Used Universal Machining Center for sale (68,087)

Condition: ready for operation (used), Year of construction: 2004, operating hours: 61,082 h, functionality: fully functional, travel distance X-axis: 2,800 mm, travel distance Y-axis: 1,200 mm, travel distance Z-axis: 800 mm, controller model: HEIDENHAIN TNC 426, Equipment: chip conveyor, In January 2025, a new spindle was installed! The machine has been regularly maintained! TECHNICAL DETAILS Travel range X-axis: 2,800 mm Travel range Y-axis: 1,200 mm Travel range Z-axis: 800 mm Feed rates Rapid traverse: 35,000 mm/min Spindle speed S1 (continuous duty) Vertical: 10,000 rpm Spindle speed S1 (continuous duty) Universal swivel head, 2 axes: 18,000 rpm MACHINE DETAILS CNC Control: HEIDENHAIN TNC 426 Electrical data Supply voltage: 400 V (–15 %, +10 %) Frequency: 50 Hz Current draw: 101.1 A Installed total power: 59.8 kW Operating hours Power-on hours: 98,755 h Hodpfxey Dgyfj Amiol Program run time: 61,082 h EQUIPMENT High-rigidity gantry design from the FPT DINO series Precision linear guides and ball screws Spacious work area with 2.8 m X-axis travel High feed rates for efficient machining Ideal for tool, mold, and machine construction Includes documentation and acceptance certificate according to ISO standards Tool changer Coolant system Chip conveyor Interchangeable milling head with 4th/5th axis

Condition: excellent (used), Year of construction: 2007, functionality: fully functional, travel distance X-axis: 1,250 mm, travel distance Y-axis: 660 mm, travel distance Z-axis: 540 mm, rapid traverse X-axis: 40 m/min, rapid traverse Y-axis: 40 m/min, rapid traverse Z-axis: 32 m/min, feed rate X-axis: 32 m/min, feed rate Y-axis: 32 m/min, feed rate Z-axis: 32 m/min, controller manufacturer: Okuma, controller model: OSP P200M-H, rotary table diameter: 500 mm, Equipment: chip conveyor, documentation/manual, rotational speed infinitely variable, Okuma MU500VA CNC Vertical Machining Centre (2007) Hodpeyf Ncqsfx Amisl Equipped with OKUMA OSP P200M-H CNC CONTROL 20" ROTARY PLATEN 4TH AND 5TH AXIS BUILT IN TRUNION 32 POSITION AUTOMATIC TOOL CHANGER COOLANT THRU SPINDLE TOOL LENGTH MEASURING Travels X-axis (saddle left/right) – 1250mm, Y-axis (pallet front/back) – 660mm, Z-axis (spindle up/down) – 540mm, A-axis – +20~-110 deg., C-axis – 360 deg., Table surface to spindle nose – 127~667mm Table Table size – ø500mm, Max work size – ø730xh500, Floor to table top – 1073mm, Max load capacity – 500kg Spindle Spindle speed – 15000rpm, Turning specification – C-axis table 1000rpm , No. of spindle ranges – Infinitely variable, Tapered bore – 7/24 taper No.40, Bearing dia – ø70mm Feed Rapid traverse – X-Y: 40m/min, Z:32m/min, Rapid traverse (A-C) – 18,000 deg/min, Cutting feed rate – X-Y-Z: 32m/min Motors Spindle (10min/cont) – 11/7.5kW ATC Tool shank type – MAS BT40 Big plus, Retention knob type – MAS 2, Tool capacity – 32, Max. tool dia (w/ adjacent tool) – ø90mm, Max. tool dia (w/o adjacent tool) – ø125mm, Max. tool length – 400mm, Max. tool mass – 8kg, Tool selection – Memory random ATC Retention knob type – MAS 2, Tool capacity – 32, Max. tool dia (w/ adjacent tool) – ø90mm, Max. tool dia (w/o adjacent tool) – ø125mm, Max. tool length – 400mm, Max. tool mass – 8kg, Tool selection – Memory random

Condition: excellent (used), Year of construction: 2005, functionality: fully functional, Equipment: chip conveyor, documentation/manual, rotational speed infinitely variable, Deckel Maho Machining Center 5-Axis Simultaneous Machining Model DMU 50 Evo Linear Year 2005 Hsdpfx Asy Hqvijmiol CNC Heidenhain iTNC 530

Condition: used, Year of construction: 2004, frequency 50 Hz weight of the machine ca. 2,510 t 3-axis machining centre Microcut Challenger 2412 Technologies: Drilling / thread machining, form milling (3 D), milling, HSC milling without vice Table Size: 30" x 14.3" Max Table Load: 550 LBS X Axis: 24" Y Axis: 12" Z Axis: 20.47" Hedpsxgv D Asfx Amisl Spindle Speed: 8,000 RPM Spindle Taper: 40 Spindle Motor: 5.5 HP ATC: 16

Condition: used, Year of construction: 2009, Technical details: x-travel: 600 mm y-travel: 770 mm z-travel: 675 mm total power requirement: 47 kW weight of the machine ca.: 13 t Tool bore: HSK-A63 numbers of tools in magazin: 40 including additional tool magazine ZM 182 1 spindle , 5 axes Hodpfx Ameqy Sr Seiol *

Condition: excellent (used), Year of construction: 2008, operating hours: 29,000 h, functionality: fully functional, MANDELLI Storm 2500 Horizontal Machining Center / Flexible Manufacturing Cell Manufacturer: Mandelli Sistemi S.p.A. Model: Storm 2500 Type: U 42 / 8000 Factory No.: XXXX Year of manufacture: 2008 Origin: Italy Control: Siemens Sinumerik 840D System Control: CswWin / Beckhoff Industrial PC Condition/Maintenance: Very good / Single-shift machine / Very low operating hours Technical Data: X-axis travel: 2,600 mm Y-axis travel: 1,500 mm Z-axis travel: 1,800 mm B-axis: 360,000 positions / continuous APC / Pallet axis: 360,000 positions Rapid traverse linear axes: 35 m/min B-axis speed: 8 rpm Accuracy to VDI 3441: Positioning accuracy P: 10 µm Repeatability Ps: 5 µm Spindle / Head: U-head horizontal / vertical Spindle taper: ISO SK 50 Speed range: 37 – 6,000 rpm Spindle power: 44 kW Max. torque: 706 Nm Tool Magazine: 208 tool positions Rack tool magazine with automatic tool handling Max. tool length: 600 mm Max. tool diameter: 450 mm Max. tool weight: 35 kg Pallet System: Front transpallet / automatic pallet change system 6 pallets, each 1,000 x 1,250 mm 4 fixed stations Rotary unit for loading and unloading workpieces Electrical Data (as per nameplate): System: S2500 / 840D Rated voltage: AC 400 V, 3 Ph / PE Frequency: 50 Hz Current at full load: 178 A AC auxiliary voltage: 230 V DC auxiliary voltage: 24 V Standard: IEC 60204-1 / EN 60204-1 Chip Conveyor: Manufacturer: Meta Year of manufacture: 2007 Weight: approx. 1,100 kg Additionally, a screw conveyor is visible in the machine area. Equipment / Peripherals: Filtration unit Hydraulic power unit Chip conveyor Screw conveyor COSEMA peripheral unit Hjdpoy H D R Tsfx Amijl Control cabinet system Coolant and lubricant periphery Separate operator panel Comprehensive pallet system Clamping Devices / Fixtures: Multiple heavy-duty angle plates, fixture plates, t-slotted/platen clamping plates, customer-specific clamping devices, and pallet setups are available. Tools / Accessories: Numerous SK50 tool holders, boring bars, boring tools, milling holders, drill and reaming tool holders, extensions, adapters, as well as various spare and standard tools are visible. Several hundred additional tool holders can be purchased on request. Optional / On Request: Apfel tool cabinets with extensive tool inventory Additional clamping devices and fixtures ELBO CONTROLLI tool presetting unit Workbenches / tool storage / racking systems by agreement The machine is in good, production-ready condition. This is a heavy-duty horizontal machining cell for the flexible complete machining of large and complex workpieces. The work area shows normal signs of wear characteristic of a production heavy machining system. The system must be removed from the facility in June 2026. Earlier availability possible by arrangement. Inspection under power is possible by appointment. All information provided to the best of our knowledge. Subject to errors, prior sale, and technical modifications.

Condition: used, Year of construction: 2003, Technical details: x-travel: 2300 mm y-travel: 1200 mm z-travel: 600 mm turning speeds: 30-10.000 1/min max. torque on the spindle: 254 / 159 Nm control: HEIDENHAIN TNC 430 tool taper: SK 40 tool change unit: 60 Pos. Hedpfx Amjwltwmeiol spindle: 40 / 25 kW fixed working table:surface area: 1.100 x 1.100 mm rotary table: 1.100 x 1.100 mm rapid traverse: 30 m/min total power requirement: 69 kVA weight of the machine ca.: 20 t universal machining center with indexing head (2,5°), NC-rotary table, max. table load 1.500kg, internal coolant supply 30 bar, paper filter, el. handwheel, chipconveyor, automatic doors, flush gun, no touch probe available, approx. 81.400 h main swich on approx. 72.200 h control on approx. 26.700 h program running on machine under power , for functional testing *

Condition: used, Year of construction: 2009, x-travel 800 mm y-travel 700 mm z-travel 550 mm Control Heidenhain TNC 530 Hodpfjy Hxrrox Amiol

Condition: reconditioned (used), Year of construction: 2001, functionality: fully functional, Universal Milling & Drilling Machine DECKEL MAHO DMU 50 M Equipped with Heidenhain TNC 310 control Year of manufacture: 2001 Travel paths: X 500, Y 400, Z 400 mm Speed range: 20 – 4,500 rpm, infinitely variable Includes the following accessories: Manual swivel rotary table with digital display for C + B axes Hodpfsy Id Stex Amisl Clamping surface: 700 mm x 500 mm Electronic handwheel for X, Y, Z axes Splash guard enclosure Machine lamp 4 adjustable-height machine feet Coolant system Operating manual

Condition: excellent (used), Year of construction: 2016, HEIDENHAIN TNC620 control with B + C axis Working travels 750 x 620 x 520 mm Table swivelling -10°/+95° Table rotating 360° Spindle taper SK40 Spindle speeds 20-12'000 rpm tool changer 32 pos. Hjdpfxjy Hq Avo Amiol Coolant through spindle 3D Measuring taper Tool lenght measuring device Tool breakage control device Chip conveyor Misc. accessories MARCELS MASCHINEN CH

Condition: as good as new (ex-display), Year of construction: 2025, travel distance X-axis: 3,000 mm, travel distance Y-axis: 1,500 mm, travel distance Z-axis: 1,400 mm, rapid traverse X-axis: 30 m/min, rapid traverse Y-axis: 30 m/min, rapid traverse Z-axis: 30 m/min, workpiece weight (max.): 6,000 kg, rotational speed (max.): 10,000 rpm, tool length: 800 mm, New machine HDC3000 with 6 axes • Travel ranges: X=3000 mm, Y=1500 mm, Z=1400 mm • Heidenhain iTNC 640 with handwheel • NC rotary table for 5-sided machining 1250 mm x 1600 mm • 2-axis NC universal drilling and milling head, fully simultaneous and positioning operation • Spindle 10,000 rpm HSK100, S1=220 Nm spindle torque • Tool change system HSK100 / 60 stations – 800 mm tool length • Chip conveyor • Optimized for 5-sided machining including deep hole drilling • Coolant supply system • Internal/external air blow-off device • ICS 60 bar for deep hole machining • Fully enclosed Hedpfxsy Hmhno Amijl • Large interference circle 2300 mm • Including mounts • Including wash gun • Including warranty • Short delivery time, subject to prior sale

Condition: good (used), Year of construction: 2011, operating hours: 54,900 h, functionality: fully functional, travel distance X-axis: 7,350 mm, travel distance Y-axis: 650 mm, travel distance Z-axis: 560 mm, controller manufacturer: Heidenhain, controller model: iTNC 530 HSCI, table load: 600 kg, rotational speed (max.): 18,000 rpm, Equipment: chip conveyor, Motor spindle SK 40 Tool holder for HSK-A63 Infrared measuring probe ICS 40 bar Electronic handwheel iTNC 530 Hodpfx Amjy Hh T Seisl

Condition: used, Year of construction: 1998, functionality: fully functional, Equipment: chip conveyor, documentation/manual, rotational speed infinitely variable, Deckel Maho Machining Centre 5-Axis Simultaneous Hodpfjy D Nfdox Amijl Type DMU 80 P Year 1998 Heidenhain CNC With Tooling

Condition: good (used), Year of construction: 2018, functionality: fully functional, Technical details x-travel 540 mm y-travel 635 mm z-travel 400 mm weight of the machine ca. 10,2 t dimensions of the machine ca. 2,9 x 2,9 x 3,1 m Additional information Röders RXP 601 DSH – 5-Axis High-Precision Milling and Grinding Center Machine hours: 1294 (5. March 2026) General Machine Data Manufacturer: Röders TEC GmbH (Germany) Machine Type: 5-Axis CNC Milling and Grinding Center Model: RXP 601 DSH Design: Vertical High-Speed Machine Axis System: X / Y / Z + A / C Drive System: Direct drives in all linear and rotary axes Measuring Systems: Optical direct measuring systems in all axes Thermal Management: Active temperature stabilization of all main components Workspace & Mechanics X-axis travel: 540 mm Y-axis travel: 635 mm Z-axis travel: 400 mm A-axis swivel range: ±115° C-axis continuous rotation (360°) Max. workpiece weight: up to 200 kg Machine weight: approx. 10200 kg Space requirement (L×W×H): approx. 2950 × 2950 × 3100 mm Spindle system Spindle manufacturer: Levicron Spindle type: High-precision air-bearing milling and grinding spindle Bearing: Air bearing, operating pressure up to 10 bar Tool holder: HSK 25 (HSK-E depending on the version) Application: High-speed milling and precision grinding Thermal properties: Virtually frictionless, minimal heat input Grinding equipment: • Integrated grinding function in the CNC control • Optimized axis control for grinding processes • Vacuum Z-axis compensation to relieve stress on the Z-axis Hsdpfxey Emwte Amijl • Thermally stabilized Z-axis for maximum dimensional accuracy • Suitable for coordinate, profile, and fine grinding Peripheral systems: Extraction: Industrial extraction system for milling and grinding operations Oil treatment: Filter and treatment system for Grinding oil Cooling lubricant Temperature control Chip disposal Oil-based grinding medium Active media temperature control Integrated screw conveyors All information provided to the best of our knowledge, subject to technical modifications.

Condition: excellent (used), Year of construction: 2005, operating hours: 34,041 h, functionality: fully functional, travel distance X-axis: 3,000 mm, travel distance Y-axis: 900 mm, travel distance Z-axis: 850 mm, controller manufacturer: Heidenhain, controller model: iTNC530, table width: 850 mm, table length: 3,000 mm, rotary table diameter: 630 mm, spindle speed (max.): 11,000 rpm, operating hours of spindle: 11,100 h, coolant supply: 40 bar, spindle nose: SK 40, number of slots in tool magazine: 36, Equipment: chip conveyor, rotational speed infinitely variable, Very well-maintained AXA travelling column machining centre with comprehensive equipment. Only 11,000 spindle hours! Automatic B-axis +/-90 degrees. Integrated NC rotary table DM630mm. Table size: 3000 x 850mm. Heidenhain iTNC530 with handwheel. Through spindle coolant 40 bar with paper band filter. 11,000 rpm with SK40. 36 tools. Analog 3D probe. Oil mist extraction. Price without clamping devices and tool holders. Hjdpfxjy Ib Dts Amiol

Condition: used, Year of construction: 2023, operating hours: 1,285 h, QUASER UX_500 C 23.12.2025 Year of manufacture: 2022, Commissioned: 2023, Like-new, flawless condition, Only 1,285 production hours Hodpfx Asy D T H Eemiol Standard Specification: - Siemens 828 D PPU29 control with 15" touchscreen - Adjustable operator panel (tiltable and rotatable) - Heat exchanger for climate-controlled electrical cabinet - Tool system: SK40_BigPlus, suitable for holders with/without face contact according to DIN 69871 - Pull studs according to DIN 69872 - Portable electronic handwheel - Double-arm tool changer with 30 stations - Pneumatically actuated tool change door - Direct position measuring system on rotary axis - Direct position measuring system on tilting axis - Infrared receiver for workpiece and tool measurement - Three-color signal beacon - Coolant spray gun - External air blast for dry machining - Automatic central lubrication for ball screws - Computer-optimized, heavy machine base from heavily ribbed cast iron - Sturdy and rigid portal-type machine design - Chip disposal consisting of work area chip flushing system with Grundfos pump (75 L/min at 3 bar) - Chip channels made of stainless steel - Two auger conveyors in the work area - Full work area protection with two corner view windows and two work lights - Flood coolant with 4 ring nozzles at spindle nose, Grundfos pump (75 L/min at 3 bar) - Machine color: RAL 7035 light grey - Coolant tank, spindle headstock, and doors painted RAL 9005 deep black Existing Siemens options: - SW option: Kinematic measurement cycle 996 for Siemens 828 D - Cycle for measuring the center point of rotary and tilting axes - SW option: In-process measuring cycles for Siemens 828 D - Measurement cycles for automatic workpiece inspection/measurement - Workpiece zero-point probing with infrared 3D probe - Operating manual UX500 Siemens 828 D - SW option 3D simulation - Network drive management Further details, including video, available upon request by email.

Condition: good (used), Year of construction: 2014, Ref. -No.: 10553 Manufacturer: HANDTMANN / BAVIUS Type: HBZ Trunnion 120 Year of construction: 2014 Type of control: CNC-Steuerung Control: Heidenhain TNC 640 Storage location: Halberstadt Country of origin: Germany Machine-No.: 200XXXXX X-Travel: 1270 mm Y-Travel: 1100 mm Z-Travel: 900 mm Table Height: Ø 1200 mm Table Load: 2000 kg Max. Tool Weight: 20 kg Max. Tool Length: 90 x 200 / 24 x 400 mm Max. Tool Diameter: Ø 130 mm Tool Taper: HSK 100 Numbers Of Tools In Magazin: 40 Tool Piece Magazine With: 140 Pcs./pcs. Hedpfx Asx Hn A Temisl Spindle Turning Speed - Stepless: 14.000 RPM Max. Torque: 15000 Nm Rapid Traverse X-Axis: max. 60 m / min Rapid Travel Y-Axis: max. 60 m / min Rapid Traverse Z-Axis: max. 60 m / min Machine length: 7500 mm Machine width: 5500 mm Machine Height: 3500 mm Weight Of The Machine Ca.: 26 t Rapid traverse C-axis: max. 25 RPM Rapid traverse A-axis: max. 20 RPM A-axis (swivel axis): - 30 / + 120 ° C-axis (rotary table axis): 360 ° Further information: - Horizontal machine, Y-axis arranged vertically - Machine stand designed as a welded construction - set up on height-adjustable precision wedge shoes, chip tray with cooling lubricant device, for external splash water cooling capacity: approx. 400 liters, with clean water pump, LP circuit, approx. 40 1/min at approx. 5 bar and rinsing nozzles on the Z-axis and/or the spindle - Complete safety housing - Stainless steel interior lining - Work area lighting - Manual loading door to the work area with polycarbonate safety window with glass front panel - Side viewing window to the work area with polycarbonate safety pane with glass front pane - Maintenance area freely accessible - HSK 100 hollow shank taper - Tool clamping via springs, tool release hydraulically - Tool clamping control - Cone cleaning - incl. spindle orientation The machine can be viewed under power by arrangement.

Condition: good (used), Year of construction: 2010, Ref. -No.: 10530 Manufacturer: DöRRIES - SCHARMANN Type: Alpha 1000 Year of construction: 2010 Type of control: CNC Control: Siemens SINUMERIK 840 D Storage location: Halberstadt Country of origin: Deutschland X-Travel: 2000 mm Y-Travel: 2000 mm Z-Travel: 2000 mm A-Axis: 0 - 90 x 0,001 ° B-Axis: 360 x 0,001 ° Number of T-slots: 1 + 8 Max. Workpiece Weight: 5000 kg T - groove width: 22 mm Hjdpfx Aoy Ed Ehomijl T - slot spacing: 100 mm T-Slots: DIN 650 mm Tool Taper: HSK - A 100 Tool Piece Magazine With: 207 + 10 Pcs./pcs. Max. Torque: 1250 Nm Feed Speeds X/Y/Z Axis: 1 - 30000 mm / min Rapid Travel X/Y/Z: 30,00 mm / min Drive Capacity - Spindle Motor: 45 kW Total Power Requirement: 100 kW Dimensions Of The Machine Ca.: 13 x 8 x 4,5 m Size Of Pallet: 2 x 1000 x 1000 mm Spindle speed gear stage 1: 1 - 1096 1 / min Spindle speed gear stage 2: 1096 - 6000 1 / min Further information: - Measuring probe - Chip conveyor - Coolant system - Coolant through the spindle - Pallets with 5-way media connection and clamping hydraulics - Extraction system - Swivel spindle A-axis 0 - 90 - NC rotary table B-axis

Condition: excellent (used), Year of construction: 2011, functionality: fully functional, travel distance X-axis: 885 mm, travel distance Y-axis: 600 mm, travel distance Z-axis: 600 mm, rapid traverse X-axis: 90 m/min, rapid traverse Y-axis: 90 m/min, rapid traverse Z-axis: 90 m/min, controller manufacturer: Heidenhain, controller model: iTNC 530, rotary table diameter: 750 mm, spindle speed (max.): 18,000 rpm, spindle nose: HSK63, number of slots in tool magazine: 60, Equipment: chip conveyor, rotational speed infinitely variable, Machine Description: 5-axis machining center with extensive equipment and linear drives on all axes. Well-maintained and fully operational. Current run times: Program ON: 27,011 h / Machine ON: 57,198 h / Spindle ON: 24,324 h Travel Paths and Speeds: X-axis (longitudinal): 885 mm Y-axis (cross): 600 mm Z-axis (vertical): 600 mm Feed rate on all axes: 90,000 mm/min Clamping Table / NC Rotary Table: NC rotary table diameter: 750 mm Table load capacity: 800 kg Hsdpsy Hix Njfx Amisl Control: Heidenhain iTNC530 with electronic handwheel Spindle and B-Axis: Speed range: 50 – 18,000 rpm Tool holder: HSK63 Spindle power: 35 kW (S1) Torque: 80 Nm (S4) NC-controlled B-axis: +110° / -10° Coolant System and Chip Disposal: External coolant with nozzles: 4 bar Internal coolant: 40 bar External air: yes Internal air: yes Paper band filter: yes Chip conveyor: yes Automatic Tool Changer: Tool holder: HSK63 Number of positions: 60 Machine Weight: Weight: approx. 10,900 kg Additional Equipment and Accessories: Heidenhain direct measuring system with air purge on all axes iR probe by M&H Tool measurement with Blum laser Chip flushing gun Work area rinse system Machine documentation

Condition: like new (used), Year of construction: 2023, functionality: fully functional, DMG CMX 50 Year of manufacture: 2023 Spindle hours: approx. 1,300 h Spindle: 15,000 rpm inlineMASTER Tool holder: SK40 Tool stations: 30 slots Control: Siemens 840D sl X travel: 500 mm Y travel: 450 mm Z travel: 400 mm Weight: 4,700 kg Hjdpjy Em Ursfx Amiel

Condition: good (used), Year of construction: 2012, Control Heidenhain iTNC 530 Working area: 800 mm x 1020 mm x 970 mm (x/y/z) Table diameter: 630 x 630 mm Table load: 700 kg Hjdpfxjrx N Tzs Amiol Workpiece diameter - max.: 900 mm Rotary table (A-/B-axis) A-axis: -185 / +45 ° B-axis: 360 ° Total power requirement: 42 kVA Machine weight approx.: 22 t Chip conveyor Belt filter system - Motor spindle: 16,000 rpm Drive power: 25/35 kw Max. Torque: 160/223 Nm Spindle holder: HSK-A63 Tool changer: 120-position - Measuring probe - Kinematics package - Tool length checking device - BLUM laser measuring system Tool monitoring - electric handwheel - Suction - 80 bar IKZ system

Condition: excellent (used), Year of construction: 2011, Verfahrwege: X850 x Y500 x Z610 mm 2-Achsen Schwenk-Rundtisch FIBRO HEIDENHAIN iTNC 530 Tischdurchmesser 400 mm HEIDENHAIN Messlineale x,y,z Sperrluft Handrad HR-410 Wasserpistole Hauptspindel 12.000 Upm mit Direktantrieb 10/17 kW Luftkühlung durch die Spindel 40-fach Werkzeugwechsler SK 40 Hsdpfxeg N Adbo Amijl Schneckenförderer links und rechts Späneförderer Vertikale Schutzabdeckung aus Stahllamellen bis zum Dach M&H Infrarot Messtaster

Condition: used, Year of construction: 2004, Technical details: x-travel: 750 mm y-travel: 600 mm z-travel: 520 mm table surface area: D 700 x 500 mm turning speeds: 30000 1/min tool taper: HSK E50 control: HEIDENHAIN iTNC 530 tool change unit: 60 pos. rapid traverse: 50 m/min table load capacity - central/maximum: 350 kg total power requirement: 50 kVA weight of the machine ca.: 9 t dimensions of the machine ca.: 3,2 x 2,65 x 2,8 m 5-axis simultaneously HSC-machining center, Hedpfx Amoy D Tvmeijl NC-round-swivelling table B-axis 180°, C-axis 360°, chip conveyor, prepared for 3D touchprobe HEIDENHAIN TS 641 (without touchprobe), mode 4, spindle chiller, no internal coolant supply, approx. 124.200 hours "machine on", approx. 60.600 hours "spindle on" in total *

Condition: excellent (used), Year of construction: 2016, operating hours: 10,250 h, functionality: fully functional, travel distance X-axis: 800 mm, travel distance Y-axis: 800 mm, travel distance Z-axis: 550 mm, rapid traverse X-axis: 60 m/min, rapid traverse Y-axis: 60 m/min, rapid traverse Z-axis: 60 m/min, table width: 800 mm, table length: 630 mm, table load: 1,400 kg, overall weight: 12,500 kg, spindle speed (min.): 20 rpm, spindle speed (max.): 18,000 rpm, operating hours of spindle: 10,250 h, coolant supply: 80 bar, Equipment: chip conveyor, documentation/manual, rotational speed infinitely variable, For sale: Hermle C42U Dynamic in excellent, well-maintained condition. Travel Paths: X: 800 mm Y: 800 mm Z: 550 mm A: +/-130 degrees C: 360 degrees Equipment: Control: Heidenhain TNC 640 Spindle interface: HSK-A63 Spindle speed: 18,000 rpm Large machine table: 800 mm x 630 mm Swivel rotary table with tandem drive C-axis with torque drive Dynamic version linear axes IKZ (internal coolant supply) 80 bar with variovalve Scraper belt conveyor Tool changer plus Additional tool magazine ZM50 for a total of 92 tool stations Hedsyma Nkjpfx Amijl Manual cabin door Manual cabin roof Laminated safety glass window Comfort operator panel External minimum-quantity lubrication Tool measurement A2 Blum (tool breakage/measurement) 3D probe M&H Internal air blow External air blow Bed flushing Handte Compact extraction unit Electronic handwheel Purge air for glass scales Electronic thermal compensation with control functions HIMS basic package Special stop block Interpolation turning TNC 640 Rotoclear visibility aid and more… The machine can be inspected under power by prior arrangement. Machine is immediately available! Loading will be handled by us!

Condition: excellent (used), Year of construction: 2001, x travel 1600 mm y travel 1000 mm z travel 780 mm - number of processing axes (excl parallel axes) 5 - X-axis travel 1600 mm - Y-axis travel 1000 mm - Z-axis travel 780 mm Hsdpsy Ez Elefx Amijl - table surface (left-right) 1000 mm - table surface (front-back) 1000 mm - workpiece load (max) 6000 kg - - positioning/indexing 0.001 ° - - positioning/indexing 2.5 ° - - positioning/indexing 2.5 ° - spindle revolutions (max) 2500 /min - drive power 22 kW - number of positions 60 - number of store positions 2 - pallet length 1000 mm - pallet width 1000 mm - number of pallets 2 - space requirements -left/right- 6400 mm - space requirements -front/back- 6900 mm - total height 4000 mm - total weight approx. 26000 kg control HEIDENHAIN TNC 426 The machine is in very good condition and available immediately.
