Machining Center - Universal

Bimatec Soraluce FR 9000

Condition: used, Year of construction: 2013, x-travel 9000 mm y-travel 3200 mm z-travel 1900 mm w-axis 700 mm V-axis 3000 mm control Siemens 840 D SL Table Drehverschiebetisch 2 Stück table load max. 20 t Ndsdpfx Aeyr Aqzefuob Tool changer 120 pos. tool taper SK 50 size of pallet 2200x1500 mm spindle power 46 kW Workpiece interferece circle diameter: 2500 mm Orthotic head power: 46 kW Aggregate (pick-up max. 6 positions): Quill diameter 130 mm Orthotic head 1x1 degree The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale; Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team

Condition: ready for operation (used), Year of construction: 1995, functionality: fully functional, machine/vehicle number: 4304, rotary table diameter: 600 mm, grinding height: 450 mm, overall weight: 14,500 kg, Machine is equipped with 3 spindles, surface grinding, external grinding, bore grinding Njdpfxjvt A Rto Afuodb Turret head B-axis with 1° division Belt filter system included

Condition: used, TECHNICAL DETAILS - Number of axes : 8 - Number of spindles : 2 MAIN SPINDLE - Max. bar diameter : 25.4 [mm] - Max. machining length : 200 [mm] - Spindle speeds : 10000 [rpm] - C axis indexing precision : 0.1 [°] COUNTER-SPINDLE - Max. bar diameter : 20 [mm] - Spindle speeds : 10000 [rpm] - Spindle power : 3.7 [kW] - C axis indexing precision : 0.1 [°] - Number of guide bush holders : 2 GUIDE BUSH HOLDER 1 - Number of positions : 5 GUIDE BUSH HOLDER 2 - Number of positions : 5 - Number of motorized positions : 4 - Live tools speed : 8000 [rpm] SECONDARY OPERATION - Number of positions : 7 - Number of motorized positions : 3 - Live tools speed : 8000 [rpm] POWER SUPPLY - Supply voltage : 400 [V] - Total installed power : 14 [kW] WEIGHT & DIMENSIONS - Machine floor space : 2270 x 1650 [mm] - Machine height : 2200 [mm] - Machine weight : 3500 [kg] MACHINE HOURS Ndedpfsuhaycsx Afuob - Number of hours under power : 46571 [h] EQUIPMENT - CNC : Fanuc - Rotating tool motor on : S2 - Rotating guide bush - Parts catcher - Ejection of workpiece - Chips conveyor : KNOLL - Coolant tank * with high-pressure pump : 100 [bars] - Bar loader : TORNOS ROBOBAR SSF - Oil mist extractor : Elbaron - Fire extinguisher * * NB : working order not guaranteed. To have it checked by a qualified organization of the buyer.

Condition: used, Year of construction: 2003, x-travel 800 mm y-travel 600 mm z-travel 805 mm Control Sinumerik 840D weight of the machine ca. 13 t 1 horizontal machining centre Make: HECKERT type: CWK 500D year 2003 serial no. 16087 control, make: Siemens, type: Sinumerik 840D travel X/Y/Z 800 x 600 x 805 mm 2-fold pallet changer pallet size 500 x 500 mm NC-rotary table 360 x 0,001° 60-fold tool changer, tool holder HSK 63 Speed max. 15,000 rpm IKZ 50 bar Operating hours 32,450 Spindle hours 6.080 Nodpfeuddgfex Afusdb Accessories: Coolant temperature control, belt filter, chip conveyor, spindle cooling, Infrared probe preparation

Condition: ready for operation (used), Year of construction: 2009, operating hours: 1,000 h, spindle speed (max.): 2,600 rpm, travel distance X-axis: 360 mm, travel distance Y-axis: 120 mm, travel distance Z-axis: 980 mm, spindle motor power: 22,000 W, overall weight: 7,000 kg, controller manufacturer: SIEMENS, controller model: 840D Solution Line, number of axes: 4, This 4-axis SPINNER TC800 was manufactured in 2009. It features a radial turret and is equipped with Siemens control, ensuring reliable operation. With approximately 1,000 operating hours, this machine has been barely used. If you are looking to get high-quality turning capabilities, consider the SPINNER TC800 horizontal turning machine we have for sale. Contact us for further details. • Control: Siemens 840D Solution Line • Rapid traverse X-axis: approx. 18 m/min • Rapid traverse Z-axis: approx. 24 m/min • Main spindle speed: up to approx. 4000 rpm • Main spindle power: approx. 24 kW (100%) • Main spindle power: approx. 33 kW (40%) • Spindle nose: A11 • Bar capacity: approx. 77 mm • Counter spindle: Yes • Counter spindle speed: up to approx. 5000 rpm • Counter spindle power: approx. 15 kW • Counter spindle spindle nose: A6 • Counter spindle bar capacity: approx. 52 mm • Tool turret type: VDI 50 • Number of tool stations: 12 • Driven tools: Yes • Number of driven tools: up to 12 • Driven tool speed: up to approx. 4000 rpm • Maximum turning diameter: approx. 500 mm • Maximum swing over bed: approx. 800 mm • Maximum turning length: approx. 800 mm • Tailstock: Yes • Tailstock taper: MK4 • Tailstock stroke: approx. 100 mm • Tailstock force: approx. 8500 N • Voltage: 400 V • Frequency: 50/60 Hz • Control voltage: 24 V DC Ndedpfeyv Epvsx Afujb • Compressed air pressure: approx. 6–10 bar • Hydraulic pressure: approx. 70 bar • Chip conveyor: Yes • Coolant system: Yes • Hydraulic unit: Yes • Electrical cabinet: Yes • Radial turret • No quill • Barely used, approximately 1,000 operating hours Technical Specification Counter Spindle Yes Driven Tools Yes

Condition: used, Year of construction: 2007, Technical details: Ndedpfxox A S Rdj Afusb pressure: 225 t chamfer lenght: 4100 mm height of stroke: 400 mm throat: 250 mm dayligth: 917 mm total power requirement: 30 kW dimensions of the machine ca.: 5500 x 2270 x 3310 mm weight of the machine ca.: 22 t

Condition: good (used), Year of construction: 2007, control 840 D x-axis 2500 mm Nedpfx Afjwzyp Usujdb y-axis 2500 mm z-axis 1700 mm Control system - Siemens Sinumerik 840 D Max. workpiece weight - 6000 kg Spindle diameter - 130 mm Quill stroke - 700 mm Tool holder - ISO 50 DIN 69871 - AD Max. torque at the spindle - 1847 Nm Total power requirement - 65 kW Machine weight approx. 45 t Space requirement approx. 10.9 x 9.3 x 5.7 m

Condition: used, Year of construction: 2019, Technical details: Njdjzp Itbepfx Afuedb x-travel: 16000 mm y-travel: 4000 mm z-travel: 1600 mm

Year of construction: 2001, condition: ready for operation (used), A CNC 3-axis milling machine Hurco is available. Travel X/Y/Z: 760mm/510mm/610mm, table dimensions X/Y: 1020mm/510mm, max. table load: 1360kg, speed: 10000rpm, tool stations: 18, tool holder: SK40, rapid traverse: 30m/min. Machine dimensions X/Y/Z: approx. 2700mm/2200mm/2400mm, weight: approx. 4000kg, control: Hurco Ultimax, spindle hours: approx. 10500h. Documentation available. An on-site inspection is possible. Nedjw Dfg Djpfx Afuedb

Condition: ready for operation (used), Year of construction: 2015, operating hours: 6,361 h, functionality: fully functional, travel distance X-axis: 600 mm, travel distance Y-axis: 560 mm, travel distance Z-axis: 510 mm, rapid traverse X-axis: 36 m/min, rapid traverse Y-axis: 36 m/min, rapid traverse Z-axis: 30 m/min, controller manufacturer: Siemens, controller model: 840D ShopMill, workpiece length (max.): 900 mm, workpiece width (max.): 560 mm, workpiece height (max.): 630 mm, workpiece weight (max.): 600 kg, total height: 3,000 mm, total length: 4,000 mm, total width: 5,000 mm, table width: 900 mm, table length: 560 mm, table load: 600 kg, overall weight: 5,000 kg, spindle speed (max.): 12,000 rpm, operating hours of spindle: 6,361 h, spindle nose: SK40 (DIN69871), number of spindles: 1, number of slots in tool magazine: 30, input voltage: 400 V, Equipment: chip conveyor, documentation/manual, rotational speed infinitely variable, Beschrijving Deze Japanse DMG MORI ecoMill 600V hebben wij werkend uit productie overgenomen en is in frisse staat. De CMX 600V (ecoMill 600V) is voorzien van een C-frame constructie (klassieke opbouw) en beweegbare tafel (x-as) wat bedoeld is voor algemeen/all-round freeswerk. Aanvullende opties & accessoires: Siemens 840D SlimLine incl. 3D-simulatie. PROGRESSLine (weergave van de resterende productietijd en het aantal stuks van een volledig bewerkingsproces). Spanentransporteur Spoelpistool Voorbereiding voor interne cooling. Originele documentatie Nsdsy Dg Euepfx Afuodb Gewicht & afmetingen: 400x500x300 cm +/- 5.000 kg
