Used Horizontal Frame for sale (14,729)

Condition: like new (used), Year of construction: 2017, operating hours: 10,000 h, functionality: fully functional, travel distance X-axis: 730 mm, travel distance Y-axis: 730 mm, travel distance Z-axis: 830 mm, rapid traverse X-axis: 60 m/min, rapid traverse Y-axis: 60 m/min, rapid traverse Z-axis: 60 m/min, Base Machine - SH-5000P - Demonstration Machine Like New • Basic machine, 4-axis • Control: Siemens 840D sl Rcedps Af Ui Rjfx Afgoh • Table size: 500x500mm • Max. table load: 500kg • X/Y/Z travels: 730/730/830mm • X/Y/Z rapid traverse: 60/60/60 m/min • Milling spindle: • HSK63 • 30/50kW • 18,000 rpm • Tool magazine with 40 stations • Automatic pallet changer • Automatic loading door • Hydraulic unit • Oil separator • Oil mist extraction • Air conditioning unit for electrical cabinet • External measuring systems, linear axes • Media feed under pallets • Central lubrication • Door interlock • Coolant unit • Internal cooling with 70 bar high pressure • Coolant and compressed air gun • Chip conveyor • Documentation in German, digital

Condition: used, Year of construction: 1998, travel distance X-axis: 2,000 mm, travel distance Y-axis: 1,300 mm, travel distance Z-axis: 1,200 mm, controller model: MSC 502, spindle speed (max.): 6,000 rpm, TECHNICAL DETAILS X-axis travel: 2,000 mm Y-axis travel: 1,300 mm Z-axis travel: 1,200 mm Number of axes: 4 Spindle speed: 60–6,000 rpm Spindle power: 30–37 kW Spindle mounting: ISO 50 / BT Number of pallets: 2 Pallet size: 1,000 × 1,000 mm Pallet load: max. 3,000 kg Workpiece diameter: max. 2,000 mm Workpiece height: max. 1,550 mm Workpiece weight: max. 3,000 kg Magazine type: Chain magazine Tool positions: 120 MACHINE DETAILS Control system: MSC 502 Dimensions & Weight Rjdpfx Afs Agfrzegsch Machine weight: 35,200 kg Overall dimensions: 5,330 × 7,720 × 3,810 mm EQUIPMENT Pallet changer High-pressure coolant system Chip conveyor RS-232 interface Tool pre-setter

Condition: good (used), Protech Horizontal Collator Model: HC2010 Plastic belt, belt width: 250 mm Distance between dividers: 200 mm, divider height: 150 mm Clearance: 140 mm x 150 mm Total dimensions: 2900 mm x 560 mm x 1540 mm. Redpfx Afev T D Duogjch

Condition: good (used), Year of construction: 2012, functionality: fully functional, travel distance X-axis: 560 mm, travel distance Y-axis: 560 mm, travel distance Z-axis: 660 mm, spindle speed (max.): 12,000 rpm, Equipment: chip conveyor, MORI SEIKI NHX 4000 CNC Horizontal Machining Center with Pallet Changer General Machine Data Manufacturer: MORI SEIKI Model: NHX 4000 Year of Construction: 2012 Control System: Siemens Sinumerik 840D solutionline with SLIMline operator panel Machine Type: CNC Horizontal Machining Center Number of Axes: 4 (X, Y, Z, B) Rcedpfxe Agn Tlj Afgeh Travel and Feed Rates X-axis: 560 mm Y-axis: 560 mm Z-axis: 660 mm B-axis: 360° NC rotary table Rapid Traverse X/Y/Z: 60 m/min Maximum Feed Rate: 60,000 mm/min Main Spindle Maximum Spindle Speed: 12,000 rpm Tool Interface: HSK-A63 Spindle Power: Dependent on the installed spindle version Internal Coolant Supply (ICS) through the Spindle Tool Changer Automatic Tool Changer Tool Interface: HSK-A63 Tool Magazine: 40 positions Maximum Tool Diameter: approx. 70 mm Maximum Tool Diameter with Free Adjacent Positions: approx. 170 mm Maximum Tool Length: approx. 450 mm Maximum Tool Weight: approx. 8 kg Work Table and Pallet Changer Automatic 2-position Pallet Changer Pallet Size: 400 × 400 mm Maximum Pallet Load: approx. 400 kg Maximum Workpiece Diameter: approx. 630 mm Maximum Workpiece Height: approx. 880 mm B-axis: 360° Equipment Siemens Sinumerik 840D solutionline SLIMline operator panel HSK-A63 main spindle with 12,000 rpm Automatic Tool Changer Automatic 2-position Pallet Changer NC rotary table / B-axis Internal Coolant Supply (ICS) Chip Conveyor Coolant System Machine Dimensions and Weight Length: approx. 4,214 mm Width: approx. 2,720 mm Height: approx. 2,512 mm Machine Weight: approx. 8,000 kg The machine has been regularly maintained. All hydraulic and air hoses have been replaced. Spindle hours: 39,000

Condition: used, Year of construction: 1970, grinding length 3000 mm grinding width 800 mm workpiece height 750 mm total power requirement 42 kW weight of the machine ca. 29,5 t dimensions of the machine ca. 8169x4400x4200 m Rcodps Agw Ibefx Afgeh Zum Verkauf steht unsere eigengenutzte Flachschleifmaschine mit zusätzlicher schwenkbarer Schleifspindel für Führungen oder Untergriffe. Die Maschine wurde von uns nur zum Schleifen von Obertischen, Untertischen, Spindelstöcken etc. die im Zuge von Überholungen von insbesondere Kellenberger Rundschleifmaschinen eingesetzt. Leider können wir sie in unserer neuen Halle nicht aufstellen. Magnettisch 3000 x 600mm Abgabe voraussichtlich im März 2027. Preis vertseht sich ab Standort. Hallenkran bis 20t vorhanden.

Condition: ready for operation (used), Year of construction: 1995, Available immediately ex works: Hydraulic horizontal band saw automation machine, Jaespa Type W 320 AZ – 6 Year of manufacture 1995 Cutting capacity: 320 mm round / 90 degrees Cutting capacity: 320 x 320 mm rectangular / 90 degrees Band speed, infinitely variable: 15 – 110 m/min Drive power: 4.9 kW Cutting lengths: 5 – 9999 mm Rjdpfs Aa Iibox Afgsch Complete as shown in the picture, including all powered roller conveyors Weight: 2.2 tons Price: EUR 2,750.00 plus VAT, ex works

Condition: used, Year of construction: 2008, functionality: fully functional, For sale: a window and door pressing machine, model Junior, manufactured by the Italian company Casolin. Bale pressing machine. Redpfx Aszzn Dwsfgech Working area: 3000 mm (width) x 2500 mm (height). The machine is in good working order. We have the instruction manual in English. Export price – domestic price + VAT. Transportation is the responsibility of the buyer; loading is the responsibility of the seller.

Condition: used, Year of construction: 2023, operating hours: 1,621 h, machine/vehicle number: 6000030, travel distance X-axis: 3,000 mm, travel distance Y-axis: 1,800 mm, travel distance Z-axis: 575 mm, controller manufacturer: SIEMENS, controller model: SINUMERIK 840D SL, workpiece length (max.): 3,000 mm, workpiece width (max.): 1,800 mm, workpiece height (max.): 875 mm, total height: 6,600 mm, total length: 8,200 mm, total width: 4,800 mm, overall weight: 32,000 kg, spindle speed (min.): 17,500 rpm, spindle speed (max.): 1 rpm, distance table to spindle center: 1,300 mm, distance table center to spindle nose: 425 mm, number of spindles: 1, number of slots in tool magazine: 40, Equipment: chip conveyor, documentation/manual, Technical Data Operating time: 1,621 hours Technical Data Supply voltage: 3 × 400 V / 50 Hz (earthed) Supply system: TN-S or TN-C system Total connected load: 105 kVA Nominal load factor RDF: 0.6 Circuit breaker: 160 A gG (5 s) Dimensions Footprint including coolant cleaning system (W × H × D): 8.20 × 4.80 × 6.60 m Weight Operating weight of the machine: 32,000 kg Transport weight: 27,000 kg Control System CNC control: SIEMENS SINUMERIK 840D SL Main Spindle Spindle arrangement: horizontal Rsdpfs Aax U Ijx Afgjch Design: liquid-cooled motor spindle, AC synchronous technology Spindle lubrication: oil lubrication with minimum quantity lubrication Tool holder: HSK-A63 Tool Clamping System Mechanical clamping force: > 18 kN Setting dimension: 10.5 ± 0.1 mm Performance Data Speed range: 1–17,500 min⁻¹ Acceleration time: 0.7 s Power: 35 kW Nominal power: 26 kW Torque: 80 Nm (40% duty cycle) Nominal torque: 60 Nm Tool Magazine Tool change system: pick-up Tool management: permanently coded Capacity: 40 (1 × 40) tools Maximum total tool load: 200 kg Working Area X-axis: 3000 mm Y-axis: 1800 mm Z-axis: 875 mm Distance between spindle and center of swivel table: 425–1300 mm Tool change position X/Y/Z: 0/0/-310 mm Drive System General Design: Three-phase linear motors Position measuring system X-/Y-/Z-axis: direct, absolute X-axis Rapid traverse speed: 120 m/min Maximum acceleration: 10 m/s² Relative acceleration increase (G0): 200 m/s³ Relative acceleration increase (G1): 50 m/s³ Peak force: 10,000 N Nominal force: 5,000 N Y-axis Rapid traverse speed: 120 m/min Maximum acceleration: 16 m/s² Relative acceleration increase (G0): 600 m/s³ Relative acceleration increase (G1): 300 m/s³ Peak force: 10,000 N Nominal force: 5,000 N Z-axis Rapid traverse speed: 120 m/min Maximum acceleration: 20 m/s² Relative acceleration increase (G0): 1000 m/s³ Relative acceleration increase (G1): 500 m/s³ Peak force: 7,000 N Nominal force: 3,500 N Accuracy Positioning accuracy A: ≤ 0.010 mm Repeat accuracy R: ≤ 0.006 mm Tool Change Average chip-to-chip time at n < 17,500 min⁻¹: 4.00 s Workpiece Handling Design: Swivel table driven by an AC servomotor with two opposing clamping surfaces Swivel table: bilateral locking via gear coupling, hydraulically actuated Swivel time 0/180 degrees: 4.0 s Maximum asymmetrical load: 3000 Nm Repeat accuracy at a diameter of 1200 mm: ≤ 0.010 mm Maximum dimensions of clamping device and workpiece: Ø 2200 mm × 3480 mm Maximum weight of clamping device and workpiece per side: 1000 kg Swivel range: 358° Swivel range with parallel loading: -16°–0° and 164°–180° Worm gear division: 2° Maximum speed: 16 min⁻¹ Interface for Control Programs Rotary Distributor Rotary distributor pair for NC rotary table (A/U-axis): unregulated, leak-proof sealed Distribution channels: 16 Maximum hydraulic operating pressure: 250 bar Maximum operating pressure: 8 bar Nominal diameter: 6 Maximum permissible speed at p = 200 bar: 20 min⁻¹ Hydraulic System Operating pressure: 250 bar Flow rate: 9 dm³/min Capacity of the hydraulic tank: 120 dm³ Hysteresis when charging the accumulator: 230–260 bar

Condition: excellent (used), Year of construction: 2014, Universally applicable frame and elongated hole drilling machine Specifically designed for window construction and universal use with pneumatic height adjustment. Double-hole drilling on two levels in a single clamping operation. Motor power: 1.5 kW Motor start with a practical handle switch. Equipped with a two-jaw chuck, 1–20 mm, by Röhm. Pneumatic adjustment of the machining height, allowing dowel holes to be drilled on two levels without re-positioning. The desired drilling heights can be set for each drilling level using a digital counter. Switching between levels is then performed pneumatically from the front. Cross adjustment: 430 mm, stepless or in a 12 mm grid. Maximum height adjustment: approximately 100 mm above table height. Drilling stroke: approximately 150 mm. 2 pneumatic workpiece clamps. Grid rail for quick lateral adjustment in a 12 mm grid. Stop for length adjustment when milling elongated holes. 2 swiveling workpiece supports. Special stop system, approximately 3.1 m long, with swiveling stops. Removable special stop with centering via a lever mechanism for different ladder rung widths, etc. Dust extraction funnel. Center stop. Side stop. Drill head mount. Rjdpo Aa A Eqjfx Afgoch Laser. Operating manual. CE marking. Few small areas where paint has been touched up. Almost new condition, see original photos. Dimensions: approximately 1500 x 900 x 1400 mm (L x W x H), weight: 300 kg. The machine can be demonstrated on-site by appointment. We only offer machines that are readily available for demonstration in our warehouse; see "other offers from this seller."

Condition: good (used), Year of construction: 2008, functionality: fully functional, travel distance X-axis: 560 mm, travel distance Y-axis: 600 mm, travel distance Z-axis: 600 mm, spindle speed (max.): 12,000 rpm, number of slots in tool magazine: 40, Equipment: chip conveyor, documentation/manual, CNC horizontal machining center with pallet changer DECKEL MAHO DMC 55 H duoBLOCK Year of manufacture: 2008 Control system: Siemens Sinumerik 840D Machine type: CNC horizontal machining center Number of axes: 4 (X, Y, Z, B) Spindle hours: approx. 46,000 h Travel distances X-axis: 560 mm Y-axis: 600 mm Z-axis: 600 mm B-axis: 360° NC rotary table Rapid traverse X/Y/Z: 40 m/min Positioning accuracy according to manufacturer: ± 0.003 mm Repeatability accuracy according to manufacturer: ± 0.001 mm Main spindle Spindle speed: 12,000 rpm Tool holder: HSK-A63 Spindle power: 20 kW (40% duty cycle, standard version according to manufacturer) Spindle torque: 110 Nm (standard version according to manufacturer) Tool changer Tool magazine: 40 tool positions Tool holder: HSK-A63 Maximum tool diameter: 80 mm Maximum tool diameter with free adjacent positions: 160 mm Maximum tool length: 330 mm Automatic tool change Work table and pallet changer Automatic 2-position pallet changer Pallet dimensions: 400 × 400 mm Maximum pallet load: 500 kg Maximum workpiece height: 850 mm NC rotary table with 360° B-axis Equipment Siemens Sinumerik 840D CNC control system HSK-A63 main spindle with 12,000 rpm 40-position tool magazine Automatic 2-position pallet changer NC rotary table / B-axis Internal cooling (IKZ) Chip conveyor Measuring probe Coolant system Electrical connection data Mains connection: 400 V / 50 Hz Connected power: approx. 58 kVA Maximum fuse rating: approx. 100 A Dimensions and weight Length: approx. 5,000 mm Width: approx. 3,000 mm Height: approx. 2,800 mm Machine weight: approx. 11,000–13,000 kg The machine has been regularly maintained. All hydraulic and air hoses have been replaced. Emergency stop switch on the control panel is defective. Clamping devices and tool holders are not included. Rcedpfxo Agn H Us Afgoh

Condition: used, Year of construction: 2021, x-travel 1400 mm y-travel 1200 mm z-travel 1400 mm Redpfe Adu Raex Afgsch control Sinumerik 840 D sl Siemens tool taper HSK- A 100 no. of tools in the magazine 117 Stück size of pallet 1.000 x 800 mm numbers of pallets 2 rapid traverse 50 m/min table rotating 360.000 x 0,001 B-Achse ° table load 2200 kg turning speed range 7.200 U/min max. torque on the spindle 1.666/1.273 Nm power capacity - milling spindle 75/64 kW weight 34 t dimensions 7,0 x 5,8 x 4,0 m 4 axis horizontal machining centre in perfect condition Only 1600 h spindle running time First installation 2022 - 4x disc magazine for 117 HSK-A 100 tools - two pallets with installation station - pallets with six fluid connecting points - Chip conveyor - 2x spiral chip conveyor - Air though spindle - oil skimmer - coolant gun - hydraulic system for part clamping - touch probe Renishaw - package for higher machining accuracy - coolant filter system - elec- mech. tool lenght control - laser system Blum for tools - tool cleaning system - oil dust collector 2.100 qm - Roto clean window

Condition: excellent (used), Year of construction: 2012, Horizontal conveyor 2500x410 mm year 2012 Rsdpfx Aoznb Ebofgech price: € 1,750.00 contact: Mr. Rainer Eckerle

Condition: used, Year of construction: 2015, Used machine Year of manufacture: 2015 Note: Operator terminal and angle scale on the right side! Cutting length: 3200 mm Max. saw blade overhang: 100 mm Feed rate, continuously variable: 5-100 m/min; return speed: 130 m/min Saw carriage guided on round shafts Drive via gear and rack and pinion system Automatic cutting length detection via laser sensor on the saw carriage Quick-change system for main and scoring saw blade (ProLock) Cutting direction against the stop Motor: 13.5 kW, total connected load: 18 kW, rated current: 38 A Electronic cutting height adjustment (continuously variable) for the sawing unit Raising and lowering of the sawing unit by means of a positioning drive Dimensional measurement via non-contact magnetic measuring system Including nesting program Scoring saw adjustment, horizontal and axial, from the control panel via electric servo motors Scoring saw unit with pneumatic lowering, scoring saw motor 2.2 kW Manual pressure regulators for package clamps and pressure bar for sensitive materials Tilting table on the left: 2300 x 600 mm with air cushion Solid stop rail with 2000 mm 2 side tables, 2300 mm with air cushion Material pusher, cutting length 3200 mm Feed rate: 25 m/min; return speed: 80 m/min Rear support table with 9 double roller tracks Package clamps, 6 pieces, 2-finger design, opening height 80 mm 3 veneer stops for cutting panels with protruding veneers Device for automatic positioning of the trimming position by the material pusher Lateral pressing device for workpieces from 20 to 1200 mm Modular control system with 24" TFT flat screen Rcjdpfxe Adv Rus Afgsh PC with Windows 7 Pro operating system With thermal label printer Availability: approx. January 2027 Location: North Rhine-Westphalia

Condition: good (used), Year of construction: 1992, machine/vehicle number: 43817, Offer 26319 Technical data: - Cutting range at 90° (round): 50 to 420 mm - Cutting range (square): 420 x 420 mm - Saw band dimensions (approx.): 6280 x 38 x 1.3 mm - 6 cutting speeds: 16 x 105 m/min - Cutting pressure, continuously adjustable: 0 - 400 mm/min - Hydraulic material clamping - Material feed automation: 8 - 520 mm - Multi-stroke up to: 2080 mm - Minimum remaining piece length: 70 mm - Pre-selection of the saw band stroke height - Chip conveyor - Coolant system - Total drive power: 400 V / 7.5 kW - Space requirement (approx.): W 2900 x H 2700 x D 2400 mm - Weight (approx.): 2900 kg Rcsdj Agvk Sepfx Afgsh - Motorized feed roller runs: 3 x 2000 mm - Total weight of roller runs (approx.): 1200 kg

Condition: good (used), Year of construction: 2004, functionality: fully functional, machine/vehicle number: 1591, Equipment: documentation/manual, Dienst horizontal case erector – used, fully functional, and removed from a production line. It is stored in a warm and dry hall. Redpfe Af Uthsx Afgjch The unit comes with a complete set of technical documentation, including a declaration of conformity. Detailed technical information regarding the design and performance can be found in the attached file – a document in German.

Condition: good (used), For sale: HESS frame press pneumatic, retrofitted with pressure booster control max. press length approx. 355 cm in good condition, from a small carpentry workshop. Rcodpfx Afo Af Humogeh

Condition: used, total length: 4,100 mm, total width: 1,900 mm, total height: 1,850 mm, Year of manufacture: 1997 Colour: Blue Empty weight: 5.000 kg Price: On request - Year: 1997 - Documentation available: Yes - CE marking present: Yes - Serial number: 9712854F - Drive system: Teach-in - Power [kW]: 14.0 - Centre height [mm]: 275 - Swing over bed [mm]: 550 - Carriage turning diameter [mm]: 360 - Distance between centres [mm]: 2000 - Bed width [mm]: 360 - Spindle bore [mm]: 105 - Min. spindle speed [rpm]: 180 - Max. spindle speed [rpm]: 2500 - Options: Fixed steady, Three-jaw chuck, Travelling steady, Quick-change tool post - Transport dimensions: 4100mm x 1900mm x 1850mm (l x w x h) - Transport weight [kg]: 5000kg - Transport packages [pcs.]: 1 Financial information VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Rcsdpfx Afo Agwr Rsgeh Delivery and trade-in always possible for everything in the industrial sectors Lukas van Rossum

Condition: used, Year of construction: 1990, cutting diameter 340 mm saw band length 5800 × 41 × 1,3 mm mm cutting width 700 mm turning speeds 17-120 m/min 700 x 340 mm mm total power requirement 4 kW Rcodpfx Ao Agckyefgjh weight of the machine ca. 2,4 t dimensions of the machine ca. 3,0 x 1,8 x 1,5 m The BEHRINGER HBP 340/700 G is a semi-automatic horizontal band saw designed specifically for cutting flat profiles, beams, and solid materials in heavy steel construction and metalworking. The "G" in the model name denotes an integrated miter-cutting function, which allows for precise angled cuts.

Condition: used, Year of construction: 2011, x-travel 730 mm y-travel 730 mm z-travel 850 mm control MSX 701 IV MAPPS 4 max. spindle speed 14.000 min/-1 power capacity - milling spindle 22 / 18,5 kW tool taper HSK A-63 distance ground floor - table top edge 1.200 mm distance Spindlenose and center of table 100 - 950 mm numbers of pallets 2 size of pallet 500 x 500 mm max. workpiece weight 500 kg max. workpiecediameter 800 mm max. workpiece height 1.000 mm Rcodps Af Naiofx Afgjh change time of pallets 7 sec Indexing-time 1,57 sec B-axis (table) 0,001 ° number of toolpositions 120 pos. tool taper HSK A-63 max. tool diameter 70 mm max. tool-dia with free toolbox 140 mm max. tool length 500 mm max. tool weight 12 kg rapid traverse 50 m/min feed speeds max. 50.000 mm/min Tipp feed 0 - 1.260 mm/min total power requirement 51 kW weight of the machine ca. 12 t dimensions of the machine ca. 5,5 x 3,0 x 2,8 m CNC - MachiningCenter Horizontal MORI SEIKI - NH 5000 / 40 DCG - 2 pos. palletchanger - 2x mounting towers - Processing time: approx. 14,200 hours

Condition: used, Year of construction: 1995, Fanuc MSC 516 2 pallets, 500x500mm BT40 spindle Rsdpfx Afozgrzkjgjch Spindle speed: 12,000 RPM 120-tool changer Coolant pressure: 20 bar Renishaw 3 additional pallets Chip conveyor

Condition: refurbished (used), 105m3 horizontal steel tank with heating coil Diameter: 2.80m Rcedpfx Afsxqfwtjgoh Length: 17.10m

Year of construction: 2012, condition: good (used), cutting height (max.): 350 mm, neva orbit plus Rcjdpfx Ajz R Uvxofgoh 350 mm, with numerous frame saws and grinding machines.

Condition: ready for operation (used), Year of construction: 2014, functionality: fully functional, number of slots in tool magazine: 60, Equipment: chip conveyor, documentation/manual, Technical specification: - horizontal spindle - spindle HSK-A63 - spindle torque 240 Nm - 4 axis machining - ATC 60 tools - pallet changer (2 pallets) - pallet size 500x500 mm - coolant chiller - coolant filtration system by Knoll - cooland pressure 50 bar through spindle - control system Fanuc - chips transporter - robot interface Rsdpfxszqyvwo Afgjch - linear measuring systems (scales) - manufactured in year 2014

Condition: good (used), Year of construction: 1998, functionality: fully functional, CNC Machining Center, Horizontal Manufacturer: MORI SEIKI Machine Model: SH400 Control: MSC 518 (FANUC) Year of Manufacture: 1998 Rsdpfx Ae Agwm Nsfgjch TECHNICAL DATA Travel Ranges - X-axis: (mm) 560 - Y-axis: (mm) 510 - Z-axis: (mm) 510 Rapid Traverse Rates - Rapid traverse in X (mm/min) 40,000 - Rapid traverse in Y (mm/min) 40,000 - Rapid traverse in Z (mm/min) 40,000 Main Spindle - Speed range RPM: 12,000 Tool Magazine - Tool holder: MAS BT 40 - Number of tool positions: 60 - Maximum tool length (mm) 350 Pallet System - Pallet size (L x W) (mm) 400 x 400 - Number of pallets: 2 EQUIPMENT FEATURES + Chip conveyor + 3D measuring probe Renishaw + Tool length measuring device Blum + Tool breakage detection Blum Dimensions and Weight - Machine weight approx.: 9,000 kg Subject to changes and errors in the technical data and specifications.

Condition: good (used), Year of construction: 2006, CNC machining center - horizontal Manufacturer: HELLER Machine model: MCH 250 Control: Siemens 840 D – Powerline Year of construction: 2006 TECHNICAL DATA - X-axis mm 800 - Y-axis mm 800 - Z-axis mm 800 Travel range along the center of the table, X-axis mm +400 to -400 Travel range vertically above the pallet clamping surface, Y-axis mm +120 to +920 Travel range transversely to the center of the table, Z-axis mm +150 to +950 Feed forces - X-axis at ED S3 – 40% N 15000 - Y-axis at ED S3 – 40% N 15000 - Z-axis at ED S3 – 40% N 17500 Speeds - Feed rate in X, Y and Z axes mm/min 1-50000 - Rapid traverse speed mm/min 50000 - Acceleration in X, Y and Z axes m/s² 4.0 Rcedpfj Agvffsx Afgjh - B-axis (360 x 1° rotary table) max. speed 1/min 25 Rotary table - Division degrees 360 x 1 - max. permissible clamping weight daN 800 - Max. tangential moment Nm 20000 - max. tipping moment Nm 18000 Spindle - Speed range 1/min 45 – 6000 - Tool holder DIN 69893 HSK 100 Form A - Motor Three-phase spindle motor - Drive power max. at the spindle at ED S1 - 100% kW 40 -- at ED S6 - 40% kW 60 -- at ED S6 - 25% kW 70 --- from speed 1/min 500 - Torque max. at the spindle at ED S1 - 100% Nm 765 -- at ED S6 - 40% Nm 1145 -- at ED S6 - 25% Nm 1340 -- up to speed 1/min 500 Tool magazine - Magazine type Rack - Magazine places incl. 2 x 7 setup positions 405 places - Magazine places for max. tool diameter 23 places Pallet changing device - Pallet size mm 630 x 630 - Workpiece dimensions: Swiveling diameter in the working area x height mm Ø900 x 1000 - Pallet changing accuracy in X, Y and Z axes mm 0.01 - Pallet changing time at 500 (800) daN s 12 (14) - Rotary storage RSP 4-fold - Pallets in the system, number 6 EQUIPMENT FEATURES + Coolant system ++ with vacuum rotary filter - high pressure 50 bar (Knoll VRF 250) ++ Coolant tank capacity l 1500 ++ Coolant pump 3 bar flow rate l/min 170 ++ Coolant pump 2 bar flow rate l/min 40 ++ High-pressure pump 70 bar flow rate l/min 22 + Chip removal ++ Conveyor spirals in the machine bed number 2 ++ Diameter mm 160 ++ Transverse chip conveyor ++ Conveyor speed m/min 1.5 ++ Discharge height mm 1200 + Rotary storage RSP 4-fold + Pallets in the system, number 6 + Integrated tool monitoring IPM + Drill breakage control + Measuring probe Renishaw + Status lamp 3 colors + Remote diagnostics via modem Machine weight daN 19000 Space requirement basic machine L x W x H approx. m 6.3 x 4.9 x 4.0 Power requirement basic machine kVA 85 Maximum power requirement (including all options) kVA 131 Subject to changes and errors in technical data and specifications.
