 5,000 - Drive power (kW) 22 - Torque max. (Nm) 349 Cedpfo Ahynkex Aqvjhd - Spindle nose A2 - 6 inches - Indexing (degrees) 0.0001 Second spindle - Speed range (rpm) 35 – 5,000 - Drive power (kW) 18.5 - Torque max. (Nm) 326 - Indexing (degrees) 0.0001 Driven tools - Speed range (rpm) 15 – 12,000 - Drive power (kW) 15 - Torque max. (Nm) 120 - Tool holder Capto C6 Tool magazine - Number of tool positions 40 - Tool weight max. (kg) 10 - Tool diameter max. (mm) 90 - with free secondary positions max. (mm) 125 - Tool length max. (mm) 300 - Tool change time (sec.) approx. 1.3 sec Connected load 62 kVA Operating voltage 400 V / 50 Hz EQUIPMENT FEATURES + Coolant tank capacity 220 liters + Chip conveyor, hinged belt design, discharge to the side + Automation alphaMAX ++ Industrial robot designation Motoman NX 100 ++ Number of axes 6 ++ Load capacity 20 kg ++ Positional repeatability ± 0.06 mm DIMENSIONS and WEIGHTS Machine weight (kg) approx. 10,200 Machine footprint (mm) 3,820 x 2,060 Subject to changes and errors in technical data and specifications.
