AMADA HRB 1003

AMADA HRB 1003

Condition: used, Year of construction: 2004, pressure 80 t chamfer lenght 2550 mm distance between columns 2050 mm Stroke beam 350 mm max. opening beam/table 620 mm C-recess 420 mm traveldistance X1+X2 cnc programmable 700 mm Z1+Z2 axes controlled by cnc 0-2000 mm max. distance R-axes 200 mm Quick speed,inspeed 100 mm/sec bendingspeed 0-10 mm/sec opening speed 100 mm/sec Number of working hours 24000 h length 3380 mm width 1800 mm Dcsdpfx Ajxyzzasffsf height 2750 mm weight 6100 kg total power requirement 9 kW dimensions of the machine ca. 3x2x2,5 m All machines can be viewed under power at all times. Demonstrations of the machines possible at any time.

Condition: as good as new (ex-display), Year of construction: 2024, operating hours: 158 h, arm reach: 1,300 mm, Hello, Dedpfx Asp E T N Asffjcf we are selling a demonstration robot UR10e, was used for a concept study but was discarded.

Condition: excellent (used), Year of construction: 2017, operating hours: 3,200 h, pressing force: 130 t, Space requirement: 11,500 mm x 10,000 mm + Increased installation height/lift + 230 mm + 4-axis backgauge system + Rear work area lighting + Front work area lighting - TruBend documentation Automation BendMaster (60) Standard equipment: BendMaster - Sturdy base frame and manipulator made of cast aluminum construction - Load capacity 60 kg, sheet plus gripper - Low-level floor track in welded construction - Sheet sensor for contour detection - Rotary feedthrough for quick gripper change Gripper coupling on the BendMaster - Sensor system for 4-axis backgauge system - Electric drives - Double sheet detection - NC regrip station - Vacuum generation for suction grippers Control - TRUMPF PC control with operator terminal - Teleservice via internet - Convenient operation: screen, mouse, keyboard Safety - Safety fence with access door Special equipment + Track extension to 10 m + Gripper change console + Modular vacuum gripper without separation (materials for 3 grippers) + Modular vacuum gripper with separation (materials for 3 grippers) + Clamp gripper with rotary axis + Sheet removal station with linear axis + Additional pallet for sheet removal station + Right-hand side door for safety fence (or left-hand side in combination with ToolMaster) Machine - Robust machine frame entirely in steel construction - Press beam - Spherical mounting of pressure beam with inclined position - Electro-hydraulic upper drive system with 4-cylinder technology - Optical set-up and positioning assist with control valves Dcodpfjxayl Dex Affef - Generous free space for bending - Flat front covers - Block hydraulic system - Electronic pressure gauge - Measuring system with glass scale and spring-back compensation - Hydraulic oil in machine (lifetime lubrication) - Oil cooler - Electrical cabinet cooling via air-to-air heat exchanger - Modern machine design Backgauge System - 2-axis backgauge system, X and R axes Tool Clamping - Hydraulic upper tool clamping - Lower tool holder, hydraulic clamping, hardened - Lower tool displacement, 2 positions, pneumatic Crowning - CNC crowning Control - TRUMPF TASC 6000 - Graphical workshop programming - Windows XPe (embedded), Pentium 4 with 2.8 GHz clock speed - 2 GB RAM - 15-inch touch screen - Network capability - Teleservice via internet Operation - Control panel with LCD keypad and foot switch - Communication rail - MobilControl Safety - Standard safety equipment - CE marking

Condition: like new (used), Year of construction: 2024, operating hours: 50 h, functionality: fully functional, arm reach: 1,300 mm, The perfect package for your welding automation with the very latest UR10e robot series - please do not buy any more CB series. Would you like to automate your welding shop with a cobot to master your future challenges? Then the OH-au2mate Cobot Welding Solutions with Lorch power source is just right for you! The perfectly coordinated package combines - high-quality robot technology from the cobot market leader Universal Djdpfx Aet S U Aueffocf - innovative welding technology from Lorch - intuitive operating software Exact contents of the package: UR10e robot welding machine, operating elements, torch holder, Translas 8XR extraction torch, Lorch S5 power source with 400A.

Condition: like new (used), Year of construction: 2013, functionality: fully functional, Weiler Praktikant VCD Precision Lathe Manufacturer: Weiler Model: Praktikant VCD Precision Lathe Year of manufacture: 2013 Condition: used, very good, as-new condition, no signs of wear, incl. new servicing and measurement protocol prior to sale Centre distance: 650 mm Centre height: 160 mm Swing diameter over bed: 320 mm Swing diameter over cross slide: 190 mm Cross slide travel: 150 mm Top slide travel: 110 mm Top slide swivel range: +/-65° Bed slide guide length: 350 mm Dodpfx Aex I Rtkjffecf Bed width: 205 mm Turning tool cross-section (height x width): 20 x 20 mm Height from top slide to centre: 30 mm Spindle nose according to ISO DIN 702-3 (DIN55027) size 5 Spindle diameter at front bearing: 70 mm Spindle bore: 43 mm Main spindle taper metric 50 Drive power: 6 kW Speed range: 30 – 4000 rpm Number of gear stages: 1 Number of speed ranges: stepless Number of feeds: 24 Longitudinal feed: 0.02 – 0.63 mm/rev Facing feed: 0.006 – 0.2 mm/rev Quill diameter: 40 mm Quill travel: 85 mm Quill taper: 3 Morse taper Weight, without packing and accessories, approx. 1150 kg Length / Width / Height, net: 1720 x 890 x 1700 mm Headstock / rear wall / sliding safety cover: Light grey RAL 7035 Machine base / machine bed: Basalt grey RAL 7012 Screen display housing: Blue NCSS 4550-R80B

Condition: new, Year of construction: 2024, cutting height (max.): 150 mm, cutting range round steel at 45°: 108 mm, cutting range round steel at 90°: 108 mm, BERG+SCHMID GBS 218 Eco AutoCut double mitre bandsaw Speed: 25-80 m/min - Mitre left 60° - For cutting steel, stainless steel and aluminum profiles - Quick-clamping vice with quick-clamping device a. - Built-in blade tension control b. - Saw blade guide made of carbide c. - Electric automatic cooling system - Machine base (supplied disassembled) Dodpfx Aet I R Edjffjcf The AutoCut system consists of: - Hydraulic cylinder, feed control, spring assembly, limit switch and enables three work sequences: 1. automatic lowering of the saw frame via hydraulic cylinder with infinitely adjustable feed control valve and limit switch at the end of the cut 2. high-speed lowering of the saw frame from the rest position up to the workpiece, then switching to normal saw feed 3. manual operation - hydraulic cylinder works as a brake cylinder Saw blade dimensions: 2455x27x0.9mm Further accessories such as saw bands, roller conveyors, measuring stops, minimum quantity lubrication etc. available on request! Delivery time: ex stock Waiblingen Beinstein

Condition: good (used), Year of construction: 2010, functionality: fully functional, operating hours: 15,996 h, input voltage: 400 V, overall weight: 6,750 kg, 1000 KN Max. stroke: 200 Weight: 6750 Noise level: 74 dB Year of manufacture: 07/2010 Voltage: 400 V / 50Hz Rated current: Current operating hours: 15,996 hours with manual angle measurement and correction system with safety laser UVV inspection on a regular basis / maintenance always carried out by Amada on a regular basis Accessories: Tool die: Dedpfstwliwox Affecf 2 pieces UKB 20.478 V8/12 30° 835mm 3 pieces UKB 20.344 V4/V7 88° 835mm Tool holder: 4 pieces UKB substructure for double V die 20.287 + 60.919 835mm Bending swords: 5 pieces UKB 10.261 H100 R0.6/90° 2 pieces UKB 11.158 H80 R0.6/30° 2 pieces UKB 11.200 H66 R0.8/90° Other: Light barrier in need of repair (new price approx. €4500) – separately as a replacement as an attachment (has been renewed) The machine can be inspected under power in DE84051 Mettenbach by appointment. Sale only to commercial customers and with exclusion of any warranty!

Condition: used, Year of construction: 2004, functionality: fully functional, Amada HFE 220- L Year of construction 2004 Laser height adjustment Working width 3100mm Dsdpfxsuiwyps Affecf pressing force 220 tons with many tools

Condition: used, Year of construction: 1996, spindle passage 80 mm max. turning diameter 395 mm Max. Turning length 750 mm control System TX 8H Dedpfxoxbtqvo Affjcf max. Spindle speed 3.150 U/min. CNC lathe | TRAUB - TNA 400 The machine is in a well-maintained condition. - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - #Tags:TNA400 | TNA-400

Condition: as good as new (ex-display), Year of construction: 2025, operating hours: 50 h, functionality: fully functional, A welding robot system is for sale with the following contents: Elite Robot CS620 (1750mm range) with programming flange and software Fronius TPSi 500 Positioner rotateZERO 500 with 1800mm x 800mm intermediate frame Machine frame System is ready for welding immediately Dcedpfx Asv Dvlleffef
