BLOHM HFS 12

BLOHM HFS 12

Condition: ready for operation (used), TOS Gear Hobbing Machine FO16 Maximum wheel diameter: 1,600 mm Gear width: 560 mm Maximum module: 16 Maximum workpiece weight: 7,000 kg Table surface area: 1,350 mm Fodpfx Agsxwl R Torspb Turning speed range: 16–80 rpm Feeds – axial: 0.05–1.5 mm/min Feeds – radial: 0.25–6 mm/min Feeds – tangential: 0.13–4 mm/min Electrics – voltage/frequency: 380/50 V/Hz Total power requirement: 12 kW Machine weight approx.: 18.5 t Machine dimensions approx.: 4.3 x 2.0 x 3.2 m The machine includes one additional head, change gears, and arbors. Video of the machine under power available.

Condition: used, Technical details: x-travel: 6500/13150 mm y-travel: 4000 mm z-travel: 1250 mm w-axis: 2250 mm table surface area: 5500/12150 x 3000 mm max. workpiece weight: 70.000/105.000 kg ram head dimension: 480 x 510 mm milling spindle motor: 63 kW max. torque on the spindle: 3300 Nm tool taper: DIN 39871 AD ISO 50 milling head speed: 6,3 - 4000 U/min feed speeds: 1 - 24000 mm/min w-axis: 1 - 6000 mm/min. distance between columns: 3500 mm passage: 3000 mm total power requirement: 120 kW weight of the machine ca.: 245 t dimensions of the machine ca.: 29,0 x 7,7 x 8,1 m The machine is in mint condition and was generally overhauled in 2020! with CNC SIEMENS 840 D autom. tool magazine for 153 tool stations autom. milling head magazine for 6 heads milling heads - straight - straight extended length - milling head -angular head standard - 4000 rpm, 144 x 2,5°, ISO 50 milling head -angular small extended length -40 kW, 4000 rpm, 1800 Nm, 144 x 2,5°, ISO 50 milling head -universal index - 40 kW, 4000 rpm, 2100 Nm, C-axis 144 x 2,5° , B-axis +/- 44 x 2,5°, ISO 50 Fedswc A Shspfx Agrjpb coolant attachment, chip conveyor *

Condition: good (used), grinding diameter: 1,600 mm, grinding length: 6,000 mm, Manufacturer: CINCINNATI Type: 60 x 216 Year of manufacture: 1970 Covex and Concave grinding 6 steady rest included 2 steady rest hydrostatic Coolant system with magnetic filter Measuring system with 5 arms caliber: Arm 1: Working area 1300 to 1600 mm Arm 2: Working area 1000 to 1300 mm Arm 3: Working area 700 to 1000 mm Arm 4: Working area 400 to 700 mm Specifications Metric US Standard Center height 787 mm Grinding diameter Ø 1574 mm Grinding length 5800 mm Grinding stone dimensions 914 x 101.6 x 304.50 mm Grinding stone speed 1800 rpm Dimensions (estimate) Length Fjdpfx Agovvvw Eoropb 15100 mm Width 5500 mm Height 3550 mm Weight 120000 kg Please note: The information on this page is correct to the best of our knowledge and belief and, where possible, has been obtained from the manufacturer. The information is given in good faith but accuracy cannot be guaranteed. Accordingly, it will not constitute a representation and terms of contract. We recommend that you check all important details.

Condition: used, functionality: fully functional, turning diameter over cross slide: 380 mm, spindle bore: 72 mm, turning diameter: 600 mm, Manufacturer: Gurutzpe Model: Super M 300 Admissible dimensions: Distance between centers: 3,000 mm Diameter over bed: 600 mm Diameter over carriage: 360 mm Diameter over gap: 780 mm Bed width: 415 mm Spindle bore: 72 mm Speeds: 18 speeds available: from 16 to 1,000 rpm Fsdewtwqajpfx Agrepb Motor: Power: 10 HP Equipment: Fagor digital readout Quick-change toolpost 4-jaw self-centering and adjustable chuck Steady rest General condition: Lathe in good condition

Condition: excellent (used), Year of construction: 2001, center height: 525 mm, workpiece weight (max.): 5,000 kg, grinding length: 4,000 mm, grinding wheel diameter: 1,060 mm, The machine underwent a retrofit in 2024. Control: Siemens Sinumerik 840D. Fodpfx Agew Ngm Usrepb

Condition: good (used), Year of construction: 1988, turning diameter over cross slide: 900 mm, spindle bore: 105 mm, turning diameter: 1,200 mm, turning length: 5,000 mm, total length: 8,000 mm, total width: 1,800 mm, total height: 1,550 mm, bed width: 650 mm, workpiece weight (max.): 10,500 kg, Motorized tailstock CE-Chuck cover protection Fpsdpfx Aewrxpbogreb Telescopic guide cover over guideways Steady rest  4 chuck 1000 mm diameter 3 chuck 500   mm diameter   2 Axis digital read out system DBC Turning Length: 5000mm Swing over bed Ø: 1150mm Swing over cross slide Ø:850mm Spindle bore: 105mm Bed width: 650mm Tailstock spindle Ø: 140Ø Stroke pinole: 300mm Spindle taper: 6Mk Speeds / ranges: 4,5 - 900Rpm Workpiece load: 8000 Length: 8000mm Width: 1800mm Height: 1550mm Weight: 13800kg

Condition: good (used), Year of construction: 1963, Vertical lathe JUNGENTHAL Type: DK 1400 built in 1963 with 1 axis digital readout. Fpodpfx Aevi Hryjgrjb turning diameter max : 1400 mm face plate : 1250 mm Automatic turret head spindle speed : 3,5-180 rpm feeds : 0,063 - 3,15 mm/rev rapid traverse : 1800 mm/min Further data see data sheet Machine documentation available . Dimensions : Length 4 m Width 2,4 m Height 3 m Weight 16t Good general condition .

Year of construction: 1993, condition: good (used), machine/vehicle number: 03.2370, Arthur Klink - internal broaching machine (WAG 748) Fedpfx Agscc D Ddsrepb machine type: internal vertical hydraulic broaching machine manufacturer: Arthur Klink type: RISZ 10 x 1000 built in: 1993 stroke: 1000mm pulling force: 10.000KG working stations: 3 PCs drive: hydraulic system equipment: coolant system, magnetic chip conveyer remark: machine under power in stock the machine has an automatic workpiece loading system for 2 workpieces, ideal useable for high production Optional accessories available on request: tools, workpiece holder Information about us: we are specialized for second hand broaching machine and still have anytime about 80 pcs of used broaching machines in our stock, vertical and horizontal machines from 3000kg up 63.000kg pulling force and from 1000mm stroke up to 3500mm stroke.

Condition: like new (used), turning diameter: 1,500 mm, MAXIMUM WORK DIAMETER : 1600 mm. MAXIMUM WORKING LENGTH : 3000 mm. DIAMETER OF LANTERN SHAFT : 83 mm. Fpedpfx Aor Ui R Negreb OUR MACHINE IS ACTIVE WITHOUT ANY PROBLEMS ALL REVOLUTIONS AND AUTOMATICS ARE IN VERY GOOD CONDITION

Condition: reconditioned (used), Year of construction: 1992, functionality: fully functional, center height: 150 mm, grinding length: 620 mm, center width: 680 mm, grinding wheel diameter: 350 mm, total width: 500 mm, Condition of the machine: The machine is currently in a used, non-overhauled condition. The following work carried out on the machine: - Complete disassembly of the entire machine except for the guides - Replacement of all sealing and wear parts of the entire machine - Replacement of the infeed spindle of the X-axis - Replacement of the main bearing of the workpiece spindle - Replacement of grinding spindle - All machine assemblies are restored to as-new condition Geometry: - Scraping of the X-axis guide Fpsdpfx Agjrz Nfloreb - Scraping the Z-axis guide - Grinding the X-axis table - Grinding the Z-axis table - Grinding the upper tables - Grinding of the assembly housing (workpiece headstock, grinding headstock and tailstock) - Creation of measurement report for TSCHUDIN cylindrical grinding machine Painting: The main assemblies are repainted, the rest of the machine retains the original paintwork Electronics: The complete electronics of the machine are checked, tested and defective switches and cables are replaced
