Portal milling machine

Mecanumeric

Condition: good (used), Year of construction: 2015, CNC milling machine, milling and engraving machine, MECANUMERIC, MECA EASY 1510 – used: Price ex works: €23,500 (net)! Manufacturer: MECANUMERIC Type: MECA EASY 1510 Year of manufacture: 2015, former DEMO MACHINE Three-axis milling machine in a flat-bed gantry design. Working travels X, Y, Z axes: 1,050 / 1,550 / 200 mm. Table frame and gantry: Designed as a solid, stress-free, fully welded steel structure, powder-coated. Heavy table substructure for mounting the vacuum table VAC-CAISSON, designed as a cassette, with air passage holes in a 10 mm grid. Feed rate: 300 mm/sec (18 m/min) in rapid traverse and feed mode! Guidance on rails, slide shoes with upstream ball screw. Transmission: Precision ball screws Ball screw on all axes Maintenance-free, brushless servo drive motors (750 W on X and Y, 300 W on Z) Repeat accuracy: +/- 0.025 mm Mechanical resolution: 0.0006 mm Numerical control: Mecanumeric CN 7000 ISO-G-Code Machine operation via a 10" touch screen display Complete documentation and CE declaration of conformity in accordance with the basic safety and health requirements of Vacuum table 1,020 x 1,500 mm Support/work table designed as a closed aluminum plate, on which vacuum passage holes are arranged in a 10 mm grid. The table is divided into 2 main areas, which can be switched on manually. Vacuum generation by one (1) two-stage high-performance vacuum side-channel compressor. Motor power 4.5 KW, suction capacity 320 m/hour, filter and silencer included. Due to the overall size and potential heat development, the pumps are housed outside the machine body. The electrical control and safety devices for the pump and valves are integrated in the machine control cabinet or on the control panel. Milling spindle HF40-ATC24 ENC Conversion Module APSG-A Crsdpszbybiofx Al Rec Vacuum generation by one (1) two-stage high-performance vacuum side-channel compressor. Motor power 4.5 KW, suction capacity 320 m/hour, filter and silencer included. Due to the overall size and potential heat development, the pumps are housed outside the machine body. The electrical control and safety devices for the pump and valves are integrated in the machine control cabinet or on the control panel. High-frequency motor milling spindle 4KW Power: 4KW Speed range: up to 24,000 rpm. Fast tool change with pneumatic ejection, ISO30 taper. Tool holder: Clamping diameter up to 2-16 mm. Cooling with compressed air 6 bar 20 m/h Converters and switching elements are included in this position. Safety enclosure for the machine Front with door and safety lock - Position PROTCHOC omitted - Preparation of the electrical control and switching elements as well as the output socket for a high-performance industrial vacuum cleaner. Changer CH 6 S Condition: good Available: immediately Location: Delmenhorst

Condition: excellent (used), 5-axis Year of production: 2018 Crodpfx Aljun Rqgo Rjc Machine working area dimensions for the X and Y axes: X 2100 mm Y 3100 mm Head stroke in the Z axis: 1250 mm Machine travel speed X, Y. Z: X: 80 m/min Y: 80 m/min Z: 12 m/min Vacuum table BECKER pump HITECO spindle in the HSK 63F standard Price of a new machine: approx. 135.000 €

Condition: used, Year of construction: 2010, travel distance X-axis: 3,020 mm, travel distance Y-axis: 1,520 mm, • Monoblock structure in welded steel with a mobile gantry in steel. • Processing speed up to 18 m/min. • Worktable: fixed table made of high-thickness aluminum profiles. • Hardened linear guides and preloaded ball-bearing carriages. Crsdpfx Aexxii Asl Rsc • Transmission via precision ball screws on all 3 axes. • CN7000 numerical control with touch screen and brushless servo drives. • Available in 5 sizes for maximum flexibility. • Z 350 option for 3D applications. • Quality and performance suitable for good productivity. • Well-known ease of use. • Compliant with European safety regulations. • Numerous options: brushless servomotors, micro-lubrication, automatic tool changer, vacuum table (with turbine or vacuum pump), high-frequency spindles, contact engraving spindles, fourth axis.

Condition: excellent (used), Year of construction: 2018, operating hours: 1,142 h, functionality: fully functional, machine/vehicle number: 18234, travel distance X-axis: 4,050 mm, travel distance Y-axis: 2,020 mm, travel distance Z-axis: 400 mm, rotational speed (max.): 28,000 rpm, number of slots in tool magazine: 12, The machine has only processed aluminum and plastic. TECHNICAL DETAILS Travel X: 4,050 mm Travel Y: 2,020 mm Travel Z: 400 mm Table Table size: 4,000 × 2,000 mm Clamping surface: industrial T-slot aluminum profile Max. material width: 2,200 mm Table covering: replaceable PVC protective covering Side channel blower: 2 × 7.5 kW, 520 m³/h Csdpfowtcvusx Al Rjrc Vacuum: 420 mbar at 145 m³/h Gantry & Clearance Gantry clearance height: 375 mm Construction: welded, stress-relieved steel structure Speeds Rapid traverse & feed rate: 417 mm/s Accuracy Repeatability: ± 0.025 mm Mechanical resolution: 0.006 mm Guides & Drives Axis transmission: precision ball screw drives (X 2 × Ø 32 mm) Axis drives: 750 W servomotors on X1, X2, Y, Z Dual drive: X-axis Spindle Model: HSD ES 929 Power: 7.5 kW Speed range: 2,000 – 28,000 rpm Max. torque: 5.6 Nm at 12,000 rpm Tool holder: ISO 30, clamping diameter up to 20 mm Cooling: air/convection (motor ribs) Tool changer Number of positions: 12 Max. tool length: 80 mm Length measurement: automatic Control & Operation CNC: Mecanumeric CN 7000 (ISO G-code) Control panel: 15″ touch screen Cooling & Extraction Systems Tool cooling: regulated spray mist Oil mist extraction: integrated Chip/dust extraction: spindle extraction device MACHINE DETAILS Machine dimensions (L × W × H): 5,750 × 2,500 × 2,090 mm Machine weight: 5,000 kg Machine on time: 5,185 h Spindle hours: 1,142 h Power supply: 400 V AC, 50 Hz EQUIPMENT - Heavy-duty flatbed gantry with vacuum-ready aluminum profile table - Two side channel blowers, each 7.5 kW, for powerful vacuum - Swiveling laser pointer for workpiece positioning detection - Automatic tool changer with 12 ISO 30 tool holders and measuring station - Spray mist tool cooling for temperature-sensitive materials - Chip and dust extraction directly at the spindle - Pneumatically retractable positioning pins for quick setup - Safety bumpers and emergency stop buffers for operator protection - High-performance industrial vacuum ASPG 40-100 L for table cleaning - EnRoute BASIC v6 software including thread milling module - CE conformity according to directives 89/336/EEC, 98/37/EC, 73/23/EEC

Condition: used, Used Trumpf 5axis laser for sale / 3d laser for sale Used Trumpf 5axis laser for sale / 3d laser for sale Trumpf TLC Cut 5 Year 2006 Fully serviced twice a year by Trumpf Uk Crodjfuah Njpfx Al Rec Last service January 2019 New vacuum pump fitted – 28/05/19 Hours: Beam on: 14,922 hours Laser on: 59,480 hours 3.2kw Fully serviced. Jigs / cutting beds included. Delivery and installation can be arranged.

Condition: ready for operation (used), Year of construction: 2024, travel distance X-axis: 2,100 mm, travel distance Y-axis: 3,050 mm, travel distance Z-axis: 400 mm, number of axes: 4, spindle motor power: 9,000 W, This 4-axis QUICK CNC UA 481 was manufactured in 2024. It features a 2100 x 3050 x 400 mm working area, a 9 KW HSD/HSK F 63 spindle, and a double layer vacuum table with 6 zones. Equipped with a Yaskawa servo motor and two Becker pumps at 250 m3/h each, it's ideal for advanced woodworking. Consider the opportunity to buy this QUICK CNC UA 481 CNC Wood Machining Centre. Contact us for more information about this machine. • Condition: New • Power supply: 380 V, 3-phase • Spindle: HSD, 9 kW, HSK F63 • Controller: NC Studio (German language) • Tool changer: Linear, 10 tools • Drives: Yaskawa servo motors Cedpfx Alex E Efvs Rerc • Table: Double-layer vacuum table, 6 zones Additional equipment • Vacuum system: 2 Becker vacuum pumps, 250 m³/h

Condition: used, Year of construction: 2014, - Machine available from: 2026-03-30 - Year: 2014 - Documentation available: Yes - CE certificate present: Yes - Serial number: AA1/017825 - Number of milling spindles [pcs.]: 1 - └ Milling spindle 1: - - Number of controlled axes [pcs.]: 5 - Type milling table: Beam table - Drilling unit present: Yes - Tool changer positions [pcs.]: 12 - Vacuum pump present: Yes - └ Number [pcs.]: 1 - └ Brand: Becker - └ Type: VTLF 2.250/0-791 - └ Year of manufacture: 2014 - └ Main motor power [kW]: 5.5 - └ Capacity [m³/h]: 244 - └ Vacuum pressure [bar]: 200 - Working range X [mm]: 5200 - Working range Y [mm]: 1550 - Z-axis working range [mm]: 160 - Installed length [mm]: 9000 - Installed width [mm]: 5000 - Installed height [mm]: 3100 Financial information VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Delivery and trade-in always possible for everything in the industrial sectors Codpfsx Hwhxox Al Rsrc Glenn Smeets

Condition: used, Year of construction: 2012, operating hours: 9,974 h, total height: 2,700 mm, total length: 7,700 mm, total width: 2,420 mm, Empty weight: 7.390 kg CNC machining centre SCM Morbidelli M-600 5-axis machine Year of construction 2012 Machine no. AA2/002032 Working distance X-axis 5020 mm Working distance Y-axis 1680 mm Working distance Z-axis 250 mm Tool positions 36 Vertical drilling spindles 24  Software SCM XILOG MAESTRO SCM PRISMA K SCM TTS system Milling spindle liquid-cooled SCM TecPad MORBIDELLI TV Matic SCM PRO-SPACE SCM RAPID 12 SCM RAPID 24 Crjdpfx Aewnhccol Rsc Including vacuum pump Capacity 250 m3/h Disassembled for transport Weight 7450kg - Details: - └ Description: Machine gives malfunction spindle - Year: 2012 - Documentation available: No - CE marking present: Yes - CE certificate present: No - Serial number: AA2/002032 - Operating hours: 9974 - Number of milling spindles [pcs.]: 1 - └ Milling spindle 1: - - Number of controlled axes [pcs.]: 5 - Type milling table: Beam table - Drilling unit present: Yes - └ Horizontal drill spindles [pcs.]: 6 - └ Vertical drilling spindles [pcs.]: 24 - Saw unit present: Yes - Tool changer positions [pcs.]: 36 - Vacuum pump present: Yes - └ Number [pcs.]: 1 - └ Brand: Becker - └ Capacity [m³/h]: 250 - Working range X [mm]: 5020 - Working range Y [mm]: 1680 - Z-axis working range [mm]: 250 - Transport dimensions: 7700mm x 2420mm x 2700mm (l x w x h) - Transport weight [kg]: 7390kg - Transport packages [pcs.]: 1 Financial information VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Delivery and trade-in always possible for everything in the industrial sectors Glenn Smeets

Condition: used, Year of construction: 2018, Delivery time approx. 5 months. Machine from educational use – TOP condition, low hours (edging unit unused). No tools included. Dismantling, delivery, assembly, commissioning, and training not included in the price. Includes Maestro 3D and Pro View. MORBIDELLI P200 Working area X-Y: 3,110 x 1,620 mm, workpiece height Z180 mm Edge banding made for you: The CNC machining center is equipped with a comprehensive selection of edge banding tools to meet any woodworking requirement. MAIN ADVANTAGES · High performance with the advanced H80C edge banding unit, 8,000 rpm drilling spindles. The most robust spindle technology on the market, offering over 1,000 maintenance-free operating hours. · Better equipped: Suction cups can be disabled and configured via the FLEX worktable to optimally adapt the machine to requirements. · Easier, more intuitive programming thanks to the integrated CAD-CAM module for edge banding technologies “MAESTRO EDGE”. · Easier operation: The lowered frame ensures the worktable is always accessible. The control cabinet and vacuum pump are integrated, and in the PRO SPACE configuration, no safety barriers are needed. Crodpfx Alsyuw Sro Rec Base structure: The base frame is a monolithic construction made from thick-walled steel, reinforced across the entire machine bed with welded square plates for exceptional rigidity. The bed’s shape, with a wide base, is the secret to lasting precision and stability. The load-bearing structure consists of a particularly robust, monolithic steel base, heavily ribbed and highly stiffened; the extra-wide support was specially designed to give the machine maximum stability, ensuring lasting precision regardless of operating conditions—with no need for floor anchoring. The base provides a large, solid support for the moving gantry: the working unit is thus equipped with a balanced, stable, and resilient support capable of handling the highest loads, ensuring top-quality performance and greater accuracy. The moving gantry is made from a robust single piece anchored to the base, sliding along top-quality prismatic guides with recirculating ball carriages. The working unit is attached and moves along the Y and Z axes on prismatic guides with recirculating ball carriages. Movement of the lower carriage (X-axis) and the working unit along the moving carriage (Y-axis) is enabled by rack-and-pinion transmission with helical teeth. This design results in greater tooth-on-tooth engagement, delivering higher acceleration and greater speed along the X and Y axes. The specially designed helical gearing ensures reduced wear on mechanical components and quieter operation. The vertical Z-axis is driven by a ball screw, ensuring perfect balance with dynamic loads and smooth acceleration and deceleration. The main milling unit is directly coupled to the Z-axis carriage for maximum finishing quality.

Year of construction: 2020, condition: ready for operation (used), Main Drive Spindle motor power 13.2 kW Spindle Speed 24000 RPM Number of axis 3 Movement X-Axis Movement 3765 mm Z-Axis Movement 378 mm Y-Axis Movement 1560 mm This 5-axis BIESSE Rover PLAST A FT 1536 was manufactured in 2020, featuring a robust electro-welded base and high-precision movement systems. It boasts a main electrospindle power of 13.2 kW, a programmable rotation speed up to 24,000 RPM, and an 8-position revolver tool magazine. Ideal for intricate woodworking, it includes a 21.5" LCD monitor and Industry 4.0 integration. Consider the opportunity to buy this BIESSE Rover PLAST A FT 1536 CNC Wood Machining Centre. Contact us for more information. Application Types Cjdjx Nr Npepfx Al Rorc CNC Wood Machining
