Vertical machining center

MÜGA S 3030

Condition: excellent (used), Year of construction: 2006, FAMUP MCP 45 CNC machining center TECHNICAL DATA axes Number of axes: 3 X-axis: 450 mm Y-axis: 300 mm Z-axis: 400 mm Feed rate Work feed X,Y,Z: 10`000 mm/min Rapid feed X,Y,Z: 30`000 mm/min Working pressure force X,Y: 2000 N Working pressure force Z: 3300 N Pallet Dimensions: 400 x 300 mm Number of grooves: 2 Groove width: 14 mm Groove spacing: 80 mm Max. Table load: 100 kg Changeover time: 9 sec. Bjdpfxoq U Rm Hs Ap Iodd Spindle Spindle motor power: 5 kW Speed: 10`000 rpm Tool changer Magazine slots: 16 Max. Tool diameter: 63 mm Max. Tool length: 150 mm Max. Tool weight: 4 kg Tool change time: 1.7 sec Weight: Approx. 3000 kg No responsibility is taken for the correctness, completeness and up-to-dateness of the information.

Condition: good (used), Year of construction: 1999, functionality: fully functional, Machine new white-color in 2014 (order by SIEMENS Energy) Technical Data Working area Max. swing over bed: 570 mm Max. swing over cross slide: 365 mm Max. turning length: 1500 mm Centre height over flat bed: 280 mm Max. workpiece weight: 400 / 1000 kg Max. workpiece clamping length: 1300 mm Work spindle Spindle head DIN 55027, size 8, internal taper 70 Spindle bore: Ø 62 mm Spindle diameter in front bearing: 100 mm Spindle through-hole (depth): 200 mm Max. chuck size: Ø 315 mm Speed range: 3–2500 rpm Max. faceplate diameter: Ø 560 mm Max. faceplate speed: 700 rpm Max. torque: 1800 Nm Carriage – travel Longitudinal travel (Z-axis): 1160 mm Cross travel (X-axis): 345 mm Tooling system: Parat-3 Tool cross-section DIN 770 (h × b): 32 × 25 mm Tailstock Tailstock movement by hand Quill taper: MK5 (MT5) Quill diameter: 80 mm Quill stroke: 190 mm Accessories / special equipment CNC control: SINUMERIK 810 D 32-bit processor, digital control ManualTurn with cycle support 10.4" colour LCD display Operating manual 094.0003.1330-00 3-jaw chuck Ø 315 mm Faceplate Ø 350 mm (up to Ø 560 for thin workpieces) Bdedpfxjx Ahx Ds Ap Ijd Radius turning function Turret on support: size 3, Parat 4-station, manually indexable 4 × 90° Chip conveyor Bürener Maschinenfabrik Particularly suitable for: see production spectrum

Condition: used, Year of construction: 2002, Machining dimensions (tool diameter 25mm): X=3015 mm Y=1483 mm Z=325 mm Max. travels: X=3268 mm Y=1483 mm Z=325 mm Max. programming speed: X/Y = 75 m/min / Z = 30m/min Tool holder HSK 63F Drilling unit 7964, 14 vertical drilling spindles with 32 mm grid (10 in x / 4 in y) Sawing unit 7946 3.6 kW, 90° pneumatically pivotable Milling unit 7933 9 kW Wood Her Vector axis (C-axis) Tool magazine (6 disk places) Hand control unit Laser device (positioning of the suction cups) PC control panel with 17" monitor Operating system Windows 2000 Software: TwinCAM32 - office version Vacuum pump 100 m³/h Dry running Selective safety mats (3-field division) Storage location: Nattheim Bodpfx Apsvvi Nbj Isdd

Year of construction: 2019, operating hours: 1 h, condition: as good as new (ex-display), machine/vehicle number: MISCO1082, Oil Mist Collecting and Regaining. MISCO is used for collecting and getting rid off the oil in the CNC machines cabin. It is a water vapor, aerosol, smoke, oil mist filtering / separating device. Also allows condensing and recycling the condensed liqud back to the sump Bdedpod Nwk Usfx Ap Ied The particulate-smoke-gas-water in the air sucked in is filtered through the vapor separation units. The saturated oil-water etc. contained in the air is also separated and recovered, and the air is cleaned by 98% of the dry air. Removal of parts washing machines vapor-mist, Welding fumes, Oily air off CNC machines In the industry and even In the industrial kitchens a lot of oil mist, various gases, fumes and dusts are mixed into the air and create a risk of fire. In addition, they are inhaled by workers and cause damage especially to the lungs, respiratory tracts and other vital organs. For this reason, harmful substances such as gas, dust, smoke and similar substances must be cleaned by absorbing harmful substances in terms of safety and health. Application Areas: CNC Machines Welding fumes, Allows removal of oil vapor and recovery of existing fluid in CNC machines Automotive - Metal Processing – Food Industry - Industrial Kitchens - Steel - Casting - Chemical Industries etc. Working Principle; 1-Entry of dirty smoke –vapor- mist 2- Condensation with laminar flow over the walls 3- Disintegration of the particles passing through the filter 4-Recycling of condensing liquid 5-Dry and clean air evacuation For detailed information please contact us. mistcollector, cnc cutting oil, fume removal, cutting oil fume collector

Condition: used, table length 400 mm table width 300 mm x-travel 300 mm y-travel 250 mm Bedpfx Aevwgq Sjp Iodd z-travel 250 mm weight of the machine ca. 1,2 t dimensions of the machine ca. 2000 x 1200 x 2500 mm The machine is supplied with a wide range of accessories

Condition: used, Year of construction: 2005, - Fagor 8055 CNC control - Additional tank for internal spindle cooling (15 bar) 400 liters - Year of construction 2005 Technical data: - Travel X/Y/Z: 610 / 455 / 520 mm - Rapid traverse: 24 m/min - Working spindle speed: 8000 rpm Bedpfx Aetvf Htep Ijdd - Tool holder: BT40 - Table size: 762 x 363 mm - Maximum table load: 350 kg - Motor power: 18 kW - Operating voltage: 400 V - Weight: 3140 kg

Condition: good (used), Year of construction: 2000, High-performance CNC vertical machining center with SIEMENS 840 D, dual pallet changer, internal coolant system, linear guides, and 30-tool automatic tool changer. Table size: 2 x 1000 x 450 mm Tool holder DIN 69871: ISO 40 Travel ranges: X-axis: 1100 mm Y-axis: 500 mm Z-axis: 640 mm Spindle speed range: 50 – 10,000 rpm Table load: 600 kg Feed rate range, X/Y/Z, stepless: -10,000 mm/min Rapid traverse in all axes: 30 m/min Drive power: 18.5 kW Machine dimensions L x W x H: approx. 3605 x 3041 x 3220 mm Weight: approx. 6700 kg Accessories / Special features: • CNC control system SIEMENS 840 D • Dual pallet changer • 30-tool automatic tool changer • Full enclosure with safety doors, electrically secured • High spindle speed up to 10,000 rpm and drive power of 18.5 kW • Linear guides with double roller recirculating bearing, allowing high torques to be absorbed evenly in all directions • Ball screws in all 3 axes • The entire machine bed is made of Meehanite cast iron, ensuring precision, rigidity, and vibration damping • Tool holder DIN 69871, ISO 40 Bdsded I R E Nopfx Ap Iod • Chip conveyor with integrated coolant system • 4th axis pre-configured • CE compliant Siegfried Volz Werkzeugmaschinen Rüschebrinkstr. 151-153 D - 44143 Dortmund - Wambel

Condition: good (used), Year of construction: 2000, functionality: fully functional, CNC lathe, HITACHI SEIKI, type HT 23-RIII, year 2000 Bdodpfx Asv T Un Djp Ijd SEICOS L MULTI DIALOG control system. Maximum turning diameter: 450 mm Maximum turning length: 630 mm Tool turret with 12 positions VDI 40 Chuck diameter: 250 mm Spindle bore: 78 mm Spindle speeds: 30-4000 rpm Rapid traverse: X and Z 30 m/min Chip conveyor. For further information, see data sheets. The machine is in good condition and can be demonstrated under power. Machine documentation is available.

Condition: good (used), Year of construction: 2001, Mori Seiki SV-500/50 4 Axis Vertical Machining Centre with Mori Seiki MSC-501 CNC Control, Table Size 1100mm x 600mm, 40 Tool ATC, BT50 Spindle Taper, Cool Jet 70 - 30 DF High Pressure, Coolant Filtration Unit, Filtermist FX7002 Oil Mist Extractor, Spindle Speed Max 6000rpm, Renishaw Tool Probe Eye, Machine Weight 7800kg. S/No. 1864 Includes Various BT50 Spindle Tool Holders in ATC and Boxes Bsdpfxsx Nap Do Ap Iodd

Year of construction: 2006, condition: good (used), 5-axis vertical machining center fully equipped with direct-drive technology. Bdodpfx Apopkyn Rj Isd Machine equipped with 30,000 rpm spindle, 60-place tool magazine and Heidenhain TNC 530 CNC
