3-POINT HEAD

BIESSE

Condition: ready for operation (used), Year of construction: 2022, machine/vehicle number: 1000056636, functionality: fully functional, cutting width (max.): 3,500 mm, overall weight: 3,969 kg, cutting length (max.): 3,200 mm, No minimum price – guaranteed sale to the highest bidder! TECHNICAL DETAILS Max. cutting length: 3,200 mm Max. cutting width: 3,200 mm MACHINE DETAILS Dimensions & Weight Dimensions (L x W x H): 8,000 x 2,400 x 2,400 mm Weight: 3,969 kg Iodpfx Ajz Ni Eqjp Djtn Shipping packages: 4 units EQUIPMENT CE marking Documentation

Condition: ready for operation (used), Year of construction: 2009, travel distance X-axis: 6,200 mm, travel distance Y-axis: 1,520 mm, travel distance Z-axis: 660 mm, number of axes: 5, number of slots in tool magazine: 22, controller manufacturer: BIESSE, controller model: XP600, spindle speed (max.): 22,000 rpm, This 5-axis BIESSE Rover C 6.65 was manufactured in 2009. It features a working area of 6,200 x 1,520 x 275 mm and a powerful main electrospindle with a maximum speed of 22,000 RPM. The machine includes a 22-position tool changer and an integrated vacuum system for efficient operation. If you are looking to get high-quality CNC machining capabilities, consider the BIESSE Rover C 6.65 CNC processing center we have for sale. Contact us for further details. Iodpfx Aoz Trctjp Dotn - Control Unit: Biesse XP600 (Upgraded to PC with Windows 10 OS in 2021)- Main Electrospindle Power (S1 100%): 12 kW @ 12,000 RPM- Main Electrospindle Power (S6 40%): 15 kW @ 12,000 RPM- Max Spindle Speed: 22,000 RPM- Tool Interface: HSK F63- C-Axis: 360° continuous rotation (Replaced complete in 2015)- B-Axis: +/- 100° (positioning), +/- 98° (interpolation)- Z-Axis Stroke: 660 mm- Z-Axis Feed Speed: 30 m/min- Drilling Head: BH 9 (5 vertical spindles at 32 mm pitch in Y, 2 horizontal double-output spindles)- Tool Changer: 22-position chain-type tool changer (180 mm pitch, max tool dia 250 mm) + 1-position Pick-up tool changer- Work Table: 10 ATS work tables (L = 1,525 mm), 30 module supports with Electronic Positioning System (EPS X-Y)- Vacuum System: Vacuum pump 250 m³/h (Replaced in 2016)- Cooling Unit: 1,600 W liquid cooling unit for electrospindles- Chip Conveyor: Integrated chip transport belt in machine bed- Optional Equipment: Uniclamp clamping devices (20 double-stroke, 10 round), 8 horizontal clamps, 20 vacuum modules (132x146 H74mm), 6 vacuum modules (132x75 H74mm), 8 positioning aids (36 kg lift force each), saw blade 350 mm Z=28, safety fence elements, control cabinet with air conditioning.- Software: NC-Hops 5-axis license, ACADemy 2D CAD, Automatic suction cup positioning module.

Condition: used, total height: 2,200 mm, total length: 5,350 mm, total width: 1,200 mm, Year of manufacture: 2018 Colour: White Weight: 3.500 kg - Year: 2018 - Documentation available: Yes - CE marking present: Yes - Serial number: 1000022855 - Number of units [pcs]: 8 - └ 1st unit type: Pre-milling unit Iodpfx Aozw El Rep Djtn - - Tools available: Yes - └ 2nd unit type: Glue unit - └ 3rd unit type: Pressure rollers - - Tools available: Yes - └ 4th unit type: Cap unit - - Tools available: Yes - └ 5th unit type: Rough milling unit - - Tools available: Yes - └ 6th unit type: Radius scraping unit - - Tools available: Yes - └ 7th unit type: Flat scraping unit - - Tools available: Yes - └ 8th unit type: Brushing unit - - Tools available: Yes - Min. edge band thickness [mm]: 0.4 - Max. edge band thickness [mm]: 3 - Edge band height [mm]: 64 - Min. panel thickness [mm]: 10 - Max. panel thickness [mm]: 60 - Min. panel width [mm]: 85 - Max. panel width [mm]: 3200 - Min. panel length [mm]: 140 - Max. panel length [mm]: 3200 - Min. feed speed [m/min]: 12 - Max. feed speed [m/min]: 18 - Feed speed control: Variable - Left or right-sided: Yes - Max. spindle speed [rpm]: 12000 - Voltage [V]: 400 - Current consumption [A]: 20 - Fuse [A]: 32 - Power [kW]: 11.0 - Transport dimensions: 5350mm x 1200mm x 2200mm (l x w x h) - Transport weight [kg]: 3500kg - Transport packages [pcs.]: 1 Financial information VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Delivery and trade-in always possible for everything in the industrial sectors Yorick Diebels

Condition: used, machine/vehicle number: 008689, X axis working area: 6735 mm Y axis working area: 1650 mm Working Table: Pod and Rail Main Electrospindle power: 13.2 KW Number of controlled axes: 4 axes Maximum edge height: 65 mm Total number of drilling spindles: 30 Total number of tool changer positions: 22 Itodjznuxbspfx Ap Djn

Condition: used, machine/vehicle number: 008470, X axis working area: 4300 mm Y axis working area: 2205 mm Working Table: Flat table Main Electrospindle power: 13 KW Ijdpfxoyzyrvs Ap Detn Number of controlled axes: 5 axes Total number of drilling spindles: 46 Total number of tool changer positions: 22

Condition: used, machine/vehicle number: 008782, Max. panel width: 3200 mm Max. panel length: 1000 mm Ijdpsz S T Unsfx Ap Dotn No of Bottom Units: 5 No of Top Units: 2 Positioning of Units by NC: yes Lateral horizontal groups: yes

Condition: used, machine/vehicle number: 008438, Max. panel width: 4500 mm Max. panel length: 4500 mm Itedjyngy Sepfx Ap Den Main saw blade projection: 50 mm No of Grippers: 8

Condition: used, machine/vehicle number: 008606, Max. panel width: 3200 mm Max. panel length: 1000 mm No of Bottom Units: 5 No of Top Units: 2 Positioning of Units by NC: yes Lateral horizontal groups: yes Iedszqz Rcopfx Ap Dotn

Condition: used, machine/vehicle number: 008694, X axis working area: 4320 mm Y axis working area: 1287 mm Working Table: Pod and Rail Main Electrospindle power: 11 KW Itedpszqz Nxsfx Ap Den Number of controlled axes: 5 axes Total number of drilling spindles: 16 Total number of tool changer positions: 31

Condition: excellent (used), Year of construction: 2022, Manufacturer: BIESSE Model: AKRON 1440 A Category: Edge banding machine Year of manufacture: 2022 Availability: short notice Itjdpjzb Aicofx Ap Don Operational status: disassembled/stored Technical data Maximum edge banding thickness: 12 mm Maximum panel thickness: 60 mm Maximum thickness of roller material: 3 mm Minimum workpiece length: 140 mm Minimum workpiece width: 50 mm Minimum feed rate: 12 m/min Maximum feed rate: 18 m/min Feed rate: stepless Height adjustment: motorized Belt overpressure Gluing system: granulate Glue reservoir: top Quick-change glue reservoir Suitable for PUR adhesives Strip magazine Spraying device Edge trimming unit Preheating zone Pressure zone, NC-controlled Miter saw unit: 2 motors Edge trimming/radius/chamfer stations: 1 Corner copying unit: 2 motors Pulling blade unit Profile pulling blade, flat pulling blade Smoothing unit Nesting equipment Edge trimming/radius/chamfer stations, profile pulling blade Units controlled by timer NC axis(es) Profile change: automatic Edge trimming/radius/chamfer stations Design: left-hand machine Machine length: 5,610 mm Control system: BIESSE SMART TOUCH 23" Conformity marking: CE marking, EAC marking Total connection: 13 kW Weight approx.: 2,250 kg Location: at customer's site - available immediately - As it is disassembled/stored.
