Used Wooden Pallets Machine for sale (70,547)

Condition: good (used), Wohlenberg 115 TS Paper Cutting Machine Machine in very good condition, ready for production. Fjdpo Af E E Refx Ab Eogi Year of manufacture: 2008. Available immediately from stock. The guillotine can be used as a standalone unit or integrated with cutting systems. Program generation is menu-driven and includes a variety of cutting tasks, such as single cut, programming, multiple cuts, non-cutting hold-down, and automatic actual value transfer. Wohlenberg premium cutting machines are manufactured in Solms, Germany. Distinguishing Features of the Wohlenberg Machine: – Interactive User Interface – 18.4” Touchscreen – USB Interface – Ethernet Interface – Windows CE Operating System – Positioning via Electronic Handwheel – Optimized Cutting Cycle – Programmable Hold-Down Pressure – Automatic Adjustment of Hold-Down Pressure to Cutting Width – Automated Front-Mounted Knife Change – Quick Knife Change – New Machine Body Cast in One Piece = Increased Stability – Maintenance-Free Electromagnetic Clutch Technical Data: Cutting Length: 1150 mm Maximum Stack Height: 165 mm Infeed Depth: 1150 mm Minimum Cutting Capacity with Sheet Metal Under Pressure Beam: 77 mm Minimum Cutting Capacity Without Sheet Metal Under Pressure Beam: 20 mm Maximum Saddle Feed Speed: 300 mm/s Maximum Mechanical Efficiency Knife speed: 44 cycles/min Saddle movement: above the work table Main motor power: 4 kW Net weight: 3200 kg The machine is equipped with a spare knife, cutting sticks, a pressure plate, documentation, and tools.

Condition: good (used), Year of construction: 2005, machine/vehicle number: SBLG 0005, Proto Trax VL 3 jaw SMW chuck 11KW Spindle motor 104mm spindle bore Spindle speeds 30-1800RPM Fjdpfx Aozb Ipzob Ejgi 350mm swing over cross slide X axis travel 280mm Z axis travel 1650mm 1750 mm between centres Coolant pump and tank

Condition: excellent (used), Year of construction: 2011, XYZ Proturn SLX 1630 ProtoTRAK CNC Gap Bed Centre Lathe Ex Research machine – Superb Condition ProtoTRAK SLX Control (2011) Max’ Distance Between Centres 760mm Max’ Swing over Cross-slide 218mm Max Swing over Bed 400mm Spindle Bore 52mm Spindle Speeds 150 – 2500 rev/min Fgjdpezav D Dsfx Ab Esi Spindle Motor 5.75Kw Spindle Camlock D1-6 Quick Change Tool Post Tailstock MT4 Tailstock Dia’ 60mm Tailstock Travel 127mm Manufactured | 2011 Weight 1560Kgs Supplied with: Two-axis CNC, Two-axis DRO. TRAKing, Constant surface speed. Electronic hand-wheels for X & Z Axes. Joystick for feed & rapids. Interlocked chuck guard and main guard. Quick change toolpost with holders. 3 Jaw chuck 5C Collet Chuck Coolant For sale with *Jet Machinery Ltd* Jet Machinery Stock No: #78211 Machine Serial Number: 16P99080-063 Cost: £17,950.00 + VAT Whilst every effort has been made to ensure that the above information is accurate it is not guaranteed. We advise prospective purchasers to check any vital details. Health and Safety At Work Act 1974: It is not reasonably practical for ourselves as suppliers to ensure that for your application the goods comply with requirements of the Act with respect to guarding etc. Prospective purchasers should ensure that a guarding specialist inspect the goods prior to use.

Condition: ready for operation (used), Year of construction: 2009, functionality: fully functional, machine/vehicle number: 08120055, workpiece weight (max.): 227 kg, travel distance X-axis: 440 mm, travel distance Y-axis: 500 mm, travel distance Z-axis: 410 mm, TECHNICAL DETAILS Fgedpfxe Afhtqj Ab Eji Travel range X-axis: 440 mm Travel range Y-axis: 500 mm Travel range Z-axis: 410 mm Max. workpiece weight: 227 kg Table height: 930 mm MACHINE DETAILS Last overhaul: 2025 Last calibration and maintenance: 09/09/2025 Calibration and measurement protocols: available Operating manual: available on CD Dimensions & Weight Dimensions (L x W x H): 1,030 x 1,160 x 2,320 mm Total weight: 293 kg Input voltage: 220 V Input current type: Alternating current (AC) EQUIPMENT PC-DMIS Pro for Windows Version 4.2 MR4 Release Software, legally transferable Renishaw MH20i measuring head with TP-ES probe system EM1 extension module, length: 70 mm TP20 SF probe module with standard probing force TP20 EF probe module with high probing force Functional HP computer Additional Renishaw Brown & Sharpe TP-ES measuring head, functional Several probe extensions Various probe tips The scope of delivery also includes a TESA Star-i measuring head and a Renishaw MIP measuring head. The TESA Star-i measuring head is defective. The Renishaw MIP measuring head is likely defective. However, the machine itself is equipped with the fully functional and even higher-quality Renishaw MH20i with TP-ES probe system and is therefore immediately ready for use.

Condition: new, functionality: fully functional, NEW CT-400 industrial screw press dewatering machine - in stock at our Chino, CA warehouse, ready for inspection and pickup. Continuous solid-liquid separation for wet organic material: food waste, fruit and vegetable pulp and pomace, brewery and distillery spent grain, juice press cake, manure, and plant fiber. The press separates out the liquid and discharges a stackable cake - most loads lose up to two-thirds of their weight before they leave your site. Ideal for SB 1383 organics compliance and cutting hauling and disposal cost. KEY SPECS - Capacity: 5 tons/hour (8-10 m3/h) - Motor: 30 kW / 40 HP - 480V, 3-phase (440V compatible) - Screw speed: 20 RPM - Wedge-wire screen, 0.75 mm slot (0.5 and 1.0 mm spares available) - Discharge cone: hydraulic or pneumatic adjustable back-pressure - Footprint: 177 x 39 x 79 in - Weight: 7,050 lbs Fgsdpfx Abe Adyk Sj Eei WHY ZEN SURFACE LLC - Machinery supplier at a fraction of US-built separator prices - FREE live demo: bring your material and watch it run before you pay - Full range in stock or built to order: CT-160 to CT-600 (0.5 - 15 tons/hr) - NEW: GS-1200 twin-shaft shredders - ask about a complete shred + press line Local pickup in Chino, CA. Freight can be arranged anywhere in the US. Message us through this listing for details, pricing and a live material demo.

Condition: used, machine/vehicle number: 2820-0419, No minimum price – guaranteed sale to the highest bidder! Loading: December 1st to December 10th. TECHNICAL DETAILS General Information Machine type: CNC-controlled tool milling machine Condition: good Machine weight: approx. 1.9 kg Travel distances X-axis travel: 500 mm Y-axis travel: 400 mm Z-axis travel: 400 (340) mm Work table Table surface: 710 × 430 mm Spindle and milling head Speed range: 40–4,000 rpm Head swivels: ±90° Quill stroke: 80 mm Spindle mount: SK 40 Feed rate and rapid traverse Feed rate range: 0.2–3,600 mm/min Rapid traverse: 4.0 m/min Feed axes: 3 axes Control system Fgsdpfxo Aa Acvo Ab Eji Control system: Contour 3 / Dialog 4 Performance data Total power consumption: 5.5 kW Dimensions Space requirement: approx. 2 × 1.4 × 1.8 m EQUIPMENT Rotatable vertical head ±90° Hydraulic tool clamping Automatic central lubrication Coolant system Safety emergency stop Machine lighting Chip guard enclosure with chip collection tray Mobile control panel Electronic handwheel

Condition: refurbished (used), Year of construction: 2003, functionality: fully functional, production capacity: 3,650 unit/h, The system has been completely overhauled! TECHNICAL DETAILS Capacity: approx. 3,650 pieces/hour Round dough pieces (cut): 40–65 g Long-rolled dough pieces (cut and uncut): 40–65 g Dough piece weight in 3-row operation: 40–85 g Round/smooth dough pieces via pretzel discharge: 40–85 g Processable products Sliced rolls Round and smooth dough pieces Baguette rolls Hotdog buns Bread rolls EQUIPMENT Complete stainless steel design 3-row operation Fgsdpfx Abj Agnwae Eei Pretzel discharge

Condition: new, number of aggregates 2 St. working width 2000-3500 mm work height max. 2450-3200 mm Wintech M9Cb Sealing Machine Automatic sealing system for wooden windows and doors with 2 processing units. For a detailed description, see the PDF document. ----- Manufacturer’s technical description: M9Cb robotic sealing system The machine comprises a robust structure made from aluminium profiles, fitted with motorised conveyor belts on which the window units are transported. The silicone is distributed evenly into the joint by means of two automatically controlled nozzles. The electronic control system, which is in constant communication with the sensor, determines the movement of the guns and the operating parameters. Technical data: Standard Optional Max. window width 2000 mm 3500 mm Max. window height 2450 mm 3200 mm Max. window thickness 160 mm 190 or 250 mm* Max. window weight 150 kg 200 or 400 kg* Loading station 2000 mm 3500 mm Unloading station 2000 mm 3500 mm Choice of silicone: Standard 1 colour 2 or 3 colours Master head 1 2 Sealing of timber panels no yes Formulation adapted to the type of elements no yes Synchronised conveyor belt no yes for heavy loads and/or conveying in both directions Double movable crossbar for flush-mounted hinged window sashes no yes *Please contact us for greater thicknesses or weights Optimisation of the sealing process: The M9Cb robotic sealing system revolutionises the sealing process by injecting exactly the right amount of silicone, thereby preventing unwanted streaks. It enables the glazing beads to be ‘nailed’ invisibly and saves the time required to cover the nail heads. The precision ensures high-quality, uniform sealing, which guarantees optimal watertightness whilst maximising the clarity of the units. With a feed speed of approx. 2 metres per minute, it offers fast and efficient processing on both sides simultaneously (on average 4 minutes per unit). More space available: No more lack of space in the workshop! The M9Cb operates vertically and therefore takes up very little floor space. Leaning against a wall or partition, it frees up the space previously occupied by horizontal sealing tables. In addition, a strategically positioned conveyor belt can also serve as a vertical glazing table, thereby optimising the layout of the work area Automation of sealing: To ensure a seamless seal, it is no longer necessary to juggle the window unit or struggle with fitting seals. The M9Cb automates this laborious process on both sides Time savings: Thanks to the M9Cb, the workflow is no longer one-dimensional. Whilst the machine takes care of sealing the windows and doors, the operator can work on other tasks, e.g. glazing, blocking, packaging... This versatility enables the operator to diversify their activities and thus offers them a more rewarding experience. ----- ----- Price of the above machine on request! Fsdpfszmy Ifsx Ab Esgi -----...

Condition: good (used), Year of construction: 1976, max. wheel diameter 2300 mm gear width 1000 mm max. module 22 min. module 1 total power requirement 45 kW Fjdpozr Rpdofx Ab Eogi weight of the machine ca. 22 t dimensions of the machine ca. 5x3x4 m

Condition: good (used), Year of construction: 2016, Traverses X Y Z: 508 x 406 x 394mm, Table 660 x 381mm, Spindle taper BT30, 11.2kW Spindle Motor giving 15,000rpm, HAAS Control, 20 Station ATC, Coolant. Fgedpfo Agn I Dex Ab Eoi

Condition: excellent (used), Year of construction: 1982, Used Noble & Lund Double Column Plano Milling machine model P/RLMA with vertical milling head and planing head. Serial #6344P Year of manufacture: October 1982. MACHINE FORMERLY INSTALLED AT ROLLS ROYCE PLC IN DERBY UK. IMMEDIATELY FOR SALE AND NOW LOCATED IN BELGUIM WHERE IT CAN BE INSPECTED. Fgjdpfxeh U Nvko Ab Eoi SPECIFICATION TABLE WORKING AREA 5’-0 x 16’ 0”( 1524mm x 4876mm) MAX COMPONENT HEIGHT 5’0 (1524 mm) DISTANCE BETWEEN COLUMNS 6’1” (1866mm) MAX. WEIGHT OF WORKPIECE 15000kgs RAM TRAVEL 4’0”(914mm) RAM SECTION 14” x 14”(355 x 355 mm) SPINDLE TAPER ISO 50 MILLING SPINDLE MOTOR 40HP (30Kw) MILLING FEED RATES / MIN 1”-48”/MIN( 25-1200MM/MIN) PLANING MOTOR 40HP(30 Kw) MILLING SPINDLE SPEEDS 7-835 RPM ELECTRICAL SUPPLY 415V 3Ph 50Hz LENGTH TBA MM WIDTH TBA MM HEIGHT TBA MM WEIGHT 42000 KGS NOTE: The information contained herein is provided in good faith, but however due to unforeseen errors or omissions cannot be binding as to accuracy.

Condition: good (used), Year of construction: 1984, Used TOS KAMENICEK model BUC63A x 3000 Universal cylindrical grinding machine. YEAR OF MANUFACTURE: 1984. MACHINE FORMERLY INSTALLED AT ROLLS ROYCE PLC IN DERBY UK. IMMEDIATELY FOR SALE AND NOW LOCATED IN BELGUIM WHERE IT CAN BE INSPECTED. SPECIFICATION Max Swing 630 mm Fodpeh U Rznsfx Ab Eogi Distance between centres 3000 mm Workhead swivel – towards wheelhead only 90 deg. mm Work spindle bored taper No. 6 M.T. Length of stroke of tailstock barrel 70 mm Tailstock barrel taper No. 6 M.T. Spindle nose clamping Din 55021 Swivelling of wheelhead + 30 deg – 10 deg Length of adjustment by re-circulating ball screw 290 mm Additional length of adjustment 250 mm Length of rapid feed 90 mm Length of infeed setting per each rev. of handwheel, measured on work diameter 0.5 mm Grinding wheel dia. X width X bore 750 x 80 x 305 mm Min. dia. of worn grinding wheel 570 mm Max. face width of grinding wheel 125 mm Rate of table traverse – steplessly variable 0.5-0.6 m/min Table traverse per 1 rev of handwheel 8 mm Swivelling of table +/- 5 deg. Max. permissible weight of work between centres 2500 kg Max. permissible weight of workpiece in chuck with overhang. (including weight of chuck) 150 kg Wheel spindle speeds (2) 840,970 rpm Grinding wheel surface speed 33 m/sec Work spindle speeds – int. var. in 2 ranges 8-50, 50-315 rpm Drive – total power required rated 31 kva Output of workhead motor 3 kw Output of wheelhead motor Electrics 15 kw 415V ,3Ph,50Hz Equipped with:- Additional wheel flanges, coolant system with clarifier and splash guards. FEATURES AND EQUIPMENT – Swivel Round Internal Grinding Attachment

Year of construction: 1994, condition: good (used), machine/vehicle number: 491P, Technical data: Fsdpedkx Ansfx Ab Eegi - Drilling capacity in steel ST 60: 28 mm - Drilling diameter in steel ST 60: 32 mm - Drill spindle mount: MK 3 - Right/left rotation - Drill spindle stroke: 150 mm - Drill spindle speeds, stepless: 80 - 1170 rpm - 2 feed rates: 0.1 / 0.2 mm/rev - Overhang: 290 mm - Max. distance table - drill spindle: 780 mm - Table with 2 T-slots: 480 x 400 mm - Height adjustable via rack and pinion with hand crank - Drive: 400 V / 0.9 / 1.3 kW - Space requirement, approx.: W 600 x H 2100 x D 900 mm - Weight, approx.: 420 kg - Includes: - Coolant system - Quick-change drill chuck 1-13 - Lighting

Condition: like new (used), Year of construction: 2020, functionality: fully functional, operating hours: 1,500 h, USED Akira Seiki 1600XP Fanuc 0iMF Open Fronted Vertical Machining Centre with Fanuc Ex Stock - Subject to Prior Sale. YOM 2020, Machine with Very Low Hours Usage. Approx 1500 Hours  12,000 RPM Spindle with Refrigeration System  36 Station Arm Type ATC  Full Splash Guard  Fully Integrated Detron GXA-255h 4th Axis Nc Rotary Table with SR255H Tailstock Support Unit Fgsdpjq Nmm Tofx Ab Eji  Chip Conveyor & Chip Bin (Scraper Type)  Chip Flushing System Including Coolant Wash Gun  Through Spindle Coolant System - 35 Bars with Filter  Fanuc Memory Extension - 2 Mb  Fanuc 10.4 “ Screen with Manual Guide-I  Coolant Tank Capacity - 640 Litres  THK Heavy Duty Linear Guideways  Manual Pulse Generator  3 Colour Signal Lamp  Automatic Lubrication System  Rigid Tapping & Helical Interpolation Function TABLE Working Surface 1,750 X 800 MM Tee Slots 18 x 125 x 6.0 MM Spindle Nose to Table 100 ~ 915 MM Spindle Centre to Column 865 MM Table Load Capacity 2,300 KGS TRAVEL X-Axis Travel 1,630 MM Y-Axis Travel 850 MM Z-Axis Travel 815 MM SPINDLE Spindle Nose Taper BT-40 Spindle Speed - Max 12,000 RPM FEED Rapid Traverse (X & Y-Axis) 33 M / MIN Rapid Traverse (Z-Axis) 25 M / MIN Cutting Feedrates - Max 12 M / MIN ACCURACIES Positioning 0.01 MM Repeatability + - 0.003 MM ATC Tool Storage Capacity ARM TYPE - 36 STATIONS Maximum Tool Weight 7.0 KGS Tool Diameter - Max 75 MM Tool Length - Max 250 MM Tool Shank BT-40 Tool Exchange Time 2.2 SEC MOTOR Spindle Drive Motor (FANUC) 18.5 KW POWER SUPPLY Voltage 415V / 3PH / 50HZ Power Requirement 30.0 KVA MACHINE DIMENSIONS Machine Floor Space Requirement 4,820 x 3,576 MM Machine Weight 12,600 KG

Condition: used, machine/vehicle number: 1484.04.01, No minimum price – guaranteed sale to the highest bidder! Loading: December 1st to December 10th. TECHNICAL DETAILS General Information Machine type: Precision coordinate grinding machine Machine weight: approx. 4.5 t Travel and working area X-axis travel: 700 mm Y-axis travel: 400 mm Workpiece height: 620 mm Internal grinding diameter: 250 mm Axial movement of the grinding spindle: 115 mm Work table Table size: 1,000 × 630 mm Feed and accuracy Feed rate: 0.5–63 mm/min Stroke: 5–100 mm Resolution: 0.001 mm Grinding spindles High-speed spindle: 30,000–60,000 RPM Additional spindle: 12,000–30,000 RPM Planetary spindle speed: 5–250 RPM Slide head Slide travel: ±50 mm Control and operation Digital control: ARKURITE VRO 300 Interface: RS 232 Speed adjustment: electronic, stepless Operating modes: manual and NC operation Performance data Total power consumption: 6 kW Dimensions Space requirement: approx. 2.375 × 2.470 × 2.560 m Fgjdpfx Ao Aa Aqaeb Eei EQUIPMENT High-speed spindle Second high-speed additional spindle Slide head Feed rate display Digital speed display Electronic stepless speed adjustment ARKURITE VRO 300 digital control RS-232 interface Switch for manual and NC operation Safety emergency stop

Condition: used, Year of construction: 1965, bore capacity in steel (diameter) 40 mm total power requirement 4 kW Fedpfov S Iqcjx Ab Esgi

Condition: used, Year of construction: 1981, thread length: 100 mm, overall weight: 4,310 kg, screw diameter: 12 mm, production capacity: 260 unit/h, Equipped with Vibratory Bowl & Stand Fgodpozt Tc Nefx Ab Eei

Condition: like new (used), Year of construction: 2024, operating hours: 2,026 h, functionality: limited functionality, machine/vehicle number: 28 zoll, type of input current: DC, overall weight: 45 kg, input voltage: 86 V, total length: 28 mm, total width: 28 mm, cubic capacity: 43 cm³, I am selling my 28-inch electric bicycle, which is still in perfect working order. All purchase documents are included. I bought it in February 2025. It has a Bosch 625W battery and can reach a speed of 245 km/h. Size: L. Fgsdpfxe Aa I Dxj Ab Eoi

Condition: used, machine/vehicle number: 208 597, No minimum price – guaranteed sale to the highest bidder! Loading: December 1st to December 10th. TECHNICAL DETAILS General Information Manufacturer: Hauser Machine Type: Coordinate Grinding Machine Type: 3SMO Machine Weight: approx. 2 t Working Area X-axis travel: 400 mm Fsdj Aaz Evopfx Ab Esgi Y-axis travel: 250 mm Workpiece height: 500 mm Grinding wheel diameter: 220 mm Overhang: 310 mm Angle range: 12° Vertical grinding slide adjustment: 110 mm Workpiece weight: max. 80 kg Work Table Table area: 600 × 320 mm Grinding Spindle Grinding spindle speed: max. 50,000 rpm Peripheral speed: max. 35 m/s Feed Rate Feed rate: 0–6 m/min Dimensions Space requirement: approx. 1.2 × 1.3 × 2.3 m EQUIPMENT Heidenhain 2-axis digital display Electrical control Work light Chip guard

Condition: used, machine/vehicle number: 2880, No minimum price – guaranteed sale to the highest bidder! Loading: December 1st to December 10th. TECHNICAL DETAILS General Information Machine type: Universal tool milling machine Machine weight: approx. 0.6 t Travel distances X-axis travel: 290 mm Y-axis travel: 120 mm Z-axis travel: 350 mm Work table Table clamping surface: 690 × 175 mm Spindle Spindle mount: SK 40 Speed stages: 17 Speed range: 50–2,240 rpm Spindle drive: dual-pole, switchable with clockwise/counterclockwise rotation Feed Feed range: 42–680 mm/min Feed stages: 14 Electric feed: X-axis Rapid traverse: X-axis via handwheel Milling head and horizontal milling Vertical head: rotatable ±90° Horizontal milling: possible via cross slide Operation and safety Handwheels: Vernier handwheels for all 3 axes Cam switch: 3-way in the X-direction for program sequence Emergency stop: present Main switch: present EQUIPMENT Rotatable vertical head ±90° Vernier handwheels for all 3 axes Fjdps Aaz N Isfx Ab Ejgi Rapid traverse via handwheel in the X-direction Electric feed in the X-direction Feed stages adjustable via change gears Cross slide for horizontal milling 3-way cam switch in the X-direction for program sequence Safety emergency stop Main switch

Condition: used, Year of construction: 1985, machine/vehicle number: 31268, No minimum price – guaranteed sale to the highest bidder! Loading: December 1st to December 10th. TECHNICAL DETAILS General Information Machine type: universal tool milling machine Machine weight: approx. 6.6 t Travel distances X-axis travel: 850 mm Y-axis travel: 700 mm Z-axis travel: 600 mm Quill stroke: 115 mm Work table Table surface: 900 × 700 mm Table swivel range: ±30° Table tilt range: ±30° Fjdpfx As Aa At Uob Eegi Table rotary range: ±45° Spindle and milling head Spindle speed: 30–6,000 rpm Spindle mount: SK 50 Spindle drive: 7.5 kW Milling head: swiveling in 2 axes Feed Feed rate: 0–6,000 mm/min Control Control system: Siemens Sinumerik 3 M Performance data Total power requirement: 32 kW Dimensions Space requirement: approx. 3.8 × 1.8 × 2.9 m EQUIPMENT Separate control cabinet Coolant system Automatic central lubrication Work light Safety emergency stop

Condition: used, Year of construction: 1970, No minimum price – guaranteed sale to the highest bidder! Loading: December 1st to December 10th. TECHNICAL DETAILS Travel ranges X-axis travel: 900 mm Y-axis travel: 250 mm Z-axis travel: 370 mm Fgedpfxo Aa Ayno Ab Eji Work table Table clamping surface: 1,525 × 325 mm Performance data Total power consumption: 9.85 kW Machine weight: approx. 3.1 t Dimensions Space requirement: approx. 2.0 × 2.5 × 1.7 m EQUIPMENT No information on accessories available.

Condition: good (used), Year of construction: 1973, FELLOWS 70-15 GEAR SHAPER - Model 70-15 Fellows heavy duty vertical gear shaping machine , suitable for the manufacture of external straight spur gears up to 70" pitch diameter, as well as internal spur gears and splines within a range of 0" to 88" pitch diameter, regardless of shaper-cutter radius. This unique feature, combined with the machines 15" face-width capacity and 1.7DP cutting capability in steel, provide a formidable platform for producing a wide range of larger geared part members. Equipped with: * Machine Main Base With Work-table, Upper Column, Cutter Ram and Slide of "Super Robust" Construction * Machine with "Saddle Backoff" Method of Cutter Relieving * Cutter Spindle 6.25" diameter w/Standard Straight Spur Guide * Cutter Positioning via Stroke Jog-Button * Rapid Rotation of Work Spindle for Trueing Work-Piece * Rapid Saddle Traverse for Traversing Saddle Relative to Work * Automatic Depth Feed Mechanism for One to Four Cuts, With 4 Speed Motor Providing Speed Change on Finishing Cut * Assorted Work and Feed Change Gears * Assorted Stroke Change Gears * 2" Riser Plate * Main Drive Motor 15HP, 650/220 rpm, 240 Volt 60Hz w/Westinghouse Rectifier Unit for AC * Power Forced Lubrication to Working Elements with "Lubriquip Lub Controller" * Coolant Tank, Pump, and Piping, With Chip Pan * Full Complement of Electrics * Assorted Guards, Covers * 84" T-Slotted Table * Hydraulic System Fjdpsrtrxiofx Ab Eogi * Work Lamp * Work Platform * Cutter Adaptor * Manuals Specifications: Max. Diameter External Gear Cut (Nominal): 70" Max. Diameter Internal Gear Cut (Nominal): 88" Max. Diameter Workpiece Accommodated: 104" Worktable Diameter: 84" Max. Permissible Weight of Workpiece & Fixture: 36,000 Lbs. Max. Distance Workspindle Centerline to Centerline of Cutter Spindle: 35" Min. Distance Workspindle Centerline to Centerline of Cutter Spindle: 0" Max. Work & Fixture Clearance Height w/Cutter Spindle in Upper Position: 28" Max. Diametral Pitch (full length teeth): 2 DP Max. Diametral Pitch (stub teeth): .75 DP Max. Diameter Pitch (30P.A. splines): 2-5/5 DP Diameter of Cutter Spindle: 6.25" Max. Stroke Length: 19.118" Max. Face-Width (nominal): 15" Stroking Speeds (infinitely variable): 5 to 122 S.P.M. Max. Infeed of Cutter Ram: .0020 inch/min. Min. Infeed of Cutter Ram: .0005 inch/min. Max. Rotary Feed Per Stroke (per 1" of cutter diameter): .0068"/Min. Min. Rotary Feed Per Stroke (per 1" of cutter diameter): .0006"/Min. Approximate Machine Dimensions: 192"L x 144"W x 150"H Approximate Machine Weight: 95,000 Lbs.

Condition: good (used), workpiece diameter between centers: 2,286 mm, The No. 61 Angular Hypoid Tester is designed to test large bevel and hypoid gears up to 90" diameter and with shaft angles from 0 - 135 degrees. Spur, helical and internal gears can also be accommodated. The drive or pinion spindle can be rotated in either direction at a recommended spindle speed of 600 RPM. It is mounted in a head which is vertically adjustable on a column, so that the spindle can be offset either above or below the center line of the gear spindle for testing hypoid gears. The pinion head column is adjustable angularly in a horizontal plane to permit testing of gears of any shaft angle from 0 - 135 degrees. Specifications: Centerline of Drive Spindle to Nose of Brake Spindle (90 degrees shaft angle and without face plate): 38-1/2" Max. / 7-5/8" Min. Centerline of Brake Spindle to Nose of Drive Spindle (90 degrees shaft angle and without face plate): 60" Max. / 10" Min. Centerline of Brake Spindle to Nose of Drive Spindle (90 degrees shaft angle and with 54" face plate): 60" Max. / 28" Min. Centerline of Brake Spindle to Centerline of Drive Spindle (For Spur Gears): 56" Max. / 6" Min. Distance Between Nose of Brake Spindle and Nose of Drive Spindle (for spur gears): 36-1/2" Max. / 0" Min. Offset of Drive Spindle Either Above or Below Centerline of Brake Spindle: 10" Range of Shaft Angles: 0 - 360 Degrees Maximum Diameter of Gear: 90" Diameter of Face Plate: 54" Outboard Bearing: 3" Diameter Hole Spindles: RPM of Drive Spindle Pulley Set No. 1: 100 - 400 RPM of Drive Spindle Pulley Set No. 2: 250 - 600 Diameter of Taper Hole (large end): 6" Taper Per Foot: 3/4" Depth of Taper: 8" Hole Through Spindle: 5-1/2" Net Weight of Machine: 20,000# Fsdpfsrtrzdox Ab Ejgi Net Weight of Machine W/Outboard Support and Bed Plate: 24,000#

Condition: good (used), Year of construction: 1998, grinding wheel diameter: 915 mm, overall weight: 14,000 kg, GIUSTINA Grinder R242 to ground big bearings (up to 800mm). All machine's actions are controlled by Bosch Control. Fgjdpfx Asrtr D Isb Eji Beside controlling parts grinding process, the NC programs are also an operator guide for the machine set up and a source of information about wheel wear, thus allowing the operator to check wheels without opening the hood. Equipped with: Bosch CNC Control Specifications: Wheel Rotation Axis: Horizontal Grinding Wheel Size (OD): 915 mm Grinding Wheel Size, Usable Width: 65 mm Grinding Wheel Size, Peripheral Speed: 30 ms Spindle Motors: 75 kw Grinding Feedrate: 0.1 - 1000 mm/min Spindle Type: Moving Quill Angular Contact Spindle Bearings (Precision): ABEC-7 (ISO4) Slide Position Accuracy: 0.001 mm Coolant Flow Rate: 600 l/min Work Capacity (Approx) Rotary: 20 -200 Dia. In.
