Used Window Dolly for sale (11,590)

Condition: used, System 68,78,88,98 IV Number of tools 6 St. Bore 50 mm Leitz window tool set for IV 68/78/88/98 (timber) and IV 68/88 (timber-aluminum), plus entrance doors and lift-and-slide systems ----- Timber: Leitz IV 68/78/88/98 (timber) Timber-Aluminum: Leitz IV 68/88, entrance doors, and lift-and-slide systems Tools were used on a Weinig Unicontrol 6 NC (with stepless vertical adjustment) Njdoz Albpopfx Afujdb ----- Price for the above-mentioned tools available upon request! ----- (Technical specifications provided by the manufacturer – subject to change/no guarantee!) All prices are net, plus statutory VAT.

Condition: used, Year of construction: 2016, max. workpiece length 4500 mm profile spindle 1 Stück main drive 19,2 kW MASTERWOOD 4 WIN 2.0 CNC Machining Center with automatic loading and unloading ----- Specially designed for efficient and flexible production of wooden windows and doors Nsdpfxezn Ahwo Afujdb HIGHLIGHTS: - Various tool magazines for optimal tool loading - Simultaneous loading of up to 6 workpieces - Patented clamping system for optimal machining of workpieces - CNC-controlled worktable with automatic positioning of beams and clamps - Automatic re-clamping for switching between exterior and interior profiling - INTEGRATED window manufacturing software, meaning the machine does not have to (but can, of course) be controlled from the office using external industry software. - Powerful 19.2 kW HSK-63 E motor - Loading and unloading conveyors - Auxiliary table for round arch production and door panel machining Request a quote and see for yourself this unbeatable value for money! VIDEO of an identical machine attached! For sale on behalf of a client Technical specifications provided by the client (Technical specifications according to the manufacturer—subject to change!)

Condition: used, System 68, 78, 80, 92 IV Number of tools 4 St. Bore 50 mm Used Leitz window tools, Zuani IV 68, 78, 80, 92 Sale on behalf of our customer Njdpezughnsfx Afusdb ----- Window cross-sections attached as a PDF! Due to modifications, some tools are older than those shown in the attached window cross-sections/drawings. Tools are sold in their current condition, in the quantities shown and with accessories as available. Note regarding window cross-sections, tool drawings and tool system listings: Engelfried accepts no liability for the actual tools being consistent with the systems mentioned and shown in the drawings. ----- (Technical specifications as per the customer – subject to change!) All prices quoted are net, plus statutory VAT.

Condition: used, Year of construction: 2020, max. workpiece length 6360 mm profile spindle 1 Stück main drive 13 kW Control Maestro SCM CNC Machining Center ACCORD 40 FX for windows and doors ----- Available as an OPTION at an additonal cost of 20.000 Euro: extensive window and door tooling among others (window cutting available upon request!): Wooden windows IV 68, 78, 92 Wooden "style" windows Wood-aluminum windows Front doors Lift-and-slide doors Box windows Machine still in operation, available for viewing! Technical Summary (detailed description available upon request!): ----- - ??Working area X-Y = 6360 x 1905 Z = 350 - Automatic table with 8 support rails MATIC - L1825 - 5-axis spindle MAXI - Prisma T, HSK 63 E, 13 kW - RTCP Setting - Self-calibration system for Prisma work unit - Adjustable chip removal device on the electric spindle - Preparation for "Prisma T-S" angle gearbox - BRC - Working unit: Saw blade for face machining, 1 vertical milling cutter connection 3 vertical, independent drill heads, center distance 32 mm 3 vertical drill heads (not independent), center distance 21.5 mm, for mortise drilling 4 horizontal drill heads (2 per side, not independent), center distance 21.5 mm 2 horizontal milling heads (1 per (Page) - TRC 48 - Rear Tool Magazine 48 tool positions (excluding tool holders) Center-to-center distance between positions: 104 mm Max. tool diameter: 350 mm Max. tool length: 320 mm Max. weight per tool: 10 kg (15 kg with HSK 63 E spindle) Max. total weight on the magazine: 250 kg - MACH 5 - Quick-change system: Allows tool changes on the electric spindle in just a few seconds. - Pendulum operation - Automatic lubrication of the axes - eye-M operating console with integrated PC - Additional fixed control panel - TECPAD - Remote control of machine functions - Clamping jaw preparation H145 for worktable with 8 support rails - Front stop row H110 for worktable with 8 support rails - Rear stop row H110 for worktable with 8 support rails - Suction cup H110 145x145 mm - Swivel suction cup H110 145x55 mm - Swivel suction cup H110 180x65 mm - First side stop row H145 for worktable with 8 support rails Second side stop row H145 for worktable with 8 support rails Clamp H145 with round base Ndodpfx Afey Hl Iyjueb Clamp H145 with square base N.6 Lifting devices with double stroke H145 Laser and reference stop H145 for sheet (left) - PRO-SPEED safety system - Maestro CNC - Machine operator interface and programming - Maestro ProView - Simulation software Tools are sold in the condition, scope, and with accessories as they are currently in stock. Note regarding window cutouts, tool drawings, and tool system listings: Engelfried GmbH does not guarantee that the tools actually available correspond to the systems listed and drawn. (Technical specifications according to the manufacturer - without guarantee!)

Condition: used, Year of construction: 2011, Length 5000 mm Width 100 mm Height 2800 mm Year 2011 0 Range + Heine Conveyor Technology with Reiter electrostatic airless spray technology. Fully automatic industrial painting and coating line for wooden windows, window frames, doors, and wooden elements for sale on behalf of a client. Viewing available. ----- ----- Technical Manufacturer’s Description (Summary): Item 1 Conveyor System: Power + Free circular conveyor, frequency-controlled drives, buffers, stop stations, crossbeams, steel structure according to layout. Item 2: Flood Coating System: flowcomat II-P for priming/pretreatment. Item 3: Spraying Technology: Reiter MAE 7-059 electrostatic airless spray systems with automatic spray nozzles. Item 4: Lifting Technology: MH2T mechanical lifting devices, lifting range approx. 3,200 mm. Item 5 Material Supply: High-pressure paint supply, insulated material supply, paint changeover, ring line, flushing agent supply. Item 6 Control System: Siemens S7-300 for conveyor technology as well as Reiter control system with workpiece recognition and high-voltage power supply. Item 7 Documentation (available separately): Range + Heine order confirmation, layout plan, Reiter order confirmation, and technical descriptions available. ----- Key Technical Specifications: Workpieces: Wooden windows, window frames, doors Workpiece length: up to approx. 5,000 mm Workpiece height: up to approx. 2,800 mm Capacity: approx. 60 window units per shift Coating systems: water-based systems / low-VOC Control system: Siemens S7-300 Electrostatic: 100 kV / 1 mA ----- ----- Price of the above machine available upon request! ----- Price is ex-location. Dismantling, decommissioning, packaging, loading, and all transportation etc. are the sole responsibility of the customer and are not included in the sale or provided by the seller. Ndedpfx Afey Ty E Hjuob Further technical data and information in the attached PDF! ----- (Technical specifications according to the manufacturer—not guaranteed!) All prices listed are net, plus applicable VAT.

Condition: used, Year of construction: 2010, max. workpiece length 4500,6000 mm profile spindle 4 Stück main drive 30 kW Weinig Conturex C226 Machining Center ----- For sale on behalf of a client; includes software (Klaes) and tooling (Oertli) for IV68/IV78/IV92 and Wood/Alu 68–92 systems. Machine still is electrically connected. Technical specifications and window cross-sections available upon request! ----- Price of the above-mentioned machine available upon request! Ndodpfxozqvnio Afusb ----- Dismantling and reinstallation available upon request! (Technical specifications provided by the manufacturer – subject to change/no liability assumed!) All prices are net, plus statutory VAT.

Condition: used, Tenoning spindle 2 Stk. Number of milling agregates 5 St. Spindle diameter 50 mm Control Weinig, PC-Nexus Weinig Unicontrol 10 NC Window System — Optional: Extensive Tooling Set ----- Optionally available (at an additional cost): IV 68 Wood, Wood/Aluminum IV 78 Wood, Wood/Aluminum IV 68 Entrance Doors Manufacturer's Technical Description: ----- Item 1: Weinig Unicontrol 10 NC Window System ----- Cross-cut Saw ----- with laser alignment light; motor power: 3 kW; spindle diameter: 40 mm; spindle speed: electronically variable (with brake) from 3,000 to 6,000 rpm. Max. tool cutting circle: 400 mm Axial adjustment: 150 mm via NC axis Radial adjustment: pneumatic, to 8 positions for top edge rounding Horizontal bottom rounding unit ----- Axial adjustment travel: mechanically coupled with cut-off saw 1st Tenoning and Slotting Spindle ----- Motor power (with brake): 15 kW Spindle diameter: 50 mm Spindle speed: 2,925 rpm Max. tool cutting circle: 400 mm Tool clamping length: 640 mm Axial adjustment travel: NC axis Home position (below table): 5–10 mm Radial adjustment travel: fixed 2nd Tenoning and Slotting Spindle ----- Motor power (with brake): 11 kW Spindle diameter: 50 mm Spindle speed: 2,925 rpm Max. tool cutting circle: 400 mm Tool clamping length: 320 mm Axial adjustment travel: NC axis Radial adjustment travel: NC axis Home position (below table): 5–10 mm 1st Profiling Spindle (Climb and Conventional Milling) ----- Motor power (with brake): 11 kW Spindle diameter: 50 mm Spindle speed: 6,000 rpm Tool cutting circle: 140 mm Max. tool diameter: 232 mm Tool clamping length: 400 mm (with outboard bearing) Axial adjustment travel: 350 mm (NC axis) Radial adjustment travel: NC axis Home position (below table): 5–10 mm 2nd Profiling Spindle ----- Motor power: 11 kW Spindle diameter: 50 mm Spindle speed: 6,000 rpm Tool cutting circle: 140 mm Max. tool diameter: 232 mm Tool clamping length: 400 mm (with outboard bearing) Axial adjustment travel: 350 mm (NC axis) Radial adjustment travel: NC axis Home position (below table): 5–10 mm Horizontal Profiling Unit (Top) ----- Motor power (with brake): 3.0 kW Spindle diameter: 40 mm Clamping length: 40 mm Spindle speed: 5,850 rpm Max. tool cutting circle: 130 mm Nsdpfxszawizo Afusdb Pneumatic adjustment: 8 positions (axial and radial) 3rd Profiling Spindle ----- Motor power: 11 kW Spindle diameter: 50 mm Spindle speed: 6,000 rpm Tool cutting circle: 140 mm Max. tool diameter: 232 mm Tool clamping length: 400 mm (with outboard bearing) Axial adjustment travel: 350 mm (NC axis) Radial adjustment travel: NC axis Home position (below table): 5–10 mm Vertical Profiling Unit (Right, at Machine End) ----- Motor power (with brake): 3.0 kW Spindle diameter: 40 mm Clamping length: 160 ...

Condition: used, Year of construction: 2020, max. workpiece length 3740 mm profile spindle 1 Stück main drive 15 kW Control CNC Felder Format4 Type Profit H500S 16.38 CNC Machining Center to be sold on behalf of our customer ----- Ndsdeyq Sztepfx Afueb - From a wood window manufacturing company. - Machine still connected and ready for demonstration - Without machining tools Technical description (summary, full text see PDF): ----- Working dimensions: X = 3,740 mm Y = 1,570 mm Z = 350 mm clearance height (from console level), depending on clamping system, see layout. Travel: X = 4,930 mm Y = 1,925 mm Z = 500 mm Axis positioning speed: X = 80 m/min Y = 80 m/min Z1 = 30 m/min Z2 = 20 m/min - 5-axis milling spindle: 15 kW HSK F63 with liquid cooling, 1,000 - 24,000 rpm - Additional C-axis locking - Drilling head DH 18 6H1S: Vertical drilling unit with 12 spindles (7 spindles in the X direction, 5 spindles in the Y direction, grooving saw in the X direction) Horizontal drilling unit with 6 spindles, 4 spindles in the X direction and 2 spindles in the Y direction. 1 groove saw in the X direction, max. diameter 120 mm - Tool changer with 24 tool positions on the right side of the machine stand max. workpiece diameter 240 mm max. tool height 370 mm - Tool changer for circular saw blade mounted on the boom/tool changer max. saw blade diameter 350 mm - Tool changer on the left side of the machine stand with 10 tool positions. Max. workpiece diameter 180 mm Max. tool length 230/300 mm Collet spacing 110 mm - 24-position tool changer mounted on the boom, moving in the X-direction Max. workpiece diameter 240 mm Max. tool height 370 mm - Moving pick-up area for chip deflector plate - 6 workpiece supports with s-motion position control - 2 machining areas for pendulum machining - Vacuum pump 90 m³/h - Chip conveyor belt - Line laser for curved machining - Includes all existing solid wood clamps and vacuum suction cups - Automatic central lubrication - CE safety device - "WoodFLash" software Lamello Clamex P Macro Notching Macro software - "Greenline package" for reduced energy consumption ----- Price of the above machine on Inquiry! ----- NOTE VIDEO: Not an original video. The video is from the machine manufacturer and shows a machine of this type. Option: New Oppold tool set for H500. The customer reused the existing tooling—previously employed on this H500—for their new machine. A brand-new tool set, matching the programming already established on the machine, costs €50,000. -Windows Timber windows IV 68, 78, and 88 (inward-opening), with stepped rebate on sides and top. 20 mm glazing rebate; frame and sash profiles with 20° slope For loose and integral glazing beads Renovation-style timber windows IV 68, 78, and 88 (inward-opening), without rain rail, with stepped rebate on sides, top, and bottom. 20 mm glazing rebate; frame and sash profiles with 15° slope Attached drip rail Timber-aluminum windows (System provider: Gutmann Mira, sloped rebate system) HA IV 68, 78, and 88, inward-opening; 2 sash variants: square and sloped, Stepped rebate at bottom, sides, and top -Entrance doors Timber entrance doors (IV 68, 78, and 88) with single rebate in frame a...

Condition: used, Tenoning spindle 1 St. Number of milling agregates 5 St. Spindle diameter 50 mm Control Weinig PC-Nexus Weinig Unicontrol 11 Window System with Extensive Tooling ----- Optionally available (at additional cost): - Weinig Univar 6 Rebating Machine (Price upon request!) - Götzinger PowerDrill Drilling and Milling Center for Windows and Doors (Price upon request) Manufacturer's Technical Description: ----- Item 1: Weinig Unicontrol 11 Window System ----- Includes existing tooling sets: - IV 67 (Wood and Wood-Aluminum) - IV 77 (Wood and Wood-Aluminum) - IV 90 (Wood) Cross-cut Saw ----- With laser alignment light; motor power: 3 kW; spindle diameter: 40 mm; electronically variable spindle speed with brake: 3,000–6,000 rpm. Max. tool cutting circle: 400 mm Axial adjustment: 150 mm via NC axis Radial adjustment: pneumatic, to 8 positions for top edge rounding Horizontal Bottom Rounding Unit ----- Motor with brake: 1.5 kW; Spindle diameter: 20 mm; Clamping length: 25 mm Spindle speed: 9,000 rpm Max. tool cutting circle: 130 mm Axial adjustment travel: mechanically coupled with cut-off saw Radial adjustment travel: pneumatically controlled Tenoning and Slotting Spindle ----- With hydraulically clamped outboard bearing Motor power with brake: 15 kW Spindle diameter: 50 mm Spindle speed: 2,800 rpm Max. tool cutting circle: 400 mm Tool clamping length: 640 mm Axial adjustment travel: NC axis Home position below table: 5–10 mm Radial adjustment travel: fixed 1st Profiling Spindle (Climb and Conventional Milling) ----- Motor power with brake: 11 kW Spindle diameter: 50 mm Spindle speed: 6,000 rpm Min. tool cutting circle: 140 mm; Max. tool cutting circle: 232 mm Tool clamping length: 400 mm (with outboard bearing) Axial adjustment travel: 350 mm (NC axis) Radial adjustment travel: NC axis Home position below table: 5–10 mm 2 feed rollers opposite the spindle; axial adjustment pneumatically controlled (8 positions) Horizontal Top Profiling Unit ----- Motor power with brake: 3.7 kW Spindle diameter: 40 mm Clamping length: 40 mm Spindle speed: 9,000 rpm Max. tool cutting circle: 130 mm Adjustment: pneumatic, to 8 positions (axial and...) radial 2. Profile Spindle Nedpfsy T R Tuex Afujdb ----- Motor power: 11 kW Spindle diameter: 50 mm Spindle speed: 6,000 rpm Tool cutting circle: min. 140 mm, max. 232 mm Tool clamping length: 400 mm (with outboard bearing) Axial adjustment travel: 350 mm (NC axis) Radial adjustment travel: NC axis Home position (below table): 5–10 mm Indexed guide fence with muntin support strip 2 feed rollers (opposite the spindle); axially pneumatically controlled (8 positions) Vertical Profile Milling Unit (Right-hand side, at machine end) ----- Motor power (with brake): 3.7 kW Spindle diameter: 40 mm Clamping length: 160 mm Spindle speed: 5,850 rpm Tool cutting circle: min. 112 mm, max. 210 mm Adjustment: Pneumatic (8 positions—axial a...

Condition: used, Year of construction: 2009, max. workpiece length 4500 mm profile spindle 1 Stück main drive 20 kW Control Siemens Weinig Conturex 2 C 114 ----- Working width: 40-260 mm Working height: 25-110 mm 2 x PowerGrip clamp tables, 2 x 2280 mm ----- Workpiece length 200 - 4,500 mm Workpieces over 2,700 mm in length are machined using a repositioning cycle. Main spindle 1: ----- Motor with brake 20 kW HSK 63F Electronically adjustable speed 2,000-18,000 rpm Maximum tool length from flat surface HSK 63 F: 290 mm With C-axis Tool magazine: ----- Number of pockets: 30 mm Pitch between pockets: 100 mm Nsdpfxswunwye Afusdb Permanently installed multi-spindle drilling head ----- For horizontal and vertical drilling and milling work without tool changes ----- Price ex-site Prices for disassembly and loading onto customer trucks Transport within Germany and abroad as well as reassembly Commissioning and, if required, new profiles are available upon request! Used tools included (drawings available upon request): ----- Wood: IV 68, 78, 88, opening inside and out, with hinged weatherboard Wood-aluminum: IV 68/68, 78/78, 87/68, 97/78 Lift-and-slide doors IV 68 and 78 Front doors IV 68 and 78 Pivot windows Corner connection: counter/dowel Technical specifications according to the manufacturer - no guarantee! Detailed technical description available upon request!

Condition: used, Year of construction: 1999, Tenoning spindle 1 St. Number of milling agregates 4 St. Spindle diameter 50 mm Control Weinig PC-Nexus Weinig Unicontrol 6 with NC spindles ----- Machine available for inspection while still in operation until September 2026 Summary of technical data (please inquire about any additional accessories included) Item 1: Cross-cut saw ----- > Electronic cross-cut saw, horizontally continuously adjustable > Number of tools: 1 unit > Spindle speed: 2,800 rpm > Spindle diameter: 40 mm > Max. tool diameter: 400 mm > Motor power: 3.0 kW > Laser alignment light for identifying the cut position > NC length stop mounted on the slotting table included; positioning of the cross-cut saw integrated into the control system. > Length 3500 mm Item 2: Tenoning and slotting spindle ----- > Number of tools: variable, infinitely adjustable via NC axis > Tool clamping length: 320 mm > Vertical spindle stroke: variable, infinitely adjustable 254 mm via NC axis > Spindle speed: 3500 rpm > Spindle diameter: 50 mm > Max. tool diameter: 320 mm > Motor power: 11 kW Item 3: 1st profiling spindle (climb-cut and conventional-cut capable) ----- > Position: vertical right > Number of tools: 1 pc. > Tool clamping length: 120 mm > Spindle speed: 6000 rpm > Spindle diameter: 50 mm > Max. tool cutting circle: 232 mm > Motor power: 7.5 kW Item 4: 2nd profiling spindle ----- > Position: vertical right > Number of tools: variable, infinitely adjustable via NC axis > Tool clamping length: 320 mm > Vertical spindle stroke: variable, infinitely adjustable 254 mm via NC axis > Spindle speed: 6000 rpm > Spindle diameter: 50 mm > Max. tool cutting circle: 232 mm > Motor power: 11 kW Item 5: Horizontal profile milling unit (top) ----- > Clamping length: 40 mm > Spindle diameter: 40 mm > Motor power: 3.0 kW > Speed: 5,850 rpm > Max. tool cutting circle: 130 mm > Axial adjustment range: 2 positions > Radial adjustment range: 2 positions Item 6: 3. Profiling spindle (hardware groove spindle) ----- > Position: vertical, right > Tool clamping length: 160 mm > Axial adjustment range: 3 positions > Radial adjustment range: 2 positions > Spindle speed: 5,850 rpm > Spindle diameter: 40 mm > Max. tool cutting circle: 210 mm > Motor power: 3.0 kW Additional features ----- > Network-ready (online capability) > Rebating unit for tear-free rebating > Double-part processing package > Return conveyor system for one-man operation: slat conveyor > Screen-based control system Nodjz Euxaspfx Afujdb > Angled window processing unit > Electronic angle display for angled windows > Industrial PC, PC control/NEXUS > Excluding machining tools Inclusive: 1 tool set of Stehle IV68 Wood tools also included ----- Price of the above-mentioned machine available on request! ----- Optional extra: EUR 6,500.00 Note regarding used tools: We currently have used "Gold" series tools in stock (Stock No. #2790) Window tools (Gold series) for IV78 Wood and IV78 Wood/Aluminum Previously used on a Weinig Unicontrol 10; a jointing cutter is additionally required for use on a Unicontrol 6. Tool set for fixed-stroke or CNC spindle machines (80 mm and 95 mm stroke), (Tool set prepared for I...

Condition: used, Tenoning spindle 1 0 Number of milling agregates 2 St. Spindle diameter 40,50 mm Item 1: Okoma UF1 S Angle Combination Unit and Item 2: UF2 EG Rebating Machine, incl. Item 3: Tooling Set for IV78 Timber Windows, IV78 Timber Entrance Doors, and IV78 Timber-Aluminum Windows (Gutmann system) with straight and angled sash profiles For sale on behalf of a customer ----- Manufacturer's Technical Description: Item 1: Okoma UF 1 S Tenoning and Profiling Machine / Rebating Machine ----- Compact, heavy-duty automatic window machine featuring a cast-iron construction, consisting of: Top-mounted cross-cut saw with 12-position turret stop system; Positive-guided saw guard for accident prevention Tenoning spindle: 40 mm diameter x 252 mm length; 2-step stroke mechanism for 3 tool positions (stroke height: 83 mm); Motor: 7.5 kW Sliding table: Adjustable on both sides from 0 to 60 degrees Automatic feed system with various infinitely variable speed settings; dual pneumatic clamping system; Length stop (LAS) with 3-position system, 2300 mm capacity Automatic transfer unit to the profiling section Profiling spindle: 40 mm diameter x 252 mm length Pneumatic stroke: 112 mm (adjustable) for 2 tool positions Motor: 7.5 kW; Spindle horizontally adjustable relative to the tool cutting edge; Adjustable front milling fence jaw Glazing bead saw with 3 kW motor and 4-position turret head adjustment; Heavy-duty articulated feed system, infinitely variable from 0 to 25 m/min. adjustable, Roller groups pivotable inward and outward Counter-stop with 5-position turret head Frame milling unit ----- Item 2: OKOMA Automatic Rebating Machine, Model UF 2 EG ----- Power Specifications: - Operating voltage: 3-phase, 380 V, 50 Hz - Compressed air: Air requirement: 13 NL/min; Operating pressure: 8 bar Conditioned air: According to Pneurop 6611 1. Profiling Spindle 1: - Spindle arrangement: Right - Power: 11 kW - Speed: 7000 rpm - Direction of rotation: Climb and conventional milling - Spindle diameter: 50 mm - Usable length: 272 mm - Max. tool diameter: 230 mm - Vertical (U-axis) movement of the profiling spindle - Vertical positioning: Actuation: Pneumatic cylinder; 90 mm stroke for 3 tool positions Position sensor: Limit switches - Horizontal positioning: Ndjdpsy T R Tbjfx Afueb Actuation: Pneumatic cylinder (forward/backward) Position sensor: Limit switches - Automatic plunge mechanism: Plunge speed adjustable to ensure tear-out-free rebating - Safety and dust extraction hood with 140 mm diameter connection port 2. Profiling Spindle 2: - Spindle arrangement: Right - Power: 11 kW - Speed: 7000 rpm - Direction of rotation: Counter-rotation - Spindle diameter: 50 mm - Usable length: 272 mm - Max. tool diameter: 230 mm - U-axis movement of the profiling spindle - Vertical positioning: Drive: Pneumatic cylinder; 90 mm stroke for 3 tool positions Position sensor: Limit switches - Horizontal positioning: Drive: Pneumatic cylinder (forward/backward) Position sensor: Limit switches - Safety and dust extraction hood with connection port (140 mm diameter) 3. Hardware Routing Unit EG: - Spindle arrangement: Right - Drive: 3 kW three-phase motor - Speed: 6000 rpm - Spindle diameter: 30 mm - Usable length: 47 mm - Vertical positioning: None - Horizontal p...

Condition: used, Year of construction: 2011, max. workpiece length 4100 mm profile spindle 8 Stück main drive 16 kW Control SIEMENS Working Process Wooden Window Production Line Ndedpfezughuox Afusb ----- Sale on behalf of the client; ex-site. System can be viewed while still in operation! System comprising: Item 1: Infeed conveyor following the planer (planer NOT included, can be bougth additonally as option)) Item 2: Working Process Sapiens, Year of Mfg. 2011 (end-grain milling and drilling) - Spindle 1: 10 kW, HSK-E63, A/C-axis - Spindle 2: 10 kW, HSK-E63, A/C-axis - Spindle 3: 16 kW, HSK-E63, C-axis - Spindle 4: 16 kW, HSK-E63, C-axis Item 3: Transport system to LOGOS SCH Item 4: Working Process LOGOS SCH, Year of Mfg. 2008 (end-grain and longitudinal milling and drilling) - Spindle 1: 16 kW, HSK-E63 - Spindle 2: 16 kW, HSK-E63, C-axis - Spindle 3: 10 kW, HSK-E63, C-axis, A-axis - Spindle 4: 3 kW, fixed configuration, for 2 tools (e.g., for weather-seal grooves, wood-aluminum clip slots, etc.) - Central pick-up tool changer with 95 tool positions Item 5: Outfeed conveyor Detailed descriptions and layout available upon request! (Technical specifications according to manufacturer – subject to change/without guarantee!)

Condition: new, max. workpiece length 4500,6000 mm profile spindle 3 Stück main drive 24 kW Control Siemens 840d Working Process Logos Life Evo XS 2345 ----- Vollautomatisches CNC-Fensterfertigungsanlage mit automatischer Be- und Entladung. 2 Portale mit 3 Frässpindeln mit 4- und 5-Achstechnologie CNC-gesteuerter Manipulator für Werkstückpositionierung mit 16 Stück Doppelzangen 8 Stück komplett unabhängige Werkstückspanner für höchste Felxibilität und Produktivität 128 Werkzeugplätze Njdpfxoyrtyyo Afuedb NEU: Working Process baut nun auch 1-spindlige Anlagen mit bewährter Technologie für kleinere Betriebe! Nebenstehend finde Sie aktuelle Videos dieser Baureihe.

Condition: new, max. workpiece length 5150 mm profile spindle 1 Stück main drive 16 kW Control Beckhoff CNC Number of axles 5 St. CNC machining center Masterwood Project 385 WL, NEUMASCHINE The all-rounder for Windows, round arches and doors interior Post and beam 5-axis machining of all kinds Detailed description in the adjacent PDF file! Nodpsd Ih Htjfx Afujdb HIGHLIGHTS: - Working range: X = 5150 mm; Y = 1500 mm; Z = 200 mm - 1 pc. 5-axis high-performance spindle, 16 kW, double bearing with HSK 63 F recording - fixed drill head with 19 spindles with 7 individually retrievable vertical spindles X-direction with 6 individually retrievable vertical spindles Y-direction with 2 double horizontal spindles X-direction and 1 double horizontal boring spindle in the Y direction Saw unit integrated in drill head - Carousel tool changer with 22 places and 102 mm grid spacing - Carousel tool changer with 16 places and 102 mm grid spacing - linear 4-fold tool magazine - Special clamps for straight window and door parts - special clamps for round window and door elements - 24 pcs. Vacuum clamps for internal installation - Vacuum pump - Chip conveyor belt - extensive design software for interior design, panel processing as well as f. Windows and doors: Masterwork: 2D-Wop for standard application panel processing / interior fitting with Additional function Lamello connection Master 3D Level 2: for more complex edits, optionally also expandable for 5-axis fully interpolating MasterWindow: Integrated window and door design software i.e. Machine does not have to (but of course) with external industry software be controlled. VIDEO shows production of 4 sash parts in one clamping Complete machining including glazing bead production. Corner joint hybrid. Of course, all common corner joints on the machine producible. OTHER OPTIONS ON REQUEST! We are also happy to offer you suitable tools for the machine. (Techn.According to the manufacturer - without guarantee!)

Condition: new, max. workpiece length 3200,5100 mm profile spindle 1 Stück main drive 12 kW Control Beckhoff CNC Number of axles 5 St. Masterwood Project 385 CNC-Bearbeitungszentrum ----- 5-Achs CNC-Bearbeitungszentrum in Portalbauweise zum Einsatz für Rundbogenfenster, Türen, Pfosten-Riegel, Innenausbau, Treppen Kurze Zusammenfassung: ----- Arbeitsbereich: X = 3200 mm (Optional 5100 mm) ; Y = 1500 mm; Z = 200 mm 1 Stk. 5-Achs-Hochleistungsspindel, 12 kW, mit HSK 63 F Aufnahme 1 Stk. fest installierter Bohrkopf mit 19 Spindeln mit 7 einzeln abrufbaren Vertikalbohrspindeln X-Richtung mit 6 einzeln abrufbaren Vertikalbohrspindeln Y-Richtung mit 2 doppelten Horizontalbohrspindeln X-Richtung und 1 doppelte Horizontalbohrspindel in Y-Richtung Sägeaggregat in Bohrkopf integriert 27 Werkzeugwechselplätze: Karussellwerkzeugwechsler mit 22 Plätzen und 102 mm Rasterabstand lineares 5-fach Werkzeugmagazin für große WKZ-Durchmesser Konsolentisch mit 6 Traversen Werkstückanhebevorrichtung 6 Stk. spezielle Spanner für runde Fenster- und Türenelemente 24 Stk. Vakuummspanner für Platten und Innenausbau 1 Stk. Vakuumpumpe 100m3/h 1 Stk. Spänetransportband 1 Stk. Fernbedienung Konstruktions-Software Masterwork: 2D-Wop für Standardanwendung Plattenbearbeitung/Innenausbau, Rundbogen, Türen Master 3D Stufe 2: für komplexere Bearbeitungen, optional auch erweiterbar für 5-Achs voll interpolierend Fracht und Montage innerhalb Deutschland Technik und Dienstleistungen gemäß beiliegender ausführliche Beschreibung ----- Nodsd N Rt Tepfx Afusdb Gesamtpreis in dieser Ausführung: auf Anfrage! ----- Optionen mit Mehrpreisen: ----- Arbeitslänge 5.100 mm anstelle 3.200 mm inklusive Erhöhung Konsolenanzahl und Spannmittel Mehrpreis: 7.500,00 Euro zzgl. MwSt. Zusätzlicher Karussellwerkzeugwechsler mit 16 Plätzen und 102 mm Rasterabstand Mehrpreis: 6.500,00 Euro zzgl. MwSt. Ausführliche Beschreibung siehe PDF anbei. Mehr Optionen auf Anfrage! (technische Angaben laut Hersteller- ohne Gewähr!)

Condition: new, Manual hand unit Ja J/N Automatic for frames Ja J/N Njdpfx Ajyrtymofuodb

Condition: new, Manual hand unit , J/N Automatic for single pieces Ja J/N Automatic for frames Ja J/N Ndodpfxoytx T Us Afujb

Condition: new, Finiture Paint Line for Windows and Doors ----- Short description: Item 1: 1x Double-rail overhead conveyor Item 2: 1x Traverse rotation unit with one coupling Item 3: 1x "Superjet" flood coating system Item 4: 1x High-pressure humidifier Item 5: 1x Wastewater separation system Optional: Flood channel or dipping tank (5–6 basins) For detailed technical description and layout, please see the PDF attachment! ----- Price of the above-mentioned paint line on request! ----- (Technical specifications according to manufacturer – no guarantee!) Njdpfx Afey D A Hheusdb All prices are net plus statutory VAT.

Condition: new, max. workpiece length 3200/5100 mm profile spindle 1 Stück main drive 12 kW Control Beckhoff CNC Ndedpfxod Rhd Re Afuob Number of axles 5 St.

Condition: new, Year of construction: 2026, Tenoning spindle 1 0 Number of milling agregates 3 St. Spindle diameter HSK, 50 mm mm Njdpfxoy T R S Rs Afuodb control Maestro active windoor

Condition: reconditioned (used), Tenoning spindle 1 St Number of milling agregates 4 St. Spindle diameter 50 mm Control Weinig, PC-Nexus Weinig Unicontrol 10 CNC - Spindles radially and axially CNC-controlled ----- The machine was factory overhauled by Weinig in 2024. The control panel was also upgraded to a Siemens S 7 677 C, with a new membrane panel "Touch". With the following machining units: Crosscut saw ----- with laser alignment light, motor power 3 kW, spindle diameter 40 mm, spindle speed 3,000 Axially adjustable via NC axis Radial pneumatic adjustment to 8 positions for edge rounding from above Unit from below for edge rounding ----- Axially adjustable with crosscut saw Ndjdpfx Ajxpi Dujfusb Tenon and slotting spindle ----- Motor power 15 kW Spindle diameter 50 mm Spindle speed 2,925 rpm Tool travel radius min. 380, max. 400 mm Tool clamping length 640 mm Axially adjustable CNC axis Axially adjustable travel 580 mm Adjustment speed 100 mm/sec. 1. Profile spindle (up- and down-rotation) ----- Motor power 11 kW Spindle diameter 50 mm Spindle speed 6,000 rpm Tool clamping length 400 mm with counter bearing Axially and radially adjustable via CNC axis 2. Profile spindle ----- Motor power 11 kW Spindle diameter 50 mm Spindle speed 6,000 rpm Tool clamping length 400 mm with counter bearing Axially and radially adjustable via CNC axis Profile milling unit horizontally mounted on top ----- Motor power 3 kW Spindle diameter 40 mm Spindle speed 9,000 rpm Pneumatically adjustable to 8 axial and radial positions Profile milling unit vertically mounted on the right side Machine end ----- Motor power 3 kW Spindle diameter 40 mm Spindle speed 5,850 rpm Pneumatic adjustment to 8 axial and radial positions Additional accessories ----- CNC-controlled length stop, mounted on the slotting table for lengths up to 3,500 mm, including a positioned cross-cutting saw integrated into the control system. Studio window device, pivots 60° on both sides Double-part package with automatic separation and transfer Synchronization device with automatic window rebating Rebating carriage for rebating small sash widths Air conditioning unit in the control cabinet PC control NEXUS Automatic turning system Slat conveyor, including conveyor belt for returning the workpieces to the operator (Technical specifications according to the manufacturer - without guarantee).

Condition: reconditioned (used), Tenoning spindle 1 St. Number of milling agregates 4 St. Spindle diameter 50 mm control Weinig, PC-Nexus Weinig Unicontrol 6 with NC spindles ----- Machine will be cleaned and completely checked before delivery Technical data summary (please enquire about any additional accessories included) Item 1: Cross-cut saw ----- > Electronic cross-cut saw, infinitely adjustable horizontally > Number of tools: 1 piece > Spindle speed: 2,800 rpm > Spindle diameter: 40 mm > Max. tool diameter: 400 mm > Motor power: 3.0 kW > Laser aiming light for detecting the saw section > NC length stop, mounted on slot table included Positioning of the cross-cut saw integrated in the control system. > Length 3500 mm Item 2: tenoning spindle ----- > Number of tools: variable, infinitely variable adjustment NC axis > Tool clamping length: 320 mm > Vertical spindle stroke: variable, infinitely variable adjustment 254 mm NC axis > Spindle speed: 3500 rpm > Spindle diameter: 50 mm > Max. tool diameter: 320 mm > Motor power: 11 kW Item 3: 1st profiling spindle (synchronous spindle and counter-rotation) > Position: vertical right > Number of tools: 1 pc. > Tool clamping length: 120 mm > Spindle speed: 6000 rpm > Spindle diameter: 50 mm > Max. tool flight circle: 232 mm > Motor power: 7.5 kW Item 4: 2nd profiling spindle ----- > Position: vertical right > Number of tools: variable, infinitely variable adjustment NC axis > Tool clamping length: 320 mm > Vertical spindle stroke: variable, infinitely variable adjustment 254 mm NC axis > Spindle speed: 6000 rpm > Spindle diameter: 50 mm > Tool flight circle max.: 232 mm > Motor power: 11 kW 2 feed rollers opposite the spindle, axially pneumatically controlled, 2 positions Ndodpfovu Hfqsx Afusb Rung guide consisting of: Guide ruler in the stop (area of ??synchronous spindle), Rung support bar from above in the area of ??profile milling unit vertical right and profiling spindle. Pos. 5: Profile milling unit horizontal top ----- > Clamping length: 40 mm > Spindle diameter: 40 mm > Motor power: 3.0 kW > Speed ??5,850 rpm > Tool flight circle max. 130 mm > Axial adjustment range 30 mm, 8 positions using pneumatic turret > Radial adjustment range 125 mm, 8 positions using pneumatic turret Pos. 6: 3rd profiling spindle (fitting spindle) ----- > Position: vertical right > Tool clamping length: 160 mm > Axial adjustment range 115 mm, 8 positions using pneumatic turret > Radial adjustment range 100 mm, 8 positions using pneumatic turret > Spindle speed: 5,850 rpm > Spindle diameter: 40 mm > Max. tool flight circle: 210 mm > Motor power: 3.0 kW Other features ----- > online-capable > rebating device for tear-free rebating > double parts package > return conveyor for 1-man operation: tilting belt > screen control > inclined window device > electronic angle display for inclined windows > industrial PC, PC control/NEXUS > Weinig type production program > without processing tools No original images available yet. Images show identical machines from our archive. ----- Price of the above-mentioned machine upon request! ----- Optional with additional charge: EUR 6.500,00 Note on used tools: We currently have used...

Condition: excellent (used), Tenoning spindle 1 St. Number of milling agregates 4 St. Spindle diameter 40/50 mm Weinig Unicontrol 6 ----- Machine will be checked in our factory before delivery! Technical Data Summary (Please inquire about any additional accessories included) Item 1: Cut-off saw Ndedpfoxtvgkex Afujb ----- > Number of tools: 1 pc. > Spindle speed: 2,800 rpm > Spindle diameter: 40 mm > Maximum tool diameter: 400 mm > Motor power: 3.0 kW > Laser guide light for identifying the saw cut CNC-controlled length stop ----- > Length: 3,600 mm > Electronic length stop including positioned cut-off saw Item 2: Tenoning spindle ----- > Number of tools: 3 (stroke 2 x 100 mm) or 4 (Stroke 3 x 80 mm) > Tool clamping length: 320 mm > Pneumatic vertical spindle stroke: 240 mm for wood thicknesses 68 - 92 mm > Spindle speed: 3000 rpm > Maximum tool swing diameter: 320 mm > Spindle diameter: 50 mm > Maximum tool diameter: 360 mm > Motor power: 11 kW Item 3: 1. Profiling spindle (co-rotation and conventional) ----- > Position: vertical right > Number of tools: 1 pc. > Tool clamping length: 120 mm > Spindle speed: 6000 rpm > Spindle diameter: 50 mm > Maximum tool swing diameter: 232 mm > Motor power: 7.5 kW Item 4: 2. Profiling spindle ----- > Position: Vertical right > Number of tools: 3 (stroke 2 x 100 mm) or 4 (stroke 3 x 80 mm) > Tool clamping length: 320 mm > Pneumatic vertical spindle stroke: 240 mm for wood thicknesses 68 - 92 mm > Spindle speed: 6000 rpm > Spindle diameter: 50 mm > Maximum tool swing diameter: 232 mm > Motor power: 11 kW 2 axially indexed feed rollers opposite the profiling spindle, for the production of narrow, short parts (e.g., glass-dividing muntins) Munch guide consisting of: Munch support strip from above in the area of ??the vertical right-han d profile milling unit and profiling spindle. Item 5: Horizontal top profile milling unit ----- > Clamping length: 40 mm > Spindle diameter: 40 mm > Motor power: 3.0 kW > Spindle speed: 5,850 rpm > Maximum tool swing diameter: 130 mm > Axial travel: 52 mm, indexed in 2 positions > Radial travel: 125 mm, indexed in 2 positions Item 6: 3rd profiling spindle (fitting spindle) ----- > Position: Vertical right > Tool clamping length: 160 mm > Axial travel: 90 mm, indexed in 3 positions > Radial travel: 100 mm, indexed in 2 positions > Spindle speed: 5,850 rpm > Spindle diameter: 40 mm > Maximum tool swing diameter: 210 mm > Motor power: 3.0 kW Further features ----- > Electric feed height adjustment including mechanical digital display and manual feed bar clamping > Rebating device for tear-out-free rebating > Double part package > Return conveyor for 1-person operation: swivel conveyor > Screen control > Angled window device > Electronic angle display for angled windows > Industrial PC with Windows PC control/NEXUS Extraction nozzle diameter: ----- Crosscut saw 80 mm Tenoning spindle 140 mm Profile spindle 1 140 mm Profile spindle 2 140 mm Grooving device from above 80 mm Hardware spindle 120 mm -----...

Condition: not inspected (used), Year of construction: 2004, Tenoning spindle 2 St. Number of milling agregates 7 St. Spindle diameter 50 mm control Weinig PC-Nexus Weinig Uncontrol 12 with radial and axial CNC spindles and VARIO table ..... The machine has already been professionally dismantled and stored in 73447 Oberkochen Specifications summary (please inquire about any additional accessories included) ..... crosscut saw ..... > Crosscut saw electronically, horizontally infinitely adjustable > Number of tools: 1 pc. > Spindle speed: 3000-6000 rpm > Spindle diameter: 40 mm > Tool diameter max.: 400 mm > Motor power: 3.7 kW > Laser guide light for detecting the sawing section > Axial adjustment path 150 mm NC axis, electronically stepless > Adjustment path, radial, pneumatic, 8 positions, e.g. for edge rounding from above rounding aggregate ..... > Position: horizontally below > Axial adjustment path together with the crosscut saw. electronic length stop ..... > Length 4500mm 1. Tap and Slot Spindle ..... > Number of tools: variable > Motor power: 15 kW > Spindle diameter: 50 mm > Tool clamping length: 640 mm, with counter bearing > Axial adjustment range: 580 mm NC axis, stepless > Spindle speed: 2,800-4,000 rpm > Tool diameter: 380-400mm > Overrun counter, complete clamping length is countered 2. Tap and Slot Spindle ..... > Number of tools: variable > Motor power: 15 kW > Spindle diameter: 50 mm > Tool clamping length: 640 mm, with counter bearing > Axial adjustment range: 580 mm NC axis, stepless > Spindle speed: 2,800-4,000 rpm > Tool diameter: 380-400mm > Overrun counter, complete clamping length is countered transfer tape ..... Included for transferring the parts to longitudinal processing Separation of double parts before entering longitudinal processing. 1. Profiling spindle (synchronous and counter-rotating) ..... > Position: vertical right > Number of tools: variable > Motor power: 11 kW > Spindle diameter: 50 mm > Tool clamping length: 400 mm, with counter bearing > Axial adjustment range 350 mm NC axis, stepless > Radial adjustment range 80 mm NC axis, stepless > Spindle speed: 6000 rpm > Minimum tool flight circle: 140 mm > Tool flight circle max.: 232 mm 2. Profiling spindle ..... > Position: vertical right > Number of tools: variable > Motor power: 11 kW > Spindle diameter: 50 mm > Tool clamping length: 400 mm, with counter bearing > Axial adjustment range 350 mm NC axis, stepless > Radial adjustment range 80 mm NC axis, stepless > Spindle speed: 6000 rpm > Minimum tool flight circle: 140 mm > Tool flight circle max.: 232 mm 3. Profile milling unit (grooving device from above) ..... > Position: horizontally above > Motor power: 3.0 kW > Spindle diameter: 40 mm > Tool clamping length: 40 mm > Axial adjustment range 30 mm NC axis, stepless Njdpoyrtzkjfx Afusdb > Radial adjustment range 125 mm NC axis, stepless > Spindle speed: 9000 rpm > Tool flight circle max.: 130 mm ...
