Used Grinding Mill for sale (4,043)

Condition: refurbished (used), Year of construction: 2025, functionality: fully functional, machine/vehicle number: 6360.16.65, Country of manufacture: Switzerland Voltage: 380/400/50/3 Net weight: 1350 kg Customs tariff number: 8460.1920 Dimensions: 200/120/160 cm TECHNICAL SPECIFICATIONS Maximum saddle travel: 530 x 220 mm Maximum grinding surface: 520 x 230 mm Laodpfx Ajw Ucxqjgzek Table clamping surface: 600 x 200 mm Table speeds Longitudinal, standard operation: 0-25 m/min With slow feed: 5/10 mm - 8 m/min Cross feed: 0-6 m/min Vertical travel by hand: 330 mm Rapid travel by motor: 290 mm Rapid feed rate: 460 mm/min Max. distance between table and spindle axis: 412 mm Vertical feed movement Handwheel, 1 division: 0.01 mm Micrometric device, 1 division: 0.001 mm Automatic: 0.001-0.099 mm With pulse button: 0.001 mm Cross feed movement Handwheel, 1 division: 0.01 mm Micrometric device: 0.001 mm Grinding wheel Diameter x width x bore: 225x25x50/51 mm Standard RPM: 2700 rpm With variable speed drive: 3700-1300 rpm All technical data are provided without guarantee and are subject to possible errors or omissions.

Condition: good (used), Year of construction: 1970, functionality: fully functional, Rotary Table Surface Grinding Machine Sweeping Type RS 6B Stock No: 14-10-008 Machine data: Year of construction: approx. 1988 L x W x H: approx. 2700 x 2000 x 2200 mm Weight: approx. 3500 kg Specifications: Lodpfx Ajvtz Ukjgzjak Grinding range: Diameter: approx. Ø 600 mm Grinding height: approx. 300 mm Magnetic clamping surface: approx. Ø 600 mm Drive power: approx. 15 kW Grinding spindle speed: approx. 1500 rpm Grinding wheels - diameter: approx. Ø 350 mm Accessories: - Segment grinding wheel Price on request

Condition: ready for operation (used), Year of construction: 1996, operating hours: 5,592 h, functionality: fully functional, TECHNICAL DETAILS Grinding length: 1,200 mm Grinding width: 450 mm Max. grinding wheel size: 400 x 60 x 127 mm Distance from grinding wheel to magnet max.: approx. 400 mm MACHINE DETAILS Dimensions & Weight Dimensions (L x W x H): 4,000 x 2,300 x 2,400 mm Weight: 5,800 kg Operating Hours Lodpox E U A Dsfx Agzsak Spindle rotation hours: 5,592 h Total operating hours: 44,885 h EQUIPMENT Magnetic clamping plate 1,200 x 500 mm Borazon grinding wheel (mounted)

Condition: used, functionality: fully functional, GRINDING PLANT capacity 1 t/h with roll press, sieving in 3 granulometries with nutation screen and horizontal screens. Input: inlet grain size < 10 mm (marble, granite and quartz) with loading by big-bags on the included hopper. Output: 3 grain sizes (0-50, 50-100 and 100-300 microns). 70% of 100-300 microns, Laodpox Agxvofx Agzjk 15% of 50-100 and 15% of 0-50 microns. Storage with propulsion system for sending to silos (silos not included)

Condition: good (used), Robust horizontal surface grinding machine with a large long-bed design, suitable for heavy workpieces and precise surface grinding operations. The machine is in operational condition and can be inspected under power. Technical data (approx.): • Grinding length: approx. 4000 mm • Grinding width: approx. 500–900 mm • Hydraulic table movement • Magnetic chuck • Electromechanical feed • Solid machine frame → low vibration and precise. Equipment: • Magnetic chuck • Coolant unit • Control panel • Work lighting. Advantages: • Ideal for long/heavy workpieces • High accuracy due to solid construction • Immediately ready for use. Inspection possible by appointment. Lajdpfxjx Ngx So Agzsk

Condition: used, Year of construction: 1995, Surface grinding machine Manufacturer: Jung Model: JA 500 CNC-C Year of manufacture: 1995 Overhauled in: 2003 Grinding length: 500 mm Grinding width: 200 mm Max. workpiece height: 250 mm Table dimensions X/Y: 600 mm / 200 mm Grinding wheel diameter: 225 mm Grinding wheel width: 25 mm Grinding wheel bore: 51 mm Speed: 4,200 rpm Ledpswp E Rgofx Agzsak Machine weight: approx. 2,500 kg

Condition: excellent (used), machine/vehicle number: 31.207.011, Manufacturing origin Swiss Voltage 380/50/3 Netweight 3150 kg Dimensions 400x185x175cm Custom position 8460 TECHNICAL DATA Distance between centres 1000 mm Centres height 175 mm Wheelhead Wheel : diameter/width/bore 500 / 80 (100) / 203.0 mm Ljdpfxsiwtm Sj Agzeak Max width of wheel 80(100) mm Spindle speeds 1220,1360,1530 min-1 Table maximal travel 1100 mm Table, speed (variator, progressively adjustable) 0.02 to 6.0 m/min Workpiece headstock Swivel 360° speed (variator,progressive adjust) 20 min-1 to 400 min-1 Wheelhead motor 6 HP Total power 7 HP Max diameter of workpiece 249 mm Tailstock internal taper Morse 3 errors and omissions excepted-data given without obligation

Condition: good (used), Machine spindle, precision spindle, double grinder spindle, precision spindle for belt drive, belt drive spindle, grinding spindle -Manufacturer: Voumard, grinding spindle precision spindle -Type: C 40-9 D Ledpfswub Ifox Agzjak -Recording: M6 -Dimensions: Ø 90 x 335 mm -Transport dimensions box: 480/320/H225 mm -Weight: 17.8 kg

Condition: new, Year of construction: 2025, Dimensions (L/W/H) 4410x3050x2727 mm Lajdpfx Agsv A Hf Tszsk Weight 13070 kg Total power requirement 172 kw Wide Belt Sanding machine Linie SANDOMAT WT-RRC1300+SUR-RP1300 Wide Belt Sanding machine WT RRC1300 (Roller+Roller+combination)- Max. Working width 1300mm- Min. Working Length 490mm- Working Thickness 3-150mm- First unit: Contact roller Ø240- Second unit: Contact roller Ø240- Third unit: Ø240 pad- Total: Motor 77kw- First Unit: Motor 30kw- Second Unit: Motor 22kw- Third Unit:Motor 18.5kw- Conveyor belt: Motor 4kw- Lifting Motor 0.55kw- Brush roller: Motor 1.5kw- First unit: Contact roller shore Steel- Second unit: Contact roller shore 80sh- Third unit: Contact roller shore 55sh- Conveyor belt: Speed 5-30m/min- Abrasive Belt Size 1350*2620mm- Air Pressure 0.6Mpa- Overall Dimensions 2235×3050×2600mm- Net Weight 5700 kgs- Working Table Fixed- Working table height from the ground 900mm- Voltage 400v/50hz/3phases- Air jet for each belt Optional- Automatic centering of conveyor belt YES- Press roller (rubber) YESWide Belt Sanding machine SUR-R-P1300 (Roller+Roller+Pad)- Max. Working width 1300mm- Min. Working Length 350mm- Working Thickness 10-100mm- First unit: Contact roller Ø255- Second unit: Contact roller Ø255- Third unit: pad- Total: Motor 95kw- First Unit: Motor 37kw- Second Unit: Motor 30kw- Third Unit:Motor 18.5kw- Conveyor belt: Motor 4kw- Lifting Motor 0.55kw- Brush roller: Motor 0.55kw- First unit: Contact roller shore 80sh- Second unit: Contact roller shore 70sh- Third unit: Contact roller PAD- Conveyor belt: Speed 5-30m/min- Abrasive Belt Size 1320*2000mm- Air Pressure 0.6Mpa- Overall Dimensions 2175×2976×2727mm- Net Weight 7370 kgs- Working Table Fixed- Working table height from the ground 1038mm- Voltage 400v/50hz/3phases- Air jet for each belt YES- Automatic centering of conveyor belt YES- Press shoes(steel) YES

Condition: used, functionality: fully functional, GRINDING PLANT 8 t/h capacity with roll press, inclined sieve, n.2 wind separators. Input: Input grain size Ledpox Agx Asfx Agzsak

Condition: good (used), Year of construction: 1999, operating hours: 16,000 h, functionality: fully functional, machine/vehicle number: 650341, Year 1999 with Fanuc 18 TB – 3 axes XZB Marposs E30/E20 Country of manufacture: Switzerland Voltage: 400V/50Hz/3ph Dimensions: 410 x 220 x 190 cm Net machine weight: 5,000 kg TECHNICAL SPECIFICATIONS CNC control: Fanuc 18TB Intermediate Section Fixed intermediate section: grinding head R Swiveling section with manual indexing 2.5°: R / RS / UR / URS -210° to +30° Swiveling section with automatic indexing 2.5°: R / RS / UR / URS -210° to +30° B axis, resolution 0.1'': R / RS / UR / URS -210° to +30° Standard workhead Swivel range: -10° to (+100°) Spindle speed (continuous): 6 – 600 rpm Internal taper: MT5 Reducing sleeve: MT5/MT4 Short external taper fitting: DIN 55026 / Size 5 Permissible torque: 160 Nm Guaranteed roundness for chuck work Standard: 0.5 µm Option: 0.2 µm Workpiece weight between centers: 150 kg Tailstock Taper fitting: MT4 Quill stroke: 50 mm / 2° Option: fine adjustment with correction (Ø +/- 150 µm) Grinding wheel data (max. speed) Diameter 300: 27 m/s Diameter 400: 35 m/s Diameter 500: 45 m/s Laedpfx Aew T Tb Hogzek UR Grinding Head Power: 9.2 kW / 12.5 HP Wheel mounting, left max.: Ø 500 x 80 mm Right, additional max.: Ø 400 x 63 mm Internal grinding device: spindle HJN 828 Lower table (Z axis) Distance between centers: 1000 mm Max. travel: 1150 mm Max. speed: 15 m/min Max. resolution: 0.1 µm Upper table Distance between centers: 1000 mm / swivel 0° to 9° Grinding carriage (X axis) Max. travel: 320 mm Max. speed: 7.5 m/min Max. resolution: 0.1 µm Pneumatics Min. connection: 6 bar Air consumption: approx. 0.6 m³/h Coolant Max. connection pressure: 3 bar Required space (version 1000): 3600 x 2000 mm Unless otherwise stated, technical data is provided without engagement and may be subject to errors or omissions.

Condition: new, Year of construction: 2025, Dimensions (L/W/H) 4630x3005x2334 mm Lodpfx Agov A Hftozjak Weight 12160 kg Total power requirement 135,6 kw

Condition: refurbished (used), Year of construction: 2025, operating hours: 50 h, machine/vehicle number: 3018-04, Country of manufacture: Switzerland Voltage: 380/50/3 Net weight: 3100 kg Overall dimensions: 230x155x170 cm Installed power: 13 kVA Customs tariff position: 8460.2920 TECHNICAL SPECIFICATIONS MAIN DIMENSIONS Distance between centers: 650 mm Grinding capacity SpW+bs: -80 Stroke: 700 LONGITUDINAL SLIDE Max stroke: SpW+50 mm Minimum automatic feed: 1.5 mm Speed: 50-5500 mm/min Reversal delay: 0-6 sec Maximum table swivel: 12°/10°/8.5°/6° Pneumatic relief for table and workhead CROSS SLIDE Max stroke: 300 mm Rapid traverse: 60 mm Plunge grinding depth in diameter: 3.4 mm Feed 1: 0.012-6 mm/min Feed 2: 0.012-1.2 mm/min Feed per pulse: 0.001-0.05 mm GRINDING WHEEL HEADSTOCK Left-side wheel, external grinding: 400x80x127 mm Drive power: 5.5 kW Peripheral speed: 35 m/s RPM: 1670/2110 min-1 Internal grinding device for belt-driven spindles, including drive unit: 1.5 kW WORKHEAD Swivel range: 0-90° Continuously variable RPM: 30-1000 min-1 Internal taper: Morse 5 Collets: W-25 Drive power: 0.55 kW Maximum workpiece weight between centers: 130 kg Grinding load between centers: 100 Nm TAILSTOCK Internal taper: Morse 3 Quill stroke: 35 mm Fine adjustment for cylindricity correction: ± 40 μm TECHNICAL CHARACTERISTICS: GUARANTEED WORKING ACCURACY Straightness of the generator over 630 mm: 0.003 mm Roundness during chuck grinding: 0.0003 mm CONNECTION VALUES Maximum absorbed power: 13 kVA Maximum permitted voltage fluctuation: -15%/+10% Laodpfxjw T Sd To Agzek Maximum permitted frequency variation: ± 3% Required compressed air pressure: 5 bar Unless otherwise stated or in case of error or omission, these technical details are provided without engagement.

Year of construction: 2025, condition: new, Dimensions (L/W/H) 1700x860x850 mm Weight 190 kg Total power requirement 1,5 kw Laedpfxjvz Hzle Agzjk

Condition: refurbished (used), Year of construction: 2025, operating hours: 36 h, functionality: fully functional, machine/vehicle number: 1024-54, Country of Manufacture: Switzerland Voltage: 380/50/3 Net weight: approx. 1600 kg Customs tariff: 8460.2920 Dimensions: 235 x 155 x 145 cm TECHNICAL FEATURES: MAIN DIMENSIONS: Centre height: 100 mm Distance between centres: 400 mm LONGITUDINAL SLIDE: Max travel: 420 mm Lsdpfx Agew T Sc Nezeak Minimum automatic travel: 1 mm Table feed speed: 100–3500 mm/min Overtravel delay: 0–5 sec. Maximum table swivel (400/650 mm): 30°/15° CROSS SLIDE: Max travel: 170 mm Rapid traverse: 30 mm Plunge depth (diameter): 1.9 mm Feed rate 1: 0.03–1.5 mm/min Feed rate 2: 0.02–0.3 mm/min Plunge feed per impulse: 0.0005–0.025 mm WHEELHEAD: Grinding wheel (diameter x width x bore): 350 x 32 x 127 mm Drive power: 3 kW Peripheral speed: 30 m/s Spindle speeds: 1600/1975/2200 rpm Manual stroke: 120 mm Swivel to right: 15°/30° Optional wheel guard for wheel set max width: 50 mm WORKHEAD: Swivel range: 0°–90° Spindle speeds: 80/175/380/800 rpm Internal taper: Morse 4 Collet type: W-20 Drive power: 0.5 kW Maximum workpiece weight: 20 kg Load for in-the-air grinding: 12 Nm Optional stepless drive speed range I: 30–300 rpm Optional stepless drive speed range II: 120–1200 rpm TAILSTOCK: Internal taper: Morse 2 Quill travel: 20 mm GUARANTEED WORKING ACCURACY: Generator straightness: Between centres: 400 mm Measured over 400 mm: 0.002 mm Between centres: 650 mm Measured over 650 mm: 0.003 mm Roundness accuracy for in-the-air grinding: 0.0004 mm CONNECTION VALUES: Power consumption: max. 8 kVA Permissible voltage variation: –15% / +10% Permissible frequency variation: ±3% Compressed air: 5 bar All technical specifications are given without obligation and subject to errors or omissions.

Year of construction: 2025, condition: new, Dimensions (L/W/H) 1700x660x850 mm Weight 180 kg Lodpfjvz Hzfsx Agzjak Total power requirement 3 kw

Condition: refurbished (used), machine/vehicle number: 2257, Manufacturing origin France Voltage 380/50/3 Netweight 3000 kg Custom position 8460.29 20 Dimensions 2400x1550 mm TECHNICAL DATA Diameter capacity 80 mm Type 2HA : 120 mm Maximum infeed grinding length 200 mm Maximum throughfeed grinding length (with normal-type guides) 300 mm Grinding wheel : -diameter 400 mm -maximum width 200 mm -bore 203.2 mm Driving wheel : -diameter 254 mm -width 200 mm -bore 127 mm Main drive motor 11-22 kW Driving wheel motor 1,1 kW Driving wheel speed 10 – 200 U/Min Standard accessories : 1 flange with grinding wheel 1 flange with driving wheel 1 workpiece support bridge 1 set of shims for workpiece support -Hydraulic dressing and trueing device for grinding and driving wheels -Variable speed drive of driving wheel -Electrical equipment for 3x380 v, 50 Hz -Main drive motor, 11 kW -Ammeter for main drive motor Laodofnm Iispfx Agzek Starter keys and operating manual errors and omissions excepted data given without obligation.

Year of construction: 2025, condition: new, Dimensions (L/W/H) 800x860x850 mm Weight 140 kg Total power requirement 1,5 kw Laedpfx Aovz Hy Usgzek

Condition: refurbished (used), Year of construction: 2025, functionality: fully functional, machine/vehicle number: 1845/455, Completely refurbished: Mechanics, geometry, hydraulics, and electrical components Wheelhead Disassembly, cleaning of parts, replacement of worn and defective components, motor overhaul, replacement of bearings, replacement of belts, spindle disassembly, replacement of seals and O-rings, plus adjustment. New paintwork. Workhead Disassembly, cleaning of parts, replacement of worn and defective components, motor replacement, replacement of belts. New spindle bearings. New paintwork. Tailstock Disassembly, cleaning of parts, replacement of worn and defective components, motor replacement, replacement of belts. New spindle bearings. New paintwork. Internal grinding attachment Disassembly, cleaning of parts, replacement of worn and defective components, installation of the support and geometry alignment. New paintwork. Hydraulics Disassembly, motor replacement, hose replacement, defective and worn parts replaced. Hydraulic block checked. X-Axis Disassembly, replacement of worn items such as O-rings, seals, rings, etc., overhaul of hydraulic piston, regrinding of tables. Z-Axis Lajdpfx Aext Ilfegzek Disassembly, regrinding of tables, replacement of worn and defective parts, overhaul of hydraulic piston, scraping of V and flat guides. New paintwork. Measuring system Digital 2-axis display included. Electrical cabinet Replacement of motor contactors and relay controls. New wiring. New variable speed drive (frequency inverter) for the workhead. TECHNICAL SPECIFICATIONS Distance between centers: 1500 mm Distance between centers (workhead to tailstock overhang): 1650 mm Center height, standard: 125 mm Center height with riser blocks: 225/250 mm Maximum grinding diameter: Ø 250 mm Maximum grinding diameter with riser blocks: 450/500 mm Table Usable surface: 2060 x 140 mm Max. length and width for surface grinding: 1750 x 200 mm Longitudinal travel, manual or hydraulic: 1750 mm Manual table movement, 1 handwheel revolution – coarse: 20.006 mm Manual table movement, 1 handwheel revolution – fine: 2.457 mm Table speed, continuously via hydraulics: up to 6 m/min Table swivelling: 6° Stop and return: 0–5 sec. Workspindle Workpiece speeds, continuously variable (electric): 20–400 rpm Swivelling: 360° Workspindle taper (internal): MT5 Tailstock Internal taper, tailstock spindle: MT3 Spindle retraction, manual or hydraulic: 30 mm Diamond dresser taper (internal): MT0 Universal grinding head Cross slide travel for wheel: 285 mm Rapid traverse for wheel slide, front and rear: 40 mm Grinding spindle speeds: 1500 – 1700 – 2200 – 3600 rpm Vertical grinding spindle movement, center heights: 125–330 mm Max. wheel for cylindrical grinding: 400 x 50 x 127 mm Max. wheel for surface grinding: 250 x 20 x 76 mm Head swivelling with locking at every 90°: 270° Wheel feed 1 division of the micrometer drum: 0.005 mm/Ø Automatic wheel feed, max.: 0.9 mm/Ø Motors Grinding spindle motor: 2,900 rpm / 4.0 hp Workspindle motor: 3,000 rpm / 2.0 hp Coolant pump motor: 2,850 rpm / 0.12 hp Internal grinding attachment Bore: 70 mm Internal grinding spindle speed Ø70 mm: 14,000 rpm Internal grinding spindle speed Ø50 mm: 21,000 rpm Subject to error or omission, the technical information is provided without obligation.

Condition: new, Year of construction: 2025, Dimensions (L/W/H) 650x1160x650 mm Lodpovz Hv Aofx Agzoak Weight 125 kg Total power requirement 3 kw

Condition: refurbished (used), functionality: fully functional, machine/vehicle number: 32461/2384, Manufacturing origin Swiss Voltage 380 / 50 / 3 Netweight 4900 lbs Dimensions 121 x 69 inches TECHNICAL DATA Nominal distance between centre 600 mm Max. distance between centres, headstock and tailstock projecting 750 mm Height of centres, standard 125 mm Height of centres by means of raising blocks for work head-and tailstock 175 =ᐳ 250 mm Max. swing diameter with 125 mm height of centres 250 mm Max. swing diameter with raising blocks 350 =ᐳ 500 mm Table swivels each side 10° Max. lenght for surface grinding (width=200 mm) 900 mm Table speed infinitely viable by hydraulic drive, approx. .. 6 m/min Dwell of table reversal 0 - 5 sec. Grinding wheel for cylinrical grinding (diameter x width x hole) 350/400x50x127mm Grinding wheel for surface grinding diameter x width x hole 250 x 13 x 76 Speeds of grinding wheel spindle 1500/1700/2200/3600 Grinding wheel head swivels 270° with indexed stop each 90° Vertical movement of grinding wheel head, height of centres -350 mm Cross movement of grinding wheel head 285 mm Rapid advance and withdrawal of wheelhead 40 mm Intermittent infeed per reversal of table 0,001-0,03 mm/dia Infeed for plunge grinding 0-0,9 mm/dia Micro-corrector of infeed, 1 division of dial 0,001 mm/dia Swivel of work headstock 360° work speeds infinetely viable, normal/special 20-400/10-400 Internal taper of headstock/tailstock 5/3 Morse Grinding wheel motor, approx. 4 HP errors and omissions excepted data given without obligation Inventory Nr.2170089, machine equipped with : 1 Workpiece headstock MT5 1 sinus rule without comparator 1 Wheel headstock with 4 pulleys 1 Tailstock MT3 Lodjd Amifepfx Agzjak 1 Collet clamping device with drawbar and reduction sleeve B32 1 Internal grinding device with quill Fischer UJ50x250 – pulley Ø 48 for 14000 min-1 1 Pivoting wheel trueing-up device with sole 50 mm 1 Table’s pivoting stop without comparator 1 Cooling device through decantation 1 extractor 1 balancing stake

Condition: new, Year of construction: 2025, Dimensions (L/W/H) 750x1160x550 mm Weight 85 kg Lodpfx Aevz Hv Njgzeak Total power requirement 2,2 kw

Condition: refurbished (used), Year of construction: 2007, functionality: fully functional, machine/vehicle number: 027.0400/067, CNC CYLINDRICAL GRINDER STUDER S-33 CNC Year: 2007 - Fanuc 21i-TB 1 External Grinding Spindle Country of Origin: Switzerland Voltage: 380/50/3 Net machine weight: 4,000 kg TECHNICAL SPECIFICATIONS Distance between centers: 600 mm Center height: 175 mm Maximum workpiece weight: 80 kg Longitudinal Slide Z Max. travel: 800 – 1,150 mm Travel speed: 0.001 to 10,000 mm/min Lsdew T Sh Eepfx Agzsak (early 2000’s model: 0.001-5,000 mm/min) Resolution: 0.0001 mm Cross Slide X Max. travel: 285 mm Travel speed: 0.001 to 20,000 mm/min (early 2000’s model: 0.001-10,000 mm/min) Resolution: 0.0001 mm Wheelhead (universal version) Swiveling range: -15° to 225° (early 2000’s model: -15° to 195°) Swivel axis: 2.5 / 1 ° Hirth Drive power: 7.5 or 9 kW or 11 kW Grinding wheel: 500x63 (80/110F5) x203 mm Workhead Rotational speed: 1 – 1,500 min-1 Mount taper: MT4 or MT5 / ISO 50 Drive power: 1.6 or 3.0 or 4.0 kW Tailstock Mount taper: MT3 or MT4 Quill stroke: 35 / 50 mm (early 2000’s model: 35 mm) Quill diameter: Ø 50 mm Fine adjustment: +/- 40 µm Control system: Fanuc 21i-TB All technical details are provided in good faith but subject to errors or omissions.

Condition: refurbished (used), Year of construction: 2025, functionality: fully functional, machine/vehicle number: 510-1986, CYLINDRICAL GRINDER JOTES SCHAUDT A440X1500 Specifications Maximum longitudinal travel: 1500 mm Grinding diameter: 298 mm External grinding: Yes Internal grinding: Yes Dimensions (L x W x H): 5400 × 2400 × 1600 mm Weight: 4800 kg Operating hours: — Ljdpfsw T Ti Dox Agzoak Power-on hours: — Condition: Rebuilt Compliant with local standards: — Status: Under power Technical features - Grinding length [mm]: 1500 - Grinding diameter [mm]: 300 - Manual table displacement [mm/rev]: 10 - Table speed range [mm/s]: 0.01–5 - Smallest table stroke [mm]: 3 - Wheelhead swivel [°]: ±90 - Centre sleeve taper [Morse No.]: 4 - Grinding wheel dimensions [mm]: 500 x 63 x 203 - Spindle speed [rpm]: 32–500 - Grinding wheel drive motor power [kW]: 5.5 - Workpiece drive motor power [kW]: 0.75 - Hydraulic pump motor power [kW]: 1.5 - Grinding attachment drive motor power [kW]: 0.75 - Machine dimensions [mm]: L=5400 / W=2400 / H=1580 / Machine weight [kg]: 4800

Condition: good (used), machine/vehicle number: 7351, Manufacturing origin Germany Voltage 380/50/3 Netweight with/without acc. 4700/4000 kg Dimensions 3700x2000x2550 mm Total power Custom position 8460.29 20 Colour TECHNICAL DATA Grinding-wheel dia. 457 mm Grinding capacity 1 to 20 mm Winding width 10 to 60 mm Grinding wheel adjustment on each side 150 mm Discus grinding wheel 457 x 75 x 76 mm Total required power 32 to 42 HP Grinding procedure infeed grinding Grinding-wheel spindle 2 vertical spindles Working height with new wheel 95 mm One superior and one inferior grinding headstock Dia. 457 mm Rotation speed upper wheel 251 – 1254 rpm Lower 251 – 1254 rpm Surface speed upper wheel 60 – 30 m/s Lower wheel 60 – 30 m/s Laodpfx Ageip A Uxszok Workfeed 21,8 to 215 mm/s errors and omissions excepted-data given without obligation
