Used Pin Slot Machine for sale (68,799)

Condition: excellent (used), PANHANS long-hole drilling machine Drilling table size 520 x 290 mm Max. drilling depth approx. 130 mm Max. drilling length approx. 240 mm Height adjustment approx. 135 mm Drill spindle speed 3000 rpm Motor power 1.5 kW, 400 V, 50 Hz Space requirement approx. L x W = 900 x 1100 mm Weight approx. 220 kg 2-lever operation WESCOTT drill chuck 20 mm Dowel drilling device with 4 grids (16, 22, 25, 32 mm) Miter stop, adjustable by 45° 2 workpiece clamps Height adjustment with handwheel Motor protection switch with undervoltage release Workpiece stop 1500 mm Including test report for conformity with Section 4 of the AM-VO (German Ordinance on Machinery) Pedpfoza Dx Nox Ai Dogr Space requirement approx. 950 mm x 1000 mm x 1300 mm Weight approx. 200 kg Note regarding used machines: • Subject to errors in technical specifications and prior sale. • Quoted prices are ex-works prices, collection only - free loading! • The machine has been cleaned and function-tested. • All machines are sold as seen, without any warranty claims. The buyer is free to inspect the machine at the location. • Special agreements are only possible in written form. (We only answer inquiries if you provide your address + telephone number!)

Condition: excellent (used), Motor power 1.2 HP, 400 V, 50 Hz Speed 2800 rpm Drilling table size 650 x 330 mm Cross adjustment 300 mm Depth adjustment 150 mm Height adjustment 170 mm Table height 880 mm Weight approx. 280 kg Podpfxsvzrams Ai Dsgr

Condition: new, Year of construction: 2025, heavy-duty construction with cast iron table smooth movements using hand lever and handwheel eccentric clamping device dowel drilling unit with 16-22-25-32 mm grid 2 spindle speeds: 1500/3000 rpm WESCOTT drill chuck 1 - 16 mm CE compliant Work table dimensions: 287 x 550 mm Longitudinal travel: 200 mm Vertical travel: 160 mm Podpfoycg U Ejx Ai Dogr Cross travel: 125 mm Three-phase motor power: 1.8 kW, 400 V, 50 Hz

Condition: used, Year of construction: 1988, Slot drilling machine Manufacturer: SCM Psdezuynuopfx Ai Dogr Type: AS 16 Year of manufacture: approx. 1988

Condition: used, Vertical Slotting Machine GSP M 743 3-jaws chuck Ø 360 mm Table travel: X = 500 mm / Y = 450 mm Slide travel: 300 mm Throat depth: 500 mm Rotary table: Ø 690 mm Slide tilting: + 8° Rotative table/slide maxi height: 450 mm Motor power: 8 CV Rapid feeds on X - Y - W axes Pedpfozw A A Hex Ai Djgr Strokes/min.: from 3 to 300 strokes/min. Equipped with one tool removal system upon lifting Voltage: 380 V Length: 2000 mm Depth: 2500 mm Total height: 2200 mm Weight: approx 4 T

Condition: used, Slotting Machine MAILLEFER type MAC-350 M Useful travel: 0 - 350 mm Slots width: max 36 mm Motor power: 2,5 CV Feeds: from 0,025 mm to 0,125 mm Bore: from 15 to 160 mm Automatic forward and stop Supplied with many tools (see photos) Dimensions (L x W x H): 1400 x 800 x 800 mm Pjdpfxezw A Ate Ai Djgr Weight: approx 700 kg

Condition: used, Vertical Slotting Machine GSP M 743 3-jaws chuck Ø 360 mm Pgsdpfxjzw A Aaj Ai Djr Table travel: X = 500 mm / Y = 450 mm Slide travel: 300 mm Throat depth: 500 mm Rotary table: Ø 690 mm Slide tilting: + 8° Rotative table/slide maxi height: 450 mm Motor power: 8 CV Strokes/min.: from 3 to 300 strokes/min. Equipped with one tool removal system upon lifting Voltage: 380 V Length: 2000 mm Depth: 2500 mm Total height: 2200 mm Weight: approx 4 T

Condition: used, WEINIG UNITEC 10 tenoning and slotting machine from a UC-Matic window production line, not in working order. Podpfx Aoztv Axoi Djgr Technical data: - Year of manufacture: 1997

Condition: like new (used), Year of construction: 1994, functionality: fully functional, HOFFMANN HT 200 Dowel and Slot Drilling Machine In very good condition, this machine comes from an educational institution, has been used very little, and is in absolutely like-new condition; it has only very few signs of wear. It can be used to mill slots and drill dowel holes; the drilling height can be read very precisely on a digital counter. Comes with 3 drill chucks: for drills with an M10 external thread and for drills with 12mm and 16mm shanks. Podpfx Aieyy Rtzs Degr With workpiece support rests on the left and right sides, which are pivotable and have a support roller. The machine has a chassis. With 2 angle stops on the machine table for left and right. The clamping arms are reversible and adjustable. 380V, 1400 and 1800W through the 2 speed ranges. 1400 and 2850 rpm. Year of manufacture: 1994 Weight: approx. 280 kg With this machine, you can mill slots for, e.g., lock cases and similar items, or produce all types of frame dowel joints at right angles, butt joints, and miter joints. Ideal for producing dowel joints in timber frame construction, furniture, door, window, and staircase construction, and for similar applications. The drilling unit can be pivoted on both sides up to 65° and has a detent at 0°; this allows the machine to also be used to drill handrail posts into staircase stringers. The 2 speed ranges allow drills with large diameters to be used without overheating during drilling. Due to the detents and stops and the machine's design, dowel joints can be produced in a very short time, making the machine very economical. The machine requires a compressed air connection of 6 bar (the air consumption is very low). Right-hand rotation. Mills and drills very well and cleanly. Workpiece clamping is done with 2 pneumatic clamping cylinders via a foot pedal. The linear laser at the top of the machine allows marked dowel holes and angles to be drilled quickly and accurately. Comes with a precision 12mm guide rail with a center detent and 13 detents on the left and right. Working travel in width: max. 330mm The max. borehole height is 90mm. The max. borehole depth is 200mm with stop. The max. workpiece height is 150mm. Everything functions perfectly. Comes with manual. We will personally deliver and demonstrate the machine anywhere in Germany for €220.00, so you have no risk when purchasing; delivery to Austria and other countries is also possible upon request. The machine table is 1100mm wide and 250mm deep. Professional equipment, not cheap hardware store junk. You can start working with the machine immediately. Very stable and durable construction. The precision guides with the play-free ball bearing bushings are in good condition and move smoothly; the pivoting mechanism is also very smooth due to a ball bearing; locking is possible with a locking screw.

Condition: reconditioned (used), Year of construction: 1999, functionality: fully functional, Two-jaw drill chuck, 2 hand-operated eccentric clamps, dial indicator in the handwheel, 2 speeds 1400 – 2800 rpm. The machine has been fully overhauled and newly adjusted at our facility. Pgedpfxjyzc E Se Ai Dor

Condition: used, Year of construction: 2020, The Centauro Alfa NC is your go-to solution for comprehensive machining operations on doors and frames. Whether you're working on hinge recessing, lock slots, keep plates or 3-point locks, the Alfa NC is a versatile addition to any door and frame manufacturing process. With a solid track record of delivering reliable performance and exceptional results, this highly popular machine is trusted by industry leaders. Achieve perfect hinge placements with precise recessing operations, create exact lock slots and keep plates for secure installations, and manufacture intricate handle holes, key slots and euro grooves with ease. The Centauro Alfa NC is designed with user convenience in mind, with simple programming via the TOP12 graphic touch screen controller, allowing quick setup and easy adjustments with pre-installed macros, making it accessible for both experienced operators and newcomers to CNC machinery. Experience the difference in quality that this exceptional machine brings to your production line and join the many satisfied customers who trust the Centauro Alfa NC for their door and frame machining needs. Pjdpfx Asy H Iq Rji Degr Specification: Axis capacity – X 2800mm – Y400 mm – Z 150mm X axis positioning speed 35 m/min Y and Z axis positioning speed 6m/min Maximum work table dimensions 3000mm x 618mm Main router head 3.3kw – rpm 0 to 18,000 – ER32 collet 2 x front pneumatic retractable positioning stops 2 x front support legs for doors Elco TOP 12 colour graphic touch screen controller CE side / rear safety guards with front light beam 2020 CE C/W Optional Extras: Y axis stroke 400mm in lieu of 180mm ISO 30 Quick change manual pneumatic toolchanger

Condition: new, Centauro ALFA NC Machining Centre For Joinery Components & Doors A versatile and flexible NC controlled machining centre suitable for a variety of machining operations including hinge recessing, lock slots, handle holes, key slots and euro grooves etc. Programming is extremely simple thanks to the colour graphic touch screen controller using pre-installed electronic macros. As standard the machine can be equipped with one milling head that automatically moves for either vertical or horizontal machining. It also has interpolation of the axis. Optional additional machining operations include producing a square corner hinge plate recess or lock face recess by means of the additional milling unit. The operator simply selects in the program if they want a radius or square corner and the machine does the rest. In addition the same milling head can be used to make the small pilot hole for hinge screws etc. There is also the possibility to produce a square end tenon, round end tenon or dovetail / dovetail slot when the special front table is fitted. Lastly on request the machine can be configured to import ISO files from external design software (e.g ARTCAM Express) to enable detailed engraving of items such as name plates etc. Axis capacity - X 2800mm, Y 180mm, Z 150mm. (2400mm X capacity when optional drilling head fitted). 1 x ER32 collet for milling cutter 16mm max. dia. Max working table dimensions - 3000x618mm X axis positioning speed 35m/min. Pgjdpfx Aob Tmngsi Der Y axis / Z axis positioning speed 6m/min. Retractable pneumatic positioning stops 2 off - on front of table Adjustable pneumatic workpiece clamps x 3 - mounted on rear of table. Left hand side ref. stop. Front table extension supports x 2 Router motor power 3.3kw. Router motor RPM 0-18,000 rpm. Touch screen controller - Elco Power 1000. Dust extraction outlet x 1 80mm dia, 2 x 100mm dia CE side and rear safety guards with front light curtain.

Condition: used, Table unit from a DROOP & REIN portal milling machine Clamping plate with T-slots made of cast steel gray cast iron Table unit with clamping plate and very solid guideway Table clamping surface 5500 x 2000 mm Travel of the table clamping plate approx. 3100 mm Table height 1050 mm Table load: max. 20 tons Ball screw: Ø 100 mm Pgodpethuzpofx Ai Der Thread pitch: 20 mm (single-start) - Processing table guided very stably on the bed - Metal telescopic guideway cover - comes from a DROOP & REIN portal milling machine - Longitudinal table movement via ball screw and SIEMENS servo motor - Clamping surface with 11 T-slots 28 mm - Drive via SIEMENS 1FT6134-6AB71-1AG2 servo motor with IC200448S/R encoder (RN 000 B25) Total length 9500 mm Width 2000 mm Overall height 1050 mm dead weight 28 ton. good condition

Condition: used, Keyway milling head, head for DECKEL milling machine, type FP 1 Factory number: 21948 Dovetail width: approx. 74 - 88 mm Dovetail height: approx. 14.5 mm Dovetail length: 285 mm Pgjdpfx Aeznn Hroi Djr Distance from the front edge of the dovetail to the center of the gear: approx. 200 mm Stroke size: max. 80 mm Stroke rate: max. 475 double strokes/min. Tool holder: 4-sided, 16 x 16 mm with clamping plate - Stroke size adjustable via eccentric adjustment - Drive from the machine gearbox, within the dovetail guide (as with the normal vertical head) - This keyway milling head is inserted into the dovetail guide in place of the normal vertical milling head (Mounting in place of the vertical milling head) - Drive gear in the keyway milling head, 39 teeth, gear width 15 mm, presumably 15° pressure angle - Keyway milling head can be rotated 360° on the flange plate, degree scale +/- 35° - Small breakout point on the housing Weight: 28.5 kg DECKEL FP1 has a pressure angle of 15° on the drive wheel. DECKEL FP2 + FP3 have a pressure angle of 20° on the drive wheel.

Condition: excellent (used), functionality: fully functional, Slotting machine Urpe model M-300 G of tilting head, Slotting of course of 0-300mm of travel, number of blows per minute 30-35-40, distance of the tool to the column 500mm, distance adjustable from the table to the ram 425 -585mm, max distance between tool and body 450mm, table surface 800x325mm, long table travel 550mm, rec transv 265mm, motor pot 5.5cv, estimated weight 1850kg, with Chuck Psdpfx Aijvdknze Djgr

Condition: good (used), Code: 0451 Pgjdpfxezm Slpj Ai Djr Brand: MCN - ITALY Model: JUNIOR - CE Standard Bit mortising machine for furniture, joinery, custom-made furniture, doors, shelves and various – CE standard Technical data: Table length 530 mm Table width 230 mm Table height from floor 800 mm Max groove length 200 mm Max groove depth 150 mm Vertical spindle stroke 200 mm Spindle attack 16 mm Spindle 2800 rpm Motor power 2 Hp Pneumatic clamping device for workpieces Weight kg 160

Condition: good (used), Year of construction: 1992, Well-maintained elongated hole drilling machine with the following features: Table can be tilted Pgjdpezdcdlsfx Ai Dor With center stop With length stop With turret drilling template for series drilling with spacing of 16, 22, 25, 32 mm.

Condition: new, Year of construction: 2025, GANNOMAT "MASTER 325" FRAME DOWEL AND MORTISE BORING MACHINE Specifically designed for staircase construction Complete in standard configuration according to price list 01/19/D, featuring: - Precision collet chuck for ER40 collets Ø 3-26 mm, incl. collets Ø 10 / 13 / 16 / 20 - Pole-switchable motor 1400/2800 rpm, 1.5 kW - Line laser with bracket - Boring unit, continuously rotatable from the front (65°-0°-65°) - Position setting via digital counter - Position adjustment for 2 levels, pneumatic (0-100 mm) - Maximum boring depth 200 mm - Precision indexing rail with 12 mm pitch with central detent and lateral adjustment 320 mm - Complete stop system consisting of: 1 center stop and 1 stop for oversized frames 1 stop rod, approx. 850 mm long (can be reversed from left to right) 2 flip stops - Mortising unit lowerable, with 2 program cams (400V, 3Ph, 50Hz, 1.5 kW) Pedpfx Asxdttpsi Dsgr Extraction funnel, dust-tested, Ø 80 mm Double miter stop adjustable from 0°-60° Pneumatic clamping of the X-axis with on/off switch at the indexing handle Pair of auxiliary workpiece supports, swiveling (left and right) Clamp column re-positionable to the front Chassis with 4 wheels for easy machine movement 1 piece Collet extension Ø 20 mm, incl. collet for drill shank Ø 9 mm 1 piece Baluster drill bit Ø 25 mm, chrome steel, with centering tip Available: at short notice

Condition: new, Year of construction: 2026, Panhans long hole drilling machine type: 116/10 -Drilling depth max. 145 mm -Drilling length max. 240 mm -Height adjustment 135 mm -Suction nozzle ø 100 mm -ColorRAL 7035 light greyRAL 5000 violet blue -Net weight approx. 200 kg Solid German mechanical engineering Professional slot milling and precise dowel drilling Fixed table, smooth-running mobile drill motor Travel mechanism for greater mobility Cast iron table 700 x 380 mm thick-walled and highly ribbed Smooth-running cross support with adjustable ball guides for lateral and depth adjustment Height adjustment via handwheel and scale, drilling depth stop via scale, drilling length limit adjustable via side stops left and right Drill motor output 1.3 kW/1.8 hp with motor brake and practical tool tray Incl. emergency stop button High-precision three-jaw drill chuck, clamping range 5 - 20 mm Dowel drilling device for drilling holes in rows with 16, 22, 25 and 32 mm raster roller High-precision milled raster, fixed via spring-loaded raster bolt Plug-in frame stop with index bolt for the positions: center, left, right CE-compliant GS tested Incl. additional special accessories: - Single lever operation - Handwheel with dial gauge Pedpjr Eli Tjfx Ai Djgr Location: ex stock 54634 Bitburg - immediately available -

Condition: new, Year of construction: 2024, Hoku Houfek long hole drilling machine LLB VD 20 R Top condition - Top machine - Pgsdpfou Agzxex Ai Der Motor 1,5/1,9 kW, Transverse displacement in Y-axis 250 mm, Longitudinal displacement X 340 mm, Vertical displacement z-axis 200 mm, 2 speeds 1,440 and 2,880 rpm. One-hand dowel drilling device with pitch 16 - 22 - 25 - 32 mm, 2 manual eccentric clamps, manual digital display for drill bit height, Table dimensions 700 x 400 mm, Drill chuck max. D = 20 mm, table rotatable +/- 45°, weight approx. 345 kg immediately ex stock 54634 Bitburg Subject to prior sale,

Condition: excellent (used), Year of construction: 2001, Felder slot mortising machine FD-250 Pgjdpfxjyvv Ngs Ai Der Motor power: 2.2 kW Year of manufacture: 2001 Height adjustment via handwheel Lever operation 2 manual clamps Includes several slot mortising cutters Location: ex stock 54634 Bitburg - immediately available -

Condition: excellent (used), Year of construction: 1995, used, in good condition, low hours, top equipment Manufacturer: Panhans Pedpfsxgu Uaex Ai Degr Model: 116H Year of manufacture: 1995 Machine No.: 640 GS wood dust tested 2-lever operation Drill chuck 20 mm Dowel boring device with 4 stops 45° continuously adjustable mitre fence Mobile 2 pneumatic workpiece clamps Pneumatic height adjustment with foot pedal Extraction connection D 100 mm Required space approx. 950 mm x 1000 mm x 1300 mm Weight approx. 200 kg Storage location: 54634 Bitburg, free loaded, unpacked Handover in current condition as inspected without guarantee or warranty

Condition: used, total length: 4,300 mm, total width: 600 mm, total height: 1,100 mm, Colour: Green Empty weight: 600 kg - Documentation available: No - CE certificate present: No - Drive system: Conventional - Drive type: Hydraulic - Model: Horizontal - Number of axes [pcs]: 1 - X-axis travel [mm]: 1500 - Transport dimensions: 4300mm x 600mm x 1100mm (l x w x h) - Transport weight [kg]: 600kg - Transport packages [pcs.]: 1 Financial information Pgsdpfszkkukjx Ai Dor VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Delivery and trade-in always possible for everything in the industrial sectors Lukas van Rossum

Condition: used, Year of construction: 2002, Second-hand machine Year of manufacture: 2002 Table size 580 x 280 mm Drilling table height: 800 mm Drilling depth: 150 mm Drilling length 225 mm with Wescott drill chuck 0–20 mm Height adjustment: 120 mm Swivel range of drilling unit: 2 x 45° with 2 eccentric clamps Pgsdpfx Aijzk Nups Dsr with one-hand operation with dowel drilling device with dial gauge in the handwheel with digital display with 2 speeds: 1,400 and 2,800 rpm with travel mechanism LxWxH 850x1000x1050 mm Weight approx. 240 kg Availability: at short notice Storage location: Flörsheim

Condition: used, Year of construction: 2018, Second-hand machine Year of manufacture: 2018 Features and technical specifications: - The drilling depth is adjusted via a maintenance-free linear guide - Efficient and cost-effective operation thanks to the rapid-lift system, eliminating the need for laborious cranking - Smooth-running and infinitely variable drilling unit - Height adjustment with fine adjustment and gas pressure cylinder for weight compensation - Transverse and height adjustment with scales and adjustable stops - Vibration-free operation thanks to robust steel construction - Drilling depth adjustable via a scale and stop - The drill head height adjustment can be used entirely for vertical slotting - Large-dimension grey cast iron table with a ground surface - Motor power: 1.5 / 1.9 kW - Voltage: 400 V - Speed: 1,400 / 2,850 rpm - Westcott drill chuck: 0–20 mm - Maximum drilling depth: 220 mm - Drilling width: 340 mm - Height adjustment: 145 mm - Swivelling drill head: -60° to +60° - Drilling table size: 595 × 315 mm - Table extension: 2 × 200 × 220 mm - Drilling table height: 830 mm Dimensions: 1,200 × 1,050 × 1,300 mm Weight: approx. 240 kg Pgodpfozk Nlnox Ai Der Availability: at short notice Location: Flörsheim
