FIMAL concept 350

FIMAL concept 350

Condition: new, engine output 5 kW Dedpfswli Nrex Aidsuw saw-blade dia. 300-350 mm Working speed 0-40 m/min weight ca. 1.300 – 1.800 kg kg

Condition: new, Year of construction: 2026, The composition of the cabinet handling systems to create a manual, semi- or fully-automatic cabinet assembly line is depending on individual production requirements. Cabinet assembly lines that will make work easier, reduce set-up time and increase precision, we will explain to you in a personal conversation. Dusdpfxedx R D Do Aidsw

Condition: used, Year of construction: 2016, total length: 6,400 mm, total width: 1,500 mm, total height: 1,700 mm, Weight: 1.500 kg Price: On request - Year: 2016 - Documentation available: No - CE certificate present: No - Max. cutting length [mm]: 3200 - Min. saw blade diameter [mm]: 300 - Max. saw blade diameter [mm]: 350 - Arbor saw blade diameter [mm]: 30 - Dust extraction nozzle diameter [mm]: 120 - Spindle speed: Automatic - └ Max. spindle speed [rpm]: 4000 - Voltage [V]: 400 - Current consumption [A]: 18.5 - Fuse [A]: 25 - Transport dimensions: 6400mm x 1500mm x 1700mm (l x w x h) - Transport weight [kg]: 1500kg - Transport packages [pcs.]: 2 Financial information VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Delivery and trade-in always possible for everything in the industrial sectors Dodpfxjyvh Rvo Aidjuw Yorick Diebels

Condition: excellent (used), Year of construction: 2015, functionality: fully functional, Cutting length: 3200 mm Maximum width: 1300 mm Blade diameter: 300 - 350 mm Duedpjzk H Rbjfx Aidow Saw blade tilt: 0-45° Blade rotation speed: 4000 rpm Approximate weight: 1300 kg.

Condition: excellent (used), C.N.C. WORKING CENTER 3 axes (X-Y-Z) Vertical position of the panel (workpiece) Movable panel (workpiece), movable working head Numerical Control POWERCONTROL + POWERTOUCH Software woodWOP Duodpfxeyywcvj Aidew Safety cabin (enclosure) of the working head No. 1 Workpieces fixing clamps (for the panels introduction in the working area Panels feeding by motorized chain/track Minimum workpieces dimensions (X - Y - Z) mm 200 x 70 x 8 Maximum workpieces dimensions (X - Y - Z) mm 3050 x 850 x 56 Total installed power (Kw) 11,5 (ca.) WORKING GROUPS: No. 1 Drilling head (power Kw 2.3) with vertical spindles - No. 13 Independent vertical boring spindles (V13 High Speed) - No. 6 Independent horizontal boring spindles (4 in X + 2 in Y) No. 1 Circular Grooving Saw (on X axis) dia. (mm) 100 No. 1 Vertical electro-spindle (HKS63) power Kw 5 Automatic Tools Changing System - Tools storage plate (No. 4 folds-positions)

Condition: excellent (used), Year of construction: 2022,

Condition: ready for operation (used), Year of construction: 2016, functionality: fully functional, saw blade diameter: 350 mm, saw blade bore: 30 mm, rotational speed (max.): 4,000 rpm, cutting length (max.): 3,200 mm, intake manifold diameter: 120 mm, TECHNICAL DETAILS Max. cutting length: 3,200 mm Saw blade diameter min.: 300 mm Saw blade diameter max.: 350 mm Saw blade bore diameter: 30 mm Dust extraction nozzle diameter: 120 mm Max. spindle speed: 4,000 rpm (automatically adjustable) MACHINE DETAILS Voltage: 400 V Dedpfoy Ai U Aex Aideuw Power consumption: 18.5 A Fuse: 25 A Transport packages: 2

Condition: used, machine/vehicle number: 008125, Type of edging: Thin edge, Thick edge Gluing System: EVA Hotmelt, Hot Air Duedpfx Asw Tivmsidsw Premilling Unit: yes Corner Rounding Unit: yes Max feed speed: 18 m/min Operating Units: 7 nr

Condition: new, - NEW - Concept 350 ELITE Partnership Edition - Cutting length 3200 mm - General Features: - Aluminium machine and extension tables - Saw unit tiltable up to 46° - Pressure beam, incl. LED lighting with 3 different indicator colors: WHITE: Machine in standby RED: Pressure beam lowering or emergency stop function BLUE: Saw unit in operation - Variable support table, 1,000 x 500 mm - Scoring system via main saw blade in the same direction of rotation - Automatic workpiece length detection for minimal travel distances - Mobile and height-adjustable control panel, incl.: Saw blade holder, template holder, emergency stop button, start button, selector switch for grooving / scoring / sawing, feed speed rotary switch, switch for laser (option), and USB socket Partnership Edition includes: - Motorised rip fence with 4 aluminium stops, synchronized traversing Dodswzmvbepfx Aidsuw All 4 stops travel up to 1,300 mm. Table length approx. 2,000 mm. - Windows 10 display control (10" touchscreen). The graphical interface offers the following functions: Tool database, mitre cut calculation at the length stop, Cutting plans can be created and saved, programs can be stored, exported, and imported via USB. - Telescopic stop extendable to 3,400 mm, including 2 digital displays Technical Specifications: - Max. saw blade projection: 350 mm - Saw blade: 100 mm at 90° / 70 mm at 45° - Saw blade diameter: 300 – 350 mm, bore 30 mm - Saw blade speed: 4,000 rpm - Motor: 5 kW (= 7.5 HP) - Feed speed: 0 – 40 m/min - Overall length: approx. 4,250 mm - Weight: approx. 1,300 – 1,700 kg (depending on cutting length and configuration) - Required air pressure: 7 bar - Extraction ports: 1 x 100 mm, 1 x 120 mm - Order No.: FIMAL379 Including: - Motorised rip fence with 4 aluminium stops, traversing up to 2,100 mm instead of 1,300 mm. Order No.: 47/17 - Cutting line laser Order No.: 3410451 - Saw motor with 7.5 kW (10 HP) incl. automatic star-delta start Order No.: Programmable saw blade height adjustment incl. height correction when tilting the saw unit Optional accessories at extra cost: - Mitre stop +/- 50° tiltable with length compensation Order No.: 3380132 including telescopic stop and folding stop

Condition: as good as new (ex-display), functionality: fully functional, power: 7.35 kW (9.99 HP), cutting height (max.): 105 mm, cutting width (max.): 2,100 mm, saw blade diameter: 350 mm, total length: 4,300 mm, The FIMAL CONCEPT 350 ELITE is the further development of the proven CONCEPT 350 PLUS, setting new standards in precision, safety, and efficiency. With a reinforced machine base, optimized extraction system, and a redesigned Multistop fence table, it offers even greater comfort and performance for joiners, furniture makers, and industrial panel processing. Thanks to its pressure beam with automatic feed, the ELITE combines the flexibility of a sliding table saw with the cutting quality of a pressure beam saw – all within a footprint of just 28 m². Technical Specifications ⦁ Aluminum machine and extension tables ⦁ Saw unit tiltable up to 46° ⦁ Pressure beam, including LED lighting with 3 different action colors: WHITE: Machine in stand-by RED: Pressure beam lowering or emergency-stop function BLUE: Saw unit in motion ⦁ Versatile support table 1,000 x 500 mm ⦁ Scoring system via the main saw blade (co-rotating) ⦁ Automatic workpiece length detection for minimal travel distance ⦁ Mobile and height-adjustable control panel, including: Saw blade holder, template holder, emergency-stop button, start button, selector switch for grooving/scoring/cutting, rotary switch for feed speed, switches for laser (option) and USB socket ⦁ Max. saw blade projection (350 mm blade): 100 mm at 90° / 70 mm at 45° ⦁ Saw blade: diameter 300 – 350 mm, bore 30 mm ⦁ Saw blade speed: 4,000 rpm ⦁ Motor: 5 kW (= 7.5 HP) ⦁ Feed speed: 0 – 40 m/min ⦁ Total length: approx. 4,250 mm ⦁ Weight: approx. 1,300 – 1,700 kg (depending on cutting length and configuration) ⦁ Required air pressure: 7 bar ⦁ Extraction port: 1 x 100 mm, 1 x 120 mm ⦁ Extension table length: 3,670 mm / 4,270 mm / 4,870 mm (total length) ⦁ Tilting range: 0 - 46° ⦁ Sliding table: 1,000 x 400 mm (extension table) ⦁ Crosscut fence: 3,200 mm with 2 digital flip stops ⦁ Speed: 4,000 rpm ⦁ Air requirement: 6 bar ⦁ Motor voltage: 400 V (50 Hz) ⦁ Feed speed: 0 - 40 m/min Dusdpfew Axf Rex Aidjw Options Multistop, cutting width 2,100 mm instead of 1,300 mm Programmable saw blade height adjustment Miter fence +/-50° Cutting line laser Including delivery and installation within postal code areas 71,72,73,77,78,79,86,87,88,89

Condition: new, Year of construction: 2026, Bio Machines has been designing production lines, manufacturing machinery, and providing assembly services for over 20 years. We offer both complete production lines and individual machines, tailored to your needs. Our solutions include: Pellet production lines Briquette production lines Drying systems: rotary and belt-type Hammer mills Moving floors Feed bins Wood chippers Chain, bucket, screw, and belt conveyors Cyclones Silos Pellet coolers Sawdust and pellet sifters Bagging machines for small bags and big bags Palletizing lines for bags And many other specialized machines Dedjylm Tyopfx Aidjuw

Condition: as good as new (ex-display), Year of construction: 2023, functionality: fully functional, power: 7.35 kW (9.99 HP), input voltage: 400 V, input frequency: 50 Hz, cutting height (max.): 105 mm, cutting width (max.): 1,300 mm, saw blade diameter: 350 mm, rotational speed (max.): 4,000 rpm, total length: 4,300 mm, overall weight: 1,300 kg, cutting length (max.): 3,200 mm, pivoting range: 45 °, The Concept 350 combines the advantages of various saw systems: As flexible as a panel saw, the cutting quality of a pressure beam saw, and as ergonomic as a trimming saw. This is the sawing concept for modern industrial production. The machine is a leasing return. Further technical data: - Motorized rip fence with 4 aluminum stops, which move synchronously - Screen control with 8" touchscreen - Air requirement: 6 bar - Sliding table: 1,000 x 400 mm (extension table) - Outrigger table size: 3,200 mm with 2 digital stop jaws - Extraction connection: 1 x 100 mm, 1 x 120 mm Dujdpfxowzuipo Aidsw - Feed speed: 0 - 40 m/min Special features: - Programmable saw blade height adjustment - Mitre fence +/- 50° - Cutting line laser - Additional support table 800 x 200 mm With the new Concept 350, you no longer need a panel saw! The workpiece rests on the machine and is positioned precisely with a pressure beam. The saw unit can be swiveled from 90° to 45°, is guided with precision, and cuts your workpiece at a constant feed speed of 0–40 m/min, ensuring the best possible cutting results. The standard crosscut fence enables quick cutting to length and efficient operation, with significantly less space required compared to any sliding table saw! Advantages over a sliding table panel saw: - Significantly less space required - The pressure beam secures the workpiece on the machine and guarantees optimal cutting results - The pressure beam prevents the operator from reaching into the saw blade - Ergonomic operation, as the operator no longer has to push the material through the saw blade - Time saving, as the operator does not need to guide the material during the sawing process Including delivery and installation within postal code areas 71, 72, 73, 77, 78, 79, 86, 87, 88, 89.
