Used Paper Spindle for sale (14,502)

Condition: ready for operation (used), Year of construction: 1992, functionality: fully functional, spindle speed (max.): 3,750 rpm, bar diameter (max.): 26 mm, overall weight: 6,800 kg, No reserve price – guaranteed sale to the highest bidder! The machine is sold complete with collets, toolholders, and additional accessories! For further Schütte multi-spindle machines for sale from the same location, see below! TECHNICAL DETAILS Bar diameter round: 26 mm Bar diameter square: 19 mm Bar diameter hexagonal: 22 mm Bar diameter octagonal: 24 mm Spindle circle diameter: 270 mm Standard bar feed: 125 mm Special bar feed: 290 mm Longitudinal slide travel, standard total: 80 mm Longitudinal slide travel, standard working length: 63 mm Longitudinal slide travel, special total: 125 mm Longitudinal slide travel, special working length: 98 mm Cross slide travel, upper slide total: 40 mm Cross slide travel, upper slide working length: 25 mm Cross slide travel, middle slide total: 40 mm Cross slide travel, middle slide working length: 25 mm Cross slide travel, lower slide total: 50 mm Cross slide travel, lower slide working length: 31 mm Number of spindle speeds: 49 Spindle speed range I: 530–3,750 rpm Spindle speed range II: 236–1,700 rpm Workpiece revolutions per working cycle, standard: 60–425 Workpiece revolutions per working cycle, short: 33.5–236 Workpiece revolutions per working cycle, extended: 95–670 Number of main times per spindle speed: 35 MACHINE DETAILS Rated drive motor power: 18.5 kW Drive motor speed: 1,500 rpm Dimensions & Weight Dimensions with control cabinet (L x W): 3,500 x 1,450 mm Length with bar guide: 6,470 mm Machine weight: 6,800 kg Space requirement for packed machine: 14 m³ Lodpfx Anez Agy Hecjhl

Condition: good (used), Polar Mohr LW 1000-4 Paper Stack Lift This device is in excellent technical and visual condition. This is the current production model. Hydraulic drive. 380V power supply. Automatic lifting cycle controlled by a photocell or manual mode, fast operation. Load capacity: 1000 kg. Lsdpfx Anozw Tzyocohl Pallet dimensions: 1200 x 800 mm

Condition: good (used), Perfecta BSH 5-1200 Paper Stack Lift with Sidewall This machine is in excellent technical and visual condition. It’s practically unused. It features an adjustable sidewall for easy stacking. Stylish design. 1200 kg lifting capacity Plate size: 990 x 1350 mm Ledpfezw Tz Tjx Ancjhl 380V power supply Weight: 800 kg The lift is very easy to move, mounted on wheels. The control panel is adjustable to the right and left. Photocell-controlled lifting. Quiet hydraulic unit.

Condition: used, machine/vehicle number: 008238, X axis working area: 3660 mm Y axis working area: 1550 mm Working Table: Flat table Main Electrospindle power: 12 KW Number of controlled axes: 3 axes Lsdpox A E Tfsfx Ancshl Total number of drilling spindles: 12 Total number of tool changer positions: 15

Condition: ready for operation (used), Year of construction: 2016, operating hours: 23,500 h, functionality: fully functional, machine/vehicle number: 8107000021B, spindle bore: 32 mm, spindle speed (max.): 8,500 rpm, overall weight: 4,300 kg, controller model: FANUC 32i MB, bar length: 3,200 mm, DMG MORI GILDEMEISTER SPRINT 32/5 – Short/Long Turning Automaton Well-maintained machine, low operating hours, including IEMCA BOSS 338/32 HD bar feeder (up to 3,200 mm bar length), year of manufacture 2016, as well as a conversion kit to a long turning automaton (Swisstype kit) for short and long turning on a single machine. Delivery terms: Free on truck Availability: Immediate - subject to agreement NOTE: The machine must be picked up on a fixed date in mid/late October 2026; we will provide the exact date in advance! Technical data: Control: FANUC 32i MB Operating hours recorded: 25,263 Spindle hours recorded: 22,772 MAIN SPINDLE DATA: Max. turning diameter: 32 mm (guide bushing bore: 38 mm) Stroke Z1: 100 mm Max. speed: 8,500 RPM Drive power S1: 5.5 kW TAILSTOCK SPINDLE DATA: Max. turning diameter: 32 mm (guide bushing bore: 38 mm) Stroke Z2: 200 mm Max. speed: 8,500 RPM Drive power S1: 2.2 kW AXIS DATA X1: Travel: 70 mm Max. speed: 40 m/min Max. acceleration: 5 m/s² AXIS DATA Y1: Travel: 405 mm Max. speed: 30 m/min Lhsdpfsz A Tbujx Ancjl Max. acceleration: 5 m/s² AXIS DATA X2: Travel: 300 mm Max. speed: 40 m/min Max. acceleration: 5 m/s² TOOL HOLDER DATA – SLIDE 1: Tool holder diameter: 25 mm Number of fixed tools for external machining: 6 Tool holder size: 16 × 16 mm Number of driven tools: 4 Collet type: ESX20 TOOL HOLDER DATA – SLIDE 2: Number of fixed tools for internal machining: 4 Tool holder diameter: 25 mm Scope of delivery: IEMCA BOSS 338/32 HD bar feeder (up to 3,200 mm bar length), year of manufacture 2016 Chip conveyor Available manuals Accessories as shown in the pictures Dimensions & Weight Footprint (L x W x H): approx. 7500 x 1600 x 2500 mm Weight: approx. 4300 kg Attention: Disc damaged! If you have any questions or would like to arrange a viewing, please do not hesitate to contact us! Additional notes: ► Upon request, we can offer transport to your destination. ► The goods are sold without any warranty. ► Technical data is subject to change.

Condition: used, Year of construction: 2017, We offer you: CNC Bed Milling Machine Manufacturer: DMG MORI Model: DMF 260-11 linear Year of manufacture: 2017 Control: Celos with Siemens 840D sl Operate Main spindle renewed Technical specifications: Lhodpjwtd A Nsfx Ancjl Travel distances: - X-axis travel: 2,600 mm - Y-axis travel: 1,100 mm - Z-axis travel: 900 mm Main spindle: - Speed range: 20 - 15,000 rpm - Drive power (40/100%): 46 / 30 kW - Torque (40/100%): 200 / 130 Nm - Tool holder: SK 40 Worktable: - Fixed table with integrated rotary table - Clamping surface: 3,200 x 1,100 mm - Rotary table diameter: 1,050 mm - Max. table load: 1,200 kg Tool changer: - Number of tool stations: 60 positions - Chip-to-chip time: 7.5 s - Power-on hours: approx. 21,000 h - Operating hours: approx. 9,200 h Technical features: - ICS (internal coolant supply) 40 bar - Coolant spray gun - Rotating viewing window - Tropical package - Dynamic package Accessories: - Paper band filter 600l - Chip conveyor - Heidenhain TS 649 DMG touch probe - 3D quickSET - 2x Oil and emulsion mist separators - 4-color signal lamp - Electronic handwheel Accessories, pictured tools, and clamping devices are only included in the scope of delivery if noted in the additional information. Subject to changes and errors in the technical data and information, as well as prior sale!

Condition: good (used), Year of construction: 1989, CNC Surface Grinding Machine Machine type: Elb Schliff SWDE 012 NPC-K Year: 1989 SPECIFICATIONS max. grinding length: 1.500 mm max. grinding width: 900 mm Lhodpfxjzi Antj Ancjl max. Arbeitshöhe mit neuer Schleifscheibe: 800 mm max. Arbeitshöhe bei abgenutzter Scheibe: 880 mm Max. workpiece weight: 1.000 kg statisch kg Max. Table Load: 1.500 kg/m dynamisch kg grinding wheel-Ø: 500 mm Grinding wheel width : 100 mm Table size: 1.500 x 740 mm Equipment paper band filter Nassschleifeinrichtung EL.-Geraden-Abrichtapp Querklemmung grinding spindle taper: Konus 75 magnetic plate: 1.500 x 900 kein Rundtisch

Condition: refurbished (used), Year of construction: 2015, functionality: fully functional, TECHNICAL SPECIFICATIONS, MODEL RTR 600 CN Table diameter mm: 600 Electromagnetic chuck diameter mm: 600 Cross travel mm: 350 Max. grinding height with new grinding wheel mm: 400 Table speed, continuously adjustable rpm: 1-200 Gripping wheel dimensions mm: 400 x 50 x 127 Gripping wheel rotation speed, fixed rpm: 1,450 Automatic feed on the vertical axis, min. mm: 0.001 Spindle motor power kW: 15 Max. load on table kg: 1,000 Net weight approx. kg: 5,200 Vertical movement is achieved on linear slides and is driven by a precision ball screw and a YASKAWA AC motor. Vertical axis resolution: 0.001 mm. Measuring system = encoder Dimension read on display. Display resolution = 0.001 mm. Electronic handwheel for manual movement. Transverse movement is performed on linear slides and is controlled by a precision ball screw and a YASKAWA AC motor. Transverse movement is performed by the grinding wheel head mounted on the cross slide. Transverse axis resolution = encoder Lhodpfex N I Aljx Ancol Dimension read on display. Display resolution = 0.001 mm. Electronic handwheel for manual movement. Rotary table with hydrostatic circular slides. Infinitely variable rotation speed, with YASKAWA AC drive motor. Balanced hardened steel spindle with 15 kW motor. Fixed speed. Option: YASKAWA frequency converter for continuously variable spindle speed (1,100–1,900 rpm) Lubrication unit with automatic lubrication cycle, external to the machine, without initial filling. Standard accessories: - LODI CNC type T 2000 (see photo) - Automatic work cycle with different values ​​for the various cycle phases: roughing, finishing, flash grinding - Digital measurement of the vertical and transverse axes. Resolution = 0.001 mm - Electronic handwheel for manual axis movement - Continuously variable table speed via YASKAWA AC motor. Rotary table with hydrostatic slides - Grinding wheel headstock with 15 kW motor. Fixed spindle speed: 1,450 rpm. - Central lubrication for all moving parts - Hydraulic unit located outside the machine - Complete watering system with piping, electric pump, guards, electrical equipment, and a 250-liter settling tank (without filter) - Complete enclosure of the work area with sliding door (open ceiling) - 1 complete flange with grinding wheel - Work light - 1 set of service wrenches - CE Declaration of Conformity + CE plate - Operating voltage 400 V +/- 5%, 50 Hz - Electro-permanent magnetic plate with electronic device for adjusting the attraction force. WAGNER brand, type EP 360 - Ø 600mm - YASKAWA frequency converter for continuous adjustment of the grinding wheel speed (1,100-1,900 rpm) and for braking at the end of the cycle - LOSMA paper filter, type DTE 100 (capacity 300 liters) - LOSMA wet fume extractor, type AS1 (capacity 1,300 m³/h) - "MARPOSS" dynamic grinding wheel balancing device for dynamic and automatic balancing of the rotating grinding wheel - Linear diamond holder mounted on the grinding wheel headstock. Automatic dressing cycle with automatic grinding wheel wear compensation. Diamond increment by AC motor. Resolution 0.001 mm - 1 Diamond - Complete auxiliary pump for washing parts and the magnetic platen

Condition: used, Year of construction: 2003, functionality: fully functional, travel distance X-axis: 1,600 mm, travel distance Y-axis: 1,250 mm, travel distance Z-axis: 1,000 mm, rapid traverse X-axis: 60 m/min, rapid traverse Y-axis: 60 m/min, rapid traverse Z-axis: 60 m/min, feed length X-axis: 1,600 mm, feed length Y-axis: 1,250 mm, feed length Z-axis: 1,000 mm, feed rate X-axis: 15 m/min, feed rate Y-axis: 15 m/min, feed rate Z-axis: 15 m/min, nominal power (apparent): 90 kVA, controller manufacturer: HEIDENHAIN, controller model: TNC 530, workpiece weight (max.): 3,000 kg, total height: 3,600 mm, total length: 8,017 mm, total width: 4,905 mm, table width: 1,000 mm, table length: 1,250 mm, table load: 3,000 kg, rotational speed (max.): 10 rpm, overall weight: 35,000 kg, spindle speed (max.): 18,000 rpm, spindle motor power: 28 W, spindle nose: HSK63A, number of slots in tool magazine: 60, Equipment: CE marking, chip conveyor, documentation/manual, rotational speed infinitely variable, Equipped with: - 5 axes Ljdjzgbdzjpfx Ancjhl - Automatic pallet changer system - High-pressure coolant system running through the spindle with paper filter and 1000-liter tank - Automatic tool presetting system by BLUM - CE marking

Condition: excellent (used), Year of construction: 2007, functionality: fully functional, CNC turning and milling center Okuma Multus B300 Control: OSP-P200L Year of manufacture: 2007 Internal machine number: 60 Travel ranges: X-axis 690 mm Y-axis 230 (-115 to +115) mm Z-axis 1,545 mm B-axis 0.001 ° Lhjdpfx Anezwl S Rocsl C-axis 360 ° W-axis: 1,550 mm Max. turning diameter: 710 mm Tool holder: HSK 63 Total number of tool positions: 40 Spindle speed: 38 – 3,800 rpm Equipment / Accessories - Chip conveyor - 3-jaw chuck SMW KNCS-N-260-72 - Compact paper band filter system 500 l - One Touch IGF

Condition: good (used), Year of construction: 1988, grinding length: 1,000 mm, grinding width: 550 mm, grinding height: 400 mm, grinding wheel diameter: 400 mm, grinding wheel width: 100 mm, Manufacturer: ELB-SCHLIFF Model: SWBE 010 ND Year of manufacture: 12-1988 Delivery time: immediately Electro-permanent magnetic clamping plate SAV 1000 X 400 mm Fine pole pitch 45-5 mm Electric straightening device with compensation Digital display vertical Holder with grinding wheel max. 400 X 100 X 127 mm Spindle motor 7.5 KW 1435 min/1 Setting wedges Ledpfou Rqynjx Ancehl Coolant system with universal paper belt filter Complete documentation

Condition: good (used), Year of construction: 2001, functionality: fully functional, machine/vehicle number: 0397, travel distance X-axis: 2,000 mm, travel distance Y-axis: 800 mm, travel distance Z-axis: 1,100 mm, spindle speed (max.): 9,000 rpm, table length: 2,500 mm, table width: 850 mm, coolant supply: 20 bar, Equipment: documentation/manual, Well-maintained MATEC 30HV with various features: automatic B-axis +/-90 degrees with 1-degree division Lhedpfxszt Izts Ancsl integrated NC rotary table, diameter 630mm Heidenhain TNC426 with electronic handwheel internal coolant supply with paper band filter (20 bar) tool magazine with 36 positions spindle hours: 13,000h suitable for SK40 compressed air to the external nozzles chip conveyor with integrated coolant system (discharge height: approx. 850mm) chip flushing gun tool probe for tool measurement center partition available complete enclosure of the work area with a roof Bellows are new Lifting cylinder was renewed in 2026 Ball screw drive including nut, bearing, and coupling was renewed in 2025 The risk of dismantling and transport, as well as the costs of dismantling and transport, are entirely borne by the buyer. Inspection is possible by appointment.

Year of construction: 2006, condition: used, CNC SELCA 4045 1200 X 1500 MM TURNTABLE TABLE X AXIS TRAVEL 2200 MM Y AXIS TRAVEL (VERTICAL) 1000 MM V AXIS TRAVEL (DRILLING) 1000 MM Z AXIS TRAVEL (MILLING) 360 MM W AXIS TRAVEL (APPROACH) 500 MM B AXIS ROTATION ( TABLE ) 360,000 MAXIMUM DRILLING CAPACITY 5. 40 MM MAXIMUM TAPPING CAPACITY M 30 MILLING TOOL TAPER : ISO 40 AXIS FEEDS X Y V W 0 - 10000 MM/MIN DRILLING AND MILLING SPINDLE MOTOR POWER 9 KW WEIGHT 26000 KG DRILLING ROTATION 4200 RPM MILLING ROTATION 4500 RPM WORKPIECE WEIGHT IN ROTATION 12000 KG WEIGHT OF STATIONARY WORKPIECE 18000 KG MAXIMUM DIAMETER OF THE ROTATING PART DIA. 2700MM TOOL CHANGER FOR MILLING TOOLS 20 PLACES Lhedpfoq Nni Ssx Ancjl PAPER FILTRATION SYSTEM

Condition: good (used), Nagel Citoborma 490 Paper Drill This is the largest Citoborma drill currently in production. Very good condition, ready for production. The machine has 4 drilling heads. Drilling waste is discharged into a basket located at the rear of the machine. The machine is operated using a foot pedal or two-handed buttons. Each head has a separate up/down adjustment, allowing for the use of drill bits of different lengths. The set includes spare drill bits, tools, and an instruction manual. Technical specifications: Number of drilling heads: 4 (each head can be quickly removed) Maximum stack height: 60 mm Drill bit size: 2-10 mm Adjustable spacing: 45 – 425 mm Lhodpfx Anez Dr U Nscjl Two drilling speeds 380V power supply Weight: 365 kg Made in Germany.

Condition: good (used), Nagel Citoborma 480AB Paper Drill This machine is in very good condition. It has four drilling heads. Technical specifications: Drill bit distance: 45-285 mm Drill diameter: 2-20 mm Stack height: 60 mm Weight: 275 kg Automatic drilling cycle, controlled by a foot pedal and manual buttons. Sturdy construction on a pedestal. The drill table is adjustable in all planes. This is one of the newest Citoborma models. Includes operating tools, instructions, and a new cutting stick and drill bits. Lhjdpfxez Dtaaj Ancel

Condition: excellent (used), Year of construction: 2011, operating hours: 2,450 h, travel distance X-axis: 6,000 mm, travel distance Y-axis: 12,001,400 mm, travel distance Z-axis: 18,001,790 mm, controller manufacturer: Heidenhain, controller model: iTNC 530, workpiece weight (max.): 3,000 kg, total height: 4,700 mm, total length: 12,700 mm, total width: 7,800 mm, rotary table diameter: 2,200 mm, rotational speed (max.): 200 rpm, overall weight: 57,000 kg, spindle speed (max.): 8,000 rpm, operating hours of spindle: 2,450 h, coolant supply: 40 bar, number of slots in tool magazine: 60, tool length: 460 mm, Equipment: chip conveyor, documentation/manual, CNC controller: Heidenhain iTNC 530 Axes X-axis travel mm: 6000 Y-axis travel mm: 1200/1400 Z-axis travel mm: 1800 (H) / 1790 (V) C-axis degrees: 360º (0,001) A-axis degrees: ±180° B-axis degrees: ±180° Rapid traverse m/min: 30 Worktable Table dimensions mm: 6000x1235 Milling/turning table nc: Table dimensions mm: Ø2200 Max. workpiece weight kg: 3000 Table rotation speed rpm: 200 max. torque Nm: 4600 Spindle Spindle speed rpm: 8000 Spindle drive power kW: 33/24 (40%ED/cont) Spindle torque Nm: 382/278 (40/100%ED) Cooling Cooling through the Spindle Center bar: 40 Tank capacity: 900 Tool system Tool holder: HSK-A 100 Tool magazine slots: 60 With free neighboring places mm: 200 With occupied neighboring places mm: 104 Max. Tool Length mm: 460 Max tool weight kg: 25 Chip-to-chip time s: 9.8 Equipment Electronic Handwheel Chip conveyor Infrared probe Internal cooling lubricant supply Rinsing gun Operating mode 4 blowing air through spindle center selectable via M-function Workarea light DXF import function Paper band filter Automatic door Indexing Head Set Up for Shaft Machining Axles can be hydraulically locked using the M function Machine running times Under power: 29447 Spindle Working: 2450 Basic machine dimensions / weight Length mm: 12700 Ljdpfezb H Tfsx Ancshl Width mm: 7800 Height mm: 4700 Weight kg: 57000

Condition: excellent (used), Year of construction: 2020, Maximum turning diameter 3800 mm Maximum swing diameter 3800 mm diameter of spindle flange 1900 mm control Siemens 840 D sl Table rpm 100 1/min Maximum speed of driven tools 6000 1/min x-travel 2800/3200 mm z-travel 1000 mm Feed - X 20 m/min feed capacity - x 22 kN tool taper CAPTO C8 total power requirement 280 kVA Lhedpfjzpzblex Ancel dimensions of the machine ca. 10,4 x 6.3 x 5,7 m weight of the machine ca. 155 t Equipment/Accessories: - 2 tool changers, each with 60 positions - 2 x chip conveyors - Coolant system, 6 bar - High-pressure cooling, 70 bar - Knoll paper belt filter - 12-jaw balancing chuck, RÖHM - internal coolant supply - Hydraulic unit - Automatic door - Electric handwheel - Technical documentation

Year of construction: 2003, condition: used, A Deckel Maho 5-axis CNC milling machine in need of repair is offered. Travel X/Y/Z: 1080mm/710mm/710mm, NC-mounted rotary table C-axis X/Y: 800mm/620mm, swiveling milling head B-axis: 90°, max. spindle speed: 12000rpm, tool taper: SK40, tool positions: 32, control: Heidenhain iTNC 530, control-on hours: 75100h, program run hours: 24720h. Equipped with internal air blast supply, external coolant supply, Heidenhain infrared touch probe, Heidenhain electronic handwheel, Rotoclear rotating inspection window, chip conveyor, oil mist extraction system, coolant system with paper band filter, chip flushing gun, work area light and clamping support next to the mounted rotary table for longer workpieces. The milling head clamping system is leaking, but the machine is still operational. An on-site inspection is possible. Lhjdpszwfq Hefx Ancel

Condition: excellent (used), Year of construction: 2012, Equipment: chip conveyor, Spinner U5-1520 5-axis machining center Control system: Heidenhain 620 Year of manufacture: 2012 Table dimensions: 2-part – fixed 920x540 mm / rotary round table 650x500 mm (with enlarging ring) Travel in X-axis: 1,520 mm Travel in Y-axis: 520 mm Travel in Z-axis: 420 mm Spindle mount: ISO 40 Spindle speed: 12,000 rpm Automatic tool changer: 32 positions Spindle motor power: 15 kW Ledpfeztv Ihex Ancshl Net weight approx.: 10,000 kg Accessories: Internal cooling system with paper band filter Chip conveyor Handwheel

Condition: as good as new (ex-display), Year of construction: 2023, functionality: fully functional, machine/vehicle number: VT0479, VC850 travels: X850, Y510, Z510 mm High-performance milling spindle up to 12,000 rpm as a built-in hybrid spindle with direct drive, without belt Tool holder on spindle SK40 DIN69871 with pull stud DIN69872-A / ISO 7388-3-AD TOOL MAGAZINE with 32 tool stations DIRECT MEASURING SYSTEMS in X/Y/Z axis SIEMENS 840DE control with the following basic features: - SPINNER - SPIOS 24" touch panel for I4.0 applications - Control panel height-adjustable, rotatable and tiltable for best ergonomics - incl. engraving cycles - 24" liquid crystal flat color screen with multi-touch functionality - User memory 2 GByte - 15 zero-point offsets - 1 free USB interface - Ethernet interface standard In the latest generation of SIEMENS "SINUMERIK ONE" control - SPINNER - SPIOS 24" touch panel for I4.0 applications - Control panel height-adjustable, rotatable and tiltable for best ergonomics - incl. engraving cycles - 24" liquid crystal flat color screen with multi-touch functionality - User memory 2 GByte - 15 zero-point offsets - 1 free USB interface - Ethernet interface standard SPINNER MULTI-CONTROL-WHEEL on the control panel, integrating the following functions into a single control element: - Handwheel function in jog mode - Feed override in automatic mode - Start button and feed influence in single-block setup mode, automatically resetting to 0% at the end of the block -> all important functions of the setup mode integrated into one control element - SHOPMILL - 3D SIMULATION - REMNANT MATERIAL RECOGNITION - DXF reader Fully integrated 1-axis TILTING TABLE, centrally mounted in the working area on the table, with: - Pivoting cheek approx. 580mm long for 3-sided machining - Swivel range of the A-tilting axis is infinite - Counter bearing to support the rotary table bridge UNIVERSAL CHIP CONVEYOR VC850 PREPARATION of the spindle FOR HIGH PRESSURE for the use of the additional tank up to 22 bar HIGH-PRESSURE TANK 22 bar Additional compressed air on the spindle head Compressed air centrally through the milling spindle, alternatively to coolant nozzle in the working area PREPARATION FOR SPINNER STANDARD MEASURING PROBE Lhedpfey S Tpiox Ancol Wireless SPINDLE PROBE universal robot interface UNIROB CLAMPING HYDRAULICS incl. 2 pcs. 4/4-way VALVE for workpiece clamping up to 200 bar hydraulically STANDARD DOCUMENTATION GERMAN consisting of machine manual and CNC manuals is supplied in digital form on the control. Paper manuals available at an additional cost LIFTING LUGS for crane unloading, set consisting of 4 pcs. mandatory for crane transport STANDARD PAINTING two-tone in light gray RAL7035 and blue-gray RAL5008 Electrical design EUROPEAN STANDARD as follows: Operating voltage 3x400V +/-10% Mains frequency 50Hz (+/-2%) TN network (5-conductor) Notes: The price includes warranty services only within Germany. For new and demonstration machines, the images are not necessarily images of the individual machine, but of comparable machines. Accessories shown, such as clamping devices or tool holders, are only included in the scope of supply to the extent listed in the technical description. Ask for a detailed offer ex works. Visit our factory near Munich or one of our showrooms. We may have other offers for comparable machines. Subject to prior sale.

Condition: used, Year of construction: 2019, turning diameter over bed 32 mm spindle passage 32 mm control SIEMENS 840-D-SL spindle stroke 220 mm main spindle speeds: 6000 U/min spindle drive 5,5 / 3,7 kW Sub - spindle - bar diameter 32 mm turning speed range sub spindle 8000 U/min Lodpfx Aeytx Sksncehl turning length 220 mm collets 1536E motor power 5,5 / 3,5 kW total power requirement 16 kVA weight of the machine ca. 4,3 t dimensions of the machine ca. 6,40 x 1,60 x 2,10 m MAIER Swiss lathe in very good condition with SIEMENS 840-D-SL 3-channel control system, equipped with: - 2 counter spindles - NC C-axis on main and both counter spindles - Additional 3rd channel in the form of a second counter spindle - Channel 1 with Y1 and 4 driven tool holders - Channel 2 - Back side machining, tool carrier with 4 driven and 4 fixed tool stations - Tool holders for 4 fixed turning tool holders, cross-section 16 x 16 mm - Bar loading magazine, manufacturer FMB Turbo Ø 3-36 / 3200 C - Stack magazine for holding a complete bundle of bars - Chip conveyor - Electronic handwheel - KNOLL high-pressure system 50 bar with paper belt filter system - Fire protection system, manufacturer KRAFT & BAUER - Table for removing long parts - Removal of long parts (flange + pipe) - ARTIS - Tool and process monitoring “Genior Modular fully automatic tool and process monitoring” The machine can be inspected under power!

Condition: reconditioned (used), Year of construction: 2013, functionality: fully functional, CNC Vertical Machining Center "MÜGA S 3030" With MITSUBISHI path control Year of manufacture: 2013 Travel distances: X 300 Y 250 Z 250 Spindle speed range: 60 – 15,000 rpm, stepless Including the following accessories: Ledpfx Anoyx H Nvscshl Rigid angle table, 400 mm x 250 mm clamping surface Vertical tool changer with 12 magazine slots (SK 30) Various tool holders (SK 30) Dual pallet changer 4 pcs. Allmatic vices, jaw width 100 mm Electronic handwheel Full safety enclosure with sliding doors and interior lighting Coolant unit with paper band filter Coolant system 2-color signal light Chip conveyor 6 pcs. machine feet Operating manuals

Condition: like new (used), Year of construction: 2015, operating hours: 14,717 h, functionality: fully functional, turning length: 800 mm, turning diameter: 500 mm, spindle speed (max.): 12,000 rpm, travel distance X-axis: 480 mm, travel distance Y-axis: 100 mm, travel distance Z-axis: 845 mm, rotational speed (max.): 5,000 rpm, type of input current: three-phase, workpiece weight (max.): 7 kg, total height: 2,247 mm, total length: 2,890 mm, total width: 5,193 mm, overall weight: 7,800 kg, CNC controller: Siemens 840D sl with CELOS ERGOline Capacity X-axis travel mm: 480 (–10) Y-axis travel mm: ±100 Z-axis travel mm: 845 B-axis travel mm: ±110° (0,001º) Lsdpfjxdlynsx Ancohl C-axis: 360º (0,001º) Turning length mm: 800 Max. turning diameter mm: ø: 500 Distance between spindle centers mm: 1.020 Turn-mill spindle Speed spindle rpm: 12.000 Drive power kW: 22 / 19 Tool magazine Magazine places: 48 Tool holder: HSK-A63 Tool length max. mm: 300 Tool diameter max. mm: 125 Tool weight max kg: 7 Main spindle Speed spindle rpm: 5.000 Drive power spindle kW: 25 / 34 (100 / 40%) Spindle bore mm: 67 Maximun torque Nm: 380 / 280 Counter spindle Speed spindle rpm: 6.000 Drive power spindle kW: 20 / 27 (100 % / 40%) Spindle bore mm: 52 Maximun torque Nm: 170 Counter spindle travel mm: 800 Coolant system Tank capacity liter: 600 L High-pressure bar: 8 / 20 Equipment Chip conveyor Blowing air through spindle center selectable via M-function Signal lamp Tool measuring arm Workarea light Coolant gun Internal coolant supply Interface for Bar feeder Paper band filter Working time hours Under power: 36.049 Cutting Time: 14.171 Basic machine dimensions / weight Length mm: 2.890 Width mm: 5.193 Height mm: 2.247 Weight kg: 7.800

Condition: ready for operation (used), Year of construction: 2006, functionality: fully functional, machine/vehicle number: 3075419, spindle speed (max.): 2,400 rpm, travel distance X-axis: 432 mm, travel distance Z-axis: 1,118 mm, swing diameter over cross slide: 635 mm, turning diameter over bed slide: 1,016 mm, For sale is a HAAS SL-40HE CNC turning center, manufactured in 2006, in a High-Center configuration with a full C-axis and driven tools. This robust CNC turning machine is suitable for demanding turning and milling operations. TECHNICAL DETAILS Travel in X-axis: 432 mm Travel in Z-axis: 1,118 mm Spindle speed max.: 2,400 rpm Swinging diameter over bed: 1,016 mm Swinging diameter over cross slide: 635 mm Bar capacity max.: 101.6 mm Lhodezy Npfepfx Ancsl C-axis: full C-axis Spindle power: 29.8 kW / 40 hp Spindle nose: A2-8 Spindle bore: approx. 116.8 mm Gearbox: 2-speed Turret capacity: 10 stations Driven tools: yes MACHINE DETAILS Dimensions & Weight Dimensions (L x W x H): approx. 5,500 x 2,300 x 2,300 mm Machine weight approx.: 11,000 kg

Condition: good (used), Year of construction: 2008, 1 used 5-axis machining center Manufacturer: DECKEL MAHO Type: DMU 60 Monoblock Year of manufacture: 2008 Technical data: Main drive: Motor spindle 12,000 rpm 15 kW (40% duty cycle); 10 kW (100% duty cycle) Ljdpfx Anozv Dxaecshl Tool holder: SK 40 according to DIN 69871 Control system: iTNC 530 / MillPlus IT NC rotary table integrated into a fixed table Diameter 600 mm / 1000 mm x 600 mm Controlled NC swivel milling head (B-axis) including hydraulic clamping Spindle offset 100 mm Swivel range -120/+30° Chain magazine with 60 magazine slots Production package 40 bar Paper band filter Internal coolant supply through the spindle center, Form AD Rotating viewing window
