Bed type milling machine for sale

Identified location: Ashburn (US) (Edit)
Retrofitted: 2019 Numerical control: HEIDENHAIN TNC-320 (¡NUEVO! / NEW!) Technical features Dimensions Table dimensions: 2000 x 630 mm Number of T slots: 6 T slots dimensions: 18 mm Traverses of axis X axis traverse: 1800 mm Y axis traverse: 800 mm Z axis traverse: 800 mm Milling head Head type: Universal Manual Tool clamping system: Hydraulic Taper nose: ISO 50 Speed range: 25 - 2600 rpm Spindle power: 16 kW Feedrates Feedrate: 5 - 5000 mm/min Rapid feedr... more
x-travel 3300 mm y-travel 2000 mm z-travel 1300 mm Control TNC 426/430 Heidenhain table-size 5500 x 2000 mm tool taper SK 50 spindle turning speed range 63- 3150 U/min feeds - automatic programming 5- 3000 mm/min rapid traverse 6/4 m/min 0p78ha7g stroke of milling spindle 350 mm total power requirement 45 kW weight of the machine ca. 70 t dimensions of the machine ca. 9,5 x 5,5 x 5,8 m Machine with Heidemhain TNC 426/430 control. We will supply a package of spare parts along with the machin... more
Milling machine droop & rein LFAS 2000 Bed type milling machine Manufacturer: Droop & rein Bdt7rv7g0l Type: LFAS 2000 Year of construction: 1981 Technical data: programmable digital display Work table: 5300 x 2000 mm Clamping surface: 4260 x 2000 mm 11 T-slots upper width: 28mm Table height: 990 mm Drive type: Voltage 380 V Three-phase 50 Hz Milling unit: Milling spindle diameter in the front Lager140mm Tool holder taper 60 The milling spindle sleeve diameter 240 mm Spindle speeds in 4 hydau... more
x-travel 1000 mm y-travel 600 mm z-travel 450 mm control Heidenhain TNC 151/55 max. workpiece weight 2000 kg tool taper SK 40 table surface area L 1300 x B 500 mm number of T-slots 5 T-slot - width 18 mm Npial T-slot - distance 100 mm table height over floor 1000 mm turning speed range stufenlos 40-2000 U/min head swivability +/- 90 ° feeds: speed max xyz 8/8/8 m/min feed speeds 10 - 20000 mm/min total power requirement 25 kW weight of the machine ca. 5000 kg dimensions of the machine ca. L... more
x-travel:2600 mm y-travel:1000 mm z-travel:1000 mm table-size:3.600 x 900 mm max. workpiece weight:8.000 kg no. of flutes:6 groove width:22 mm flute distance:125 spindle taper ISO:50 DIN 69871 number of spindle speeds:4.000 (2 Steps 0 - 1.000, 1001 - 4.000) U/min feed speeds:10 - 5.000 mm/min rapid speed:10.000 / 10.000 / 10.000 mm/min dimensions of the machine ca.:9,82 x 5,1 x 3,16 m weight of the machine ca.:21,5 t Engine: Zgmozxnz Spindle drive motor: 29 kW Feed drive motor Y-axis: 20 Nm,... more
x-travel 1050 mm y-travel 560 mm z-travel 510 mm table-size 1200 x 560 mm spindle taper ISO 50 turning speed range 15 - 4000 U/min feeds longditudinal/cross/vertical 1 - 3000 mm/min rapid motion -longitudinal/cross/vertical 10 m/min distance spindle nose and table 150 - 660 mm distance spindle center to column max. 650 mm table load max . 1 t no. of tools in magazin 24 tool diameter 110 mm workpiece length 350 mm weight of tools max. 15 kg Beohsipq9w spindle drive 7,5 kW control FANUC 11 MA t... more
Retrofitted: 2019 Numerical control: HEIDENHAIN TNC-426 Technical features Dwkfn3 Dimensions Table dimensions: 2200 x 600 mm Number of T slots: 5 T slots dimensions: 18 mm Traverses of axis X axis traverse: 2000 mm Y axis traverse: 900 mm Z axis traverse: 800 / 700 mm Milling head Head type: Automatic 2 positions (Horizontal/Vertical) Tool clamping system: Hydraulic Taper nose: ISO50 Speed range: 0 - 2000 rpm Accesories Guarding Automatic tool changer: ATC-20... more
x-travel:3000 mm y-travel:1000 mm z-travel:1500 mm T-slot (width-distance-quantity):22H8x7 Stk. mm Table area:3100x1050 mm max. table load:8000 kg spindle taper:50 SK spindle speeds:3500 1/min. spindle motor:15/18,5 kW feed:1~8000 mm/min rapid speed:10 m/min positioning accuracy:JIS 6338;±0,005mm / 300mm VDI 3441:P0,014mm repeating accuracy:JIS 6338:±0,003mm VDI3441:PS0,01 mm total power requirement:35 KVA weight of the machine ca.:18 t dimensions of the machine ca.:7670x4325 (LxT) mm Bei9iv9... more
x-travel 2600 mm y-travel 900 mm z-travel 907 mm table-size 2700 x 800 mm table load capacity 8.000 kg distance spindle /table 28 - 935 mm spindle taper ISO 50 DIN 69871 spindle turning speed range 30 - 3500 U/min power capacity - milling spindle 22 kW max. torque on the spindle max. 700 Nm rapid traverse 10 m/min feed speeds 50 mm/min tool change unit 24 control Heidenhain TNC 415B voltage 400 V total power requirement 44 kW weight 13 t Bezj8btfmy dimensions of the machine ca. 7,60 x 5,00 x 2... more
x-axis 1600 mm w-axis 850 mm control Heidenhain TNC 355 useful area 1800 x 600 mm groove width 18 mm tool taper ISO 50 feed Y 700(900) mm/min feed Z 500 mm/min rapid traverse 8000 mm/min total power requirement 2(17) kW weight of the machine ca. 11,2 t dimensions of the machine ca. L 3,1 x B 4,1 x H 2,65 m Bfsk3lefaj We ask for price proposal! The machine is in good condition and can be moved to Appointment to be visited. *** Changes and errors in the technical data and information as wel... more

New machines via email!

Yes, send news from this list to my inbox!
Stay updated!
You can create a label.
How often do you want to be notified about new listings?
x-travel:1800 mm y-travel:750 mm z-travel:790 mm table surface area:2000 x 800 mm spindle taper ISO:50 spindle turning speed range:20 - 2000 U/min rapid motion -longitudinal/cross/vertical:5 m/min table load:6000 kp spindle motor:30 kW milling head -swivable +/-:90 ° total connected load:40 kW weight of the machine ca.:12 t dimensions of the machine ca.:6,2 x 3,2 x 3,6 m with CNC HEIDENHAIN TNC 155 Bzhpgprb Vertical and Horiz. Milling spindle diverses accessories ( vice , toolholders and cla... more
x-travel:1600 mm y-travel:720 mm z-travel:650 mm table surface area:2500 x 575 mm table load:2 t T-slots:3 T-slot - width:22 mm T-slot - distance:152,5 mm distance spindle nose and table:80 - 730 mm feed stepless:20 - 900 mm/min rapid traverse: longitudinal and cross:2000 mm/min no. of turning speeds:16 turning speed range:45 - 1400 U/min spindle taper:SK 50 total power requirement:19 kW X8tp2jz8b weight of the machine ca.:9 t dimensions of the machine ca.:3,4 x 3,2 x 2,8 m Universal milling... more
Retrofitted: 2019 Numerical control: HEIDENHAIN TNC-320 (¡NUEVO! / NEW!) Technical features Dimensions Table dimensions: 1700 x 630 mm Number of T slots: 6 T slots dimensions: 18 mm Traverses of axis X axis traverse: 1300 mm Y axis traverse: 630 mm Z axis traverse: 630 mm Milling head Head type: Universal Manual / DM16 Tool clamping system: Hydraulic Taper nose: ISO 50 Speed range: 80 - 2500 rpm Spindle power: 16 kW Feedrates Feedr... more
Milling, copying milling machine DROOP & REIN ecomill type FS 80 Fabr. No. 310 built circa 1968, rebuilt in 1976 Copy length 800 mm Copy width 450 mm Copy depth 200 mm Routes x 800 mm, Y: 450 mm, w: 500 mm Quill movement 150 mm Table size 1650 x 550 mm Spindle speed: 33-1750 RPM. Spindle retainer for SK 50 Spindle diameter 80 mm Quill diameter 150 mm Feed speed 10-300 mm / min. Spindle drive approx. 7,5 kW Power supply 380 v, 50 Hz -Vertical head swivel +/-90 ° -Control cabinet opposite 1600 x 5... more
x-travel:3000 mm y-travel:1050 mm z-travel:1300 mm table-size:3200x900 mm Bcu2vrgdpo spindle speed::0-4000 spindle taper:DIN 69871 SK 50 more
x-travel 5.000 mm y-travel 1.000 mm z-travel 1.200 mm Control Heidenhain TNC 131 Tool bore SK 50 feed stepless bis 4.500 mm/min feeds infinitely variable by: Potentiometer The machine is in a good general condition, no known Defects according to issuer. Was regularly maintained and comes from a large company and can be visited by appointment. The machine has an automatic tip protection on the table. Documentation available. Bfskwv70dw *** Changes and errors in the technical data and inf... more
x-travel 1250 mm y-travel 700 mm z-travel 665 mm table-size 1350 x 700 mm table load max. 1000 kg spindle taper ISO 50 turning speed range 20 - 2000 U/min control HEIDENHAIN TNC 150 feed X/Y/Z-axis 1 - 3000 mm/min. rapid traverse X/Y/Z axis 6000 mm/min. total power requirement 12 kW Beohssawtx weight of the machine ca. 9 t range L-W-H 3,10 x 2,70 x 2,55 m acc.: original HURON-millinghead, hydr. tool clamping more
x-travel:2000 mm y-travel:800 mm z-travel:1000 mm Bhw3pd3i table surface area:2200 x 750 mm T-slots:5 T-slot - width:18 mm T-slot - distance:140 mm table load:4 t feed stepless:0 - 10000 mm/min turning speed range:40 - 3000 U/min rapid traverse:0 - 15000 mm/min tool adaptor:SK 50 DIN 69871 spindle drive:15 / 22 kW Tool changer:ja total power requirement:ca. 30 kW weight of the machine ca.:10 t dimensions of the machine ca.:5,5 x 4,5 x 2,5 m :20 ATC tool changer (arm type) Hydraulic tool cla... more
Retrofitted: 2019 Numerical control: HEIDENHAIN TNC-320 (¡NUEVO! / NEW!) Technical features Dimensions Table dimensions: 3500 x 1100 mm Number of T slots: 8 T slots dimensions: 22 mm Traverses of axis X axis traverse: 3000 mm Y axis traverse: 1200 mm Z axis traverse: 1000 mm Milling head Head type: Universal Manual Tool clamping system: Hydraulic Taper nose: ISO-50 Speed range: 20 – 3000 rpm Spindle power: 29.6 kW S9fx2dzl Feedrates Feedrate: 2 - 5000 mm/m... more
Steuerung: Heidenhain iTNC 530 Verfahrwege X/Y/Z: 1500/1200/1000 mm Tisch: 1600 x 1000 mm Drehzahl Fräskopf: max. 4000 U/min. Bft8dfv8ie ISO 50 Kopf manuell schwenkbar Maschinenstunden: ca. 8000 h Zubehör: Kühlmitteleinrichtung, Späneförderer, IKZ, Messtaster, Handrad Gewicht 21 t more
x-travel:900 mm y-travel:600 mm z-travel:600 mm Ikdwnn2l8 table clamping surface::1.000 x 700 mm control:HEIDENHAIN TNC 415 turning speeds:20 - 3150 1/min tool taper:SK 40 spindle:11 kW max. torque on the spindle:600 Nm total power requirement:30 kW weight of the machine ca.:8,5 t dimensions of the machine ca.:3,5 x 3,5 x 2,7 m CNC universal bed milling machine, head is swivelling manually horizontal / vertical head is swivelling manually on the 4 th axis approx. 21.000 hours "machine on" more
x-travel:2600 mm y-travel:1000 mm z-travel:950 (opt.1500) mm T-slot (width-distance-quantity):22H8x7 Stk. mm Table area:2700×1050 mm max. table load:5000 kg spindle taper:50 SK spindle speeds:3500 (5000 opt.) 1/min. spindle motor:15/18,5 (22/26 opt) kW feed:1~8000 mm/min rapid speed:10 m/min positioning accuracy:JIS 6338;±0,005mm / 300mm VDI 3441:P0,014mm repeating accuracy:JIS 6338:±0,003mm VDI3441:PS0,01 mm total power requirement:35 KVA weight of the machine ca.:15 t Yxftwk390 universal mi... more
CNC bed milling machine Reckermann BETA 10 KombiBj. 10/1989 path control Heidenhain TNC 355with horizontal and vertical milling spindle travel X=1500 mm, Y=600 mm, Z=450 mmmax. workpiece weight 3000 KGcondition good, horizontal spindle overhauled, control checked and memory batteries exchanged J9a7crxp more
x-travel:1200 mm y-travel:600 mm Nkfc7 z-travel:600 mm table::1300 x 700 mm T-slots:7 spindle turning speed range:3150 U/min turning speed range:20 - 3150 U/min spindle taper:SK40 table load:2,5 t total power requirement:36 kVA weight of the machine ca.:10,0 t dimensions of the machine ca.:4,0 x 2,5 x 2,4 m more
Numerical control: SELCA 3045 Technical features Dimensions Table dimensions: 1800 x 700 mm Number of T slots: 5 Traverses of axis X axis traverse: 1600 mm Y axis traverse: 920 mm Z axis traverse: 900 mm Milling head Head type: Universal Manual Tool clamping system: Hydraulic Taper nose: ISO 50 (DIN 2080) Speed range: 60 - 2000 rpm Spindle power: 18,5 kW Weight and dimensions Maximum weight on table: 4000 kg Machine weight: 10500 kg Machine dimensions: 5000 x 3... more
x-travel:1800 mm y-travel:1000 mm z-travel:1000 mm Bskty7zm table-size:2100x850 mm spindle taper:ISO 50 rapid traverse in x-y-z axis:20.000 mm/min more
x-travel:2000 mm y-travel:1000 mm Bdthm9reib z-travel:1050 mm table clamping surface::2.400 x 1.000 mm control:HEIDENHAIN TNC 426 CB turning speeds:20 - 5000 1/min tool taper:SK 40 spindle:22 kW total power requirement:57 kW weight of the machine ca.:10 t dimensions of the machine ca.:5 x 3 x 3 m CNC universal bed milling machine, direct measuring system, coolant device, head is swivelling automaticaly horizontal / vertical head is swivelling manually on the 4 th axis with display on screen... more
x-travel:4000 mm y-travel:1000 mm z-travel:950 (opt.1500) mm T-slot (width-distance-quantity):22H8x7 Stk. mm Table area:3600x1000 mm max. table load:9000 kg spindle taper:50 SK spindle speeds:3500 (5000 opt.) 1/min. spindle motor:15/18,5 (22/26 opt) kW feed:1~8000 mm/min rapid speed:10 m/min positioning accuracy:JIS 6338;±0,005mm / 300mm VDI 3441:P0,014mm repeating accuracy:JIS 6338:±0,003mm VDI3441:PS0,01 mm total power requirement:40 KVA weight of the machine ca.:23,6 t universal milling he... more
x-travel 2800 mm y-travel 1000 mm z-travel 1200 mm table surface area 2000 x 800 mm rotary table dia. 800 mm spindle taper SK 50 spindle turning speed - stepless 50 - 2000 U/min max. torque on the spindle 3000 Nm spindle drive 30 kW Ccuphadt feeds longditudinal/cross/vertical 2 - 2000 mm/min rapid motion -longitudinal/cross/vertical 7 m/min control SIEMENS control SINUMERIK 850 M no. of tools in magazin 56 workpiece diameter at full load 114 mm wotkpiece diameter with 2 vacant positions 200 ... more
x-travel:1300 mm y-travel:500 mm z-travel:570 mm table surface area:ca. 400 x 1500 mm power capacity - milling spindle:12 kW T-slot - distance:63 mm T-slot length:16 mm T-slot notches:5 max. table load:700 kg Distance spindle nose -table centre:150-670 mm distance spindle center to column:540 mm spindle nose:DIN 69871 spindle speeds::6000 U/min Pj0u23pt Tool changer:16 rapid traverse in x-y-z axis:10 m/min weight of the machine ca.:4,1 t dimensions of the machine ca.:3,8x3,8x2,8 m Spindle ... more
Retrofitted: 2019 Numerical control: HEIDENHAIN TNC-426 Technical features Dimensions Table dimensions: 3000 x 1100 mm Number of T slots: 8 T slots dimensions: 22 mm Traverses of axis X axis traverse: 3000 mm Y axis traverse: 1200 mm Z axis traverse: 1000 mm Milling head Head type: Universal manual Tool clamping system: Hydraulic Taper nose: ISO 50 Speed range: 20 - 3000 r.p.m. Spindle power: 22 kW Feedrates Feedrate: 2 - 5000 mm/min 2rihni Rapid feedrate:... more
Table : 3.200 x 1.120 mmX axis : 3.000 mmY axis : 1.600 mmZ axis : 1.600 mmControl: Heidenhain iTNC 530Equipped with the following accessories:Ortogonal head Infinitely variable in both axes. 7000 umd/minTool changer 50 fachIKZ with 50 bar.radio probe M Bfoceyu3np more
x travel 2000 mm Bi9lstnqg y travel 1000 mm z travel 1050 mm ----- WORKING RANGE -CUBIC- - number of processing axes (excl parallel axes) 4 - X-axis travel 2000 mm - Y-axis travel 1000 mm - Z-axis travel 1050 mm TABLE - table surface (left-right) 2400 mm - table surface (front-back) 820 mm MILLING SPINDLE / HEAD - spindle revolutions (max) 5000 /min - tool fixture: ISO SK 50 - drive power 22 kW more
x-travel:1500 mm y-travel:1000 mm z-travel:950 (opt.1500) mm T-slot (width-distance-quantity):22H8x7 Stk. mm Table area:1600x1050 mm max. table load:3000 kg spindle taper:50 SK spindle speeds:3500 1/min. spindle motor:15/18,5 (22/26 opt) kW feed:1~8000 mm/min rapid speed:10 m/min positioning accuracy:JIS 6338;±0,005mm / 300mm VDI 3441:P0,014mm repeating accuracy:JIS 6338:±0,003mm VDI3441:PS0,01 mm total power requirement:30 KVA weight of the machine ca.:10 t universal milling head:manuell LI... more
x-travel 1900 mm y-travel 1000 mm z-travel 1015 mm table surface area 2200 x 1000 mm spindle taper SK 50 control SIEMENS control SINUMERIK 840 C spindle turning speed range 2000 U/min feeds longditudinal/cross/vertical 5000 mm/min rapid traverse 15 m/min Ccuyyfxu table load max. 10 t total power requirement 34 kW weight of the machine ca. 24 t Accessories: magnetic plate 1250 x 500 mm, approx. 30 tool fixtures, measuring probe HEIDENHAIN, chip conveyor, coolant more
Technical details x-travel 1100 mm y-travel 560 mm z-travel 560 mm table-size 1600 x 630 mm tool taper ISO 50 spindle turning speed range 44 - 2240 U/min feed range 2 - 2000 mm/min Jvd23a main drive 11 kW weight of the machine ca. 6,0 t dimensions of the machine ca. 2,95 x 2,35 x 3,0 m Other information With: * 3-axis D.R.O. * Electro-tool-clamping * Operators manual Inspection under power in our warehouse possible. more
Retrofitted: 2018 Numerical control: HEIDENHAIN TNC-426 Technical features Dimensions Table dimensions: 2000 x 700 mm Bqmbxcfk Number of T slots: 5 T slots dimensions: 22 mm Traverses of axis X axis traverse: 2000 mm Y axis traverse: 800 mm Z axis traverse: 800 mm Milling head Head type: Universal manual Tool clamping system: Hydraulic Taper nose: A50 DIN69871 Speed range: 20 - 4000 r.p.m. Spindle power: 22 kW Feedrates Feedrate: 5 - 5000 mm/min Rapid feed... more
an extremely rigid, large-sized box-column design, made of premium cast-iron, provides a solid base for optimum work results extra wide guideways ensure maximum stability and precision at high loads extra long table travel distance (1500 mm) and large table set-up area (2100 x 500 mm) allow machining of large single parts or interactive machining of several parts - to give you a leading edge over your competition wide spindle speed range from 40 to 1600 rpm infinitely variable linear and cross f... more
Semco VMC 1000 CNC Bed Mill Model 1000, Anilam 1100M Control, Handwheel Control, Boxed Ways, 12 x 50" Table, 40 Int Spindle, 40" Travel X, 16" Travel Y, 27" Travel Z. Bfsblyspil more
Table : 2700 x 1000 mm. travels: 2000 x 900 x 900 mm. CNC HEINDENHAIN 407 Weight: 18000 kgs Yra2r8 more
x-travel 1500 mm y-travel 700 mm z-travel 700 mm table surface area 1800 x 600 mm spindle taper SK 50 spindle turning speed range 30 -1600 U/min transmission ratio 2 control HEIDENHAIN control TNC 155 feeds 5 - 2000 mm/min rapid motion -longitudinal/cross/vertical 8 m/min spindle drive 11 kW total power requirement kW weight of the machine ca. 9,2 t dimensions 3,4 x 3,15 x 3,07 m Accessories: vertical head swivelling in 2 planes (manual) with hydr. tool clamping, 2 counter bearings, ele... more
x-travel 4500 mm y-travel 1200 mm z-travel 2000 mm table surface area 4700 x 1200 mm table load 14 t tool taper SK 50 spindle turning speed range 6000 rpm transmission ratio 3 feed range 0 - 12000 mm/min power capacity 30 kW total power requirement 40 kW weight of the machine approx. 22 t Bft9hrfmt8 * CNC-control SIEMENS 840 D * automatic milling head 2,5 x 2,5 deg. * 40-station ATC * coolant through spindle 20 bar * swarf conveyor * prepared for 4th axis The milling head has been ... more
Retrofitted: 2019 Numerical control: HEIDENHAIN TNC-426 Technical features Dimensions Table dimensions: 2500 x 700 mm Number of slots: 5 T slots dimensions: 22 mm Traverses of axis X axis traverse: 2500 mm Y axis traverse: 800 mm Z axis traverse: 800 mm Milling head Head type: New! Universal Automático UDG (2,5º) Tool clamping system: Hydraulic Taper nose: ISO 50 (DIN 69871) Speed range: 3000 r.p.m. Spindle power: 22 kW Feedrates Feedrate: 5 - 5000 mm/min ... more
x-travel:1250 mm y-travel:470 mm z-travel:540 mm spindle speed:40,55,80,115,160,225,315,440,620,880,1240,1750 U/min (12 Stufen) spindle taper:50 NT/BT/SK table load:1000 kg table-size:400x1800 mm T-slot (width-distance-quantity):18x4x80 mm distance spindle nose and table:50-520 mm (vertikal) distance spindle center to table:50-520 mm (mit Halter), 360-790 mm (ohne Halter) feeds:X/Y/Z:16-1200/16-1200/8-450 mm/min rapid travel x/y/z:2000/2000/700 mm/min distance spindle center to column:500 mm ... more
CNC bed type milling machine AUERBACH type FBE 1200 CNC path control HEIDENHAIN TNC 407 A Fabr. No. 074 built in 1996 Routes x 1200 mm, Y: 600 mm, w: 600 mm Table size 1300 x 600 mm Table load 2 ton. ISO 50 spindle adaptor Distance spindle nose - table 58-658 mm Spindle speed continuously variable 30-3500 RPM. Feed 1 to 6000 mm/min. Rapid traverse 10 m / min. Spindle drive 22 kW Spindle torque 600 nm Max Power supply 400 Volt, 50 Hz, 50 amps. -CNC railway control system TNC 407 A -electronic han... more
Travel: longitudinal (X): 2500 mm Senkr. (Z): mm 1250 *(1750) Bdmoedjog9 Transverse (Y): mm 1200 Table size: Length: 2700 mm Width: mm 1000 T-slot: mm 6 x 22 H12 Referenznut: mm 1 x 22 H8 T - slot distance: mm 140 Power 100% ED: (option) 24 kW Spindle taper: ISO 50, DIN 69871 AD Speeds: (optional) min-1 20-5000 Torque: (option) nm 611 Feed range: X -, Y -, Z-axis 10-10000 mm/min Maximum speed: X -, Y -, and Z-axis 25000 mm/min Maximum thrust: X -, Y -, and Z-axis N 10000 Average acc... more
Bed-Type Milling Machine Zc9ypsg The successful multipurpose milling machine for heavy workpieces The massive cast-iron frame in bed-type milling machines brings many advantages when working with very large and heavy workpieces All guides are hardened and ground, X and Y axes are also counter-laminated with Turcite B to reliably avoid any stick-slip effect Infinitely variable spindle speeds and the main spindle features a quiet and smooth operation even at maximum speed The ISO 40 tool mount en... more
- CNC control Heidenhain iTNC530 - milling head VH-2 (C-axis: horizontal-vertical, B-axis: manual) - tool changer for 22 tools - chip conveyor - electronical hand wheel - coolant device Btvzlsf Technische Daten / technical details: Verfahrweg X / X-Travel 2600 mm Verfahrweg Y / Y-Travel 1000 mm Verfahrweg Z / Z-Travel 1500 mm Tischgröße / table size 2700x1050 mm Werkzeugschaft / spindle taper SK50 Drehzahlbereich (2-stufig) / spindle speed (2-steps) 3500 UpM /rpm Anzahl der Werkzeugplätze / to... more
Retrofitted: 2019 Numerical control: HEIDENHAIN TNC-530 Technical features Dimensions Table dimensions: 2800 x 1000 mm Number of slots: 5 T slots dimensions: 22 mm Traverses of axis X axis traverse: 2500 mm Y axis traverse: 1000 mm Z axis traverse: 1000 mm Milling head Head type: Universal manual (U22) Tool clamping system: Hydraulic Taper nose: ISO 50 – DIN 69871 Speed range: 20 – 4000 rpm Spindle power: 22 kW Feedrates Feedrate: 5 - 5000 mm/min Rapid fee... more
x travel mm y travel mm z travel mm ----- WORKING RANGE -CUBIC- - X-axis travel 4000 mm - Y-axis travel 1000 mm - Z-axis travel 1400 mm TABLE - table surface (front-back) 4200 mm - clamping surface diameter 1100 mm MILLING SPINDLE / HEAD - spindle type: tilting head - spindle revolutions (max) 6000 /min - number of gears 3 - tool fixture: ISO SK 50 TOOL MAGAZINE - number of positions 24 DIMENSIONS / WEIGHTS - space requirements -left/right- 10000... more
