Used Universal Surface Grinding Machine for sale (66,274)

Year of construction: 1998, condition: good (used), CHEVALIER FSG 1640 AD SURFACE GRINDING MACHINE MAKE CHEVALIER, MADE IN TAIWAN MODEL FSG-1640 AD YEAR 1998 TABLE SIZE 1000 x 400 mm Kwedpfsirfpgox Afzet GRINDING WHEEL SIZE 445 mm TRAVERSES 400 x 1000 mm MAX HEIGHT FROM TABLE TO SPINDLE CENTRE 445.0 mm TOTAL POWER REQUIRMENT 7.4 kW PLUS AUTOMATIC DOWN FEED WHEEL-MOUNTED WHEEL DRESSER SYSTEM HYDRAULIC MOVEMENT COOLANT SYSTEM 400.0 x 1000.0 mm ELECTRO MAGNETIC CHUCK MACHINE MANUALS

Condition: good (used), Jones & Shipman 540 surface grinder Power raise & lower Kwjderpi I Ejpfx Afzjt C/w a 460 x 150 mm close pole magnet, Dust extraction Calibration : TBC execution.

Condition: excellent (used), Jones & Shipman 624 Dominator CNC Surface Grinder Under power and working. Can be shown demonstrating at our premises in Burscough Fanuc Series 210i-M CNC Control Table Length 600mm x 200mm width Kjdpfsu D H Uhex Afzswt Wheel diameter 250mm Wheel width 25mm Max wheel speed 3200rpm Spindle power 5.6kw

Condition: excellent (used), Year of construction: 1977, grinding diameter 350 mm grinding length 1000 mm centre height 100 mm grinding wheel diameter 360 mm weight of the machine ca. 3,8 t Ksdpfx Afsunt Eyjzowt dimensions of the machine ca. 3,5 x 1,3 x 1,5 m Machine in very nice condition, external + internal spindle, many accessories.

Condition: excellent (used), Year of construction: 1997, grinding diameter 80 - 250 mm grinding length 600 mm centre height 175 mm longitudinal feed 750 mm workpiece turning speeds 6 - 600 U/min grinding spindle speed 1500 - 3600 U/min cross movement - autom. and by hand 320 mm Control Kelco 80 weight of the machine ca. 4,4 t Kwsdpfsyb S Rcjx Afzet dimensions of the machine ca. 3,1 x 2,1 x 2,0 m

Condition: new, Year of construction: 2025, cutting speed 35 m/s grinding height 210 mm workpiece length / mm weight of the machine ca. 210-260 kg required space 1100 x 760 x 860 mm The G115 Surface Grinder is a compact grinding machine designed for processing the circumference or face of the grinding wheel on the horizontal or vertical surfaces of a workpiece. Using fixtures or shaped grinding wheels, inclined or shaped surfaces can also be processed. The machine is ideal for small businesses, maintenance industries, home workshops, laboratories, teaching demonstrations, and more. TECHNICAL DATA Maximum cutting amount: not greater than 0.03 mm Maximum linear speed of the grinding wheel: 35 m/s Table size: 152×304 mm Maximum grinding height: 210 mm Longitudinal stroke of the worktable: 340 mm Transverse travel of the worktable: 170 mm T-slot of the worktable: 1-12 mm Outer diameter × inner diameter × thickness of the grinding wheel: 180×32×13 mm Grinding head motor: 550 W/220 V Vertical feed handwheel interval: 0.025 mm Lateral feed handwheel interval: 0.02 mm Net weight / Gross weight: 210/260 kg Machine dimensions: 930×780×730 mm Package size: 1100×760×860 mm FEATURES The worktable can be moved back and forth as well as left and right. The grinding head can be raised and lowered vertically. High rigidity of the entire machine. The grinding head runs smoothly. Compact design with low noise. The machine is lubricated by a manual oil pump. To lubricate, simply pull out the handle. Work cabin is available separately. If you need any other special accessories to improve work efficiency, please contact customer service. (Special accessories must be purchased separately.) Kwsdpsvuuvkofx Afzst PRODUCT INFORMATION: From the proximal end of the main spindle to 100 mm, the radial runout of the tapered hole axis is 0.01~0.02 mm.

Condition: used, grinding length / mm grinding width / mm workpiece height / mm total power requirement / kW Ksdpfx Aoxxb Nbsfzswt weight of the machine ca. / t required space / m

Condition: used, Year of construction: 2012, grinding length 1000 mm grinding width 600 mm workpiece height 400 mm table-size 1.100 x 500 mm max. table load 1.000 kg dist. center of grinding spindle - table 600 mm table travel longitudinal 1400 mm table travel cross 550 mm table feed 1 - 30 m/min turning speed range - grinding wheel 1.000 - 3.000 U/min power capacity - grinding motor 11,0 kW grinding wheel size 400 x 80 x 127 mm magnetic clamping plate 1000 x 500 mm dressing device Tischabrichter voltage 400 V total power requirement 21 kW weight of the machine ca. 6,0 t dimensions of the machine ca. 4,30 x 2,95 x 2,55 m band filter unit 1,80 x 1,30 x 0,80 m Kjdpeya Ihhjfx Afzjwt hydraulic power unit 0,90 x 0,75 x 0,95 m suction device 1,10 x 0,60 x 0,70 m - Serial-No.: Available at end of january 2026 - autom. vertical feed - table dresser with compensation - electr. hand wheel - paper band filter unit with magn. separator - coolant mist extraction unit

Condition: good (used), Year of construction: 1984, Machine is in good working codition. Kodpfx Afjxvikuezjwt

Condition: excellent (used), Year of construction: 1996, grinding length 600 mm grinding width 350 mm total power requirement 7,5 kW Q U O T A T I O N We are pleased to offer you ex our stock, subject to prior sale, and error in technical data : GEIBEL & HOTZ CNC horizontal surface & profile grinding machine model FS 635 - Z CNC year 1996 Grinding length max. (table movement 660 mm) 600 mm Grinding width max. (cross movement 360 mm) 350 mm Mounting height under new grinding wheel 375 mm Distance table – center of spindle min / max 140 – 525 mm Standard size of magnetic plate 600 x 350 mm Table size 820 x 350 mm Max. table load 400 kg Table speed 5 – 35.000 mm/min Cross movement, intermittently 3 – 40 mm Cross-/Vertical quick feed 5 m/min Grinding wheel measurements 300 x 50 x 76,2 mm Grinding spindle speeds, variable 1.000 – 3.000 rpm Grinding spindle-drive approx. 7,5 kW Total electrical load approx. 15 kW - 400 V - 50 Hz Weight approx. 2.600 kg Accessories / Special Features: • SIEMENS CNC control model 840 D with comprehensivel GEIBEL&HOTZ grinding software. User friendly interface, supported by dialog and graphics, simple programming also of complex grinding wheel profiling and easy linking of grinding cycles. • All standard grinding-programms and cycles as surface and multiple surfaces grinding with roughing-finishing-sparkout- return, plunge in grinding, automatic dressing cycle with compensation, etc. • electronic handwheel for 3 axis; cross feed (Z) and infeed (Y) effected by ball screw drive. Kwjdpfx Asx Haryofzst • Table movement is actuated by belt drive (Z), which allows both very high and very low table speeds and is also ideal for profile grinding. • Hydraulically upwarding diamond dressing device mounted on the left side of the table (also for profile dressing); additional fixed dresser with automatic dressing cycle, including compensation. • Mounted sinus tilting magnetic plate 600 x 200 mm, fine pole division. • Separate paper band coolant filtration unit, separate switch cabinet, lamp for working area, various accessories, manuals, etc. Condition : very good, universal machine for all sorts of grinding tasks ! Please click here to view a video of the machine running : ! Delivery : immediately available, FCA Metzingen Payment : 100 % Net, after conclusion of contract, before loading We always have a large selection of surface grinders – CNC or conventional - available. Please let us know your requirements.

Condition: excellent (used), grinding length 600 mm grinding width 250 mm workpiece height 450 mm Control Siemens Primo SG magnetic clamping plate, electical 500 x 200 mm grinding wheel diameter 300 x 50 x 76,2 mm Kwjdpfeya Iifsx Afzet spindle turning speed - stepless 800 - 4200 U/min total power requirement 4 kW weight of the machine ca. 2,9 t dimensions of the machine ca. 4,8 x 3,6 x 2,1 m

Condition: used, Year of construction: 2003, Technical details: grinding diameter: 350 mm grinding length: 600 mm centre height: 175 mm grinding wheel hole diameter: 127 mm dimensions of grinding wheel: 400 x 50 mm grinding spindle speed: 1.500, 1.700, 2.200 1/min work piece spindle speed: 6 - 600 1/min max. workpiece weight between centres: 150 kg grinding head swivelling: -30 bis +120 Grad grinding head swivellable ° table swivelabel ° table adjustment - longitudinal: 905 mm automatic feed per table reverse control:: 0,001 - 0,030 mm feed - continual: 0 - 0,99 mm table speeds: 0 - 6 m/min taper in tailstock: MK 4 tailstock travel: 30 mm diameter of internal spindle: 80 mm spindle drive motor: 3,6 kW spindle cone: MK 5 total connected load: ca. 7,5 kW weight of the machine ca.: 2,3 t dimensions of the machine ca.: 3,2 x 2,1 m universal cylindrical grinding machine, internal grinding attachment incl. spindle, HEIDENHAIN DRO in 2 axis, balancing device ELASO EB 2000, ASYST APNC 400 NC-dressing and programming unit, Kwodpfjya Ekmjx Afzet cooland device incl. paperfilter, manuals (German language), a lot of accessories (grinding wheels (external+internal), steady, pusher dog, collets, chucks, balancing device, dresser...) MACHINE FROM TOOLSHOP, BARELY USED ! *

Condition: new, Year of construction: 2025, functionality: fully functional, grinding length: 1,600 mm, grinding width: 600 mm, New High-Precision Surface Grinding Machine, Kraft brand, Type FS 16060 SD Grinding area: 1600 x 600 mm Main Technical Data - Grinding length: 1,600 mm - Grinding width: 600 mm - Distance from table surface to spindle center: 820 mm - Table drive: Hydraulic - Table load (incl. magnetic chuck): 1,230 kg - Table speed, infinitely adjustable: 5–25 m/min - Max. table travel: 1,700 mm - Max. cross feed speed: 2,000 mm/min - Maximum cross travel: 610 mm - Max. vertical feed speed: 2,000 mm/min - Grinding spindle motor: 22 kW - Grinding wheel dimensions: 500 x 75 x 304.2 mm - Grinding spindle speed: infinitely variable - Machine weight (net): 8,500 kg - Machine width: 7,500 mm - Machine depth: 3,400 mm - Machine height: 2,700 mm - Electrical connection: 400 V / 50 Hz Features: see attachment. Standard Accessories: - 1 Standard grinding wheel 500x75x302.4 mm - 1 Standard wheel flange - 1 Wheel dresser incl. diamond dresser Kodpfx Asyak H Hefzswt - 1 Balancing arbor - 1 Balancing stand - 1 Machine lamp - 1 Set of machine tools - 1 Documentation package incl. spare parts list - Machine in CE version (Metric version) Equipment features: - Surface grinding machine with automatic vertical feed - Grinding cycle: roughing – finishing – spark-out - Siemens S700 touchscreen panel and electronic handwheel for Y-axis - Digital readout for vertical axis Y and cross axis Z - Grinding spindle drive 22 kW (including stepless speed regulation) - Electro-magnetic chuck combination (L 1600 x W 600 mm) - Magnetic plate supply unit - Coolant filtration system (incl. coolant tank, paper band filter, and pressure pump) Installed special accessories: - 1 Additional wheel flange for 500 x 75 x 302.4 mm grinding wheel - 1 Full enclosure. Completely closed machine cover with manually operated sliding doors incl. safety interlock - 1 Wheel dressing unit mounted on the spindle head (for straight dressing of the grinding wheel) - 1 Coolant mist extraction unit incl. base frame Precision and surface quality at an optimal price. Fully equipped and ready for grinding, suitable for universal use in a wide range of industrial and application sectors.

Condition: new, Year of construction: 2025, functionality: fully functional, grinding length: 500 mm, grinding width: 250 mm, New High-Precision Surface Grinding Machine of the “Optimal” Series Grinding area: 500 x 250 mm Features: ● Surface grinding machine with automatic vertical feed ● Grinding process: roughing – finishing – spark-out ● Siemens S700 touchscreen panel and electronic handwheel for Y-axis ● Digital readout on vertical axis Y and cross axis Z ● Table cover and splash guards made of stainless steel ● Electrical control cabinet mainly equipped with Siemens components ● Including handwheel dressing device, electro-magnetic chuck, and coolant filtration system Main technical data: Grinding length mm 500 Grinding width mm 250 Distance table surface to spindle center mm 450 Table drive Hydraulic Table load capacity kg 180 Longitudinal movement X Table speed, infinitely variable m/min 7 – 23 Max. longitudinal travel mm 560 Cross movement Z Max. traversing speed mm/min 990 Max. cross travel mm 275 Vertical movement Y Max. traversing speed mm/min 460 Grinding spindle/grinding wheel Grinding spindle drive power kW 2.2 Grinding wheel dimensions mm 200x20x31.75 Kjdpfxeyak Dlj Afzowt Grinding spindle speed (speed control optional) rpm 2850 Dimensions Net machine weight kg 1800 Machine dimensions (incl. table movement) Width mm 2300 Depth mm 1650 Height mm 1680 Power connection kW 3.7 All models include standard accessories: ● 1 standard grinding wheel ● 1 wheel arbor ● 1 dressing block incl. diamond ● 1 balancing arbor ● 1 balancing stand ● 1 machine lamp ● 1 set of machine tools ● 1 set of documentation including spare parts list ● CE-compliant machine (metric version) Precision and surface quality at an optimal price. Fully equipped for universal use in a wide range of industrial and application sectors.

Condition: used, Year of construction: 2000, grinding length 600 mm grinding width 300 mm magnetic clamping plate 600x200 mm wheel diameter 220-300 mm Kwsdpfx Aox U A Ugjfzjt machine weight ab. 2200 kg serial number 245

Condition: used, Year of construction: 1954, x-travel 600 mm Kwedpfx Afevu Hl Dozet ja

Condition: used, Year of construction: 1999, magnetic clamping plate 1400 - 700 mm x-travel 1400 mm Kwodevu Hlqjpfx Afzet y-travel 300 mm dismantled ja weight of the machine ca. 6 t

Condition: used, Year of construction: 1990, 1000 x 600 mm Kwjdpfsvanvuox Afzst magnetic plate size 1000 x 600 mm grinding height max 400 mm grinding wheel width x diameter 400 x 60 x 127 mm dimensions 3900 x 20 50 x 2400 m ja weight of the machine ca. 6 t

Condition: used, Year of construction: 1954, grinding length 600 mm grinding width 205 mm x-travel 600 mm ja Kedpfxovu Hkyo Afzswt

Condition: used, Year of construction: 1970, Year ca. 1970 magnetic plate size 520 x 200 mm weight of the machine ca. 1,4 t +++++ Kwedpfxsirazpe Afzst Please note: The machine is dismantled and ready for loading. It is not possible to show it under power or make a video. Our offer includes already the best pictures. So we don’t have and won’t send additional pictures. +++++

Condition: good (used), Year of construction: 2008, functionality: fully functional, Technical details grinding length 2000 mm grinding width 850 mm distance spindle center to table 900 mm control Siemens 840 D total power requirement 155 kVA weight of the machine ca. 15 t dimensions of the machine ca. 8815 x 4185 x 2963 mm Additional information CNC Precision Surface and Profile Grinding Machine Technical Specifications: Grinding length 2000 mm Kwsdpex Uzn Ejfx Afzet Grinding width 850 mm Travel, transverse 750 mm Distance from table to spindle center 900 mm (or 800 mm with intermediate plate) Magnetic plate size 2000 x 700 mm Table load without magnet 3500 kg Table speed 60 m/min. Spindle drive 26 kW Grinding wheel dimensions 500 x 150 x 203.2 mm Grinding wheel peripheral speed 35 m/s Equipment: 3-axis contouring control Siemens 840 D Grinding programs: Full-cut grinding Face grinding Plunge grinding Path grinding X/Y-axis and Y-Z-axis Profile grinding Automatic program sequence with roughing, finishing, fine finishing and spark-out grinding. Multiple plunge grinding for economical production Surface grinding with continuous, continuously programmable cross feed Grinding wheel calibration Plunge/step grinding Face grinding Dressing in the grinding cycle with lift-off amount Fully automatic compensation of dressing amounts Tool management AC servo drives with ball screw and absolute measuring system in the X, Y, and Z axes Preloaded precision roller guides in the X, Y, and Z axes with linear guides Portable electronic handwheel Automatic belt filter system Coolant heating Electro-permanent magnetic chuck Fully enclosed Direct measuring system in the vertical axis Temperature-controlled machine bed for consistent accuracy Linear motor in the X-axis, table speed max. 60 m/min. Swiveling control panel Continuous speed control of the grinding spindle Electrical linear measuring device for cross-travel adjustment with zero point setting in any position, resolution 0.001 mm Electro-mechanical locking via position control of the headstock in the cross direction for profile and plunge grinding Mechanical extraction of coolant mist TAG table dresser Pre-profiling dresser VPG 190 Diamond grinding wheel, 190 mm diameter Software program for pre-profiling dresser VPG Rough profiling (roughing) CNC table profile dresser TAD 190 Profile depth max. 45 mm Contour accuracy +/- 0.0025 mm Swivel angle +/- 65 degrees Max. dressing speed 210 mm/min. Diamond wheel for table dressing machine TAD 190 Regrinding package for diamond wheel Intermediate plate for raising the magnet WinWop profiling software Import of CAD profile data SP 60 JOB Listing expansion package Additional holes for the magnet clamping plate to facilitate removal of workpieces using compressed air Ghost shift circuit for shutting down the machine after the end of the program

Condition: good (used), Year of construction: 2001, functionality: fully functional, Technical details grinding length 4200 mm grinding width 1300 mm workpiece height 550 mm Control SIEMENS 840 D magnetic clamping plate 4200 x 1300 mm segment head diameter 1400 mm grinding motor turning speeds up to 320 U/min. Kodpfex Uyd Sex Afzswt grinding motor 306 kW weight of the machine ca. 50,0 t Additional information Segment dimensions: 120/106 x 41 x 250 mm Number of segments: 1 set = 26 pieces Grinding motor feed: 0.5 - 35 m/min, infinitely variable Grinding motor feed: - in steps: 0.002 - 1 mm continuous: up to 5 mm/min. infinitely variable Equipment: * CNC-control SIEMENS Sinumerik 840 D * Automatic hydr. swivelling of the grinding motor from hollow to cross grinding * NC-controlled adjustment of the Marposs measuring head by means of precision support. - new grinding dimensions can be entered into the control, whereby the the grinding head automatically adjusts to the corresponding height. * Dresser with adjustment axis in the machine bed * Coolant system * Electro-magnetic table * Switch cabinet * Oil mist extraction * Documentation Dimensions (length x width x height) Bed: 11800x2200x1400 mm, weight 27500 kg Grinding head: 3000 x 2500 x 3100 mm, estimated weight 14 t 2 x Oil mist extraction: 1200 x 800 x 2000 mm each Control panel: 1200 x 800 x 400 mm Small control cabinet: 1400 x 1400 x 800 mm 2 x gears each 1200 x 800 x 500 mm Control cabinet: 1600 x 800 x 2000 mm Control cabinet: 3400 x 600 x 2400 mm

Condition: used, Year of construction: 1968, 450 mm Länge x-travel 500 mm workpiece height . mm Kwodpfxjqwpwzo Afzst

Condition: used, Year of construction: 1994, grinding length 800 mm grinding width 350 mm Control Haidenhain Kedewlvr Tspfx Afzewt Bandfilteraggregat

Condition: used, Year of construction: 1995, table-size Breite: 800 mm table-size Tiefe: 350 mm Kwodewp Tuyepfx Afzet Dimensions (L/W/H) 4600 x 3200 x 2500 mm weight of the machine ca. 4,5 t
