Used Cnc Cylindrical Grinding Machine for sale (65,440)

Condition: new, We offer all types of spare parts for your conventional or CNC Karstens/GP cylindrical grinding machine, including components for your tailstock, workpiece spindle head, grinding spindle head, ball screws, glass scales, grinding wheel flanges, drive motors, axis drives (BOSCH SIEMENS), bellows, bearings, K11/K21 infeed control systems—new and used—as well as reversing blocks for the Z axis on an exchange basis. Also suitable for similar Weiss/EMAG/GP cylindrical grinding machines, Studer, Kellenberger, Schaudt, Tschudin, Tacchella, Dannobat, Bahmüller, Fortuna. Bwodpfx Ajraibvon Usr

Condition: excellent (used), Year of construction: 1980, Karstens K11 1000 This Karstens K11 comes from a university and has seen very little use. All cables and hoses in the wet area have been replaced. It has extremely few operating hours. Bwodpfx Aoh Rit Ejn Ujr Since we specialize in Karstens round grinding machines, we can offer you complete service (electrical and mechanical) for the machine after purchase. Technical data: Center distance: 1000 mm Center height: 180 mm Workpiece weight: 70 kg cantilevered, 250 kg between centers Grinding wheel diameter: 400 mm Workpiece spindle: MK 4, speed continuously adjustable 30-450 rpm, swivel range 0 - 90 ° Tailstock: MK4, quill travel 45 mm Tailstock rest next to the Z-axis table Quill force: 200-600 N Table tilt: 12.5 degrees Adjustable travel of the feed spindle: 80 mm Rapid traverse: 50 mm Coarse adjustment with air cushion: 280 mm Grinding spindle motor (external): 4 KW Grinding spindle motor (internal): 2.2 KW Workpiece spindle motor: 0.55 KW Machine weight: Net 3500 kg Feed drive via DC motor Air cushion-supported rapid adjustment of the grinding spindle stock for quick and safe positioning of the grinding position. Separate drive for the spindles for external and internal grinding. Fully automatic working cycle, feed movement via a wind rose switch: Rapid traverse forward, rapid traverse backward, grinding operation, feed stop, mym feed. Automatic longitudinal grinding cycle Central coolant supply for all grinding points Workpiece spindle stock with continuously adjustable drive for both rotating and lockable spindle. Feed control for longitudinal grinding and face grinding, input for retraction, feed amounts, feeds, dwell times, clearance strokes Digital display for X-axis from Heidenhain Paper band filter system can be offered upon request. Similar to Weiss/EMAG/GP round grinding machines/Studer/Kellenberger/Schaudt/Tschudin/Tacchella/Dannobat .

Condition: refurbished (used), Year of construction: 2026, Karstens K11 650 This cylindrical grinding machine has been completely overhauled by PS-Karstens. The machine has been inspected and is in very good condition. Since we specialize in Karstens cylindrical grinding machines, we can offer you complete service (electrical and mechanical) for the machine after purchase. Technical data: Distance between centers: 650 mm Distance between centers: 180 mm Workpiece weight: 100 kg cantilevered, 250 kg between centers Grinding wheel diameter: 400 mm Workpiece spindle: MK 4, speed continuously adjustable 30-450 rpm, swivel range 0 - 90 ° Tailstock: MK4, quill stroke 45 mm, cylinder fine adjustment Quill force: 200-600 N, hydraulically operated via foot pedal Table inclination: 10 degrees Adjustment travel of feed spindle: 80 mm Rapid traverse: 50 mm Rough adjustment with air cushion: 280 mm Grinding spindle motor external: 4 KW Grinding spindle motor internal: 2.2 KW Bwsdpfx Aneh Rixxe Uer Workpiece spindle motor: 0.55 KW Machine weight: Net 3800 Kg Feed drive via DC motor Air cushion-supported rapid adjustment of the grinding spindle head for quick and safe positioning to the grinding position. Separate drive for the spindles for external and internal grinding. Fully automatic process, feed movement via jog shuttle switch: Rapid traverse forward, rapid traverse backward, grinding operation, feed stop, incremental feed. Automatic longitudinal grinding cycle Central coolant supply for all grinding points Workpiece spindle head with continuously adjustable drive with a rotating and lockable spindle. Feed control for longitudinal grinding and plunge grinding, input for retraction, feed amounts, feed rates, dwell times, non-cutting travel Paper band filter system approx. 250 L Similar to Weiss/EMAG/GP cylindrical grinding machines/ Studer/ Kellenberger/ Schaudt/ Tschudin/ Tacchella/ Dannobat/ Bahmüller/ Fortuna

Condition: as good as new (ex-display), Year of construction: 2026, Karstens K11 1000 Premium Retrofit Cylindrical Grinding Machine Manufacturer: Karstens Technical Data: Center distance: 1100 mm Center height: 180 mm / (250 mm = Option) Workpiece weight: 100 kg unsupported, 300 kg between centers Grinding wheel diameter: 400 mm or 500 mm (external grinding wheel) Workpiece spindle: MK 4, infinitely variable speed adjustment 30-450 rpm, swivel range 0 - 90° Tailstock: MK4, quill stroke 45 mm Quill force: 200-600 N manually, (up to 2500 N possible, adjustable = Option) Table tilt: 10 degrees Adjustment travel of feed spindle: 80 mm Rapid traverse: 50 mm Rough adjustment with air cushion: 280 mm Grinding spindle motor (external): 4 KW / (5.5 KW = Option) Infinitely variable speed adjustment of the grinding wheel with potentiometer Grinding spindle motor (internal): 2.2 KW Workpiece spindle motor: 1.1 KW Hydraulic motor: 1.5 KW Lubrication motor: 0.1 KW Hydraulic tank: 80 liters Machine weight: Net 3800 kg Feed drive via DC motor Air cushion-assisted rapid adjustment of the grinding spindle stock for quick and safe approach to the grinding position. Separate drive for the spindles for external and internal grinding. Fully automatic operating sequence, feed movement via wind rose switch: Rapid traverse forward, rapid traverse backward, grinding operation, feed stop, incremental feed. Automatic longitudinal grinding cycle Central coolant supply for all grinding points Bsdpfsiv Au Esx An Ujwr Workpiece spindle stock with infinitely variable drive with a rotating and lockable spindle. New digital feed control with Siemens panel and Siemens PLC for longitudinal grinding and plunge grinding, input for retraction, feed amounts, feeds, dwell times, rapid traverse distances, compatible with the old Karstens feed control, with a color Siemens touch panel, scale in X and Z axis, manufacturer HEIDENHAIN. Similar to Weiss/EMAG/GP cylindrical grinding machines/Studer/Kellenberger/Schaudt/Tschudin/Tacchella/Dannobat /Bahmüller/Fortuna

Condition: as good as new (ex-display), Year of construction: 2026, Karstens K11 650 Premium Retrofit Round Grinding Machine Manufacturer: Karstens Technical Specifications: Center distance: 750 mm Center height: 180 mm / (250 mm = Option) Workpiece weight: 100 kg cantilevered, 250 kg between centers Grinding wheel diameter: 400 mm or 500 mm (external grinding wheel) Workpiece spindle: MK 4, speed continuously adjustable 30-450 rpm, swivel range 0 - 90 ° Tailstock: MK4, quill stroke 45 mm, cylindrical correction Quill force: 200-600 N manually, (up to 2500 N possible, adjustable = Option) Table inclination: 12.5 degrees Travel of the feed spindle: 80 mm Rapid traverse: 50 mm Rough adjustment with air cushion: 280 mm Grinding spindle motor, external: 4 kW / (5.5 kW = Option) Continuously adjustable grinding wheel speed with potentiometer Grinding spindle motor, internal: 2.2 kW Bwjdpsiv Audjfx An Usr Workpiece spindle motor: 1.1 kW Hydraulic motor: 1.5 kW Lubrication motor: 0.1 kW Hydraulic tank: 80 liters Machine weight: Net 3500 kg Feed drive via DC motor Air cushion-supported rapid adjustment of the grinding spindle head for quick and safe positioning to the grinding location. Separate drive for the spindles for external and internal grinding. Fully automatic operating sequence, feed movement via wind rose switch: Rapid traverse forward, rapid traverse backward, grinding operation, feed stop, incremental feed. Automatic longitudinal grinding cycle Central coolant supply for all grinding points Workpiece spindle head with continuously adjustable drive with a co-rotating and lockable spindle. Feed control, digital with Siemens panel and Siemens PLC for longitudinal grinding and plunge grinding, input for retraction, feed increments, feeds, dwell times, idle strokes, compatible with the old Karstens feed control, with color Siemens touch panel Scale in X and Z axes, manufacturer HEIDENHAIN. Similar to Weiss / EMAG / GP round grinding machines / Studer / Kellenberger / Schaudt / Tschudin / Tacchella / Dannobat / Bahmüller / Fortuna.

Condition: as good as new (ex-display), Year of construction: 2026, Centre height: 181 mm Centre distance: 1000 mm Maximum grindable workpiece diameter: 360 mm Max load cantilevered: 1000 N (100 kg) Max load between centres: 3000 N (300 kg) Z-axis: Table swivel angle: 10° Table drive, hydraulic: 0–4 m/min X-axis: Cross slide travel: 80 mm Rapid traverse (hydraulic): 50 mm Bodetqf Rzopfx An Uewr Coarse adjustment – air cushion: 280 mm Infeed drive by DC motor Rapid infeed speed: 48 mm/min/Ø Infeed cycle: Plunge grinding / Longitudinal grinding 4 preselectable speeds: mm/min/Ø: 0.01–48 4 preselectable infeed increments: mm: 0.001–0.1 Automatic shut-off during stop-grinding: 0–99 s or 0–99 strokes Stepwise infeed: mm/Ø: 0.001 Grinding headstock universal, swivelling: 0–180° Grinding wheel (OD): D x width x bore: 500 x 100 x 127 mm or 203.2 mm Grinding wheel (face, option) D: 250 x 32 x 76.2 mm Grinding wheel (ID, option) D: 2–250 mm Drive power, external/face: 5.5 (7.5) kW Drive power, internal: 2.2 kW Peripheral speed, external: 35 (50) m/s Grinding wheel wear (OD): mm/Ø: 160 Guard width: 100 mm Grinding spindle diameter: 60 mm Internal spindle mounting: 80 (100) mm Workpiece headstock: Infinitely variable drive: MK 4, 1/min: 30–270 / 50–450 Workpiece spindle lockable Spindle mounting: MK 4/24 mm Spindle nose for flange attachment: MK 4, cylindrical Ø63H6 x 6 mm Headstock swivels on rotating part: 0–90° Tailstock: Quill mounting / Quill diameter: MK 4, 750 mm Quill stroke: 45 mm Quill force, N: 100–800 / 250–1400 adjustable Quill operation: manual (foot switch) Quill fine adjustment: ±40 μm Connections: Total machine connected load: 6.5–10 kW Grinding headstock: 5.5 (7.5) kW Workpiece headstock: 0.55 (1.1) kW Coolant filtration: 0.75–2.2 kW Lubrication pump – guideways: 0.1 kW Hydraulic pump: 1.5 kW Hydraulic tank: 80 l Pneumatics: 6 bar Comparable to: Weiss / EMAG / GP cylindrical grinders / Studer / Kellenberger / Schaudt / Tschudin / Tacchella / Dannobat

Condition: as good as new (ex-display), Year of construction: 2026, Karstens K11 1000 Premium Retrofit Cylindrical Grinding Machine Manufacturer: Karstens Technical Data: Distance between centers: 1100 mm Center height: 180 mm / (250 mm = Option) Workpiece weight: 100 kg cantilevered, 300 kg between centers Grinding wheel diameter: 400 mm or 500 mm (external grinding wheel) Workpiece spindle: MK 4, stepless speed control 30-450 rpm, swivel range 0 - 90° Tailstock: MK4, quill travel 45 mm Quill force: 200-600 N manual, (up to 2500 N possible, adjustable = Option) Table inclination: 10 degrees Travel of the infeed spindle: 80 mm Rapid traverse: 50 mm Rough adjustment with air cushion: 280 mm Bjdpfx Aeh Rimmon Uewr Grinding spindle motor external: 4 kW / (5.5 kW = Option) Stepless speed adjustment of the grinding wheel with potentiometer Grinding spindle motor internal: 2.2 kW Workpiece spindle motor: 1.1 kW Hydraulic motor 1.5 kW Lubrication motor 0.1 kW Hydraulic tank 80 liters Machine weight: Net 3800 kg Infeed drive via DC motor Air cushion-assisted rapid adjustment of the grinding spindle head for quick and safe positioning of the grinding position. Separate drive for the spindles for external and internal grinding. Fully automatic operating sequence, infeed movement via a wind rose switch: Rapid traverse forward, rapid traverse backward, grinding operation, infeed stop, incremental infeed. Automatic longitudinal grinding cycle Central coolant supply for all grinding points Workpiece spindle head with steplessly adjustable drive with a rotating and lockable spindle. New digital infeed control with Siemens panel and Siemens PLC for longitudinal grinding and plunge grinding, input for retraction, infeed increments, feeds, dwell times, clearance strokes, compatible with the old Karstens infeed control, with a color Siemens touch panel similar to Weiss/EMAG/GP cylindrical grinding machines/Studer/Kellenberger/Schaudt/Tschudin/Tacchella/Dannobat /Bahmüller/Fortuna

Condition: used, Year of construction: 2012, workpiece . workpiece diameter 15 -70 mm swing diameter max. 150 mm clamping length max. 500 mm Swing over bezel area 70 mm dimension 150 x 300 mm max. turning speeds 250 min/-1 longitudinal adjustment manuell über Kettenrad Fixed tip MK 4 (Junker D75 mm) clamping capacity ü. Hydraulik einstellbar travel -z axis max. 1000 mm feed z - Achse (CNC gesteuert) dimension D 205 x 450 mm flange diameter D 190 mm standards association D 127 mm drive 30 kW speed control mit Frequenz- Umformer max. turning speeds 4400 min/-1 type Borazon (CBN) o. Diamant mm diameter 450 mm bore D 127 mm peripheral speed max. 90 m/sec type GR-3520-NR mm diameter range D 20 - D 35 mm Bsdpfsx H Andjx An Uswr dimension D 80 x 250 mm flange D 100 standards association D 75 drive 1,8 kW max. turning speeds 24000 min/-1 weight of the machine ca. 7,0 t In our opinion, the machine is in good condition and can be inspected under power by appointment. There are 2 identical machines available. Accessories, tools and clamping devices shown are only part of the scope of delivery if this is noted in the additional information. Changes and errors in the technical data and information as well as Subject to prior sale!

Condition: as good as new (ex-display), Year of construction: 2020, operating hours: 200 h, functionality: fully functional, workpiece weight (max.): 150 kg, grinding length: 500 mm, grinding wheel diameter: 455 mm, grinding diameter: 300 mm, workpiece weight between centers: 150,000 g, type of input current: three-phase, workpiece diameter between centers: 500 mm, grinding wheel width: 75 mm, spindle speed (max.): 500 rpm, spindle speed (min.): 10 rpm, grinding spindle motor power: 7,500 W, overall weight: 4,600 kg, Demonstration CNC cylindrical grinding machine with automation setup Brand OKAMOTO Model OGM-350 P NCIII Year of manufacture 2020 Control: Fanuc Oi Model D Operating hours: approx. 200 hours Technical specifications Maximum swing diameter: 320 mm Maximum distance between centers: 500 mm Maximum workpiece diameter to be ground: 300 mm Maximum workpiece weight between centers: 150 kg Maximum workpiece weight: flange + chuck + workpiece: 40 kg Grinding wheel: Diameter x width x bore: 455 x 75 x 127 mm Wheel speed: Continuously variable Circumferential speed: 45 m/sec Grinding headstock (x-axis) Maximum travel: 300 Swivel angle: Non-swivel Workpiece table (z-axis) Travel: 870 mm Swivel angle: 0 – 10° Workhead Fixed/Live Center Design MK 4 Taper Chuck Spindle Bore Diameter 20 mm Spindle Speed ​​10 – 500 rpm Swivel Angle: Non-Swivel Tailstock Tailstock Type: Manual Fine Taper Adjustment Quill Travel 30 mm MK 4 Taper Chuck Drive Power Grinding Wheel Drive 5.5 kW Total Power 20 kVA Dimensions/Weight Length x Width x Height approx. 3400 x 2330 x 1950 mm Machine Weight approx. 4,600 kg Standard Equipment: 2 Carbide Centers Full FANUC Keyboard with Radius Compensation for Creating ISO Programs Bwodpfszn U S Iox An Usr Workshop Programming: Graphic Software for Grinding and Dressing Cycles with Teach-in Function GAP Eliminator Shoulder Positioning Constant Table coolant flush 3 color LED lamp Documentation Leveling screws and support plates Operating tool set Accessories Automation preparation Automatic door Automation interface Grinding wheel guard fully open when door is open Miscellaneous Signal lamp Tailstock with electric quill retraction 1 flange 1 grinding wheel Options upon request: Paper belt filter on request Clamping devices on request Commissioning and training on request (Commissioning by Okamoto is required for warranty purposes) Transport on request

Condition: ready for operation (used), A Koebau centerless cylindrical grinding machine is offered for the high-precision grinding of cylindrical workpieces. Main motor power: 18.5kW, min./max. grinding diameter: 2mm/100mm, max. workpiece length: approx. 600mm, grinding wheel dimensions X/Y: 600mm/200mm, regulating wheel dimensions X/Y: 300mm/200mm, grinding speed: 45m/s. The machine is equipped with a material feeding system, a singulation unit, a robust base frame and a stepped platform. Overall dimensions X/Y/Z: approx. 2500mm/2100mm/2200mm, weight: approx. 4200kg. An on-site inspection is possible. Bwedpfx Anjzpa R Sj Ujr

Year of construction: 1996, condition: ready for operation (used), Offered is a WALTER 5-axis CNC tool grinding machine for the production and resharpening of rotationally symmetrical cutting tools such as drills, milling cutters, reamers and special tools. Travels X/Y/Z: 400mm/250mm/580mm, C-axis swivel range: +/-200°, A axis: 360°, rapid traverse X/Y/Z: max. 15m/min, linear axis resolution: 0.0001mm, center height range: 130mm-165mm, max. workpiece diameter: 190mm, workpiece mounting: ISO 50, spindle motor power: 4.4kW, grinding spindle speed: 6000rpm, spindle diameter: 70mm, max. grinding wheel diameter: 200mm, control: WALTER HMC 400. Overall dimensions X/Y/Z: approx. 1420mm/2010mm/2150mm, weight: approx. 3100kg. An on-site inspection is possible. Bjdpfozpa Scox An Uowr

Condition: good (used), Year of construction: 2002, functionality: fully functional, X-travel 450mm, Z-travel 200mm exhaustion device, extinguishing system, without coolant device weight ca. 4000kg Bwjdpfx Ajy Ix Ezjn Uer

Condition: ready for operation (used), Year of construction: 1998, functionality: fully functional, machine/vehicle number: LEAN PRO, FANUC 16 T Bwedpfxjzfx D Ns An Ujr FULLY FUNCTIONAL RANGE OF ACCESSORIES FILTRATION SYSTEM MIST EXTRACTOR MACHINE MANUALS

Condition: used, TOS BHU 50×2000 – USED UNIVERSAL CYLINDRICAL GRINDER A used TOS BHU 50 universal cylindrical grinder, center distance 2,000 mm, from a company liquidation. Inspection on-site or via video call is possible at any time. The following technical data are taken from the machine-specific TOS-BHU-50 data sheet and serve as a technical reference. Binding values for this individual machine will be determined after inspection. KEY FEATURES - Automatic program for longitudinal, transverse, and plunge grinding, external and internal - Precision standard IT class 5 - Spindles on hydrodynamic bearings with automatic bearing adjustment - Infinitely variable workpiece spindle speed, swivel headstock on both sides - Swiveling grinding wheel head TECHNICAL DATA (BHU 50 SERIES) - Grinding diameter: 500 mm - Center distance: 2,000 mm - Center height: 250 mm - Grinding wheel (Ø x width x bore): 500 x 80 x 203 mm - Diameter of worn grinding wheel: 380 mm - Diameter of workpiece in open/closed steady rest: 110 mm - Diameter of chuck: 200 mm - Taper in workpiece spindle and tailstock spindle: MK 5 - Swivel range of workpiece spindle headstock: 90°, grinding wheel headstock: ±45° - Largest longitudinal travel of the table (at 2,000 mm center distance): 2,290 mm - Table speed, infinitely variable: 0.05-5 m/min - Grinding spindle speed: 1,230 / 1,470 rpm - Workpiece spindle speeds: 16 steps, range 12-400 rpm - Grinding wheel headstock motor: 7.5 kW - Total power consumption: 16 kVA - Machine weight (at 2,000 mm center distance): approx. 6,600 kg - Largest workpiece weight: 300 kg between centers, 300 kg cantilevered Bjdpfozi Strjx An Uswr STANDARD EQUIPMENT (SERIES) - Grinding wheel 500 x 80 x 203 mm for 33 m/s circumferential speed, flange, and guard - Dressing and mounting device for the grinding wheel flange, balancing mandrel - 2 fixed centers MK 5, 2 open steady rests (Ø 10-110 mm) - Sedimentation coolant system, splash guard - Micrometric dressing device for the grinding wheel (tailstock) - Driver and operating key set, machine lamp, technical documentation We would be happy to clarify in advance whether the specific machine has the full range of features based on its actual equipment. CONDITION Used machine from a company liquidation. Sold "as is, where is," warranty excluded. On-site inspection or video call inspection is highly recommended; independent functional and accuracy testing is available upon request. A general overhaul is possible upon request and for an additional charge. OUR SERVICE Online or on-site factory inspection, transport can be organized upon request, installation, commissioning, and operator training by our service technicians, direct German-speaking contact person for spare parts and support, member of FDM, the German Association of Machine and Tool Wholesale. As this is an individual machine, availability is subject to prior sale. Please call or write to us briefly, and we will arrange an inspection appointment as soon as possible.

Condition: excellent (used), Grinding range 800 x 600 x 500 mm Wheel diameter 400 mm Magnetic plate 800 x 600 mm Bjdpfx Anor Ezfwj Uswr Automatic dresser Automatic balancing device Misc.accessories MARCELS MASCHINEN CH

Condition: good (used), Technical specifications: Machine weight: 19,400 kg Total machine power consumption: 18 kW Max. grinding diameter: 630 mm Distance between centers: 4,000 mm Bjdszpx Hrepfx An Uewr Max. workpiece weight: 2,500 kg

Condition: good (used), Cylindrical grinding machine, external cylindrical grinding machine, internal cylindrical grinding machine, centering grinding machine, center grinding machine -Max. shaft diameter: 320 mm -Max. grinding length: 345 mm -Chuck size: Ø 133 mm -Dimensions: 1925/1135/H1755 mm -Weight: 1592 kg -functionally tested Bwodpfxsduiw Aj An Ujr

Condition: used, Cylindrical grinding machine, external cylindrical grinding machine, internal cylindrical grinding machine, centering grinding machine, center grinding machine -Precision universal cylindrical grinding machine -Max. Shaft diameter: 203 mm -Max. Grinding length: 490 mm -Collet: Ø 32 x 87 mm Bodofig Suopfx An Ujwr -Grinding wheels diameter: 160 mm -Dimensions: 1660/1500/H1500 mm -Weight: 1802 kg

Condition: good (used), Brush cylindrical grinder, external cylindrical grinder, internal cylindrical grinder, centering grinder, center grinding machine, hydraulic universal cylindrical grinder, polishing machine -Manufacturer: WMW Heckert, Hydraulic universal cylindrical grinding machine -Spindem lotor: VEB 0.8/1 kW / 1410/2840 rpm -Hydraulic drive: ADDA 0.75 kW -Centre height: 270 mm -Max. material diameter: Ø 320 mm when converted Bwodpog Uggtjfx An Usr -Brush: max. Ø 250 mm -Center distance: 420 mm -Dimensions: see photos -Base cabinet: with extensive accessories incl. -Dimensions: 1720/920/H1230 mm -Weight: 790 kg

Condition: used, Cylindrical grinding machine, external cylindrical grinding machine, internal cylindrical grinding machine, centering grinder, center grinder Bjdped Atx Dsfx An Uewr -Image below: MK5 -grinding wheel mount: -Motor data: 0.3 kW 1380 rpm -Dimensions: 370/180/H480 mm -Weight: 36 kg

Condition: refurbished (used), machine/vehicle number: 3439.39, Universal cylindrical grinding machine for external and internal cylindrical grinding. • Distance between centers: 650 mm • Height between centers: 175 mm • Completely overhauled (refurbished) – The machine was completely disassembled and rebuilt component by component. Guide rails were reconditioned, bearings were replaced, new control cabinet and new electrical installation, complete new paint job, and geometrical readjustment for maximum precision. Bsdpfx Ajxxy A Tsn Uowr • Equipped with a digital measuring system (Fagor). • Machine condition comparable to a new machine, ready for immediate use. • Extensive accessories included in the scope of delivery, as shown in the photos. • Demonstration under power and test run possible at any time. Availability: Available for immediate delivery!

Condition: used, Year of construction: 2003, functionality: fully functional, Control system: Siemens Sinumerik 840D Includes: Grinding media preparation, hydraulic unit, and portal loading system for loading and unloading the machine. Technical data: Center distance: 600 mm, Center height: 180 mm Maximum grinding diameter: 355 mm Maximum workpiece weight: 150 kg Maximum Z-axis speed: 11 m/min Minimum Z-axis speed: 0.01 m/min Maximum X-axis speed: 7.5 m/min Minimum X-axis speed: 0.01 m/min External cylindrical grinding spindle: Grinding wheel standard (outer diameter x width x inner diameter): 600 x 80 x 304.8 mm Grinding wheel peripheral speed: 5 - 50 m/s Power consumption of grinding spindle motor: 11 kW Workpiece spindle: Bwjdszh Ux Iopfx An Usr Taper bore of workpiece spindle: MK 5 Power consumption: 2.7 kW Tailstock: Taper bore of center: MK 4 Coolant tank: 2000 liters, Lubricating oil: 30 liters, Hydraulic oil: 60 liters Operating voltage: 400 volts, 3 phases Mains frequency: 50 Hz Total machine weight: approx. 5800 kg Operating sound pressure level: 70 dB (A)

Condition: used, Year of construction: 2003, functionality: fully functional, Siemens Sinumerik 840D control system includes: grinding media preparation, hydraulic unit, and portal loading system for loading and unloading the machine Technical data: Center distance: 600 mm, center height: 180 mm maximum grinding diameter: 355 mm maximum workpiece weight: 150 kg maximum Z-axis speed: 11 m/min minimum Z-axis speed: 0.01 m/min maximum X-axis speed: 7.5 m/min minimum X-axis speed: 0.01 m/min External cylindrical grinding spindle: Bedpfx Aezh Uwqen Uswr Grinding wheel standard (outer diameter x width x inner diameter): 600 x 80 x 304.8 mm Grinding wheel peripheral speed: 5 - 50 m/s Power consumption of grinding spindle motor: 11 kW Workpiece spindle: Taper bore of workpiece spindle stock: MK 5 Power consumption: 2.7 kW Tailstock: Taper bore of center: MK 4 Coolant tank: 2000 liters, lubricating oil: 30 liters, hydraulic oil: 60 liters Operating voltage: 400 volts, 3 phases Mains frequency: 50 Hz Total machine weight: approx. 5800 kg Operating sound pressure level: 70 dB (A)

Condition: used, Year of construction: 2001, functionality: fully functional, Control system: Siemens Sinumerik 840D Includes: Grinding media preparation, hydraulic unit, and portal loading system for loading and unloading the machine. Technical data: Center distance: 600 mm, Center height: 180 mm Maximum grinding diameter: 355 mm Maximum workpiece weight: 150 kg Maximum Z-axis speed: 11 m/min Minimum Z-axis speed: 0.01 m/min Maximum X-axis speed: 7.5 m/min Minimum X-axis speed: 0.01 m/min External cylindrical grinding spindle: Grinding wheel standard (outer diameter x width x inner diameter): 600 x 80 x 304.8 mm Bwsdpfxjzh Uvtj An Ujr Grinding wheel peripheral speed: 5 - 50 m/s Power consumption of grinding spindle motor: 11 kW Workpiece spindle: Taper bore of workpiece spindle: MK 5 Power consumption: 2.7 kW Tailstock: Taper bore of center: MK 4 Coolant tank: 2000 liters, Lubricating oil: 30 liters, Hydraulic oil: 60 liters Operating voltage: 400 volts, 3 phases Mains frequency: 50 Hz Total machine weight: approx. 5800 kg Operating sound pressure level: 70 dB (A)

Condition: used, Year of construction: 2003, functionality: fully functional, Siemens Sinumerik 840D control system includes: grinding media preparation, hydraulic unit, and portal loading system for loading and unloading the machine Technical data: Center distance: 600 mm, center height: 180 mm maximum grinding diameter: 355 mm maximum workpiece weight: 150 kg maximum Z-axis speed: 11 m/min minimum Z-axis speed: 0.01 m/min maximum X-axis speed: 7.5 m/min minimum X-axis speed: 0.01 m/min External cylindrical grinding spindle: Grinding wheel standard (outer diameter x width x inner diameter): 600 x 80 x 304.8 mm Bwsdpfx Anjzh Uvaj Usr Grinding wheel peripheral speed: 5 - 50 m/s Power consumption of grinding spindle motor: 11 kW Workpiece spindle: Taper bore of workpiece spindle stock: MK 5 Power consumption: 2.7 kW Tailstock: Taper bore of center: MK 4 Coolant tank: 2000 liters, lubricating oil: 30 liters, hydraulic oil: 60 liters Operating voltage: 400 volts, 3 phases Mains frequency: 50 Hz Total machine weight: approx. 5800 kg Operating sound pressure level: 70 dB (A)
