Used Omatic Roller Grinding Machine for sale (95,361)

Condition: used, Year of construction: 1975, max. bore diameter to be ground 6 bis 100 mm stroke - stepless adjustable 550 mm grinding depth ca. 250 mm workpiece weight 150 kg total power requirement 15 kW weight of the machine ca. 4.300 kg Hfedpfx Ahoucgwkeyob dimensions of the machine ca. 2,7 x2,4 x 2,2 m

Condition: used, Year of construction: 1995, Technical details: grinding length: 1250 mm grinding width: 600 mm workpiece height: 730 mm table surface area: 1720 x 500 mm headstock: dist. table - spindle center: 900 mm max. longitudinal movement: X-1450 feed range: 10 - 20.000 mm/min vertical movement: Y-730 mm feed range: 0,2 - 3.000 mm/min cross travel: Z-550 mm Hfedsx Uzvpspfx Ahyob feed range: 5 - 5.000 mm/min power capacity: 1500 U/min.- 44 kW / 8000 U/min. - 38 kW kW grinding wheel turining speeds: 50-6.000 U/min cutting speed: max. 80 m/sec. weight of the machine ca.: 11 t with CNC SIEMENS 840 C auto. dynamic balncing system integrated in the grinding conus profile grinding unit ( on table mounted ) Diamant profile rollers ( dia. max 140 mm , width max. 200 mm, hole 52 H3 ) speed 3000 rpm two magnetic plates ( 1000 x 400 mm, 1200 x 350 mm ) divers Flanges ect. *

Condition: used, centre distance 2.500 mm centre height 250 mm grinding wheel diameter 600 mm Total travel of the grinding support 320 mm spindle speeds 50 - 450 mm tool adaptor MK5 tail stock MK Cylindrical Grinding Machine | NAXOS-UNION - W-500 Hfjdpfex Avtcox Ahyeb the cylindrical grinding machine was overhauled in 2017 by KPS-Schleiftechnik (RETROFIT – see order confirmation). The machine is in a well-maintained condition. Please refer to further technical details in the attachement of the offer. - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - #Tags: W-500-2500 | W500 | W 500 | W 500 2500

Condition: good (used), Year of construction: 2008, functionality: fully functional, Technical details grinding length 2000 mm grinding width 850 mm distance spindle center to table 900 mm control Siemens 840 D total power requirement 155 kVA weight of the machine ca. 15 t dimensions of the machine ca. 8815 x 4185 x 2963 mm Additional information CNC Precision Surface and Profile Grinding Machine Technical Specifications: Grinding length 2000 mm Grinding width 850 mm Travel, transverse 750 mm Distance from table to spindle center 900 mm (or 800 mm with intermediate plate) Magnetic plate size 2000 x 700 mm Table load without magnet 3500 kg Table speed 60 m/min. Spindle drive 26 kW Grinding wheel dimensions 500 x 150 x 203.2 mm Grinding wheel peripheral speed 35 m/s Equipment: 3-axis contouring control Siemens 840 D Grinding programs: Full-cut grinding Face grinding Plunge grinding Path grinding X/Y-axis and Y-Z-axis Profile grinding Automatic program sequence with roughing, finishing, fine finishing and spark-out grinding. Multiple plunge grinding for economical production Surface grinding with continuous, continuously programmable cross feed Grinding wheel calibration Plunge/step grinding Face grinding Dressing in the grinding cycle with lift-off amount Fully automatic compensation of dressing amounts Tool management AC servo drives with ball screw and absolute measuring system in the X, Y, and Z axes Preloaded precision roller guides in the X, Y, and Z axes with linear guides Portable electronic handwheel Automatic belt filter system Coolant heating Electro-permanent magnetic chuck Fully enclosed Direct measuring system in the vertical axis Temperature-controlled machine bed for consistent accuracy Linear motor in the X-axis, table speed max. 60 m/min. Swiveling control panel Continuous speed control of the grinding spindle Electrical linear measuring device for cross-travel adjustment with zero point setting in any position, resolution 0.001 mm Electro-mechanical locking via position control of the headstock in the cross direction for profile and plunge grinding Mechanical extraction of coolant mist TAG table dresser Pre-profiling dresser VPG 190 Diamond grinding wheel, 190 mm diameter Software program for pre-profiling dresser VPG Rough profiling (roughing) CNC table profile dresser TAD 190 Profile depth max. 45 mm Contour accuracy +/- 0.0025 mm Swivel angle +/- 65 degrees Max. dressing speed 210 mm/min. Diamond wheel for table dressing machine TAD 190 Regrinding package for diamond wheel Intermediate plate for raising the magnet WinWop profiling software Hfodpfxox Uzn Ee Ahyjb Import of CAD profile data SP 60 JOB Listing expansion package Additional holes for the magnet clamping plate to facilitate removal of workpieces using compressed air Ghost shift circuit for shutting down the machine after the end of the program

Condition: good (used), Year of construction: 2013, grinding diameter 320 mm grinding length 1500 mm centre height 180 mm workpiece weight max. 150 kg grinding wheel size 400 x 50 x 203 mm grinding wheel speeds 1670 U/min grinding head - swivable +/- 30 ° adjustment grinding slide 246 mm workpiece spindle stepless 25-220 U/min grinding wheel adjustment manuell 0,01 / 0,0025 taper in spindle headstock MK 4 taper in spindle tailstock MK 4 Number of working hours ca. 20 h total power requirement 5,5 kW weight of the machine ca. 4,3 t dimensions of the machine ca. 4,3 x 2 x 2 m Hydraulic universal cylindrical grinding machine with a machining length of 1500 mm and a grinding diameter of 320 mm, with internal grinding attachment. Rotatable workpiece spindle head and swiveling table, hydraulic longitudinal table movement, hydraulic rapid traverse of the grinding head, hydraulic grinding head feed when reversing the table, manual + hydraulic adjustment of Hjdpfswyd S Dsx Ahyofb the tailstock quill. For further details, see data sheets, pics 9 and 10. Commissioning 2015: The machine was only used for a FEW HOURS on special workpieces, and then the orders dried up!

Condition: not inspected (used), Year of construction: 1989, functionality: unexamined, Grinding area: 650x350 mm, machine weight: 2,500 kg, in need of repair (for hobbyists / electronics technicians) Hfedpfx Ahoxx Tctjysb

Condition: used, Year of construction: 1970, Year ca. 1970 magnetic plate size 520 x 200 mm weight of the machine ca. 1,4 t +++++ Please note: The machine is dismantled and ready for loading. It is not possible to show it under power or make a video. Our offer includes already the best pictures. So we don’t have and won’t send additional pictures. Hfedpfxsirazps Ahyeb +++++

Condition: like new (used), Year of construction: 2022, functionality: limited functionality, grinding length: 450 mm, grinding width: 150 mm, table length: 450 mm, table load: 120 kg, table width: 150 mm, grinding spindle speed: 3,000 rpm, Surface Grinding Machine from Showroom (new) Manufacturer: Okamoto Model: ACC-450 AV (open design) Year of manufacture: 2022 Control: Okamoto FX Operating hours: 0 Hjdjx U Dawopfx Ahyofb S/N: XXXX Technical specifications: ----- • Table size: 450x150 mm • Table travel longitudinal/cross: 530x165 mm • Max. table load: 120 kg • Max. grinding height table / new wheel: 397.5 mm • Standard magnetic chuck: 450x150 mm (P=13mm) • Automatic infeed: 0.0001–0.030 mm • Manual micro feed: 0.0001 / 0.001 / 0.01 mm • Spark-out strokes: 0–5 • Rapid traverse: 600 mm/min • Grinding wheel: 205 x 6–19 x 31.75 mm • Speed: 3,000 rpm • Grinding spindle motor: 1.5 kW • Connected load: 7 kVA • Dimensions: 2,000 x 1,430 x 2,265 mm • Machine weight: 1,250 kg Accessories: ----- • Grinding wheel on flange (new) • Paper band filter with 160 l tank • Table dresser + diamond • Work light • Tool kit • Operating manuals

Condition: good (used), Year of construction: 2001, functionality: fully functional, Technical details grinding length 4200 mm grinding width 1300 mm workpiece height 550 mm Control SIEMENS 840 D magnetic clamping plate 4200 x 1300 mm segment head diameter 1400 mm grinding motor turning speeds up to 320 U/min. grinding motor 306 kW weight of the machine ca. 50,0 t Additional information Segment dimensions: 120/106 x 41 x 250 mm Number of segments: 1 set = 26 pieces Grinding motor feed: 0.5 - 35 m/min, infinitely variable Grinding motor feed: - in steps: 0.002 - 1 mm continuous: up to 5 mm/min. infinitely variable Equipment: * CNC-control SIEMENS Sinumerik 840 D * Automatic hydr. swivelling of the grinding motor from hollow to cross grinding * NC-controlled adjustment of the Marposs measuring head by means of precision support. - new grinding dimensions can be entered into the control, whereby the the grinding head automatically adjusts to the corresponding height. * Dresser with adjustment axis in the machine bed * Coolant system * Electro-magnetic table * Switch cabinet * Oil mist extraction * Documentation Dimensions (length x width x height) Bed: 11800x2200x1400 mm, weight 27500 kg Grinding head: 3000 x 2500 x 3100 mm, estimated weight 14 t 2 x Oil mist extraction: 1200 x 800 x 2000 mm each Control panel: 1200 x 800 x 400 mm Small control cabinet: 1400 x 1400 x 800 mm Hfsdsx Uyd Sspfx Ahyeb 2 x gears each 1200 x 800 x 500 mm Control cabinet: 1600 x 800 x 2000 mm Control cabinet: 3400 x 600 x 2400 mm

Condition: used, Year of construction: 1998, serial number 908278 max. dia. of grinding wheel 1,5-75 mm Hodsxzu A Topfx Ahyofb switchgear cabinet Ohne weight of the machine ca. 3,7 t

Condition: good (used), Year of construction: 1995, functionality: fully functional, Technical details internal diameter 800 mm grinding depth 500 mm swing diameter 850 mm weight of the machine ca. 6,4 t Additional information Used internal cylindrical grinding machine with face grinding device in special design with enlarged swing diameter and extended, hydraulic transverse movement Reconstructed and modernized 1995 in the Glauchau manufacturer’s plant, put into operation 1996 1. TECHNICAL DATA 1.1 Working area Grinding diameter in the workpiece guard internal grinding, min./max. mm 30/630(800) External grinding, max. mm 800 Grinding depth, up to approx. mm 500 Table stroke mm 800 Workpiece diameter, max. mm 800 Swing diameter in workpiece protection, max. mm 800 Without workpiece protection, approx. mm 850 Distance from workpiece spindle head to grinding spindle carrier, max. mm 1225 Adjustment of the internal grinding device on the table, max. mm 545 1.2 Workpiece headstock Hodpfx Ahsx Ux T Eeysfb Cross shift, max. mm 650 Cross adjustment via gear motor and positioning device with HEIDENHAIN digital position display Swivel, max. degrees 15 Workpiece spindle Speeds rpm 16/22/32/ 45/63/90/ 125/18/250 Load capacity, max 1000 Spindle head (with bayonet flange) DIN 55021 size 11 Machine accessories: 2-axis digital displays made by HEIDENHAIN Coolant system with magnetic separator Fixators (machine shoes) Various grinding wheels Diamond dresser Large face plate Internal and face grinding device Halogen machine lamp Machine documentation

Condition: used, Year of construction: 1999, max. dia. of grinding wheel 1,5-75 mm Hfodsxzu A Hspfx Ahyob switchgear cabinet mit serial number 910279 weight of the machine ca. 3,7 t

Condition: used, Year of construction: 1980, weight of the machine ca. 6 t Hfjdpfx Aoxzu Ayohyeb

Condition: used, Year of construction: 1992, 920229 grinding band dimension 75 mm x 2000 mm Hedpfsrxg Tqex Ahyofb wheel dimensions 250 mm weight 90 kg volt 380 V

Year of construction: 1973, condition: used, grinding length 1600 mm Hfedpfx Aspid Ivshysb centre height 185 mm diamter spiral cutter 55mm mm indexing 4-32 Modul length 5900 mm width 2300 mm height 2000 mm weight 7 t

Condition: used, Year of construction: 2017, grinding length 1000 mm centre height 180 mm length 3600 mm Hfjdpfx Ahewp Tumeyeb width 1650 mm height 1800 mm weight of the machine ca. 3,7 t

Condition: used, Year of construction: 2017, grinding length 1500 mm centre height 180 mm weight of the machine ca. 3,9 t Hedpfxewm Rqge Ahyjfb dimensions of the machine ca. L: 4900 x 1650x 1800 m

Condition: used, Year of construction: 1968, 450 mm Länge x-travel 500 mm workpiece height . mm Hfjdpfoqwpwzjx Ahysb

Condition: used, Year of construction: 1994, grinding length 800 mm grinding width 350 mm Control Haidenhain Hfedpewlvr Tofx Ahyeb Bandfilteraggregat

Condition: used, Year of construction: 1995, table-size Breite: 800 mm Hfjdpfxjwp Tuye Ahysb table-size Tiefe: 350 mm Dimensions (L/W/H) 4600 x 3200 x 2500 mm weight of the machine ca. 4,5 t

Condition: used, Year of construction: 1989, centre height 250 mm centre distance 600 mm Dimensions (L/W/H) 3600 x 1900 x 2100 mm weight of the machine ca. 2,25 t Hfodpoxzuzcsfx Ahysb

Condition: used, Year of construction: 2000, grinding length 600 mm grinding width 300 mm magnetic clamping plate 600x250 mm wheel diameter 220-300 mm Hfjdjw Hg Uzspfx Ahyob weight 2200 kg

Condition: used, Year of construction: 1960, grinding diameter ca. 360 mm grinding length 1500 mm serial number 12013 Hfedpfxow Sya To Ahyeb

Condition: used, Year of construction: 1999, grinding diameter 120 mm Hedpfx Aew Sybdehysfb centre height 100 mm Stirnschleifeinrichtung Kein Typenschild auffindb

Condition: used, Year of construction: 1999, grinding diameter 300 mm grinding length 500 mm Hodpfexzu Aasx Ahyefb centre height 150 mm digital readout 2 Achs Mitutoyo Ka Counte Knoll PF 70 magnetic chuck ja type Schild nicht auffindbar
