FULLY AUTOM. INLINE M. FOR FOLDING BOXES

BOBST MIDLINE 924

FULLY AUTOMATIC INLINE MACHINE FOR FOLDING BOXES BOBST MIDLINE 924

Speed: up to 18000 boxes per hour
Nominal machine width: 2400 mm
Nominal plate cylinder circumference: 1000 mm
Largest printing area: 920 x 2400 mm
Maximum corrugated board thickness: 10 mm
Standard slitting blade thickness: 6.35 mm
Average connected load: 200 kVA

The line consists of:
1) Feeder Serco
2) Main machine – Flexographic printing machine midline 924
Colors: 3 // Automatic washing device
3) Slotter (Riller)
Longitudinal slots // Tool is installed in the machine.
4) Punching module (e.g. for punching handles)
5) Breakout vibrating station
Nwjdpexrfraefx Agzsr
(Material – punching residues are disposed of using compressed air)
6) Glue station Robotech
7) Folding unit
8) Counting station & display
The specified number of cartons will be bundled
- up to here main unit -
9) Package binder / bundling machine CEMA
Fully automatic strapping machine with weld seal and press for 5 mm plastic strapping,
for binding corrugated cardboard bundles in the direction of travel of the flute
10) Palletizing system Martin
Automatic layer formation. Roller tables receive the packages from the bundling machine. The packages are positioned using the ball bearing table according to their arrangement in the preselected position. If necessary, the package can be rotated 90° or 180° simultaneously with the lateral movement.
