Used Hegenscheidt 7487-1 for sale (7)

Condition: used, Year of construction: 2000, machine/vehicle number: 202000, Hegenscheidt MFD 7893 CNC Deep Rolling Machine max length 920mm, max radius of counter weight (deending on dtroke and bearing width) 195 - 270mm, max 8 main + 6 pin bearings, min/max main bearing dia 33 - 88mm, min/max pin bearing dia 30 - 84mm, max bearing width 18,5mm, max stroke 140mm, CNC SIEMENS SINUMERIK 840D, 400V 50Hz 35kVA, weight 13to Knsdpfx Agexxyluszjf

Condition: used, Year of construction: 2006, functionality: fully functional, Description Headstock and tailstock manually adjustable. Ideally suited for machining one crankshaft type with different strokes. Workpiece Max. center-to-center distance of the outer main bearings: 920 mm Max. roll arm length (½ stroke + counterweight radius): 195 – 270 mm Max. number of machineable bearings: 8 main bearings, 6 pin bearings Main bearing diameter, min. / max.: 30 / 88 mm Knjdswm Elfjpfx Agzsf Pin bearing diameter, min. / max.: 30 / 84 mm Bearing width, min.: 18.5 mm Stroke, max.: 140 mm Bearing pitch, min.: 29.5 mm Deep rolling machines Max. deep rolling force: 30,000 N Headstock Main drive motor power: 20 kW Deep rolling speed: 120 rpm / 60 rpm Leveling rolling speed: 30 min¯¹ Machine Weight including auxiliary units: approx. 13,800 kg Dimensions including integrated control cabinet and hydraulics (L/W/H): approx.: 4.5 x 2.5 x 2.2 m Max. machining height: 1,100 mm

Condition: good (used), Year of construction: 1996, incl. Chip conveyor incl. Chip crusher Under power incl. spare rollers Power on hours  23.000 H Working hours ca 8.000 H Rail track gauge: 1435mm Max. wheel tread Ø: 1400mm Min. wheel tread Ø: 520mm Max. axle length wheel set:2450mm Min. axle length wheel set:1620mm Speeds / ranges: 154Rpm Number of slides: 2 Power: 44kW Knodpew Rc Drofx Agzsf Length: 6000mm Width: 2200mm Height: 2600mm Weight: 33000kg

Condition: like new (used), Year of construction: 2019, Roller burnishing machine, hardly used in crankshaft production, as good as new Kedsxlr Ibepfx Agzonf

Condition: ready for operation (used), controller model: Siemens Sinumerik, empty load weight: 35,000 kg, total length: 7,000 mm, total width: 2,300 mm, total height: 3,300 mm, PORTAL WHEEL LATHE Siemens CNC control track wheel diameter range: 540 1400 mm axle length: max 2600 mm max track: 1435 mm max. workpiece weight: 5 tons main power: 100 kW cutting speed: max 500m/min Railset lathe / Railway lathes / Rail lathe high machining accuracy in terms of concentricity and surface quality optimal force parallelogram measuring system for diameter and profile wear measuring system for CL+CR determination measuring system for determining the concentricity of the drive shaft measuring system for wheel and axle brake discs re-profiling of all common locomotive, passenger car and wagon wheel sets planning of axles and wheel brake discs rim processing axle processing marking groove turning Knsdpfx Agsv St E Eezef Chip shredder included

Year of construction: 1984, condition: good (used), functionality: fully functional, machine/vehicle number: 100752, Underfloor wheelset lathe type 106 Machine its good maintenenced Knedpfx Asttz D Tegzsf Hydraulic copy lathe

Year of construction: 2010, condition: good (used), Make: Hegenscheidt MFD Type: PR 250 / 1000 Control: Siemens TOUCH Year: 2010 Rebuild in 2010 with SIEMENS TOUCH Rebuild cost EUR 200.000 Distance measuring device with double taster Big package with pressing tools in several diameters Specifications Metric US Standard Centre height Knjdpfx Agokvnggjzof 550 mm Max. wheel tread Ø 1100 mm Max. wheelset length 2500 mm Max. pressing force 250 T Max. cylinder stroke 500 mm Cylinder Ø 300 Working speed 10 - 80 mm/min. Pinole feed 1300 mm/min. Return speed 1300 mm/min. Dimensions (Estimate) Length 6100 mm Width 5730 mm Height 3750 mm Weight 15900 kg Please Note: The information on this page has been obtained to the best of our ability and belief, and from the manufacturers where possible. It is given in good faith, but its accuracy can not be guaranteed. Accordingly, it will not form a representation or constitute contractual terms. We advise you to check any vital details!
