Used Coolant System for sale (4,210)

Condition: excellent (used), Year of construction: 2003, functionality: fully functional, travel distance X-axis: 750 mm, travel distance Y-axis: 600 mm, travel distance Z-axis: 520 mm, controller manufacturer: Heidenhain, controller model: iTNC-530, rotational speed (max.): 18,000 rpm, operating hours of spindle: 14,120 h, coolant supply: 40 bar, 5-Axis Machining Center Manufacturer: DMG Model: DMU-70 Evo Control: Heidenhain iTNC-530 Year of manufacture: 2003 Operating hours: 59,270 h Spindle hours: 14,120 h S/N: XXXXX Technical Data: ----- • X-Y-Z travel: 750 / 600 / 520 mm • Rotary table: 700 x 500 mm • Spindle: 18,000 rpm (35/25 kW 40%/100% duty cycle) • Tool magazine: 32x HSK-A63 • High-pressure coolant 40 bar incl. 900L auxiliary tank • Option: Sealing air for linear measuring systems • Option: Programmable coolant nozzles • Option: 3D probe TS-641 • Option: Operating mode 4 • Option: Chip conveyor • Weight: 8,675 kg Hpjdjx Hz S Uopfx Af Doa Accessories: ----- • Manuals • Electronic handwheel • Emulsion mist extractor • Rinsing gun Remarks: ----- • Machine from training department!

Condition: used, Year of construction: 2020, functionality: fully functional, machine/vehicle number: 1473114, This filter and cooling unit was previously used for two Starrag Heckert machining centers (lot 2770011 and 12). Order number: 2153651 Control voltage: 24 V DC Connection voltage: 3×400 V + PE / 50 Hz Connected load: 6.30 kW Fuse: 50 A Country of manufacture: Germany Additional unit: Manufacturer: BKW GmbH, Wolfschlugen Model: WRK3C-2KK2P Year of manufacture: 2005 Refrigerant: R134a Permissible operating pressure: 24 bar Voltage: 400 V / 50 Hz Output: 5.02 kW Control voltage: 24 V DC Country of manufacture: Germany Hpedpfxjx Hinks Af Dja

Condition: used, Year of construction: 2017, liter capacity 980 l Pressure of pump 8 / 20 / 80 bar control Schütze / Contactors weight of the machine ca. 765 kg dimensions of the machine ca. 2,3 x 2,0 x 1,8 m Coolant System MAYFRAM - DPF400-V980 SKD (BFU 980 /S/20+/8) - NEW, unused - universally applicable - can be controlled via contactors - incl. paper band filter Hedex Ak Eyepfx Af Dopa - Number of pumps: 3 - Pump capacity: 4.0 kW, 2,917 rpm, 5.8 m³/h, 96.6 l/min, pressure 25 bar, max. temp. 90°C 3.0 kW, 3,514 rpm, 20.5 m³/h, 341.66 l/min, pressure 25 bar, max. temp. 90°C -.- kW, 2,864 rpm, 2.0 m³/h, 33.3 l/min, pressure 25 bar, max. temp. 90°C

Condition: used, cooling capacity: 5.5 kW (7.48 HP), input voltage: 400 V, input frequency: 50 Hz, immersion depth: 460 mm, Spandau Pump SKF Lubrication Systems Germany GmbH Submersible centrifugal pump, submersible pump, coolant submersible pump, centrifugal pump unit TYPE PSL0303GBS460N05BA Immersion depth: 460 mm Hjdpfxow Rvhdo Af Dopa 400 V 50Hz Delta connection 5.5 kW IE2 The coolant pump was used on a Hoffmann filter system of a Kapp grinding machine. Price / details on request All technical data subject to typographical error / change. We sell exclusively to countries within the European Union.

Condition: used, Liquid chiller, cooling unit, Used machine Manufacturer: Hoffmann Type: ERK 360-H Overall dimensions: Width: 2380 mm Depth: 980 mm Height: 2450 mm Year of manufacture: 1996 Cooling capacity: 36,000 kcal/h Refrigerant: R134A – 20 kg Max. operating pressure: 17 bar Electrical data: 400V; 17 kW Hpedpoxackpsfx Af Dsa

Condition: good (used), Year of construction: 2010, functionality: fully functional, coolant tank capacity: 550 l, Equipment: cooling unit, Vomat 120 EKSd Year of manufacture: 2010 Tank capacity: 550 litres Filtering capacity: 120 L/min Pump power: 6 kW Including air conditioning unit Fully functional For sale due to site closure All filters included Immediately ready for use Hedsx Dic Tspfx Af Djpa

Condition: new, Coolant mixer Make Hebro type ND 2305 unused in closed original packing Hpjdpfx Ash D Rytof Dsa flow rate at 4 Bar/20 L/min. 2 Bar 14 L/min

Condition: good (used), Year of construction: 2018, Internal item no.: 25043 5-Axis CNC Machining Center POSmill H 500 U Year: 2018 Just approx. 1,000 spindle hours since spindle replacement Machine total approx. 20,500 hours Spindle replaced in 2024 (18,000 rpm) Geometry realigned in 2024. Travel axes: X 650 / Y 850 / Z 500 mm Rotary table: 360° infinite Control: Heidenhain iTNC 530 Spindle: 18,000 rpm Spindle interface: HSK-A63 The machine is equipped as follows: 60-position tool changer Through-spindle coolant (20 bar) with belt filter system Compressed air through the spindle Kessler rotary table, diameter 500 mm Infrared 3D part measurement probe Tool measurement via BLUM laser Rotating inspection window POS DCM collision module Mobile electronic handwheel Oil mist extraction system Heidenhain linear measurement system X, Y, Z Purge air for all linear measurement systems Active control cabinet air-to-air cooler Active cooling for 4th + 5th axis, controlled Hpedowz I Acspfx Af Dsa Network connection + USB port Controlled spindle cooler Heidenhain rotary measuring system Contour protection POSkontur External hinge belt chip conveyor Coolant pump at the head, operated via M-functions Pump for chip flushing device Chip flushing device Machine status indicator light Spindle air purge Electromechanical oil/coolant separator Automatic coolant level monitoring 3-fold media interface in the center of the table Hydraulic unit incl. control via M-function Connected load: 60 kVA Installation dimensions: W 4800 / D 4600 / H 3000 mm + Through-spindle coolant unit (LxWxH): 2200 x 1300 x 1400 mm Weight: approx. 13,000 kg The machine is in very well-maintained condition and comes from a small, family-run business. In 2024, the spindle was replaced and the geometry was set (guides repaired and adjusted). Since then, the machine has seen only minimal use.

Condition: used, Year of construction: 2019, liter capacity 980 l Pressure of pump 8 / 20 bar control Schütze / Contactors weight of the machine ca. 560 kg dimensions of the machine ca. 2,3 x 2,0 x 1,8 m Coolant System MAYFRAN - BFU 980 /S/20+/8 - NEW, unused Hodpex Ak Etofx Af Dspa - universally applicable - can be controlled via contactors - incl. paper band filter - Number of pumps: 2 - Pump capacity: 4.0 kW, 2,917 rpm, 5.8 m³, 96.6 l/min, pressure 25 bar, max. temperature 90°C -.- kW, 2,864 rpm, 2.0 m³/h, 33.3 l/min, pressure 25 bar, max. temperature 90°C

Condition: ready for operation (used), Year of construction: 2015, Offered is a coolant system type 800L CC 61 year 2015 with integrated centrifuge WZ 95 SP year 2016. Tank capacity approx. 880l, pump delivery rate 160l/min, nominal volume flow 800-1200m³/h. Including cooling unit ET 55 V with refrigerant R134a HP max. 24bar/LP max. 13bar. Inspection possible by arrangement. Hsdpexzt D Aofx Af Dopa

Condition: new, functionality: fully functional, For sale: The Haas automatic coolant refill system monitors the coolant level in the machine and automatically adds new coolant to the tank at the correct mixing ratio. 2 units available. When purchasing both coolant refill systems together: Only €800 each! All technical details can be found on the Haas website: 3w.haascnc.com/de/productivity/chip-and-coolant-management/coola nt-refill.html Hjdpjxzr S Eofx Af Depa

Condition: used, Container size approx.: 0.7 x 1.3 x 0.14 m Hpsdpfx Ajxy Ibyof Dja Container volume approx.: 110 liters

Condition: excellent (used), Year of construction: 2008, functionality: fully functional, Vomat 120 kg Year of manufacture: 2008 Tank capacity: 550 L Filtration capacity: 120 L/min Hpjdpexp Um Iofx Af Doa

Condition: used, Technical details: voltage: 360-730 / 50 V / Hz weight of the machine ca.: 0,150 t * Hpodpfou N Afyox Af Dsa

Condition: excellent (used), Blaser coolant mixer. The unit is manufactured by Hamma, model Misceo 3. The device is fully operational. Hpedsxv Encjpfx Af Doa

Condition: good (used), Year of construction: 2004, Overall dimensions: 3300 x 2100 x 2200 mm Hpodeiuxmvepfx Af Dsa Year of manufacture: 2004 Processing and filtering capacity: 700 l/min Filter fineness: 40 ppm > 20 µm Filling volume: 7250 l Pump capacity: 7,5 kW; 550 l/min; 5 bar

Condition: used, Year of construction: 2022, liter capacity 980 l Pressure of pump 8 / 80 bar control Schütze / Contactors total power requirement 16,7 kVA weight of the machine ca. 1,1 t dimensions of the machine ca. 2,40 x 2,00 x 1,96 m Coolant System BMF - BMF 980 L -4 - NEW, unused - universally applicable Hedpfxowhzm Is Af Dopa - can be controlled via contactors - Number of pumps: 2 - Pump output: 5.5 kW, 2,950 rpm, 1.2 m³/h, 20.0 l/min, pressure 80 bar, max. temperature 80°C 2.2 kW, 3,501 rpm, 6.9 m³/h, 115.0 l/min, pressure 25 bar, max. temperature 90°C - incl. paper belt filter Technical Data (Motor): - 1,350 rpm - 0.12 kW - incl. cooling unit (Deltatherm E4) Technical Data: - Power: 4 kW - Max. ambient temperature: 40 °C - Max. operating pressure: 28 bar - Refrigerant: R407C - Refrigerant quantity: 2.4 kg - Connected power: 2.5 kW

Condition: excellent (used), Coolant mixer Emulsion mixer Nimatec Hjdpfx Aowf Ht Isf Djpa Stock number (28599) 1/2-inch water supply connection

Condition: used, Year of construction: 2023, tank 1.300 l Pressure of pump 8 / 20 / 80 bar control Schütze / Contactors total power requirement 18,4 kVA weight of the machine ca. 1,2 t dimensions of the machine ca. 2,40 x 2,00 x 1,96 m Coolant System BMF - BFU 1300 S/80/20/8+ Z/K - NEW, unused - universally applicable - can be controlled via contactors - Number of pumps: 4 - Pump capacity: 5.5 kW, 2,950 rpm, 1.2 m³/h, 20.0 l/min, pressure 80 bar, max. temperature 80°C 4.0 kW, 2,917 rpm, 5.8 m³/h, 96.6 l/min, pressure 25 bar, max. temperature 90°C -,- kW, 3,447 rpm, 2.3 m³/h, 38.3 l/min, pressure 25 bar, max. temperature 90°C 2.2 kW, 2,899 rpm, 5.8 m³/h, 96.6 l/min, pressure 25 bar, max. temperature 90°C - incl. paper belt filter Technical Data (Motor): - 1,350 rpm - 0.12 kW - incl. centrifuge (Ruma MZ 35) Technical Data: - Rotor speed: 4,615 rpm - Rotor diameter: 230 mm - Temperature (min/max): 10 - 50 °C - Flow rate (min/max): 10 - 35 l/min - Max. solids quantity: 6 kg - Rated power: 2 kW Hedowgd Irspfx Af Dopa - incl. cooling unit (Deltatherm E4) Technical Data: - Power: 4 kW - Max. ambient temperature: 40 °C - Max. operating pressure: 28 bar - Refrigerant: R407C - Refrigerant quantity: 2.4 kg - Connected power: 2.5 kW

Condition: excellent (used), Suction & Filtration Trolley Manufacturer: Anton Metzger Model: MKR 400 S Capacity: 400 liters Technical data, see photo Documentation available Hpsdpfjw Avzpex Af Dsa Length: 2650 mm Width: 800 mm Height: 1440 mm Weight: 610 kg

Condition: used, Year of construction: 2023, tank 1.300 l Pressure of pump 8 / 20 / 80 bar control Schütze / Contactors total power requirement 18,4 kVA weight of the machine ca. 1,2 t dimensions of the machine ca. 2,40 x 2,00 x 1,96 m Coolant System BMF - BFU 1300 S/80/20/8+ Z/K - NEW, unused - universally applicable - can be controlled via contactors - Number of pumps: 4 - Pump capacity: 5.5 kW, 2,950 rpm, 1.2 m³/h, 20.0 l/min, pressure 80 bar, max. temperature 80°C 4.0 kW, 2,917 rpm, 5.8 m³/h, 96.6 l/min, pressure 25 bar, max. temperature 90°C -,- kW, 3,447 rpm, 2.3 m³/h, 38.3 l/min, pressure 25 bar, max. temperature 90°C 2.2 kW, 2,899 rpm, 5.8 m³/h, 96.6 l/min, pressure 25 bar, max. temperature 90°C - incl. paper belt filter Technical Data (Motor): - 1,350 rpm - 0.12 kW - incl. centrifuge (Ruma MZ 35) Technical Data: - Rotor speed: 4,615 rpm - Rotor diameter: 230 mm - Temperature (min/max): 10 - 50 °C - Flow rate (min/max): 10 - 35 l/min - Max. solids quantity: 6 kg - Rated power: 2 kW - incl. cooling unit (Deltatherm E4) Technical Data: Hpodewgd I Ejpfx Af Dsa - Power: 4 kW - Max. ambient temperature: 40 °C - Max. operating pressure: 28 bar - Refrigerant: R407C - Refrigerant quantity: 2.4 kg - Connected power: 2.5 kW

Condition: used, Year of construction: 2019, liter capacity 980 l Pressure of pump 8 / 20 bar control Schütze / Contactors weight of the machine ca. 560 kg dimensions of the machine ca. 2,3 x 2,0 x 1,8 m Coolant System MAYFRAM - DPF400-V980 SKD (BFU 980 /S/20+/8) - NEW, unused Hjdjwhzmhspfx Af Djpa - universally applicable - can be controlled via contactors - incl. paper band filter - Number of pumps: 3 - Pump capacity: 4.0 kW, 2,917 rpm, 5.8 m³/h, 96.6 l/min, pressure 25 bar, max. temp. 90°C 3.0 kW, 3,514 rpm, 20.5 m³/h, 341.66 l/min, pressure 25 bar, max. temp. 90°C -.- kW, 2,864 rpm, 2.0 m³/h, 33.3 l/min, pressure 25 bar, max. temp. 90°C

Condition: used, Year of construction: 2019, liter capacity 980 l Pressure of pump 8 / 20 bar control Schütze / Contactors weight of the machine ca. 650 kg dimensions of the machine ca. 2,3 x 2,0 x 1,8 m Coolant System BOSCH REXROTH - BFA 980-50Hz /S/20/8 Hpodpfjwhzmnex Af Dsa - very good condition - universally applicable - can be controlled via contactors - incl. paper band filter - Number of pumps: 2 - Pump performance: 1.7 kW, 2.3 HP, 2,890 rpm, 60 l/min 3.0 kW, 4.0 HP, 2,930 rpm, 40 l/min

Condition: used, Year of construction: 2019, liter capacity 600 l Pressure of pump 8 / 20 bar control Schütze / Contactors weight of the machine ca. 450 kg Hpedpfowhzmzox Af Doa dimensions of the machine ca. 1,2 x 1,8 x 1,6 m Coolant System BMF - BFU 600 /S2/20/8+ - NEW, unused - universally applicable - can be controlled via contactors - incl. paper band filter - Number of pumps: 2 - Pump performance: 2.6 kW, 3.5 HP, 2,880 rpm, 160 l/min 3.0 kW, 4.0 HP, 2,930 rpm, 40 l/min

Condition: used, Year of construction: 2019, liter capacity 980 l Pressure of pump 8 / 20 bar control Schütze / Contactors weight of the machine ca. 560 kg dimensions of the machine ca. 2,3 x 2,0 x 1,8 m Coolant System MAYFRAN - BFU 980 /S/20+/8 - NEW, unused - universally applicable - can be controlled via contactors - incl. paper band filter - Number of pumps: 2 - Pump capacity: 4.0 kW, 2,917 rpm, 5.8 m³, 96.6 l/min, pressure 25 bar, max. temperature 90°C Hpjdpjwhzm Uefx Af Dsa -.- kW, 2,864 rpm, 2.0 m³/h, 33.3 l/min, pressure 25 bar, max. temperature 90°C
