Used Numbering for sale (23,397)

Condition: used, machine/vehicle number: 008491, X axis working area: 2500 mm Y axis working area: 1300 mm Dodeyxmvvopfx Affokk Working Table: Pod and Rail Main Electrospindle power: 12 KW Number of controlled axes: 5 axes Total number of drilling spindles: 0 Total number of tool changer positions: 24

Condition: used, machine/vehicle number: 008407, X axis working area: 6700 mm Y axis working area: 1520 mm Working Table: Pod and Rail Main Electrospindle power: 12 KW Number of controlled axes: 5 axes Dedpfx Aeycdaxoffskk Total number of tool changer positions: 48

Condition: used, machine/vehicle number: 008471, X axis working area: 6360 mm Y axis working area: 1680 mm Working Table: Pod and Rail Main Electrospindle power: 12 KW Number of controlled axes: 5 axes Total number of drilling spindles: 10 Total number of tool changer positions: 36 Dkedpsywaf Ujfx Affsk

Condition: used, machine/vehicle number: 008473, X axis working area: 4900 mm Y axis working area: 1680 mm Working Table: Pod and Rail Main Electrospindle power: 12 KW Dkodpfoywaf Ijx Affok Number of controlled axes: 5 axes Total number of drilling spindles: 10 Total number of tool changer positions: 36

Condition: used, machine/vehicle number: 006488, X axis working area: 2500 mm Y axis working area: 850 mm Dksdpfx Afswuclxefjk Main Electrospindle power: 5 KW Number of controlled axes: 3 axes Total number of drilling spindles: 11

Condition: used, machine/vehicle number: 008255, X axis working area: 3050 mm Dksdpfxex A Td Ee Affek Y axis working area: 850 mm Main Electrospindle power: 9 KW Number of controlled axes: 3 axes Total number of drilling spindles: 19 Total number of tool changer positions: 4

Condition: used, Cut-to-length line Delta-Alcos 72”x0.5”x60,000Lb (A3770) Make: Delta / Alcos Material Width: 36" - 72" Thickness Capacity: .048" - .530" Weight Capacity: 60,000Lbs Coil ID: 16" - 24" Coil OD: 72" Yield Strength: 50,000PSI Direction: Right to Left Coil Storage Conveyor Entry Coil Car Hydraulic Lift and Traverse Cone Uncoiler DC Motorized Brake Sliding Base Wichita Cooled Brake Powered Hold-Down Roll Hydraulic Peeling Table Powered In & Out Set of Driven Pinch Rolls Delta Corrective Plate 4-Hi Leveler Number of Work Rolls: 9 Work Roll Diameter: 8" Work Roll Width: 82" Powered Up & Down Back-Up Flights DC Motor & Drive Delta Corrective 4-Hi Leveler Number of Work Rolls: 19 Work Roll Diameter: 4" Work Roll Width: 82" Motorized Back-Up Flights Powered Work Roll Adjustment Dodpfx Afsixqg Nsfjkk DC Motor & Drive Alcos Mechanical Shear Down Cut Shear Driven Entry Pinch Rolls Pneumatic Clutch & Brake AC Motor Drive Alcos Drop Type Stacker 40' Sheet Length Driven Exit & End Conveyrors Touch Screen Digital Panel Operator Push Botton Station Digital Read Outs Hydraulics, Electrics, Controls, Presently Installed

Condition: used, machine/vehicle number: 005796, X axis working area: 3700 mm Y axis working area: 1550 mm Main Electrospindle power: 9 KW Number of controlled axes: 3 axes Total number of drilling spindles: 10 Dkjdjhwi U Tspfx Affek Total number of tool changer positions: 8

Condition: used, machine/vehicle number: 008238, X axis working area: 3660 mm Y axis working area: 1550 mm Dsdjx A E Tfepfx Affokk Working Table: Flat table Main Electrospindle power: 12 KW Number of controlled axes: 3 axes Total number of drilling spindles: 12 Total number of tool changer positions: 15

Condition: used, machine/vehicle number: 008369, X axis working area: 3100 mm Y axis working area: 1600 mm Working Table: Flat table Main Electrospindle power: 10 KW Number of controlled axes: 4 axes Dkodpsx A Tinjfx Affjk Total number of drilling spindles: 14 Total number of tool changer positions: 6

Condition: used, machine/vehicle number: 008321, X axis working area: 4200 mm Y axis working area: 1350 mm Working Table: Pod and Rail Main Electrospindle power: 12 KW Number of controlled axes: 4 axes Dedpfx Afox A Tdlsfokk Maximum edge height: 60 mm Total number of drilling spindles: 18 Total number of tool changer positions: 22

Condition: used, machine/vehicle number: 007564, X axis working area: 3700 mm Y axis working area: 1550 mm Working Table: Flat table Main Electrospindle power: 10 KW Dedpfx Afeum H Ekefekk Number of controlled axes: 3 axes Total number of drilling spindles: 12 Total number of tool changer positions: 13

Condition: used, machine/vehicle number: 008013, X axis working area: 5780 mm Y axis working area: 1650 mm Working Table: Pod and Rail Main Electrospindle power: 13.2 KW Number of controlled axes: 4 axes Dkodpjwuz Ekjfx Affjk Maximum edge height: 60 mm Total number of drilling spindles: 16 Total number of tool changer positions: 16

Condition: used, machine/vehicle number: 007328, X axis working area: 3200 mm Dkedsxmgybepfx Affek Y axis working area: 1850 mm Working Table: Pod and Rail Main Electrospindle power: 15 KW Number of controlled axes: 3 axes Number of controlled axes: 3 axes Total number of drilling spindles: 31 Total number of tool changer positions: 10

Condition: used, machine/vehicle number: 007329, X axis working area: 3200 mm Y axis working area: 1850 mm Working Table: Pod and Rail Main Electrospindle power: 15 KW Number of controlled axes: 3 axes Number of controlled axes: 3 axes Total number of drilling spindles: 31 Dksdpsxn Nfvofx Affek Total number of tool changer positions: 10

Condition: good (used), Year of construction: 2013, IFP Europe KP 50 HMA Basic Vacuum Parts Washer Mfd. 2013 S/N: 201305-00974 Specifications: Number of Baskets per Wash Cycle 1 Basket Size 11.9″ x 7.9″ x 17.7″ Machine Dimensions 70″ x 103″ x 70″ Chiller Size 5 ton Solvent Capacity 106 Gallon Wash Cycles Per Hour 4 to 8 Chamber “Max. Load Weight” 110 lbs Machine Weight 4,000 lbs Equipped With: Rotos & Vane Pumps, Liquid Ring Tank, Rust Inhibitor Tank Filter, Dkjdpfxsx Ddc Ie Affsk Waste Oil Separator, Siemens Touch Screen Control, Budzar BWA-AC-05-FCB-12-0-000 5-HP Chiller, Safety Guarding, Light Curtains, Automatic Door, (3) Wash Settings, Rust/Vap/Mist/Vac/Oscillation Settings, 100-Lb. Batch Weight Repairs necessary: Pumps C301.00020 DVP LC106 Vane Pump — $5,500.00 C301.00078 Liquid Ring Pump — $3,561.55 C301.00081 RBS 45 Rotary Lobe Pump — $13,500.00 Pump Subtotal: $22,561.55 Accessories / Pipes for Conversion A508.00031 — $287.50 A508.00012 — $287.50 A508.00013 — $345.00 Accessories Subtotal: $920.00 Grand Total $23,481.55

Condition: used, Year of construction: 2007, turning length 2500 mm control Sinumerik 840 D spindle head A 11 tool numbers 48 swing diameter over bed slide 750 mm Dksdpewwaruefx Affok swing over bed 780 mm c-axis 0,1-30 1/min diameter of quill 160 mm taper bore MK 5 tool length - max. 500 mm weight of tools max. 15 kg weight of the machine ca. 27 t dimensions of the machine ca. 8,4 x 4,0 x 2,5 m Technical details: Nominal turning length: 2,500 mm Swing diameter over bed slide: 750 mm Swing diameter over bed: 780 mm Working height: 1,300 mm Spindle head to DIN 55026: A 11 Bore through: 123 mm Diameter in front bearing: 200 mm Oriented spindle stop: 0-359 degrees Drive power at 100/60 % duty cycle: 37/45 kW Total speed range: 10-2,500 1/min Number of speed ranges: 2 Speed range I: 10-775 1/min Speed range II: 20-2,500 1/min Max. torque at 60 % duty cycle: 2,500 rpm. Torque at 60 % ED: 2,083 Nm (up to 186 rpm)

Condition: good (used), Year of construction: 2006, control FANUC 21i-TB Control x-axis 390 mm z-axis 780 mm spindle taper A2-11 number of spindle speeds 2000rpm engine output 37 kW weight of the machine ca. 9000 kg dimensions of the machine ca. 1905,0 × 2720,0 × 3260,0 m The machine has chucks that can produce gears from 100 to 500 mm. Special chuck is available Dodsvzln Repfx Affekk

Condition: used, Year of construction: 2012, Control Siemens 840 D weight of the machine ca. 13,5 t dimensions of the machine ca. 7m x 4m x 2,75m m Accessories: Coolant tank Grinding wheels Various spare parts Operating and maintenance instructions CE conformity Dodexh Rqtspfx Affokk Dimensions: 7x4x2.75 m ( LxWxH) TECHNICAL DATA: Workpiece data: max. outer diameter: 250 mm with max. grinding wheels Ø 450 mm max. diameter to be machined over table: 375 mm Profile depth for dressable grinding wheels: 40 mm max. workpiece length: 3,600 mm max. distance between centers (1): 2,800 mm max. bevel angle: +/- 90° Number of teeth of the workpiece: 1 - 999 max. weight of the workpiece: 250 kg Working area: Center distance between workpiece and tool spindle: 355-170 mm Radial travel: 185 mm Axial travel: 3,000 mm Swivel angle: +/- 90°

Year of construction: 1998, condition: excellent (used), machine/vehicle number: ExCello Serial Number 3888, MICHIGAN Rotoflo Type 3237 Cold Forming Machine. Original Serial Number: 4590 ExCello Serial Number 3888 Dkodpfefnk Ehex Affok New 1975 rebuilt by ExCello late 1990’s Country of Origin: USA For the coldforming of profiles for serrations (straight or angular), spiral teeth, oil grooves, threads and knurls. Capacity: Maximum slide stroke 1065 mm Maximum rack length 915 mm Maximum profile diameter 50 mm Maximum profile length 125 mm Standard module range 0.3 to 1.25 Motor size 15 kW Hydraulic tank capacity 1000 l Overall floorspace width of machine 5014 mm Width of machine 2768 mm Depth with outboard support 4165 mm Height 2000 mm Approximate weight of machine 11,700 kgs Complete with: Hydraulically operated outer support assembly to accommodate part length universal headstock, Universal rack holding feature.

Condition: good (used), Year of construction: 2003, NAGEL MODEL TBT M320-6 6 SPINDLE CNC HORIZONTAL GUN DRILL, 2003 Equipped with: Panel Mate Power Pro Control Counter Rotation Dodpfxertrzts Affskk Cross Drilling High Pressure Coolant System Auto Loader Magnetic Chip Separator Hydraulic System Chiller Specifications: Maximum Drill Depth (Approx): 16" Maximum Drill Length: 36" Number of Drill Spindles: 6 Spindle Motors (3): 7.5HP HP Per Spindle: 3.75 Drill Head Slide Stroke: 16.9" Maximum Diameter Mild Steel: 0.750"

Condition: used, Year of construction: 1996, functionality: fully functional, machine/vehicle number: 25734, Equipped with: Fanuc 150MB Control Hydraulic Chucking Work Spindle Large Bore Work Spindle #80 Taper Stock Divider Helical Motion Modified Roll Hansen Coolant Chiller & Filtration Coolant Tank & Pumps Chip Conveyor Dodpfx Afexaqa Sefjkk Chip Hopper Reven Mist Collector Hydraulic System Transformer Cutter Bolt Work Light Operator Platform Hand Tools Documentation Specifications: Extreme Ratio: Face Milling: 10:1, Face Hobbing: 10:1 Full Depth: Maximum: Face Milling:1.25" (31.75mm), Face Hobbing: 0.93" (23.50mm) Face Width: Maximum: Face Milling:6.00" (152.00mm),Face Hobbing: 3.00" (76.20mm) Range of Tooth Numbers: 1-300 Inclusive Gear Pitch Diameter, Maximum: 1000 mm (39.37") Cutter Size, Maximum: 18" (diameter) Face Milling Cutter Size, Maximum: 350 mm (radius) Face Hobbing Root Angle Range (B-Axis) 5 deg.to 90 deg., Face Hobbing:5 deg. to 90 deg. Machine Center to Work Spindle Face:9.00"Fixed, 229mm (Fixed) A-Work Spindle: 0 to 67 RPM, 0 to 333 RPM B-Swinging Base: 0 to 30 deg./sec, N/A C-Cutter: 0 to 500 deg., Same X-Horizontal: +/-305mm (+/-12") Y-Vertical: +/-305 mm (+/-12") Z-Sliding Base: -25/+700mm (-1/+28") B-Root Angle: -5 Degree/+90 Degree Diameter of Taper Hole at Large End: 8" (#80 Taper) to 6" (#60 Taper) Taper Per Foot:3/4", Same Depth of Taper Front:6", 152.40 mm Depth of Bore: 678 mm (26.7") Diameter of Taper Bore: 140 mm (5.5") Diameter Through Spindle of Hole:7.125", 180.98 mm MACHINE DIMENSIONS: Length x Width:233"x 209", 5920 mm x 5310 mm Height: 129", 3280 mm Weight: 65,000 lbs., 29,484 kg

Condition: used, Year of construction: 1977, machine/vehicle number: 19909, Equipped with: Index Plate Geneva Cam Cutter Body Hydraulic Work Clamping Coolant Pump & Tank Chip Conveyor Additional Cutter Bodies, Index Plates & Geneva Cams Available Specifications: Minimum Outside Cone Distance: 2.75" Maximum Cone Distance: 10" Maximum Gear Pitch Dia.: 20" Cutter Diameters Utilized: 9 - 18" Root Angle: 55 - 80 Deg. Face Width: 3" Number of Teeth: 20 -75 Diameter of Taper Hole at Large End: 3-27/64" Dedpfxoxdfazj Affokk Taper Per Foot: .50" Depth of Taper: .625" Cutter Speeds: 15.6 to 87.7 RPM Feeds (seconds/tooth): 5 to 34.3 Main Motor: 10hp, 1800 rpm Hydraulic Motor: 7.5hp, 1800 rpm Approximate Floor Space: 118" x 86.5" Needed Overall Height: 70" Approximate Net Weight: 18,820 lbs Shipping Weight Boxed for Export: 20,500 lbs

Condition: used, Year of construction: 1973, machine/vehicle number: 24109, Equipped with: Djdpfxjxdfa Ue Affjkk Stock Divider Hydraulic Work Clamping Chip Conveyor Cutter Clamping Bolt Index Plate Change Gears Hydraulic System Coolant System Specifications: Min. Outside Cone Distance: 2.75" Max. Cone Distance: 10" Max. Gear Pitch Dia.: 20" Cutter Diameters Utilized: 9 - 18" Root Angle: 55 - 80 deg. Face Width: 3" Number of Teeth: 20 -75 Diameter of Taper Hole at Large End: 3-27/64" Taper Per Foot: .50" Depth of Taper: .625" Cutter Speeds: 6.8 to 16.5 RPM Feeds (seconds/tooth): 3 to 9 Main Motor: 5hp, 900 rpm Hydraulic Motor: 7.5hp, 1800 rpm Approx. Floor Space: 118" x 86.5" Needed Overall Height: 70" Approx. Net Weight: 16,000 lbs Shipping Weight Boxed for Export: 17,000 lbs

Condition: good (used), Year of construction: 2019, machine/vehicle number: 25653, Equipped with: -Automatic Central Lubrication System -Machine Guard -Indramat - MTX and Sercos CNC Control -The standard machine is equipped with CNC-control make Indramat - MTX and SERCOS-interface -Tool Dressing (Automatic dressing cycle of the dressing master and honing wheel tip diameter by a diamond coated dressing roll. The dressing cycle of workpieces can be pre-selected) -Electronic Indexing Unit -Operator and Maintenance Manual -All Electrical Drawings -PLC Language in English -Software and Hardware for Remote Diagnosis -High Precision Control of the Stock Allowance Material -Manual Loading on Spindle for Prototypes Djdpow Iquysfx Affskk -Software for Infeed Optimized Cycle Type Reduction (Adaptive Honing) -Software for Vario Speed Dressing -Software for Calibration of Master Gears -Software for Timing Gears (including additional sensor for the hole of 4mm) -Software for Shortening of Workpiece Change-Over Time -Clamping Cylinder -RITTAL Cooling Unit -Lighting for Working Area -Installation of Vibration Detecting Sensors -Coolant Unit -Electrostatic Oil Mist Exhauster IFS With Rigid Piping -Internal Automation -Pallet Ring Conveyor System FlexLink (L-form shape see approved layout) -Parallel - Double Gripper -Pick and Placer Between Pallet Conveyor and Internal Loader -Extended Loading Length of the Pick and Placer Specifications: Workpiece: -Part Diameter: 20-150 mm -Maximum Face Width: 70 mm -Part Weight: 20 kg -Number of Teeth: 6-150 -Module: 1-5 mm Workpiece Spindle: -Maximum Speed: 6000 1/min -Installed Power: Approx. 25 kW Tool: -OD of Honing Wheel: 270 mm -Widths of Honing Wheel: 20-70 mm -Honing Wheel Material: Ceramics Tool Spindle: -Maximum Speed: 2000 1/min -Installed Power: Approx. 25 kW Machine: -Total Connected Load, Approx: 70 kVA -Floor Space (w x l x H): -Total Weight, Approx: 11 Ton -Bosch Rexroth MTX Control CML 85 Longitudinal Slide, Z-Axis: -Linear Drive -Drive Torque: 3,700 Nm -Infeed Speed: 60 m/min -Theoretical Infeed: 200 m/min -Drive Length, Maximum: 400 mm Cross Slide, X-Axis: -Linear Drive -Drive Momentum: 2,150 Nm -Infeed Speed: 60 m/min -Theoretical Infeed: 200 m/min -Drive Length, Maximum: 1050 mm Swiveling Axis, W-Axis: -AC-Servo Drive: 10,000 1/min -Setable Gear Transmission: i=5000:1 -Swiveling Angle: -90 Degrees / +16 Degrees Workpiece Spindle, C-Axis: -Direct Drive, Maximum RPM: 7,000 1/min -Drive Power: 30 kW -Drive Torque: 112 Nm -Digital Measuring System Tool Spindle, B-Axis: -Direct Drive (hollow spindle drive), Maximum RPM: 2000 1/min -Drive Power: 30 kW -Drive Torque: 150 Nm -Digital Measuring System
