Used Press Frame for sale (19,884)

Year of construction: 2003, condition: used, frame hydraulic press WEGOMA Workspace: width 3600 mm height 2500 mm the amount of lateral hydraulic cylinders 3 pieces top two pieces beam mechanically Move Mechanical compression setting Gsdpfxjcmat Us Akysuc more photos an questions

Condition: as good as new (ex-display), Year of construction: 2026, Working width 4500 mm Working height 3000 mm Number of cylinders 6 St. Dimensions (L/W/H) 5500x1400x3550 mm Weight 3000 kg S&S frame press Bavaria 2000 L, built 2026 ----- SHORT TIMED availabe exw warehouse Engelfried, 73447 Oberkochen NEW for the Holz-Handwerk 2026 trade fair in Nuremberg: Now also with semi-automatic positioning of the vertical press cylinders 1, 2, and 3 via enabling switch, including ON/OFF selector switch for beam 2 With automatic pressing cycle + manual control for corner connections tenon+slots and dowel connection/mortised tenon, can be switched using a selector switch on the control cabinet. With basic equipment for optional use of counter profiles if the sash is rebated on the loose part. CE version Basic machine in the strongest frame welded construction, with thick-walled special hollow profiles. Guideways of the pressure beams for the press corners in a low-abrasion machined version. Fast, smooth, manual width adjustment using ball-bearing carriage, fixing in 50 mm hole grid, optional motorized width adjustment with hydraulic clamping (at an additional cost). Height adjustment and pressing using long-stroke cylinders in one work cycle. Right-hand press corners with integrated horizontal cylinders, therefore no vertical positioning of the horizontal pressure cylinders is necessary, which avoids cylinder collisions. Lower support can be adjusted in several positions to the most suitable insertion height. 3 KW compact hydraulic system with integrated control block, variable pressure control from 20 - 120 bar, pressure gauge Control via touch button with separate control circuits for the vertical and horizontal press cylinders, mounted on a freely movable control panel. 2 vertical press cylinders, double-acting, stroke adapted to working height, piston diameter 60 mm Pressure force per cylinder max. 2100 kg 2 horizontal press cylinders, double-acting, 80 mm stroke, piston diameter 40 mm Pressure force per cylinder max. 1250 kg Abutment and pressure plate depth 100 mm Control cabinet on the machine base on the left, 400 volts, 50 Hz Machine with ready-to-connect plug 16 A Paint: RAL 7035 light gray with RAL 7016 anthracite gray Working size: length x height = 4,500 mm x 2,750 mm Note: Actual working size: 4,500 x 3,000 mm (length x height) Space required: 5,500 mm x 1,400 mm x 3,550 mm (LengthxWidthxHeight) Article medium pressure bar complete with pressure cylinder, pressure hose and shut-off valve up to 2,750 mm high Note: actual working height: 3,000 mm Article Individual pressure control for medium pressure bar, pressure control range up to max. 100 bar (For pressing cross-bar windows) Article infinitely height-adjustable cross pressure device, complete with pressure cylinder and abutment, throttle and shut-off valve Article Individual pressure control for cross pressure device pressure control range up to max. 100 bar (For pressing cross-bar window) Article Shut-off valve on the 3rd vertical cylinder Gujdpfeyyqnfox Akyec Article Shut-off valve on the upper horizontal cylinder Article Shut-off valve on the lower horizontal cylinder ...

Condition: reconditioned (used), Working width 3500 mm Working height 2550 mm Number of cylinders 6 St. loading dimensions L x W x H 4500x950x2900 mm Hess Speedy frame press ----- will be checked Insertion dimension / pressing length max. 3,500 mm Insertion dimension / pressing height max. 2,550 mm Sliding carriage for width adjustment locking in 50 mm Double hole grid system Electric height adjustment of the long-stroke cylinders (hydraulic) Insertion height of the abutment plates can be preselected in 4 positions 3 vertical printing cylinders stroke 1000 mm Pressure force per cylinder 2000 kN / 20000 N 3 horizontal printing cylinders stroke 80 mm Pressure force per cylinder 1250 kN / 12500 N Printing plate depth 100 mm width 140 mm Grid for cylinder fixation/rear bearing 50 mm Medium pressure beam with shut-off valve Final pressure switch-off and pressure control Control and pressing process in touch button operation Adjustable pressing pressure min. 25 – max. 160 bar Electrical connection 2.2 kW / 400V 3 pendulum pressure plates for studio windows 1 pendulum pressure plate for pointed windows 1 extension for pendulum pressure plate 1 small parts allowance Image and video not original, show identical model Godpfx Asxnqw Tekyjuc ----- (technical data according to the manufacturer - no guarantee!)

Condition: reconditioned (used), Working width 3600 mm Working height 2600 mm Number of cylinders 5 St. loading dimensions L x W x H 4400 x 1150 x 2970 mm weight 3000 kg Schafberger + Sproedhuber Bavaria Frame Press ----- Machine is overhauled by us before delivery. With automatic pressing cycle + manual control for tenon + slot corner joints. CE-certified version Basic machine in the strongest welded frame construction, with thick-walled special hollow profiles. Guideways for the pressure beams for the press corners in a low-wear machined design. Fast, smooth, manual width adjustment Gsdpfew T Un Uex Akysuc via ball-bearing carriages, fixed in a hole pattern. Height adjustment and pressing via long-stroke cylinders in a single work cycle. Right-side press corners with integrated horizontal cylinders, therefore no vertical positioning of the horizontal pressure cylinders necessary, thus avoiding cylinder collisions. Lower abutment adjustable in several positions for the most favorable insertion height. 3 vertical press cylinders, double-acting, stroke adjusted to working height 2 horizontal press cylinders, double-acting Abutment and pressure plate depth 80 mm Working size: Length x Height = approx. 3,600 mm x 2,600 mm Space requirement/loading dimensions: approx. 4,400 mm x 1,150 mm x 2,970 mm (Length x Width x Height) Option: ALWA pressing supports for sloped windows (Technical specifications according to the manufacturer – no guarantee! Images may differ from the original. Prices are net, plus VAT (domestic))

Condition: used, Year of construction: 2003, Working height: 2300 mm, Working width: 3500 mm, Motor: 1.5 kW, 3 pressure cylinders from above, 2 from the side, Pressure per cylinder: 3000 kg, Cylinder stroke: up to 200 mm, Hydraulics: 10-150 bar, Space required: 3950 x 900 x 2550 mm, Weight: 670 kg Storage location: Nattheim Gedpsvvkmbjfx Akyjuc

Condition: good (used), Code: 0119 Brand: KOLMAG - ITALY Gusdpowk Ntzofx Akyjc Model: PGP 600 F Hydraulic press for moulds, frames, furniture elements, solid wood doors, plastic materials, composite materials and various Press modular structure with heavy thick plates without weldings and worked by tool machine Oleodinamic plant with pistons prefilling system in order to have a quick opening and closing of the platens Dimensions of massive steel platens mm 1600 x 500 - Thickness mm 60 with electric resistances - Max temperature 260°. N° 3 pistons diameter mm 240 Pressure kg/cm2 56 Thrust Tonn 450 Safety photocells Hydraulic power unit Kw 7,5 Power absorbed heating platens 31 Kw Control board with pressure control gauge - Timer for platens opening - Telethermometer to regulate upper platen temperature - Telethermometer to regulate lower platen temperature - Switches for opening and closing of the platens - Emergency push button Overall dimensions mm 2250 x 1700 x 3300 h Weight kg 9000

Condition: excellent (used), Year of construction: 1985, functionality: fully functional, The machine is fully operational and in good condition. Working dimensions: 3200 x 2200 mm Dimension adjustment is electrically controlled from the control panel. Godpjxmr Rxsfx Akysuc Powered by a hydraulic unit.

Condition: reconditioned (used), Year of construction: 1995, functionality: fully functional, working width: 3,000 mm, working height: 1,700 mm, Branded used hydraulic press designed for bonding frame structures such as window and door frames. The machine features a robust welded steel frame, constructed from thick-walled closed profiles and heavy-duty I-beams, ensuring high rigidity and strength. It is equipped with a central electro-hydraulic pump operated via a central control panel. The height of the bottom beam is adjustable in 3 positions. Working area dimensions: 3000 x 1700 mm Pump motor power: 2 kW Total pressing force: approx. 14 + 6 tons Overall dimensions: 3800 x 1000 x 2660 mm Weight: approx. 1800 kg Gujdpsvva Izefx Akyec Side-mounted swivel control panel Foot-operated control pedals Light curtain safety barrier

Condition: used, Year of construction: 1982, pressure 40 t distance between columns 695 bzw. 215 mm stroke 100 mm table surface area 650 x 440 mm ram surface 580 x 285 mm dayligth 400 mm total power requirement 15 kW weight of the machine ca. t dimensions of machine L x W x H 1,63 x 1,05 x 2,61 m - with die cushion Gusdpfx Aetqqq Rokyjc - with light bareer make SICK

Condition: used, Year of construction: 1983, Working area: approx. 4500 x 2400 mm 4 vertical cylinders 3 horizontal cylinders Hydraulic operation Gujdpfxozcdm So Akyoc

Condition: not inspected (used), Working width 3500 mm Working height 2500 mm Number of cylinders 5 St. # 6913 Hess Quickstep frame press ----- Sold on behalf of the customer in its current condition Technical data summary (please enquire about any additional accessories included) ----- General ----- Working width: 3500 mm Working height: 2500 mm Features: ----- > hydraulic: yes > Number of vertical press cylinders: 3 > Number of horizontal press cylinders: 2 > Vertical adjustment type: electric (long stroke cylinder) > Horizontal adjustment type: electric > 1 medium pressure bar According to the customer, the control system has been renewed and the hydraulic pump with connections has been renewed Gusdpfx Akoy S Diysyec (technical information according to the manufacturer - no guarantee!)

Condition: used, Hydraulic punch, punch frame for use with JOKA punching units type HP-S Hydraulic hole punch, hydraulic press for punching brackets Year of manufacture: approx. 1995 Gujdpfx Akjltrmujyjc Pressing force: 5 tons Throat depth: 155 mm Stroke: approx. 20 mm Punching unit width: max. 54 mm Punching unit installation height: max. 220 mm Die holder: Ø 48 mm Motor output: 1.5 kW Power supply: 230 Volt, 50 Hz - Suitable for universal use with JOKA SW 20 or SWD 20 punching units - Throat depth of punching units can be larger, can be pushed through to the rear - Stroke release via electric two-hand control - Hydraulic power pack HAWE, type HCW 4 / 2.5-B 1/400-1 - On subframe, mobile Required space (L x W x H): 1100 x 800 x 1450 mm Weight: approx. 200 kg Good condition

Condition: used, Single-column hydraulic press MAE type S63SZ SO . 551277 Year of manufacture approx. 1977 Nominal pressing force: 63 tons Pressing force: 50 tons (practically tested) Throat depth: 320 mm Table area: 850 x 630 mm Ram area: 1050 x 500 mm Ram stroke: 500 mm Max. installation height: approx. 730 mm Table height above floor: 970 mm Hydraulic tank capacity: 600 liters Drive power: 15 kW Power supply: 380 Volt, 50 Hz - Hydraulic draw cushion below the table with bores through the tabletop - Two-hand operation Godpfx Aedzp Trskyouc - Electrical control cabinet damaged Required space (L x W x H): 2000 x 1200 x 3420 mm Weight approx. 5 tons The machine is operational, the control cabinet is mechanically damaged. During test run, the machine achieves a pressing force of 50 tons, presumably a pressure relief valve is venting.

Condition: used, Single-column toggle press MAY - MAYPRES - KOMATSU Type MKN 1-63/6 Eccentric toggle press, eccentric press Year of manufacture approx. 1984 Pressing force 60 tons Thrust 160 mm Table size 580 x 360 mm Ram surface Ø 270 mm Clamping pin bore Ø 40 mm Distance between columns 218 mm Ram stroke 60 mm Ejector stroke 15 mm Ram adjustment travel 30 mm Max. installation height 300 mm (with intermediate table plate) Stroke rate 70 strokes per minute Motor speed 1400 rpm Motor power 3 kW Power supply 380 V, 50 Hz - Pneumatic clutch and mechanical brake with pneumatic release (separate clutch-brake combination) - Table intermediate plate L x W x H 580 x 360 x 58 mm, with holes and cutouts - Mechanical ejector, ejector device in the machine table, Ø 80 mm - Electric two-hand control and foot switch - Movable safety screen, UNIDOR protective housing with pneumatic front screen - BALLUFF cam switch Space requirement L x W x H 1400 x 1200 x 1850 mm Gujdpfx Akev Uraajyec Weight 3 tons Good condition

Condition: new, Year of construction: 2023, Pressing area: 3000 mm x 1800 mm Number of manual hydraulic cylinders vertical: 4 Number of manual hydraulic cylinders horizontal: 2 Gjdpfjiwfhwsx Akyjuc Press pressure: 1500 kg Machine length: 4000 mm Machine width: 750 mm Machine height: 2250 mm

Condition: excellent (used), Year of construction: 1991, functionality: fully functional, power: 11 kW (14.96 HP), input voltage: 200 V, pressing force: 160 t, table length: 600 mm, overall weight: 19,000 kg, punching force: 160 t, height adjustment type: electric, installation height: 1,900 mm, ram adjustment: 100 mm, stroke adjustment: 130 mm, Equipment: documentation/manual, safety light barrier, Manufacturer: AIDA Type: NC2-160 Gujdpfx Akou D Dhxeyoc Push force: 160t Year of manufacture: approx. 1991 Stroke length: 130mm Distance above table: (adjustable) 285-335mm Table size: 1900x600mm Bear size: 1360x585mm Electric power: 3x200V(!!), 15kW - Japanese standard Net weight: 19000kg Size: 2140x2210x3175mm Automatic greasing system. Optionally sheet feeder winder and straightener.

Condition: new, Working width 4000 mm Working height 2600 mm Number of cylinders 6 St. Dimensions (L/W/H) 5300 x 1250 x 3330 mm S&S frame press type RP 2000, ----- C E - version Stable frame welded construction made of thick-walled special hollow profiles, Sliding carriage and pressure bar with 50 mm hole pattern. Continuous abutment on the left for width compression, lower abutment in two levels. Vertical press cylinder on special pressure bar with one-hand quick adjustment with weight compensation in the 50 mm hole pattern, height-adjustable, long Sliding carriages ensure the permanent absorption of high pressing forces. Fast, smooth width adjustment with ball-bearing carriage Central locking, fixation in 50 mm hole pattern. Upper horizontal press cylinder infinitely adjustable in height and with Equipped with counterbalance. Lower horizontal press cylinder with center holes for the two Abutment levels, with weight compensation. Abutment and pressure plate depth 100 mm Printing plate and support width 130 mm Machine electro-hydraulically controlled, with 2 vertical pressure cylinders d = 50 mm, stroke 120 mm double-acting, with counterweight and One-hand quick adjustment, 2 pieces Horizontal pressure cylinders d = 40 mm, stroke 120 mm double-acting, with weight balancing; 2 manual control valves, Pressure gauge, 1 pressure control valve from 20 to 125 bar corresponds to 400 to 2400 kg pressure vertical, with 3 kW three-phase motor for 400 volts, 50 Hz operating voltage. Complete with electrical connection. Paint finish: RAL 7035 light gray with RAL 7016 anthracite grey Working size: 4000mm x 2600mm (length x height) Required space: 5300 x 1250 x 3330 mm (L x W x H) Machine including the following options: ----- Article .00 pc Medium pressure bar with pressure cylinder double-acting, weight compensation, pressure hose and shut-off valve up to 2600 mm high Article .00 pc Individual pressure control for medium pressure bar, Pressure control range up to max. 100 bar (for pressing crossbar windows) Article .00 pc Cross printing device complete with pressure cylinder double-acting, weight compensation, pressure hose and shut-off valve There is no weight compensation on the lower horizontal cylinder Article .00 pc Individual pressure control for transverse pressure device, Pressure control range up to max. 100 bar (for pressing crossbar windows) Article .00 pc Shut-off valve on the 3rd vertical cylinder Article .00 pc Shut-off valve on the upper horizontal cylinder Article .00 pc Width allowance for compression of small frames to bridge the 1st pressure beam, including shut-off valve on the 1st vertical cylinder Article .00 pc Basic equipment for counter profiles The space required in height increases by 100 mm Item All pressure plates and abutments covered with plastic Article .00 pc Triangle studio window pressing device consisting of: locking device of Vertical pressure bar and 3 attachable, side-guided pendulum pressure plates Article .00 pc double pendulum pressure plate for pointed windows (triangle) ----- Gjdju Uvalepfx Akysuc Total price in the above version ex works: On request! ----- Options: Article ....

Condition: new, Year of construction: 2025, functionality: fully functional, ACTION M frame press Press for any kind of window system: windows, slatted shutters, shutters and solid wood doors. Max working dimensions L x H 3500x2500 mm Min working dimensions L x H 250x375 mm Max vertical/horizontal thrust 7,4/2 ton Working height 480/1050 mm Hydraulic pump power 2.1 kW MACHINE COMPOSITION: Guodpfewh T Dlox Akyjc ACTION M ACTION M FRAME PRESS num 1 109831 Normative CE per SM 1 R00494 action m 35-25 1 930731 Volt 400 EU 1 931201 Frequency 50 Hz 1 530074 PVC-coated beams working surfaces 1 530075 Intermediate manual crossbeam complete of piston and counter-stop 1 530076 Hydraulic system for low pressure working 1 530077 Equipment for trapezoidal products with oscillating head to adapt to the different corners of the windows system 1

Condition: excellent (used), For sale: Hofer press in good working condition. Guodjx Rrw Njpfx Akyec

Condition: excellent (used), Year of construction: 2007, Window fitting press Gujdpfx Ajt T Srpskyoc

Condition: used, Year of construction: 1997, machine/vehicle number: 15109, functionality: fully functional, power: 1 kW (1.36 HP), Equipment: CE marking, I am selling a RAMARCH PN31 frame press. Year of manufacture: 1997. Maximum workpiece dimensions: 2500 x 1300 x 600 mm. Guedpfslu Hhcsx Akyjc Electropneumatic operation. Manufacturer: RAMARCH, Spain (now DYNMA). In good condition. Available immediately.

Condition: excellent (used), working length 3300 mm working height 1800 mm 3 vertical cylinders 2 horizontal cylinders Guedpfx Aoy Uuwaekyoc manual operating mode

Condition: like new (used), Year of construction: 2026, pressing force: 20 t, For sale is a C-frame assembly and small-series production press from the manufacturer DURENDUS with a maximum pressing force of 20 tons. The machine has a table size of 700 × 920 mm, a maximum installation height of 550 mm, and a stroke of 400 mm, making it suitable for assembly work, small-series production, pressing operations, and straightening processes in industrial applications. ##### Technical data + information: C-frame assembly and small-series production press – 20 tons – 700 × 920 mm ==== General information - Design: C-frame / single-column press - Manufacturer: DURENDUS - Pressing force: 5–20 tons (adjustable) - Maximum installation height: 550 mm - Table size: 700 × 920 mm - Press head: Ø 100 mm - Table height above the ground: 1,000 mm - Overall dimensions (W x D x H): 900 × 900 × 2,340 mm - Total weight: approx. 1,200 kg - T-slots: DIN 650 – 22 mm or according to customer requirements - Forklift pockets: available - Press area lighting: available ==== Hydraulic cylinder - Stroke: 0–400 mm (adjustable) - Cylinder diameter: Ø 110 mm - Piston rod diameter: Ø 65 mm - Maximum working pressure: 280 bar - Return speed: 50 mm/s - Working speed: 10 mm/s - Idle speed: 10 mm/s - Pressure build-up time: max. 2 sec. (steel on steel) ==== Hydraulics & drive - Hydraulic pump: ASC - Delivery rate: 24 l/min - Motor power: 3 kW - Pressure accuracy: ±5 bar - Tank volume: 60 l - Valve technology: DUPLOMATIC - Filter technology: FILTREC Guedpfx Akey Sx Uwsyjc - Oil level monitoring: electronic - Cooling: oil-air cooling - Hydraulic unit: mounted at the top rear ==== Control system - Operation: foot pedal or hand lever - Pressure setting: via rotary control - Stroke limitation: via adjustable sensors - Selector switch: foot / hand operation - Switch cabinet components: mostly SIEMENS ==== Safety - Emergency stop switch - Stroke limitation - Stable steel construction - CE-compliant design ==== Electrical connection - Main supply: 400 V AC - Control voltage: 24 V DC - Frequency: 50 Hz - Main motor connection power: 3 kW - Total connection power: max. 5 kW ##### Application areas: Assembly work, small-series production, pressing, straightening, toolmaking, fixture construction, metalworking, maintenance, workshop operations, service applications (Hydraulic press, C-frame press, single-column press, assembly press, small-series production press, workshop press, 20-ton press, pressing press, straightening press, industrial press, C-frame press) Are you looking for a hydraulic press tailored to your specific application? Contact us for an individual offer. Our hydraulic presses are manufactured according to German Machinery Directives and European Machinery Directives (Directive 2006/42/EC), EC standards, and EU safety regulations. Furthermore, our presses exceed Canadian and European safety requirements as they meet all aspects of the national Brazilian safety regulation NR 12, which is based on these. Our strength lies in the design and construction of special machines and press automation. We distribute customized hydraulic presses at surprisingly affordable prices. The hydraulics of the presses predominantly use components from leading European manufacturers.

Condition: used, Year of construction: 1989, Capacity: 80 ton Throat depth: 280 mm Ram stroke: 8 - 140 mm Slide adjustment: 100 mm Shut height (stroke down, adjustment up): 520 mm Table surface area : 850 x 670 mm Slide area: 550 x 400 mm Hole in table: 250 x 180 mm Number of strokes: 20 - 100 s.p.m. Required power: 7,5 kW Dimensions L x W x H: 2210 x 1510 x 2750 mm Oil volume: 50 l Guodey Hqz Sepfx Akyjc Die weight at the ram max.: 300 kg Weight of machine approx.: 8,3 ton

Condition: used, Year of construction: 2009, machine/vehicle number: 184, functionality: fully functional, input voltage: 400 V, type of input current: three-phase, overall weight: 4,400 kg, We offer a used FAMAD HSKG 6.6 hydraulic press, manufactured in 2009. Type: HSKG 6.6 Factory number: 184 Year of manufacture: 2009 - 4 loading stations - loading height: 1140 mm - length of strips in one station: 2200 mm - maximum strip width: 150 mm - maximum length of glued elements: 6600 mm The press is in good working order and fully functional. It can be inspected while in operation. Net price is negotiable (invoice available). Weight: ~4400 kg Type of current: ~ Frequency: 50 Hz Operating voltage: 3 x 400 V Control voltage: 24 V Power: 4.0 kW Nominal current: 8.9 A Godpfx Akjy Th E Ueyouc If you have any questions or require further information, please send a message or contact us by phone.
