Used Horizontal Jig Boring Machine for sale (66,630)

Condition: used, Quill for jig boring mill, fine boring mill, plate boring mill, table boring mill, boring mill, milling machine, -Stroke: 60 mm -in: a wooden box Rjdofc R D Ijpfx Ab Rjch -Dimensions: 390/340/H170 mm -Weight: 15.8 kg

Condition: excellent (used), Year of construction: 1984, functionality: limited functionality, machine/vehicle number: B30157, travel distance X-axis: 400 mm, travel distance Y-axis: 250 mm, travel distance Z-axis: 450 mm, table length: 600 mm, table width: 380 mm, table load: 300 kg, spindle mount: MK 3, total height: 2,545 mm, total length: 1,700 mm, table height: 965 mm, total width: 1,330 mm, rapid traverse X-axis: 1 m/min, rapid traverse Y-axis: 1 m/min, rapid traverse Z-axis: 900 m/min, rotational speed (min.): 30 rpm, rotational speed (max.): 2,500 rpm, drilling capacity: 30 mm, type of input current: three-phase, quill stroke: 140 mm, quill diameter: 85 mm, spindle diameter: 100 mm, spindle motor power: 8,200 W, workpiece weight (max.): 300 kg, rotary table diameter: 200 mm, Additional specs: Resolution: 0,001mm Rodpfx Abeungrgj Rsch Max. capacity of boring: 220mm Machine weight: 2500kg Additional equipment: - One rotating table with two rotating axis. - Collets, clamping elements miscellaneous, tool holders. - Documentation for machine

Condition: used, Year of construction: 1989, table length: 2,240 mm, table width: 1,400 mm, workpiece weight (max.): 5,000 kg, controller model: Siemens 840D, No minimum price – guaranteed sale to the highest bidder! Submitting a bid commits you to collecting the item on time, no later than October 31, 2026! TECHNICAL DETAILS Longitudinal adjustment of the table (X-axis): 2,000 mm Transverse adjustment of the intermediate slide (Y-axis): 1,600 mm (1,500 mm) Vertical adjustment of the crossbeam (W-axis): 900 mm Adjustment of the drilling spindle (Z-axis): 400 mm Distance between the table clamping surface and the spindle head: min. 100 mm Distance between the table clamping surface and the spindle head: max. 1,400 mm Passage between the columns: 1,600 mm Workpiece weight max.: 5,000 kg Tool holder: SK 50 Table Width of the clamping surface: 1,400 mm Length of the clamping surface: 2,240 mm Clamping surface: 3.14 m² Number of T-slots: 9 T-slot width: 22 H7 mm Distance between T-slots: 160 mm Adjustment speeds Axis X: 0.1–4,000 mm/min Axis Y: 0.1–4,000 mm/min Axis Z: 0.1–4,000 mm/min Difference between adjacent feeds: 0.1 mm/min Rapid traverse speeds Axis X: 12,000 mm/min Axis Y: 12,000 mm/min Axis Z: 8,000 mm/min Axis ZW: 1,600 mm/min MACHINE DETAILS Control system: Siemens 840D Dimensions & Weight Space requirement (L × W × H): 7,000 × 6,500 × 5,300 mm Weight: 22,500 kg Rjdsz Hvyzopfx Ab Roch EQUIPMENT Comprehensive documentation All fluids will be drained before collection. Data backup has been saved to a USB drive. A 10-ton bridge crane is available on-site to assist with disassembly and loading. A forklift can be used if arranged in advance.

Condition: used, functionality: fully functional, Manufacturer: SIP, Switzerland Model: MP-5E Rcjdpjzvxw Dsfx Ab Reh Machine type: Coordinate drilling machine Longitudinal travel X: 700 mm Transverse travel Y: 500 mm Spindle travel: 180 mm Work surface of the table: 900 × 770 mm Max. distance table–spindle: 800 mm Min. distance table–spindle: 200 mm Clearance between columns: 875 mm Spindle sleeve diameter: 95 mm Spindle feed/increment: 5 mm Number of spindle speeds: 12 Spindle speed: 50–2,250 rpm Number of feed stages: 4 Feed rate during drilling: 0.04–0.21 mm/rev Max. table load: 600 kg Required electrical power: 5 kVA Machine weight: approx. 5,400 kg

Condition: used, Year of construction: 1998, travel distance X-axis: 2,000 mm, travel distance Y-axis: 1,300 mm, travel distance Z-axis: 1,200 mm, controller model: MSC 502, spindle speed (max.): 6,000 rpm, TECHNICAL DETAILS X-axis travel: 2,000 mm Y-axis travel: 1,300 mm Z-axis travel: 1,200 mm Number of axes: 4 Spindle speed: 60–6,000 rpm Spindle power: 30–37 kW Spindle mounting: ISO 50 / BT Number of pallets: 2 Pallet size: 1,000 × 1,000 mm Pallet load: max. 3,000 kg Workpiece diameter: max. 2,000 mm Workpiece height: max. 1,550 mm Workpiece weight: max. 3,000 kg Magazine type: Chain magazine Tool positions: 120 MACHINE DETAILS Control system: MSC 502 Rcsdpfj Agfrzox Ab Rjh Dimensions & Weight Machine weight: 35,200 kg Overall dimensions: 5,330 × 7,720 × 3,810 mm EQUIPMENT Pallet changer High-pressure coolant system Chip conveyor RS-232 interface Tool pre-setter

Year of construction: 2012, condition: excellent (used), YASDA YBM Vi40 CNC jig boring machine / machining center machine in perfect condition incl. accessories (see photos) For the complete photo gallery: See attached PDF file (from page 4) TECHNICAL DATA Travels X-axis: 900 mm Y axis: 500 mm Z axis: 450 mm Distance from the table surface to the spindle tip: 100 to 550 °. Rotary table diameter: 400 mm Pallet loading capacity: 200 kg Table surface configuration: 44-M12 thread C axis: 360 ° Table tilt axis movement range (B axis): +- 110 ° Distance between center of tilt axis and rotary table: 0 mm Rotary axis (C axis): 100 rpm Max. rotation of the inclination axis: 20 rpm Motor for rotary axis: 4,2 kW Motor for inclination axis: 4,5 kW Spindle type: SA40-24`000-18,5 Spindle speed range: 100 - 24`000 rpm Spindle speed range programming: Programming by direct input of a 5-digit S-command Number of spindle speed ranges: 1 Type of spindle conical bore: HSK-63A Inner diameter of spindle bearing: 65 mm diameter Rapid traverse Speed: X,Y,Z axis: 20`000 rpm Feed rate: X,Y,Z axis: Max. 5000 rpm C-axis: 100 rpm B axis: 20 rpm Smallest input increment: 0.0001 mm/deg Automatic tool changer: 60 tools Selection method: Any selection Tool shank type: HSK-63 A Max. tool diameter Tool diameter: 100 mm Max. tool diameter Tool diameter at full setting: 70 mm Max. Tool length: 250 mm Max. Tool weight: 7 kg Tool balance weight: within G2.5 Machine dimensions: 3220 x 3885 x 3515 mm Rjdpspqx H Tofx Ab Rsch Machine weight: 15`000 kg No responsibility is taken for the accuracy, completeness and timeliness of the information.

Condition: excellent (used), Year of construction: 1968, functionality: fully functional, travel distance Z-axis: 950 mm, spindle speed (max.): 1,900 rpm, spindle speed (min.): 38 rpm, feed rate X-axis: 400 m/min, feed rate Y-axis: 400 m/min, feed rate Z-axis: 400 m/min, table length: 1,000 mm, table width: 1,000 mm, table load: 2,000 kg, spindle mount: MK 5, total height: 3,500 mm, total length: 2,750 mm, table height: 850 mm, total width: 2,280 mm, rapid traverse X-axis: 1 m/min, rapid traverse Y-axis: 1 m/min, distance between stands: 1,575 mm, spindle diameter: 120 mm, spindle motor power: 11,000 W, spindle stroke: 300 mm, Additional techical specs: - Distance between pilars - 1575mm Rcodpfounhd Rjx Ab Roh - Spindle speed: Nr.of gears: 18, Range 1:50: 18 to 1900 RPM, Stepup: 1,26 - Spindle feed: Drilling feed, nr. of gears: 15. Range: 0,03 to 0,8 mm/rev. Frictional feeds, nr.of gears: 3. Range: 2, 3 to 4 mm/rev. - Performance: Largest drilling diameter into solid material: 55mm for cast iron with feed: 0,6mm/rev. Largest drilling diameter approx.: 300mm Largest facing diameter: 620mm Largest cutting diameter (for steel,cast iron) approx.:120mm Largest milling-cross section (with table feed): 150mm2 at a milling feed of: for cast iron- 400mm/min, for steel: 200mm/min Power of drilling motor: 6 HP Power of lifting motor: 5 HP Connected load of the machine: 11kW Extras: coilets, tool holders, other additional equipment, documentation for machine

Condition: used, Year of construction: 1980, spindle diameter 135 mm x-travel 950 mm distance between columns 1100 mm y-travel 700 mm cross rail adjustment - vertical 780 mm quill travel 300 mm max. distance between table and spindle-nose 1000 mm table surface area 1100x842 mm Rodpfoy Ehwhjx Ab Rjch table load 1500 kg speeds 40-2000 U/min adjustment speed 5-1500 mm/min electrics - voltage/frequency 380/50 V/Hz total power requirement 8 kW weight of the machine ca. 9,5 t dimensions of the machine ca. 3,3x2,34x2,8 m total power requirement 8 kW weight of the machine ca. 9,5 t dimensions of the machine ca. 3,3x2,34x2,8 m

Condition: ready for operation (used), SIP 640, CNC, precision boring machine with Fanuc control. Rcodsz H Nrqjpfx Ab Rjh

Condition: good (used), Year of construction: 2004, functionality: fully functional, machine/vehicle number: 10160, travel distance X-axis: 800 mm, travel distance Y-axis: 750 mm, travel distance Z-axis: 805 mm, rapid traverse X-axis: 38 m/min, rapid traverse Y-axis: 38 m/min, rapid traverse Z-axis: 38 m/min, total height: 3,500 mm, total length: 7,000 mm, total width: 6,000 mm, overall weight: 17,000 kg, number of slots in tool magazine: 180, tool length: 600 mm, tool diameter: 250 mm, tool weight: 35,000 g, STARRAG HECKERT CWK 500 Horizontal Machining Center - Tool holder: HSK A 100 - Min. distance from the front edge of the working spindle to the center of the pallet: 150 mm - Min. distance from the center of the working spindle to the top edge of the pallet: 100 mm - Max. permissible height of workpiece and clamping devices for changing the work area: 900 mm - Workpiece side (pallet) with hole grid according to DIN 55201, clamping surface: 500 x 500 mm - Max. load per pallet (centered): 800 kg - Guide bore diameter: 20 H6 - Centering bore diameter: 50 H6 - Number of mounting threads: 23 x M12 - Distance of the guide bore to the center of the table: diameter 200 +- 0.013 mm - Interference circle diameter: 800 mm - Max. table rotation: 18 rpm - Automatic pallet changer - Pallet changer with rotating setup station - max. pallet change time: 10 sec Rsde Afnc Eepfx Ab Rech - Pallet change time with clamping hydraulics: min. 12 sec - Feeds: X/Y/Z axis: continuously adjustable working feed range: 1 - 38,000 mm/min - Working spindle diameter in the front bearing: 100 mm - Max. tool diameter with free neighboring positions: 250 mm - Max. tool diameter for bridge tools: 500 mm - Max. tool diameter with occupied neighboring positions: 125 mm - Tool overhang length: 600 mm - Max. tool weight: 35 kg - Average tool weight with full occupancy: 10 kg - Max. imbalance in the tool magazine: 100 kg - Number of pallets: 2 With Balluff system, technical documentation, with RENISHAW 3D measuring probe, including 30 HSK 100 tool holders, mostly equipped with tools. Transport: The machine can most likely be transported on a truck with a width of up to 3000 mm. FCA D-01445 Radebeul - loaded onto a truck

Condition: good (used), Year of construction: 2005, functionality: fully functional, machine/vehicle number: 255179729, travel distance X-axis: 1,050 mm, travel distance Y-axis: 800 mm, travel distance Z-axis: 880 mm, rapid traverse X-axis: 40 m/min, rapid traverse Y-axis: 40 m/min, rapid traverse Z-axis: 40 m/min, nominal power (apparent): 74 kVA, torque: 525 Nm, controller manufacturer: Mazak, controller model: 640M, workpiece height (max.): 1,000 mm, workpiece diameter (max.): 1,050 mm, workpiece weight (max.): 1,500 kg, total height: 3,200 mm, total length: 6,400 mm, total width: 2,600 mm, table width: 630 mm, table length: 630 mm, table load: 1,500 kg, overall weight: 19,700 kg, spindle speed (min.): 50 rpm, spindle speed (max.): 10,000 rpm, spindle nose: BT 50, number of spindles: 1, number of slots in tool magazine: 80, mount diameter: 50 mm, tool length: 500 mm, tool diameter: 420 mm, tool weight: 30,000 g, Equipment: chip conveyor, documentation/manual, rotational speed infinitely variable, TECHNICAL DETAILS Operating condition Condition: fully functional Inspection: possible under power after prior arrangement Table and swivel axis Table design: swivel axis Division of swivel axis: 1/360° Machine dimensions Length: approx. 6,400 mm Width: approx. 2,600 mm Height: approx. 3,200 mm Redpfxez R A Ibj Ab Rsch Coolant system Tank volume: approx. 800–900 l Tank length: 1,800 mm Tank width: 800 mm Tank height: 650 mm Pallets Number of pallets: 2 pcs. Pallet dimensions: 630 × 630 mm EQUIPMENT Tool holders External coolant drum filter tank Renishaw MP10 measuring probe system Grid frame in front of the machine, partially mobile 2 pallets, 630 × 630 mm

Condition: excellent (used), Year of construction: 1998, Used cnc horizontal milling boring machine Brand: AYCE Model: AC100-k4 Serial number: 740 Year: 1998 Power: 16kw Weight: 12,700kg AC100-K4 MODEL WITH CONTINUOUS ADVANCE VARIATION Numerical control: Heidenhain TNC124 with 4 axes (X, Y, Z, B) Number of bench supports: 4 (K4) OPTIONALS: - Cnc Heidenhain - Automatic positioning of the table rotation 4 x 90º. - Vertical course 1200mm (Instead of 1000mm that the standard model has) - Refrigeration equipment Rcedpfx Aoizxbiob Roh - Face plate and clamping arm - Universal vertical apparatus, Huron type with hydraulic tool clamping - Rest for vertical course of 1200mm - Table rotation display 4th AXIS (B) Principal axis: - Shaft diameter: 100mm - Inner cone: ISO 50 with quick tool clamping (Instead of Morse 5) - Drill mounting diameter: 171.45mm - Horizontal course of the main axis: 700mm - Vertical course of the main axis: 1200mm - Number of turning speeds: 18 - Speed range: 12-1200 rpm - Maximum distance between plate and steady rest: 2250mm Advances: - Number of work advances in all directions: INFINITE - Min/max value of work progress: 2 - 1500 mm/min. - Rapid advances in carriages and head: 3000 mm/min. - Rapid advance main axis: 1500 mm/min. - Rapid table rotation advance: 600 degrees/min. Rotary table: - Turntable dimensions: 1100x1200mm - Table longitudinal course without steady rest: 1500mm - Curos longitudinal table with lunette: 1200mm - Cross course: 1700mm - Distance between axis/maximum table center without steady rest: 1975mm - Distance between axis/maximum table center with steady rest: 1600mm Automatic centralized greasing. Hardened and rectified guide. Telescopic guide protectors. Ball screws in the 3 axes. Automatic hydraulic locks in all movements.

Condition: excellent (used), functionality: fully functional, travel distance X-axis: 2,000 mm, travel distance Y-axis: 1,200 mm, travel distance Z-axis: 2,000 mm, table load: 6,000 kg, spindle diameter: 110 mm, spindle speed (min.): 5 rpm, spindle speed (max.): 1,120 rpm, total height: 4,300 mm, total length: 7,200 mm, total width: 4,600 mm, table length: 1,600 mm, table width: 1,400 mm, feed length W-axis: 800 mm, type of input current: AC, spindle stroke: 800 mm, overall weight: 26,000 kg, year of last overhaul: 2020, A Union Gera BFT 110/6 horizontal boring mill is for sale The machine was built around 1980 and was overhauled by us in 2009/2010 and has been in our care since then. The scope of the overhaul includes the following: - Electrical system almost completely renewed - New control cabinet incl. Siemens S7-200 PLC control system - New drive technology Siemens Simodrive 611, feed motors Siemens 1FK7 - Heidenhain TNC 124 line control + electronic handwheel - Heidenhain length measuring systems on X, Y and Z axes - Heidenhein angle measuring device in B-axis (rotary table) - Spindle drive three-phase asynchronous with DC brake electronics - Renewal / overhaul of all hydraulic components - New KGT in X and Y axes - Overhaul of the drive systems of all feed axes - All axles were rescraped - Lubrication systems of axes and headstock overhauled - New bearings and overhaul of the gear components of the headstock For further technical details see photos or on request. Equipment of the machine: - Heidenhain TNC 124 line control + electronic handwheel - Facing slide (U-axis) - Electric tool clamp SK 50 The sale is due to capacity reasons. Redpfxeu U Hvwe Ab Rjch The machine is fully functional and immediately available. It achieves production accuracies according to the manufacturer's protocol. Technical documentation is available. The machine is fully functional and, by prior arrangement, can be inspected under power. The offer is subject to our terms and conditions of business and delivery. Subject to errors and prior sale. As a warranty is excluded for the purchase of used machines, we recommend that our our customers to inspect the machine before making a purchase. As is customary with used machines, payment is made by bank transfer before delivery of the goods. bank transfer. Dismantling, relocation, installation, commissioning and geometric adjustment at the new location, can be carried out by us on request. We will be happy to submit a separate offer for this. Delivery of the machine to other EU countries is also possible on request.

Year of construction: 1997, condition: ready for operation (used), functionality: fully functional, travel distance X-axis: 600 mm, travel distance Y-axis: 400 mm, travel distance Z-axis: 350 mm, controller manufacturer: Fanuc, spindle speed (max.): 20,000 rpm, machine/vehicle number: 97-VP461, TECHNICAL DETAILS Travel X-axis: 600 mm Travel Y-axis: 400 mm Travel Z-axis: 350 mm Spindle speed: 20,000 rpm Tool changer positions: 30 Rcjdpfx Abeyi U Iae Rsh MACHINE DETAILS Control manufacturer: Fanuc EQUIPMENT BT 40 Big Plus tool holder 4th axis table Oil mist minimum quantity lubrication system

Condition: refurbished (used), Year of construction: 2025, functionality: fully functional, machine/vehicle number: 7/61, Manufacturing origin Swiss Voltage 380/50/3 Netweight abt. 760 kg Dimensions abt. 1250x1000x1700 mm TECHNICAL DATA WORK CAPACITY Travel X and Y 200x200 mm Vertical slide travel 250 mm Travel of drilling spindle 70 mm Max free passage between table and spindle nose 330 mm Free passage between column and centre of spindle 260 mm Max drilling capacity (steel) 10 mm Max reaming capacity 50 mm TABLE Usable surface 400x300 mm Admitted load 100 kg Travels X and Y through motors Number of T-slots 6 (longitudinal) DRILLING HEAD Spindel morse taper 0 Speed of spindle 150-3000 rpm Feed of drilling spindle 0,015 mm/t PRECISION Direct reading on divided drums 0,01 mm Direct reading on verniers 0,001 mm Guaranteed precision on displacement of slide-way 0,002 mm MEASURE Measuring system direct, optical Elements of measure graduated rule, div.1mm Read-out projection screens Shifting of zero-point yes Direct read-out 0,001 mm Guaranteed positioning precision 0,002 mm Installed power 1,2 kW errors and omissions excepted data given without obligation Rcodpsd Amgkjfx Ab Roh Inventory Nr.2160006, machine equipped with : 1 turning table Ø 220 with optical measure 1 centering microscope with 3-points suspension, zoom 40x, lightening 1 centering device with dial comparator cap. 3 mm. MT0 1 centering point MT0 1 tracing tool with spring-mounted point MT0 1 center punch MT0 1 chuck for centering drills MT0 1 self clamping drill-chuck 0-5 mm., MT0 1 boring head type 0, cap. 0.5-30 mm., MT0 1 levelling foot with 2 round levelling supports

Condition: good (used), Year of construction: 2005, operating hours: 33,000 h, functionality: fully functional, travel distance X-axis: 800 mm, travel distance Y-axis: 800 mm, travel distance Z-axis: 800 mm, controller manufacturer: Okuma, controller model: OSP E100, table width: 500 mm, table length: 500 mm, rotational speed (min.): 10 rpm, rotational speed (max.): 15,000 rpm, spindle speed (max.): 15,000 rpm, coolant supply: 40 bar, spindle nose: BT40, number of spindles: 1, number of slots in tool magazine: 60, Equipment: chip conveyor, documentation/manual, Horizontal machining center Okuma MB 500H with a 2-position pallet changer Year of manufacture: 2005 Control system: Okuma OSP E100M Technical data: Spindle speed: 10 - 15,000 rpm Drive power: 26 kW Tool holder: BT 40 Number of magazine positions: 60 Internal coolant pressure: 70 bar Travel distances: Rcjdpfx Asz Tc Uyob Roh X-axis: 800 mm Y-axis: 800 mm Z-axis: 800 mm 4th axis: Index 1° Number of pallets: 2 Pallet size: 500x500 mm Accessories: - Coolant system, type ConSep 2000, by Mayfran - Chip conveyor, type ConSep, by Mayfran - Tool breakage monitoring in the magazine - Workpiece coolant shower

Condition: like new (used), Year of construction: 2018, machine/vehicle number: DC-2075, Work table 700 x 300 mm, Drilling width 240 mm, Drilling depth 150 mm, Max. travel 230 mm, Drill head height adjustment 160 mm, Rcodpfsvl Eynjx Ab Roh Drill head swivel 45°-0°-45°, Wescott drill chuck 0 - 20 mm, Speed 3,000 rpm, Motor 2.2 kW, 400 volts, 50 Hz, Weight approx. 345 kg, Ex works, from the Seevetal location, excluding transport, as inspected, subject to prior sale.

Condition: not inspected (used), Year of construction: 2013, Bore diameter , mm Number of heads horizontal , St. Number of heads vertical , St. Götzinger Drilling and Milling Centre ----- For sale on behalf of a client! Machine for ‘left-hand’ and ‘right-hand’ parts. The machine was controlled via window-making software, but can also be operated via the machine’s own software. The machine is equipped as follows: Rjdpfx Absv N N Spo Rsch - Drilling units on the left and right for end-face drilling. - 3 units for drilling and milling for longitudinal machining. - Parts are loaded once and the unit carrier then moves to perform the various machining operations. Machine installation length approx. 6 m. For further information, see the attached PDFs.

Condition: good (used), Year of construction: 2008, operating hours: 54,682 h, functionality: limited functionality, machine/vehicle number: 211934, travel distance X-axis: 730 mm, travel distance Y-axis: 730 mm, travel distance Z-axis: 740 mm, feed length X-axis: 730 mm, feed length Y-axis: 730 mm, feed length Z-axis: 740 mm, feed rate X-axis: 60 m/min, feed rate Y-axis: 60 m/min, feed rate Z-axis: 60 m/min, nominal power (apparent): 57 kVA, controller manufacturer: Mazatrol, controller model: Mazatrol Matrix Nexus, workpiece length (max.): 800 mm, workpiece width (max.): 800 mm, workpiece height (max.): 1,000 mm, workpiece diameter (max.): 800 mm, workpiece weight (max.): 700 kg, total height: 2,814 mm, total length: 4,690 mm, total width: 2,330 mm, table width: 500 mm, table height: 1,100 mm, table length: 500 mm, table load: 700 kg, rotary table diameter: 500 mm, rotational speed (min.): 35 rpm, rotational speed (max.): 18,000 rpm, overall weight: 11,000 kg, spindle speed (min.): 35 rpm, spindle speed (max.): 18,000 rpm, operating hours of spindle: 25,876 h, coolant supply: 8 bar, distance table to spindle center: 830 mm, distance table center to spindle nose: 810 mm, spindle motor power: 25,000 W, spindle mount: MK 1, spindle nose: ISO 40, number of spindles: 1, number of slots in tool magazine: 40, mount diameter: 100 mm, input voltage: 480 V, Equipment: chip conveyor, documentation/manual, We are selling a used Mazak HCN Nexus 5000 machining center, manufactured in 2008, with a dual-pallet changer. This is a well-maintained machine from its first owner, and it can be inspected while powered on. Photos and a technical description can be found in the attachment. Rcedpfx Ae Agnq Hob Rjh

Condition: used, Year of construction: 1995, Max. bending capacity: 300 kN (30t) Pressure adjustable from 0-300 kN Tool height: 300 mm Biegleistung:140 x 20 mm at V125; 200 x 18 (19) mm at V200 Automatic and manual mode possible Miscellaneous accessories and operating manual Rsdpfxo Aaz U Do Ab Rech Weight: approx. 700 kg

Condition: like new (used), Year of construction: 2017, operating hours: 10,000 h, functionality: fully functional, travel distance X-axis: 730 mm, travel distance Y-axis: 730 mm, travel distance Z-axis: 830 mm, rapid traverse X-axis: 60 m/min, rapid traverse Y-axis: 60 m/min, rapid traverse Z-axis: 60 m/min, Base Machine - SH-5000P - Demonstration Machine Like New • Basic machine, 4-axis • Control: Siemens 840D sl • Table size: 500x500mm • Max. table load: 500kg • X/Y/Z travels: 730/730/830mm • X/Y/Z rapid traverse: 60/60/60 m/min • Milling spindle: • HSK63 • 30/50kW • 18,000 rpm • Tool magazine with 40 stations • Automatic pallet changer • Automatic loading door • Hydraulic unit • Oil separator • Oil mist extraction • Air conditioning unit for electrical cabinet • External measuring systems, linear axes • Media feed under pallets • Central lubrication • Door interlock • Coolant unit Rodpfx Abs Af Ui Rj Roch • Internal cooling with 70 bar high pressure • Coolant and compressed air gun • Chip conveyor • Documentation in German, digital

Condition: used, Year of construction: 1990, functionality: fully functional, machine/vehicle number: 254002, type of input current: three-phase, overall weight: 130 kg, input voltage: 380 V, number of spindles: 8, input frequency: 50 Hz, Schleicher frame dowel hole drilling machine DBH 600, Drilling motor 1.5 kW, 380 Volt, 50 Hz, Drilling stroke 0 - 130 mm, Special drilling gear with 3 rows and 8 spindles, 1 clamping cylinder, Rcedpfx Asz Nkutob Rsh Special stop system for window frames and window mullions Weight approximately 130 kg as is, at the Seevetal location, excluding transport, EXW (Ex Works), subject to prior sale.

Condition: excellent (used), Year of construction: 2000, functionality: fully functional, travel distance X-axis: 1,000 mm, travel distance Y-axis: 800 mm, travel distance Z-axis: 810 mm, workpiece length (max.): 1,000 mm, workpiece width (max.): 900 mm, workpiece weight (max.): 1,200 kg, total height: 3,291 mm, total length: 5,412 mm, total width: 3,760 mm, table width: 630 mm, table length: 630 mm, overall weight: 24,000 kg, spindle speed (min.): 50 rpm, spindle speed (max.): 12,000 rpm, operating hours of spindle: 13,450 h, number of spindles: 1, number of slots in tool magazine: 60, input voltage: 380 V, type of input current: AC, Equipment: chip conveyor, documentation/manual, rotational speed infinitely variable, Okuma MA-60HA horizontal CNC machining centre, manufactured in 2000 and equipped with an Okuma OSP-U100M CNC control system. The machine is in very good condition and features a high-speed spindle with a maximum speed of 12,000 rpm and a BT40 tool interface. Redpj Ady Iwsfx Ab Rjch The machine is equipped with a two-pallet system with 630 × 630 mm pallets, a 60-position tool magazine, and a Mayfran ConSep 2000 chip conveyor. The sale also includes more than 80 tools and tool holders, providing a comprehensive tooling package for the new owner. With its high-speed spindle, dual-pallet configuration and extensive tooling package, this Okuma MA-60HA is an attractive opportunity for manufacturers looking for a horizontal machining centre. Technical Specifications Manufacturer: Okuma Model: MA-60HA Year of manufacture: 2000 Machine type: Horizontal CNC machining centre CNC control: Okuma OSP-U100M Condition: Very good Maximum spindle speed: 12,000 rpm Tool interface: BT40 X-axis travel: 1,000 mm Y-axis travel: 800 mm Z-axis travel: 810 mm 4th Axis / Rotary Table Rotary table positioning: 360,000 positions Indexing resolution: 0.001° Pallet system: 2 pallets Pallet dimensions: 630 × 630 mm Tool magazine capacity: 60 positions Manufacturer: Okuma Motor type: VAC-MOTOR Type designation: VAC-YMB15/11-6.5/120-A Peak output: 18/42 kW 30-minute rated output: 15/15 kW Continuous rated output: 11/11 kW Via nameplate. Included Equipment Okuma OSP-U100M CNC control system High-speed spindle, up to 12,000 rpm BT40 tool interface Two pallets, 630 × 630 mm 60-position tool magazine More than 80 tools and tool holders Mayfran ConSep 2000 chip conveyor Operating Hours Power-on time: 32,500 hours Control power-on time: 15,340 hours Spindle rotation time: 13,450 hours Cutting time: 11,220 hours Inspection can be arranged by appointment.

Condition: used, Year of construction: 1996, travel distance X-axis: 1,500 mm, travel distance Y-axis: 1,200 mm, travel distance Z-axis: 1,250 mm, controller model: Siemens 840 C, spindle speed (max.): 4,000 rpm, TECHNICAL DETAILS X-axis travel: 1,500 mm Y-axis travel: 1,200 mm Z-axis travel: 1,250 mm Spindle speed: 10–4,000 rpm Spindle power: 40 kW Spindle interface: HSK-A100 Pallet size: 1,000 × 1,000 mm Rotary table speed: 1–500 rpm Pallet load: max. 2,000 kg Magazine type: Chain magazine Rjdpfx Abe Agftms Rech Number of tool positions: 161 MACHINE DETAILS CNC control: Siemens 840 C Overall dimensions: 8,500 × 4,800 × 4,800 mm EQUIPMENT Chip conveyor Paper filter Rotary table Automatic horizontal and vertical spindle

Condition: used, Year of construction: 1975, Number of spindles: 20 Rodpfjy E Hfksx Ab Rjch Drill spacing: 32 mm Power consumption: 1.8 kW
