Universal machining center

DMG DMC 340 U

Condition: used, Year of construction: 2019, x-travel 3.400 mm y-travel 3.400 mm z-travel 1.600 mm Control CELOS 840D sl Op Siemens max. spindle speed 20 - 15.000 min/-1 power capacity - main spindel 52 / 42 kW tool taper HSK-A100 max. Torque 404 / 280 Nm swivellable B: -30° / +180 ° table diameter 2.500 x 2.000 mm max. table load 10.000 kg table speed 5 min/-1 distance spindle center to table hor.: 130 - 1.730 mm distance spindle center to table vert.: 230 - 1.830 mm distance spindle nose and table hor.: -1.500 - 1.900 mm distance spindle nose and table vert.: -1.600 - 1.800 mm type 5x Rad- / Wheel number of toolpositions 303 pos. Gedex H Tt Depfx Ag Tstt max. tool diameter 110 mm max. tool-dia with free toolbox 280 mm max. tool length 900 mm max. tool weight 45 kg tool changing time 7,5 sec tool taper HSK-A100 rapid traverse 60 / 30 / 40 m/min total power requirement 140 kVA weight of the machine ca. 106 t dimensions of the machine ca. 14,0 x 13,0 x 7,0 m 5-Axis-CNC-Heavy-Duty-Machiningcenter Universal DMG MORI - DMC 340 U - Pallet Changer 2 pos. - Accuracy package - MDynamics package (Improved surface finish with reduced machining time) - Only approx. 10,500 spindle hours - Cone cleaning station with rotating brushes - Balluff tool identification - Machine protection via rapid shutdown (MPC) - Laminated safety glass - Machine design for pit installation - Heidenhain linear scales (instead of Magnescale) - Camera remote system with screen on the control panel
