Used Hydraulic Valve for sale (21,216)

Condition: used, Year of construction: 1985, sheet width 3100 mm plate thickness 4.0 mm thickness at "Niro-steel" 2.5 mm Lhsdpfx Ajxab Tvsfuel cutting angle adjustment 1.0 ° back stop - adjustable 10 - 1000 mm adjustment speed 180 mm/s down holder 21 Stück strokes per minute 18 - 31 oil volume 160 L Control ELGO P8511 column arm 200 mm distance between columns 3050 mm 0 max. 300 bar voltage 400 V main drive 9.0 kW weight of the machine ca. 4800 kg. dimensions of the machine ca. 3660 x 2070 x 2140 mm from a maintenance workshop Equipment: - electro-hydraulic sheet metal shear "swing cut" - machine frame = all-steel welded construction - ELGO NC control model P8511, control panel at the front left * for positioning the electro-motoric rear stop * target/actual position value input possible * adjustment by three-phase motor via toothed belt - support table with ball rollers * there are recessed grips between the table plates - front finger guard - hydraulically acting sheet metal hold-down device - 1x freely movable foot switch - emergency stop button at the front - movable scrap switch - original operating instructions + circuit diagram Special accessories included: - EHT pneumatic sheet metal holding device for thin sheet metal cuts - 1x EHT extra long side stop 3.000 mm with mm scale & support foot - 1x EHT extra long support arm with 3.000 mm with scale & Support foot - EHT additional support arms with mm scale

Condition: new, sheet width 3100 mm plate thickness 13,0 mm thickness at "Niro-steel" 8,0 mm down holder 14 Stück no. of strokes 11 Hub/min oil volume 310 ltr. cutting angle 2,0 ° throat 350 mm table height 900 mm total power requirement 22,0 kW weight of the machine ca. 12200 kg range L-W-H ca. 4100 x 2300 x 2235 mm ----- heavy electr. / hydraulic CNC swing cut shears * with CYBELEC CNC touch screen control * with electr. / hydr. Kerf adjustment ----- Furnishing: - CNC electr. / hydraulic swing cut shears - CYBELEC CNC touch screen controller, model CybTouch 8 * Backgauge preselection - X axis * Cutting gap adjustment * Number of pieces * Cutting length limitation * Material preselection, including sheet thickness * Cutting line lighting - motorized backgauge, travel = 1,000 mm (X axis) * on ball screws * autom. Can be folded up at vel, for longer cuts - 1x side stop Lhsdpfx Asxaa U Sjfuel - 2x front support arms - Ball casters in the front support table - hinged finger protection, with safety switch - BOSCH / HOERBIGER hydraulic system - SIEMENS electrical system - light barrier behind the machine (safety device) - foot switch - CE mark / declaration of conformity - User manual: machine and control in German

Condition: new, sheet width 3100 mm plate thickness 10,0 mm thickness at "Niro-steel" 6,0 mm down holder 14 Stück Ledpexabdbefx Afujhl no. of strokes 13 Hub/min oil volume 260 ltr. cutting angle 2,0 ° throat 350 mm engine output 22,0 kW back stop - adjustable 1.000 mm weight 10.575 kg. range L-W-H 4,05 x 2,5 x 2,17 m ----- heavy electr. / hydraulic CNC swing cut shears * with CYBELEC CNC touch screen control * with electr. / hydr. Kerf adjustment ----- Furnishing: - CNC electr. / hydraulic swing cut shears - CYBELEC CNC touch screen controller, model CybTouch 8 * Backgauge preselection - X axis * Cutting gap adjustment * Quantity * Cutting length limitation * Material preselection, including sheet thickness * Cutting line lighting - motorized backgauge, travel = 1,000 mm (X axis) * on ball screws * autom. Can be folded up at vel, for longer cuts - 1x side stop - 2x front support arms - Ball rollers in the front support table - hinged finger protection, with safety switch - BOSCH / HOERBIGER hydraulic system - SIEMENS electrical system - light barrier behind the machine (safety device) - foot switch - CE mark / declaration of conformity - User manual: machine and control in German

Condition: new, sheet width 2100 mm plate thickness 6,0 mm ST 42 thickness at "Niro-steel" 4,0 mm VA cutting angle 1,2 Grad no. of strokes 28 Hub/min oil volume 150 ltr. down holder 11 Stück control CYBELEC CybTouch engine output 11,0 kW back stop - adjustable 1.000 mm table height 800 mm weight 4.500 kg range L-W-H 3.010 x 2.100 x 1.640 mm ----- electr. / hydraulic CNC swing cut shears * with CYBELEC CNC touch screen control * with electr. / hydr. Kerf adjustment ----- Furnishing: - CNC electr. / hydraulic swing cut shears - CYBELEC CNC touch screen controller, model CybTouch 8 * Backgauge preselection - X axis * Cutting gap adjustment * Quantity * Cutting length limitation Ledpfxoxaa Aco Afushl * Material preselection, including sheet thickness * Cutting line lighting - motorized backgauge, travel = 1,000 mm (X axis) * on ball screws * autom. Can be folded up at vel, for longer cuts - 1x side stop - 2x front support arms - Ball casters in the front support table - hinged finger protection, with safety switch - BOSCH / HOERBIGER hydraulic system - SIEMENS electrical system - light barrier behind the machine (safety device) - foot switch - CE mark / declaration of conformity - User manual: machine and control in German

Condition: new, sheet width 3100 mm plate thickness 6,0 mm distance between columns 3.100 mm down holder 14 Stück no. of strokes 16 - 24 Hub/min oil volume 150 ltr. cutting angle 0,5 - 1,5 ° thickness at "Niro-steel" 4,0 mm column arm 350 mm engine output 11,0 kW weight of the machine ca. 7.060 kg range L-W-H 4100 x 2200 x 2190 mm ----- electr. / hydraulic CNC guillotine shears - guided by a backdrop * with CYBELEC CNC touch screen control * with electr. / hydr. Cutting gap and cutting angle adjustment ----- Furnishing: Lhjdpfx Afsxaag Usujl - CNC guiding guillotine shears - with electr. / hydr. Cutting gap and cutting angle adjustment - CYBELEC CNC touch screen controller, model CybTouch 8 * Backgauge preselection - X axis * Cutting gap adjustment * Number of pieces * Cutting length limitation * Material preselection, including sheet thickness * Cutting line lighting - motorized backgauge, travel = 1,000 mm (X axis) * on ball screws * autom. Can be folded up at vel, for longer cuts - 1x side stop - 2x front support arms - Ball rollers in the front support table - hinged finger protection, with safety switch - BOSCH / HOERBIGER hydraulic system - SIEMENS electrical system - light barrier behind the machine (safety device) - foot switch - CE mark / declaration of conformity - User manual: machine and control in German

Condition: used, Year of construction: 1982, sheet width - max. 1255 mm plate thickness 4.0 mm ST plate thickness 2.0 mm VA plate thickness 6.0 mm ALU number of strokes - loaded ~ 66 Hübe/min. cutting angle 1.5 ° back stop - adjustable max. ~ 1.000 mm total power requirement 5.5 kW weight of the machine ca. 2600 kg. range L-W-H 1750 x 1800 x 1800 mm Machine from a technical college - prototype construction very well-maintained condition (!!) Furnishing: - electro-hydraulic guillotine shears - manual backgauge with analogue position display (scale + magnifying glass) - electrical cutting length limitation - manual cutting gap adjustment - 1x extra long side stop - 2x extra long support arms - 1x free moving footswitch Lhsdpfxoxaa I Se Afuol - rear sheet metal slide - User manual (PDF) * Machine link : ?machineno=1008-9325278

Condition: new, sheet width 3100 mm plate thickness 6,0 mm thickness at "Niro-steel" 4,0 mm down holder 14 Stück no. of strokes 20 Hub/min cutting angle 1,2 ° control CYBELEC CybTouch work height max. 800 mm oil volume 150 ltr. total power requirement 11,0 kW weight 5500 kg range L-W-H 4.000 x 2.410 x 1.640 mm ----- electr. / hydraulic CNC swing cut shears * with CYBELEC CNC touch screen control * with electr. / hydr. Kerf adjustment ----- Furnishing: - CNC electr. / hydraulic swing cut shears - CYBELEC CNC touch screen controller, model CybTouch 8 * Backgauge preselection - X axis * Cutting gap adjustment * Quantity * Cutting length limitation * Material preselection, including sheet thickness * Cutting line lighting - motorized backgauge, travel = 1,000 mm (X axis) * on ball screws * autom. Can be folded up at vel, for longer cuts - 1x side stop - 2x front support arms - Ball casters in the front support table - hinged finger protection, with safety switch Lsdpsxaa Rgefx Afuohl - BOSCH / HOERBIGER hydraulic system - SIEMENS electrical system - light barrier behind the machine (safety device) - foot switch - CE mark / declaration of conformity - User manual: machine and control in German

Condition: new, sheet width 4100 mm plate thickness 10,0 mm thickness at "Niro-steel" 6,0 mm down holder 28 Stück no. of strokes 18 Hub/min oil volume 260 ltr. cutting angle 0,5 - 2 ° control CYBELEC Cybtouch engine output 22,0 kW back stop - adjustable 1000 mm range L-W-H 6100 x 2580 x 2460 mm weight 15.100 kg. ----- electr. / hydraulic CNC guillotine shears - guided by a backdrop * with CYBELEC CNC touch screen control * with electr. / hydr. Cutting gap and cutting angle adjustment ----- Furnishing: - CNC guillotine guillotine shears - with electr. / hydr. Cutting gap and cutting angle adjustment - CYBELEC CNC touch screen controller, model CybTouch 8 Lodpfx Aexabwujfuohl * Backgauge preselection - X axis * Cutting gap adjustment * Number of pieces * Cutting length limitation * Material preselection, including sheet thickness * Cutting line lighting - motorized backgauge, travel = 1,000 mm (X axis) * on ball screws * autom. Can be folded up at vel, for longer cuts - 1x side stop - 2x front support arms - Ball rollers in the front support table - hinged finger protection, with safety switch - BOSCH / HOERBIGER hydraulic system - SIEMENS electrical system - light barrier behind the machine (safety device) - foot switch - CE mark / declaration of conformity - User manual: machine and control in German including special equipment: - pneumatic sheet metal holding device * Monoblock design

Condition: used, Year of construction: 1990, plate width 2503 mm plate thickness 4.0 mm ST plate thickness 2.5 mm VA plate thickness 6.0 mm ALU number of strokes - loaded 15 - 20 Hübe/min cutting angle 1.7 ° work height max. 900 mm Control ELGO TYP 85 total power requirement 8.5 kW weight of the machine ca. 3400 kg range L-W-H 2913 x 2250 x 1760 mm Features: - Robust NC electro-hydraulic guillotine shear - NC electro-motorized backgauge * with ELGO control unit - Manual cutting gap adjustment - Front support table including recessed grips Lhjdjxabd Uepfx Afuol - 1x sturdy side stop with scale and tilting cam - 2x sturdy front support arms - 1x freely movable foot switch - Front finger guard - Front emergency stop button - Operating instructions (PDF)

Condition: new, sheet width 3100 mm plate thickness 13,0 mm thickness at "Niro-steel" 8,0 mm down holder 14 Stück no. of strokes 11 - 20 Hub/min oil volume 310 ltr. cutting angle 0,05 - 2,0 ° throat 350 mm table height 900 mm total power requirement 22,0 kW weight of the machine ca. 13.300 kg range L-W-H 5.110 x 2.570 x 2.400 mm ----- heavy electr. / hydraulic CNC guillotine shears - guided by a backdrop * with CYBELEC CNC touch screen control * with electr. / hydr. Cutting gap and cutting angle adjustment ----- Furnishing: - CNC guillotine guiding shears - with electr. / hydr. Cutting gap and cutting angle adjustment - CYBELEC CNC touch screen controller, model CybTouch 8 * Backgauge preselection - X axis * Cutting gap adjustment * Number of pieces * Cutting length limitation * Material preselection, including sheet thickness * Cutting line lighting - motorized backgauge, travel = 1,000 mm (X axis) * on ball screws * autom. Can be folded up at vel, for longer cuts Lhsdpexabikjfx Afuol - 1x side stop - 2x front support arms - Ball casters in the front support table - hinged finger protection, with safety switch - BOSCH / HOERBIGER hydraulic system - SIEMENS electrical system - light barrier behind the machine (safety device) - foot switch - CE mark / declaration of conformity - User manual: machine and control in German

Condition: used, pressure 100 t punching cross-cut in cmm Ø 31 in 25 mm stroke 10 - 50 mm column arm 510 mm work height max. 1100 mm no. of strokes 14 - 45 Hub/min punch diameter max. Ø 90.0 mm oil volume 103 l total power requirement 7.5 kW Ljdsxabrfepfx Afuohl weight of the machine ca. 2400 kg. range L-W-H 1750 x 1020 x 2050 mm maintained condition (!!) New price without accessories approx. 25.000 euros Special price on request Furnishing: - heavy / robust electro-hydraulic hole punch, with large throat - Punching station with material/sheet metal scraper - stepless stroke adjustment .. 10-50 mm - freely movable foot switch including protective cover - hydraulic low pressure finder for foot switch operation - Crane hanging eye for easy transport - side storage area - Hydraulic unit, integrated - Three-phase motor, 400 volts, 50 Hz - original instruction manual

Condition: used, Year of construction: 2008, sheet width 4100 mm plate thickness 6.0 mm thickness at "Niro-steel" 4.0 mm no. of strokes 12 - 24 Hub/min cutting angle 1 ° 30 work height max. 865 mm back stop - adjustable 1.0 - 1000 mm down holder 20 Stück Control ENC 100 M column arm 50.0 mm oil volume 200 ltr total power requirement 15.0 kW range L-W-H 5230 x 2250 x 2150 mm weight 11460 kg New price ~ 50,000 euros (!!) Special price on request ----- NC electro-hydraulic swing cut shears * with DURMA "ENC 100 M" control * manual cutting gap adjustment (eccentric) * including pneumatic sheet holding device for thin sheet metal cuts ----- Equipment: - robust electro-hydraulic swing cut shears - including DURMA "ENC 100M" NC control unit Lhsdpfx Afow U U T Teuel * Back stop pre-selection - X axis * Quantity * Cutting length limitation * Pivoting operation, left front - Monoblock welded steel construction made of high-quality steel - CNC electro-motorized back stop * with ball screw and linear guides * Automatic retraction of the back stop during the cutting process - Light barrier protection for access to the rear of the machine - manual cutting gap adjustment via eccentric - high-performance hydraulic cylinder made of SAM 1040 material - high-quality chrome-plated and finely ground hydraulic piston - split, fold-up finger guard 1,000 mm - easy handling of the sheets via ball rollers in the table - 1x long side stop including mm scale and tilting cam - 3x front support arms - 1x freely movable foot switch - operating instructions Special accessories included: - pneumatic sheet holding device for cutting thin sheet metal - up to max. material thickness - ST .. 3.0 mm

Condition: used, Year of construction: 2008, sheet width 3100 mm plate thickness 13.0 mm thickness at "Niro-steel" 8.0 mm down holder 14 Stück no. of strokes 11 - 20 Hub/min oil volume 310 ltr. cutting angle 0.05 - 2.0 ° throat 350 mm table height 900 mm total power requirement 22.0 kW weight of the machine ca. 13400 kg range L-W-H 5.110 x 2.570 x 2.400 mm Current new price approx. 80.000 Euro Special price upon request - in checked conditions - machinevideo - ?v=K4ymYMIJ7_Y Lhsdpfxoxaadas Afusl ----- Robust electro-hydraulic CNC sheet metal shear with slide guides * Includes CYBELEC "DNC 60 CUT" control system * Includes CNC electro-hydraulic cutting gap adjustment * Includes CNC electro-hydraulic cutting angle adjustment ----- Equipment: - CNC electro-hydraulic guillotine shear with slide guides - Includes CYBELEC CNC controller, model "DNC 60" - CNC electro-motorized backgauge, travel range = 5.0 - 1,000 mm (X axis) * On recirculating ball screws * Automatically folds up at maximum travel, for longer cuts * Includes selectable retraction function ("swing-away function") * Positioning accuracy 0.1 mm * Approx. travel speed 80.0 mm/sec. - Electro-hydraulic cutting angle adjustment - Electro-hydraulic cutting gap adjustment - 1x side stop with T-slot and mm scale - 2x front support arms with T-slot and mm scale - Ball transfer units in the front support table - Hinged finger guard with safety switch - BOSCH/HOERBIGER hydraulic system - SIEMENS electrical system - Light curtain behind the machine (safety device) - Rear sheet chute (sheet inserts) - 1x freely movable foot switch - CE mark - Operating instructions

Condition: good (used), Year of construction: 2010, sheet width 4100 mm plate thickness 6.35 mm thickness at "Niro-steel" 4.00 mm cutting angle 0.5 - 2.5 ° cutting gap adjustment 0.05 - 0.8 mm no. of strokes 9 - 26 Hub/min back stop - adjustable 10.0 - 750 mm down holder 22 Stk. oil volume 200 ltr. engine output 7.5 kW weight 8000 kg. range L-W-H 5145 x 2200 x 1750 mm From a maintenance workshop Very well-maintained / good condition With very few operating hours (!!) Current list price approx. 60.000 euros Special price upon request Features: - Robust electro-hydraulic, slide-guided sheet metal shear - LVD control panel centrally located on the front of the machine (left) - Electro-hydraulic cutting angle adjustment * Includes digital display of actual values - Manual cutting gap adjustment * via handwheel from the front (left) * Includes analog value display - Electro-motorized backgauge with ball screws * Includes digital actual position display * Rapid traverse is possible - 1x extra-long side stop 3,000 mm, with support foot - 1x long support arm - Ball-bearing recessed handles in the support table - Front finger guard - Rear sheet metal chute Lhodpfx Afezcqy Sjuel - Safety device - rear (protective grille) - 1x freely movable foot switch - Machine lighting at the front (custom-built) - Operating instructions

Condition: new, sheet width 2600 mm plate thickness 8,0 mm thickness at "Niro-steel" 5,0 mm down holder 12 Stück no. of strokes 18 Hub/min oil volume 200 ltr. cutting angle 1,5 ° engine output 15,0 kW weight of the machine ca. 6.300 kg range L-W-H 3525 x 2350 x 1700 mm ----- electr. / hydraulic CNC swing cut shears * with CYBELEC CNC touch screen control * with electr. / hydr. Kerf adjustment ----- Furnishing: - CNC electr. / hydraulic swing cut shears - CYBELEC CNC touch screen controller, model CybTouch 8 * Backgauge preselection - X axis Lsdpfx Afexab D Ioujhl * Cutting gap adjustment * Quantity * Cutting length limitation * Material preselection, including sheet thickness * Cutting line lighting - motorized backgauge, travel = 1,000 mm (X axis) * on ball screws * autom. Can be folded up at vel, for longer cuts - 1x side stop - 2x front support arms - Ball casters in the front support table - hinged finger protection, with safety switch - BOSCH / HOERBIGER hydraulic system - SIEMENS electrical system - light barrier behind the machine (safety device) - foot switch - CE mark / declaration of conformity - User manual: machine and control in German

Condition: new, sheet width 4100 mm plate thickness 6,0 mm thickness at "Niro-steel" 4,0 mm down holder 18 Stück no. of strokes 15 Hub/min oil volume 150 ltr. cutting angle 1,2 ° control CYBELEC Cybtouch back stop - adjustable 1000 mm work height max. 800 mm engine output 11,0 kW weight 8.100 kg. range L-W-H 5000 x 2410 x 1650 mm ----- electr. / hydraulic CNC swing cut shears * with CYBELEC CNC touch screen control * with electr. / hydr. Kerf adjustment ----- Furnishing: - CNC electr. / hydraulic swing cut shears - CYBELEC CNC touch screen controller, model CybTouch 8 * Backgauge preselection - X axis * Cutting gap adjustment * Quantity * Cutting length limitation * Material preselection, including sheet thickness * Cutting line lighting - motorized backgauge, travel = 1,000 mm (X axis) * on ball screws * autom. Can be folded up at vel, for longer cuts - 1x side stop - 2x front support arms - Ball casters in the front support table - hinged finger protection, with safety switch Lhsdpfxoxaa R To Afuel - BOSCH / HOERBIGER hydraulic system - SIEMENS electrical system - light barrier behind the machine (safety device) - foot switch - CE mark / declaration of conformity - User manual: machine and control in German

Condition: new, sheet width 3100 mm plate thickness 6,0 mm Ljdpfxoxaa D He Afushl thickness at "Niro-steel" 4,0 mm distance between columns 3100 mm down holder 14 Stück oil volume 150 ltr. no. of strokes 18 Hub/min cutting angle 1,2 ° control CYBELEC CybTouch total power requirement 11,0 kW weight 6300 kg range L-W-H 4.000 x 2.100 x 1.640 mm ----- electr. / hydraulic CNC swing cut shears * with CYBELEC CNC touch screen control * with electr. / hydr. Kerf adjustment ----- Furnishing: - CNC electr. / hydraulic swing cut shears - CYBELEC CNC touch screen controller, model CybTouch 8 * Backgauge preselection - X axis * Cutting gap adjustment * Quantity * Cutting length limitation * Material preselection, including sheet thickness * Cutting line lighting - motorized backgauge, travel = 1,000 mm (X axis) * on ball screws * autom. Can be folded up at vel, for longer cuts - 1x side stop - 2x front support arms - Ball casters in the front support table - hinged finger protection, with safety switch - BOSCH / HOERBIGER hydraulic system - SIEMENS electrical system - light barrier behind the machine (safety device) - foot switch - CE mark / declaration of conformity - User manual: machine and control in German including special equipment: - pneumatic sheet metal holding device

Condition: used, Year of construction: 2015, sheet width 3080 mm plate thickness 16.0 mm thickness at "Niro-steel" 12.0 mm no. of strokes 7 - 12 Hub/min Lhedpoxab Ruofx Afusl cutting angle 0.5 - 2.5 ° back stop - adjustable max. 1000 mm traversing speed 200 mm/sek down holder 14 Stück work height max. 840 mm Column width 3420 mm throat 350 mm Control D-Touch 7 oil volume 450 l voltage 400 V engine output 45.0 kW weight 18150 kg range L-W-H 4130 x 2210 x 2570 mm Good / well-maintained condition (!!) New price ~ €120.000 Special price upon request Features: - Robust electro-hydraulic sheet metal shear ("guided") - CNC control unit D-Touch 7 ("touchscreen") * Anti-reflective robust 7" color touchscreen control panel * Easy positioning to the desired size * Positioning accuracy 0.1 mm * Unlimited material definition in the material library * Intuitive menu navigation * Separate display for actual and target values * Backgauge retraction function * Cutting length control via adjustable stroke length * Cut counter * Automatic machine stop when the programmed cuts are reached - CNC electro-motorized adjustable backgauge * Travel range max. 1,000 mm * Backgauge adjustment via ball screws and linear guides - CNC electro-motorized cutting gap adjustment - CNC Electro-hydraulic cutting angle adjustment - Heavy-duty welded steel construction - Ergonomically positioned and clearly laid-out control panel - Hold-down clamp positioned close to the cutting edge - Front light barrier (instead of finger guard) - Self-regulating hold-down clamp pressure - Rear safety device (light barrier) - 1x side stop (L = 1,500 mm) - 2x support arms (L = 1,000 mm each) - Wide sheet supports with ball transfer rollers - Mobile foot switch with emergency stop function - High-quality, regrindable blades (split) - Rear sheet chute - Original operating instructions

Condition: new, sheet width 3100 mm plate thickness 6,0 mm distance between columns 3.100 mm down holder 14 Stück no. of strokes 16 - 24 Hub/min oil volume 150 ltr. cutting angle 0,5 - 1,5 ° thickness at "Niro-steel" 4,0 mm column arm 350 mm engine output 11,0 kW weight of the machine ca. 7.060 kg range L-W-H 4,1 x 2,2 x 2,19 m ----- electr. / hydraulic CNC guillotine shears - guided by a backdrop * with CYBELEC CNC touch screen control * with electr. / hydr. Cutting gap and cutting angle adjustment ----- Furnishing: - CNC guillotine guillotine shears - with electr. / hydr. Cutting gap and cutting angle adjustment - CYBELEC CNC touch screen controller, model CybTouch 8 * Backgauge preselection - X axis * Cutting gap adjustment * Number of pieces * Cutting length limitation * Material preselection, including sheet thickness * Cutting line lighting - motorized backgauge, travel = 1,000 mm (X axis) * on ball screws * autom. Can be folded up at vel, for longer cuts - 1x side stop - 2x front support arms - Ball rollers in the front support table - hinged finger protection, with safety switch - BOSCH / HOERBIGER hydraulic system - SIEMENS electrical system - light barrier behind the machine (safety device) - foot switch Lsdsxabcqspfx Afuehl - CE mark / declaration of conformity - User manual: machine and control in German including special equipment: - pneumatic sheet metal holding device

Condition: new, pressure 30 t stroke 150 mm table surface area 185 mm Breite column travel between the guideways 530 mm weight of the machine ca. 162 kg Lhedpfxexabg Nj Afujl dimensions of the machine ca. 800 x 700 x 1805 mm

Condition: new, pressure 20,0 t stroke 185 mm table surface area 170 mm Breite column travel between the guideways 510 mm weight of the machine ca. 112 kg dimensions of the machine ca. 1630 x 560 x 730 mm Furnishing: - Standard with pressure cylinder that can be moved to the left and right - For aligning, pressing, bending, assembling gears, discs, etc. - Standard with foot pedal and hydraulic hand pump for piston delivery - Standard with support prism for aligning shafts - With automatic piston retraction by integrated return spring as standard - Height-adjustable press table with locking bolts Lhodpfx Afoxaapcouel - Large manometer for reading the compressive force - Including two-stage hydraulic pump - Robust construction with welded steel frame

Condition: used, Year of construction: 1999, sheet width 3060 mm plate thickness 8.0 mm thickness at "Niro-steel" 6.0 mm distance between columns 3100 mm Ledpfx Afjxaci Eeuohl down holder 16 Stück no. of strokes max. 10 - 15 Hub/min oil volume 160 ltr. cutting angle 1.6 ° back stop - adjustable 6.0 - 750 mm Control ELGO P9521 total power requirement 18.5 kW weight 6300 kg range L-W-H 3900 x 2300 x 1630 mm Features: - Robust electro-hydraulic swing beam shear - ELGO digital display model P9521, for electric backgauge * Backgauge travel X = 750 mm * Backgauge-free ball screw drive * Travel speed 100 mm/s - 1x stable side stop * With T-slot, flip-stop, and millimeter scale - 2x stable front support arms - Electric cutting length limiter * Cutting length limiter to increase the stroke rate/min. - Manual cutting gap adjustment * Centrally operated on the right side stand - Front support plates - Front finger/interference guard - Inching operation with push buttons on the left control panel - Protective grille = safety device behind the machine - Operating instructions (PDF)

Condition: new, pressure 150 t stroke 300 mm table surface area 1070 x 290 mm column travel between the guideways 1070 mm ajustment speed 9.0 mm/sec working feed 5.0 mm/sec return speed 10.0 mm/sec engine output 11.0 kW weight of the machine ca. 2070 kg. range L-W-H 2200 x 1200 x 2550 mm Display machine from 2023 With only approximately 2 operating hours Like new condition Special price upon request Furnishing: - Robust electro-hydraulic workshop press, with adjustable cylinder - Ideal for aligning axles, shafts, etc., but also for pressing in and out of bolts, bearings, bushings and much more. - Robust welded steel construction for high demands - Table height adjustment via piston rod Lhedpfsxabnajx Afujl * including round steel chain and 2x locking bolts * Piston rod with metric socket - 1x set of V-block prism supports - Manometer for pressure display - simply constructed hand control with: * 1x delivery speed * 1x working speed * 1x retreat speed - Piston can be stopped in any position - Hydraulic tank mounted on the side - Operation manual

Condition: good (used), Year of construction: 2005, sheet width 3050 mm plate thickness 12.0 mm ST plate thickness 8.0 mm VA no. of strokes 7 - 14 Hub/min down holder 18 Stück cutting angle 0.5 - 3.0 ° work height max. 930 mm back stop - adjustable 1000 mm Control SP 8 total power requirement 22.5 kW weight 8500 kg range L-W-H 4180 x 2030 x 2210 mm from a maintenance workshop good / well-maintained condition (!!) Equipment: - electro-hydraulic guillotine shear with guided blade beam - includes HACO NC control system "SP 9" * in like-new condition * backgauge pre-selection positioning * digital display of actual value * electro-hydraulic cutting angle adjustment with digital display Lhodpfx Afozr Rqnsusl * emergency stop switch - NC motorized backgauge on recirculating ball screws - manual blade gap adjustment, adjustable from the rear - front finger guard - 1x side gauge ... 1,000 mm - rear sheet metal chute - 1x movable foot pedal - operating manual

Condition: new, pressure 100 t stroke 300 mm table surface area 1070 x 315 mm column travel between the guideways 1070 mm ajustment speed 8.0 mm/sec working feed 5.0 mm/sec return speed 10.0 mm/sec oil volume 90.0 l engine output 5.5 kW weight of the machine ca. 1870 kg. dimensions of the machine ca. 2050 x 1000 x 2200 mm Furnishing: - Robust electro-hydraulic workshop press, with adjustable cylinder - Ideal for aligning axles, shafts, etc., but also for pressing in and out of bolts, bearings, bushings and much more. - Robust welded steel construction for high demands - Table height adjustment via piston rod * including round steel chain and 2x locking bolts * Piston rod with metric socket - 1x set of V-block prism supports - Manometer for pressure display - simply constructed hand control with: * 1x delivery speed * 1x working speed Lhjdpfx Aoxaar Dsfujl * 1x retreat speed - Piston can be stopped in any position - Hydraulic tank mounted on the side - Operation manual
