Used T 40 E for sale (98,573)

Condition: good (used), Year of construction: 2015, Capacity: 100 l Gjdpfx Alsz D T R Se Usbu

Condition: excellent (used), Year of construction: 2016, Clamping force (kN): 1600 Opening stroke (mm): 460 Mould height (min–max) (mm): 250 – 600 Platen size (mm): 760 × 760 Tie bar distance (mm): 520 × 520 Ejector stroke / force (mm / kN): 150 / 40 Dry cycle time (sec): 1.4 – 320 Injection unit 1: Screw diameter (mm): 30 Screw stroke (mm): 160 Shot volume (cm³): 113 Screw speed (rpm): 420 L/D ratio (3 zones): 23.6 / 20.0 Plasticizing capacity (g/sec): 15 / 22 L/D ratio (barrel): -29 Plasticizing capacity (barrel) (g/sec): -29 Injection flow (cm³/sec): 157 / 214 Injection pressure (bar): 2400 / 2000 Nozzle stroke / force (mm / kN): 225 / 28 Injection unit 2: 30 mm Drive / Power Pump motor power (kW): 16.91 Working hours 13.227 h Type: Multicomponent Drive: Electric Gedpfx Aljyyz Ddj Ujbu Possible to buy with Viper robot

Condition: used, Year of construction: 2007, machine/vehicle number: M1348, Dimensions: 255 width x 170 depth x 254 height Weight: 4,100 kg Max pressing force: 400 kN (40 tons) Max bending length: 1,600 mm Distance between uprights: 1,600 mm Godpeylhkyjfx Al Uobu X-axis travel: 600 mm Max stroke: 290 mm Controlled axes: X, Y, R Control: Equipment: 4 backgauges Condition: Original monitor defective --> Second monitor installed and connected to the machine. (Works) Crowning: Servo-mechanically operated Power Belt system --> even force distribution The machine is fully operational and in good overall condition.

Condition: excellent (used), Year of construction: 2023, Capacity: Distance between spindle center and guides mm 220 Swinging diameter over bed mm 440 Swinging diameter over cross slide mm 230 Max. turning diameter over bed mm 400 Max. turning length between centers mm 1,000 / 1,500 Bed width mm 330 Headstock: Distance spindle center - bed mm 220 Spindle nose according to standard DIN 55027 Type C6 Spindle bore according to DIN Godpfx Aloz Ai N Dj Uobu 55027 mm 66 Max. spindle speed rpm 3,500 3-jaw chuck diameter mm 250 3-jaw chuck bore mm 76 Spindle motor power S1 100% / S6 40% / S6 25% kW 10 / 14 / 17 Spindle torque S1 100% / S6 40% / S6 25% Nm 159 / 224 / 272 Tailstock: Travel of quill mm 120 Quill diameter mm 65 Internal taper MT 4 Control: HEIDENHAIN TNC 620 MANUAL PLUS Accuracy: Positioning accuracy mm +/- 0.010 on 1,000 Repeatability mm 0.010 on 1,000 General information: Dimensions (without control panel): L x W x H mm 2,500 x 1,600 x 1,800 Weight kg 2,500 Max. installed power kVa 16

Condition: good (used), Year of construction: 2009, ENGEL Emotion 440/100T Clamping force: 1000 kN Gbedpjyktp Ssfx Al Uou Opening stroke: 400 mm Ejector stroke: 130 mm Ejector force: 37 kN Screw diameter: 40 mm Max. swept volume: 220 cm³ Screw speed max: 420 rpm Injection rate: 224 cm³/s Specific injection pressure: 2200 bar Nozzle stroke: 305 mm Nozzle contact force: 40 kN

Condition: like new (used), Year of construction: 2023, operating hours: 100 h, functionality: fully functional, ABB Robotics IRB 4600-40/2.55 robot IRC5 controller Year of manufacture: 04/2023 Approx. 100 operating hours Used item – shows normal signs of wear. Further details, article numbers, and images available upon request. Two-week commissioning guarantee. No further warranty. Gjdpfsz I I Nqsx Al Ujbu In addition, spare parts are constantly available in stock. The robot is fully functional and can be inspected at any time. Ex works / free loading. The stated amount is net. The legally required value-added tax of 19% will be added at checkout. You will receive a proper invoice with the value-added tax shown. Collection on site in 74722 Buchen/Hainstadt. Shipping or freight costs vary depending on the quantity, weight, and desired delivery conditions. Shipping costs to foreign countries available upon request – please specify the country, city, and postal code. Freight costs available upon request – please specify the delivery address.

Year of construction: 1999, condition: excellent (used), working width: 620 mm, machine/vehicle number: SE 01510 A10, Heating Element Welding Machine HP60/40 by BRANSON The drive is hydraulic, supported by positioning and control systems. The machine is equipped with its own vacuum pump. Only a few operating hours (approx. 6,800 hours). Gedpeykvdlsfx Al Uobu Usable heating element area: width 600 mm x depth 400 mm Max. workpiece dimensions: - Max. width: 620 mm - Max. depth: 420 mm - Max. upper height: 350 mm - Max. lower height: 350 mm (Combinations of part heights possible, depending on contour) - Max. processing temperature for contact method: 400°C The modular frame design allows for easy conversion and retrofitting. The side doors and the front door in the welding area can be easily opened (for rapid retooling). The automatic safety lift door ensures a high level of operator safety. The temperature control units on the operator panel have actual/target displays. The control device is a Siemens PLC HMI. The machine is controlled by a Siemens PLC (S7-300 controller). Heating elements are equipped with temperature sensors for temperature regulation and serve as safety cut-offs in case of overheating. The pin systems in the tool mounting surfaces ensure reproducible positioning. Advantages of heating element welding technology: - Reliable welding of workpieces with low or varying wall thicknesses. - Low scrap rate due to dimensionally accurate and repeatable welds. - Precise time, temperature, and force control enable welding of sensitive parts. - Virtually all thermoplastics can be welded with this process. - Different thermoplastic types can be joined (compatibility needs to be verified). Technical data of the machine: - Power supply: 3 x 400 V AC + N + PE - Power: 25 kVA - Rated current: 20 A - Required cable cross-section: 5 cables, each 6 mm² - Required pneumatic connection: 6 bar Machine dimensions: - Machine width: approx. 1.22 m - Machine width with operator panel: approx. 1.8 m - Machine depth: approx. 2.1 m - Machine depth with operator panel: approx. 2.6 m - Machine height: approx. 2.4 m - Machine height with raised safety door: approx. 2.85 m (open door) Machine weight: approx. 2.2 t

Year of construction: 2023, condition: new, pressure 40 t throat 195 mm stroke 8-78 mm no. of strokes 76-190 Hub/min ram - range of adjustment 60 mm table surface area 650x380 mm table height 840 mm hole in the table Ø 110 mm ram surface 250x350 mm Gedpfxjp Udupj Al Uebu tool hole in ram Ø 40 mm total power requirement 3 kW weight of the machine ca. 2,2 t dimensions of the machine ca. BxTxH 1450x1220x2110 mm

Condition: used, Year of construction: 2012, operating hours: 32,200 h, The machine offered is an ENGEL VC 200/40 Tech, manufactured in 2012. The machine is currently connected to the power grid. Technical specifications: Manufacturer: ENGEL Model: victory 200/40 tech Year of manufacture: 2012 Control system: ENGEL CC 200 Operating hours: approx. 32,200 h Clamping force: 400 kN / 40 t Screw diameter: 30 mm Injection pressure: 1,451 bar Displacement: 99 cm³ Platen size: 500 × 450 mm Tool height: 200 mm Opening stroke: 400 mm Max. platen distance: 600 mm Centering: 125 mm Ejector stroke: 100 mm Nozzle thread: M28 × 1.5 Smallest tool size: 280 mm Power: 15 kW Machine weight: approx. 2,900 kg Core pull: 1 Air ejector: 2 RSP: 3-part Design: tie-bar-less ____ Wittmann W702 picker / handling device Manufacturer: Wittmann Type: W702 Year of manufacture: 2012 Serial No.: 0000171976 Article No.: 7F00000506 X-axis: 100 mm Y-axis: 550 mm Z-axis: 90° Weight: approx. 52 kg Voltage: 105–250 V Current consumption: 1.6 A Gbodpfx Alsz Ap Ims Usu According to the available Wittmann documentation, the handling device has been refurbished. After completion of the work, a functional test and test run were carried out with the result "OK". _____ Cooling unit Manufacturer: aic regloplas GmbH Model: TAE EVO 081 Year of manufacture: 2006 Serial No.: 2200 086 152 Connection: 400 V / 3 Ph / 50 Hz Rated power: 11 kW Max. current consumption: 19 A Protection class: IP54 Max. operating pressure, water circuit: 6 bar Max. water temperature: 65 °C Refrigerant: R407C Refrigerant quantity: 5.5 kg Weight: approx. 331 kg _____ Scope of supply ENGEL victory 200/40 tech injection molding machine Wittmann W702 picker / handling device aic regloplas TAE EVO 081 cooling unit Inspection is possible by appointment. Dismantling and loading are the responsibility of the buyer! The machine is located in Bremen. _____ Subject to prior sale and errors in technical specifications. The technical specifications have been compiled to the best of our knowledge, but do not constitute guaranteed characteristics. Our general terms and conditions apply; the seller is not liable for typing or data transmission errors. The appearance of the offered items corresponds to their age and the images shown. The technology and wear of the offered items are consistent with their age. Used machines are sold exclusively to commercial customers and without warranty.

Year of construction: 2011, condition: ready for operation (used), A complete Stürtz window production line is available. 1) Stürtz STBAZ-IPT-4000-V bar processing system for frames, sashes and mullions, year of manufacture: 2004. 2) Stürtz SE HSM-25/26-Compact-Plus four-head welding machine for sashes, year of manufacture: 2006. 3) Stürtz 4MC Motion Control CNC cleaning machine for the sash line, year of manufacture: 2011. 4) Stürtz WST-25-CNC turning station at the sash cleaner (3), year of manufacture: 2011. 5) Stürtz SE-HSM-40/26-Compact-Plus horizontal four-head welding machine for frames, year of manufacture: 2006. 6) Stürtz 2MC Motion Control CNC cleaning machine in the frame line, year of manufacture: 2008. 7) Stürtz WST-30 turning station in the frame line, year of manufacture: 2008. 8) Stürtz SE-BHT-3000 brush lifting table as a stop and transport table before the sash stop, year of manufacture: 2008. 9) Stürtz FBS-1 sash hardware screwing machine in continuous operation, year of manufacture: 2008. 10) Stürtz SE-VW-FT distribution and stacking trolley in the sash buffer system, year of manufacture: 2008. This is a complete production line for window construction. Documentation available. An on-site inspection is possible. Gbodpfszcyqmjx Al Uju

Condition: excellent (used), Year of construction: 2015, Clamping force: 100 t Godpfx Ajzypwpjl Usbu Screw diameter: 40 mm Shot weight: 150 g Shot volume: 165 cm3 \+ robot Sepro success 11 Type: Horizontal Drive: Electric

Condition: used, Drilling / Milling machine OPTIMUM type OPTI F 40 E Gedpfjz Nxw Ajx Al Usbu Travel X: 500 mm Travel Y: 200 mm Spindle: Ø 80 mm Cone CM3 Spindle exit: 120 mm Spindle speed: from 95 to 3200 RPM Table size: Length 730 mm x Width 210 mm 2 speeds motor Motor power: 1,5 Kw Straight head Cross table Manual Descent Equipped with: 1 rotary vice Voltage: 380 V Dimensions (L x W x H): 1200 x 900 x 1400 mm Weight: approx 350 KG

Condition: excellent (used), ENGEL e-cap 3440/420 T injection molding machine Basic data • Manufacturer: ENGEL • Model: e-cap 3440/420 T • Year of manufacture: 2012 • Machine type: Fully electric injection molding machine • Control system: ENGEL CC200 • Operating hours: 63,000 h • Screw diameter: 80 mm Technical data Clamping unit • Clamping force: 4,200 kN (420 tons) • Clamping mechanism: Kneel-type, fully electric • Opening stroke: 700 mm Gbedpozlgi Hefx Al Ueu • Minimum mold height: 350 mm • Maximum mold height: 750 mm • Mounting plate dimensions: 1350 × 1350 mm • Column spacing: 920 × 920 mm • Ejector stroke: 220 mm • Ejector force: 120 kN • Maximum mold weight: 6200 kg Injection unit • Unit size: 3440 • Screw diameter: 80 mm • Injection volume: 1709 cm³ • Maximum injection pressure: 1950 bar • Number of heating zones: 6 Equipment • ENGEL CC200 control system • Fully electric drives for all axes • Energy-efficient ENGEL e-cap technology • Very high precision and process repeatability • Suitable for continuous 24/7 operation Machine history The machine has been used since new for the production of plastic buckets. It has never been used for the production of PET caps, although the e-cap series was designed specifically for this type of application. The average cycle time was approximately 15 seconds. As a result, the clamping unit has performed significantly fewer operating cycles than typical e-cap machines used for cap production, where the cycle time is usually below 2–4 seconds. This potentially indicates lower mechanical wear compared to machines operated according to their original intended purpose.

Condition: used, functionality: unexamined, Lutetia Tumbler T 40 with defrost function. Gbsdpfszpg Uwox Al Uju

Condition: excellent (used), Year of construction: 2012, functionality: fully functional, Press force: 300 t Bending length: 4050 mm Distance between uprights: 3550 mm Control system: EHT EPS D01-3D Total power requirement: 30 kW Machine weight (approx.): 24,000 kg Machine height: 3.60 m Gbjdpozt R A Hsfx Al Ueu Operating hours (approx.): 12,000 h Accessories/Equipment: Rear back gauge system, 5-axis Travel range and back gauge area Travel range X-axis: 600 mm Max. back gauge range in X: 1000 mm Travel range X1-axis: ± 125 mm Travel range R-axis: 200 mm Travel range Z-axis: 3150 mm Accuracy Positional deviation of the axes X-axis: 0.02 mm X1-axis: 0.02 mm R-axis: 0.05 mm Z-axis: 0.05 mm Speeds X-axis: 1200 mm/s X1-axis: 300 mm/s R-axis: 200 mm/s Z-axis: 1200 mm/s

Condition: used, Year of construction: 2020, max. workpiece length 6360 mm profile spindle 1 Stück main drive 13 kW Control Maestro SCM CNC Machining Center ACCORD 40 FX for windows and doors ----- Available as an OPTION at an additonal cost of 20.000 Euro: extensive window and door tooling among others (window cutting available upon request!): Wooden windows IV 68, 78, 92 Wooden "style" windows Wood-aluminum windows Front doors Lift-and-slide doors Box windows Machine still in operation, available for viewing! Technical Summary (detailed description available upon request!): ----- - ??Working area X-Y = 6360 x 1905 Z = 350 - Automatic table with 8 support rails MATIC - L1825 - 5-axis spindle MAXI - Prisma T, HSK 63 E, 13 kW - RTCP Setting - Self-calibration system for Prisma work unit - Adjustable chip removal device on the electric spindle - Preparation for "Prisma T-S" angle gearbox - BRC - Working unit: Saw blade for face machining, 1 vertical milling cutter connection 3 vertical, independent drill heads, center distance 32 mm 3 vertical drill heads (not independent), center distance 21.5 mm, for mortise drilling 4 horizontal drill heads (2 per side, not independent), center distance 21.5 mm 2 horizontal milling heads (1 per (Page) - TRC 48 - Rear Tool Magazine 48 tool positions (excluding tool holders) Center-to-center distance between positions: 104 mm Max. tool diameter: 350 mm Max. tool length: 320 mm Max. weight per tool: 10 kg (15 kg with HSK 63 E spindle) Max. total weight on the magazine: 250 kg - MACH 5 - Quick-change system: Allows tool changes on the electric spindle in just a few seconds. - Pendulum operation - Automatic lubrication of the axes - eye-M operating console with integrated PC - Additional fixed control panel - TECPAD - Remote control of machine functions - Clamping jaw preparation H145 for worktable with 8 support rails - Front stop row H110 for worktable with 8 support rails - Rear stop row H110 for worktable with 8 support rails - Suction cup H110 145x145 mm - Swivel suction cup H110 145x55 mm - Swivel suction cup H110 180x65 mm - First side stop row H145 for worktable with 8 support rails Second side stop row H145 for worktable with 8 support rails Clamp H145 with round base Clamp H145 with square base N.6 Lifting devices with double stroke H145 Gbodpfx Ajy Hl Iyel Uou Laser and reference stop H145 for sheet (left) - PRO-SPEED safety system - Maestro CNC - Machine operator interface and programming - Maestro ProView - Simulation software Tools are sold in the condition, scope, and with accessories as they are currently in stock. Note regarding window cutouts, tool drawings, and tool system listings: Engelfried GmbH does not guarantee that the tools actually available correspond to the systems listed and drawn. (Technical specifications according to the manufacturer - without guarantee!)

Condition: excellent (used), Year of construction: 2018, operating hours: 33,526 h, functionality: fully functional, clamping force: 1,600 kN, screw diameter: 40 mm, clearance between the columns: 520 mm, displacement volume: 220 cm³, plate length: 760 mm, plate height: 760 mm, total length: 67,500 mm, total width: 2,000 mm, total height: 2,420 mm, overall weight: 8,500 kg, Equipment: documentation/manual, ENGEL e-motion 440-160 Stock No.: 503676 Manufacturer: ENGEL Type: e-motion 440-160 T Control: CC300 Year of manufacture: 2018 Operating hours: 33526 h Technical data, clamping side Clamping force: 1600 kN Tie bar spacing h x v: 520 x 520 mm Platen size h x v: 760 x 760 mm Minimum installation height: 375 mm Maximum installation height: 600 mm Maximum platen spacing: 1060 mm Opening stroke: 460 mm Ejector stroke: 150 mm Ejector force: 40 kN Centering of moving platen D: 160 mm Centering of fixed platen D: 160 mm Tool weight: 1250 kg Technical data, injection side Screw diameter: 40 mm Displacement: 220 ccm Injection pressure: 1940 bar Screw length: 24 l/d Screw stroke: 175 mm Screw speed: 420 min Screw torque: 605 N Plasticizing rate: 33 g/s PS Free injection rate: 224 g/s PS Number of heating zones: 4 Nozzle stroke: 305 mm Dimensions & Weight Machine dimensions L x W x H: 6.75m x 2m x 2.42m Total weight: 8500KG Gedpfx Ajz A S I Tjl Uebu Equipment Screen text in German Screen text in English CEE socket 32A Hydraulic core pull, 2x Hydraulic core pull unit Air valve 1x Machine with water manifold Machine without material hopper Machine without suction conveying system Pneumatically operated needle shut-off nozzle Leveling elements EUROMAP 63 interface EUROMAP 67 Handling interface Interface for ejector plate locking Schuko socket 10A

Year of construction: 2015, condition: used, functionality: fully functional, Epilog Fusion 40 / 120 Watt, laser engraving and laser cutting system - 120 Watt CO2 "WaveGuide" laser source, according to the last service on August 5th, 2024, laser power 132 Watt - Working area 1016X711mm - 2" focus lens - Drive: brushless DC servo motors for crystal-clear cutting edges in acrylic glass - Max. material thickness 362mm - Max. weight of workpiece: 91kg - Laser safety class 2 - Interface: Ethernet, freely programmable IP address - Air assistant on laser beam - Joystick for motorized movement of the axes - Zero position can be changed, machine LED lighting - Large format viewing window made of safety glass - Laser beam expansion, base frame on castors - Honeycomb cutting table - Round engraving unit for cylindrical objects with roller system Extraction: vacair UML 1350 extraction system - Recirculation system with 3 levels -Filter - Filter: particle filter HEPA H14, pre-filter cassette - Activated carbon cassette 43kg (with HEPA) - Fan output 1350 m³/h - Pressure 10,000 Pa - Separation level >99% - Suction/exhaust air nozzle DM 125mm - - Sale only to traders - Exclusion of any guarantee or warranty claims - Sale with invoice and VAT - No liability for spelling errors, typos - Sale as seen, later complaints excluded Machine in very good condition, few operating hours - Machine is very well maintained and clean New prices: Round engraving unit, built in 2019, €1840/net Laser Fusion 40 /120 watts, built in 2015, €55,000/net Godpovvha Sefx Al Usbu Vacair UML 1350 extraction system, built in 2021, €5,450/net Total: €62,300/net

Condition: excellent (used), Year of construction: 2011, cutting diameter 400 mm capacity 90 degrees: flat 500 x 400 mm saw band length 6220 x 41 x 1.3 mm speed 15.0 - 150 m/min work height max. 750 mm workpiece weight ca. 250 - 300 kg/m Control MEBA NC coolant tank capacity 80.0 ltr. Gbedpfez Dkzuox Al Ueu oil volume 30.0 ltr. power capacity 5.5 kW weight of the machine ca. ca. 2250 kg range L-W-H 3100 x 1620 x 2150 mm Current list price: approx. 50.000 euros Special price available upon request Features: - MEBA - Fully automatic "two-column linear guide system" * Fully automatic machine for 90° cuts only - User-friendly NC dialog control * With plain-text display 5.7-inch CE panel * Program memory with 50 programs, each with 20 steps - Automatic material feed * Minimum cutting diameter .. Ø 5.0 mm * Residual piece length without bundle clamping .. manual 25.0 mm * Residual piece length without bundle clamping .. automatic 110 mm * Automatic movement of the clamping blocks - Rapid-feed lowering of the saw frame * With automatic material detection - Band saw speed via frequency-controlled AC drive (15-150 m/min) - Automatic cutting pressure and feed monitoring - Driven chip-clearing brush via friction wheel - Hydraulic full-stroke material clamping - Saw blade angled 3° relative to the material support surface - Saw blade idler rollers with carbide guides - Manual saw blade tensioning - Removable coolant tank for easy cleaning - Operating instructions

Condition: used, Year of construction: 1985, round bar steel 40 mm square edge steel 40 mm L-beam 120 x 12 mm Punch power 600 kN hole punching press: throat 400 mm hole punching press: max. length of stroke 32 mm hole punching press: capacity (dia. x thick.) 30 x15 mm hole punching press: capacity (dia. x thick.) 20 x 20 mm notching: l + T material 80 x 10 mm no. of strokes 40 / 46 Hub/min shear: flat material 150 x 15 mm shear: length of knifes 275 mm total power requirement 3 kW weight of the machine ca. 2,9 t dimensions of machine L x W x H 2,18 x 0,83 x 2,15 m Godpeydqn Sefx Al Usbu Accessories: tool cabinet with various punches and dies, length stop

Condition: used, functionality: fully functional, Main Technical Specifications Machine Model: COMDEC LV 50-40 PFT horizontal baling press Pressing force: 50 tons Horizontal hydraulic baler for cardboard, paper and industrial waste Electrical data Power supply: 380 V / 3 phase / 90 A Hydraulic motors: 2 × 22 kW hydraulic pump motors Conveyor pump motor Hydraulic system Hydraulic main cylinder: 180 / 150 × 2000 mm Hydraulic pressure control system with oil cooling and filtration Oil tank with pressure and return filters Machine dimensions Total machine length: approx. 8,394 mm Width: approx. 1,920 mm Height: approx. 3,104 mm Functional equipment Automatic wire tying system Bale length control system Hydraulic wire twisting unit Gedsy Uddiopfx Al Ujbu Automatic bale ejection system Conveyor control cabinet and electrical automation system Noise level Working noise level below 70 dBA

Year of construction: 2022, condition: excellent (used), Dycometal Type: CCK -40/1500T Water-cooled climate chamber Volume in liters: 1500 Internal dimensions: height 1000 mm, width 1000 mm, depth 1500 mm Gbjdpfxjzgr Rrj Al Uju External dimensions: height 2200 mm, width 1293 mm, depth 3400 mm Thermal testing Minimum temperature: -40°C Maximum temperature: +150°C Cooling rate: 2.0 K/min Heating rate: 3.5 K/min Temperature stability: ±0.1°C to ±0.3°C Temperature uniformity: ±0.5 °C to 1.5°C Climate testing, temperature range: +10°C to +90°C Humidity range: 10% to 98% RH Dew point range: +6.5°C to +86°C Humidity stability: ±1% RH to ±3% RH Condenser: water-cooled Rated voltage: 400 V 3N~PE 50 Hz Power: 16.1 kW, 27.5 A Refrigerant: R-452A Weight: 1120 kg Condition: used Scope of delivery: (See image) (Subject to changes and errors in the technical data and specifications!) We will be happy to answer any further questions you may have by phone.

Condition: used, Year of construction: 2007, functionality: fully functional, SE-HSM-40/26-COMPACT-PLUS Horizontal four-head welding machine Gjdpszm N Nrjfx Al Usbu 2MC Horizontal CNC corner edging machine, motion control WST-30 Horizontal turning station Minimum element size 320 × 320 mm Maximum element size 4,000 × 2,600 mm Maximum element weight 80 kg Minimum working area 320 × 320 mm Maximum working area 4,000 × 2,600 mm

Condition: good (used), Year of construction: 2011, total length: 5,100 mm, total width: 2,200 mm, total height: 3,400 mm, overall weight: 19,700 kg, Press force: 230 t Bending length: 4050 mm Distance between uprights: 3550 mm Upright overhang: 420 mm Oil capacity: 400 l Control system: ModEva 10S Machine weight (approx.): 19700 kg Dimensions: 5100 x 2160 x 3420 mm Equipment/Accessories: - Automatic tool clamping, pneumatic - Motorized crowning - Akas-Fiessler safety laser Gsdpfxoztafqj Al Uobu - Bending aid 1 + 2 (right and left) - Die shifting m1 and m2 - Axis-controlled: Y1, Y2, Xs, Xm, X delta, R, Z1, Z2

Condition: good (used), Year of construction: 2019, pressure 220 t Godpfx Aezu A Rxol Uobu chamfer lenght 4100 mm distance between columns 4100 mm stroke of upper beam 400 mm dayligth 570 mm working feed 21.0 mm/sec return speed 200.0 mm/sec work height max. 970 mm Control LVD Touch-B CNC 18" total power requirement 37.0 kW weight 27500 kg range L-W-H 5100 x 1950 x 2850 mm well-maintained condition (!!) Special price on request Equipment: - CNC electro-hydraulic press brakes * Intuitive, touchscreen-based user interface * Simple navigation * Tool and program library * X-axis control and position display * Y-axis control and position display * Swiveling control panel (front left) - CNC-controlled - CNC electric backgauge (X-axis) * CNC electric gauge fingers (R-axis) * Includes height adjustment (R-axis) * Intelligent tool storage (automatic tool changing) * Bending aid - LVD upper tool holder * Hydraulic upper tool clamping - LVD lower tool holder * Hydraulic die clamping - Side safety guards (swiveling doors) - Rear safety guard (swiveling door) - 1x movable foot pedal - Machine documentation ToolCell is a fully equipped hydraulic press brake with an integrated automatic tool changer. It is the ultimate bending solution for small to medium-sized batches, high product variety, and increased workpiece complexity.
