Used Travelling Column Milling Machine for sale (68,209)

Condition: used, Year of construction: 2017, operating hours: 15,218 h, functionality: fully functional, machine/vehicle number: 5639, travel distance X-axis: 10,000 mm, travel distance Y-axis: 3,600 mm, travel distance Z-axis: 1,900 mm, position of the milling head: 0.001°, mount diameter: 50 mm, rotational speed (max.): 4,000 rpm, torque: 2,000 Nm, coolant supply: 70 bar, spindle motor power: 60,000 W, Equipment: documentation/manual, rotational speed infinitely variable, SORALUCE CNC gantry milling and boring center with complete equipment x-10000mm y-3600mm z-1900mm - Automatic indexing milling head H 342 0.001° x 0.001° - Additional long angular head 90° - Capto C6 tool holder, horizontal/vertical with automatic tool clamping - Main drive 60KW 2000Nm - Machine weight 80 t Laedpfjz Iy Irex Ahajh - Safety package for the rear machine area - Safety package for the working area - Heidenhain iTNC 640 - Dynamic Active Stabilizer - Cross-axis compensation - Automatic head changing system - Milling slide extension z-1900mm - High-performance milling head 4000 rpm 1531Nm 0.001° x 0.001° - Additional long angular milling head 90° 2000 rpm 700Nm - Capto C8 turning tool holder horizontal / vertical with automatic clamping - Fixed storage station for 8 heads - Heidenhain handwheel - Coolant tank 200 liters - Automatic tool changer 120-fold - Increased tool weight 35 Kg - SORALUCE rotary table, diameter 3500mm with 2000mm travel, payload 40 t - Measuring probe M+H - Tool measurement M+H - Adaptive Control - Industry 4.0 machine status in real time - Swivel machining - 3-sided complete splash guard for the rotary table - Plate table 5000x3000x300mm - Chip conveyor - Teleservice remote diagnostics - 3D volume model - Interpolation turning HEIDENHAIN

Condition: good (used), Year of construction: 1990, 1 used, well-maintained CNC tool milling machine, traveling column design, with CNC path control GRUNDIG Dialog 11 Table size 1600 x 675 mm Tool holder SK / ISO 40 Travel distances X-axis, longitudinal 1200 mm Y-axis, transverse 600 mm Z-axis, vertical 500 mm Table load 2000 kg Spindle speed range 20 – 6300 rpm Feed rate range, stepless 2 – 10,000 mm/min Rapid traverse in all axes 10 m/min Quill stroke 80 mm Drive power 100% ED 7.5 kW 40% ED 12 kW Machine dimensions L x W x H 3600 x 3000 x 2300 mm Machine weight 6800 kg Laodjhhuf Hjpfx Ahajh Control cabinet dimensions L x W x H 1700 x 900 x 1750 mm Control cabinet weight 470 kg Accessories / Special features: • CNC tool milling machine suitable for tool and fixture manufacturing, training, and mold making • CNC path control GRUNDIG Dialog 11 • Screen graphics, dialog-guided input, 3D linear interpolation, circular interpolation, helical interpolation, polar coordinate input, numerous drilling and milling cycles, cycle input graphically supported, milling cycles "contour pocket" for automatic free milling of irregular pockets, even with islands, shifting and rotation of the coordinate system • Electronic handwheel • RS 232 interface • Swiveling vertical milling head +/- 90° • Hydraulic tool clamping, DIN 2080 with clamping groove, Ott system • Quill adjustment 80 mm • Horizontal milling attachment • Full protection enclosure • Ball screw spindles in all 3 axes • Coolant system • Lighting Siegfried Volz Werkzeugmaschinen Rüschebrinkstr. 151-153 D - 44143 Dortmund - Wambel

Condition: used, Year of construction: 2011, functionality: fully functional, travel distance X-axis: 8,000 mm, travel distance Y-axis: 1,500 mm, travel distance Z-axis: 2,000 mm, spindle speed (max.): 4,000 rpm, rotational speed (max.): 4,000 rpm, table length: 6,500 mm, table width: 1,100 mm, torque: 900 Nm, spindle motor power: 32,000 W, We are offering this used SORALUCE SP-8000 vertical milling machine with a moving column, manufactured in 2011. Model: SP-8000 Year of manufacture: 2011 Travel: 8000X1500X2000 Table: 6500 x 1100 Automatic head: 2.5° X 2.5° Spindle speed: 4000 rpm Spindle power: 32 Kw Spindle torque: 900Nm Number of tools: 40 Portable crank handle Lajdpfs Aaq Efex Ahajh Chip conveyor If you have any questions or require further information, please do not hesitate to send us a message or call us.

Condition: good (used), Year of construction: 1999, Boring and milling machine MECOF Agile M3, serial number 07 99 05, year of manufacture 1999, control system FIDIA M2, X/Y/Z travel 6,000/1,250/2,000 mm, chip conveyor, indexing head, tool changer, chip filtration system. Laedpfxoz Icc Eo Ahash

Condition: used, Year of construction: 2002, machine/vehicle number: 6243, travel distance X-axis: 5,000 mm, travel distance Y-axis: 2,100 mm, travel distance Z-axis: 1,500 mm, Equipment: documentation/manual, Base machine / travel ranges: X-axis machine stand 5,000 mm, Y-axis spindle head slide 2,100 mm, Z-axis spindle head 1,500 mm. Machine stand: Compact, torsion-resistant welded construction with hardened flat guide rails and telescopic steel covers to protect against chips and coolant. Spindle head slide: Cast iron design with hydraulic weight compensation, guided by combined roller/plain bearing guides. Machine bed: Flat bed design with approximately 1,200 mm guide rail width and roller compact guides for high precision. Automatic universal milling head: CNC-swiveling milling head arbor 340 x 1°, Hirth gearing approximately 125 kN; milling head 180 x 1°, approximately 100 kN; milling spindle with hydromechanical tool quick-change system, clamping force approximately 25 kN; tool holder SK 50, DIN 69871. Main drive: 37 kW at 100% ED, 53 kW at 40% ED; externally ventilated AC motor, 2-stage gearbox with automatic changeover; speed 22–4,000 1/min. Feed drives: Digital AC individual drives; X/Y: 2–12,000 mm/min, Z: 2–15,000 mm/min. Control system / measuring systems: Central operation via Heidenhain TNC 430 M. Direct, non-contact linear measuring systems. Optional: Heidenhain iTNC 530. Electrical system: EN 60204 / VBG 4, 400/230 V ±10%, 3 phases, 50 Hz, 24 V control voltage; connected load approximately 80 kVA. Control cabinet IP54, main motor IP55. Lubrication: Main gearbox / milling head drive oil circulation lubrication; main spindle grease long-life lubrication; guides / ball screws pulse central lubrication. Coolant: Internal / external coolant supply with paper band filter. Max. 50 l/min at 10 bar or 47 l/min at 16 bar; tank 500 l. Coolant / air changeover. Oil cooler for temperature stabilization and increased manufacturing accuracy. Leveling system: Electromechanical, via 2 vertical ball screws with separate drives, measuring systems, and CNC axes. Lajdpoz Dvycsfx Ahajh Working platform: Moves in the X direction, with CNC control panel; electrically secured door with viewing window. Pick-up station: 10 tools; max. tool weight 25 kg, length 400 mm, Ø 125 mm, with free adjacent slots Ø 250 mm. Clamping plate: 3,500 x 3,000 mm; T-slots 22 H12 DIN 650, spacing 250 mm; clamping surface accuracy class 1 DIN 876. CNC rotary table: Clamping surface 1,250 x 1,600 mm / Ø 1,800 mm; Hirth division 360 x 1°; 6 longitudinal slots 22 H12, 2 positioning slots 22 H7; T-slot spacing 160 mm; centering bushing Ø100 H7 x 20 mm; max. 5 1/min; tilting moment 85,000 Nm; tangential moment 120,000 Nm; table load max. 11,500 kg. Additional equipment: Oriented spindle holder 360 x 1°; hinged band chip conveyor for X=5,000 mm, feed width approximately 350 mm, discharge height approximately 1,250 mm; 3D touch probe; electronic handwheel HR 410 for 3 axes; pendulum machining for 2 work areas with monitored safety areas; manually adjustable splash guard. Collision monitoring: Brankamp CMS with piezoelectric strain gauge; if the process limit is exceeded, the axes are braked and the machine is switched off. Painting: Machine / control cabinet RAL 7035, milling head / spindle head RAL 5021; DD structured paint, semi-gloss, oil and alkali resistant. Power connection: 400 V, 3 phases, 50 Hz, 80 kVA, 160 A slow-blow; compressed air 4–6 bar, connection G 1/4. CE-relevant environmental protection to be provided on-site; adapter plates for chip / coolant return are not included. Coordinate information: Y 730.0124. Documentation: Operating manual SHW-UF6L and Heidenhain TNC

Condition: good (used), Year of construction: 2007, functionality: fully functional, Machine-Details Stock-No. 1022-E06374 Type of machine Travelling column milling machine Make CME Lodpfxsz S Arpo Ahajah Type MB-9000 Year of manufacture 2007 Type of control CNC Storage location Spain Country of origin Spain Delivery time Immediately Freight basis Ex site, without dismantling and loading Technical details x-travel 9000 mm y-travel 4000 mm z-travel 1000 mm W-axis (spindle longitudinal) 700 mm spindle diameter 150 mm tool taper ISO 50 DIN-69871 spindle turning speed range 2350 U/min transmission ratio 2 main drive motor 37 kW weight of the machine ca. 125 t Additional information * CNC-control SIEMENS Sinumerik 840 D * 2 rotary tables (hydrostatic) make RÜCKLE, 2500 x 2500 mm, table load 25 to, travel 2000 mm * Coolant equipment (1000 liter) with coolant through spindle 40 bar * Chip conveyor * 90-station automatic toolchanger - max. tool diameter 125 (240) mm - max. tool length 400 mm - max. tool weight 20 kg * several toolholders

Condition: used, Year of construction: 1996, operating hours: 17,625 h, functionality: fully functional, machine/vehicle number: 03-106, travel distance X-axis: 2,000 mm, travel distance Y-axis: 1,000 mm, travel distance Z-axis: 1,000 mm, rotational speed (max.): 3,000 rpm, type of input current: three-phase, total width: 2,700 mm, total height: 3,000 mm, total length: 7,000 mm, table length: 2,200 mm, table width: 850 mm, table height: 900 mm, spindle motor power: 22 W, workpiece weight (max.): 16,000 kg, grinding spindle motor power: 22 W, Equipment: documentation/manual, Fixed-table milling machine CME bf 03, travels 2000x1000x1000mm, Heidenhain 426 control, 30-tool changer (ISO 50), 4th axis, and internal cooling. Ljdpfx Ajz Tdkijhaoah It is used regularly and is in full working order.

Condition: good (used), rotational speed (max.): 2,050 rpm, rotational speed (min.): 45 rpm, type of input current: three-phase, table length: 600 mm, table width: 210 mm, Used conventional milling machine Make: Metba Model: MB-1 Features a 3-axis dimension display. Table: 600x210mm Travel: Lajdpsz Dtw Ssfx Ahaoh - Longitudinal with motor / Manual table: 290mm / 300mm - Vertical manual with bellows / without bellows: 270mm / 320mm - Vertical motorized with bellows / without bellows: 260mm / 310mm - Cross travel of the headstock, manual: 180+120mm Automatic feeds: - Vertical and longitudinal: 15 to 500 mm/min. - Slow feed: 7 mm/min. - Rapid traverse: 1200 mm/min. Speeds: 12 (From 45 to 2,050 rpm) Motor power: 5Hp (Three-phase 380V) Headstock type: Swivel / Universal (accepts arbor or vertical headstock). Common uses: Machining of small/medium-sized parts, prototyping, and maintenance or restoration work. Includes: - Vise with swivel - Collet chuck with various sets of collets - Various milling tools (See photographs of the material on the floor)

Condition: excellent (used), Year of construction: 2018, operating hours: 9,219 h, functionality: fully functional, machine/vehicle number: 2730218, travel distance X-axis: 2,500 mm, travel distance Y-axis: 1,700 mm, travel distance Z-axis: 1,500 mm, controller manufacturer: Heidenhaim, controller model: HAIDENAIN TNC 530 HSC, total height: 4,070 mm, total length: 6,800 mm, total width: 6,500 mm, table width: 1,300 mm, table length: 1,800 mm, table load: 6,000 kg, overall weight: 19,000 kg, spindle speed (max.): 3,500 rpm, operating hours of spindle: 9,219 h, number of slots in tool magazine: 32, input voltage: 400 V, type of input current: three-phase, Equipment: chip conveyor, documentation/manual, MACHINE FEATURES Model: RTX 25 TG130 Serial Number: 2730218 RTX Series Features Structure: Fixed bed and moving column. Movements: Longitudinal table and transverse column with constant support. Rotary Table: Replaces the fixed rectangular version for continuous machining operations. Head: Bi-rotational head as standard for maximum flexibility. Type: Universal milling machine with fixed bed. Applications: Precision mechanical machining and complex profiles. Construction: Designed and assembled in Turin by Goglio Milling Systems. Travels Longitudinal Travel (X-axis) 2500 RCV UL1007 Transverse Travel (Y-axis) 1700 RCV UL1007 Vertical Travel (Z-axis) 1500 RCV UL0714 Rotary Table TG-130_1300x1800 Spindle Motor Power 24 kW Maximum Spindle Speed 3500 rpm Rapid Traverse Rate X-axis (CNC) 15,000 mm/min Rapid Traverse Rate Y-Z axis (CNC) 15,000 mm/min Rapid Traverse Rate Axes (Manual) 6,000 mm/min Working Feed Rate (CNC) 10,000 mm/min Working Feed Rate (Manual) 2,500 mm/min Continuous Torque Motors X-Y Axis 36 Nm Continuous Torque Motors Z Axis 36 Nm Tool Holder Electro-hydraulic Spindle Taper ISO 50, Tool Drawbar BIR 200 Maximum Permissible Load on the Table 6,000 kg Bi-rotational Head Continuous for B-axis 0 - 360° Module Rotary Table Coupled to Hydraulic Rotating C-axis 0 - 360° continuous Machine Chiller Yes Tool Magazine 32 Positions Operating Temperature 10-40 degrees C Base Machine Mass 19000 Kg CNC HEIDENHAIN TNC 530 HSCI Lasdpfx Asyn Rdujhaoh

Condition: used, Year of construction: 2010, x-travel 2.600 mm y-travel 700 mm z-travel 700 mm control iTNC 530 Heidenhain turning speed range - main spindle 20 - 18.000 min/-1 power capacity - main spindel 35 / 25 kW tool taper SK 40 table surface area 2.900 x 700 mm max. table load 2.150 kg number of toolpositions 30 pos. tool taper SK 40 max. tool diameter 80 mm max. tool-dia with free toolbox 130 mm max. tool length 300 mm max. tool weight 6,0 kg rapid traverse ( X / Y / Z ) 40 m/min feed speeds max. 40.000 mm/min feed power max. 8 kN total power requirement 54 kVA weight of the machine ca. 14,4 t dimensions of the machine ca. 8,0 x 5,6 x 2,8 m CNC - Travel Column Milling Machine DECKEL MAHO - DMF 260 New Design - NC dividing head (A-axis) - Operating hours: 18.709h spindle run - overhauld spindle installed (Dec 2023) - Z-axis weight compensation changed (Feb 2023) - Production package - Option: tool clamping for tightening bolts Lodpfoz I T Rmex Ahaoah - WITHOUT vices!

Condition: refurbished (used), Year of construction: 2007, functionality: fully functional, travel distance X-axis: 7,000 mm, travel distance Y-axis: 1,600 mm, travel distance Z-axis: 1,400 mm, feed length X-axis: 7,000 mm, feed length Y-axis: 1,600 mm, feed length Z-axis: 1,400 mm, Complete with all assemblies required for installation and commissioning x = 7 m y = 1.6 m z = 1.4 m (800 mm + quill = 600 mm) General overhaul in 2007, year of manufacture 1991 Rapid traverse: 12,000 mm/min; w-axis: 6,000 mm/min Lodpfx Ajz Dunlehajah Fitted with new Siemens Sinumerik 840D control system, new drive motors, refurbished guideways, and new control cabinets. ECOCUT 1 was only operated for a few hours thereafter. TDV 2 rotary table, max. workpiece weight 6 t / clamping area 1,000 x 1,000 mm TDV 3 rotary table, max. workpiece weight 12 t / clamping area 1,250 x 1,600 mm Accessories: 2 right-angle milling heads / chain-type automatic tool changer / platen table / full enclosure / Knoll hopper feeding system / extraction unit / coolant system with belt filter. Supplied with all BWF fixtures required for installing the machine bed and clamping plate.

Condition: excellent (used), functionality: fully functional, travel distance X-axis: 5,000 mm, travel distance Y-axis: 1,600 mm, travel distance Z-axis: 1,500 mm, table length: 5,000 mm, table width: 1,730 mm, table height: 300 mm, Equipment: documentation/manual, Special Offer Inspected and fully functional traveling column milling machine including clamping plate SHW UF 6 L Ledpez Spn Dsfx Ahaeah Technical Data Travel distances • X-axis (bed): 5,000 mm • Y-axis (vertical): 1,600 mm • Z-axis (spindle head): 1,500 (1,200) mm Control system • CNC control: Heidenhain TNC 415 Feed rate • X, Y, and Z axes, continuously variable from: 2 – 8,000 mm/min Universal milling head in orthogonal design • Swiveling range of milling head mounting, motorized: 340 degrees • Swiveling range of milling head: 180 degrees • Tool holder: SK 50 Year of manufacture: 1992 Inspection: 2026 The machine has been put back into operation and inspected at MBM and can be demonstrated under power at D-73479 Ellwangen. About us: MBM Maschinenservice & Gebrauchtmaschinen GmbH is an independent specialist for SHW machine tools. Our main focus is on tool milling machines. Our services include, among others, the supply of spare parts, on-site customer service, machine overhauls, and control system upgrades. Services: - Used machines - Spare parts - Customer service - Machine service - Machine overhauls - Control system modernization _____ Used machine – used milling machine – used traveling column milling machine – orthogonal milling head – metalworking – tool milling machine – milling head – SHW machine – SHW spare parts – milling machine used – milling machine used – CNC milling machine used – drilling and milling machine used – milling machine metal used – metal milling machine used – used CNC milling machine – CNC milling machines – CNC milling machines – milling machine – large-part machining – large-part machining – large-part machining – CNC large-part machining – milling – shw – uf6 – uf 6 – Uniforce – SHW UF – SHW Uniforce – SHW Uniforce 6 – UFZ 6 – UFZ6L – UFZ 6 L – Heidenhain – MBM milling machine – MBM machine – column milling machine

Condition: used, Year of construction: 2008, functionality: fully functional, travel distance X-axis: 10,000 mm, travel distance Y-axis: 3,500 mm, travel distance Z-axis: 1,500 mm, rapid traverse X-axis: 25 m/min, rapid traverse Y-axis: 25 m/min, rapid traverse Z-axis: 25 m/min, feed rate X-axis: 6 m/min, spindle speed (max.): 5,000 rpm, rotational speed (max.): 5,000 rpm, total width: 11,000 mm, total height: 5,430 mm, total length: 16,630 mm, table length: 2,500 mm, table width: 2,500 mm, torque: 2,045 Nm, table load: 40,000 kg, coolant supply: 40 bar, workpiece weight (max.): 40,000 kg, grinding spindle motor power: 46,000 W, rotary table diameter: 2,500 mm, Equipment: documentation/manual, CNC HEIDENHAIN iTNC530 Drive system: SIEMENS SINUMERIK TRAVEL Longitudinal (X): 10,000 mm Vertical (Y): 3,500 mm Cross (Z): 1,500 mm Table (V): 1,500 mm Axis support: Hydrostatic FEED RATES Working feed rates: 0 – 6,000 mm/min Laedpfoz Ib Elex Ahajh Rapid traverse rates for axes Y/Z/X: 25,000 mm/min SPINDLE Ram section: 700 x 500 mm Power: 46/37 kW Rotation speed: 5,000 rpm Torque: 1,691 – 2,045 Nm Morse taper: ISO 50 ATC Number of positions: 100 CLAMPING SURFACE: Dimensions: 10,000 x 2,500 mm Load capacity: 10,000 kg/m² TABLE Surface: 2,500 x 2,500 mm Travel: 1,500 mm Resolution (B-axis): 0.001° Load capacity: 40,000 kg Support: Hydrostatic HEAD Type: TUPC Spindle taper: ISO50 A/C axis: 0.001° Maximum torque: 1,210 Nm Maximum speed: 5,000 rpm Maximum power: 46/37 kW Coolant: Internal, 40 bar HEAD 2 Type: SEELS4 Spindle taper: ISO50 Spindle extension: 400 mm HEAD CHANGING PICK-UP STATION Positions: 3 Maximum workpiece weight: 79.3 kg Machine dimensions: 16,630 x 11,000 x 5,430 mm Year of construction: 2008 ACCESSORIES: - 3-position head changer - High pressure, 40 bar - Filtration system - Chiller - Renishaw RMP60 probe - Blum tool presetter - Electrical diagrams - Perimeter guarding - Chip conveyor - Operation and maintenance manuals - CE certification

Condition: good (used), Year of construction: 2001, Boring and milling machine MECOF Performa, No. 05 01 06, year of manufacture 2001, control system HEIDENHAIN TNC 430M, X/Y/Z 2,000/1,200/1,000 mm, table 2,200 x 1,150 mm, universal milling head TBA4, dust extraction, cooling, control cabinets, filter systems. Lajdpfez Icfmox Ahaeh

Condition: used, Year of construction: 2001, functionality: fully functional, travel distance X-axis: 6,000 mm, travel distance Y-axis: 1,000 mm, travel distance Z-axis: 1,700 mm, feed length X-axis: 5,700 mm, feed length Y-axis: 1,000 mm, feed length Z-axis: 1,700 mm, position of the milling head: Testa birotativa A+B 1° + 3°, rapid traverse X-axis: 20 m/min, rapid traverse Y-axis: 20 m/min, rapid traverse Z-axis: 20 m/min, spindle speed (max.): 4,000 rpm, table length: 7,300 mm, table width: 1,090 mm, spindle motor power: 30 W, Equipment: documentation/manual, rotational speed infinitely variable, - FIDIA C20/H6 numerical control - Electronic handwheel - Operator platform - Spindle cooling system - 24-position tool magazine Laodpfx Ahezix Rweajh - 3 longitudinal tables, 1520 x 1000 x 900 mm - Splash guard enclosure - CE marking

Condition: excellent (used), Year of construction: 2015, functionality: fully functional, travel distance X-axis: 4,000 mm, travel distance Y-axis: 1,300 mm, travel distance Z-axis: 1,600 mm, Travel ranges: Longitudinal (X): 4000 mm Vertical (Z): 1600 mm Lateral (Y): 1300 mm Rotary table: Diameter: 1600 mm Maximum speed: 250 min⁻¹ Drive power (100% duty cycle): 53 kW Maximum transport load (positioning): 8000 kg Maximum transport load (rotation): 3000 - 8000 kg Work table: Length: 4000 mm Width: 1240 mm Ledpfx Ahozi S E Usaeah Height of work table: 760 mm Automatically indexing milling head: Tool interface: ISO 50, DIN 69871 AD Automatic tool clamping: Clamping force 20000 N Spindle speed range: Spindle speed: 20 - 5000 min⁻¹ Full power from 340 min⁻¹ Torque at 32 kW/S1: 900 Nm Main drive: Drive power: 43 kW Maximum rapid traverse rate: X-axis 45000 mm/min Y- and Z-axis 35000 mm/min Maximum feed force: X, Y and Z-axis 16000 N Automatic tool changer Magazine positions in M version: Maximum tool positions: SK 50 40 positions Maximum tool positions: Capto C8 20 positions Machine weight: approx. 32,100 kg Equipment: - Work table 4000 x 1240 x 760 mm with integrated rotary table Ø 1600 mm - Swiveling control panel with telescopic arm with HEIDENHAIN TNC 640 HSCI (6 axes + spindle) control, including 19" flat screen, metallic keyboard with integrated mouse and USB interface on the control panel. Processor speed 0.5 ms including HEIDENHAIN smarT.NC. - Interpolative turning with HEIDENHAIN TNC 640 HSCI consisting of CAM system, HEIDENHAIN postprocessor, software adaptation for C-axis (spindle). - Portable electronic hand-held unit HEIDENHAIN HR 520 with 5 m cable. - Automatically indexing milling head / 2 levels with 2.5° x 2.5° division and a tool clamping force of 20,000 N (H200), 32 kW / 900 Nm, tool interface ISO 50 - DIN 69871 AD. Mounting flange with Hirth gearing for adapting turning tool holders, grinding spindles or additional milling heads and a protective ring to cover the Hirth gearing; not required if H205 is selected. - Spindle drive 43 kW at 100% duty cycle via water-cooled HEIDENHAIN inline motor with direct power transmission. The motor is integrated into the milling slide. - Turning tool holder with Capto C8 interface (manual tool clamping) for turning operations incl. Hirth gearing and SK 50 interface according to DIN 69871 AD for adaptation to SORALUCE milling heads. (Semi-automatic changing with additional manual fastening by 8 x M8 screws); not required with fully automatic changing of the turning tool holder. - Pneumatically adjustable pick-up station (travel 500 mm) in the tool changer area for the turning tool holder and protective ring for semi-automatic changing. - Work table with integrated NC rotary table Ø 1,600 mm, for turning operations and for positioning operations with hydraulic clamping. - Rack and pinion drive in the X-axis via two servomotors controlled in a master-slave process.

Condition: ready for operation (used), Year of construction: 1997, travel distance X-axis: 4,500 mm, travel distance Y-axis: 1,200 mm, travel distance Z-axis: 1,000 mm, rotational speed (max.): 3,000 rpm, CNC Heidenhain TNC 426 30-tool changer SA 50 spindle with automatic tool changer Maximum spindle speed: 3000 RPM Table size: 6000 x 1100 mm Travel: 4500 x 1200 x 1000 mm Ljdpfx Aszh U Hfshajah Chip conveyor 4th axis Tooling

Condition: used, Year of construction: 2007, functionality: fully functional, travel distance X-axis: 8,000 mm, travel distance Y-axis: 2,100 mm, travel distance Z-axis: 1,300 mm, position of the milling head: 360 x 1° en 180 x 1°, spindle speed (max.): 6,000 rpm, type of input current: three-phase, total width: 9,000 mm, total height: 4,900 mm, total length: 16,200 mm, table length: 5,500 mm, table width: 2,600 mm, table load: 10,000 kg, coolant supply: 16 bar, workpiece weight (max.): 10,000 kg, grinding spindle motor power: 30,000 W, feed length W-axis: 1,000 mm, SHW Powerspeed 5 with Heidenhain iTNC530, including: • X-8,000 mm, Y-2,100 mm, Z-1,300 mm • W-1,000 mm with C-axis, with 1600 x 1600 mm (suitable for a 10T table load) • Fixed clamping table with T-slots 22 mm, 5,500 x 2,600 mm • Orthogonal machining head SK50, max. 6,000 rpm, 360 x 1° and 180 x 1° • Power P = 30 kW at 100% ED / 41 kW at 40% ED. • Tool holder SK50 according to DIN 69871/72-AD • Heidenhain measuring scales in X, Y and Z axes Lodpfxjzz Hkpo Ahajah • Chip conveyor in articulated belt design for X-8,000 mm • External and internal coolant supply with paper band filter and 1,000L clean water tank. High-pressure pump 16 bar • Air cooling along and through the spindle • Tool magazine with 48 positions SK50 (max. Ø125 mm, max 400 mm length, max. 25 kg) • Shuttle machining capability with a fixed position for the removable partition • Dimensions L x W x H = 16.2 m x 9 m x 4.9 m (from the normal floor) • Electrical connection 400V / 50 Hz / 3Ph, 65 kVA and 3 x 95A slow-blow fuse

Condition: good (used), Year of construction: 2007, CNC traveling column milling machine Manufacturer: KEKEISEN Machine model: UFF 4000/16 Control system: Heidenhain iTNC 530 Year of manufacture: 2007 TECHNICAL DATA X-axis travel: 4000 mm Y-axis travel: 1400 mm Z-axis travel (vertical): 1600 mm Table area: 4200 x 1500 mm Table load: 10 t Spindle speeds (gear stages): 20 – 7000 rpm Spindle drive: 30 kW Rapid traverse: 18 m/min Machine weight approx.: 24.0 t + table EQUIPMENT FEATURES + CNC control system HEIDENHAIN iTNC 530 with fast MC424 Lasdpfx Ahjz Ear Seajh + X-axis with hydrostatic guidance + B-axis with stepless swivel function + Air, water supply through the spindle and spray ring + Edge gap filter for water purification + Additional tank and pump for deep hole drilling at 80 bar + Minimal lubrication system + Chip conveyor with water pump and water tank + Cooling unit for hydrostatic guidance + Cooling unit for spindle and gearbox cooling + NC dividing head WALTER TABIH Evolution 320 EG, year of manufacture 11/2014, with horizontal table axis and tailstock MK6, center height 320 mm, max. Subject to changes and errors in the technical data and specifications.

Condition: excellent (used), Year of construction: 2021, operating hours: 3,000 h, travel distance X-axis: 6,100 mm, travel distance Y-axis: 2,000 mm, travel distance Z-axis: 950 mm, CNC Travelling Column Milling Machine – Fully Retrofitted by REM (2021) Powerful and versatile heavy-duty milling machine, completely modernized by REM specialists in 2021 with state-of-the-art Heidenhain TNC 320 control. Ready for immediate production use. KEY SPECIFICATIONS: • X-axis (transversal travel): 6,000 mm • Y-axis (vertical head travel): 2,000 mm • Z-axis (axial slide travel): 950 mm • Dual-spindle head | Head rotation: 360° • Spindle speed: 1,000 – 4,000 rpm • Spindle taper: ISO 50 (automatic locking/unlocking) • Head dimensions: 290 × 290 mm • Spindle motor power: 15 kW (DC) • Machine weight: approx. 32 tonnes • CNC Control: Heidenhain TNC 320 WHY BUY FROM REM? ✔ Machine fully inspected and tested in working conditions ✔ Modern CNC retrofit – new electrics, new drives ✔ Documentation and technical support available ✔ Export worldwide | Competitive shipping Laoden D N H Tspfx Ahash Ideal for heavy component machining in aerospace, energy, and heavy industry. Contact us today for full technical specifications, photos, and video demonstration.

Year of construction: 2000, condition: ready for operation (used), Travel path X/Y/Z: 1670mm/800mm/900mm, Speed: 4000rpm, Tool positions: 16, Tool holder: SK40, Table dimensions X/Y: 2000mm/900mm, Weight: approx. 4500kg, Operating hours: approx. 9680h. According to the error message, the standstill monitoring of the Z-axis is defective. Documentation available. An on-site inspection is possible. Lajdpoymfdasfx Ahash

Condition: used, Year of construction: 2010, functionality: fully functional, For sale is a powerful and precise 5-axis CNC portal milling machine from the premium manufacturer Kolb, model Studioline M. The machine is ideally suited for model making, mold making, and large-format machining. Technical data & highlights: Manufacturer: Kolb Model: Studioline M Initial commissioning: March 2010 Control system: Fidia, including handheld operating device / handwheel HPX21 Working area / travel ranges: X-axis: approx. 11,500 mm Y-axis: approx. 1,550 mm Z-axis: approx. 2,550 mm B-axis: ± 210° C-axis: ± 104° Spindle & tool: Tool holder: HSK 50A Spindle speed: max. 16,000 min⁻¹ Dynamics & drives: Linear axes (X, Y, Z): Feed rate up to 16 m/min Lasdpfoz Ahrkox Ahaeh Scope of supply & notes: Tables: Includes 2 square clamping tables. (Note: The 4 columns shown in the pictures are not included in the scope of supply.) Transport & handling: Dismantling & transport: The machine has already been dismantled; worldwide delivery is possible upon request. Loading: Will be carried out by us, free of charge. Condition & inspection: The machine is in a well-maintained condition, considering its age. An inspection is possible after prior arrangement. However, the machine has already been dismantled and is no longer powered. Subject to prior sale and errors in the technical specifications.

Condition: good (used), Year of construction: 2009, functionality: fully functional, travel distance X-axis: 10,000 mm, travel distance Y-axis: 1,600 mm, travel distance Z-axis: 3,800 mm, ZAYER MOVABLE COLUMN MILLING MACHINE TECHNICAL SPECIFICATIONS Model: 30KCU 10000 AR CNC: Siemens 840D X: 10,000 mm Y: 1,600 mm Z: 3,800 mm Rotary table: 2500 x 2500 mm 2 T-slot tables: 2500 x 2000 and 4000 x 2500 mm Tool magazine: 60 positions Automatic head: 0.001º Motorized cabin for the operator PRICE AND FURTHER INFORMATION AVAILABLE UPON REQUEST (CNC, SIEMENS, HASS, LAGUN, FAGOR, CINCINNATI, HEIDENHAIN, MACHINING, Lasdpfozzxntex Ahaoh PINACHO, MORISEIKI, MILLING MACHINE, LATHE, GRINDER, BORING MACHINE, PRESS, LASER, SHEAR, PRESS BRAKE)

Condition: refurbished (used), Year of construction: 1997, travel distance X-axis: 6,500 mm, travel distance Y-axis: 1,780 mm, travel distance Z-axis: 1,400 mm, spindle speed (max.): 16,000 rpm, total width: 4,000 mm, total height: 5,000 mm, total length: 11,000 mm, table length: 6,000 mm, table width: 1,500 mm, spindle motor power: 7,500 W, Very Clean 5-Axis Machining Center Axis motors and the control unit were replaced in 2022 with a Fagor 5-axis module. X - 6500mm Y - 1780mm Z - 1400mm A - 200 degrees Lajdpfx Aezl H Trjhaeh C - 400 degrees Max. Speed: 20000mm/min RPM: 16000 HSK63A Taper

Condition: used, Year of construction: 1990, x-travel 6000 mm y-travel 1670 mm z-travel 1050 mm spindle taper ISO 50 Control Heidenhain Table dimensions 8000x1030 mm table height 765 mm spindle drive 22 kW spindle turning speed range 16-1600 U/min Feed 5-2500 mm/min rapid traverse 7500 m/min weight of the machine ca. 20 t The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale; Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop Lajdpsyqvpujfx Ahajh If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team
