Used Index C 200 for sale (144)

Condition: ready for operation (used), Year of construction: 2000, spindle motor power: 22,000 W, total height: 2,050 mm, overall weight: 4,000 kg, controller manufacturer: INDEX, controller model: C200-4 / C200-8, This 5-axis Index G200 C turn-mill centre was manufactured in 2000. Consider the opportunity to buy this Index G200 C turn-mill centre. Contact us for more information. Additional equipment • Synchronous device for counter spindle machining • Tool carrier 3 for synchronous spindle (rear end machining) • Additional milling spindle • Thread milling and polygon turning device • Gripperless tool changer (6 tools, HKS-50 B, KM40) • Workpiece handling WHU100 • with c-axis • no driven tools Machine Benefits Technical Machine Benefits • Space requirement (without material guide): 3580 x 3108 mm • Control unit: resolution: 0. 001 mm (input/output/correction) • Comprehensive movement range with multiple axes configuration • High precision with 0. 001 mm resolution in numerical control Iodpfjyailzex Abvsth • Versatile expansion stages and additional equipment for enhanced functionality Extra Information Movement Cross slide 1 (top) - XYZB axes: X-axis: Slide path 155 mm, feed force 5000 N, rapid traverse 20 m/min, resolution 0.0005 mm Y-axis: Slide travel 120 mm, feed force 10000 N, rapid traverse 7.5 m/min, resolution 0.0005 mm Z-axis: Slide path 590 mm, feed force 5000 N, rapid traverse 30 m/min, resolution 0.001 mm B-axis (rotating): 360° swivel range, angular steps 5° (with locking), resolution 0.001° (with clamping), switching time for 180°: 1 s Cross slide 2 (bottom) - XZ axes: X-axis: Slide travel 105 mm, feed force 5000 N, rapid traverse 20 m/min, resolution 0.0005 mm Z-axis: Slide path 307 mm, feed force 5000 N, rapid traverse 30 m/min, resolution 0.001 mm Turret Turret right: X-axis: Slide path 120 mm Z-axis: Slide travel 400 mm Tail Stock Center distance: 400 mm Pressure force (max): 5500 N Drive: Hydraulic or electric Media Power supply: 400 V, 50/60 Hz Connected load: 20-45 kVA Current consumption: 35-80 A Hydraulic system: Delivery rate: 18 l/min System pressure: 90 bar Filling capacity: 70 liters Cooling lubricant system: Pump capacity (switchable): 20 l/min at 18 bar / 50 l/min at 3 bar / 60 l/min at 5-7 bar Filling quantity: Approx. 230 liters Chip conveyor: Hinged belt or scraper Workpiece holder: Main spindle: DB5 internal mount / D140 external mount, optional short taper Counter spindle: D140 external mount (only tensile clamping permitted for collet and chuck clamping) 1st spindle data (main/counter spindle): Spindle clearance (collet clamping): Variants: 30 mm / 42 mm / 60 mm / 65 mm Spindle Ø in front bearing: 75 mm (with 30 mm clearance) / 85 mm (42 mm) / 100 mm (60+65 mm) Speed (max): 7500 rpm (30 mm) / 6300 rpm (42 mm) / 5000 rpm (60 mm) Spindle nose: ISO 702/1 (size 4 or 5) Chip diameter (workpiece Ø): 110-130 mm (30 mm) / 140-160 mm (42 mm) / 165 mm (60 mm) Torque (Md max 100%): 33-62 Nm (30 mm) / 35-95 Nm (42 mm) Power (P max 100%): 7-13 kW (30 mm) / 7.5-20 kW (42 mm) Dimensions Machine Depth 3580 mm

Year of construction: 1997, condition: ready for operation (used), Turning diameter: 200mm, turning length: 400mm, turning diameter: 420mm, bar diameter: 60mm, max. spindle chuck diameter: 160mm, speed: 5000rpm, turret: 2, positions: 2x14, rapid traverse X/Z: 20m/min/30m/min. Machine dimensions X/Y/Z: approx. 7500mm/2100mm/2100mm, weight: approx. 4500kg. Documentation available. On-site inspection is possible. Iedpfxsu T Rgkj Abveth

Condition: used, Year of construction: 2017, INDEX C200 Mfd. 2017 Tooling in photos to be divided between 3 C200 machines available. Power-on hours: ~49,960 h Hydraulic hours: ~48,700 h Main spindle hours: ~24,800 h Counter spindle hours: ~24,000 h Stroke mm 20 Clamping pressure min.Max. bar 8/80 Piston Area pressure cm^2 57 Area piston thrust cm^2 57 pressure Force Max. CN 45,6 Tensile force Max. CN 45,6 10350989 1 INDEX C200 CNC-turning machine with 3 revolvers with Siemens-Based Index C200 control system SINUMERIK 840D SolutionLine - Rigid cast iron bed, perpendicular angle to the ground, excellent gradient chips - The kinematics of tool head movements guarantees maximum damping, reducing tool wear - Patented plate supports with excellent properties damping and stiffness The motion of the X-axis is derived through kinematics. "double scissors" guaranteeing high dynamics - Thermosymmetric spindle Control system Index C200 Identical to SIEMENS SINUMERIK 840d SolutionLine - Modular multiprocessor control system, SINAMICS with 120 drives - Siemens Operate control box, display in language Iedpfxjy Um Rrj Abvsth Germany - language switching WINDOWS and flat screen - 2x USB 2.0 connection on the control panel, 2x USB connection on the control panel - NCU 720.3 B PN NCK - Integrated PLC 317-3 PNDP and ET200S - Security features implemented in software through SIEMENS Safety-Integrated and ProfiSave Extended machining cycles consisting of: Einstechzyklus Freistechzyklus Gewindestrehlen with 4 point move Lighting work. space in LED design 1 flat color TFT screen, 18.5" PCT-Touch IP65 front panel 10142338 1 Main spindle dia 65 Spindle end AD140mm, ID 85mm Material passage Max. mm 65 Speed max. 1 / min 5000 Front bearing diameter mm 110 Power 100% / 40% kW 31,5/32 Torque Max. 100%/40% Nm 125/170 Continuously synchronous variable speed drives Main spindle with hollow clamping cylinder D65/20 for pincer clamping or Chuck clamping Hydraulic control with clamp metering C axis of main spindle Drive: hollow spindle motor clamping cylinder, metering system directly on the spindle Resolution 0.00014 degrees Positionsstreubreite (VDI/DGQ 3441) Psmax = 0.01 degree 11040430 pressure clamping device Clamping pressure 8-75 bar adjustable For anti-spindle clamping cylinder 10038475 1 tool carrier 1 X-axis work vehicle mm 110 X-axis quick shift m / min 30 X-axis acceleration m / s^2 9 X-axis shear force N 5000 Z-axis work vehicle mm 320 Z-axis quick feed m / min 50 Z-axis acceleration m / s^2 9 Z-axis shear force N 5000 Y-axis working vehicle mm 100 Y-axis quick feed m / min 15 Y-axis acceleration m / s^2 9 Y-axis shear force N 5000 Offer: 1702114 - 02 / 30.3.2017 CNC-lathe INDEX C200 (GP3790. 0000F) Revolver 1: 14 stations with cylindrical shank clamping D25x48 (DIN 69880), W-grooves on the revolver-higher repeated accuracy when replacing the tool. Centering plate set, V-strips, not content of delivery, must be ordered separately. Gearshift revolver AC motor, hydraulic locking A driven tool is possible in each station of the revolver 1 . Power 25% kW 10 Torque 25% Nm 16 Speed max. 1 / min 8000 10720950 1 tool carrier 2 X-axis working vehicle mm 110 X-axis quick shift m / min 30 X-axis acceleration m / s^2 9 X-axis shear force N 5000

Condition: excellent (used), Year of construction: 2009, operating hours: 28,742 h, functionality: fully functional, bar passage: 65 mm, FANUC Series 31i-Model A Iedoydmbuopfx Abveth 3 turrets Parts conveyor Magazine Further details on request

Condition: used, Year of construction: 2014, INDEX C200 CNC Lathe 3 Turrets 2 spindles Fanuc Control: 31i-Model B Ijdpfx Aoxxm Hfobvsth Axial Motorized Switches: 6 pcs Radial Motorized Switches: 13 pcs Tool Holders: 11 pcs Boring Bar Holders: 21 pcs Pin: 1 pcs Loader Bushings + Sleeves: Ø51/Ø46/Ø41 New MBL loader bushings: 2 sets 2 optical scales overhauled by HEIDENHAIN 1 Balluff Socket Gantry Arms Box with various sensors and proximity switches and cables Motorized Belts: 6 pcs Set of anti-vibration bushings for MBL loaders Start-up time: On time: 37946 Hydraulic hours: 37,500 Production time: 26,500 With MBL Bar Feed

Condition: excellent (used), Year of construction: 2009, operating hours: 29,000 h, functionality: fully functional, Equipment: documentation/manual, The INDEX C200 – manufactured in 2009 – is a powerful CNC production turning center with a FANUC 31i control, main and counter spindle, and a 65 mm bar capacity. The machine features a high-quality 3-turret design, with turrets 1 and 2 each equipped with X, Z, and Y axes, and turret 3 used for machining on the counter spindle. All three disc turrets are equipped with 10 stations and, with driven tools up to 6,000 rpm, enable highly flexible complete machining. With a portal parts handler, conveyor belt, C-axes on the main and counter spindles, and powerful spindle drives, the machine is particularly suitable for productive series production of complex turned/milled parts. Control: FANUC 31i Design: Machine with 3 tool holders / 3 disc turrets Bar capacity: 65 mm Machine bed: Vertically arranged gray cast iron machine bed Main spindle: Spindle 4 Counter spindle: Spindle 5 with Z-axis Spindles Main spindle Bar capacity: 65 mm Spindle diameter at front bearing: 110 mm Spindle nose: ISO 702/1, Size 140 Cyl. Chuck diameter: 160 mm Power: 25 kW at 100% ED / 33 kW at 40% ED Torque: 112 Nm at 100% ED / 150 Nm at 40% ED Speed: 5,000 rpm C-axis: Resolution 0.001° Counter spindle Bar capacity: 65 mm Spindle diameter at front bearing: 110 mm Spindle nose: ISO 702/1, Size 140 Cyl. Chuck diameter: 160 mm Power: 25 kW at 100% ED / 33 kW at 40% ED Torque: 112 Nm at 100% ED / 150 Nm at 40% ED Speed: 5,000 rpm C-axis: Resolution 0.001° Counter spindle Z-axis: 700 mm travel Rapid traverse Z-axis: 50 m/min Tool holder / Turret Design with 3 disc turrets, each with 10 stations. Tool system with 10 stations: Cylindrical shank DIN 69880 – Ø30 x 55 mm. Tool holder 1 X, Z, Y axes 10 stations X-axis: 110 mm Z-axis: 320 / 550 mm (according to documentation) Y-axis: 100 mm, ±50 mm Driven tools: 6.5 kW / 16 Nm / 6,000 rpm Tool holder 2 X, Z, Y axes 10 stations X-axis: 110 mm Z-axis: 550 mm Y-axis: 100 mm, ±50 mm Driven tools: 6.5 kW / 16 Nm / 6,000 rpm Tool holder 3 X-axis 10 stations Used exclusively for machining on the counter spindle X-axis: 180 mm Driven tools: 6.5 kW / 16 Nm / 6,000 rpm Further technical equipment according to documentation Portal parts handling system with numerically controlled Z-axis Workpiece removal from main or counter spindle to conveyor belt Removal of scrap material from the main spindle into a scrap container Portal parts handler: Traverse speed: 100 m/min Traverse range: 70 mm Workpiece diameter max.: 90 mm Ijdpfx Asy Tmhzobveth Workpiece length max.: 250 mm Scrap length max.: 250 mm Workpiece weight max.: 3.5 kg Hydraulic system: Flow rate: 19 l/min System pressure: 90 bar Hydraulic tank: 40 l Coolant circuit: Flow rate: 19 l/min Coolant unit power: 13 kW Coolant system: Pump output: 80 l/min / 8 bar Tank capacity: 300 l Chip conveyor: Chip discharge height: 1,250 mm

Condition: excellent (used), Year of construction: 2014, operating hours: 27,000 h, functionality: fully functional, Pump + Filter + Cooler No. 06 Axial Driven Tools No. 13 Radial Driven Tools Toolholder Boring Bar Holder Steady Rest: Magazine Bushings + Sleeves: Ø51/ Ø46 / Ø41 No. 02 new sets of MBL magazine bushings No. 02 optical scales overhauled by HEIDENHAIN 1 Baluff socket Grippers for Gantry Various sensors, proximity, cables Belts for driven tools: 6 pcs Itjdpfx Ajy Rlbzjbveh Set of anti-vibration bushings for MBL magazines

Condition: used, Year of construction: 2011, turning diameter 160 mm turning length 550 mm Isdsyuzfpepfx Abveth control Siemens weight of the machine ca. 9000 kg

Year of construction: 2003, condition: ready for operation (used), Max. turning diameter: 200mm, max. turning length: 400mm, spindle speed: 6000rpm, bar capacity: 42mm, weight: approx. 4300kg. Isdpfxstdwwqo Abvoth

Condition: used, Year of construction: 2011, controller manufacturer: Siemens, controller model: C200-4D SL, _____ Description: Year of manuf. : 2011 Control : Siemens C200-4D SL In General: Year of construction:2011 Control system:Siemens 840 Dsl (C200-4D SL) Bar capacity:65 mm Milling spindles:18,000 rpm Main spindle: Technology:Motorised spindle Speed:5,000 rpm Max. power:35.5 kW Torque max.:170 Nm C-axis:0.001° Z-axis:390 mm Bar capacity:65 mm Clamping cylinder:Hollow clamping cylinder Chuck:3-jaw chuck Sub spindle: Technology:Motorised spindle Speed:5,000 rpm Max. power:35.5 kW Torque max.:170 Nm C-axis:0.001° X-axis:600 mm Z-axis:390 mm Bar capacity:65 mm Chuck:3-jaw chuck Tool carrier I: Technology:Milling spindle on cross slide Speed:18,000 rpm Tool holder:HSK 40 X-axis:350 mm Y-axis:160 mm (+/- 80 mm) B-axis:230° Tool carrier II: Technology:Milling spindle on cross slide Speed:18,000 rpm Itedpfx Abey Sq T Sovjh Tool holder:HSK 40 Y-axis:160 mm(+/- 80 mm) B-axis:230° Tool magazin: Technology:Chain magazine Number of stations:80 pieces Tool changer:Double gripper Tool length max.:180 mm Equipment: Chip disposal:Chip conveyor Coolant supply:IKZ system with filter Parts removal:Gantry-type pick-up

Condition: defective spare-parts repository (used), Year of construction: 2005, functionality: not functional, turning length: 600 mm, turning diameter: 140 mm, spindle speed (max.): 5,000 rpm, travel distance X-axis: 110 mm, travel distance Z-axis: 360 mm, controller model: Siemens 840 D PowerLine, Hydraulic unit, main and counter spindles defective TECHNICAL DETAILS Turning diameter: 140 mm Turning length: 600 mm Distance between spindles: 615 mm Travel X-axis: 110 mm Travel Z-axis: 360 mm Travel Y-axis: 70 mm B-axis: 2x +/-1° Rapid traverse (X / Y / Z-axis): 25 / 12 / 50 m/min Main spindle Max. speed: 5,000 rpm Drive power: 20 / 27 kW Max. torque: 105 / 145 Nm C-axis positioning: 0.001° Chuck diameter: 140 - 160 mm Spindle nose: ISO 702/1 A5 Max. bar diameter: 65 mm Spindle bearing diameter: 110 mm Counter spindle Max. speed: 5,000 rpm Drive power: 20 / 27 kW Itedpfeyxgc Nex Abveh Max. torque: 105 / 145 Nm C-axis positioning: 0.001° Chuck diameter: 140 - 160 mm Spindle nose: ISO 702/1 A5 Max. bar diameter: 65 mm Travel X-axis: 150 mm Travel Y-axis: 600 mm Spindle bearing diameter: 110 mm Turrets Number: 3 Tool holder: VDI 25 x 48 DIN 69880 Number of tool stations: 3 x 12 Number of live tool stations: 3 x 12 Max. speed of live tools: 6,000 rpm Drive power for live tools: 8 kW Max. torque: 16 Nm MACHINE DETAILS Total power requirement: 53 kVA Dimensions & Weight Space requirement: 8.0 x 3.5 x 2.5 m Machine weight: 6.5 t EQUIPMENT 2(3) Y-axes +/-35 mm 2 B-correction axes (+/-1°) Chip conveyor Parts catcher Tool breakage monitoring Bar feeder: IRCO Profimat 65.6

Condition: used, Year of construction: 2015, Technical details: turning diameter: 65 mm turning length: 120 mm control: Index C200-4D SL z-axis main spindle travel: 390 mm z-axis subspindle travel: 390 mm x-axis subspindle travel: 600 mm Travel Y1: ± 80 mm Travel y2: ± 80 mm x-axis rapids: 45 m/min y-axis rapids: 15 m/min z-axis rapid travel: 45 m/min Spindle 1 RPM: 5000 1/min Itsdpfx Asyxpadsbvjh Spindle 1 Power: 35,5/27,5 kW Spindle 1 Torque: 170 /125 Nm Spindle 2 RPM: 5000 1/min Spindle 2 power: 35,5/27,5 kW Spindle 2 torque: 170/125 Nm c-axis: 0,00014 ° bar material dia.: 65 mm spindle nose: AD 140 spindle bore: 85 mm Milling spindle 1 RPM: 18000 1/min Milling spindle 1 power: 11 kW Milling Spindle1 torque: 19 Nm Milling spindle 2 RPM: 18000 1/min Milling Spindle 2 power: 11 kW Milling spindle 2 torque: 19 Nm B-axes swivel angle: 230 ° B-axes torque: 440 Nm B-axes angle resolution: 0,001 ° Milling spindle 1 & 2 tool magazine: 80 HSK A40 Milling spindle 2 tool magazine static tools : 6 x VDI 25 internal coolant system feed: Knoll 80 bar / Ecofluid weight of the machine ca.: 16,3 t dimensions of the machine ca.: 3,73x2,92x2,58 m Accerories Chip conveyor Spindle 1 Chuck SMW HFKN 165-46 mm Spindle 2 Chuck SMW HFKN 165-46 mm Collet chuck main spindle Hainbuch Spanntop Collet chuck subspindle Hainbuch Spanntop Barfeeder Interface Unimag Short bar loader IRCO ILS RBK 10016 Parts catcher for main- and sub-spindle Conveyor for partsdisposal Air Filter Büchel High performance heavy duty turning and milling center with 2 multi axis milling heads and two spindles. Both milling heads are full 5-axis. The z-axes are installed in the spindle heads The x2 axis is installed in the spindle head of the subspindle Milling1 head has x/y/b -axes Milling head 2 has y/b-axes Both milling heads have B-(Swivel-)axis 230° The machine is equipped with an IRCO short barfeeder and parts gripper for finished parts. Max. dim for finished parts: Ø 65 mm, length 120 mm, weight 5 kg. Rest piece length 200 mm All linear- axes are equipped with linear scales. Coolant through main and subspindle. Tool breakage control from drill Ø 1mm All existing tool from machine are part of delivery Machine is in excellenten Condition! *

Condition: good (used), Year of construction: 2006, Year of manufacture: 1998 to 2006 Itsdpfeypltgox Abveh Available from current location

Condition: used, Year of construction: 1998, turning diameter 200 mm turning length 400 mm control Siemens type C 200-4 840 C spindle passage 65 mm Tool changer 2 x14 Pos. live tooling 2x Revoler weight of the machine ca. 4 t Main and counter spindle 3-jaw chuck with numerous jaws Hainbuch collets Many tool holders Various driven tools Bar loader "Index MBL" Chip conveyor with coolant unit Complete set of spindle reducers etc. see photo The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale; Our terms and conditions of sale apply exclusively. Iedpfx Abeyqvygsvjth About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team

Condition: used, Year of construction: 1998, turning diameter 200 mm turning length 400 mm control SIEMENS SINUMERIC 840 C total power requirement 40 kW weight of the machine ca. 6.500 kg dimensions of the machine ca. m Itedpfot Hw Rkox Abvjh

Condition: ready for operation (used), Year of construction: 2005, functionality: fully functional, machine/vehicle number: 720052, turning length: 600 mm, turning diameter: 140 mm, bar passage: 65 mm, controller model: Siemens 840 D PowerLine, distance between spindles: 615 mm, TECHNICAL DETAILS Turning diameter: 140 mm Turning length: 600 mm Maximum bar diameter: 65 mm Distance between spindles: 615 mm Max. spindle speed: 5,000 rpm Main spindle drive power: 20/27 kW Spindle nose: ISO 702/1 140 mm Spindle bearing diameter: 110 mm Max. torque: 105/145 Nm C-axis: 0.001 Chuck diameter: 140 - 160 mm Tool turret: 3 Y-axes: 2 to 3 axes +/- 35 mm B-correction axes: 2 axes +/-1 Driven tool positions: 3 x 12 Tool holder: VDI 25 x 48 DIN 69880 Drive power for driven tools: 8 kW MACHINE DETAILS Control: Siemens 840 D PowerLine Dimensions & Weight Space requirements: approx. 8.0 x 3.5 x 2.5 m Machine weight: approx. 6,500 kg Electrical Data Rated voltage: 400 V AC Rated current: 101 A Rated power: 59 kW Number of phases: 3 Frequency: 50 Hz Control voltage: 24 V DC Total power requirement: 53 kVA EQUIPMENT Index MBL bar loader Iedpfxexg Im Aj Abvjth

Year of construction: 2003, condition: ready for operation (used), A fully autonomous CNC dual-spindle turning machine Index is available. Turning diameter: 220mm, main spindle bar capacity: 65mm, main spindle power chuck diameter: 210mm, sub-spindle bar capacity: 60mm, sub-spindle power chuck diameter: 210mm, tool stations: 12, Y-axis travel: 120mm, gripper diameter range: 4mm-45mm/40mm-65mm, coolant pump pressure: 8bar, high-pressure pump capacity: 80bar, chip conveyor discharge height: 1250mm. Overall system dimensions X/Y/Z: approx. 9150mm/4350mm/2000mm, weight: approx. 10500kg, operating hours: approx. 92000h. Including bar loader FMB turbo 8-80 XT/3200A, automatic loading and unloading system alphaMAX 6-axis, chip conveyor, coolant system, high-pressure pump and spare parts. Operation with the loading and unloading system is designed for disc diameters from 80mm to 220mm. This is a fully automated system without operator. Documentation available. On-site inspection is possible. Expected to be available from June 2026. Isdpfjyfv Nkex Abveth

Condition: used, TECHNICAL DETAILS - Number of axes : 10 - Number of spindles : 2 Itjdev Ig Avspfx Abvjh MAIN SPINDLE - Spindle power : 24 [kW] - Spindle speeds : 5000 [rpm] - Max. bar diameter : 65 [mm] - C axis indexing precision : 0.001 [°] COUNTER-SPINDLE - Spindle power : 24 [kW] - Spindle speeds : 5000 [rpm] - Max. bar diameter : 65 [mm] - C axis indexing precision : 0.001 [°] - Travel : 390 / 600 [mm] TURNING-MILLING SPINDLE - X stroke : 350 [mm] - Y stroke : ± 80 [mm] - B Axis stroke : 270 [°] - B axis indexing precision : 0.001 [°] - Tool type : HSK-T40 - Spindle speeds : 18000 [rpm] - Spindle power : 11 [kW] - Fixed tools on milling electrospindle : 6 x VDI25 LOWER TURNING-MILLING SPINDLE - Y stroke : ± 80 [mm] - B Axis stroke : 270 [°] - B axis indexing precision : 0.001 [°] - Tool type : HSK-T40 - Spindle speeds : 18000 [rpm] - Spindle power : 11 [kW] - Fixed tools on milling electrospindle : 6 x VDI25 TOOL CHANGER - Auto. Tool Changer type : Bras chargeur - Tool magazine capacity : 80 - Tool exchange time : 4.5 [sec] POWER SUPPLY - Supply voltage : 400 [V] - Total installed power : 68 [kW] WEIGHT & DIMENSIONS - Machine height : 2500 [mm] - Machine weight : 11000 [kg] MACHINE HOURS - Spindle hours : 19781 [h] - Number of turning-milling spindle hours : 9713 [h] EQUIPMENT - CNC : Siemens Sinumerik 840D SL - Coolant tank * with high-pressure pump * with paper filtering unit * Coolant through spindle - Chips conveyor - Spindle cooling unit - Parts catcher

Condition: used, Cnc multispindle lathe INDEX MS 32 C Itedsuhaqbspfx Abvsh

Condition: used, TECHNICAL DETAILS - number of spindles : 6 independent - bar clearance : 32 [mm] - maxi spindle speed : 6 300 [rpm] - machine equipped with 28 numerical axes - slide unity 1.1 : X and Z axes controlled by CNC - slide unity 2.2 : X and Z axes controlled by CNC - slide unity 3.1 : X and Z axes controlled by CNC - slide unity 3.2 : X and Z axes controlled by CNC - slide unity 4.1 : X and Z axes controlled by CNC - slide unity 4.2 : X and Z axes controlled by CNC - slide unity 5.1 : X and Z axes controlled by CNC - slide unity 5.2 : X and Z axes controlled by CNC - slide unity 6.1 : X and Z axes controlled by CNC - slide unity 6.2 : X and Z axes controlled by CNC - synchronous unit, spindle position 6.1 EQUIPMENT - INDEX C200-4 control (Siemens SINUMERIK 840D) - Simple NCU - IEMCA SIR MS32/33/P bar feeder - Coolant tank: KNOLL AE 1076 * with high-pressure pump - KNOLL VRF 500 chips conveyor - Parts catcher with conveyor in position 6 Iodpfeuhauyjx Abvjth

Condition: used, TECHNICAL DETAILS - Quantity of spindles : 6 - Bar clearance : 40 [mm] - Rotation speed : 7 000 [rpm] - Spindle power : 13 / 24 [kW] NUMERICAL AXES : 27 - Slides unit 1.1 : axes X and Z CNC-controlled - Slides unit 1.2 : axes X and Z CNC-controlled - Slides unit 2.1 : axes X and Z CNC-controlled - Slides unit 2.2 : axes X and Z CNC-controlled - Slides unit 3.1 : axes X and Z CNC-controlled - Slides unit 3.2 : axis Z CNC-controlled - Slides unit 4.1 : axes X and Z CNC-controlled - Slides unit 4.2 : axis Z CNC-controlled - Slides unit 5.1 : axes X and Z CNC-controlled - Slides unit 5.2 : axis Z CNC-controlled - Slides unit 6.1 : axis Z CNC-controlled + SCARA axis - Slides unit 6.2 : axes X and Z CNC-controlled - Slides unit 6.3 : axis X CNC-controlled Iodpeuhantsfx Abvoth ELECTRICAL INPUT - Voltage : 400 [V] - Frequency : 50 [Hz] - Installed power : 65 [kW] DIMENSIONS OF THE MACHINE - Floor space : 3329 x 2032 [mm] - Height : 2654 [mm] - Weight: 7100 [kg] HOURS - Hours under power : 45965 - Production hours : 19065 EQUIPMENT - CNC Siemens 840D (PL) double NCU - 2 control panels CN - 6 collet receivers TOPLUS with built-in stop - 1 counter-spindle in position 6.1 - Clamping device in counter-spindle : chuck Röhm KFD-HS 110/3 - Coolant through counter-spindle center - Cn options counter-spindle/ polygonal milling - Rear machining device on slide 6.2 : 3x fix - Preparation 2 additional controls with electronic shaft in position 1.2.3 - Preparation 2 additional controls with electronic shaft in position 4.5.6 - STAUBLI robot type TX60 (6 axes) - Robot collet double clamping external type PZN50 - Swiveling plate (4 positions) - Coolant tank KNOLL with hinged chip conveyor, 2 HP pumps 40 [bars] - Oil mist aspiration device Büschel - Cooling unit RIEDEL - Preparation ARTIS

Condition: good (used), Index HBFHydraulic pump and oil pump Rod loader Itsded Tx A Tjpfx Abvoh

Condition: good (used), Year of construction: 2006, INDEX MS52C CNC Multi-Spindle Mfd. 2006 Control: Siemens 840D 6 Spindles 52mm Capacity Equipped as pictured Under power Knoll System Chip Conveyor Riedel Chiller Itjdot Rkzwjpfx Abveh 3.6 meter (12ft) IEMCA SIR Bar Feed SIR MS52/F Type 38 XL Mfd. 2005

Condition: ready for operation (used), Year of construction: 2012, operating hours: 75,685 h, spindle speed (max.): 6,000 rpm, travel distance X-axis: 85 mm, travel distance Z-axis: 280 mm, spindle motor power: 20,000 W, number of axes: 7, This 7-axis Index ABC horizontal turning machine was manufactured in 2012. It features a main spindle with a maximum speed of 6000 rpm and a sub spindle with a speed of 4500 rpm. The machine includes two turrets, each equipped with X and Z axes, and a powerful tool drive. If you are looking to get high-quality turning capabilities, consider the Index ABC machine we have for sale. Contact us for further details. • Main spindle: D65, spindle interface AD140, ID83, max speed 6000 rpm; max power 20 kW at 100% duty cycle; C-axis; electronic synchronization between spindles • Sub spindle: 7.5" chuck interface, max speed 4500 rpm • Spindle hours: • S1 – 18914h • S2 – 661h • S3 – 3h • S4 – 29211h • S5 – 2413h • S7 – 1250h • Chuck: 3-jaw KFN95/3, clamping force 480 daN, max 4000 rpm • Turrets: two turrets each with X and Z axis; tool drive on turret 6000 rpm, 3.3 kW • Rear working attachment: without quill, 5 quill positions • Coolant: 80 l/min at 8 bar and 20 l/min at 18 bar; system prepared for emulsion; coolant return at spindle end D60 (without bar feed) • Control: INDEX C200-4D based on Siemens 840D; color display 26 cm; thread cutting without compensating chuck; motor-current-based tool monitoring; internal tool management and setup dialog; extended machining cycles; parts counter and production monitoring • Power/connection data: 400 V, 50 Hz TN network; total connected load 45 kVA; rated power 38 kW; rated current 65 A; max fuse protection 100 A • Hydraulic hollow clamping cylinder D65 Additional equipment • Chip conveyor: hinged belt, discharge height 1250 mm • Bar feeder: MBL 65/3700 for spindle height 1010 mm; bar diameters up to 65 mm; bar feeder length 3700 mm; guide channel system with rolling bearings; loading rods (Ø12 mm and Ø20 mm, length 1400 mm); guide sets for 14–18 mm, 18–22 mm, 22–65 mm • Workpiece unloading device for main and sub spindle with part catcher • Teleservice preparation (ISDN) with software • Machine prepared for extraction system 230 V • Working area light • Two electrical cabinet cooling units • Transformer 3 kVA Technical Specification Iodpfx Aboy Sg Daoveth Counter Spindle Yes Driven Tools Yes

Condition: used, Year of construction: 2015, Technical details: number of spindles: 6 spindle passage: 22 mm ?Bar feeder complete is 4.70 meters - for 3 meters of material ?The machine is still on ?Materail to be processed on the machine: Steel ?Production with OIL Machine has only Single-NCU without PCU. Itedpfexc Idmex Abvjh The complete energy supply of all 6 main spindles was replaced in April 25. No socket for powered tools! *
