Universal machining center

DECKEL MAHO DMU 70

Condition: used, Year of construction: 2002, x-travel 750 mm y-travel 600 mm z-travel 520 mm control iTNC 530 Heidenhain turning speed range - main spindle 20 - 18.000 min/-1 power capacity - main spindel 35 / 25 kW max. Torque 130 / 87 Nm tool taper HSK-A63 table surface area 700 x 500 mm Swivel range B-Axis 0 - 180 ° Swivel range C-Axis 0,001 ° max. table load 350 kg center hole 30 H6 mm T-slots 7x 14H7 x 63 mm table turning speeds 21,5 rpm number of toolpositions 32 pos. max. tool length 315 mm max. tool diameter 105 mm max. tool-dia with free toolbox 130 mm max. tool weight 6,0 kg rapid traverse ( X / Y / Z ) 50 / 50 / 50 m/min feed speeds 20.000 mm/min Feed force X / Y / Z: 8 / 8 / 7 kN total power requirement 50 kVA weight of the machine ca. 8,5 t dimensions of the machine ca. 6,5 x 3,5 x 3,5 m 5 Axis-CNC-Machining Center DECKEL MAHO - DMU 70 eVolution - 5 Axis - NC-Swivel-Rotary-Table Bjdpfxsuntmdj Aknewu - Operating-Hours: Power-On: ca. 62.500h / Spindle: ca. 15.100h

Condition: good (used), Year of construction: 2000, functionality: fully functional, machine/vehicle number: 018.0179.90.035, (Please tell us your offer price) Sale only within Europe, incl. Turkey Price without packaging; delivery condition: FCA (machine location) ===== Technical data see handout. All warranty rights are excluded. For the correctness of the technical data and year of construction, for the completeness of accessories and tool equipment, and for compliance with all safety and environmental protection requirements specified in the accident prevention regulations. No sale to private individuals. Bodpfx Aoyh R Uwjknewu Sales only within Europe, incl. Turkey Price without packaging; Delivery condition: FCA (machine location) ===== Technical data please see handout in attachment. German text leading language. Without any guaranty and warranty, including completeness of tools & accessories as well as environmental and safety regulations. No private sales.

Condition: used, Year of construction: 2005, X-axis: 750mm, Y-axis: 600mm, Z-axis: 520mm, B-axis: 180°, C-axis: 360°, max. table load: 350kg, tool changer: 32-position, max. spindle speed: 18,000rpm, rapid traverse: 50m/min, max. feed rate: 20,000mm/min, tool holder: SK40, control: Heidenhain Mill Plus iT, spindle operating hours: 6,000h, with through-spindle coolant, chip conveyor, replacement spindle has 6,000h, X- and Y-axis guideways repaired in 2024, X-axis measuring system replaced in 2025, rotary union replaced in 2025, both chain changer motors replaced in 2025, an on-site inspection is possible. Bwedez Ea Rujpfx Akneu

Condition: good (used), Year of construction: 2000, functionality: fully functional, travel distance X-axis: 2,050 mm, travel distance Y-axis: 520 mm, travel distance Z-axis: 520 mm, rotational speed (max.): 12,000 rpm, CNC control Heidenhain TNC 430 32-fold tool changer coolant device 2x chip conveyor measuring feeler The hole X-axis travel is 2050mm. You can work in one move 2 meters. A dividing wall is also with the machine. Then the X-travel will be split. Technische Daten / technical details: X-Weg / X-travel 2050 mm Y-Weg / Y-travel 520 mm Z-Weg / Z-travel 520 mm Spindelaufnahme / spindle taper SK40 Drehzahlbereich / spindle speed 12000 UpM /rpm Werkzeugwechselmagazinplätze / number of tool places in changer 2x 32 Antriebleistung Spindel / drive capacity spindle 36 kW Gewicht ca. / weight 12800 kg Bjdeu Hf Ryspfx Aknewu Technische Daten, Zubehör und Beschreibung der Maschine sind unverbindlich - Technical data, accessories and description of the machine are not binding.

Condition: used, Lasko hammer KGK 063 Impact force 630 mkp Stroke max. 630 mm Bear weight 630kp Top pressure - filling pressure 5 bar Bwodpfsu Eb Nijx Aknsu

Condition: used, Year of construction: 2001, Manufacturer: DECKEL MAHO (DMG) Model: DMU 70 VL Year of Manufacture: 2001 Control Unit: HEIDENHAIN TNC 430 Machine Type: 5-Axis Universal Machining Center Working Range / Travels: X-axis: 710 mm Y-axis: 520 mm Z-axis: 520 mm B-axis (Swivel range): -10° / +95° (NC-controlled) C-axis (Rotary table): 360° (NC-controlled) Work Table: Table Type: NC Swivel-Rotary Table Clamping Surface: Ø 700 x 500 mm Max. Table Load: 350 kg Milling Spindle: Max. Spindle Speed: 12,000 RPM (Motor Spindle) Drive Power (40% / 100% ED): 15 kW / 10 kW Tool Taper: SK 40 (DIN 69871) Tool Changer: Bjdpfxoyh Nm Sj Aknowu Magazine Positions: 30 slots Max. Tool Diameter: 80 mm / 160 mm (with empty adjacent pockets) Max. Tool Length: 315 mm Max. Tool Weight: 6 kg Feed Rates & Motion: Rapid Traverse (X/Y/Z): 30 m/min Max. Feed Rate: 20,000 mm/min Weight & Footprint: Machine Weight: approx. 5,500 kg Total Power Requirement: 40 kVA Space Requirements: approx. 4.0 m x 3.0 m x 2.8 m Equipment & Features: High-End Control: Heidenhain TNC 430 5-Axis Capability: Full NC swivel/rotary integration.

Condition: used, Year of construction: 2000, operating hours: 3,273 h, machine/vehicle number: 15015702974, travel distance X-axis: 710 mm, travel distance Y-axis: 520 mm, travel distance Z-axis: 520 mm, torque: 130 Nm, controller manufacturer: Heidenhain 426/430, workpiece weight (max.): 350 kg, total height: 2,724 mm, total length: 2,756 mm, total width: 2,020 mm, table width: 500 mm, table length: 700 mm, rotary table diameter: 700 mm, overall weight: 5,500 kg, spindle speed (max.): 12,000 rpm, spindle motor power: 15,000 W, number of spindles: 1, number of slots in tool magazine: 32, input voltage: 400 V, type of input current: three-phase, Equipment: chip conveyor, documentation/manual, 5-Axis Machining Center DECKEL MAHO DMU 70V We offer for sale an advanced, universal vertical machining center, the Deckel Maho DMU 70V (part of the renowned DMG MORI group), equipped with a numerically controlled (NC) rotary/tilting table. The machine features a compact and robust design, minimizing its footprint in the production hall while offering full capabilities for advanced 5-axis machining. AXIS SPECIFICATIONS AND WORKING AREA • Axis travel (XYZ): X = 710 mm | Y = 520 mm | Z = 520 mm • Working travel: 710 mm (X) / 520 mm (Y) / 520 mm (Z) INNOVATIVE NC ROTARY/TILTING TABLE (4th and 5th AXIS) • Mounting surface dimensions: ∅ 700 mm x 500 mm (practical design with factory-cut sides, facilitating optimal mounting of vises and fixtures) • Maximum table load: 350 kg (full mechanical safety of the gearbox, bearings, and measuring system) • Axis rotation range: • C-axis (rotation): continuous / multi-rotation operation (advanced trochoidal milling strategies) • B-axis (tilting): wide working range of over 180°, providing excellent access to the workpiece and freedom for angled undercutting MAIN DRIVE AND SPINDLE • Spindle speed: continuously (steplessly) adjustable in the range of 20 – 12,000 rpm Bsdpszumh Ijfx Aknjwu • Spindle power: 15 kW • Maximum torque: up to 130 Nm (powerful cutting force guaranteeing excellent stiffness and stability during heavy rough machining of hard materials) CONTROL SYSTEM AND TOOL MAGAZINE • Control system: Reliable and widely appreciated by operators, the Heidenhain 426/430 (simple dialog programming, intuitive menu) • Tool magazine: Automatic, compact chain-type magazine with a capacity of 32 positions (fast tool change in automatic cycles) LOGISTICAL AND CONNECTION PARAMETERS • Overall dimensions of the machine ready for operation (with chip conveyor): • Length: 2756 mm • Width: 2020 mm • Transport height: 2724 mm (the machine fits easily on standard trailers and passes through conventional hall doors) • Total machine weight: approx. 5,500 kg • Maximum power consumption (connection): up to 42 kVA • Input voltage: 400 V (AC - three-phase current) • Current protection (fuse): 63 A • Power supply frequency: 50/60 Hz MACHINE CONDITION AND ADDITIONAL INFORMATION The machine is in good technical condition, regularly serviced and maintained. It is ideally suited for both serial production and tool shops producing complex molds, dies, and precise 5-axis parts. The machine comes complete with a chip conveyor.

Year of construction: 1997, condition: ready for operation (used), - USED - CONVENTIONAL LATHE CENTRE HEIGHT: 102 mm DISTANCE BETWEEN CENTRES: 450 mm MAX TURNING DIAMETER OVER BED: 200 mm MAX TURNING DIAMETER OVER CARRIAGE: 120 mm BAR CAPACITY: 25 mm SPINDLE: 50 - 5000 rpm; 3 kW TAILSTOCK TAPER: CM 2 QUILL DIAMETER: 30 mm QUILL TRAVEL: 80 mm TURRET HEAD: MULTIFIX Bodeyvlxqepfx Aknswu OVERALL DIMENSIONS: 1500 x 510 x 1550 mm

Condition: good (used), Year of construction: 1997, machine/vehicle number: 570035, functionality: fully functional, input voltage: 400 V, type of input current: three-phase, travel distance X-axis: 710 mm, travel distance Y-axis: 520 mm, travel distance Z-axis: 520 mm, total height: 3,300 mm, total length: 4,600 mm, total width: 5,500 mm, overall weight: 6,000 kg, table length: 700 mm, table width: 500 mm, feed rate X-axis: 10 m/min, feed rate Y-axis: 10 m/min, feed rate Z-axis: 10 m/min, spindle motor power: 25,000 W, rapid traverse Z-axis: 30 m/min, rapid traverse X-axis: 30 m/min, rapid traverse Y-axis: 30 m/min, spindle speed (max.): 12,000 rpm, spindle speed (min.): 20 rpm, Equipment: documentation/manual, 5-axis machining center, manufacturer: DECKEL MAHO, type: DMU 70 V, year of manufacture: 1996, serial no.: 570035, travel X/Y/Z): 710/520/520 mm, HEIDENHAIN control, max. spindle speed 12,000 rpm, 60-fold tool changer, compact filter system INTERLIT SUK200/900, year of manufacture: 1997, filling volume 900 l, filter surface 0.2 m³, chip conveyor, internal coolant supply Comment: 1 tool changer defective Bwjdpfx Asrkz A Isknju

Condition: ready for operation (used), Year of construction: 2003, A Deckel Maho 5-axis CNC universal machining center is offered, including an Interlit compact filtration system for the coolant supply. 1) Deckel Maho DMU 70 eV 5-axis CNC universal machining center, year of manufacture: 2003, X/Y/Z travels: 750mm/600mm/520mm, B-axis: approx. 180°, C-axis: 360°, rapid traverse X/Y/Z: 50m/min, feed rate: approx. 20m/min, max. spindle speed: approx. 18000rpm, spindle power: approx. 25kW, max. rated power: approx. 35kW, spindle torque: approx. 87Nm, tool holder: SK40, table dimensions X/Y: approx. 700mm/500mm, max. table load: approx. 200kg, tool magazine: 32, weight: approx. 8500kg. 2) Interlit SUK 200-900 compact filtration system, year of manufacture: 2003, filter area: 0.2m², filling volume: 900l. Inspection by prior arrangement is possible. Bwsdpfx Ajzrn Iqoknju

Condition: used, Year of construction: 2009, faceplate diameter 3000 mm swing diameter 3500 mm turning height 3200 mm Control Fanuc type Series 320i Model A slide adjustment 1750 mm ram head dimension 300x300 mm x-axis 2700 mm Table load 30000 kg main drive motor 100 kW Tool changer 16 Bwedpfx Asyqu Rweknsu weight of the machine ca. 89 t dimensions of the machine ca. 8,5x6x8 m No. 1104 The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale; Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team

Condition: ready for operation (used), Year of construction: 2009, travel distance X-axis: 750 mm, travel distance Y-axis: 600 mm, travel distance Z-axis: 520 mm, controller manufacturer: SIEMENS, spindle speed (max.): 24,000 rpm, spindle motor power: 35,000 W, number of axes: 5, This 5-axis DMG DECKEL MAHO DMU 70 EVO Linear was manufactured in 2009. It features a working area with X-axis travel of 750 mm, Y-axis travel of 600 mm, and Z-axis travel of 520 mm. The machine is equipped with a high-speed spindle capable of reaching 24,000 rpm and a tool magazine with a capacity of 120 positions. It includes a DMG PH 150 L8 automation. If you are looking to get high-quality machining capabilities, consider the DMG DECKEL MAHO DMU 70 EVO Linear machine we have for sale. Contact us for further details. Bwedpfx Akjymcvmeneu • Feed rates: linear 20,000 mm/min; rapid traverse 50,000 mm/min • Table: clamping surface 700 × 500 mm • Tool magazine: 120 positions • Through-spindle coolant: high-pressure 40 bar • Documentation: instruction manuals and CE declaration Additional equipment • Coolant tank with paper filter, 600 L • Measuring probe • Chip conveyor • Electronic handwheel (remote) • Pallet changer system DMG PH 150 L8, 8 stations (pallets not included) Technical Specification Taper Size HSK 63

Condition: ready for operation (used), Year of construction: 2004, operating hours: 18,183 h, functionality: fully functional, machine/vehicle number: 15035709304, travel distance X-axis: 700 mm, travel distance Y-axis: 600 mm, travel distance Z-axis: 520 mm, swivel angle B-axis (max.): 180 °, swivel angle C-axis (max.): 360 °, The machine will remain powered until 06.03.2026. TECHNICAL DETAILS Travel distances X-axis travel: 750 mm Y-axis travel: 600 mm Z-axis travel: 520 mm C-axis: ±360° B-axis: 180° Spindle type: SK-40 Spindle speed: 18,000 rpm Rotary table Clamping surface: 700 × 500 mm T-slot spacing: 63 mm Number of T-slots: 7 T-slot size: 14 H7 Centering bore: 30 H6 Rotary axis torque: max. 1,674 Nm Table rotation speed: max. 21.5 rpm Swivel torque: max. 2,019 Nm Swivel speed: 18.9 rpm Swivel range: 0 – 180° Input/display unit: 0.001° Bsdpfxeymmpds Aknowu Maximum tool length from spindle nose: 315 mm Maximum tool weight (with automatic tool changer): 6 kg MACHINE DETAILS Control system: Siemens 840D Shop Mill Operating hours Power-on hours: 65,794 h Spindle hours: 18,183 h Dimensions & Weight Machine dimensions (L x W x H): 2,604 x 2,820 x 2,785 mm Machine weight (including base): 9,255 kg EQUIPMENT 5-axis simultaneous machining 32-position tool changer Chip conveyor IKZ (internal coolant supply) with 70 bar Blum TC50 spindle probe

Condition: good (used), Year of construction: 2017, functionality: fully functional, We offer you: CNC machining center, universal Manufacturer: DMG MORI Type: DMU 80 evo Year of manufacture: 2017 Control: Heidenhain TNC 640 Technical data: Bwjdpfx Aksz Eby Roneu Travel ranges: X-axis: 800 mm Y-axis: 650 mm Z-axis: 550 mm Rotary range C-axis: 360° Swivel range B-axis: -5° to +110° Main spindle: Tool interface: HSK-63A Speed range - main spindle: 20,000 rpm Drive power - main spindle (100/40%): 35 / 25 kW Torque: 130 / 86 Nm Rotary table: Table dimensions: 800 x 700 mm Max. table load: 600 kg Tool changer: Number of tool positions: 120 Feed rates: Rapid traverse (x/y/z): 50 m/min Operating hours: approx. 36,600 h Spindle hours: approx. 20,350 h Technical features & accessories: - Active cooler - Direct path measuring system in all axes - Full enclosure - Articulated belt chip conveyor - Coolant nozzle - MPC – Machine Protection Control - NC swivel rotary table incl. table cooling - Internal coolant supply 40 / 80 bar, consisting of: - 980 l tank - Purge air for linear measuring systems - Bed flushing - Extended chip flushing - Coolant temperature control - Oil and emulsion mist separator, mechanical - Blow-off air through the spindle center - Infrared measuring probe, manufacturer Heidenhain TS 649 - Laser tool measurement, manufacturer BLUM NT - Preparation for 3D quickSET - Preparation for handling system PH 150-8 - Operating mode 4 - Free M-functions - Automation, manufacturer Zero Clamp Zerobot 100P Accessories, tools and clamping devices shown in the pictures are only included in the scope of delivery if this is noted in the additional information. Changes and errors in the technical data and information, as well as prior sale, are reserved!
