Used Jig Boring Machine for sale (65,004)

Year of construction: 1985, condition: used, spindle diameter 110 mm x-travel 900 mm y-travel 600 mm z-axis 200 mm table length 1020 mm table width 860 mm taper MK 40 Table size, approx. 1,020 x 860 mm Max. weight of workpiece 800 kg Rsdot Hwyxopfx Ac Tjcd Table travel, longitudinal, max. (X) 900 mm Boring head travel, cross, max. (Y) 600 mm Boring spindle stroke (Z) 200 mm Vertical travel of cross beam (W) 635 mm Vertical distance between table and boring spindle 15 - 850 mm Distance between columns 950 mm Spindle Ø 110 mm Spindle taper internal/external ISO 40 18 spindle speeds 10 - 2,500 rpm Milling feeds of table, infinitely variable 1 - 6,000 mm/min 4 milling feeds of boring head 30 - 180 mm/min 6 boring feeds 0.01 - 0.39 rpm Accuracy of all 3 axes when the machine was new 0.003 mm Quick feeds for table, boring head slide, and boring spindle, max. 6,000 mm/min Spindle drive 6.2 kW Weight, approx. 9,000 kg Total electrical load 15 kW - 380 V - 50 Hz Accessories / Special Features - BOSCH CNC Control, Model MICRO 8, in 3 axes, with monitor. Program input is either manual or via cassette, or via interface entry. - Digital display for Z Axis. - Separate switch cabinet. - Various tools. - Oil cooler for spindle lubrication.

Condition: excellent (used), Year of construction: 1986, functionality: fully functional, Technical details spindle diameter 135 mm x-travel 1000 mm y-travel 700 mm z-travel 300 mm cross rail adjustment - vertical 780 mm distance between table/spindle 1000 mm table surface area 1100 x 842 mm distance between columns 1100 mm table load 1500 kg Rcodezil U Aspfx Ac Tjd tool taper SK 45 spindle turning speed range 2400 U/min spindle drive 5,9 kW feed range 1 - 6000 mm/min weight of the machine ca. 10,6 t Additional information Retrofit / overhauling in May 2005 (with geometric measurement): - New Heidenhain iTNC-530 control - New electronics - New Siemens servomotors - Heidenhain glass scales - Revision of drilling spindle unit (total costs 118,436.00 EUR) Equipment: Infrared measuring probe m&h 38.10-MINI Electron. Handwheel Various tool holders Transport dimensions: - Machine (LxWxH) 3500 x 2600 x 2750 mm - Control cabinet (LxWxH) 2300 x 600 x 2300 mm - Hydraulic (LxWxH) 800 x 600 x 1000 mm

Condition: excellent (used), functionality: fully functional, travel distance X-axis: 400 mm, travel distance Y-axis: 250 mm, travel distance Z-axis: 450 mm, spindle speed (max.): 3,000 rpm, spindle speed (min.): 60 rpm, table length: 550 mm, table width: 320 mm, table load: 400 kg, spindle mount: MK 2, total height: 1,750 mm, drill spindle length: 130 mm, total length: 1,400 mm, total width: 1,400 mm, rotational speed (min.): 60 rpm, rotational speed (max.): 3,000 rpm, distance between stands: 600 mm, quill travel distance: 130 mm, quill stroke: 130 mm, space requirement width: 2,100 mm, spindle motor power: 550 W, workpiece weight (max.): 400 kg, overall weight: 1,600 kg, number of previous owners: 2, Equipment: rotational speed infinitely variable, Please, no inquiries from India, thank you! The machine is reserved until August 3, 2026. HENRI HAUSER OP3 – Unique piece / excellent condition! (Bienne/Biel, Switzerland) This quality will never be produced like this again! Redpfxsy Sx Nhs Ac Tecd Coordinate drilling machine / jig boring machine with tool set (see photos) in excellent, exceptional condition, second owner (owned for 41 years). The coordinate drilling machine features the rare option of motorized table drive in the X and Y axes and potentiometers. This eliminates the tedious manual adjustment of the individual coordinates over long distances with hand cranks. Furthermore, it has the rare thermal stabilization and expansion compensation. For this purpose, 2 heaters are provided, which can and must be switched on separately before starting work and to maintain high accuracy and dimensions. This explains the factory-high positioning accuracy of 0.002 mm with a resolution of 0.001 mm. What is particularly unique is that the Hauser has two Heidenhain digital displays with a total of 4 glass scales with 1My resolution, also for the quill feed. This is a great advantage for precise drilling and milling in depth with Wohlhaupter, spindle tools, etc. With the mentioned options and in this first-class condition, it is very rare and most likely no longer available. Those familiar with these machines, which are primarily used in the watch industry, gunsmithing / defense industry, precision engineering, material testing and the optical industry, know the value of these masterpieces of mechanical engineering. Also ideally suited for engine construction / overhaul, technical universities and training, materials technology, special machine construction, etc. All documents, manuals, electrical diagrams, etc. are, of course, available in the original! Technical data: Table length 550 mm, table width = 320 mm, longitudinal travel X-axis = 400 mm, transverse travel Y-axis = 250 mm, vertical travel Z-axis = 400 mm Max. workpiece weight on the table = 400 kg, spindle mount MK 2, stroke of the drilling spindle (Z-axis) = 130 mm Distance table to spindle = 590 mm, spindle speeds continuously variable from 60 rpm to 3000 rpm Feeds: Drilling spindle slide: 2 steps from 0.03 mm/rev to 0.06 mm/rev Connection 50 Hz 3x 380 Volt, spindle motor 0.80 PS Machine dimensions: Length = 1200 mm, width = 1150 mm, height = 1650 mm Machine weight approx. 1500 kg. Shipping (direct transport without transshipment) within the EU is possible. Price net for export within the EU!

Condition: used, Quill for jig boring mill, fine boring mill, plate boring mill, table boring mill, boring mill, milling machine, Redofc R D Ispfx Ac Tscd -Stroke: 60 mm -in: a wooden box -Dimensions: 390/340/H170 mm -Weight: 15.8 kg

Condition: good (used), Jig boring mill, fine boring mill, plate boring mill, table boring mill, boring mill, milling machine, -Table dimensions: 700 x 405 mm -Travel paths: Z 330 mm/Y 410 mm/X 630 mm -Quick stroke: 155 mm -Recording: MK4 -Speeds: 31 - 1500 rpm Rcedpfxjd Tk Sts Ac Tjd -Dimensions: 1570/1800/H2600 mm -Weight: 2600 kg

Condition: good (used), Jig boring/Milling machine HAUSER 3DR Redpfxszmx N Uo Ac Tocd Travel X: 400 mm Travel Y: 200 mm Travel Z: 400 mm Spindle: 2 speeds Cone:CM2 Spindle exit: 120 mm 2 speed ranges 60-1500 RPM / 1500-3000 RPM Table size: L 590 mm x W 320 mm Speed variator at the spindle 2 advances Auto descent: 0,03 mm/min - 0,06 mm/min X-axis functional with Mitutoyo devise Y and Z axis: defective scale Voltage: 380 V Width: 1500 mm Depth: 1700 mm Height in low position: 1800 mm Weight: approx 1,5 T

Condition: used, Jig Boring Machine WMW BKoE 450 x 800 Travel X: 560 mm Travel Y: 400 mm Travel Z: 470 mm Spindle: Ø 90 mm Cone: CM4 Spindle exit: 150 mm Spindle speed: from 50 to 1600 RPM Table size: 450 x 800 mm Redpozmxzdofx Ac Tjcd Maxi loading capacity on table: 400 kg Scale3 axes HEIDENHAIN Automatic descent Voltage: 380 V Width with ends table: 2900 mm / without ends table: 1500 mm Depth: 2500 mm Total height: 2600 mm Weight: 4,5 T

Condition: like new (used), CNC vertical jig boring machine WMW MIKROMAT Travel X: 1120 mm Rcodpfx Aozmxy Toc Tjd Travel Y: 710 mm Spindle travel Z: 315 mm Travel W: 630 mm Numerical Command: CNC NUM 1060 Spindle: Ø 125 mm Cone: SA40 Rotation: from 36 to 2240 RPM Table size: 1400 x 900 mm Distance between colums: 1080 mm Maxi distance spindle nose/table: from 0 to 900 mm max Maxi eligible load on table: 1000 kg max Separate electrical panel Machine renewed in 2000 with CN NUM1060 Voltage: 380 V Dimensions (L x W x H): 4000 x 2460 x 3030 mm Weight: approx. 9 T

Condition: used, Drilling / Jig Boring Machine CONSTANT SUPEMEC type P65 Travel X: 500 mm Travel Y: 300 mm Travel Z: 550 mm Cone: SA40 Spindle speed: from 77 to 1520 RPM Table size: Length 1200 mm x Width 420 mm Maxi distance spindle nose/table: 670 mm Mini distance spindle nose/table: 120 mm Throat depth: 300 mm Variable speed drive for X - Y Voltage: 380 V Rsdpfx Aezmxy Hoc Tscd Width: 1600 mm Depth: 1800 mm Height: 2400 mm Total width with control panel: 2700 mm Weight: 3 T

Condition: excellent (used), functionality: fully functional, travel distance X-axis: 1,000 mm, travel distance Y-axis: 700 mm, spindle speed (max.): 2,000 rpm, table length: 1,100 mm, table width: 842 mm, X axis: mm 1.000 Y axis: mm 700 Spindle travel: mm 300 Table dimensions: mm 1.100 x 842 Spindle speed: rpm 40 – 2.000 Rsdpfx Aezizgboc Tjcd Spindle cone: MT 4 Max power: kW 10 Max loading on table: ton 1 Machine weight: ton 15 EQUIPPED WITH A LOT OF ACCESSORIES

Condition: used, TECHNICAL DETAILS CAPABILITIES - Movement on X-Y : 400 x 250 [mm] - Vertical slide stroke : 400 [mm] - Drilling spindle stroke : 130 [mm] - Clearance between spindle nose and table : 570 [mm] - Clearance between mount and spindle center : 320 [mm] TABLE - Useful surface : 595 x 320 [mm] - Movement X-X : automatic with ball screws - Drilling head - Internal taper : Morse 2 - Spindle speed : 60-3000 [rpm] - Spindle feed : 0.03-0.06 [mm/r] - Voltage : 3 x 380 V / 50 Hz - Installed power : 2.1 kW - Machine net weight : 1100 [kg] - Dimensions : 2050 x 1600 x 1900 [mm] Rcedpfx Acouhbpre Tsd EQUIPMENT - Digital display : X-Y - Circular table : Ø 300 - Machine lamp

Condition: used, Technical details: z-travel: 400 mm range of revolution per miute: max. 3.000 / steples U/min feed continuous: keine Angaben quill stroke vertical: 100 mm spindle taper: MK2 Rcjdpfx Acev A S Efj Tod table surface area: 445 x 315 mm distance table - lower edge spindle: max. 520 mm table travel: längs: 250 mm table travel: quer: 330 mm table height over floor: 920 mm total power requirement: 1,6 kW weight of the machine ca.: 1500 kg machine dimensions LxWxH: 1,3 x 1,1 x 2,0 m Application: Milling and drilling slotted holes There is a precision dial gauge for depth display on the drill spindle head. 5x T-slots to DIN 650: a=10; h=18; b=18; c=8mm Features: Two-way digital ACU-RIDE display *

Condition: used, machine/vehicle number: 52 / 519, spindle diameter:90 mm x-travel:700 mm distance between columns:900 mm size of table:770 x 900 mm x-Travel:700 mm Rodpfxeh Ra Sto Ac Tecd y-travel:500 mm z-travel:1100 mm feed range - table:15 - 280 mm/min rapid traverse Z-axis:530 m/min spindle bore diameter / taper:MT4 (Morse) mm spindle bore diameter:max. 230 mm spindle stroke - max.:170 mm spindle speeds low range:10 U/min spindle speed high range:2000 U/min vertical feeds of spindle head::0.02 - 0,2 mm/r feed steps:6 Main spindle capacity:3 kW total power requirement:4,2 kW weight of the machine ca.:4 t dimensions of the machine ca.:1,9 x 2,2 x 2,4 m Hauser (SIP) High Precision Co-ordinated Jig Boring Machine, Model - M5 Douple Column Design Boring machine Large table (900 x 770 mm) for bulky Objects. All Axis are equipped with Fine Dial for High Presion Boring. A Complete Accesseries and tools are Avilable with the machine ( Drill Bits, Drill Chucks, Multiple Boring heads, Boring Inserts and Bits, Small and large rotary index table for small and big loads).

Year of construction: 2012, condition: excellent (used), YASDA YBM Vi40 CNC jig boring machine / machining center machine in perfect condition incl. accessories (see photos) For the complete photo gallery: See attached PDF file (from page 4) TECHNICAL DATA Travels X-axis: 900 mm Rcedopqx H Topfx Ac Tjd Y axis: 500 mm Z axis: 450 mm Distance from the table surface to the spindle tip: 100 to 550 °. Rotary table diameter: 400 mm Pallet loading capacity: 200 kg Table surface configuration: 44-M12 thread C axis: 360 ° Table tilt axis movement range (B axis): +- 110 ° Distance between center of tilt axis and rotary table: 0 mm Rotary axis (C axis): 100 rpm Max. rotation of the inclination axis: 20 rpm Motor for rotary axis: 4,2 kW Motor for inclination axis: 4,5 kW Spindle type: SA40-24`000-18,5 Spindle speed range: 100 - 24`000 rpm Spindle speed range programming: Programming by direct input of a 5-digit S-command Number of spindle speed ranges: 1 Type of spindle conical bore: HSK-63A Inner diameter of spindle bearing: 65 mm diameter Rapid traverse Speed: X,Y,Z axis: 20`000 rpm Feed rate: X,Y,Z axis: Max. 5000 rpm C-axis: 100 rpm B axis: 20 rpm Smallest input increment: 0.0001 mm/deg Automatic tool changer: 60 tools Selection method: Any selection Tool shank type: HSK-63 A Max. tool diameter Tool diameter: 100 mm Max. tool diameter Tool diameter at full setting: 70 mm Max. Tool length: 250 mm Max. Tool weight: 7 kg Tool balance weight: within G2.5 Machine dimensions: 3220 x 3885 x 3515 mm Machine weight: 15`000 kg No responsibility is taken for the accuracy, completeness and timeliness of the information.

Condition: used, Year of construction: 1980, spindle diameter 135 mm x-travel 950 mm distance between columns 1100 mm y-travel 700 mm cross rail adjustment - vertical 780 mm quill travel 300 mm max. distance between table and spindle-nose 1000 mm table surface area 1100x842 mm table load 1500 kg speeds 40-2000 U/min adjustment speed 5-1500 mm/min electrics - voltage/frequency 380/50 V/Hz total power requirement 8 kW weight of the machine ca. 9,5 t dimensions of the machine ca. 3,3x2,34x2,8 m total power requirement 8 kW weight of the machine ca. 9,5 t Rjdpfx Acey Ehwhe Tjcd dimensions of the machine ca. 3,3x2,34x2,8 m

Condition: ready for operation (used), Year of construction: 1994, functionality: fully functional, A used CNC jig boring machine SIP 640 FANUC control Rcjdey R Nnljpfx Ac Tsd Includes 80 tool holders Disassembly and loading are the responsibility of the buyer.

Condition: used, Year of construction: 1986, spindle diameter 1 mm x-travel 1 mm Rjdsylzv Aepfx Ac Tscd y-travel 1 mm total power requirement 1 kW

Condition: refurbished (used), Year of construction: 2025, functionality: fully functional, machine/vehicle number: 7/61, Manufacturing origin Swiss Voltage 380/50/3 Netweight abt. 760 kg Dimensions abt. 1250x1000x1700 mm TECHNICAL DATA WORK CAPACITY Travel X and Y 200x200 mm Vertical slide travel 250 mm Travel of drilling spindle 70 mm Max free passage between table and spindle nose 330 mm Free passage between column and centre of spindle 260 mm Max drilling capacity (steel) 10 mm Max reaming capacity 50 mm TABLE Usable surface 400x300 mm Admitted load 100 kg Travels X and Y through motors Number of T-slots 6 (longitudinal) Rjdped Amgkjfx Ac Tocd DRILLING HEAD Spindel morse taper 0 Speed of spindle 150-3000 rpm Feed of drilling spindle 0,015 mm/t PRECISION Direct reading on divided drums 0,01 mm Direct reading on verniers 0,001 mm Guaranteed precision on displacement of slide-way 0,002 mm MEASURE Measuring system direct, optical Elements of measure graduated rule, div.1mm Read-out projection screens Shifting of zero-point yes Direct read-out 0,001 mm Guaranteed positioning precision 0,002 mm Installed power 1,2 kW errors and omissions excepted data given without obligation Inventory Nr.2160006, machine equipped with : 1 turning table Ø 220 with optical measure 1 centering microscope with 3-points suspension, zoom 40x, lightening 1 centering device with dial comparator cap. 3 mm. MT0 1 centering point MT0 1 tracing tool with spring-mounted point MT0 1 center punch MT0 1 chuck for centering drills MT0 1 self clamping drill-chuck 0-5 mm., MT0 1 boring head type 0, cap. 0.5-30 mm., MT0 1 levelling foot with 2 round levelling supports

Condition: used, Year of construction: 1956, spindle diameter 120 mm x-travel 1200 mm y-travel 600 mm z-travel 600 mm turning speeds 19-1900 U/min table-size 600x1200 mm table load 2000 kg spindle taper ISO 50 Feed 0,042-1,46 mm/U weight of the machine ca. . t dimensions of the machine ca. . m The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale; Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. Redsyqu R Repfx Ac Tscd We look forward to your visit. Your Markus Hirsch Team

Condition: used, functionality: fully functional, travel distance X-axis: 1,000 mm, travel distance Y-axis: 700 mm, SIP 600 – Precision Coordinate Boring Machine Accuracy Positioning accuracy on X and Y axes over the entire travel: 0.003 mm Capacity Table travel (X axis): 1000 mm Slide travel (Y axis): 700 mm Vertical quill travel: 300 mm Vertical crossrail travel: 780 mm Distance between uprights: approx. 1100 mm Max. distance spindle nose to table: 1000 mm Table Usable table surface: 1100 × 842 mm Maximum load capacity: 1500 kg Feed rates: 1 – 1000 mm/min Rapid traverse: 5000 mm/min Slide (Carriage) Feed rates: 1 – 1000 mm/min Rapid traverse: 5000 mm/min Spindle and Hydrostatic Quill Rodpsyt Rrpefx Ac Tjcd Spindle speed: 40 – 2000 rpm (18 speeds) Automatic boring feeds: 0.04 – 0.35 mm/rev Tool taper: Morse 4 – SIP 4e Spindle motor power: 5.9 kW (8 HP) Hydrostatic quill diameter: 135 mm Functions: Automatic tool clamping Automatic depth stop Spindle rotation direction reversal Speed preselection Machining Assist Unit X and Y axis display: 0.001 mm Z axis display: 0.01 mm Memory capacity: 999 sequences Automatic movements: X and Y / Simultaneous XY Programmable increments: 0.002 / 0.009 / 0.1 / 1 mm Power Supply Electrical supply: 50 Hz – 380 V 60 Hz – 440 V Compressed air: 6 – 10 bar (11 l/min) Machine Dimensions Machine footprint: 2870 × 3480 mm Footprint with cabinet: 3870 × 4000 mm Total height: 3235 mm Weight Net machine weight: 10,000 kg Machine weight with cabinet and accessories: 11,000 kg

Year of construction: 1997, condition: ready for operation (used), functionality: fully functional, travel distance X-axis: 600 mm, travel distance Y-axis: 400 mm, travel distance Z-axis: 350 mm, controller manufacturer: Fanuc, spindle speed (max.): 20,000 rpm, machine/vehicle number: 97-VP461, TECHNICAL DETAILS Travel X-axis: 600 mm Travel Y-axis: 400 mm Travel Z-axis: 350 mm Redpfx Aeyi U Iajc Tocd Spindle speed: 20,000 rpm Tool changer positions: 30 MACHINE DETAILS Control manufacturer: Fanuc EQUIPMENT BT 40 Big Plus tool holder 4th axis table Oil mist minimum quantity lubrication system

Condition: ready for operation (used), Year of construction: 2003, functionality: fully functional, machine/vehicle number: M01.16.21.51.02, travel distance X-axis: 1,600 mm, travel distance Y-axis: 1,200 mm, travel distance Z-axis: 500 mm, spindle speed (max.): 10,000 rpm, No minimum price – guaranteed sale to the highest bidder! TECHNICAL DETAILS Travel range X-axis: 1,600 mm Travel range Y-axis: 1,200 mm Travel range Z-axis: 500 mm Travel range W-axis: 1,200 mm Travel range B-axis: 360° Spindle speed: 10,000 rpm Spindle motor power: 30 kW Feed drive: Brushless AC servo motors Feed rate: 0–20,000 mm/min Rapid traverse X-axis: 20,000 mm/min Rapid traverse Y and Z axes: 20,000 mm/min Manual mode: 20,000 mm/min Rcodeznkpvepfx Ac Tod Setup operation: 0–2,000 mm/min Table size: 1,500 × 1,500 mm T-slots: 5 × DIN 650-22 H12 T-slot spacing: 150 mm MACHINE DETAILS Tool clamping: Hydraulic Electrical connection: 400 V Frequency: 50 Hz Compressed air operating pressure: 6 bar Nominal flow rate: 7,000 rpm

Condition: good (used), Year of construction: 1996, Siemens 840-D SL, approximately 2012 Rjdpfx Aozq Ektjc Tscd Table: 2200 x 2250 mm Distance between columns: 3000 mm Max. workpiece height: 1200 mm Max. drilling depth: 600 mm Max. deep-hole drilling diameter: 35 mm Spindle speed: 3500 RPM Spindle power: 15 kW

Condition: excellent (used), Gannomat slot mortising machine / dowel drilling machine with Leroy-Somer motor - Motor type: LS80L2 - Power: 1.1 kW - Speed: 2810 rpm - Voltage: 220/380 V - Frequency: 50 Hz - Protection class: IP54 Rsdpfjy Saw Hjx Ac Tjcd 3-phase drive - Stable work table - Precision guide rails - Adjustable stops - Robust metal construction - Ideal for series production and precise wood joints – with drill and cup cutter - Air pressure must be shut off manually

Condition: like new (used), Year of construction: 2001, Retrofitted: 2026 Numerical control: HEIDENHAIN TNC-426 Rcodeugbrqspfx Ac Tod Technical features Dimensions Table dimensions: 6000 x 1000 mmNumber of T slots: 7T slots dimensions: 22 mm Traverses of axis Longitudinal traverse X: 5300 mmVertical traverse Y: 1050 mmTransversal traverse Z: 1500 mmVertical capacity (VC): 80 - 1130 Milling head Head type: Fixed frontalTool clamping system: HydraulicTaper nose: ISO 50 (DIN 69871)   /   Pull stud: DIN 69872-BSpeed range: 60 - 3000 rpmSpindle power: 22/30 kW Feedrates Feedrate: 5000 mm/minRapid feedrate (X,Y,Z): 10000 mm/min Weight and dimensions Maximum weight on table: UndeterminedMachine weight approximate: 43000 kgMachine dimensions approximate: 11560 x 6150 x 3538 mm Accessories Guarding: 2 front sliding doorsAutomatic tool changer: ATC40Chip conveyor: 2 longitudinals hinge typeElectronic handwheel: HR-410Coolant: External Sale conditions Warranty: 6 months mechanical partsPrice and sale conditions: On request View all technical features
