Used Cnc Turn Mill Machine for sale (67,743)

Condition: good (used), CNC turning and milling center with bar loader, FMB Turbo 3000 Turning diameter over machine bed: 400 mm Turning diameter over cross slide: 225 mm Turning length: 640 mm Dsdez Eayiepfx Ak Ascp Siegfried Volz Machine Tools Rüschebrinkstr. 151-153 DE - 44143 Dortmund - Wambel / Germany

Condition: good (used), CNC turning and milling center with bar feeder FMB Turbo 3000 Dedpfx Akez Eaxrs Ajcp Turning diameter over the machine bed: 280 mm Turning diameter over the cross slide: 185 mm Turning length: 250 mm Siegfried Volz Machine Tools Rüschebrinkstr. 151-153 DE - 44143 Dortmund - Wambel / Germany

Condition: used, Year of construction: 2012, functionality: fully functional, Manufacturer: MORI SEIKI CO., LTD. (Japan) Machine model: NLX2500SY Year / Month of manufacture: August 2012 (08 / 2012) Machine weight: 6,360 kg Electrical connection: 3 phases / 50 Hz / 200 V AC Full load current: 144 A Spindle motor current: 177 A Connected power: 50 kVA Dodpfxoz Hwkno Ak Ajcp Main technical specifications Working area & travels: Max. turning diameter: approx. 366 mm Max. turning length: approx. 705 mm Swinging diameter over bed: 920 mm X-axis travel: 260 mm Y-axis travel: ±50 mm (100 mm) Z-axis travel: 795 mm Max. bar diameter: 80 mm Main spindle: Speed range: max. 4,000 rpm Drive power: 18.5 / 15 kW Spindle nose: JIS A2-8 Chuck size: 10 inches Counter spindle: Speed range: max. 6,000 rpm Drive power: 11 / 7.5 kW Chuck size: 6 inches Tool turret: Number of tool stations: 12 stations (powered) Speed of powered tools: max. 10,000 rpm Power of powered tools: 5.5 / 4.2 kW

Condition: used, functionality: fully functional, X-axis: 6,000 mm Y-axis: 4,500 mm Z-axis: 980 mm W-axis: 1,700 mm Table size: 5,000 x 2,500 mm Spindle diameter: 220 mm Spindle mounting: ISO 60 Max. workpiece weight: 35 tons Control system: SINUMERIK 840 C Dcjdo Ah D Huepfx Ak Ajp Including angular milling head.

Condition: like new (used), Year of construction: 2022, operating hours: 2,085 h, functionality: fully functional, turning diameter: 240 mm, spindle speed (min.): 3,200 rpm, travel distance X-axis: 142 mm, travel distance Z-axis: 165 mm, rapid traverse X-axis: 24 m/min, rapid traverse Z-axis: 24 m/min, rotational speed (max.): 2,500 rpm, Only approximately 2,000 operating hours! TECHNICAL DETAILS Travel range X-axis: 142 mm Travel range Z-axis: 165 mm Dcedpfxe Ah Dv Ie Ak Aop Swinging diameter: 240 mm Spindle speed: max. 2,500 rpm Number of spindles: 2 Number of tool turrets: 2 Number of linear robots: 2 Spindle motor power: 11 kW Spindle bore: 90 mm Spindle speed: min. 3,200 rpm MACHINE DETAILS CNC control: FANUC 0i-TD Dimensions & Weight Dimensions (L x W x H): 3,590 x 2,610 x 2,700 mm Total weight: 5,200 kg Operating hours: approx. 2,000 h EQUIPMENT Powered tools C-axis 2 linear robots 2 side feed systems Collet chuck 3-jaw chuck Chain conveyor RAKU-RAKU monitor Extensive full equipment package Continuously adjustable speed Documentation/Manual

Condition: used, Offered for sale: CNC milling machine with enclosed machine guarding. Equipped with a milling spindle, enclosed machining area with viewing window, workpiece support and compressed air hose. Inspection possible by arrangement. Dcsdpfj Aga Iqjx Ak Aep

Condition: excellent (used), Year of construction: 2014, functionality: fully functional, Maximum turning diameter: 465 mm Maximum swing diameter: 680 mm Control system: Siemens Travel range X-axis: 300 mm Travel range Z-axis: 1,050 mm Dodsz Ri U Iopfx Ak Ascp Turning length: 1,050 mm Maximum spindle speed: 3,250 rpm Spindle bore: 76 mm Includes driven tools Number of positions in the tool turret: 12 stations Chuck diameter: 250 mm Maximum workpiece weight between centers: approx. 350 kg

Condition: excellent (used), Year of construction: 2013, operating hours: 19,000 h, DOOSAN PUMA GT2100M – CNC Turning and Milling Center Year of manufacture: 2013 Manufacturer: DOOSAN Model: PUMA GT2100M Machine type: CNC turning center with driven tools Condition: Very good condition Dcods Af Ut Nepfx Ak Aep Technical data Machining capacity * Turning diameter over bed: 600 mm * Turning diameter over slide: 390 mm * Recommended turning diameter: 210 mm * Maximum turning diameter: 300 mm * Maximum turning length: 513 mm * Maximum bar diameter: 65 mm * Chuck size: 8 inches Main spindle * Maximum spindle speed: 4,500 rpm * Spindle nose: ASA A2#6 * Spindle bearing diameter (front): 110 mm * Spindle bore: 76 mm * C-axis, minimum indexing angle: 0.001° Tool turret * Number of tool stations: 12 * Driven tools available * Maximum speed of driven tools: 5,000 rpm * External tool size: 25 mm * Maximum drilling bar diameter: 40 mm * Turret indexing time: 0.3 seconds Axes and travels * X-axis travel: 230 mm (80 + 150 mm) * Z-axis travel: 580 mm * Rapid traverse X-axis: 24 m/min * Rapid traverse Z-axis: 30 m/min Tailstock * Quill diameter: 80 mm * Quill taper: MT4 * Quill travel: 80 mm Electrical data * Electrical connection power: 21.80 kVA Machine dimensions and weight * Length: 2,834 mm * Width: 1,628 mm * Height: 1,700 mm * Machine weight: approx. 3,600 kg Equipment and special features * CNC turning and milling center * Driven tools * C-axis * 12-position tool turret * Tailstock

Condition: used, Year of construction: 1991, Mazak Super Quick Turn 15M – CNC turning machine with C-axis and powered tools Year of manufacture: 08/1991 Djde Ad R Hdepfx Ak Ascp

Condition: ready for operation (used), Year of construction: 1999, functionality: fully functional, machine/vehicle number: 138616, turning length: 1,000 mm, turning diameter: 580 mm, spindle speed (max.): 5,000 rpm, controller model: Mazatrol Fusion 640 MT, milling spindle speed (max.): 12,000 rpm, TECHNICAL DETAILS Dcedjz Inaiepfx Ak Aop Max. turning diameter: approx. 580 mm Max. machining diameter: approx. 520 mm Max. turning length: approx. 1,000 mm Main spindle speed: up to 5,000 rpm Milling spindle speed: up to 12,000 rpm MACHINE DETAILS CNC control: Mazatrol Fusion 640 MT EQUIPMENT Main spindle Milling spindle with B-axis Y-axis C-axis Chip conveyor Documentation, if available Coolant system Tool changer: automatic

Condition: good (used), Year of construction: 2008, turning length: 1,500 mm, turning diameter: 420 mm, Manufacturer: MAZAK Type: QTN 350 II MY Control: Mazatrol Matrix Nexus Year of Manufacture: 2008 Specifications Metric US Standard Max. Turning Diameter 420 mm X-Axis 257 mm Y-Axis 152 mm Z-Axis 1607 mm Spindle Bore 102 mm Speed 3300 rpm Spindle Power 30 kW Tool Changer 12-Speed Driven Tool Power 4000 rpm Driven Tool Power 7.5 kW Quill Mount Dodpfx Akswaikxo Ajcp 5 Mk Quill Stroke 200 mm Dimensions (Estimate) Length 5000 mm Width 2100 mm Height 2200 mm Weight 8600 kg Please note: The information on this page has been compiled to the best of our knowledge and belief, and where possible, by the manufacturer. This information is provided in good faith, but its accuracy cannot be guaranteed. Accordingly, it does not constitute a representation or contractual terms. We recommend that you review all important details.

Condition: good (used), Year of construction: 2014, Description: The machine is in good technical condition, and a test run is possible upon prior arrangement. It is more suitable for serial production; it also includes a feeder and an output belt for finished parts. It comes with accessories – 2 universal chucks, clamps, and holders. Parameter PUMA MX 1600 ST Dodjz S Hnhspfx Ak Ascp Max. machining / turning diameter: 330 mm Recommended turning diameter: 170 mm Max. machining length: 900 mm Diameter over bed: 680 mm Diameter over carriage: 630 mm Bar diameter: approx. 51 mm Standard chuck: 6" Main spindle – speed: 6,000 rpm Main spindle – power: 15 / 11 kW Max. torque of main spindle: approx. 208 Nm Spindle nose: A2-5 Tailstock – speed: 6,000 rpm Tailstock – power: 15 / 11 kW Tailstock – nose: A2-5 Milling spindle: 12,000 rpm Power of milling spindle: 9 kW Torque of milling spindle: approx. 49 Nm Y-axis: 170 mm (??85 mm) B-axis: ??120?? / range 240?? X1: 450 mm Z1: 935 mm X2: 165 mm Z2: 925 mm Tool magazine: 40 positions Max. tool Ø: 70 / 95 mm Max. tool length: 200 mm Tool change time: approx. 2.1 s Lower turret: 16 positions, BMT45 Driven tools of lower turret: 6,000 rpm Power of driven tools: 5.5 kW Control system: Fanuc 31i-A Weight: approx. 11,600 kg Dimensions: approx. 3,800 × 2,530 × 2,760 mm

Condition: used, CNC Vertical Machining Center FEHLMANN Type PICOMAX 60 CNC Control System: HEIDENHAIN TNC 426 Serial No.: 14599641 Year of manufacture: 1999 Travel paths X: 500 mm, Y: 350 mm, Z: 610 mm Feed rate: 1 - 20,000 mm/min Rapid traverse: 20 m/min Feed force: 12,000 N Table clamping surface: 920 x 380 mm T-slots: 7 pcs, 12-H8 mm Table load capacity: max. 250 kg Table height: 1004 mm Distance spindle nose - table: 94 - 704 mm Overhang spindle - column: 405 mm Spindle speed: 50 - 18,000 rpm, stepless Spindle drive: 10.2 kW (60% duty cycle) Max. torque: 70 Nm (up to 1240 rpm) Spindle taper: SK 30 / DIN 69871A Pull stud: DIN 69872 Drilling capacity in steel: 25 mm Milling capacity in steel / aluminium: 100 / 700 cm³/min Thread cutting in steel / aluminium: M20 / M24 Tool changer: 24 positions Dcsdey N Du Djpfx Ak Aop Tool change time: approx. 6 sec. Chip-to-chip time: approx. 8 sec. Control: Heidenhain TNC 426 Power supply: 400 Volt, 50 Hz Connected load: 20 kW - Electronic handwheel Heidenhain HR410 - 3D probe Renishaw MP12 - Tool measurement system - TFT display - Direct path measuring system - Coolant system (200 liters, lateral) - Spindle cooling unit (lateral) - Central lubrication Vogel - Air supply: 6 bar, 40 - 200 l/min - Oil mist extraction - Operating hours: - Control on: 97,000 h - Machine on: 80,000 h - Program run: 42,000 h Required space (L x W x H): 2,000 x 1,700 x 3,000 mm Weight: approx. 3.2 t Good condition

Condition: like new (used), Year of construction: 2023, Maximum turning diameter 220mm, distance between centres 800mm, swing over bed 240mm, spindle speed 4,000rpm, milling speed 12,000rpm, sub-spindle speed 4,000rpm, main spindle bar capacity 66mm, sub spindle bar capacity 66mm, 2 X 12 station turrets, spindle power 35Kw, Y axis + /- 45mm, swarf conveyor, coolant., Fanuc 31i. Djdpfx Aoz D Eupok Aecp

Condition: excellent (used), With C-axis With driven tools FANUC TXP-200 FA control Turning diameter max 360 mm Dedpfx Akjq Dlt Ss Aecp Turning length -683 mm Swing Diameter -450 mm Spindle speeds -3'000 rpm Top turret tool holders 12 driven positions Misc. accessories MARCELS MASCHINEN CH

Condition: new, Year of construction: 2023, machine/vehicle number: 320542/B, functionality: fully functional, number of axes: 3, controller manufacturer: TPA, CNC Drilling and Milling Machine Manufacturer: Vitap Type: K3 New machine Through-feed processing, workpiece machining from below, and automatic workpiece return to the operator Develop an individual class: - With this machine, you can perform many different milling operations in addition to grooving and drilling, from simple edge milling to milling shapes and letters. - We do not limit your creativity. Easy entry into CNC technology: - TPA makes it easy for you: Whether drilling, grooving, linear milling, contour milling, or milling letters. - The CAD software clearly displays the machining operations. - Particularly clear is the programming of the work steps on the individual workpiece sides. - You can mirror machining operations with a mouse click. - You can either enter the starting points precisely or determine them by clicking on the virtual workpiece. Vitap Bar Nesting - efficient and time-saving - This patented software produces entire corpus elements from a long workpiece. - You insert the long workpiece, and when you remove the first finished element, the machining of the next element continues directly. The DDT feed system (double dynamic transport) - 2 clamps enable uninterrupted workpiece transport. - The operator inserts the workpiece until it reaches the stop. - Both clamps then grip the workpiece and position it precisely. - During machining, both clamps communicate with each other, so that clamp 2 grips before clamp 1 releases. - This ensures a constant feed rate even during linear milling. 3 controlled axes: - X axis - DDT feed - Y axis - Drilling head travel - Z axis - Drilling - Double "0" reference: New laser generation for detecting the beginning and end of the workpiece. The program can readjust the drilling from below to achieve perfect alignment in vertical and horizontal workpieces. The laser consists of a transmitter and receiver to avoid errors with dark edge material. - Side stops with rollers, consisting of a fixed and a movable part, mechanical digital readout with automatic alignment to the 0 stop for removal of up to 3 mm on the 0 line - Constant side pressing device for precise positioning to the 0 line - Automatic 4-position tool changer - Adjustable zero point - No workpiece length limitation - Monitor LCD TFT 20" - Industrial PC - Operator interface WSC with Lister, parametric tool, and parametric setup - Graphical programming CAD TPA EDI32, basic version - USB port - Storage of all files - Macro programming - Import DXF files Technical data - Number of independent, vertical spindles: 12 - Number of independent, horizontal spindles on the X axis: (2+2) - Number of horizontal drilling spindles on the Y axis: (2+2) - 1 saw (100mm) - Electro spindle 5 kW with ISO30 taper (RPM [contact removed]) - Max. workpiece weight: 40 kg - Max. workpiece dimensions: X unlimited, Y 1250 mm, Z 50 mm - Min. workpiece dimensions: X 270, Y 150 (70op), Z 3 mm Dcedpfezvduujx Ak Ajp - Feed rate: 25 m/min - Spindle speed: 3600 RPM - Saw speed: 7000 RPM - Max. horizontal tool: 12mm - Max. drilling depth horizontally on the X and Y axis: 35mm - Max. drilling depth vertically: 43 mm - Max. vertical tool: 35mm - Motor: 1.7 kW - Adjustable zero point for 4-sided formatting - CE compliant Optional against additional charge

Condition: used, Year of construction: 2005, Technical details: turning diameter: 275 mm turning length: 900 mm spindle passage: 65 mm power capacity at 100 % load: 25/20 kW Djdewp D Nbspfx Ak Ajcp spindle turning speed range: 1 - 5000 U/min spindle diameter in front bearing: 110 mm c-axis: 1 - 500 U/min. number of workpiece supports: 4 tool turret: 1 x-axis: 290 mm y-axis: 165 mm z-axis: 360 mm b-axis: 360 ° rapid speed: 18/30 m/min number of tools: 2x2 + 2x2 number of driven tools: 2x2 + 2x2 mm toolpiece turning speed range: 8000 / 2000 U/min power capacity: 25% ED 5,8 kW tool taper: TRAUB 60 tool turret: 2/3/4 x-axis: 170 mm z-axis: 600/950 mm y-axis: +/- 60 mm rapid speed: 18/15/30 m/min number of driven tools: 10 mm toolpiece turning speed range: 1 - 6000 U/min power capacity: 25% ED 5,8 kW tool taper: DIN 69880 40 x 63 total power requirement: 95 kW weight of the machine ca.: 16 t dimensions of the machine ca.: 10,0 x 3,5 x 3,0 m with CNC TRAUB TX 8i, Barloader TRAUB Stamag DNH61 / 3000, Main and Sub spindle with C-axis 1 support with B-axis 3 turret supports dust exhauster, coolant attachment with coalescence-seperator and chip conveyor 2 pc. 3-jaw chuck SMW KNCS-N 170-43 2 pc. HAINBUCH Spanntop chuck 40 pc. various tool holder non-driven 6 pc various tool holder driven Spare parts package *

Condition: excellent (used), functionality: fully functional, fixed tool holders Machine: MORI SEIKI SL2000 Manufacturer’s tool turret: SAUTER ---- 2x → No. 444-119 Turning tool holder 25 mm steel holder Fixed turning tool holder Price: 150.00 €/piece ----- Dsdpjynb E Nofx Ak Ascp 1x → No. 444-201 Double turning tool holder for main spindle and counter spindle with 1x clamping strip for 25 mm tool steel Fixed turning tool holder Price: 250.00 €/piece ----- 1x → No. 444-210 Drill bar holder Cylindrical mount, ø 32 mm Second mount, ø 32 mm; 57 mm towards the rear Price: 220.00 €/piece ----- 1 x → No. 444-205 Turning tool holder mount 25 mm steel holder Price: 150.00 €/piece Package price: 750.00 €/net, including shipping within Germany International shipping upon request.

Condition: ready for operation (used), Year of construction: 2001, JOHNFORD VTC 880 TWIN PALLET CNC VERTICAL LATHE MAKE JOHNFORD, MADE IN TAIWAN MODEL VTC 880 + APC + ATC YEAR 2001 CONTROL FANUC 18 T MAX SWING DIA 1,000 mm MAX CUTTING DIA 900.0 mm STANDARD CUTTING DIA 800.0 mm MAX CUTTING HEIGHT 800.0 mm TRAVERSES X AXIS 50.0 mm to 810.0 mm Z AXIS 880.0 mm Dedoukupropfx Ak Aecp SPINDLE SPEEDS 10 to 800 RPM SPINDLE BEARING DIA 330.0 mm SPINDLE NOSE A2 - 11 SPINDLE MOTOR 18.5 / 22 kW TURRET TYPE AUTOMATIC TOOL CHANGER NO OF TYPES 2 X 12 ATC TOOLS SHANK SIZE BT 50 AND CAPTO PLUS FULL C AXIS MILLING TAPPING X, Z, C, A AND B AXES HIGH PRESSURE COOLANT PAPER COOLANT FILTRATION SWARF CONVEYOR FULLY OPERATIONAL FULL SET OF MANUALS GOOD RANGE OF TOOLING

Condition: used, 7-axis turning-milling center Bumotec S192 for sale. Attached is the order confirmation of the high-pressure unit, which is mounted and integrated into the control system. A Breuning short bar feeder is included. Otherwise, the machine operates without any issues. LNS chip conveyor with coolant pump. Cooling unit, oil cooler. Bumotec S192 – with fully automatic LNS chip conveyor and integrated coolant pump Oil cooler Dodpfx Aksw D Sl Tj Aecp Axis cooler Milling spindle: 30,000 rpm Breuning short bar feeder Elbaron extraction system Including 2 turning tool holders and 3 boring tool holders with HSK 40A interface Including 2 collets Counter spindle can be used with 2-jaw chuck or collet E173

Condition: used, Year of construction: 2002, functionality: fully functional, CNC lathe Gildemeister Type: CTX 420 V6 Linear Year of manufacture: 2002 Serial number: 02260000631 Control system: Siemens PowerLine Technical data: Working area: Max. swing diameter over X-axis guide 680 mm Swing diameter over X-axis guide 565 mm Chuck diameter 200/250 mm Travel in Z-axis 260 mm Travel in X-axis 635 mm Spindle head: Spindle head (flat flange) 170 main spindle, 140 counter spindle Spindle diameter in the front bearing 120/90 mm Spindle bore 79/57 mm Main drive: Power of the AC main drive (100% duty cycle) 25 kW Torque max. 270 Speed range 25-5000 rpm Counter spindle Drive power AC 25 kW Torque max. 7000 Nm Speed range 35-7000 rpm Tool carrier Number of tool stations 12 Tool interface according to DIN 69880 Cylindrical shank diameter 40 mm Indexing time 30 ° 0.15 sec. Djdpfxez I T Avj Ak Ascp Number of driven tools 5 Drive power 13.2 kW Torque 28 Nm Speed max. 4500 rpm C-axis, main spindle/counter spindle Speed range 0-250 rpm Torque 200/120 Nm Speed during point positioning 0.025 degrees Y-axis, vertical travel +/- 40 mm Hydraulics Capacity, total approx. 25 l Pressure max. 80 bar Pressure for clamping device max 70 bar

Condition: good (used), Year of construction: 1990, Ref. -No.: 10544 Manufacturer: DECKEL Type: KF 2 Year of construction: 1990 Type of control: N/A Control: N/A Storage location: Halberstadt Country of origin: Germany Power Capacity: 1,6 / 2,0 kW Tool Taper: 20 mm Ø Space requirements: 1600 x 1350 LxWxH (mm) Feed rate: 0-350 mm / min Dcsdpfx Ao Ahmu Ejk Aep Vertical portal passage, clamping table - lower beam cross member: 300 mm Distance table - spindle nose with vertical milling spindle: 50 mm Distance table - spindle nose with horizontal milling spindle: 450 mm Machine Height: 1950 mm Weight: 2,1 t Pre-milling spindle: 80...1000 min-1 Collets: 20 O taper bushing: Morse 1 Touch lift: 12 O Speed of the milling motor: 1400 RPM Further information: - Optical testing device - Pre-milling spindle - Model milling device - Rotary table - Inclined spindle - Mirror image milling device - Reduction and enlargement device - Roller engraving devices - Machine vice hydraulic clamps - Auxiliary clamping table - Dividing head - Tool cabinet - Clamping claws - template bars - articulated light The machine can be viewed under power by arrangement.

Condition: reconditioned (used), Year of construction: 2011, functionality: fully functional, Controlled by Siemens Year of manufacture: 2011 Travel in X: 300 mm Travel in Z: 1050 mm Spindle bore: 103 mm Speed range: 20 – 3250 rpm Including the following accessories: Sliding guard 12-position turret with 6 driven tool stations Tool measurement in the working area 3-jaw chuck, hydraulic, SMW Autoblock 0, 315 mm Foot switch for chuck, foot switch for tailstock Various tool holders VDI 40 Dcedpfx Aszd Dczok Ajp Various sets of top jaws Various turning tools Signal lamp, 4-color Tailstock with quill Chip conveyor with coolant tank 4 machine feet Operating manuals

Condition: reconditioned (used), Year of construction: 2018, functionality: fully functional, CNC turning machine GILDEMEISTER CLX 350 V3 With DMG MORI SLIMline Multi Touch Fanuc I series control Year of manufacture: 2018 Turning diameter: 320 mm Travel in X: 242 mm Travel in Z: 540 mm Spindle bore: 65 mm Speed range: 20 – 5000 rpm With the following accessories: Sliding safety shield with interior lighting 12-station turret with 12 driven tool stations VDI 30 C-axis, tailstock with quill Programmable tailstock via M function Tool measurement in the work area Dcsdpfx Aszd Dlpok Aep Electronic handwheel Chip conveyor 3-jaw chuck, hydraulic, Schunk ROTA THW plus 0 210 mm Foot switch for chuck adjustment Parts catcher Glass scale in the X axis Coolant system with high-pressure pump 12 bar Coolant spray gun Operating manuals

Condition: good (used), Hwacheon HI Eco 31A CNC Lathe, C Axis & Live Tools, Serial Number 1053444L45, Year 1998, Swarf Conveyor, Foot Pedal, Dcedpfoz N A Avsx Ak Aop Fanuc CNC Control, 2 Jaw & 3 Jaw Power Chucks, Tool Arm, Tailstock, 10 Station Turret, Manuals, Toolholders, Transformer
