Used Window Tool for sale (47,238)

Condition: excellent (used), Year of construction: 2002, functionality: fully functional, Universal tool grinding machine Michael Deckel S11 speed, year of manufacture 2002, in very good condition!! Technical Data: >> Year of manufacture: 2002 >> Serial No.: 2197 Clamping range: >> Clamping surface of tool slide 500 x 180 mm >> Max. tool diameter between centers 130 mm >> Max. tool length between centers 270 mm >> T-slots machine stand 12 mm Movement range: >> Working travel Grinding stroke 190 mm Grinding stroke during thread grinding 190 mm Transversal adjustment tool slide 100 mm Vertical adjustment grinding head 325 mm Longitudinal adjustment grinding spindle 5 mm >> Coarse adjustment travel Tool holder 220 mm Grinding head carrier 800 mm >> Swivel angle Grinding head carrier 360 degrees Grinding head 360 degrees Tool holder 360 degrees Grinding spindle: Three-phase drive motor 1.1 KW at 2800 rpm Spindle speeds, stepless 2000 to 12000 rpm Max. grinding wheel diameter 125 mm Max. cutting wheel diameter 200 mm Dimensions: Weight 520 kg Dimensions (D x W x H) 800 x 1100 x 1760 mm Hfjdpfxjwrnf Eo Ag Rjn Space requirement (including operation) 2.5 x 2.3 m Accessories and equipment: >> See pictures About the machine: Offered is a universal tool grinding machine of the brand Michael Deckel S11 speed. The machine is suitable for grinding high-precision parts. With the S11, individual parts and small batches can be ground amazingly fast, economically, and flexibly, with the highest operating comfort. The Deckel S11speed is in very good condition. Mechanically and electrically tested. Take the opportunity to visit and test this machine on site under power.

Condition: new, pressing force: 160 t, V80mm Amada style press brake dies Hsdpfx Agowcxtbo Rsfn

Condition: excellent (used), functionality: fully functional, Universal Milling Machine Deckel FP3 with 3-Axis Digital Readout RSF Elektronik Z-530!! Technical Data: >> Year of manufacture: approx. 1975, Machine No. 0681 >> Swivel and tilting table (recently overhauled) >> Speed range: 40 - 2000 rpm >> Feed and rapid traverse in 3 axes >> Drive power: 3 kW >> Travel X/Y/Z: 500/300/400 mm >> Features: Vertical & horizontal spindle >> Vertical quill and horizontal quill extendable - SK-40 >> Drawbar system M16 >> Weight approx. 1300 kg Hodpsxu E I Hsfx Ag Rofn Equipment and Accessories: >> 3-axis digital readout RSF Elektronik Z-530 >> Coolant system >> Central lubrication About the machine: For sale is a Deckel FP3 universal milling machine in good condition. All spindles move smoothly. Most of the bellows are nearly new. The swivel and tilting table is as new. An oil change has been carried out. The machine has been mechanically and electrically tested. The digital readout makes work easier and more precise. Take advantage of the opportunity to inspect and test the Deckel on-site under power. The machine is immediately available!!!

Condition: new, Technical specifications: Material Thickness: 2mm Internal dimensions LxWxH: 120 x 61 x 58 cm Useful volume: 420 liters External dimensions LxWxH: 122 x 61.5 x 70 cm Height (unfolded): 123 cm Drill Pattern Spacing - Large Hole (25mm): 40" x 18". Hedpfst U Sckox Ag Refn Drill Pattern Spacing - Small Hole (12mm): 8.4 x 8.4 cm Stacking fork mounts: W12 x H8.5 cm Weight: 60kg

Condition: not inspected (used), x-travel 850 mm Hjdpeud Illjfx Ag Rjfn y-travel 440 mm z-travel / mm Control TNC 355C

Condition: good (used), Extrusion tool accessories, extruder -Manufacturer: JC Times USEON, Extrusion Tooling Accessories -Type: unfortunately without type designations -Perforated plates: 3 pieces 1940/210/H60 mm -Individual components: see photos -Price/Fee: complete -Transport dimensions: 3150/1095/H1790 mm / 2050/300/H900 mm Hfsdpfx Aszpwcxeg Rsn -Weight: 2510 kg / 560 kg

Condition: used, Year of construction: 2011, turning diameter over cross slide: 75 mm, turning diameter: 381 mm, spindle speed (max.): 3,500 rpm, spindle bore: 75 mm, travel distance Z-axis: 850 mm, total height: 2,325 mm, total length: 4,820 mm, total width: 2,100 mm, overall weight: 8,000 kg, CNC Lathe with Y-axis, driven tools and 2nd Spindle CNC Control Fanuc series 18i-TB Turning diameter 381 mm Spindle bore diameter 75 mm Spindle speed 3500 R/min Spindle motor 22/15 Kw Hfedpozv Smfofx Ag Ron Movement X-axis 190 + 69,5 mm Movement Y-axis +55 / -55 mm Movement Z-axis 850 mm Movement W-axis (subspindle to mainspindle) 830 mm Min indexing C-axis main spindle 0,001 ° Number of tools on turret 12x Number of driven tools 12 x Tool Taper VDI 40 Bar feeder Irco-Breuning ILS MUK Spindle motor driven tools 4000 R/min If you have any questions concerning the machine, please do not hesitate to contact us by phone or e-mail. Feel free to view our other advertisements for a complete overview of our stock.

Condition: used, Year of construction: 1998, Window manufacturing system Manufacturer: Weinig Type: Unicontrol 10-5 Year of manufacture: 1998 Technical data Working width: 40 - 220 mm Working height, longitudinal machining: 40 - 100 mm Working height, transverse machining: 40 - 100 mm (80 mm counterpiece height) Workpiece length, longitudinal machining: min. 220 mm + 2 x tenon length Workpiece length, transverse machining: min. 275 mm + 1 x tenon length at 320 mm tool diameter Feed (transverse machining) Motor power: 0.3 kW Feed speed: 3 - 25 m/min Workpiece clamping: by means of 2 clamping jaws Length stop: with scale and magnifying glass for frame or sash outer dimensions Counterpiece: pneumatically controlled - 4 positions - (not for studio windows) up to a wood height of max. 80 mm Double part package: For single or double part feeding. With transverse separation and retention system 1. Wood (lying against the stop) Wood width: 55 - 90 mm 2. Wood Wood width: 130 mm Feed (longitudinal machining) Motor power: 2.2 kW Feed speed: 4 - 18 m/min (continuously variable via frequency converter) Feed roller spacing: 100/120 mm Feed roller width: 30/50 mm Feed roller diameter: 95 mm Machining units Cut-off saw Motor power: 3 kW Spindle diameter: 40 mm Spindle speed: 2800 rpm Hodszuyxgspfx Ag Rsfn Tool circle diameter: max. 400 mm Adjustment, axial: pneumatically controlled against a 4-position turret 1. Tenon and mortise spindle Motor power: 11 kW Spindle diameter: 50 mm Spindle speed: 3250 rpm Tool circle diameter: max. 320 mm Tool clamping length: 320 mm Adjustment, axial: 240 mm Number of tools: 4 x 80 mm Axial adjustment: hydraulic 1. Profiling spindle Motor power: 11 kW Spindle diameter: 50 mm Spindle speed: 6000 rpm Tool diameter: max. 232 mm Tool zero circle diameter: 130 to 140 mm Tool clamping length: 320 mm Adjustment, axial/radial: 240/80 mm Number of tool positions: 4 x 80 Axial adjustment: hydraulic 2. Profiling spindle Motor power: 11 kW Spindle diameter: 50 mm Spindle speed: 6000 rpm Tool diameter: max. 232 mm Tool zero circle diameter: 130 to 140 mm Tool clamping length: 320 mm Adjustment, axial/radial: 240/80 mm Number of tool positions: 4 x 80 mm Axial adjustment: hydraulic 2 Mechanical spindle brake for profiling spindle 3 Mechanical spindle brake for cut-off saw and profiling and sawing units Profiling milling unit (horizontal, top) before the last profiling spindle radially controlled to 2 positions axially controlled to 2 positions Motor power: 3 kW Spindle diameter: 40 mm Spindle speed: 5850 rpm Tool circle diameter: 130 mm Tool clamping length: 40 mm Adjustment, axial: 52 mm Adjustment, radial: 125 mm Profiling milling unit (vertical, right) at the end of the machine radially controlled to 2 positions axially controlled to 2 positions Motor power: 3 kW Spindle diameter: 40 mm Spindle speed: 5850 rpm Tool circle diameter: 210 mm Tool clamping length: 160 mm Adjustment, axial: 90 mm Adjustment, radial: 100 mm Length, tenon and mortise spindle with 640 mm tool clamping length (instead of 320 mm spindle) Motor power: 15 kW Spindle speed: 2925 rpm Number of tool positions: 8 x 80 mm Adjustment, axial: 560 mm Laser alignment light for cut-off saw for detecting the section Studio window configuration Swiveling length stop +/- 60 with electronic digital display and pneumatic clamping Sliding counter rail Special pressure pad for angled part production Limitation: Wood thickness max. 120 mm At -60 position: Workpiece width max. 110 mm with 80 mm tenon length, or max. 150 mm with counter profili

Condition: ready for operation (used), Year of construction: 1998, Table size: 400 x 800 mm Travel ranges x/y/z: 600/400/380 mm Hedpozvm H Hefx Ag Rofn Quill stroke: 80 mm Spindle mount: SK 40 Vertical milling head, adjustable in 2 planes Spindle speeds, stepless: 63 - 3150 rpm Feeds, longitudinal/vertical, stepless: 4 - 1200 mm/min Electrical connection: 400 V, 4 kW Space requirement: 1800 x 1700 x 1900 mm Weight, approx.: 1.65 t

Condition: excellent (used), max. grinding diameter 175 mm Hjdpfozxh Tmex Ag Rofn

Condition: used, diameter / mm weight / kg Type / 0 Hfodpfey Supkjx Ag Rsn

Condition: used, functionality: fully functional, EYAN Universal Tool Grinding Machine – Used, including extensive accessories & documentation For sale is a high-quality universal tool grinding machine from the EYAN brand, in good used condition. The machine is ideally suited for the precise re-grinding and production of various cutting tools and is perfect for professional toolmaking as well as for locksmiths, maintenance companies, and training workshops. Thanks to its robust cast iron construction, the machine impresses with its smooth operation, stability, and precise grinding results. Equipment EYAN Universal Tool Grinding Machine Precision chuck / tool holder Extensive adjustment and setting options Machine lamp Grinding wheel mounted Original under-cabinet with storage space Original operating manual Hsdpezhx D Iefx Ag Rsfn Technical documentation Spare parts lists and documents Additional accessories and tools in the under-cabinet (see pictures) 400 V high-voltage connection Condition The machine is in good, used condition with the usual signs of wear and tear. It comes from an operating business and was in use until recently. Scope of delivery EYAN Universal Tool Grinding Machine Under-cabinet Chuck Grinding wheel Original operating manual Technical documentation Spare parts documents Accessories and tools as shown in the photos Application areas Tool and mold making Metalworking Locksmith shops CNC manufacturing Training companies Maintenance and repair Tool grinding machine, universal tool grinding machine, tool grinder, milling cutter grinding machine, drill bit grinding machine, milling cutter grinding, twist drill grinding, turning tool grinding, tool sharpening machine, precision grinding machine, toolmaking, metalworking, grinding machine, EYAN, universal grinder, tool grinder, cutter grinder, tool grinding, tool sharpening, 400V, industrial, workshop machine, mechanical engineering, grinding technology. An inspection and functional test are possible at any time by prior arrangement. Net price, plus 19% VAT.

Condition: good (used), Year of construction: 2000, functionality: fully functional, travel distance X-axis: 875 mm, travel distance Y-axis: 500 mm, travel distance Z-axis: 500 mm, spindle speed (max.): 7,000 rpm, overall weight: 4,500 kg, CNC control Heidenhain TNC 426 electronical hand wheel manual swivel head quill coolant device Hfjdpfxjzr D Akj Ag Ren measuring feeler Technische Daten: /technical details X Weg / x travel 875 mm Y Weg / y travel 500 mm Z Weg / z travel 500 mm Drehzahlbereich 2-stufig / spindle speed range (2-steps) 20 - 7000 UpM / rpm Eilgang / rapid feed 15 m/min. Spindelaufnahme / spindle taper SK 40 Tischaufspannfläche / table clamping area 900x528 mm Gewicht der Maschine ca. / weight 4500 kg Technische Daten, Zubehör und Beschreibung der Maschine sind unverbindlich - Technical data, accessories and description of the machine are not binding.

Condition: used, x-travel 400 mm y-travel 315 mm z-travel 400 mm control Dialog 4 spindle tunring speed 3.150 U/min In our assessment, the machine is in good used condition and can be inspected under power by appointment. Accessories, tools, and clamping devices shown are only included in the scope of delivery if this is noted in the additional information. Technical data and specifications are subject to change without notice and errors. Hjdpfx Aszz S Rnsg Rsfn Prior sale is reserved.

Condition: used, Year of construction: 2006, functionality: fully functional, machine/vehicle number: 21197, overall weight: 2,100 kg, number of drawers: 100, power: 2 kW (2.72 HP), Gühring TM-136 Tool Storage System Year: 2006 Power supply: 230 V, 2 kW Empty weight: 2,100 kg Maximum total load: 6,000 kg Industrial tool dispensing and storage system with various drawer sizes. Used condition. More information and photos available on request. Hedpfx Agjz Arz No Rofn

Condition: excellent (used), functionality: fully functional, total height: 1,760 mm, total length: 1,100 mm, total width: 800 mm, type of input current: three-phase, grinding wheel diameter: 125 mm, overall weight: 520 kg, input voltage: 400 V, spindle nose: ISO 40, Tool grinding machine DECKEL S11 TECHNICAL CHARACTERISTICS: Grinding wheel diameter: 125 [mm] Workpiece spindle nose: ISO 40 Paper filtration unit: No Supply voltage: 400 [V] Total power required: 2 [kVA] Dimensions: 1100 x 800 x 1760 Weight: 520 [Kg] EQUIPMENT INCLUDED: x1 universal index head - Part N°: 255X0X x10 dividing inserts for universal index head x1 tailstock with transverse adjustment - Part N°: 2621000 x1 tailstock with vertical adjustment - Part N°: 2624000 x1 swivel bracket assembly - Part N°: 2626000 x1 universal wheel dresser - Part N°: 2628000 x1 universal setting gauge - Part N°: 2570000 x1 spiral and relief grinding attachment - Part N°: 2580000 x1 relief grinding slide - Part N°: 2673000 x1 machine vice - Part N°: 2635000 x1 opto-electronic measuring unit with miscroscope - Part N°: 2650012 Hfedpfxjzz Hk Ns Ag Rjn x2 digital readouts RSF-Elektronik x1 radius grinding attachment - Part N°: 2601X00 x1 LED lamp x3 feet pads Machine visible under power in our premises by appointment. Price on request, loading on truck included. Possibility of shipping Worldwide. The information on this page has been obtained by the best of our ability. Therefore, its accuracy can not be guaranteed. Machine for sharpening tools, milling cutters, taps, and drills. Similar to brands such as Blohm, Elb, Ewag, Favretto, Fenix, Ger, Jones & Shipman, Jung, Karstens, NUMAFFUT, Okamoto, Okuma, Saacke, SMP, Studer, Vollmer, Walter. Also see cylindrical or surface grinders, lathes, machining centers, and milling machines.

Condition: used, Year of construction: 2007, functionality: fully functional, machine/vehicle number: 6043, Year 2007 with Fanuc Series 16Oi Country of origin: CH Voltage: 3x400V/50Hz Dimensions: 216x160x216 cm Net machine weight: 3200 kg TECHNICAL SPECIFICATIONS X-axis: 300 mm Y-axis: 220 mm Z-axis: 180 mm Resolution: 0.0001 mm Clamping capacity: 0.5 – 20 mm Grinding wheel diameter: 0.1 – 16 mm Maximum clamping length: 270 mm Grinding wheel diameter: 150 mm A-axis (grinding wheel rotation): -195 / +30° B-axis (grinding head rotation): -75 / +135° C-axis (spindle indexing): 0.001° W-axis: 620 mm U-axis: 500 mm Grinding wheel speeds, continuous: from 2000 min-1 to 7200 min-1 Spindle power: 7 kW Hsdpfszxz R Esx Ag Refn Fire extinguishing system – CO₂ Kraft & Bauer – Not verified and no guarantee of functionality. To be serviced by you. Unless otherwise indicated, the technical data is provided without any commitment.

Condition: used, CNC universal tool milling machine DECKEL, type FP 4 MA Machine No. 2204-1734, Serial No. 25842, Year of manufacture 1989 CNC path control: GRUNDIG Contur 2 Travel distances: X: 485 mm, Y: 385 mm, Z: 380 mm Table size: 800 x 460 mm Spindle mount: ISO 40 Spindle speed: 63 - 3150 rpm, 18 speeds Feed rate: max. 2000 mm/min Distance table - spindle nose: max. 480 mm Arbor displacement, vertical: 80 mm Hedpfxszwmc Re Ag Rjfn Arbor displacement, horizontal: 150 mm Main spindle drive: 3.7 / 4.4 kW Power supply: 400 V, 50 Hz, 13 kW - CNC path control: GRUNDIG Contur 2 with TFT screen - Hydro-mechanical tool clamping - Swiveling control panel - Electronic handwheel for all three axes - Mechanical handwheels for all three axes - Fixed angular table - Coolant system in the machine base - Central lubrication - Control cabinet located next to the machine, dimensions W x D x H: 800 x 750 x 1150 mm Space required, dimensions W x D x H: 2400 x 2300 x 2000 mm Weight: approx. 2400 kg In good condition

Condition: ready for operation (used), Year of construction: 1997, operating hours: 13,465 h, functionality: fully functional, travel distance X-axis: 600 mm, travel distance Y-axis: 450 mm, travel distance Z-axis: 400 mm, table load: 1,000 kg, controller model: Heidenhain iTNC 430, TECHNICAL DETAILS Travel range, X-axis: 600 mm Travel range, Y-axis: 450 mm Travel range, Z-axis: 400 mm Table load: max. 1,000 kg Tool holder: SK 40 MACHINE DETAILS Control system: Heidenhain iTNC 430 Operating voltage: 400 V Control voltage: 24 V Machine weight: approx. 6,000 kg Operating hours: 48,690 h Spindle hours: 13,465 h EQUIPMENT Hfjdpjzwmx Sofx Ag Rsn Tool holders SK 40 Documentation Heidenhain programming manual Machine vise Clamping jaws

Condition: good (used), Various accessories for the tool grinding machine SWU 250, manufactured by Gotha or Königsee, are for sale. Hfedpfx Aez E U Dceg Rjn The images will be added gradually. Individual sales are possible. Inquiries about specific parts can be made. Price proposals are welcome.

Condition: excellent (used), functionality: fully functional, Offer: Like-new turning tool holders VDI40 turning tool holder Tool holders, VDI40 tool holders. The holders have been inspected and are in very good, almost new condition. The outstanding quality of well-known manufacturers confirms the high repeatability and a very long service life. ----- Order number: 435_C1 → In stock: 2 pieces; Price: €56.00/piece Order number: 430_C2 → In stock: 3 pieces; Price: €56.00/piece One tool holder has been ground on the underside (see picture), but this does not affect its functionality. Order number: 432_B4 → In stock: 2 pieces; Price: €56.00/piece Order number: 433_B4 → In stock: 2 pieces; Price: €56.00/piece For orders of 4 pieces or more, the above prices apply, including shipping costs within Germany. ----- B3 with right-hand rotation; B4 with left-hand rotation C1 with right-hand rotation; C2 with left-hand rotation ----- Short, reversed VDI radial tool holder. Tool holder for mounting external turning tools in the normal position, i.e., with carbide inserts facing upwards: C1 with right-hand rotation; C2 with left-hand rotation. Shipping costs: upon request. ----- Dimensions: D = 83 mm d-2 = 83/40 mm (45.52) H = 32.5 mm L1 = 75 L2 = 22 l-4 = ----- Hfodpfx Agjz Hn Rro Ron More VDI40 holders can be found in our other offers, e.g., VDI40 form E2. For boring tools with cylindrical shanks, with internal and external coolant supply. Surface hardened, blued, and ground.

Condition: used, 1 Assortment of tool holders, SK 45 25 pieces Hjdpsz Dvhmefx Ag Refn

Condition: good (used), Year of construction: 1998, functionality: fully functional, workpiece weight (max.): 200 kg, Universal machining center Manufacturer: MACMON Type: M 100 ADR Technical data: - Heidenhain TNC124 control system - Machine number: 7989 - Year of manufacture: 1998 - Travels: X 310 mm, Y 170 mm, Z 330 mm Hsdpferwml Aex Ag Rsfn - Spindle speed range: 40-2500 rpm (continuously variable in 2 ranges) - Feed rate: 10-800 mm/min (continuously variable) - Rapid traverse rate: 800 mm/min - Equipment: Vertical and horizontal spindle (including lifting device for vertical spindle) - Table size: 600 x 215 mm - SK40 - Drive motor: 2.2 kW - Connected load: 5.5 kW - Weight: approx. 750 kg - Space requirement: 1000 x 1160 x 1400 Includes complete documentation All information without guarantee. Subject to prior sale.

Condition: excellent (used), Year of construction: 1985, functionality: fully functional, spindle speed (max.): 2,000 rpm, spindle speed (min.): 80 rpm, type of input current: three-phase, input voltage: 400 V, Equipment: rotational speed infinitely variable, Universal milling machine Deckel FP1 – Very good condition For sale is a Deckel FP1 universal milling machine in very good, well-maintained condition. The machine is equipped with a 3-axis digital display Heidenhain TNC 113 and stepless feed in all three axes. The Deckel FP1 is known for its precision, reliability and durability and is ideal for toolmaking, single-part production, repair work and training companies. Technical data Manufacturer: Deckel Model: FP1 Year of manufacture: 1985 Machine number: 15082 Spindle speed: 80–2,000 rpm Drive power: 1.6 / 2.0 kW Stepless feed in X, Y and Z axis Hfsdpfx Aezlnmmjg Rjn Rapid traverse in all three axes Travel ranges (X/Y/Z): 300 / 160 / 340 mm Fixed angular table Vertical milling head on spindle head, adjustable by 100 mm Vertical and horizontal spindle with SK40 collet Clamping system: S20x2 Spindle brake Space requirement: 1.30 m x 1.10 m x 1.60 m (L x W x H) Machine weight: approx. 850 kg Equipment - 3-axis digital display Heidenhain TNC 113 - Hydraulic vise - Coolant system - Operating manual The machine is in very good technical and optical condition and is ready for immediate use. An inspection and a test run can be arranged at any time by appointment.

Condition: good (used), Year of construction: 1964, functionality: fully functional, travel distance X-axis: 500 mm, travel distance Y-axis: 200 mm, travel distance Z-axis: 400 mm, spindle speed (max.): 200 rpm, spindle speed (min.): 40 rpm, input frequency: 50 Hz, Manufacturer: Deckel Type: FP2 Tool holder: SK 40 Travel ranges X/Y/Z: 500 / 200 / 400 mm Speed range: (18 steps) 40 - 2000 rpm Spindle stroke, vertical: 60 mm Spindle stroke, horizontal: 100 mm Feed rates: 8 - 400 mm/min Table size: 700 x 300 mm Motor power: 2.2 kW Connection: 400 V / 16 A plug Weight: approx. 1300 kg Space requirement L x W x H, approx.: 1200 x 1250 x 1670 mm Head swivels: 90° / 90° Hfedpfoilg H Esx Ag Ren Equipment: - 3-axis digital display - Coolant system We would be happy to demonstrate the machine in operation at your location. All information is subject to change without notice. Subject to prior sale.
