Condition: good (used), Year of construction: 1995, Centre height: 330 mm Centre distance: 2000 mm Working area: Max. turning diameter over bed cover: 650 mm Max. turning diameter over cross slide: 360 mm Main spindle: Spindle diameter at front bearing: 140 mm Spindle bore: 107 mm Main drive: 58.5 kW 2-speed spindle range: 4 – 750 rpm / 750 – 3060 rpm Feed drive: Rapid traverse X-/Z-axis: 10/10 m/min Turret: Number of tool positions: 12 Driven tool positions: 6 Tool shank holder: VDI 50 mm Dimensions / Weight: Required floor space (L x W x H): approx. 6400 x 2150 x 2000 mm Weight: 9400 kg Accessories / Special features: Dcsdpfsx Sx Htox Aa Eeb • CNC path control GRUNDIG EPL 2 with color monitor • Spindle orientation C-axis • 12-station turret, VDI 50, with 6 driven tools, SAUTER brand • Hydraulic 3-jaw chuck • Hydraulic tailstock • Chip conveyor • Extraction unit, LTA brand • CE-compliant Siegfried Volz Werkzeugmaschinen Rüschebrinkstr. 151-153 DE - 44143 Dortmund - Wambel

Condition: ready for operation (used), Year of construction: 2008, functionality: fully functional, turning length: 550 mm, spindle speed (max.): 4,000 rpm, spindle bore: 50 mm, travel distance X-axis: 190 mm, travel distance Z-axis: 445 mm, rapid traverse X-axis: 20 m/min, rapid traverse Z-axis: 24 m/min, spindle nose: A2-6, Equipment: documentation/manual, rotational speed infinitely variable, This HAAS TL-15HE is exceptionally well-equipped in terms of options and comes with an LNS bar feeder and numerous accessories! This machine is supplied including: - LNS Sprint 555 bar feeder with corresponding accessories and guide tubes - Full C-axis on both spindles - Sub-spindle / tailstock - Driven tooling - Tool setting arm - Workpiece collection bin - Auger system for chip removal - Foot pedal - 7 pcs driven WTO toolholders - 12 pcs static HAAS toolholders - Various 3-jaw chucks with matching jaws and collet fixtures - Various spare wear parts Dsdpex Sx Eiofx Aa Ejcb - Original HAAS documentation.

Condition: ready for operation (used), Year of construction: 2012, Control Unit Brand SIEMENS Model Sinumerik 840D Ergoline Main Drive Number of axis 4 Additional Equipment Coolant pump 6 bar, 201 l/min Chuck rinsing device outside at main spindle Coolant equipment external on turning/milling spindle Hinged type chip conveyor, discharge height 1200 mm Cooling system for spindle motor, turning/milling spindle, and B-axis torque motor Dedpfox Stmnox Aa Ejcb Connection for oil mist extractor Machine prepared for workpiece handling robot WH3 (front loading) Environmental packages for unstable supply and increased ambient temperature This 5-axis DMG MORI Gildemeister CTX 1250 TC was manufactured in 2012, featuring a turning length of 1250 mm and a main spindle speed up to 5000 min⁻¹. It includes a Y-axis travel of 100 mm, B-axis ±110°, and a tool magazine with 24 positions. Ideal for complex machining tasks, it also comes equipped with a Siemens SINUMERIK 840D control system. If you are looking to get high-quality turn-mill capabilities, consider the DMG MORI Gildemeister CTX 1250 TC machine we have for sale. Contact us for more information. Application Types Turning

Condition: ready for operation (used), Year of construction: 2018, Control Unit Brand MAZATROL Model SMOOTH X Main Drive Number of spindles 2 Spindle speed range 1 - 3300 rpm Spindle bore ø112 mm (ø4.41 inches) Number of axis 5 Movement X-Axis Movement 615 mm X-Axis Rapid Traverse 50 m/min Dsdpfx Aaox Stk To Ejcb Y-Axis Movement 260 mm Y-Axis Rapid Traverse 40 m/min Z-Axis Movement 2563 mm Z-Axis Rapid Traverse 40 m/min W-Axis Rapid Traverse 30 m/min Tools Number of index 72 Max weight 12 kg Max tool diameter 90 mm Type of tool holder HSK-A63 (T63) This 5-axis Mazak Integrex i-400S-2500U was manufactured in 2018, featuring Mazatrol SMOOTH X Control and a Hydrafeed MSV110 Barfeed. It offers a maximum machining diameter of ø658 mm and a length of 2,497 mm. Equipped with a milling spindle speed of 12,000 rpm and a tool storage capacity of 72 tools, this turn-mill centre is ideal for complex machining tasks. If you are looking to get high-quality turning and milling capabilities, consider the Mazak Integrex i-400S-2500U machine we have for sale. Contact us for more information. Application Types Turning

Condition: good (used), Year of construction: 2003, For sale is a high-quality CNC lathe from the renowned manufacturer INDEX, model G200. Technical specifications: • Model: INDEX G200 • Suitable for turned parts up to Ø 200 mm • Year of manufacture: 2003 (according to nameplate) • Quantity: 2 available • Equipment: • Includes bar feeder • Includes measuring device The machines come from the production facilities of a German automotive manufacturer and have been regularly and professionally maintained by in-house maintenance staff. Accordingly, the condition is rated as very well maintained. Location: Germany Djdpfxsx Srkfo Aa Escb Collection of the machine is possible in January 2026. Machine demonstrations under power can be arranged at any time. If you are interested or require further information or an inspection appointment, please contact me directly.

Condition: used, Year of construction: 2008, Mazatrol Matrix CAM PC workstation with full-featured 5-axis license (incl. PCI card & PC) Description: A complete, ready-to-use PC workstation with the powerful Mazatrol Matrix CAM software is for sale. The license is perpetual and hardware-bound via a PCI card. The system was used on 5-axis machines (Integrex e-1060 V8/II) and includes rare high-end options. The PC has been recently reinstalled and is fully functional. Ideal for companies with an older Mazak machine park looking for an independent programming solution. Details on license & options: Dcjdpfx Aaex Sq Nms Eeb The following key options are unlocked and active (see photos): - 40 SIMULTANEOUS 5 AXIS (simultaneous 5-axis machining) - 49 TILTED WORKING PLANE - 55 TOOL CENTER POINT CONTROL Additional basic options such as EIA, Smoothing Control, Spiral, etc. (see photo of the options menu) Scope of delivery: - PC system: Windows 7 Pro x86 (32 Bit), Intel i5-3470 3.2 GHz, 4 GB RAM, AMD Radeon HD7570 GPU. - The fully functional computer with installed operating system (Windows 7 Pro_x86) and pre-installed software. - PCI license card: The physical license hardware installed in the PC. - Original packaging: The original packaging of the software as shown. Documentation: Manual, original CDs/media

Condition: reconditioned (used), Year of construction: 2008, functionality: fully functional, turning length: 2,129 mm, turning diameter: 550 mm, spindle motor power: 26 W, spindle speed (min.): 30 rpm, spindle speed (max.): 3,000 rpm, spindle bore: 90 mm, travel distance X-axis: 362 mm, travel distance Z-axis: 2,155 mm, rapid traverse X-axis: 16 m/min, rapid traverse Z-axis: 18 m/min, type of input current: three-phase, total height: 2,305 mm, total length: 5,550 mm, total width: 2,300 mm, overall weight: 9,800 kg, Equipment: documentation/manual, rotational speed infinitely variable, USED ​​DOOSAN 2-Axis lathe with FANUC 21i-TB CNC Djdpfx Aajx Sqwwj Eocb

Condition: excellent (used), Year of construction: 2012, functionality: fully functional, DOOSAN PUMA 3100ULY (2012) CNC LATHE WITH ROTARY TOOLS AND “Y” AXIS – “Z” TRAVEL: 3,000 mm SPECIFICATIONS: - FANUC i Series CNC, 10.4” LCD Color Manual Guide - Swing over bed: 850 mm - Swing over saddle: 670 mm - Maximum turning diameter: 420 mm - Maximum turning length: 3,125 mm - Axis travel: X 210 mm, Y ±60 mm, Z 3,125 mm - Chuck size: 400 mm (*) - Bar capacity: 102 mm - Spindle nose: ASA A2#11 - Main spindle: 2,800 rpm, 22 kW - Turret: 12 stations (indexing time per position: 0.25 sec) - Rotary tool motor: 7.5 kW, 5,000 rpm - C-axis indexing: 0.001 mm - Tailstock travel: 3,135 mm Dcsdpfx Aox Sqkwja Ejb INCLUDED EQUIPMENT: - Samchully MH-212 315 mm hydraulic chuck - C axis: 360° (0.001° increments) - Automatic tool setter - Built-in tailstock - Programmable tailstock - High-pressure pump - Chip conveyor - Mechanical, hydraulic, and electrical preparation for automatic steady rest - SMW AUTOBLOK SLU-X-4-ZS hydraulic steady rest - Complete standard toolholder set for internal and external machining, including 4 rotary holders (2 straight, 2 angular) - Set of manuals (Doosan and Fanuc) (All specifications to be confirmed) CONDITION: Under power, in excellent condition. Ready for inspection. Immediate delivery.

Condition: reconditioned (used), Year of construction: 2018, functionality: fully functional, turning length: 400 mm, turning diameter: 420 mm, spindle motor power: 22 W, spindle speed (min.): 30 rpm, spindle speed (max.): 3,000 rpm, travel distance X-axis: 268 mm, travel distance Z-axis: 488 mm, rapid traverse X-axis: 20 m/min, rapid traverse Z-axis: 24 m/min, type of input current: three-phase, total height: 3,210 mm, total length: 3,600 mm, total width: 1,900 mm, overall weight: 6,000 kg, Equipment: documentation/manual, rotational speed infinitely variable, USED ​​DOOSAN 3-axis CNC vertical lathe with live tools and C-axis Dcodpex Sqafefx Aa Ejb

Condition: like new (used), Year of construction: 2023, operating hours: 3,751 h, functionality: fully functional, turning length: 700 mm, turning diameter: 356 mm, spindle speed (min.): 6,000 rpm, spindle bore: 81 mm, travel distance X-axis: 260 mm, travel distance Y-axis: 100 mm, travel distance Z-axis: 795 mm, DMG MORI NLX2500/700 universal lathe with Y-axis, bar loader and driven tools. Main and counter spindle. Spindle bore diameter: 81 mm. An optional tooling package worth €60,000, which was purchased together with the machine, is available. Djdsx Sp Izopfx Aa Eocb

Condition: used, SAMSUNG SMEC PL-60L Ø1,030 x 3,200 mm / 2016 Model Machining Capacity / Fanuc Oi TD CNC Controller • Swing over bed: Ø 1,030 mm (32 inch hydraulic chuck) • Swing over cross slide: Ø 800 mm • Maximum turning diameter: 530 mm • Maximum machining diameter: Ø 900 mm • Maximum turning length: 3,200 mm (Ø 45~310 mm with hydraulic steady rest) • Maximum chuck machining diameter: 139.5 mm Dsdex Scprepfx Aa Ejcb Axis Travel • X-axis travel: 470 mm • Z-axis travel: 3,270 mm Spindle • Spindle bore: 1,500 mm • Spindle nose size: 21" • Spindle nose type: A2-15 • Spindle through hole diameter: Ø152 mm Turret (Standard) • Number of tool stations: 12 (Standard) • Tool shank size: □32 mm • Boring bar shank size: Ø80 mm Tailstock • Tailstock travel: 3,270 mm • Quill diameter: Ø180 mm • Tailstock taper: MT-6 (built-in) • Tailstock stroke: 150 mm Power & Installation • Power requirement: 65 kVA • Machine dimensions (L × W): 7,400 × 2,760 mm • Machine weight: 22,000 kg

Condition: used, Haas Mini mill 2, year 2010, from Research & Development facility, vices and tooling not included in images. Dedpfox Sauxox Aa Escb

Condition: used, XYZ SMX 2500, Year 2017, from research and development facility, tooling and vices in images not included. Dsdpfjx Saulox Aa Escb

Condition: used, Year of construction: 2013, Mori Seiki NTX2000/1500SZM 5-Axis Mill/Turn with F31iB5 Control, Main Spindle Kitagawa 10”dia Chuck at 4,000rpm, Sub-Spindle Kitagawa 10”dia Chuck, 76 Position ATC, 10 Station Indexing Turret, Spindle Taper Capto C6, SMW SLU 3.2 Hydraulic Steady, High Pressure Coolant, Swarf Conveyor. S/No. NTX20130611 (2013) Dcedpfx Aex R Uc Uea Eob Location: These lots are located in Tamworth, UK. Unfortunately there are no loading facilities on-site, dismantling and loading will be at the cost of the Purchaser. All/Any tooling is being offered as specifically described.

Condition: used, Year of construction: 2006, Spinner TC-52 MC cnc lathe with C-axis Year of manufacture 2006 Hours of operation 10981 Control Siemens 810D mit ShopTurn Turning diameter max. 280 mm Swing diameter max. 400 mm Center distance 550 mm Main spindle motor 13 kW Spindle speed max. 5.000 U/min Tool turret positions 12 C-axis and driven tools Dcjdpfx Asx R Tdqea Eeb Tested and fully functional Accessories/options: - swarf conveyor - driven tool holders 2 pieces - static tool holders 8 pieces - documentations - no tailstock Under power in our warehouse!

Condition: used, Year of construction: 2017, DMG Mori NLX2000SY/500 CNC Turning Centre. Serial No. NL203171121 (2017) with Siemens Ergoline Celos Type 9CE000_APDB Control, 20 Station Turret, Kitagawa BR08 Large Bore Main Spindle 3-Jaw Chuck & Kitagawa B208 Sub-Spindle 3-Jaw Chuck, Main & Sub-Spindle Toolsetters, Parts Catcher, Parts Conveyor, Hydrafeed Multifeed MX1B Bar Feed, Cleanmist CM1400/2, Swarf Conveyor, Selection of Driven & Static Tool Holders with Capto Turning/Boring Tools, Manuals, Setting Bar, Country of Origin: Japan Please Note: This machine has been decommissioned and transit brackets fitted. Dedpex R Tctsfx Aa Eocb Location: This lot is located in Birmingham, UK. A charge of £550 for dismantling and loading onto suitable transport will be automatically added to your invoice should you be successful in purchasing this item. Blocking and securing will be at the cost of the purchaser. All/Any tooling is being offered as specifically described.

Condition: excellent (used), Year of construction: 2006, turning length: 365 mm, spindle motor power: 10 W, travel distance X-axis: 160 mm, SCHUNCK 160 mm chuck with jaws Full C-Axis 360.000 Driven Live tooling Part catcher Tooling package with 12 Tooling holders 3 x Live tooling AXIAL 3 x Live tooling RADIAL Dodox R Szhepfx Aa Eecb Collet device with inserts Cutting Hours 14.462 H Max. turning Ø: 380mm X-Axis: 160mm Z-Axis: 365mm Spindle bore: 56/42mm Speedrange: 6000Rpm Spindle power: 10kW ATC / revolver: 12 Speed live tools:4000Rpm Power live tools:5kW Chip conveyor: Yes Pinole taper: 4Mk Stroke pinole: 100mm Quill Ø: 100mm Length: 3800mm Width: 1720mm Height: 1670mm Weight: 4000kg Please Note: The information on this page has been obtained to the best of our ability and belief, and from the manufacturers where possible. It is given in good faith, but its accuracy can not be guaranteed. Accordingly, it will not form a representation or constitute contractual terms. We advise you to check any vital details!

Condition: like new (used), Year of construction: 2020, operating hours: 250 h, functionality: fully functional, NCT 201/15” Touchscreen + USB Control (Windows based) Max. Swing over bed: 590 mm Max. Swing over cross slide: 340 mm Max. Turning diameter: 300 mm Center distance: 300 mm Chuck diameter: 8" Guide type: Linear Travels X / Z / Y / W: 160 / 455 / - / 325 mm Rapid traverse X / Z / Y / W axis: 24 / 30 / - / 24 mm MAIN SPINDLE: Max. speed: 3500 rpm Dcsdpjx R Smkjfx Aa Esb Spindle nose: A2-6 Spindle bore: D75 mm Bar diameter: max. D60 mm Drive: Belt Number of areas: 1 Motor power: 15 kW Cooling: Air DOUBLE SPINDLE: Max. speed: 3500 rpm Spindle nose: A2-5 mm Motor power: 6.9 kW Drive: Belt TOOLS: Tool change: Tool positions: 12 Tool equipment: VDI30 Number of driven tool positions: 12 Maximum driven tool speed: 4000 rpm SETUP: Footprint x Height: 2693 x 1810 x 1950 mm Net weight of machine: 4230 kg BAR LOADER: Type: BF1500 / DH65-LN Max. bar length: 1500 mm Max. bar diameter: 65 mm Weight: approx. 333 kg Accessories, equipments - Chip conveyor - Coolant system - Bar feeder - Finished part conveyor - Counter spindle - C-axis + driven tool turret - Tool holders - Manuals - CE marking - Foot pedals The machine has barelly been used. It is currently under power and located in Western Hungary and can be viewed upon request.

Condition: excellent (used), With sub-spindle With milling head With C-axis, with Y-axis SIEMENS 840D ERGOline ShopTurn control Turning length -1250 mm Swing Diameter -700 mm Turning diametre 340 mm Bar diameter -67 mm Spindle speeds - 4'000 + 5'000 rpm Dcedjx R R N Rspfx Aa Eob Milling head -12'000 rpm B-axis +/- 110° Turret head with 12 driven positions Tool changer with 24 positions Bar loader IEMCA Master 880 Vers - 3000 mm Workpiece pick-up attachement Tool presetting device Tool breakage control device Chip conveyor Misc. accessories MARCELS MASCHINEN CH

Condition: ready for operation (used), Year of construction: 2000, operating hours: 45,000 h, General Data Measurements width 1910 mm Dsdpfx Aajx R E Tqo Eecb Measurements depth 3580 mm Measurements height 2050 mm Machine weight 4000 kg Control Unit Brand INDEX Model C200-4 / C200-8 Additional Equipment Synchronous device for counter spindle machining Tool carrier 3 for synchronous spindle (rear end machining) Additional milling spindle Thread milling and polygon turning device Gripperless tool changer (6 tools, HKS-50 B, KM40) Workpiece handling WHU100 This 5-axis Index G200 C turn-mill centre was manufactured in 2000. Consider the opportunity to buy this Index G200 C turn-mill centre. Contact us for more information. Application Types Turning

Condition: used, Year of construction: 2005, turning diameter 140 mm turning length 600 mm control Siemens 840 D PowerLine distance between spindles 615 mm Max. rpm 5.000 min/-1 power capacity - main spindel 20 / 27 kW max. Torque 105 / 145 Nm Dsdpfx Aex R En Isa Eecb C-Axis 0,001 ° chucking diameter 140 - 160 mm spindle head ISO 702/1 A5 max. bar capacity 65 mm spindle bearing diameter 110 mm Max. rpm 5.000 min/-1 power capacity - Sub spindle 20 / 27 kW max. Torque 105 / 145 Nm C-Axis 0,001 ° chucking diameter 140 - 160 mm spindle head ISO 702/1 A5 max. bar capacity 65 mm x-travel 150 mm z-travel 600 mm spindle bearing diameter 110 mm Number of Turret 3 pos. tool taper VDI 25 x 48 DIN 69880 number of toolpositions 3x 12 pos. Number of driven toolspositions 3x 12 pos. Spindle speed - driven tools max. 6.000 min -1 power capacity - driven tools 8 kW max. Torque 16 Nm x-travel 1/2/3: 110 mm z-travel 1/2/3: 360 mm y-axis 1/2/3: 70 mm b-axis 2x +/-1 ° rapid traverse ( X / Y / Z ) 25 / 12 / 50 m/min total power requirement 53 kVA weight of the machine ca. 6,5 t dimensions of the machine ca. 8,0 x 3,5 x 2,5 m High-Performance - CNC - Turning- and MillingCenter INDEX - C65 SpeedLine - Main- and Subspindle - 3 turrets - 2(3) y-Axis +/-35mm - 2 b-corrective-Axis (+/-1°) - 3x 12 driven tool positions - IRCO - Profimat 65.6

Condition: used, Year of construction: 2015, functionality: fully functional, Type of control Mazatrol Matrix 2 Max. workable diameter ( Upper turret) Ø 658 mm Max. workable diameter ( Lower turret) Ø 420 mm X Axis Travel 260 mm Y axis travel 260 mm Z Axis travel 1,585 mm W-Axis Travel 1,539 mm X2 axis travel 230 mm Z2 axis travel 1,388 mm B axis -30° ~ 210° Spindle connection Capto C4 Self centering spindle 12" Spindle bar passage 102 mm Spindle speed 3,300 rpm Spindle power 30 Kw Spindle nose A 2-8 Self centering secondary spindle 10" Dedpfox Rzchsx Aa Eocb Secondary spindle bar passage 80 mm Secondary spindle speed 4,000 rpm Secondary spindle power 18,5 Kw High pressure 70 Bar Milling spindle rotation speed 12,000 rpm Tool turret 9 positions Probe Renishaw Equipment Chip conveyor

Condition: excellent (used), Year of construction: 2023, CNC Milling and Turning Center Machine type: DMG Mori CLX 450 TC Control: Siemens 840 D sl Operate Slimline Year of manufacture: 2023 TECHNICAL DATA: Max. turning length: 1,100 mm Turning diameter: 400 mm Main spindle: ISM 65 Speed range: 5,000 rpm Drive power: 14 / 17 kW Torque: 275 / 345 Nm Spindle nose: A2-8 Bar capacity: 67 mm C-axis CNC spindle swiveling for milling and turning operations Max. speed: 12,000 rpm Drive power: 8.8 / 10.5 kW Torque: 73 / 90 Nm Tool holder: HSK 63 Tool positions: 60 Counter spindle: ISM 65 Spindle nose: A2-8 Max. speed: 5,000 rpm Drive power: 14 / 17 kW Torque: 275 / 345 Nm C-axis X-axis: 750 mm Y-axis: +/- 100 mm Z-axis: 1,100 mm B-axis: +/- 120 mm Features: Chip conveyor Direct position measuring system Chip flushing gun 3-jaw chuck: SMW-Autoblok BBD 250/78 mm 3-jaw chuck: SMW BBD 250/78 mm Tailstock function on counter spindle Dcodex Ryw Rspfx Aa Esb High-pressure pumps: 8 bar / 20 bar Coolant tank: 600 l Oil mist extraction Probe: Renishaw RMP 40

Condition: good (used), Year of construction: 2008, functionality: fully functional, There is 5 pieces for sale, (2010 - 2008 - 2004 - 2002 - 2001) Dsdex Rw Itepfx Aa Ejcb All of them has C-Axis. All of them has Automatic Part Loader. All of them has Live tools of different amounts. (Please ask for exact amount) We can send videos of the machines. X-Axis Travel : 245mm Y-Axis Travel : +-35mm Z-Axis Travel : 240mm Spindle Speed Range: 60-6000 1/MIN Max. Bar Diameter on Main Spindle 70mm Max. Bar Diameter on Sub Spindle 80mm Spindle inner diameter 46mm

Condition: used, Year of construction: 2007, functionality: fully functional, CNC Control: Fanuc 18i-TB Dsdsx Rvivopfx Aa Eecb Travel X-axis (mm): 157.5 Travel Y-axis (mm): 35 Travel Z-axis (mm): 464.8 C-axis: 360º (0.001º increments) Turning length (mm): 399 Max. turning diameter (mm): ø190 Distance between spindle noses (mm): 750 Spindle bore (mm): 65 Upper turret: Number of tool stations: 12 Max. speed of driven tools (rpm): 6,000 Driven tool power (kW): 5.5 / 3.7 Lower turret: Number of tool stations: 12 Max. speed of driven tools (rpm): 6,000 Driven tool power (kW): 5.5 / 3.7 Main spindle: Max. spindle speed (rpm): 5,000 Spindle drive power (kW): 15 / 11 Sub spindle: Max. spindle speed (rpm): 4,500 Spindle drive power (kW): 11 / 7.5 Equipment: Parts catcher Bar feeder: LNS HYDROBAR SPRINT Rated power (kVA): 67.2 Basic machine: Dimensions / Weight Length (mm): 3,675 Width (mm): 2,258 Height (mm): 1,885 Weight (kg): 9,000
