Used Worm Milling Machine for sale (65,438)

Year of construction: 1978, condition: like new (used), 4 kW engine max. tool diameter 270 mm 30 mm spindle spindle up / down adjustment spindle locking interchangeable spindle Iiodpfxehh S Due Ap Dsh table dimensions 91 cm x 102 cm cast iron table top height to the table plane 850 mm

Condition: reconditioned (used), Awl grinding machine Manufacturer: harich (Deckel) Model: SSMplus (S0E) Refurbished, with CE marking Includes warranty Equipment: - Machine stand - Integrated dust extraction - Grinding wheel with flange - Dressing tool - New machine electrical system in accordance with current safety regulations - Documentation for the machine and control cabinet in printed form, consisting of: - Operating manual - Wiring diagram - CE declaration of conformity Additionally equipped with safety measures in accordance with standard EN 60204-1, consisting of: - Control cabinet with main switch, power supply, contactors, motor protection, safety switching devices - Emergency stop mushroom button instead of the main switch on the machine - Green button for turning the machine on (illuminated) Iedpfx Aez Hy E Ijp Deih - Red button for turning the machine off - LED status indicator in the form of the harich logo: - Blue for machine on - Green for grinding spindle on

Condition: used, Year of construction: 2006, Control MAZATROL 640M x-travel 1.740 mm y-travel 760 mm z-travel 660 mm table dimensions 2.000 x 760 mm max. table load 1.400 kg spindle tunring speed 12.000 U/min tool taper SK 40 number of tool places 30 Pos. weight approx. 11.500 kg Condition: used Accessories, tools, and clamping devices shown are included in the scope of delivery only if this is explicitly stated in the additional information. Subject to changes and errors in technical data and specifications; Isdpfx Asz S N I Dop Deih prior sale reserved!

Condition: used, Year of construction: 2005, functionality: fully functional, travel distance X-axis: 1,500 mm, travel distance Y-axis: 1,000 mm, travel distance Z-axis: 700 mm, spindle speed (max.): 8,000 rpm, Milling machine Year of construction: 2025 Work table, clamping surface: mm 1500 x 1000 Table height: mm 750 Number of T-slots: 7 Size of T-slots DIN 650: mm 18 Travel distances X-axis: mm 1500 Y-axis: mm 1000 Z-axis: mm 700 Distance: Table top edge - Spindle bottom edge min/max: mm 150 / 850 Main spindle drive for speed 8000 min-1 Tool holder: SK 40 AC motor, frequency-controlled: kW 26 at 44% duty cycle Speed range: min-1 15 – 8000 Torque: Nm 245 Coolant system Band filter system Feed drives X-axis AC servo motor: kW 3.5 Y-axis AC servo motor: kW 2.0 Z-axis AC servo motor: kW 3.5 Rapid traverse speeds (X/Y/Z): m/min 30/30/20 Indirect position measurement system. Accuracy Positioning accuracy X and Y axes over 1000 mm: mm ± 0.0150 Repeatability X and Y axes: mm ± 0.0075 Positioning accuracy Z axis: mm ± 0.0150 Iedpfx Apezvbauo Deih Repeatability Z axis: mm ± 0.0075 Tool magazine, 24-position mounted on the left side of the machine - Tool positions: 24 - Tool shank (DIN 69871 / 69872): SK 40 - Max. tool diameter: mm 76 - Max. tool length: mm 250 - Max. tool weight: kg 8 Machine control: Heidenhain iTNC530 Ex works, unloaded, plus statutory VAT. No guarantee.

Condition: excellent (used), Year of construction: 2008, functionality: fully functional, Tool milling machine Kunzmann WF4/3 with Heidenhain TNC 320 control system, in very good condition, CE-compliant, from a training workshop! Iisdpfx Apsz Eh Uuj Djh Technical data: >> Year of manufacture 2008, machine no. 347141 >> Fixed angular table >> Speed: continuously variable up to 4500 rpm >> Feed rate continuously variable in 3 axes from 0 to 2000 mm/min >> Rapid traverse X and Y axis 5000 mm/min >> Z axis 4000 mm/min >> Travel ranges X/Y/Z: 400/350/400 mm >> Table surface: 650 x 350 mm >> Table load: 250 kg >> Quill stroke vertical: 60 mm >> Vertical and horizontal quill - SK40 >> Hydraulic clamping system >> Weight approx. 1800 kg >> Space requirement approx.: 2.3 x 2 x 2 m >> Drive power: 15 KVA Accessories and equipment: >> Heidenhain TNC 320 control system >> Hydraulic chuck vertical and horizontal >> Automatic central lubrication >> Spindle brake >> Technical documentation, spare parts diagrams, operating instructions for the control system and programming examples >> Handwheels >> Coolant system (not shown in the pictures) About the machine: Offered is a tool milling machine Kunzmann WF4/3 with a Heidenhain TNC 320 control system. This universal milling machine is in very good condition and has only a few operating hours. It comes from a company where it was only used for training purposes. It has a very easy-to-use control system. Furthermore, the machine has hydraulic chucks for both vertical and horizontal operation. The conversion from vertical to horizontal is very easy by folding down the vertical head. The guides are regularly lubricated by the central lubrication system. The Kunzmann has been mechanically and electrically inspected by us. Take the opportunity to inspect and test the Kunzmann on site under power. There are 5 identical Kunzmann WF4/3 milling machines available from a vocational school. The machines are available immediately.

Condition: excellent (used), Year of construction: 2008, functionality: fully functional, Tool milling machine Kunzmann WF4/3 with Heidenhain TNC 320 control system, in very good condition, CE-compliant, from a training workshop! Technical data: >> Year of manufacture 2008, machine no. 347138 >> Fixed angular table >> Speed: continuously variable up to 4500 rpm >> Feed rate continuously variable in 3 axes from 0 to 2000 mm/min >> Rapid traverse X and Y axes 5000 mm/min >> Z axis 4000 mm/min >> Travel distances X/Y/Z: 400/350/400 mm >> Table surface: 650 x 350 mm >> Table load: 250 kg >> Quill stroke vertical: 60 mm >> Vertical quill and horizontal quill - SK40 >> Hydraulic clamping system >> Weight approx. 1800 kg >> Space requirement approx.: 2.3 x 2 x 2 m >> Drive power: 15 KVA Accessories and equipment: >> Heidenhain TNC 320 control system >> Hydraulic chuck vertical and horizontal >> Automatic central lubrication Isdpfsz Eh Ubox Ap Djih >> Spindle brake >> Technical documentation, spare parts diagrams, operating instructions for the control system and programming examples >> Handwheels >> Coolant system (not shown in the pictures) About the machine: Offered is a Kunzmann WF4/3 tool milling machine with a Heidenhain TNC 320 control system. This universal milling machine is in very good condition and has only a few operating hours. It comes from a company where it was only used for training purposes. It has a very easy-to-use control system. Furthermore, the machine has hydraulic chucks for vertical and horizontal operation. Switching from vertical to horizontal operation is very easy by folding down the vertical head. The guides are regularly lubricated by the central lubrication system. The Kunzmann has been mechanically and electrically inspected by us. Take the opportunity to inspect and test the Kunzmann on site while it is powered up. There are 5 identical Kunzmann WF4/3 milling machines available from a vocational school. The machines are available immediately.

Condition: good (used), Spindle mount, vertical + horizontal SK 40 Arbor adjustment approx. 80 mm Table clamping surface 800 x 340 mm Travel distances X-axis 500 mm Y-axis 350 mm Z-axis 500 mm Speed range 35 – 1550 rpm Table adjustment: Iedsin Dktspfx Ap Doih Feed rates 6 – 270 mm/min Rapid traverse rates X + Y Drive power approx. 3 kW Machine dimensions L x W x H 1350 x 1300 x 1880 mm Weight approx. 1750 kg Accessories / Special features: • Like-new 3-axis digital display SINO • Vertical milling head, swiveling R + L, arbor adjustment • Horizontal milling spindle • Feed in all axes • Rapid traverse X + Y • Coolant system • Emergency stop switch Siegfried Volz Machine Tools Rüschebrinkstr. 151-153 DE - 44143 Dortmund - Wambel / Germany

Condition: good (used), Year of construction: 2004, Ref. -No.: 10634 Manufacturer: ANAYAK Type: P 3200 Year of construction: 2004 Type of control: CNC-Steuerung Control: Heidenhain Storage location: Halberstadt Country of origin: Germany X-Travel: 3200 mm Y-Travel: 1400 mm Z-Travel: 750 mm Table-Size (Lxw): 3200 x 1400 mm spindle running time: 23.291 H Control: 83.301 H machine: 73.907 H Iisdpfx Apozx Nyzj Deh Program run: 27.807 H

Condition: good (used), Year of construction: 1998, Ref. -No.: 10583 Manufacturer: MTE Type: BF 4200 Year of construction: 1998 Type of control: CNC-Steuerung Control: Heidenhain TNC 426 Storage location: Halberstadt Country of origin: Germany X-Travel: 4000 mm Y-Travel: 1200 mm Z-Travel: 1500 mm Turning Speeds: 2.500 RPM Rapid Traverse X/Y/Z: 400 m / min Table surface area (LxW): 4200 x 1000 mm Tool changer: 40 Table load max.: 13.000 kg Tool Taper: SK 50 Isdpfx Apozx Nybj Djih Weight: 20 t Number Of T-Slots: 7 Pcs Width of the T-slots: 22 mm Distance between the grooves: 140 mm Further information: - Heidenhain HR410 handwheel - 3D scanner, infrared - The ball screw on axes Z and Y runs clamped and supported on combined radial/axial roller bearings and radial ball bearings with 250 N/sqm stiffness. The machine can be viewed while powered up.

Condition: new, Year of construction: 2026, Spindle Moulder SCM / CASADEI F 25 M LL FK Robust professional woodworking machine with spindle tiltable ±45° to both sides and MK4 interchangeable spindle Article number: 5220730 Brand: Holzkraft CASADEI - Heavy-duty steel/cast iron construction - Dynamically balanced cutter unit anchored to the work table Iijdsy Ehcdjpfx Ap Djh - Especially robust design - Smooth running thanks to precision units and high dead weight - Standard with forward/reverse operation and electronic lockout during rotation reversal - Five speeds from 3000 to 10000 rpm - Convenient speed change from machine side - Standard MK 4 interchangeable spindle system - Large precision-ground cast iron work table for lasting accuracy - User-friendly controls and speed display on the front of the machine - Large-format spindle fence with fine adjustment and aluminum fence jaws standard - Fence adjustment via crank handle - Numeric display of set spindle height accurate to tenths - Powerful industrial motors TECHNICAL DATA Dimensions and Weights Net weight approx.: 510 kg Dust Extraction Number of outlets: 2 Outlet diameter: 80 mm Number of fence outlets: 1 Fence outlet diameter: 120 mm Work Table Table length: 2500 mm Table width: 810 mm Table height: 923 mm Placement Information Space requirement explanation: Dimensions include max. travel distances or working lengths Working area length: 3700 mm Working area width/depth: 5000 mm Working area explanation: Please add the specified dimensions to the space requirement to get the recommended free footprint for the machine Electrical Data Connection voltage: 400 V Network frequency: 50 Hz Drive motor power: 7.0 kW Spindle Spindle tilt: -45° to +45° Usable spindle length: 140 / 180 mm (for spindle Ø 30 – 35 / for spindle Ø 40 – 50 mm) Spindle stroke: 90 mm Interchangeable spindle: MK 4 Spindle speeds: 3000/4500/6000/8000/10000 rpm Maximum Tool Diameter Max. retractable tool diameter: 320 x 60 mm Max. profiling diameter: 250 mm Max. tenoning diameter: 350 mm Max. moulding diameter: 160 mm EQUIPMENT - Spindle fence: Heavy-duty professional version with aluminum jaws and fine-adjustment, adjusted from the front via crank handle with numerical digital display - Curved workpiece safety hood: ✔ - Spindle height adjustment: motorized, with digital readout - Spindle tilt adjustment: motorized, with digital readout - Control: motorized height and tilt adjustments with digital display - Control panel position: on machine body - Work table: extension left and right, and extendable workpiece support (total width 2500 mm) Location: ex-stock 54634 Bitburg - immediately available -

Condition: good (used), functionality: fully functional, DECKEL FP1 Active milling machine Manufacturer: Deckel Type: FP1 Active Condition: very good Control type conventional Control active HEIDENHAIN TNC X-path 300 mm Y-path 160 mm Z-path 340 mm Tool holder SK40 Speed 40-2000 rpm. Control Active HEIDENHAIN TNC Total power requirement 2 kW Machine weight approx. 0.73 t Space requirement approx. TBH 1200x1100x1600 mm Ijdsztynfjpfx Ap Doih

Condition: used, Year of construction: 2017, Milling machine Optimium Optimil F 105 Iisdpfsyphnyex Ap Doh

Condition: used, Year of construction: 1981, Technical details: x-travel: 400 mm y-travel: 420 mm z-travel: 380 mm table surface area: 710 x 400 mm max. table load: 120 kg range of revolution per miute: 45 - 2240 / 18 step U/min feed continuous: 6,3 - 600 / 2 steples mm/min quill stroke vertical: 100 mm quill stroke: horizontal: 100 mm spindle taper: vertical/horizontal: SK 40/SK40 spindle head swivable left - right: 90 ° distance table/horizontal spindle: min./max.: 200 / 325 mm distance table/vertical head: min./max.: 150 / 730 mm total power requirement: 5,5 kW weight of the machine ca.: 1,95 kg machine dimensions LxWxH: 1,7 x 1,4 x 1,9 m dimensions electric cabinet: 850x500x1500 mm The milling machine is equipped with a 3-measuring path display. incl. machine feet and operating instructions * Iodpfx Apou Nc Hkj Doih

Condition: good (used), Year of construction: 2008, functionality: fully functional, Milling machine Macmon M 434 NC Manufacturer: Macmon Iijdsztw Ehjpfx Ap Dsh Type: 434 NC Control: Heidenhain TNC 128 Year of manufacture: 2008 Condition: used X-axis: 400 mm Y-axis: 250 mm Z-axis: 400 mm Clamping surface 600 x 320 mm Main drive: AC motor kW 3 Speed range: Vertical infinitely variable 30 - 6300 Horizontal stepless 0 - 4200 - Feed rate 0 - 10 m/min Tool holder ISO 40 Operating voltage 400 / 50 Volt / Hz Control voltage 24V Weight 1200 kg Scope of delivery - Documentation - Machine feet - Coolant system - Spindle guard - Machine light - HR410 Handwheel - Horizontal spindle Counterholder

Condition: excellent (used), Year of construction: 2007, operating hours: 6,000 h, functionality: fully functional, spindle speed (max.): 10,000 rpm, • X-axis: 540 mm • Y-axis: 540 mm Iiedpfx Aez Rxhdop Deh • Z-axis: 560 mm Table: 700 x 520 mm Tool changer Control system: Siemens Sinumerik 810D 24-position tool changer Mount: SK40 Chip conveyor Coolant system Without mounts Loading possible Delivery possible upon agreement

Condition: used, x-travel 2000 mm y-travel 1500 mm z-axis 3000 mm spindle diameter 100 mm table surface area 1.400 x 1.300 mm tool taper MK | dimensions 6,4 x 3,2 x 3,4 m weight of the machine ca. 11,0 t used table borer. - some tool holders - turntable with motor - coolant system - facing plate Ø 660 Iodezmitdjpfx Ap Dsih

Condition: excellent (used), Year of construction: 2000, functionality: fully functional, The machine is in very good condition and comes from a training workshop. Technical details x-travel 300 mm y-travel 160 mm z-travel 290 mm table surface area 600 x 210 mm tool taper SK 40 spindle turning speed range (16) 40 - 2000 rpm feeds -stepless- 5 - 500 mm/min rapid traverse 1,2 m/min spindle motor 1,5 / 1,9 kW total power requirement 9,5 kVA weight of the machine ca. 830 kg dimensions of the machine ca. 2000 x 2200 x 1655 mm Equipment: Iijdpfsz Rpcrox Ap Deh * 3-axis positioning control with active digital display Heidenhain TNC 123 - Manual mode: Manual operation and positioning with manual input - Automatic mode: Single-block programme run, programme storage * Fixed angle table * Movable vertical milling head, swivel range +/- 90 degr., quill stroke 60 mm * Coolant equipment * Central lubrication * Tailstock with counter bearing * Manual

Condition: used, Year of construction: 2018, x-travel 620 mm y-travel 350 mm z-travel 400 mm table surface area 820 x 420 mm Maximum weight on the table 300 kg Isdpfxjz St Nrj Ap Dsih milling head -swivable +/- 90 ° Speed range - 2 levels 0 - 4.500 U/min feed speeds 0 - 2.000 mm/min rapid traverse 5.000 m/min total power requirement 7 kW weight of the machine ca. 1,65 t dimensions of the machine ca. 2,25 x 1,9 x 2 m

Condition: good (used), rotational speed (max.): 2,050 rpm, rotational speed (min.): 45 rpm, type of input current: three-phase, table length: 600 mm, table width: 210 mm, Used conventional milling machine Make: Metba Model: MB-1 Features a 3-axis dimension display. Table: 600x210mm Iijdpfx Aoz Dtw Sop Doh Travel: - Longitudinal with motor / Manual table: 290mm / 300mm - Vertical manual with bellows / without bellows: 270mm / 320mm - Vertical motorized with bellows / without bellows: 260mm / 310mm - Cross travel of the headstock, manual: 180+120mm Automatic feeds: - Vertical and longitudinal: 15 to 500 mm/min. - Slow feed: 7 mm/min. - Rapid traverse: 1200 mm/min. Speeds: 12 (From 45 to 2,050 rpm) Motor power: 5Hp (Three-phase 380V) Headstock type: Swivel / Universal (accepts arbor or vertical headstock). Common uses: Machining of small/medium-sized parts, prototyping, and maintenance or restoration work. Includes: - Vise with swivel - Collet chuck with various sets of collets - Various milling tools (See photographs of the material on the floor)

Condition: excellent (used), Year of construction: 2001, Kity 629 rotary tiller Motor 2,2 KW/400 Volt Table size approx. 580x715 mm Finely adjustable milling fence spindle swivel + 30° to - 5° Right/left rotation of the milling spindle Speeds 4800/6400/8700 rpm Spindle stroke 130 mm Isdjr Id S Eopfx Ap Djih Tool up to Ø 180 mm Suction connection 2 x 100 mm Location: ex stock 54634 Bitburg - immediately available -

Condition: used, Year of construction: 1976, Technical details: x-travel: 815 mm y-travel: 400 mm z-travel: 410 mm range of revolution per miute: 67 - 2300 / 8ste U/min feed continuous: 0,04; 0,08; 0,2 mm/U quill stroke vertical: 130 mm spindle taper: SK40 spindle head: drehen: 90° links/rechts spindle head: ausfahrbar: 315 mm spindle head swivable left - right: 40° vor / zurück ° distance spindle nose and table: max. 450 mm distance spindle center to column: min./max.: 170 / 600 mm table surface area: 1120 x 255 mm total power requirement: ca. 1,17 kW weight of the machine ca.: 1100 kg machine dimensions LxWxH: ca. 1,7 x 1,6 x 2,2 m dimensions of hydaulic: L: 550 x B: 330 x H: 800 mm Machine table feed 15 - 230 mm/min. via 12 steps Equipment: Sauter workpiece holder with 2 stations (Ø 125 mm and Ø 32 x 26 mm journals), hydraulic operation Coolant system Iiodpfsu R Uk Rox Ap Doh Control panel; hand crank *

Condition: used, Univ. Universal milling machine TOS, type FN 32 Year of manufacture: approx. 1980 Travel distances: X: 450 mm, Y: 240 mm, Z: 380 mm Table size: 700 x 300 mm Spindle mount: SK 40 - M16 Spindle speed: 63-2000 rpm, 18 steps Feed rate: 8-400 mm/min, 18 steps Rapid traverse rate: approx. 1400 mm/min Tailstock travel: 90 mm Main spindle motor power: 2.2 kW Connection power: 400 Volt, 50 Hz - 2-axis digital display Heidenhain, type 731B for the X and Y axes - Vertical milling head with boring quill, swiveling +/- 90° and horizontally extendable - Spindle speed via 18 gear stages - Coolant system in the machine base - Electrical control cabinet on the side of the machine - Fixed angle table Iodpfx Apez Ebu Ue Deih - Support for horizontal milling - Keyway broaching attachment, 16 to 105 strokes, stroke up to 70 mm, swiveling +/- 90° - 1 piece tool holder SK 40 with slitting cutter - Control cabinet located beside the machine Space requirement L x W x H: 1500 x 1200 x 1970 mm Weight: 1650 kg Good condition

Condition: used, Year of construction: 2002, Control Heidenhain x-travel 7.300 mm y-travel 1.500 mm Iiedpfoz Ic Aljx Ap Deh z-travel 2.000 mm spindle tunring speed 4.000 U/min tool taper SK 50 number of tool places 40 Pos. Zustand: gebraucht Verfügbar: ab März 2027 Die Maschine ist unter Strom vorführbereit. Technische Merkmale & Zubehör: - Schaltschrank neu verkabelt - Orthogonal-Indexier-Fräskopf, 1° + 2,5° - Späneförderer - Kühlmittelanlage - Plattenfeld Zubehör, abgebildete Werkzeuge und Spannmittel gehören nur zum Lieferumfang wenn dies in den Zusatzinformationen vermerkt ist. Aenderungen und Irrtuemer in den technischen Daten und Angaben sowie Zwischenverkauf vorbehalten!

Condition: used, Year of construction: 1995, CNC Milling Machine, Universal Manufacturer: HERMLE Type: UWF 902 H Year of Manufacture: 1995 Operating Hours: 46,680 Control System: HEIDENHAIN TNC 426 Ijdpfjv Rpr Sex Ap Djih Travel distances X/Y/Z: 600 x 450 x 500 mm Rotary table: 900 x 458 mm Renishaw 3D probe Spindle speed range: 20 to 6,300 rpm Tool holder: SK 40 Coolant tank Drive power: 8.6 kW Weight approx.: 4,500 kg Machine dimensions L x W x H approx.: 2,950 x 2,200 x 2,300 mm 121026

Condition: good (used), Year of construction: 2004, Ref. -No.: 10604 Manufacturer: UNION Type: TC 110 Year of construction: 2004 Type of control: CNC-Steuerung Control: SINUMERIK 840 D Powerline Storage location: Halberstadt Country of origin: Germany X-Travel: 2000 mm Y-Travel: 1250 mm Z-Travel: 1000 mm W-Axis: 550 mm Table Height: 1050 mm Spindle Diameter: 110 mm Table Dimensions (Lengthxwidth): 1600 x 1250 mm Number of T-slots: 10 Max. Workpiece Weight: 6000 kg Clamping Area: 1250 mm T - groove width: 22 mm T - slot spacing: 125 mm Tool Taper: ISO 50 Max. Torque: 1639 Nm Feed Speeds X/Y/Z Axis: 6000 mm / min Rapid Traverse X-Axis: 15000 m / min Rapid Travel Y-Axis: 15000 m / min Rapid Traverse Z-Axis: 15000 m / min Feed Capacities X/Y/Z: 16000 x 16000 x 20000 N swivel angle: 360 ° Further information: Includes angle head 0,001° Iedpfozkpv Hjx Ap Djih The machine can be viewed under power.
