Thermoformer

Multivac R 245

The Multivac R245 thermoformer is designed for the fast and efficient packaging of both food and non-food products in plastic packaging. This packaging machine is equipped with both a top and bottom labeling system, providing a complete packaging and labeling solution in a single production line.
The Multivac MR625 OP cross-web top labeler applies labels to the top side of the package and is suitable for various label formats as well as the labeling of uneven package surfaces. The Multivac MR635 UP bottom labeler applies labels to the underside of the package.
The machine is also fitted with a Multivac MR299 printing system, allowing the installation of an inkjet printer for printing up to four lines of text. The printing system supports both longitudinal and transverse printing directions.
Trim waste film from the sides of the package is cut into small pieces by an integrated shredder and subsequently extracted into a collection bag via the machine’s suction system.
This thermoformer is equipped with an integrated Dansensor 8000-2 MAP gas mixer, which precisely blends the gas mixture used for Modified Atmosphere Packaging (MAP). In addition, the machine features a stretch preheating station, enabling the processing of pre-printed bottom film without distortion of the printed material during the forming process.
The machine is constructed entirely from stainless steel, ensuring durability, easy cleaning, and compliance with stringent hygiene requirements.
Features
Vacuum packaging
MAP (Modified Atmosphere Packaging)
Technical Specifications
- Production capacity: up to 10 cycles per minute
- Equipped with a Multivac HMI touchscreen control panel
- Supplied with format set 3.2
- Tray cavity dimensions (internal): approx. 113 × 182 mm
- Package dimensions (external): approx. 127 × 195 mm
- Film type: rigid film
- Film width: 420 mm
- Index length: 390 mm
Registration mark sensor for top film
Loading area length: 2,663 mm
Equipped with 2 × Busch vacuum pumps, 300 m³/h each
Equipped with 1 × Busch Panda Roots booster pump, 500 m³/h
Equipped with 3 die-cutting stations
Equipped with 2 QRF rotary knives
Fsdpszcragefx Ahnegc
Intralox discharge conveyor belt
Utility Requirements
Water supply pressure: 1.5 – 4.5 bar
Compressed air pressure: 7 – 10 bar
Electrical Data
Voltage: 400 V (3+N, 50 Hz)
Power consumption: 26.5 kW
General Information
Weight: 4,000 kg
Year of manufacture: 2009
Machine dimensions (W × D × H): 12,000 × 1,880 × 2,350 mm
