Cut-to-length and slitting line

Forstner MST 1250

Condition: as good as new (ex-display), functionality: fully functional, Year of construction: 2022, operating hours: 60 h, +++ Demo machine, approx. 60 operating hours +++ +++ Descending Die +++ Basic machine: TruPunch 3000 large format (S20) Machine: - Box frame - Hybrid axis system - Linear tool magazine with 24 stations for clamps and tools - Hydraulic clamps (3x) - Drives with maintenance-free three-phase motors - Repositioning with programmable presser foot - Foot switch to close clamps - Part chute, right - Part removal flap, left - Sensor for part removal flap - SortMaster Compact retrofit-prepared Punching head: - Delta Drive - Rotating single-station tool adapter - Programmable presser foot position - Tool length compensation - Punch spray lubrication - Punching slug vacuum - Forming function - Punch stroke counter Control: - TRUMPF control based on Rexroth IndraMotion MTX - Touch panel with 19" TFT color display - Touchpoint - Auto-shutdown - Remote support interface - Program manager - Production plan Data transmission: - Central Link - Online Update Manager Safety: - CE marking and EC Machinery Directive - Double-beam safety light barrier Advanced standard configuration: - First index pin (inside right) - Ball tables - Part chute for finished part container - Chip container to rear for removal Advanced machine and punching features: - MultiTool function - MultiShear function - MultiBend function - Tapping function with thread counter - Forming tap breakage control - Lubricant level monitoring - Unlimited time license - Marking/Quick beading function (option) - Engraving function - Deburring and roller technology function - Adaptive stroke calibration - StripLine - Die spray lubrication with fill level monitoring - Descending Die - Integrated flattening function - Smart punch monitoring - Additional clamp - Height-adjustable clamp - Vibration damping - Chip container removed to front - Brush tables with loading and unloading assistance - Warped sheet detection Technical data TruPunch 3000 large format (S20) Dimensions / Weight: Width: 7644 mm Bedpfxjxmfc Uj Ap Ijdd Depth: 7666 mm Height: 2200 mm Weight (fully equipped): 13,800 kg Control / Hardware / Electrics: Hard disk type: SSD Number and size of hard disks: 2 x 120 GB Customer program memory: 10 GB Display: Touchscreen Display size: 21.5 in Interfaces: USB Network: RJ45 Control type: Bosch CML75 Operating system: Windows 10 IoT Axis data: X/Y/C axis drive: NC-controlled, maintenance-free three-phase servo motors Punching head drive: Electric Max. X axis speed: 90 m/min Max. Y axis speed: 60 m/min Max. simultaneous axis speed: 108 m/min Max. C axis speed (punching): 350 rpm Max. C axis speed (tapping): 350 rpm Max. punching stroke rate (E=1mm): 690 1/min Max. marking stroke rate: 1000 1/min Accuracy — positioning deviation Pa: +/- 0.1 mm Accuracy — position range Ps: +/- 0.03 mm Smallest programmable increment: 0.001 mm Working range / Workpiece size: Max. sheet thickness: 6.4 mm Max. workpiece weight: 230 kg X axis working range: 3000 mm Y axis working range: 1550 mm Punch-specific data: Max. punching force: 180 kN Max. presser foot force: 20 kN Max. tool size, punching (outer diameter): 76.2 mm Max. tool size, forming (outer diameter): 101.6 mm

Year of construction: 2010, condition: used, METAL SHEET PROFILING LINE FOR TILE ROOF PANELS Reduced price due to urgent sale Scope of supply 1 Uncoiler 2 Front shear + coil guide table 3 Film applicator 4 Base parts of cassette type forming machine 5 Roll forming machine for roof tile for "COPPO" 6 Roll forming machine for rooftile for "ATIIKA" 7 Roll forming machine for rooftile for "T177.5" 8 Shearing (Cut-off) machine: Flying type 9 Drawing part 10 Auto stacker 11 Electric control panel Technical specifications - Manufacturer: IL Kwang (Korea) - Manufacturing: Year 2010 - Material: Pre-painted, galvanized steel sheet (ASTM A 526/ JIS G 3302 SGCC) - Tensile strength: 250 ~ 320 MPA - Max. coil width: 1250 mm - Coil thickness: 0.35 – 0.8 mm - Max. coil weight: 15 ton - Outer coil diameter: Max. 1300 mm - Inner coil diameter: 508 mm - Line speed (length > 5 m): Max. 8 m/min - Speed control: Frequency control by inverter - Commercial voltage: 380 / 50 V/Hz 3 Phases - Surface (LxWxH): Approx. 30 x 8 x 5 m Brand of components - Motor: Siemens (ICE. type) - PLC + Inverter: Siemens 7 - Servo: Mitsubishi (with C.E ) - Touch screen: Pro-face (with C.E.) - Electric components: L.G (with C.E.) Commercial voltage: 380 / 50 V/Hz 3 Phases Line speed (length > 5 m): Max. 8 m/min Material: Pre-painted, galvanized steel sheet (ASTM A 526/ JIS G 3302 SGCC) Tensile strength: 250 ~ 320 MPA Max. coil width: 1250 mm Coil thickness: 0.35 – 0.8 mm Max. coil weight: 15 ton Outer coil diameter: Max. 1300 mm Bdedpfx Aeymbfyop Iod Motor: Siemens (ICE. type) PLC + Inverter: Siemens 7 Servo: Mitsubishi (with C.E ) Touch screen: Pro-face (with C.E.) Electric components: L.G (with C.E.) Speed control: Frequency control by inverter Inner coil diameter: 508 mm Surface (LxWxH): Approx. 30 x 8 x 5 m

Condition: new, Year of construction: 2026, Efficient, quiet, and powerful mechanical machine Technical specifications: Working length: 4040 mm Total length: 5352 mm Depth: 2232 mm Working height: 950 mm Total height: 1924 mm Weight: 5,000 kg Maximum bending thicknesses: Steel: 1.5 mm Aluminum: 2.00 mm Bodex Hyhbjpfx Ap Ijdd Stainless steel: 1.00 mm Copper: 2.00 mm Galvanized sheet: 3.00 mm Standard equipment: • 1 bending rail, 20° with sharp nose, radius 1 mm, offset, 66/24 mm for the clamping beam • 1 insertable rail, 10/100 mm and 24/100 mm for the bending beam • Foot switch (MAF 400/CNC model delivered with a second foot switch) • Soft start for the bending beam • Electrically driven back gauge, 8-1000 mm • 5 m power cable with 32 A mains plug (EU version) • Supply voltage: 3 x 400 V, 50 Hz (EU version) CNC S-Touch control: From profile concept to bending precision in record time Standard features at no extra charge: • Graphical display of the bending sequence for the selected program • Graphical representation of sheet position before every bend • Operator guidance – each work step visually explained via the graphic control system • Programming without submenus • Profile correction by direct touch in the desired section of the profile • Programmable angle correction • Set repeat cycles for special radius arcs • Cutting program for RSL rotary shears • Easy mode for: single bends, back gauge, bending angle, lifting height, closing edges • Profile search possible by name, sketch selection, and profile drawing on the touchscreen • 21.5-inch LCD touchscreen with best-in-class graphics • USB port for program backup and transfer • Non-volatile memory for over 3,000 programs • Freely assignable program names (profile names) • Registration of produced quantities and machine operating time • 16 languages • Remote support (Team Viewer) • Soft start for bending beam • Back gauge with drive, 6-1000 mm • Foot switch For EU market: • 16 A plug with 5 m power cable • For MAF and MAZ models, 32 A plug with 5 m power cable

Condition: new, Year of construction: 2026, Automatic snap lock roof panel machine Sl-1 auto is designed by our company for the self-locking roof panels production in automatic mode. This machine forms a roof lock by rolling with the help of special rolling rolls. At the same time while rolling it cuts fastening holes for roof panel’s fixation. Automatic snap lock roof panel machine SL-1 auto consist of: - Roll forming part, which directly forms the desired profile of the panel with the help of rolling rollers. The machine is equipped with width easy adjustable system - to change the width; you just need to turn a special adjustment wheel. The rolling machine has 10 pairs of forming rolls to form a click-seam lock. It has special tool to cut fastening holes in panels. - Automatization system of machine, with the main elements as follows: automatic control panel, manual control panel, control cabinet, measuring wheel. With the help of this system, machine operator can program it to perform metal rolling and cutting operations in automatic mode. It is easy to set the number of panels for rolling and their lengths, so you just need to feed metal into machine, and it will roll panels of click-seam of the desired length and quantity in automatic mode. It is possible to perform several tasks (multi-tasking). If use manual control panel you can check each operation step of the automatic mode before put it to full automatic process. - Guillotine shear, designed for cutting click panels of various widths. The special configuration of blades makes it possible to cut such profile and to get high quality final product. Shear system has electric motor to make cutting operations easy. As an additional equipment for the machine, we offer: - metal uncoiler for convenient installation of roll metal and feeding it into the machine. - full automatic decoiler to make roll forming process maximum automatic. Bdjdpfxen Hqmmj Ap Isd - ribbed panel rolls, to form additional ribs to the click-fold panels, so it gets more interesting look to the roof and increasing the rigidity of the system. - ribbed panel forming machine RPFM (microwave panels machine) to form microwaves on roofing panels. Due to its low weight, the automatic roll forming machine for self-locking panels SL-1 auto can be used in the construction of civil and industrial facilities, in factory workshops and workshops, as well as directly on the roofing site. Using of machine close to the place of installation avoids transportation costs and the associated risk of damage to the roofing sheets. The high of snap lock roof panel profile when installed is 26mm: As an option, we can also make machine for 31mm lock high production: The maximum workpiece width for rolling can be 700mm. The minimum workpiece width is 250mm. Automatic snap lock roof panel machine Sl-1 auto has special protective cover that prevents foreign objects from getting to working part of machine. So snap lock automatic roll forming machine SL-1 auto is convenient to use with the help of automatic mode so you can minimize operator’s work and to get high-quality roofing panels with high productivity.

Year of construction: 2023, condition: new, ! Offers for customers from Baltic states only: Lithuania, Latvia, Estonia. Guillotine RAPIDO is fast reliable shearing machine. Depends on sheets length there are guillotines with different working lengths available: 1300 mm / 2600 mm / 3200 mm / 4100 mm. Machine can do up to 35 cuts per minute. The drive system with eccentrics, pulldown rods, and hold down system which can be positioned as close as 2.5 cm from the knives allow for easy and expedient trimming of narrow strips. RAPIDO guillotine shear is equipped with squaring arms on both sides and the LED cutting line light. Bjdpfx Apoixz D Us Iedd Available working lengths: 2600 mm / 3200 mm / 4100 mm

Condition: good (used), Qty 2 Linx Ink Jet Coders Models 7900 & 7300 Bdodpokyumkofx Ap Ijd In good working condition Fully serviced In working condition

Condition: new, plate thickness 1,6 mm 4 t blade length 156 mm angle adjustable from - to fest Grad table surface area 450m x 305 mm total power requirement Handbetrieb kW Bedpfx Apsftd Uae Ijdd weight of the machine ca. 95 Kg Dimensions (LxWxH) 530 x 380 x 480 mm

Condition: new, Year of construction: 2026, functionality: fully functional, coil weight: 10,000 kg, number of straightening rollers: 6, conveyor belt width: 1,500 mm, sheet thickness aluminum (max.): 3 mm, sheet thickness steel (max.): 3 mm, blade shaft diameter: 255 mm, sheet thickness copper (max.): 3 mm, inner diameter: 510 mm, outer diameter: 1,500 mm, mandrel diameter: 510 mm, mandrel length: 1,500 mm, coil width: 1,500 mm, coil outer diameter: 1,500 mm, number of blades: 8, warranty duration: 12 months, straightening roller diameter: 140 mm, total width: 1,500 mm, Slitting line model 1,500 x 3 mm, comprising: - Decoiler Aspo mod. 1500/5Ton (customizable) - Loading table - Feeder and straightener with 6 rollers, diameter 140 mm - Rotary cutter with 4 pairs of circular blades Bdodpfsx Hr S Sjx Ap Iod - Automatic punching unit with 20 customized punching stations - Mechanical shear - Aspo recoiler

Condition: new, Year of construction: 2025, Metal picket fence roll forming machine MFP-1 was designed by our company to produce semi-round shape picket metal fence profile. This profile is widely used and popular among companies with business in manufacturing, installation and selling of metal fences. Bedpjm Twnlsfx Ap Ijdd The production of the profile goes gradually, at first hemming forms on edges from the flat metal, and then the height of the profile and the semi-round shape are formed, at the last stage of rolling machine forms the rib in the profile center. Such number of forming stages makes it possible to ensure smooth sheet changes during rolling, as well as high quality of the final product. As a blank, you can use a strip of required width and length, to prepare it with pre-cut on other equipment – sheet metal slitting machine or guillotine shear. After roll forming, to make fence picket end look better, you can use special cutting press of our production. The working tools of such press have special round configuration and are the same as semi-round metal picket shape to make appropriate cutting. Those tools are made from special tool steel, and goes through process of hardening so ensure high requirements for the cutting tools of the equipment. Our company can produce as semi-automatic rolling machine for the metal fence pickets manufacturing and a manual punching press for it, as well as a fully automatic line. Such metal fence automatic line can have following components: console metal decoiler, a rolling machine equipped with an automatization system with the ability to program the number of required pickets for rolling and their lengths, automatic electric shear for cutting metal at the end and stacker part. Thus, cooperating with us, our customers can choose the best option for their manufacturing process according to their planned production volumes, budget, etc. For more details about metal picket fence roll forming machine MFP-1 please contact our sales department

Year of construction: 2004, condition: ready for operation (used), Max. working width: 1000mm, feed rate: 5-20m/min, height: 2200mm, length: 4000mm, weight: 3.3t, with documentation, was maintained regularly. Bsdpfx Asi E Trpsp Isdd
