Used Crimp Elumatec for sale (111)

Condition: ready for operation (used), Year of construction: 2013, This Elumatec DG 244 was manufactured in 2013. It features a 4.5m double mitre saw, pneumatic clamping device, dust extraction, and a profile lifting bar set. Suitable for both stationary and mobile units, it also includes a cycling device and front light curtain. Contact us for more information. Ncedpfjycuquex Afzjl • Working length: 4.5 m Additional equipment • Short Stop • Pneumatic Clamping Device • Dust Extraction • Profile Lifting Bar Set for stationary and mobile units • Cycling Device • Front Light Curtain

Condition: used, Year of construction: 1994, Cutting length scale up to 5000 mm, saw blade 420 mm, roller conveyor 1500 mm, electro-motorized movement of the right unit, digital measurement display, saw units swiveling and tiltable. Storage location: customer Nodsw Sadrepfx Afzecl

Year of construction: 2002, condition: used, Max. profile width at 180°: 220 mm Max. Profilhöhe: 210 mm Adjustment range of angle: 30°-180° Nedpfx Asyab D Njfzjcl Welding mirror: 340 x 300 mm

Year of construction: 2002, condition: used, Max. cutting length: 3000 mm Max. saw blade diameter: 380 mm Cutting area at 90°: 195 x 120 mm Cutting area at 45°: 135 x 120 mm Minimum quantity spray device Pneumatic material clamps Miter cuts possible on both sides 2-Hand-Bedienung Ncsdpfoyabzujx Afzol

Condition: good (used), Year of construction: 2009, Elumatec SBZ 140 Extended Length Version: 7.6 meters Approximate weight: 5,000 kg Automatic tool changer 2-section clamping system 2 pneumatic stops Safety hood Light curtains Automatic clamp detection Central lubrication Coolant spray system Chip trolley Conditioning unit Max spindle speed: 24,000 rpm Tool holder: HSK-63F, 8-position tool changer Max milling diameter: 80 mm Max saw blade diameter: 200 mm Compressed air: 7 bar The SBZ 140 is a 4-axis profile machining center (axes: X, Y, Z + A). Designed for aluminum and thin-walled steel profiles. 4-axis CNC machining center (X/Y/Z + tilt/rotation axis A) X-axis: approx. 7,900 mm travel Y-axis: approx. 850 mm travel Ncjdox E Ahzjpfx Afzsl Z-axis: approx. 650 mm travel A-axis (rotation/tilting): Freely programmable angle, –90° to +90° Axis traverse speed: X-axis up to approx. 65 m/min, Y- and Z-axis up to approx. 60 m/min (varies with configuration) Control: 4-axis CNC system, PC control, color display, USB & network connectivity. Software: eluCam. Automatic material clamps; automatic positioning via index pins Pendulum/shuttle operation (two work zones), improving production throughput time. In addition to milling and drilling, also tapping, sawing, and profile machining—all with stationary clamped profiles. Please note: The information on this page has been obtained and compiled to the best of our knowledge, but its accuracy cannot be guaranteed. Accordingly, it does not constitute a representation or contract and we recommend verifying all relevant details. Financial information VAT/margin: VAT: The price shown is exclusive of VAT (VAT deductible for business customers).

Condition: used, Year of construction: 2007, Technical data: Speed: 2800 1/min Saw blade: ø 380 mm Motor power: 3000 W Roller conveyor, approx.: 128 mm Weight, approx.: 200 kg Nsdorwlwvjpfx Afzjcl Dimensions (WxDxH), approx.: 1760 x 800 x 1680 mm

Condition: used, Year of construction: 1999, x-axis 6450 mm y-axis 400 mm z-axis 380 mm working lenght 6500 mm Number of tools 8 St. tool taper BT30 tool changing time 1,2 sec diameter of tools max. 80 mm turning speeds 6000 U/min Feed speed X = 34 m/min. Feed speed Y+Z = 18 m/min. Ncsdpfxot H Sn Rs Afzel total power requirement 8,5 kW dimensions 9800 x 3000 x 2400/3300 mm weight 5400 kg *Bar machining center, 3-axis machining of aluminum, plastic, steel and stainless steel profiles*

Condition: used, Copy milling machine, copy milling machine, hand lever milling machine, hand lever milling machine, single spindle copy milling machine -Manufacturer: Elu, copy milling machine type AS 70 -Travel path: manual X//Y 230/80 mm -Stop depths: see photos -Workpiece clamping: pneumatic Ncsdpfx Ajp Swvksfzsl -Coolant device -Dimensions: 600/520/H1280 mm -Weight: 111 kg with pallet

Condition: used, Year of construction: 1997, Copy milling machine, copy milling machine, hand lever milling machine, hand lever milling machine, single spindle copy milling machine -Manufacturer: elumatec, 1-SPINDLE COPY MILLING MACHINE Type AS 70/44 -Spindle speed: 12000 rpm -Stop depths: see photos -Workpiece clamping: pneumatic Ncodpfx Ajtvhr Ssfzjl -Dimensions: Milling machine 580/500/H1510 mm roller blocks 1050/210/H900 mm -Weight: 149 kg with pallet

Condition: used, Stop for chop saw, pull saw, stop and measuring system -Manufacturer: elumatec, stop and measuring system with digital display -Inclusion: Bosch profile -Length unit: 4280 mm -Price: complete Ncsdpfxsinwuqs Afzel -Dimensions: 4710/510/H635 mm -Weight: 72kg

Condition: used, Screw jack, linear drive, linear gear, lifting gear, screw jack, spindle drive, electric actuator, valve drive, actuator, servomotor, screw jack, lifting drive -Spindle lifting gear: from double mitre saw elumatec DG 204 -Manufacturer gearbox: Atlanta, type 539 05 040 i 4 -Engine manufacturer: SEM, type DPM30E4 36 V 0.18 kW -Dimensions: 450/320/H130mm Nodottnt Iepfx Afzocl -Weight: 9.5 kg

Condition: good (used), Year of construction: 2004, Large milling area despite compact construction Copy milling machines with lateral stops or a template in 1:1 ratio Two-stage pneumatic copying finger for two different cutter diameters Ncodpfxox Rixko Afzjl The patented suspension of the copying lever ensures precise milling with minimal effort Table height adjustment for extremely high profiles up to 400 mm Simple tool change with "Spindle lock" Pneumatic material clamping device Spray device with dosing

Year of construction: 2004, condition: good (used), Machine frame DG 104 M made of steel sheet (cutting length 6,000 mm) Profiled lifting bars Movable or automatically retractable workpiece supports Material clamping units Cross stop and head stop Exhaust connections, extraction system Timer system Roller conveyors Saw blades High-performance cutting fluid Nedpox Rinrefx Afzscl

Condition: excellent (used), Year of construction: 2015, functionality: fully functional, Excellent technical condition of machine. Nodpfxswltqaj Afzjcl

Year of construction: 1995, condition: used, functionality: fully functional, We offer this used Elumatec AMS 200 measuring stop, year of manufacture 1995. Manufacturer: Elumatec Model: AMS 200 Nodpjyc N A Sefx Afzecl Year of manufacture: 1995 Condition: used Category: 1231 Type: measuring stop Length: 5 m If you have any further questions or need more information, feel free to send us a message or call us.

Year of construction: 2004, condition: ready for operation (used), functionality: fully functional, travel distance X-axis: 9,500 mm, travel distance Y-axis: 1,000 mm, travel distance Z-axis: 630 mm, spindle speed (max.): 24,000 rpm, machine/vehicle number: 031809, TECHNICAL DETAILS Travel X-axis: 9,500 mm Travel Y-axis: 1,000 mm Travel Z-axis: 630 mm Feed rate X-axis: 70 m/min Feed rate Y-axis: 40 m/min Feed rate Z-axis: 40 m/min Swivel angle A-axis: ±110°, freely programmable in 0.1° increments Swivel angle C-axis: ±182°, freely programmable in 0.1° increments Spindle speed: max. 24,000 rpm Spindle power: 15 kW S1 Milling cutter diameter: max. 100 mm Slitting cutter diameter: max. 100 mm Saw blade diameter: max. 400 mm Tool holder: HSK-63F MACHINE DETAILS Compressed air connection: 7 bar Electrical connection: 400 V, 3~, 50 Hz, 80 A Ncsdoycul Sopfx Afzol Air consumption: approx. 200 l/min with spraying EQUIPMENT Machining operations: milling, drilling, tapping, thread milling, slotting, and sawing with stationary profile bar 6-sided machining: optional from the front, possible from below Profile bar protection: machining with stationary profile bar Robust and low-wear direct drives on all axes Axes: 5-axis control for spatial machining Display: 15-inch color screen Interfaces: USB ports, network connection 2-layer machining for pendulum operation Included tools (HSK holders) Two circular saws for aluminum

Condition: excellent (used), Year of construction: 2009, functionality: fully functional, We are selling a CNC machine. Price 32.000,00 We also have a complete line for the production of PVC and aluminum windows and doo. Ncsdpjw Rnl Iefx Afzjl Contact phone: +38267674894 Igor Globarevic

Year of construction: 2015, condition: good (used), functionality: fully functional, machine/vehicle number: Machinenummer 1510052425, elumatec SBZ 151 5-axis machining center with a length of 7.3 meters. - 5-axis CNC profile machining center - Designed for flexible and efficient processing of aluminium profiles and thin-walled steel profiles - Rapid positioning of the machining unit - 6-sided machining capability, including bottom-side machining with angle head - Traveling tool magazines ensure short tool change times - Magazine with 13 standard tools and seven special tools Nsdpfx Afox Tg S Hezjcl - Autonomous clamp adjustment with absolute measurement system - Two separate machining zones for pendulum (alternate) operation - 5-axis CNC control for optimal machining capabilities and complex cutting operations - Network connection and USB interface - Supplied with Windows operating system and 15” flat screen monitor Machine options: - 2 zero reference points - 10 material clamps - 21 kW spindle - 2 angle heads for machining the underside of the profile - 12 various tool holders - Remote control for all axes - Label printer

Condition: used, Year of construction: 2019, functionality: unexamined, Auction: Plant closure Roschmann, Gersthofen (Augsburg) Bid now – Sale to the highest bidder. Lot 2910010: Nsdpfxox N Nigs Afzecl Lot consisting of 1 used single mitre saw with conveyor belt in good condition. Shows minor signs of use and is suitable for precision cutting operations with pneumatic clamping and automatic feed assistance. Mitre saw: Elumatec TS161/21, year of manufacture 2019. Motor power: 1100 W, 4100 rpm. Feed system: Ruchser RU-LAP3 conveyor unit, 1.5 kW, 50 kg/m load capacity. Electrification: 400 V (saw), 230 V (RU), 50/60 Hz, 3.0 A + 4.5 A. Pneumatics: 7 bar air pressure, pneumatic clamping. Accessories: Integrated control panel, conveyor frame, length stop.

Year of construction: 2008, condition: used, functionality: unexamined, Auction: Plant Closure Roschmann, Gersthofen (Augsburg) Nedpjx N Niasfx Afzecl Place your bid now – Sale to the highest bidder. Lot 2910009: Complete industrial-grade double miter saw system for precise cutting of aluminium or PVC profiles, featuring integrated dust extraction. This robust and reliable setup is ideally suited for use in window, façade, or profile fabrication, where accurate angle cuts and clean operation are essential. Technical Specifications: Double Miter Saw - Manufacturer: Elumatec - Model: DG 244/10 - Power supply: 3~PEN / 400 V / 50 Hz - Motor output: 3.5 kW - Compressed air requirement: 7 bar - Speed: 2,800 rpm - Year of manufacture: 2008 Dust Extraction Unit - Manufacturer: Schuko (H. Schulte-Sudhoff GmbH & Co. KG) - Model: DG 244 - Airflow rate: 1,870 m³/h - Motor output: 2.2 kW - Suction pressure: 1,050 Pa - Power supply: 230/400 V, 50 Hz

Condition: excellent (used), Year of construction: 2024, operating hours: 193 h, functionality: fully functional, travel distance X-axis: 7,200 mm, travel distance Y-axis: 480 mm, travel distance Z-axis: 340 mm, cutting width (max.): 335 mm, workpiece length (max.): 6,000 mm, milling spindle speed (max.): 6,000 rpm, section length (max.): 6,000 mm, TECHNICAL DETAILS - Profile Milling Machine Processing length: 7,200 mm Number of axes: 4 Control: eluCAM graphical, Windows XP user interface Workstations: 2 independently operating stations Turret tool changer: 8 tools, servo motor driven Tool holder: BT 30 Ncsdswprmzjpfx Afzjl Disc mill diameter: 180 mm Tool length: 150 mm (from point of attachment) Travel distances Travel X-axis: 7,200 mm (without end-face processing), 7,080 mm (with end-face processing) Travel Y-axis: 480 mm Travel Z-axis: 340 mm Rapid traverse X-axis: 60 m/min Rapid traverse Y-/Z-axis: 30 m/min Positioning accuracy: ±0.1 mm/m Spindle Milling spindle speed: 1 to 6,000 rpm Milling spindle power: 6.0 kW Supply Air connection: min. 7 bar Air consumption: 100 l/min Electric connection: 400 V, 3~, 50 Hz, 35 A EQUIPMENT two independent workstations with light barrier and camera system Non-swiveling inclined milling head for 2 tools, Er20A, up to 18,000 rpm Inclined milling head swiveling 4 × 90°, Er20, up to 22,000 rpm Inclined milling head non-swiveling for steel, Er20A, 1,554 rpm Fixed saw head i=1:1, for D=300 mm saw blade, suitable for 90° cross cuts Carbide saw blade Z=100, D=300 mm, cutting width 3.2 mm Tool holder i=1:3.86 for 18,000 min⁻¹, ER25 Cooling/lubricating unit for steel processing Disc milling holder BT30, D=16 mm Disc cutter D=92 × 6 mm, Z=14, D=16 mm, carbide teeth TECHNICAL DETAILS - Double Mitre Saw Max. cutting length: 6,000 mm Min. cutting length at 90°: 335 mm Min. cutting length at 45°: 335 mm Saw blade diameter: 420 mm Cutting angle (rotation): pneumatically adjustable 90° and 45° inside, intermediate angles and 22.5° acute manually adjustable with digital display Cutting angle (tilt): pneumatically adjustable 90° and 45° inside Saw direction: saw blades move from bottom to top Control Control type: E580/1 Length adjustment: automatic with positioning control Saw blade tilt: pneumatically automatic between 90° and 45° Positioning accuracy: ±0.1 mm/m Positioning: pneumatic locking Operating system: Windows Saw unit Speed: 2,800 rpm Power per motor: 4,000 W (5.5 HP) Saw blade cooling: available Air consumption per cycle without cooling: 40 l Air consumption per cycle with cooling: 64 l Supply Electric connection: 230/400 V, 3-phase, 50 Hz Air connection: 7 bar Dimensions and Weight Length: 7,550 mm Width: 1,600 mm Height: 1,450 mm Weight: 1,750 kg EQUIPMENT Automatically closing protective covers Electronic positioning of the heads with +/- 0.1 mm/m accuracy Digital angle display for manually adjustable special angles Pneumatically adjustable saw blade rotational and tilt angles Operation via Windows control with 8.4" display and handwheel Cooling system for saw blades included Saw unit with bottom feed for optimal cutting force

Year of construction: 2008, condition: good (used), 4-axis workingcenter Ncedpfx Afsx Syx Djzol

Year of construction: 2008, condition: excellent (used), functionality: fully functional, machine/vehicle number: 1400040426, 4-axis CNC-controlled profile machiningcenter with a machining length of 7,600 mm • eluCad software including 2 user licenses • 2 machining zones for pendulum operation Ncodpfx Afox Sybrezjl • Stepless machining between −90° and +90° with any available tool • Windows operating system • For economical and efficient machining of aluminum and thin-walled steel profiles • Standard version with an 11 kW milling spindle • All machining operations, such as milling, drilling, and tapping, are performed on a stationary clamped profile • The traveling tool magazine can be equipped with up to eight tools

Year of construction: 2008, condition: excellent (used), functionality: fully functional, ❇️ elumatec SBZ 122 / 30 – CNC Machining Centre for Aluminium Profiles Very good condition | fully functional | well-maintained industrial machine ⸻ For sale is a high-quality CNC machining centre elumatec SBZ 122/30 from a window and façade construction company. The machine is in very good, well-maintained, and fully operational condition, and was productively used up to the end. It is ideally suited for efficient processing of aluminium, light metal, and thin-walled steel profiles in professional window, door, and façade construction. The machine was ordered at the end of 2007, delivered and commissioned in May 2008. Throughout its entire service life, it was operated by a single, highly conscientious employee, including all necessary work preparation. On-site inspection and functional testing are possible by appointment at any time. ⸻ ❇️ Machine • Manufacturer: elumatec • Model: SBZ 122 • Machine type: CNC machining centre for profile processing • Application: Window, door, and façade construction • Control system: elumatec CNC control with operator panel & keyboard • Axes: CNC-controlled multi-axis machining • Material processing: - Drilling - Milling - Thread cutting - Notching / profile processing ⸻ ❇️ Equipment & Highlights • CNC processing unit with automatic tool changer • Integrated roller conveyor / material support • Multi-beam safety light curtain SICK M4000 • Pneumatic clamping technology • Cooling and lubrication unit • Operator panel with monitor & keyboard • Foot switch • Heavy-duty industrial design – durable & precise • Ideal for series and single part production ⸻ ❇️ Condition & History • Very well-maintained overall condition • Technically fully functional • Maintenance and any necessary repairs carried out by Vincon (elumatec’s service and sales partner) • Use of original spare parts • Very low reject rate due to careful work preparation and operation • Minimal tool wear • No known technical defects ⸻ ❇️ Documentation & Accessories • Operating manual for SBZ 121/122 operating software (2 copies) • Operating manual for SBZ 122/20+30 • Tool list including recommended cutting data • CD-ROM for SICK M4000 multi-beam safety light curtain • Copy of the original invoice from 2008 with details of the delivery scope at that time ⸻ ❇️ Technical Data • External dimensions (L × W × H): approx. 7,000 × 2,200 × 2,600 mm (approximate, precise measurements upon inspection) • Weight: approx. 4,500 kg (estimated) Ncsdpsx Tfi Rofx Afzjl ⸻ ❇️ Price €21,900 net plus 19% VAT ⸻ ❇️ Terms & Conditions • Sale on behalf of the customer • Invoice with VAT shown separately • Location: 72229 Rohrdorf • Loading by overhead crane available on site • Delivery possible on arrangement and cost coverage • Collection preferred ⸻ ❇️ Inspection & Enquiries Available by phone or message – inspection explicitly recommended.

Year of construction: 1996, condition: used, Max. saw blade diameter: 280 mm Pneumatic material feed via two-hand operation minimum quantity spraying Ncedpfx Aex Ivqzefzsl Bevel cuts possible on both sides with detent points Roller conveyor and length stops on request
