HACO TSX3006 MOT

HACO TSX3006 MOT

Condition: good (used), Year of construction: 2008, functionality: fully functional, turning length: 750 mm, turning diameter: 590 mm, spindle bore: 78 mm, spindle speed (max.): 3,000 rpm, Equipment: documentation/manual, Centre distance: 750 mm Swing: 590 mm over bed / 375 mm over slides Spindle speeds: 25 - 3.000 rpm Godpoxmvzusfx Af Ajuf Spindle bore: 78 mm Revolver: 10 Platze Controller: Siemens 810D Shopmill Featured with: - Double footpedals - Chipconveyor - Machine manuals Country of origin: Z. Korea Motor power: 25 kW Machine weight: 6.000 kg Machine LxWxH: 300 x 180 x 190 cm

Condition: new, Year of construction: 2026, A professional folding machine with a 4.14 m working surface, directly from the manufacturer Prod-Masz. Possible sheet thickness to be processed: sheet steel up to 0.7 mm, bending radius: up to 160° to create a fold. The two cheeks are CNC-milled from solid material and ensure a long service life. The machine is solidly made, the weight of the machine is 700kg !!! Do you think there is no such company that can bend you? Is! Prod-Masz is your bending specialist! Actually our abant benches! The sheet metal bending machine has a holder for the cut sheet metal at the outlet, a protractor, angle stop and gas pressure damper to slightly position the bending beam in the height. Maximum working width of the press brake: 4140 mm Bending performance: up to 0.7 mm (steel sheet) Bending machine bending angle: 160 degrees Bending beam thickness: 20 mm Cut with the roller shears over the entire working width Lifting of the upper beam in three positions Passage opening: 80 mm degree scale angle stop depth stops Weight of the folding bench: approx. 700 kg Guodpfx Afjcgmd Uo Aef The roller scissors (max. cutting capacity up to 0.8 mm / sheet steel) plus 350 euros Manual folding machine plus 75 euros The machine complies with CE guidelines and has a 12-month guarantee Delivery: every week We are looking forward to your contact! Invoices are issued with 0% as intra-community delivery or with plus 19% of VAT.

Condition: good (used), functionality: fully functional, Sheet width: 4050 mm Sheet thickness: 8 mm Gedpfxoxu Nc Is Af Aouf Cutting angle: 2 - 10° Cutting speed: 0.053 m/s Table length: 710 mm Machine weight approx.: 10,100 kg

Condition: used, WEBSTER & BENNETT EV 36” HIGH SPEED VERTICAL BORER Guedoxp Na Nspfx Af Aef MAKE WEBSTER & BENNETT, MADE IN ENGLAND MODEL EV 36” TABLE DIA 915 mm SWING 1168 mm HEIGHT UNDER RAIL 533 - 1016 mm SPEED 13.5 - 300 rpm FEED RATE 0.005-0.250 inch/min MAIN SPEED 40 HP PLUS HIGH SPEED TAABLE EV SERIES MACHINE ELEVATING RAIL SAFETY GAURDING SET OF JAWS FULLY FUNCTIONAL GOOD SLIDES

Condition: used, Year of construction: 2011, Maximum grinding length: 1200 mm Maximum grinding length with table dresser: 1000 mm Maximum grinding width: 600 mm Grinding height (table to underside of grinding wheel): 550 mm Table load with magnetic chuck: 975 kg Table load without magnetic chuck: 1200 kg Table speed: 1 - 40 m/min Grinding spindle Motor spindle: 11 kW Grinding wheel: 406 x 152.4 x 100 mm Speed: 1400 rpm Longitudinal axis (Z-axis) Rapid traverse: 5 m/min Adjustable feed: 1 - 50 mm Continuously variable feed: 0 - 2000 mm/min Smallest infeed: 0.001 mm Vertical axis (Y-axis) Rapid traverse: 1.5 m/min Smallest infeed: 0.001 mm Space requirements approx.: 4450 x 2935 x 2540 mm Total weight approx.: 6700 kg Equipment: - Electro-permanent magnetic chuck 1000 x 500 mm incl. electronic control module and potentiometer Guedpfxexhdz Es Af Aof - Coolant cleaning system with paper filter and magnetic separator 350 l – delivery rate 100 l/min - Static frequency converter incl. automatic dressing compensation - Complete extraction system - Siemens control with electronic handwheel - Various accessories, 2 flanges and 5 grinding wheels

Condition: used, Year of construction: 1990, table load max. 40 t t with manual operation panel ja weight of the machine ca. 22 t 1918 Year ca. 1990 Dimensions (L/W/H) 3500 x 2300 x 2400 mm +++++ Guedpfxohy T Nvo Af Aof Please note: The machine is dismantled and ready for loading. It is not possible to show it under power or make a video. Our offer includes already the best pictures. So we don’t have and won’t send additional pictures. +++++

Condition: used, Year of construction: 2012, x-travel 2100 mm y-travel 1020 mm z-travel 762 mm Control Fanuc MXP-200FP spindle speed 6000 U/min spindle capacity ca. 22 kW max. torque on the spindle ca. 550 Nm tool taper SK 50 table surface area 2300 x 1020 mm max. table load 3000 kg T-slots 6 x 22 mm T-slot - distance 150 mm Guodpfx Afjx Sr A Uj Aef 3-Axis CNC Machining Center Equipment/Accessories: - Automatic tool changer with chain magazine, 40 stations - max. tool-Ø: 120/240 mm - max. tool length: 350 mm - coolant system with internal coolant supply and filter - emulsion mist extraction - electronic handwheel - 2 pcs. magnetic clamping plates 800 x 400 mm - various tool tapers SK50 - chip conveyor

Condition: used, O F F E R We can offer you ex stock, subject to prior sale and errors: Guodowftt Uspfx Af Aof TSCHUDIN (CH) Centerless cylindrical grinding machine Model TC-300 Year of manufacture 2001 Grinding range – Ø 0.5 – 25 mm (30) Max. workpiece length for plunge grinding 125 mm (140) Max. workpiece length for through-feed grinding 300 mm Grinding wheel dimensions: Ø x width Ø 300 x 125 mm (140) Regulating wheel dimensions: Ø x width Ø 225 x 125 mm (140) Grinding wheel peripheral speed 35 m/sec Grinding wheel infeed 3 mm Regulating wheel speeds, steplessly adjustable 0 – 444 rpm Regulating wheel inclination Degrees Grinding wheel drive approx. 7.5 kW Total connected load approx. 13 kW – 380 V – 50 Hz Weight 2,500 kg Accessories / Special equipment: • The machine operates with a fixed workpiece position, allowing both the grinding spindle and the regulating spindle units to be adjustable. This simplifies machine setup as well as automatic workpiece loading and unloading. • SIEMENS PLC control for automatic operation with SIEMENS touchscreen. Complete electrics and PLC control renewed in 2016! • Electromechanical profile dressing device for the regulating wheel • Regulating and grinding wheel speeds are steplessly adjustable. • Adjustable plunge guide bridge with mounted plunge workpiece rest • Electromechanically controlled workpiece pusher & automatic pneumatic workpiece ejector • Additional outfeed cylinder for automatic tilting of workpieces after plunge grinding (adjustable 4–30 mm) • Machine is prepared for use with a HELP-TEC bar loader MSHL08/400P, which is currently not present. • Complete enclosure of working area with monitoring technology • Separate control cabinet, operating and electrical manuals for the retrofit Condition: Very good! Fitted with new electronics in 2016! Click here for a video of the machine: Delivery: ex stock, immediately available, FCA Metzingen Payment: strictly net – after receipt of invoice Always a large selection of grinding machines in stock – please inquire for your requirements!

Condition: used, turning diameter 1.600 mm max. swing diameter 1.700 mm control Siemens - 840D faceplate turning speed range 1 - 320 U/min rapid traverse 3.000 mm / min feed range 1 - 3.000 mm/min size of pallet 1.168 mm numbers of pallets 2 main drive 55 kW Vertical turret lathe with cnc | SCHIESS MOWEG - BERTHIEZ TFM 125 has been overhauled by SCHIESS MOWEG (RETROFIT) in 2007. Guodpfjvp Shgex Af Aof The machine video from the production plant will be shared on request. The machine is in very good condition and was in operation at an aviation company until recently. - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - #Tags: TFM125 | TFM-125

Condition: excellent (used), Year of construction: 2006, For sale: A reliable vertical CNC machining center Yamazaki Mazak Nexus VCN-510C – a high-end production machine from the renowned Japanese manufacturer MAZAK, known for its precision, durability, and stable operation in industrial manufacturing environments. The VCN-510C is ideally suited for machining steel, aluminum, and workpieces requiring high accuracy and repeatability. Thanks to the MAZATROL 640M control, the machine offers intuitive operation and rapid production setup. Technical specifications: Year of manufacture: 2006 Control: MAZATROL 640M X-axis travel: 1,050 mm Y-axis travel: 510 mm Guodpfx Aoyha Ivef Asf Z-axis travel: 510 mm T-slot table Automatic tool changer (ATC) Central lubrication Electrical cabinet Weight: 7,100 kg Low operating hours
