Used Drilling And Tapping Machine for sale (69,998)

Condition: excellent (used), Numerical Control Type Power Control PC85T Software WoodWOP + TOPDRILL Fodpezrd Sfsfx Am Aspk No. 2 Through-feed motorized conveyoring belts No. 2 Horizontal units/supports (with Digital quota/axes display) No. 1 Drilling head for each horizontal unit (1 x Kw 1,5) No. 21 Splindles for each horizontal drilling head Max. working width (mm) 2500 Min. working width (mm) 250 No. 4 Bottom vertical units/supports (with Digital quota/axes display) No. 2 Drilling heads/blocks for each bottom vertical unit (2 x Kw 1,5) No. 4 Vertical top pressure clamps Motorized carpet to evacuate chips and wastes Total installed power (Kw) 35

Condition: ready for operation (used), functionality: fully functional, Brierley Universal Automatic Drill Grinder Fpsdpfx Aszlhlpsm Ajk Model: ZB 32 Capacity: 2.5-32mm With Cams

Condition: ready for operation (used), functionality: fully functional, total width: 355 mm, total length: 381 mm, total height: 1,270 mm, grinding wheel diameter: 203 mm, Dormer Automatic Drill Grinder Model: 108 Fpodpfxozlg Sze Am Ask

Condition: excellent (used), Cup band forming machine with press-in device Pneumatic clamps Foot pedal, stop rail and stand Some drills included Fsdpfxst Tbuts Am Aspk

Condition: good (used), machine/vehicle number: 10403, Standart Machine 4-head Fedpjzqr Sdsfx Am Aspk

Condition: good (used), functionality: fully functional, Radial drilling machine BWF BR40 * 15 speeds * min. speed: 22.4 rpm * max. speed: 2800 rpm Fsdpjviu Nmofx Am Aopk T slot table: * Length: 1600mm * Width: 800mm Machine dimensions: * Length: 2500mm * Height: 2800mm * Width: 1000mm

Condition: excellent (used), Year of construction: 2022, Specification: Vertical Drill Block with 13 Spindles Horizontal drill block with 4 spindles in the X Horizontal drill block with 2 spindles in the Y Grooving Saw D=100mm Plausibility check 10kw tool change spindle 4 position tool changer Workpiece length max 200-3050mm Workpiece width 70-850mm Workpiece thickness 8-56mm Powertouch screen Woodwop for machine Fpjdjzdki Uopfx Am Ajk Energy Saving Mode

Condition: used, Year of construction: 2016, TECHNICAL DATA AXES Max. workpiece dimensions X-Y-Z mm 3050 x 800 x 50 Min. workpiece dimensions X-Y-Z mm 300 x 90 x 10 Drilling/slotting working area mm 0 x 800/0 x 800 X axis stroke mm 750 Max. travel speed of X-Y axes m/min 25 DRILLING UNIT Vertical spindles Number 7 (4X-4Y one common) Horizontal spindles (along the Y axis) Number 2 (1+1) Horizontal spindles (along the X axis) Number 1 Fixed grooving saw (direction) X Grooving saw diameter mm 100 Max. grooving saw thickness mm 5 Motor power kW (HP) 1.5 (2) Spindle speed rpm 3350 Grooving saw speed rpm 4300 INSTALLATION Power supply V (Hz) 380 / 400 (50 / 60) Installed power KVA 4.5 Compressed air requirement bar 6 Compressed air consumption Nl/cycle 90 Extraction requirement m3 / h 1200 Extraction air speed m / sec 20 Extraction nozzle diameter mm 80+80 F10L Drilling unit Includes: - 7 independent vertical spindles - Drill chuck D10 mm - Distance between spindles 32 mm - 2 horizontal drilling heads, 1 in X direction with one drill, 1 double drilling head in Y direction (1 + 1 drill chuck D10 mm) - Speed 3350 rpm - 1 integrated sawing unit in X (max. Diameter 100 mm) - Saw blade speed 4300 rpm - Motor power 1.5 kW - Vertical pneumatic travel per spindle 70 mm - Horizontal pneumatic travel of the drilling unit. Positioning of the workpiece and drive of the work unit: A CNC-controlled suction cup clamps the workpiece and positions it sequentially under the work unit during machining. Movement in the X and Y axes takes place on THK guides with transmission to reinforced toothed rails. Movement in the Z axis is pneumatically controlled on ball-bushing guides with adjustable stop positioning. The positioning of the work units is carried out using technology and drives with DC motors. CNC CONTROL The control system was specially developed for use in drilling and milling machines. CN - 7" color screen with touchscreen function - Alphanumeric keyboard - Self-diagnosis and any error messages or malfunctions that may occur, in the operator's language Programming - Programming via the CN - Automatic optimization of drilling operations - Option of plate zero point shift - Option of saving and importing drilling programs via USB dongle - Option of importing drilling programs from CAD-CAM external software Configuration - User interface in the same language as the instruction manual Graphic representation of the unit configuration Vacuum suction cups "B-Power Vacuum suction cups with double vacuum connection, recommended for particularly porous panels (e.g. MDF light). Machine user interface software Xilog Maestro USB Hardware and software requirements: - Operating system: Windows XP Professional (SP2), Windows Vista or Windows 7 - Processor: Intel compatible, 2GHz min; Multicore processor recommended - Memory capacity: 1GB min., recommended 2GB - Free disk space: 5GB - Graphic card: Compatible OpenGL (The code includes a DVD for installation and a USB key) Xilog Maestro Features Programming - Parametric, graphic programming - Assisted programming with graphic and syntax help for drilling operations - Possibility to create and save machining macros Integrated additional functions - Self-diagnosis and possible error messages or malfunctions, in the operator's language - User interface in Fpodpfx Amjvvi I Re Ask

Condition: used, Year of construction: 2002, Drilling capacity: 25 mm, spindle mount: MK 3 Fedpsvvi Auefx Am Aspk Storage location: Nattheim

Condition: used, Year of construction: 2000, functionality: fully functional, feed length X-axis: 4,000 mm, feed length Y-axis: 1,050 mm, feed length Z-axis: 200 mm, drilling capacity: 40 mm, quill stroke: 200 mm, quill diameter: 80 mm, Dimensions and Travel Ranges Tool holder: SK 40 Table dimensions: mm 4000 x 800 Number of T-slots: 6 T-slot spacing: mm 140 Distance: - Spindle bottom edge: min. mm 140 - Table top edge: max. mm 740 Boring radius: - min. mm 540 - max. mm 1590 Travel range U-axis: mm 2600 Travel range Y-axis: mm 1050 Quill stroke (Z-axis): mm 200 Column stroke (W-axis): mm 400 Machining Data Drilling performance in solid material: - St 60: mm 40 - GG 22: mm 50 Thread cutting: - St 60: M 36 - GG 22: M 42 Main spindle drive AC motor, frequency-controlled kW 5.5 at 100% duty cycle Speed range: min-1 15 - 2800 Torque: Nm max. 250 Constant from: min-1 15 - 200 Feed drives X-axis - AC servo motor kW 0.25 Y-axis - AC servo motor kW 0.25 Z-axis - AC servo motor kW 4.50 W-axis - AC servo motor kW 2.50 U-axis - AC servo motor kW 2.50 Rapid traverse speeds (X/Y/Z): m/min 7.5 / 7.5 / 5 Rapid traverse speeds (U/W): m/min 7.5 / 3 Fpjdpey Ttrtefx Am Aok Feed rates, infinitely variable: mm/min 5 - 2000 Feed force: N 12000 Accuracy Positional accuracy X, Y axis at 1200 mm: mm ± 0.075 Repeatability X, Y axis: mm ± 0.03 Positional accuracy Z axis: mm ± 0.05 Repeatability Z axis: mm ± 0.03 Positional accuracy W axis: mm ± 0.05 Repeatability W axis: mm ± 0.03 Electrical data Operating voltage / frequency: V / Hz 400 / 50 Control voltage: V 24 Total connected load: kVA 13.0 CNC control Axes: 5 (X, Y, Z, W, U), expandable Screen: TFT flat screen, backlit, easily readable from all sides Position data: Cartesian or polar, dimensions absolute or incremental, Unit of measurement: mm or inch, or in degrees Interpolation: 2 axes (X, Y) Technology database: Tool management, tool suggestions according to machining process, material-dependent cutting data suggestions Tool management: max. 500 tools Subprogram technology: yes Machining cycles: Cycles for centering, drilling, threading, reaming, countersinking and boring, freely programmable cycle for special tools, dwell time possible in each cycle Chip breaking / chip removal: possible in drilling cycle Drilling patterns: Hole pattern, hole circle, matrix Basic software: Programming in dialog mode, 38 zero-point offsets, rotation and mirroring, teach-in for X, Y, Z, restart in program with selection functions for targeted entry Zero point determination: Cycles for determining zero points by manually probing the workpiece for: - any clamped rectangular parts - any clamped round parts - aligning cast and sintered parts - Angle detection for round parts by probing the reference edges or surfaces Data interfaces Paint finish with signs of use Standard paint finish, two-component textured paint Machine upper part: light grey RAL 7035 Machine lower part: light blue RAL 5012 Documentation Operating and programming manual Electrical wiring diagram Spare parts drawings Test report for mechanics, electrical system and safety devices

Condition: good (used), Year of construction: 2007, functionality: fully functional, Ficep 1001 DZB CNC Drilling / Sawing Line- Year 2007. Rotating Spindle. Fedpfxszrpx Ds Am Aopk Automatic Tool Changer. 4 way Scribing. Gripper feed. 18.3 metres infeed and 18.3 metres outfeed. Lift and Carry Infeed and Outfeed Cross Transfers. 1000mm Section Capacity.

Condition: used, functionality: fully functional, spindle mount: MK 2, quill stroke: 120 mm, Equipment: type plate available, Gillardon pillar drilling machine Manufacturer: Maschinenfabrik Wilhelm Gillardon II, Bretten i. Baden Fpedpfx Aeh N Svljm Ask According to the information on the attached nameplate, the drilling machine is powered by a motor from VEM Elektromotorenwerke Thurm. Electric motor Three-phase asynchronous motor, type KPER 80 K 4 VEM Motors Thurm GmbH, D Zwickau 3 speed ranges via belt drive. Pinole stroke approx. 120 mm, drilling spindle with Morse taper 2, weight approx. 150 kg / approx. 1380 RPM MK2 drilling column Power consumption 0.75 kW, mains connection 380 volts, 50 Hz. Good used condition Nameplate present An inspection of the bench drilling machine while it is powered on is possible after prior appointment. Price negotiable Our asking price is €390 net ex works, plus packaging costs. All technical specifications are subject to typographical errors/mistakes. Sale exclusively within EU countries.

Condition: excellent (used), Catalogue number: 7859 ADVANTAGES – 8 spindles – with oscillation – variable spindle spacing (adjustable) Fpsdezdz Hqspfx Am Ajk – 2 work tables – unpainted – used drilling machine, in very good condition TECHNICAL DATA Drilling spindles: 2x4 pcs Oscillation range left/right: 40mm per side Oscillation speed adjustment on inverter Spindle head adjustment: up/down Each pair of spindles (2 pcs) adjustable: left/right 2 rotation speed options + left/right Max tool diameter: 15mm Table adjustment: up/down Table dimensions: 700x200mm 4 hydraulic cylinders Motor power: 2x 2kW Oscillation motor: 0.75kW Dimensions (L/W/H): 1800x1350x1300mm Weight: 862kg Net price: 16,900 PLN Net price: 4,020 EUR Net price calculated at exchange rate 4.2 PLN/EUR (In case of significant exchange rate fluctuations, the price may change)

Condition: as good as new (ex-display), Year of construction: 2021, The machining center PROJECT TF 600 S was developed for efficient cabinet (carcass) production. Technical Specifications: Axes: X-Axis: - Max. workpiece length: 2,800 mm - Min. workpiece length: 200 mm - Travel speed: 130 m/min Y-Axis: - Max. workpiece width: 1,200 mm - Min. workpiece width: 50 mm - Travel speed: 75 m/min Z-Axis: - Max. workpiece thickness: 60 mm - Min. workpiece thickness: 8 mm - Travel speed: 30 m/min Units for 6-sided machining: 1. Top drilling head: - Vertical spindles in X-direction: 7 pcs - Vertical spindles in Y-direction: 5 pcs - Horizontal twin drilling spindles in X-direction: 2+2 pcs Fjdpfx Amew Ugpyj Aspk - Horizontal twin drilling spindles in Y-direction: 1+1 pcs - Spindle pitch: 32 mm - Spindle speed: 3,400 rpm - Motor: 2.2 kW 2. Top drilling head: - Vertical spindles in X-direction: 7 pcs - Vertical spindles in Y-direction: 5 pcs - Horizontal twin drilling spindles in X-direction: 2+2 pcs - Horizontal twin drilling spindles in Y-direction: 1+1 pcs - Spindle pitch: 32 mm - Spindle speed: 3,400 rpm - Motor: 2.2 kW 3. Top grooving saw in X-direction: - Speed: 3,400 rpm - Max. saw blade diameter: 120 mm - Groove position: between 55 and 800 mm 4. Top routing unit: - For milling and grooving - Motor: 3.5 kW - Collet: ER 25 - Max. tool diameter: 16 mm 5. Bottom routing unit: - For milling and grooving - Motor: 3.5 kW - Collet: ER 25 - Max. tool diameter: 16 mm 6. Bottom drilling head: - Vertical spindles in X-direction: 3 x 3 pcs - Spindle pitch: 32 mm - Spindle speed: 3,400 rpm Control via Windows PC Software: MASTERWORK MACHINE VERSION Mobile control console with color screen, keyboard, and mouse Wireless barcode reader Additional features: - Intelligent, patented worktable: The worktable moves automatically up and down, as well as left and right for optimal support of all drilling and milling operations. Through-feed drilling and milling is also possible. - Controlled workpiece clamping device - Energy-efficient air flotation tables using an integrated fan (instead of external compressed air) - Rack and pinion drive on X and Y axes with linear guides - Ball screw drive on Z-axis with linear guides - CE safety features: light barriers and fencing, as well as 2 pressure stages for the clamping jaws - Automatic central lubrication system Further data: Dimensions: 5,280 x 2,480 x 2,190 mm (LxWxH) Extraction connections: 2 x 200 mm, 1 x 100 mm Required air pressure: 8 bar

Condition: as good as new (ex-display), Year of construction: 2019, bore capacity in steel (diameter) 35,0 mm bore capacity in cast iron 40,0 mm threading M 24 in Stahl throat 320 mm morse taper 4 MK bore stroke 160 mm turning speeds 65 - 3250 U/min table: 500 x 420 mm throat 320 mm weight 375 kg Fjdpoxaabrefx Am Aspk range L-W-H 600 x 870 x 2.170 mm 2019 showroom model (!!) Approx. 1 hour of operation Special price on request Furnishing: - Infinitely variable speed, ideal for - Set the desired cutting speed. - Automatic tool ejector and thread cutting device as standard - Electromechanical drilling feed, adjustable from 0.1 - 0.3 mm / rev - Solid gray cast iron table with rotating and swiveling support surface - T-slots in the machine base enable high workpieces to be clamped - Guaranteed concentricity 0.02 mm, measured in the quill - Hardened and ground gears ensure smooth running - Adjustable drilling depth stop with an easily readable scale Scope of delivery: - Key chuck 1 - 13 mm / B 16 - Drill chuck arbor MK 4 / B 16 - Reducing sleeve MT 4/3, MT 4/2 - coolant device - Thread cutting device - Electromagnetic spindle feed - Automatic tool ejector - LED machine light - First filling with Shell Tellus 46 - Digital speed display - Height-adjustable protective cover

Condition: excellent (used), IM Very good condition. Fodjzkvh Nepfx Am Aspk

Condition: good (used), Year of construction: 1990, machine/vehicle number: 13616, Offer 26182 Technical data: - Drilling capacity in steel ST 60 approx. 75 mm - Drilling capacity for enlarging holes approx. 90 mm - Thread cutting up to approx. M 60 - Drill spindle mount MK 5 - Drill spindle stroke 380 mm - Overhang min. / max. approx. 420 / 2000 mm - Column diameter approx. 500 mm - Stroke of the arm approx. 1380 mm - Min. / max. distance: - Spindle - base plate approx. 370 - 1750 mm - Base plate clamping surface approx. 1100 - 2300 mm - 12 spindle speeds 19 - 1900 rpm - 9 feed rates 0.09 - 0.75 m/rev - Drill spindle drive 400 V / 10 kW - E - Central clamping system - Coolant system - T-slot table Fjdpfeztp Dijx Am Ajpk - Various chucks + drills - Space requirement approx. W 1400 x H 3400 x D 3600 mm - Weight approx. 8000 kg

Condition: used, Year of construction: 2017, bore capacity in steel (diameter) 40 mm throat 285 mm bore stroke 160 mm Spindle Speed 150-2.000 U/min. spindle taper MK4 column diameter 115 mm total power requirement 1,5/2,2 kW weight of the machine ca. 275 kg dimensions of the machine ca. 1000x700x1900 mm Fodpfx Aezpzdaem Aopk

Condition: good (used), Code: 0462 Brand: SERRMAC Model: V 22 - CE Standard Pillar drill with swivel table for machine shops, workshops, carpentry shops, and other applications - CE Standard Fsdpfx Aszp Exzom Aepk Technical data: Sturdy construction Drilling capacity in steel diameter 22 mm Spindle taper cm2 Spindle stroke 90 mm Column diameter 98 mm Distance from column to spindle center 201 mm Table 350 x 250 mm Spindle speed 255/380/420/560/630/660/950/990/1090/2380/2590/3850 rpm Motor power 0,55 Kw Overall dimensions mm 400 x 750 x 1700 h Weight kg 170

Condition: used, Year of construction: 1978, machine/vehicle number: 78004, functionality: fully functional, type of input current: three-phase, We are offering this used Csepel 12UH/1600 radial drilling machine, year of manufacture 1978. Model: 12UH/1600 Serial number: 78004 Power type: 3~ Fpedpfeyh Uaqox Am Ask Wiring diagram no.: 358000 If you have any questions or require further information, please feel free to send us a message or give us a call.

Condition: excellent (used), Year of construction: 2010, Maximum drilling diameter: 20 - 252 mm Drilling diameter in concrete: 20 - 202 mm Fjdjznvrpopfx Am Aopk Number of speeds: 3 Electrical connection: 220 V, 2300 W Weight: 7.4 kg

Condition: used, High-performance drilling machine ALZMETALL, type Abomat 20 Production drilling machine Serial No. 452, Year of manufacture 1996 Fedpfoikrtqsx Am Aopk Drilling capacity in steel ST 60: 25 mm Drilling capacity in cast iron GG 20: 30 mm Spindle mount: SK 40 - M16 Overhang: 280 mm Drill slide stroke: 500 mm Distance from spindle nose to table: 185 - 685 mm Table size: 490 x 400 mm Spindle speed: 50 - 500 rpm, infinitely variable Drill slide feed: 20 - 224 mm/min, infinitely variable Drill slide rapid traverse: 4.5 m/min Feed motor power: 0.18 kW Rapid traverse motor power: 0.75 kW Drill spindle motor power: 1.1 kW (speed 1000 rpm) Mains connection: 400 volts, 50 Hz - Spindle speed infinitely variable via frequency inverter - Drill slide feed infinitely variable via frequency inverter - 2 operating modes: setup and automatic operation - Central lubrication - Control cabinet on the back of the machine - Swiveling control panel - Mounted on a steel plate (700 x 650 x 40 mm) with precise height adjustment Space requirement L x W x H: 1200 x 700 x 2530 mm Weight: approx. 1000 kg Good condition

Condition: good (used), Year of construction: 1987, travel distance X-axis: 11,500 mm, travel distance Y-axis: 4,500 mm, travel distance Z-axis: 2,000 mm, spindle diameter: 200 mm, x-travel 11,500 mm y-travel 4,500 mm w-axis 1,600 mm z-axis 2,000 mm Spindle diameter 200 mm Rotary table 3,000 x 4,000 mm Fodpfx Amoztp Ius Aepk Bed length of rotary table 4,600 mm Tool holder SK50 Workpiece weight on rotary table 80 t Total power requirement 83 kW Additional information incl. 15 plates

Condition: good (used), Year of construction: 1983, travel distance X-axis: 6,000 mm, Spindle diameter: 200 mm Machining width: 6000 mm Machining height: 3150 mm Max. machining depth: 1985 mm Slide cross section: 530 x 550 mm Table load capacity: 20 t Fodpfx Aeztp Ibsm Aopk Plate field size: 11200 x 5550 mm Tool holder: SK 60 Machine weight approx.: 173 t Additional information: - Additional equipment: large and small angular heads - Listing No.: 22979 - The table is model S20 MP, size: 2200 x 2500 mm - The machining width on the X-axis of the machine is 6000 mm - Including 6 plates measuring 5600 mm x 1850 mm

Condition: good (used), Year of construction: 1999, Drilling capacity in steel (diameter): 60 mm / MK5 Quill stroke: 310 mm Spindle speed: 28...2500 rpm Fpjdeztp Hwjpfx Am Ask Table size: 1470 x 986 mm Total power requirement: 4 kW Machine weight approx.: 4.6 t
